Page 1
INSTRUCTION MANUAL
MANUAL DE INSTRUCCIONES
Model Numbers / No. de Modelos: VFR14PS-IS
FREEZER / REFRIGERATOR
CONGELADOR / REFRIGERADOR
BEFORE USE, PLEASE READ AND FOLLOW ALL SAFETY RULES AND OPERATING
INSTRUCTIONS.
La sección en español empieza en la página 15.
Avanti has a policy of continuous improvement on its products and reserves the right to change materials and specifications
without notice.
Avanti Products, A Division of the Mackle Co., Inc.
P.O. Box 520604 - Miami, Florida 33152
www.avantiproducts.com
Page 2
THIS PAGE LEFT BLANK INTENTIONALLY
2
Page 3
TABLE OF CONTENTS
Refrigerator Safety 4
Important Safeguides 5
Help Us Help You 6
Parts and Features 7
Important Safety Instructions 8
Installation Instructions 8
Before Using Your Appliance 8
Installation of Your Appliance 8
Electric al Connection 9
Operating Your Appliance 10
Temperature Control 10
Care and Maintenance 10
Defrosting Your Appliance 10
Cleaning Your Appliance 11
Power Failure 11
Vacation Time 11
Moving Your Appliance 11
Energy Saving Tips 11
Reversing the Door Swing of Your Appliance 11
Troubleshooting Guide 12
Service for Your Appliance 13
Wiring Diagram 13
Your Avanti Products Warranty 14
Instrucciones en Español 15 – 16
Registration Information and Registration Card 19
3
Page 4
REFRIGERATOR SAFETY
Your safety and the safety of others are very important.
We have provided many important safety messages in this manual for your appliance. Always read
and obey all safety messages.
This is the Safety Alert Symbol. This symbol alerts you to potential hazards that
can kill or injure you and others. All safety messages will follow the Safety
Alert Symbol and either the words ” DANGER”, “WARNING” or “C AUTION”.
Danger means that failure to heed this
safety statement may result in severe
personal injury or death.
Warning means that failure to heed this
safety statement may result in extensive
product damage, serious personal injury, or
death.
Caution means that failure to heed this
safety statement may result in minor or
moderate personal injury, property or
equipment damage.
All safety messages will alert to know what potential hazard is, tell you how to reduce the chance of
injury, and let you know what can happen if the ins tructions are not followed.
4
Page 5
IMPORTANT SAFEGUIDES
Before the refrigerator is used, it must be properly positioned and installed as
described in this manual,so read the manual carefully. To reduce the risk of fire,
electrical shock or injury when using the refrigerator, follow basic precaution,
including the following:
• Plug into a grounded 3-prong outlet, do not remove grounding prong, do not use an adapter, and
do not use an extension cord.
• It is recommended that a separate circuit, serving only your refrigerator be provided. Use
receptacles that cannot be turned off by a switch or pull chain.
• Never clean refrigerator parts with flammable fluids. These fumes can create a fire hazard or
explosion. And do not store or use gasoline or other flammable vapors and liquids in the vic i nity of
this or any other appliance. The fumes can create a fire hazard or explosion.
• Before proceeding with cleaning and maintenance operations, make sure the power line of the
unit is disconnected.
• Do not connect or disconnect the electric plug when your hands are wet.
• Unplug the refrigerator or disconnect power before cleaning or servicing. Failure to do so can
result in electrical shock or death.
• Do not attempt to repair or replace any part of your refrigerator unless it is specifically
recommended in this manual. All other servicing should be referred to a qualified technician.
FOLLOW WARNING CALL OUTS BELOW ONLY WHEN APPLICABLE T O YOUR MODEL
• Use two or more people to move and install refrigerator. Failure to do so can result in back or
other inju ry.
• To ensure proper ventilation for your refrigerator, the front of the unit must be completely
unobstructed. Choose a well-ventilated area with temperatures above 60°F (16
90°F (32°C). This unit must be installed in an area protected from the element, such as wind, rain,
water spray or drips.
• The refrigerator should not be located next to ovens, grills or other sourc es of high heat.
