Avanti EWC18N2PD Instruction Manual

MANUAL DE INSTRUCCIONES

Model Number / No. de Modelo:

WINE CHILLER / VINERA

INSTRUCTION MANUAL

EWC18N2PD

(Image may vary)

BEFORE USE, PLEASE READ AND FOLLOW ALL SAFETY RULES AND OPERATING
INSTRUCTIONS.

La sección en español empieza en la página 15.

Avanti Products has a policy of continuous improvement on its products and reserves the right to change materials and
specifications without notice.

Avanti Products LLC

P.O. Box 520604 - Miami, Florida 33152

www.avantiproducts.com

THIS PAGE LEFT BLANK INTENTIONALLY

2

TABLE OF CONTENTS

Appliance Safety

4

Important Safeguides

5

Help Us Help You

6

Parts and Features

7

Important Safety Instructions

8

Installation Instructions

8

Before Using Your Wine Chiller

8

Installation of Your Wine Chiller

8

Electrical Connection

9

Extension Cord

9

Operating Your Wine Chiller

10

Temperature Control

10

Storage Capacity

11

Interior Light

11

Care and Maintenance

11

Cleaning Your Wine Chiller

11

Power Failure

11

Moving Your Wine Chiller

11

Energy Saving Tips

12

Troubleshooting Guide

12

Service for Your Appliance

13

Wiring Diagram

13

Your Avanti Products War rant y

14

Instrucciones en Español

15 – 18

Registration Information and Registration Card

19

3

APPLIANCE SAFETY

Your safety and the safety of others are very important.

We have provided many important safety messages in this manual and on your appliance. Always
read and obey all safety messages.

This is the Safety Alert Symbol. This symbol alerts you to potential hazards that

can kill or injure you and others. All safety messages will follow the Safety
Alert Symbol and either the words “DANGER”, “WARNING” or “CAUTION”.

Danger means that failure to heed this

safety statement may result in severe
personal injury or death.

Warning means that failure to heed this

safety statement may result in extensive
product damage, serious personal injury, or
death.

Caution means that failure to heed this

safety statement may result in minor or
moderate personal inj ury, or property or
equipment damage.

All safety messages will alert you do what the potential hazard is, tell you how to reduce the chance of
injury, and let you know what can happen if the instruc tions ar e not foll o wed.

4

IMPORTANT SAFEGUIDES

Before the appliance is used, it must be properly positioned and installed as

described in this manual, so read the manual carefully. To reduce the risk of fire,
electrical shock or injury when using the appliance, follow basic precaution,
including the following:

• Plug into a grounded 3-prong outlet, do not remove grounding prong, do not use an adapter, and
do not use an extension cord.

• Replace all panels before operating.

• It is recommended that a separate circuit, serving only your appliance be provided. Use

receptacles that cannot be turned off by a switch or pull chain.

• Never clean appliance parts with flammable fluids. These fumes can create a fire hazard or
explosion. And do not store or use gasoline or other flammable vapors and liquids in the vicinity of
this or any other appliance. The fumes can create a fire hazard or explosion.

• Before proceeding with cleaning and maintenance operations, make sure the power line of the
unit is disconnected.

• Do not connect or disconnect the electric plug when your hands are wet.

• Unplug the appliance or disconnect power before cleaning or servicing. Failure to do so can result

in electrical shock or death.

• Do not attempt to repair or replace any part of your appliance unless it is specifically
recommended in this material. All other servicing should be referred to a qualified technician.

FOLLOW WARNING CALL OUTS BELOW ONLY WHEN APPLICABLE TO YOUR MODEL

• Use two or more people to move and install appliance. Failure to do so can result in injury.

• To ensure proper ventilation for your appliance, the front of the unit must be completely

unobstructed. Choose a well-ventilated area with temperatures above 60°F (16°C) and below
90°F (32°C). This unit must be installed in an area protected from the element, such as wind, rain,
water spray or drips.

• The appliance should not be located next to ovens, grills or other sources of high heat.

• The appliance must be installed with all electrical, water and drain connections in accordance with

state and local codes. A standard electrical supply (115 V AC only, 60 Hz), properly grounded in
accordance with the National Electrical Code and local codes and ordinances is required.

• Do not kink or pinch the power supply cord of appliance.

• The fuse (or circuit breaker) size should be 2.5 amperes.

• It is important for the appliance to be leveled in order to work properly. You may need to make

several adjustments to level it.

• Never allow children to operate, play with or crawl inside the appliance.

• Do not use solvent-based cleaning agents of abrasives on the interior. These cleaners may

damage or discolor the interior.

• Do not use this apparatus for other than its intended purpose.

5

CAUTION:

HELP US HELP YOU...

Read this guide carefully.

It is intended to help you operate and maintain
your new Wine Chiller properly.

Keep it handy to answer your questions.
If you don't understand something or you
need more assistance, please call:

Avanti Customer Service
800-220-5570

Keep proof of original purchase date (such as
your sales slip) with this guide to establish the
warranty period.

THIS WINE CHILLER IS NOT
DESIGNED FOR THE STORAGE
OF MEDICINE OR OTHER
MEDICAL PRODUCTS.

IF YOU NEED SERVICE

We're proud of our ser vice and want you to be
pleased. If for som e reason you are not happ y
with the service you receive, here are some
steps to follow for further assistance.
FIRST, contact the people who serviced your
Wine Chiller. Ex pla in wh y you are not ple ased.
In most cases, this will solve the problem.

Write down the model and serial numbers.

You'll find them on a plate located on the rear
outside wall of the Wine Chiller.

Please write these numbers here:

____________________________________
Date of Purchase

____________________________________
Model Number

____________________________________
Serial Number

Use these numbers in any correspondence or
service calls concerning your Wine Chiller.

If you received a damaged Wine Chiller,
immediately contact t he de aler (or bu ilder) that
sold you the Wine Chiller.

Save time and money. Before you call for
service, check the Troubleshooting Guide. It
lists causes of minor operating problems that
you can correct yourself.

NEXT, if you are still not pleased, write all the
details, including your telephone number, and
send it to:

Customer Servic e

Avanti Products
10880 NW 30 Street
Miami, FL 33172 USA

6

1

Cabinet

7

Upper Door Hinge w/ Cover

2

Shelves (Total 4)

8

Glass Door

3

Cold Sink Fan

9

Gasket

4

Cold Sink Fan Cover

10

Zone Separator (Door)

5

Ventilation Holes

11

Zone Separator Unit

6

Leveling Legs

12

Bottom Hinge

PARTS & FEATURES

7



To reduce the risk of fire, electrical shock,
these basic precautions:

• Read all instructions before using the Wine Chiller.

-Save these instructions-

IMPORTANT SAFETY INSTRUCTIONS

WARNING

• DANGER or WARNING: Risk of child entrapment.
Child entrapment and suffocation are not problems of the past. Junked or abandoned
appliances are still dangerous . . . even if they will “just sit in the garage a few days”.

• Before you throw away your old Wine Chiller: Take off the door. Leave the
shelves in place so that children may not easily climb inside.

• Never allow children to operate, play with, or crawl inside the appliance.

• Never clean appliance parts with flammable fluids. The fumes can create a fire

hazard or explosion.

• Do not store or use gasoline or any other flammable vapors and liquids in the vicinity
of this or any other appliance. The fumes can create a fire hazard or explosion.

• Do not repair or replace any part of the wine chiller or attem pt any servicing unless
specifically recommended in the user-maintenance instructions or in published user­repair instructions. Replace the fuse with the same type.

INSTALLATION INSTRUCTIONS

 Before Using Your Wine Chiller

• Remove the exterior and interior packing.

• Check to be sure you have all of the following parts:

(4) Shelves
(1) Instruction manual

• Clean the interior surface with lukewarm water using a soft cloth.

 Installation of Your Wine Chiller

• This Wine Chiller is designed to be free standing installation only, and should not be recessed or
built-in (Fully recessed).

• Place your Wine Chiller on a surface that is strong enough to support it when it is fully loaded.

• Allow 5 inches of space between the back and sides of the wine chiller, which allows the proper

air circulation to cool the heat sink.

• Locate the Wine Chiller away from direct sunlight and sources of heat (stove, heater, radiator,
etc.). Direct sunlight may affect the acrylic coating and heat sources may increase electrical
consumption. Extreme cold ambient temperatures may also cause the unit not to perform
properly.

• This Wine Chiller uses superconductor refrigeration technology (no compressor) and is not
recommended for storage in hot areas like garages, warehouses or outdoors since it is designed
to operate at a maximum of 30 degrees below the ambient temperature.

• Avoid locating the unit in moist areas.