• The refrigerator must be installed with all electrical, water and drain connecti ons in accordance
with state and local codes. A standard electrical supply (115 / 120 V AC, 60 Hz), properly
grounded in accordance with the National Electrical Code and local codes and ordinances is
required.
• Do not kink or pinch the power supply cord of refrigerat or.
• The fuse (or circuit break er ) size should be 15 amperes.
• It is important for the refrigerator to be lev eled in order to work properly. You may need to make
several adjustments to level it.
• All installation must be in accordance with local plumbing code requirements.
• Make certain that the pipes are not pinched or kinked or damaged during installations.
• Check for leaks after connection.
• Never allow children to operate, play with or crawl inside the refrigerato r.
• If you use the drainage container, you must set the drain select switch to OFF or the water can
overflow fr om the drainage container
• Although the unit has been tested at the factory, due to long-term transit and storage, the first
batch of cubes must be discarded.
• Do not use solvent-based cleaning agents of abrasives on the interior. These cleaners may
damage or discolor the interior.
°
C) and below
5
Page 6
• Do not use this apparatus for other than its intended purpose.
HELP US HELP YOU...
Read this guide carefully.
It is intended to help you operate and maintain
your new unit properly.
Keep it handy to answer your questions.
If you don't understand something or you need
more assistance, please call:
Avanti Customer Service
800-220-5570
Keep proof of original purchase d ate (such as
your sales slip) with this guide to establish the
warranty period.
CAUTION:
THIS UNIT IS NOT DESIGNED
FOR THE STORAGE OF
MEDICINE OR OTHER MEDICAL
PRODUCTS.
IF YOU NEED SERVICE
We're proud of our service and want you to be
pleased. If for some reason you are not happy
with the service you receive, here are some
steps to follow for further assistance.
FIRST, co ntact the people who s erviced your
unit. Explain why you are not pleased. In most
cases, this will solve the problem.
Write down the model and serial numbers.
You'll find them on a plate located on the rear
outside wall of the unit.
Please write these numbers here:
____________________________________
Date of Purchase
____________________________________
Model Number
____________________________________
Serial Number
Use these numbers in any correspondence or
service calls concerning your unit.
If you received a damaged unit, immediately
contact the dealer (or builder) that sold you the
unit.
Save time and money. Before you call for
service, check the Troubleshooting Gui de. It
lists caus es of minor operating proble m s that
you can correct yourself.
NEXT, if you are still not pleased, write all the
details, including your telephone number, and
send it to:
Customer Service
Avanti Products
10880 NW 30 Street
Miami, FL 33172 USA
6
Page 7
PARTS & FEATURES
1 Leveling Leg
2 Removable Plast i c Tray
3 Temperature Control Knob
4 Removable Wire Shelf (Total 1)
5 Upper Hinge with Plastic Cover
6 Reversible Door with Integrated Handle
7
Page 8
IMPORTANT SAFETY INSTRUCTIONS
WARNING
• Read all instructions before using the refrigerator.
• DANGER or WARNING: Risk of child entrapment.
Child entrapment and suffocation are not problems of the past. Junked or
abandoned refrigerators are still dangerous. . . even if they will “just sit in the
garage a few days.”
• Before you throw away your old refrigerator: Take off the doors. Leave the
shelves in place so that children may not easily climb inside.
• Never allow children to operate, play with, or crawl inside the refrigerator.
• Never clean refrigerator parts with flammable fluids. The fumes can create a fire
hazard or explosion.
• Do not store or use gasoline or any other flammable vapors and liquids in the vicinity
of this or any other refrigerator. The fumes can create a fire hazard or explosion.
-Save these instructions-
To reduce the risk of fire, electrical shock,
or injury when using your appliance, follow
these basic precautions:
INSTALLATION INSTRUCTIONS
Before Using Your Unit
• Remove the exterior and interior packing.
• Check to be sure you have all of the following parts:
• 1 Wire Shelf
• 1 Plastic Bottom Tray
• 1 Instruction Manual
• Before connecting the unit to the power source, let it stand upright for approximately 2 hours.
This will reduce the possibility of a malfunction in the cooling system from handling during
transportation.