• Plug the Wine Chiller into an exclusive, properly installed-grounded wall outlet. Do not under any

circumstances cut or remove the third (ground) prong from the power cord. Any questions
concerning power and/or grounding should be directed toward a certified electrician or an
authorized Avanti Products s ervice cen ter .

• After plugging the Wine Chiller into a wall outlet, allow the unit to cool down for 2-3 hours before
placing any items in the compartment.

or injury when using your appliance, follow

8

Warning

 ELECTRICAL CONNECTION

Improper use of the grounded plug can result in the risk of electrical shock. If the power cord is
damaged, have it replaced by an authorized Avanti Products service center.

This appliance should be properly grounded for your safety. The power cord of this appliance is
equipped with a three-pron g plug whic h mates with standard three pron g wall outlets to m inimize the
possibility of electrical shock.

Do not under an y circumstances c ut or rem ove the third gro und prong f rom the power c ord supplied.
For personal safety, this appliance must be properly grounded.

This appliance requir es a standard 115/ 120 Volt AC ~/60Hz electrical ground outlet with three-prong.
Have the wall outlet and circuit check ed by a qualified electr ician to make s ure the outlet is properl y
grounded. When a s tandar d 2-prong wall outlet is encount ered, it is your respons ibility and oblig ation
to have it replaced with a properly grounded 3-prong wall outlet.

The cord should be secured behind the appliance and not left exposed or dangling to prevent
accidental injury.

The appliance shoul d always be plugged i nto its own individual electrical outlet which has a voltage
rating that matches the rating label on the appl iance. This provides the best p erformance and also
prevent overloading house wiring circuits that could cause a fire hazard from overheated. Never
unplug the applianc e b y pulling th e power cord. Alwa ys grip the plug f irm ly and pull str aight out fr om
the receptacle. Repair or r eplace immediatel y a ll power cords that ha ve become frayed or oth erwise
damaged. Do not use a cor d that shows crack s or abrasion dam age along its len gth or at either end .
When moving the appliance, be careful not to damage the power cord.

 EXTENSION CORD
Because of potential safety hazards under certain conditions, it is strongly recommended that you do
not use an extension cord with this appliance. However, if you must use an extension cord it is
absolutely necessary that it be a UL/CUL-Lis t ed, 3-wire grounding type appliance extension cord
having a grounding type plug and outlet and that the electrical rating of the cord be 300 volts and at
least 10 amperes.

 SURGE PROTECTOR
Most electrical appliances use a series of electric control boards to operate. These boards are very
susceptible to power surges and could be damaged or destroyed.

If the appliance is going to be used in an area or if your city / country is prone to power surges /
outages; it is suggested that you use a power surge protector for all electrical devices / appliances
you use. The surge protector that you select must have a surge block high enough to protect the
appliance it is connected to. If you have any questions regarding the type and size of surge protector
needed contact a licensed electrician in your area.

Damages due to power surges are not considered a manufacturer covered defect and will void your
product warranty.

9

OPERATING YOUR WINE CHILLER

Red Wines

14º - 18º C

57– 64º F

Dry/White Wines

9º - 14º C

49 – 58º F

Rose Wines

10º - 11º C

51 – 53º F

Sparkling Wines

8º - 9º C

46 – 49º F

Upper Zone

8 º - 18º C

46 º – 64º F

Lower Zone

12 º - 18º C

54 º – 64º F

You can select temperature display setting from Fahrenheit to Celsius degree by
color in the temperature display window.

It is recommended you install the Wine Chiller in a place where the ambient temperature is between
23º-26ºC/ 72º-78ºF. If the ambient temperature is above or below recommended temperatures, the
performance of the unit may be affected. For example, placing your unit in extreme cold or hot
conditions may cause interior temperatures to fluctuate. The range of 8º-18ºC/46º-64ºF may not be
reached. The default temperature set at the factory is 12ºC / 54ºF.

Recommended Temperatures for Chilling Wine.

Temperature Ranges For Your Wine Chiller

 CONTROL PANEL

pushing this button approximately for 3 seconds. The degrees will appear in blue

 SETTING THE TEMPERATURE CONTROL
 Upper zone and bottom zone are each controlled separately

 Your Wine Cellar has been equipped with an “automatic” control panel lock, that will activate 12

seconds after the last time a button has been touched.

Push the and button simultaneously for 3 seconds to unlock the control panel. You will

hear a “BEEP” sound to alert you that the control is now active.