• Clean the interior surface with lukewarm water using a soft clot h.
Installing Your Unit
• This appliance is designed to be free standing only, and should not be recessed or built-in.
• Place your unit on a floor that is strong enough to support the unit when it is fully loaded. To
level your unit, adjust the leveling legs at the bottom of the unit.
• Allow 5 inches of space between the back and sides of the unit, which allows the proper air
circulation to cool the compressor and condenser.
• Locate the unit away from direct sunlight and sources of heat (stove, heater, radiator, etc.).
Direct sunlight may affect the acrylic coating and heat sources may increase elec trical
consumption. Extreme cold ambient temperatures may als o cause the unit not to perform
properly.
• Avoid locating the unit in moist areas.
• Plug the unit into an exclusive, properly installed-grounded wall outlet. Do not under any
circumstances cut or remove the third (ground) prong f r om the power cord. Any questions
concerning power and/or grounding should be directed toward a certified electrician or an
authorized Avanti Products service center.
• After plugging the appliance into a wall outlet, allow the unit to cool down for 2-3 hours before
placing food in the refrigerator compartment.
8
Page 9
ELECTRICAL CONNECTION
Improper use of the grounded plug can result in the risk of electrical shock. If the power cord is
damaged, have it replaced by an authorized Avanti Products service center.
Warning
This appliance should be properly grounded for your safety. The power cord of this appliance is
equipped with a three-prong plug which mates with standard three prong wall outlets to minimize the
possibility of electrical shock.
Do not under any circumstances cut or remove the third ground pro ng from the power cord supplied.
For personal safety, this appliance must be properly grounded.
This appliance requires a standard 115/120 Volt AC / 60Hz electrical ground outlet with three-prong.
Have the wall outlet and circuit checked by a qualified electrician to make sure the outlet is properly
grounded. When a standard 2-prong wall outlet is encountered, it is your responsibility and obligation
to have it replaced with a properly grounded 3-prong wall outlet.
The cord should be secured behind the appliance and not left exposed or dangling to prevent
accidental injury.
The appliance should always be plugged into it s own individual electrical outlet which has a v oltage
rating that matches the rating label on the appliance. This provides the best performance and also
prevent overloading house wiring circuits that could cause a fire hazard from overheated. Never
unplug the appliance by pulling the power cord. Always grip the plug firmly and pull straight out from
the receptacle. Repair or replace immediately all power cords that have become frayed or otherwise
damaged. Do not use a cord that shows cracks or abrasion damage along its length or at either end.
When moving the appliance, be careful not to damage the power cord.
EXTENSION CORD
Because of potential safety hazards under certain conditions, it is strongly recommended that you do
not use an extension cord with this appliance. However, if you must use an extension cord it is
absolutely necessary that it be a UL/CUL-Listed, 3-wire grounding type appliance extension cord
having a grounding type plug and outlet and that the electrical rating of the cord be 115 volts and at
least 10 amperes.
SURGE PROTECTOR
Most electrical appliances use a series of electric control boards to operate. These boards are very
susceptible to power surges and could be damaged or destroyed.
If the appliance is going to be used in an area or if your city / country is prone t o power surges /
outages; it is suggested that you use a power surge protector for all electrical devices / appliances
you use. The surge protector that you select must have a surge block high enough to protect the
appliance it is connected to. If you have any quest ions regarding the type and size of surge protector
needed contact a licensed electrician in your area.
Damages due to power surges are not considered a manufacture r covered defect and will void your
product warranty.
9
Page 10
OPERATING YOUR UNIT
Setting the Temperature Control
• Your unit is designed to be used either as a freezer or a
refrigerator. You can adjust the temperature c ontrol to select the
refrigerator or freezer function according to the purpose of use.
• To use as a refrigerator, you may set temperature accordingly by
turning the dial clockwise from the “OFF” position. The
temperature control is marked “FRIDGE” with a scale showing
minimum cooling to the maximum cooling position.
• To use as a freezer, turn the temperature control clockwise to the
position marked “MAX” in area marked “FREEZER”, after 24 hours, adjust the control knob the
position that best suits your needs.