 You can set the temperature as you desire by pushing the

each zone. The temperature that you desire to set will increase 1ºF or 1ºC if you push the
button once, on the contrary the temperature will decrease 1ºF or 1ºC if you push the button
once.

button on the control panel for

10

 NOTE:

• Default Temperature Setting: 54ºF (This is the default temperature set at the factory).

• When you use the wine chiller for the first time or restart the wine chiller after having been shut off

for a long time, there could be a few degrees variance between the temperature you select and
the one indicated on the LED readout. This is normal and it is due to the length of the activation
time. Once the wine chiller is running for a few hours everything will be back to normal.

 Storage Capacity

You can place 18 standard bottles in this wine chiller.
Upper zone: 6 bottles
Bottom zone: 12 bottles

Many bottles may differ in size and dimensions. As such the actual number of bottles you may be able
to store may var y. Bottle capacities are approxim ate maximums when storing tr aditional Bordeaux
750ml bottles.

 Interior Light

You can turn the interior light ON or OFF by pushing the button marked with the “Light”
symbol. The light will be turned off automatically if it remains ON for 10 minutes. You have
to push the button marked with the “Light” symbol again and the light will turn back on.

CARE AND MAINT ENANCE

 Cleaning Your Wine Chiller

• UNPLUG the Wine Chiller, and remove all items including shelves.

• Wash the inside sur faces with a warm water and b aking soda solution. The so lution should be

about 2 tablespoons of baking soda to a quart of water.

• Wash the shelves with a mild detergent solution.

• Wring excess water out of the sponge or cloth when cleaning area of the controls, or any

electrical parts.

• Wash the outside cabinet with warm water and mild liquid detergent. Rinse well and wipe dry wi th
a clean soft cloth.

CAUTION
Failure to unplug the Wine Chiller could result in electrical shock or personal injury.

 Power Failure

• Most power failures are corrected within a few hours and should not affect the temperature of
your appliance if you minimize the number of times the door is ope ned . If the power is going to be
off for a longer period of time, you need to take the proper steps to protect your contents.

• Your wine chiller is designed to return to the factory default tem perature setting onc e power the
unit is plugged in or once the power has returned after an outage.

 Moving Your Wine Chiller

• Remove all bottles.

• Securely tape down all loose items (shelves) inside your appliance.

• Tape the door shut.

• Protect outside of appliance with a blanket, or similar item.

11

 Energy Saving Tips

PROBLEM

POSSIBLE CAUSE

Wine Chiller does not operate or cool.

Not plugged in.
The circuit breaker tripped or a blown fuse.

Control panel is locked

Push the and button simultaneously for

Wait for beep sound.

Wine Chiller is not cold enough.

Check the temperature control setting.

Abnormal voltage.

The light does not work.

Not plugged in.
The light button is “OFF”.

Vibrations.

Check to assure that the Wine Chiller is level.

The door will not close properly.

• The Wine Chiller sh ould be located in the coolest area of the room, away from heat producing
appliances, and out of the direct sunlight.

• One characteristic of superconductor units is the lengt h of time it req uires to recover from having
the door opened and shut frequently. It may be necessary to wa it longer for the temper ature to
return to its former level once the door has been op ened for too lon g. This is nor mal for this t ype
of unit.

PROBLEMS WITH YOUR WINE CHILLER?

You can solve many common Wine Chiller problems easily, saving you the cost of a possible service
call. Try the suggestions below to see if you can solve the problem before calling the servicer.

TROUBLESHOOTING GUIDE

3 seconds to unlock the control panel.

External environment may require a higher
setting.
The door is opened too often.
The door is not closed completely.
The door gasket does not seal properly.
The Wine Chiller does not have the correct
clearances.

The circuit breaker tripped or a blown fuse.

The Wine Chiller is not level.
The door was not properly installed.
The gasket is dirty.

The shelves are out of position.

12

SERVICE FOR YOUR WINE CHILLER

800-323-5029

help is available.

check, mone y order, Maste r Card, or Visa.

know your appliance inside and out.

Rated Voltage

115V

Rated Frequency

60Hz

Rated Input Power

140W

COOLING MODULE

We are proud of our customer service organization and the network of professional service
technicians that provide service on your Avanti appliances. With the purchase of your Avanti
appliance, you can have th e conf idence t hat if you ever need addit ional inf orm ation or as sistanc e, the
Avanti Products Customer Service team will be here for you. Just call us toll-free.