NOTE:
• Turning the temperature control to “OFF” position stops the cooling cycle but does not shut off
the power to the unit.
• If the unit is unplugged, has lost power, or is turned off, you must wait 3 to 5 minutes before
restarting the unit. If you attempt to restart before this time delay, the unit will not start.
CARE AND MAINTENANCE
Defrosting Your Unit
• Defrost the unit when the frost accumulated on the evaporator is about 5mm (1/5 inch) thick. Set
the thermostat dial to “OFF” position.
• Remove frozen or perishable foods from the chiller compartment and place it in a cooler to
protect the food.
• Durin g the defrost cycle, the ice will melt, place a plate or other type of container below the
evaporator to collect the water.
• To remove the water, remove the collection container under the evaporator. Use a sponge or
towel to pick up the melting ice off the unit floor.
• Dry the water collection container and place back under the chiller compartment. Defrosting
usually takes a few hours. After defrosting, return the thermostat dial to the desired position. To
defrost quickly remove all foods from the unit and leave the door open. Never use a knif e or other
metal instrument to scrape ice/frost from the evaporator.
CAUTION:
Do not use boiling water because it may damage the plastic parts. In addition, never use a
sharp or metallic instrument to remove frost as it may damage the cooling system and will
void the warranty. We recommend using a plastic scraper.
10
Page 11
Cleaning Your Unit
• Turn the temperature control to "OFF", unplug the unit, and remove the food and shelf.
• Wash the inside surfaces with a warm water and baking soda solution. The solution should be
about 2 tablespoons of baking soda to a quart of water.
• Wash the shelf with a mild detergent solution.
• The outside of the unit should be cleaned with mild detergent and warm water.
• Wring excess water out of the sponge or cloth befo re cleaning the area of the controls, or any
electrical parts.
• Wash the outside cabinet with warm water and mild liquid detergent. Rinse well and wipe dry with
a clean soft cloth.
CAUTION:
Failure to unplug the unit could result in electrical shock or personal injury.
Power Failure
Most power failures are corrected within a few hours and should not affect the temperature of your
unit if you minimize the number of times the door is opened. If the power is going to be off for a longer
period of time, you need to take the proper steps to protect your food.
Vacation Time
• Short vacations: Leave the unit operating during vacations of less than three weeks.
• Long vacations: If the appliance will not be used for several months, remove all food and unplug
the power cord. Clean and dry the interior thoroughly. To prevent odor and mold gro wth, leave
the door open slightly: blocking it open if necessary.
Moving Your Unit
• Remove all the food.
• Securely tape down all loose items inside your unit.
• Turn the leveling legs up to the base to avoid damage.
• Tape the door shut.
• Be sure the unit stays secure in the upright position during transportation. Also protect the
outside of unit with a blanket, or similar item.
Energy Saving Tips
• The unit should be located in the coolest area of the room, away from heat producing appliances,
and out of the direct sunlight.
• Let hot foods cool to room temperature before placing in the unit. Overloading the unit forces the
compressor to run longer.
• Be sure to wrap foods properly, and wipe containers dry before placing them in the unit. This cuts
down on frost build-up inside the unit.
• Unit storage bin should not be lined with aluminum foil, wax paper, or paper toweling. Liners
interfere with cold air circulation, making the unit less efficient.
• Organize and label food to reduce door openings and extended searches. Remove as many
items as needed at one time, and close the door as soon as possible.
Reversing the Door Swing of Your Appliance
This appliance has the capability of the door opening from either the left or right side. The unit is
delivered to you with the door opening from the left side. Should you desire to reverse the opening
direction, please call customer service for reversal instructions.
11
Page 12
PROBLEMS WITH YOUR REFRIGERATOR ?
You can solve many common unit problems easily, saving you the cost of a possible service call. Try
the suggestions below to see if you can solve the problem before calling the servicer.
TROUBLESHOOTING GUIDE
PROBLEM POSSIBLE CAUSE
Unit does not operate.
Turns on and off frequently. The room temperature is hotter than normal.
Vibrations. Check to assure that the unit is level.
The unit seems to make too much noise.