AVANTI PRODUCTS CUSTOMER SERVICES

Product Information

Whatever your questions are about our products,

Part Orders
800-220-5570

In-Home Repair Service
800-220-5570

TECHNICAL / ELECTRICAL SPECIFICATIONS

You may order parts and accessories that will be
delivered directly to your hom e b y personal

An Avanti Products authorized service center will
provide expert repair service, scheduled at a time
that is convenient for you. Our trained servicers

WIRING DIAGRAM

13

Staple your sales receipt here. Proof of original
warranty.

WHAT IS COVERED – LIMITED ONE-YEAR WARRANTY

center for repair.

WARRANTY EXCLUSIONS / WHAT IS NOT COVERED:

Products, including without limitation, one or more of the following:

•

lightning, power surges, structural failures surrounding the appliance, and acts of God.

•

• Shipping and handling costs associated with the

remote areas.

In no event shall Avanti Products have any liability or responsibility whatsoever for damage to surrounding

for customer education, or visits where there is nothing wrong with the product; correction of installation problems

cabinetry, walls, floors, shelving etc., as well as the resetting of breakers or fuses.

OUT OF WARRANTY PRODUCT

repairs, pro-rates, or product replacement, once this warranty has expired.

WARRANTY – REFRIGERATION – NON COMPRESSOR

YOUR AVANTI PRODUCTS

WARRANTY

Avanti Products warrants that the product is free from defects in materials and/or workmanship for a period of
twelve (12) months from the date of purchase by the original owner. The foregoing timeline begins to run upon
the date of purchase, and shall not be stalled, tolled, extended, or suspended for any reason whatsoever unless
described in detail in the warranty document. For one year from the date of purchase by the original owner,
Avanti products will, at its option, repair or replace any part of the product which proves to be defective in
material or workmanship under normal use. Avanti Products will provide you with a reasonably similar product
that is either new or factory refurbished. During this period Avanti Products will provide all parts and labor
necessary to correct such defects free of charge, so long as the product has been installed and operated in
accordance with the written instructions in this manual. In rental or commercial use, the warranty period is 90
days. All Avanti appliances of 4.2 cubic feet capacity or less must be brought/sent to the appliance service

The warranty coverage described herein excludes all defects or damage that are not the direct fault of Avanti

A failure to comply with any applicable state, local, city, or county electrical, plumbing and/or building codes,
regulations, or laws, including failure to install the product in strict conformity with local fire and building codes
and regulations.

purchase date is needed to obtain service under

• Any external, elemental and/or environmental forces and factors, including without limitation, rain, wind, sand,

floods, fires, mud slides, freezing temperatures, excessive moisture or extended exposure to humidity,

Content losses of food or other content due to
spoilage.

• Incidental or consequential damages

• Parts and labor costs for the following will not be

considered as warranty:

• Inner door panels, door shelves, door rails,

and/or door supports.

• Light bulbs and/or plastic housing.

• Plastic cabinet liners .

• Punctured evaporator that voids the warranty on

the complete sealed system.

replacement of the unit.

• Repairs performed by unauthorized servicers.

• Service calls that are related to external problems,

such as abuse, misuse, inadequate electrical
power, accidents, fire, floods, or any other acts of
God.

• Failure of the product if it is used for other than it
intended purpose.

• The warranty does not apply outside the
Continental USA.

• Surcharges including but not limited to, any after
hour, weekend, or holiday service calls, tolls, ferry
trip charges, or mileage expense for service calls to

property, including cabinetry, floors, ceilings, and other structures and/or objects around the product. Also
excluded from this warranty are scratches, nicks, minor dents, and other cosmetic damages on external surfaces
and exposed parts; Products on which the serial numbers have been altered, defaced or removed; service visits

(you are solely responsible for any structure and setting for the product, including all electrical, plumbing and/or
other connecting facilities, for proper foundation/flooring, and for any alterations including without limitation

Avanti Products is under no obligation, at law or otherwise, to provide you with any concessions, including

14

INSTRUCCIONES DE SEGURIDAD

ATENCION

INSTRUCCIONES PARA

LA CONEXION A TIERRA

Este aparato electrodoméstico debe estar conectado a tierra. En caso de un cortocircuito eléctrico, la
conexión a tierra reduce el riesgo de choque eléctrico proporcionando un cable a tierra con una
enchufe de conexión a tierra. Este enchufe debe estar conectado en un tomacorriente instalado
correctamente y conectado a tierra.