The door will not close properly.
Not plugged in.
The circuit breaker tripped or a blown fuse.
The unit temperature control is set at “0FF” position.
A large amount of food has been added to the unit.
The door is opened too often.
The door is not closed completely.
The temperature control is not set correctly.
The door gasket does not seal properly.
The unit does not have the correct clearances.
The rattling noise may come from the flow of the
refrigerant, which is normal.
As each cycle ends, you may hear gurgling sounds
caused by the flow of refrigerant in your unit.
Contraction and expansion of the inside walls may
cause popping and crackling noises.
The unit is not level.
The unit is not level.
The door was reversed and not properly installed.
The gasket is dirty or bent.
The shelves, bins, or baskets are out of position.
12
Page 13
SERVICE FOR YOUR REFRIGERATOR
We are proud of our customer service organization and the network of professional service
technicians that provide service on your Avanti refrigerato rs. With the purchase of your Avanti unit,
you can be confident that if you ever need additional information or assistance, the Avanti Products
Customer Service team will be here for you. Just call us toll-free.
AVANTI PRODUCTS CUSTOMER SERVICES
Product Information
800-323-5029
Part Orders
800-220-5570
In-Home Repair Service
800-220-5570
Whatever your questions are about our products,
help is available.
You may order parts and accessories that will be
delivered directly to your home, by personal
check, money order, Master Card, or Visa.
An Avanti Products authorized service center will
provide expert repair service, scheduled at a time
that is convenient for you. Our trained servicers
know your refrigerator inside and out.
WIRING DIAGRAM
13
Page 14
YOUR AVANTI PRODUCTS
WARRANTY
WHAT IS COVERED – LIMITED ONE-YEAR WARRANTY
Avanti Products warrants that the product is free from defects in materials and/or workmanship for a period of
twelve (12) months from the date of purchase by the original owner. The foregoing timeline begins to run upon
the date of purchase, and shall not be stalled, tolled, extended, or suspended for any reason whatsoever unless
described in detail in the warranty document. For one year from the date of purchase by the original owner,
Avanti products will, at its option, repair or replace any part of the product which proves to be defective in
material or workmanship under normal use. Avanti Products will provide you with a reasonably similar product
that is either new or factory refurbished. During this period Avanti Products will provide all parts and labor
necessary to correct such defects free of charge, so long as the product has been installed and operated in
accordance with the written instructions in this manual. In rental or commercial use, the warranty period is 90
days. All Avanti appliances of 4.2 cubic feet capacity or less must be brought/sent to the appliance service
center for repair.
LIMITED SECOND THROUGH FIFTH YEAR WARRANTY
For the second through the fifth year from the date of original purchase, Avanti Products will provide a
replacement compressor free of charge due to a failure. You are responsible for the servic e labor and freight
charges. In rental or commercial use, the limited compressor warranty is one year and nine months. Costs
involved to move the product to the service center and back to the user’s home, as maybe required, are the
user’s responsibility.
WARRANTY EXCLUSIONS / WHAT IS NOT COVERED:
The warranty coverage described herein exclu des all defects or damage that are not the direct fault of Avanti
Products, including without limitation, one or more of the follow ing:
Staple your sales receipt here. Proof of original
purchase date is needed to obtain service under
warranty.
• A failure to comply with any applicable state, local, city, or county electrical, plumbing and/or building codes,
regulations, or laws, including failure to install the product in strict conformity with local fire and building codes
and regulations.
•
Any external, elemental and/or environmental forces and factors, including without limitation, rain, wind, sand,
floods, fires, mud slides, freezing temperatures, excessive moisture or extended exposure to humidity,
lightning, power surges, structural failures surrounding the appliance, and acts of God.
• Content losses of food or other content due to
spoilage.
•
Incidental or consequential damages
•
Parts and labor costs for the following will not be
considered as warranty:
•
Evaporator doors, door springs, and/or frames.
•
Inner door panels, door shelves, door rails,
and/or door supports.
•
Chest freezer lid liners.
•
Vegetable crispers.
Light bulbs and/or plastic housing.
•
•
Plastic cabinet liners.
•
Punctured evaporator that void s th e wa rra nty on
the complete sealed system.
In no event shall Avanti Products have any liability or responsibility whatsoever for damage to surrounding
property, including cabinetry, floors, ceilings, and other structures and/or objects around the product. Also
excluded from this warranty are scratches, nicks, minor dents, and other cosmetic damages on external surfaces
and exposed parts; Products on which the serial numbers have been altered, defaced or removed; service visit s
for customer education, or visits where there is nothing wrong with the product; correction of installation problems
(you are solely responsible for any structure and setting for the product, including all electrical, plumbing and/or
other connecting facilities, for proper foundation/flooring, and for any alteration s including without limitation
cabinetry, walls, floors, shelving etc., as well as the resetting of breakers or fuses.
OUT OF WARRANTY PRODUCT
Avanti Products is under no obligation, at law or otherwise, to provide you with any concessions, including
repairs, pro-rates, or product replacement, once this warranty has expired.
• Shipping and handling costs associated with the
replacement of the unit.
• Repairs performed by unauthorized servicers.
• Service calls that are related to external problems,
such as abuse, misuse, inadequate electrical
power, accidents, fire, flo ods, or any other acts of
God.
• Failure of the product if it is used for other than it
intended purpose.
• The warranty does not apply outside the
Continental USA.
• Surcharges including but not limited to, any after
hour, weekend, or holiday servic e call s , tolls, ferry
trip charges, or mileage expense for servi ce call s to
remote areas.
WARRANTY – REFRIGERATION - COMPRESSOR
14
Page 15
INSTRUCCIONES EN ESPAÑOL
INSTALACION
Retire los accesorios de empaque (plásticos protectores, cartón y tiras engomadas). Limpie el
exterior con un trapo suave y seco, y el int erior con un trapo húmedo y tibio.
UBICACION
1. Seleccione un lugar con un piso firme y nivelado.
2. Su refrigerador requiere ventilación. Deje un espacio mínimo de 5” hacia arriba y espacio
suficiente en el respaldo para permitir la circulación de aire.
3. Ev ite luz directa del sol o calor. La luz directa del sol puede afectar la capa de pintura. Las
fuentes de calor en su proximidad causarán un consumo mayor de electricida d.
4. Para un mejor desempeño, nivele el refrigerador utilizando las patas ajustables o tornillos
nivelador es. Para verific a r el ni v e l , ab r a l a puerta hasta la mitad, debe regr esar sola.
INSTRUCCIONES PARA LA CONEXION A TIERRA
Este aparato electrodoméstico debe estar conectado a t ierra. En caso de un cortocircuito eléctrico, la
conexión a tierra reduce el riesgo de choque eléctrico proporcionando un cable de escape para la
corriente eléctrica. Este aparato viene equipad o con un cordón que posee un cable a tierra con un
enchufe de conexión a tierra. Este enchufe debe estar conectado en un tomacorriente instalado
correctamente y conectado a tierra.
ADVERTENCIA
El uso inadecuado del enchufe de conexión a tierra puede resultar en un ries go de choque eléctrico.
Consulte con un electricista si no comprende bien las instrucciones de conexión a tierra o si existe
alguna duda sobre si el aparato está conectado a tierra correctamente.
NO USE UN CORDON DE EXTENSION ELECTRICA
Use un tomacorriente de pared exclusivo. No conecte su refrigera dor a cordones de prolongación
eléctrica o junto a cualquier otro electrodoméstico en el mismo tomacorrient e de pared.
COMO AJUSTAR EL CONTROL DE TEMPERATURA
Para usar como refrigerador:
La primera vez que encienda la unidad, gire el control de temperatura hacia la derecha, hasta que la
posición máxima de enfriamiento de la sección de “FRIDGE” este alineada debajo del punto rojo.
Después de 24 horas, ajuste el control de temperatura a su gusto.
Para usar como congelador:
La primera vez que encienda su unidad, gire el control de t emperatura hacia la derecha, hasta que la
posición “MAX” de la sección “FREEZER” quede alinead a debajo del punto rojo. Después de 24
horas, ajuste el control de temperatura a su gusto; el punto medio ent re “MIN” y “MAX” será la mas
adecuada para uso en la casa u oficina.