ADVERTENCIA – El uso inadecuado del enchufe de conexión a tierra puede resultar en un riesgo de
choque eléctrico. Consulte con un electricista o persona de reparaciones competente si no
comprenden bien las instrucciones de conexión a tierra o si existe alguna duda sobre si el aparato
esta conectado a tierra correctamente.

NO USE UN CORDON DE

PROLONGACION ELECTRICA

Use un tomacorriente de pared exclusivo. No conecte su vinera a cordones de prolongación eléctrica
o junto a cualquier otro electrodoméstico en el mismo tomacorriente de pared.

ADVERTENCIA IMPORTANTE:

Una vinera vacía es una atracción muy peligrosa para los niños. Saque todas las juntas,
pestillos, tapas o puerta de todo electrodoméstico que no esté en uso, o tome alguna
medida para asegurar que no presente peligro.

INSTRUCCIONES DE INSTALACION

Saque los embalajes exteriores, limpie bien el exterior con un paño suave seco, y el interior con un
paño húmedo y tibio. Evite colocar la vinera cerca de una fuente de calor, luz de sol directa, o lugar
húmedo.

Ubicación

1. Seleccione un lugar con su piso fuerte y nivelado.

2. Deje cinco pulgadas de espacio entre la parte posterior de la vinera y toda pared conti gua.

3. Las bodegas superconductores necesitan c ierto tiempo de rec uperación cuando la puerta se
abre y se deja abierta por mucho tiempo. Esto es normal para este tipo de unidad.

4. Evite la luz directa del sol o calor. La luz directa del sol puede afectar la capa de acrílico.
Las fuentes de calor en su proximidad provocarán un consumo mayor de electricidad.

5. Para un mejor desempeño, nivele la vinera utilizando las patas ajustables o tornillos
niveladores.

OPERACION

Para evitar vibraciones, el compartimiento interior deb e estar bien nivelado. La tem peratura variará
dependiendo de la cantidad de botellas almacenadas y la frecuencia con que se abre la puerta.

Cuando la vinera no se use por un período largo, desconecte el enchufe y deje la puerta entreabierta.

15

Conexión Eléctrica

ADVERTENCIA

EL USO INAPROPIADO DEL ENCHUFE A TIERRA PUEDE OCASIONAR RIESGO DE UN
CHOQUE ELECTRICO. SI EL CORDON SE DAÑASE, LLEVELO A UN CENTRO DE
SERVICIO AUTORIZADO POR AVANTI PRODUCTS PARA QUE SE REEMPLACE.

• Para su seguridad, esta vinera debe estar apropiadamente conectada a tierra. El cordón
eléctrico de esta vinera está equipado con un enchufe de tres puntas, el cual encaja
perfectamente en l os recep táculos/ enchufes d e pared de tres puntas estándar, para m inim izar la
posibilidad de un choque eléctrico.

• Bajo ninguna circunst ancia corte o retir e la tercera punta (c able a tierra) del enchufe del cordón
eléctrico.

• Nunca use un cable de extensión para conectar la unidad a la electricidad.

• Nunca use un adaptador con enchufe de solo 2 puntas.

• Si solo puede conectar la vinera a un receptáculo/en chufe de pared de 2 puntas, comuní quese

con un electricist a calif icado par a q ue r eem place ese r eceptácul o/enc hufe d e par ed p or uno de 3
puntas, de acuerdo con los códigos de electricidad aplicables.

• Esta vinera requiere un rec eptác ulo/ enchuf e de pared de tres puntas estándar de 115/120 voltios
a.c.~/60hz.

• Para prevenir cualqu ier daño físic o o lesión, el cor dón debe ser asegurado detrás de la vinera y
no estar expuesto o colgando.

Cable de Extensión

Debido al posible riesgo de seguridad causado bajo ciertas circunstancias, se recomienda
firmemente que no use un cable de ex tensión para est e electrodoméstic o. Sin embar go, si no tiene
otra opción más que usar un cable de ex t ens ión, asegúrese que es te s ea un c ab l e d e ex tensi ón par a
electrodomésticos que este listado bajo UL/CUL, que teng a enchufe y receptáculo para enchuf e de
tres puntas (cable a t ierra) y q ue la cap acidad del cordón eléctrico sea de 300 voltios y no m enos de
10 amperios.