ADVERTENCIA IMPORTANTE:
Un refrigerador vacío es una atracción muy peligrosa para los niños. Quite los sellos magnéticos,
puertas o cerraduras de todo electrodoméstico que no esté en uso, es tambien aconsejable remover
o quitar puertas al momento de desechar su refrigerador.
OPERACION
Enchufe el cable a la toma de corriente, que debe ser 115-120v A/C, 10 AMP ó más. Para evitar
vibraciones, este equipo debe estar bien nivelado. Para encender el refrigerador, gire el control de
temperatura a la posición que corresponda al enfriamiento deseado.
15
Page 16
CUIDADOS EN LOS PERIODOS DE AUSENCIA
• Para cortos períodos de aus encia (menos de 21 días) el congelador podrá quedar funcionando.
Coloque el botón de control de temperaturas en la posición mínima.
• En períodos de ausencia más largos, se aconseja dejar el refri gerador limpio y desconectado.
• Saque todo lo que tenga adentro del refrigerador y haga el deshielo y la limpieza general.
También retire la bandeja del congelador, limpie bien y séquela internamente.
• Deje la puerta entreabierta para que penetre el aire y as í evitar la formación de olores.
ECONOMIA DE ENERGIA
• Evite dejar por mucho tiempo la puerta abierta.
• Evite aperturas frecuentes de la puerta.
• Nunca coloque alimentos calientes dentro del refrigerador. Espere que estén a una temperatura
ambiental.
• Coloque el botón de control de temperaturas en la posición adecuada.
SI USTED SE VA DE VACACIONES POR UN PERIODO DE 30 DIAS O MAS
Saque todos los artículos del refrigerador-congel ador.
•
• Desconecte el refrigerador del tomacorriente y limpie el refrigerador bien, incluyendo la bandeja
del congelador.
• Deje la puerta abierta para evitar la formación de olores, condensación o moho.
SI USTED SE MUDA
• Desconecte el refrigerador del tomacorriente y limpie el refrigerador bien, incluyendo la bandeja
del congelador.
• Saque todas las partes movibles y empaquételas para que no se muevan durante la
transportación.
• Cierre la puerta del refrigerador y séllela con cinta adhesiva.
• Asegúrese que el refrigerador va parado durante el viaje y cúbralo con una frazada.
16
Page 17
THIS PAGE LEFT BLANK INTENTIONALLY
17
Page 18
THIS PAGE LEFT BLANK INTENTIONALLY
18
Page 19
Registration Information
Thank you for purchasing this fine Avanti product. Please fill out this form and return it to the
following address within 100 days from the date of purchase and receive these important benefits:
Avanti Products, A Division of The Mackle Co ., Inc.
P.O.Box 520604 – Miami, Florida 33152
Protect your product:
We will keep the model number and date of purchase of your new Avanti product on file to
help you refer to this information in the event of an insurance claim such as fire or theft.
Promote better products:
We value your input. Your responses will help us develop products designed to best meet
your future needs.
-------------------------------------------------------(detach here)-------------------- ------------------------------------------
---
Avanti Registration Card
Name Model # Serial #
Address Date Purchased Store / Dealer Name
City State Zip E-mail Address
Area Code Phone Number Occupation
Did You Purchase An Additional Warranty As your Primary Residence, Do You:
Extended Own Rent
None
Your Age:
Reason for Choosing This Avanti Product:
Please indicate the most important factors
That influenced your decision to purchase
this product:
Price
Product Features
Avanti Reputation
Product Quality
Salesperson Recommendation
Other: ___________________
Friend / Relative Recommendation
Warranty
Other: ___________________
Comments:
under 18 18-25 26-30
31-35 36-50 over 50
Marital Status:
Married Single
Is This Product Used In The:
Home Business
How Did You Learn About This Product:
Advertising
In-Store Demo
Personal Demo
19
Page 20
VFR14PS VER: 1.0 – 02/28/12 PRINTED IN CHINA
20
Loading...