Protector contra variaciones de corriente eléctrica (Surge Protector).

La mayoría de electrodomésticos utilizan una series de paneles de control para operar. Estos
paneles son muy susceptibles a las variaciones de corriente eléctrica, las cuales causan que estos se
dañen o destruyen.
Si vive en un área o c iudad done hay muchas v ariaciones de corriente o apagones, se recomienda
que utilice un protector co ntra variaciones de corriente par a todos los electrodom ésticos y aparatos
eléctricos. El protector que elija d ebe blo quear una var iación de e lectric idad alta para po der prote ger
el electrodom éstico al cua l está c onectado. Por favor contáctes e con un electrici sta licenc iado en su
área si tuviera preguntas en referencia al tipo y tamaño de protector que necesita.

Daños debido a variaciones de electricidad no se consideran un defecto del fabricante y podrían
anular la garantía.

16

CONTROL DE TEMPERATURA:

Vinos rojos

14º - 18º C

57º – 64º F

Vinos blancos

9º - 14º C

49º – 58º F

Vinos tintos

10º - 11º C

51º – 53º F

Vinos espumantes

8º - 9º C

46º – 49º F

Zona Superior

8º - 18º C

46º – 64º F

Zona Inferior

12º - 18º C

54º – 64º F

Se recomienda que Ud coloque su vinera en un lugar donde la temperatura ambiental se mantenga
entre 23º-26ºC / 72º-78ºF.
Si la temperatura ambiental oscila fuera de esos límites, pueda afectar la temperatura de la unidad.
Por ejemplo, si su unidad está situada en lugares donde hay temperaturas muy frías o calientes
también puede afectar la temperatura de la unidad y no alcanzará los límites 8º-18ºC/46º-64ºF).

Temperaturas recomendadas para enfriar vinos:

Rango de Temperatura de su vinera

Panel de controles

Control de temperatura

El panel de control de su vinera se anulará automáticamente 12 segundos después que cualquier
botón haya sido presionado.

Para activar el panel de control de su vinera, presione simultaneamente los botones
marcados y por 3 segundos. Espere por el sonido.

Ud. se puede seleccionar la temperatura preferida presionando los botones marcados

▲ o ▼. Cuando Ud. presione uno de los dos botones por primera vez la temperatura

seleccionada originalmente en la factoría a par ecer á en la pantal la. (12ºC / 54ºF).
La temperatura que Ud. selecciona subirá 1ºC/F cada vez que presione el botón marcado
contrario la temperatura bajará 1ºC/F cada vez que presione el botón marcado

AVISO:

Cuando Ud. encienda su vinera por primera vez o después de un largo tiempo de estar apagado,
habrá una diferencía entre la temperatura que Ud. selecciona y la temperatura indicada en la pantalla
digital. Este situación es normal debido al tiempo de que estuvo apagado. En cuanto la unidad esté
encendida por un par de horas la temperatura volverá a su nivel normal.

.

Luz interior

▲ al

Ud. puedes encender o apagar la luz interior presionando el botón marcado . La luz interior se
apagará automáticamente si está encendida por 10 minutos seguidos. Ud. necesita presionar el
botón de nuevo para encender la luz.

17

CUIDADO Y MANTENIMIENTO

Capacidad

18 botellas de tamaño normal (estandard)
(6 botellas en la zona superior y 12 botellas en la zona inferior).
El tamaño de las botellas puede variar y afectará la cantidad de botellas que Ud. puede almacenar.

Limpieza

Para limpiar el interior, use un paño suave con una solución de una cucharada de bicarbonato de
sodio por cada cuarto de agua, o una solución de espuma de jabón suave, o un detergente suave.
Para lavar las rejillas, sáquelas deslizándolas con cuidado, y use una solución de detergente suave;
luego séquelas con un paño suave. Limpie el exterior con un paño húmedo suave y un poco de
detergente suave o productos de limpieza para electrodomésticos.

Corte de corriente

La mayoría de los cortes de corriente se corrigen en una o dos horas y no afectarán las temperaturas
de su vinera. Sin embargo, Ud. deberá reducir la cantidad de veces que abra la puerta cuando la
corriente esté apagada. Durante los cortes de corriente de larga duración, tome medidas para
proteger sus botellas de vino.

Si Ud. se muda

Saque o asegure todos los artículos dentro de su vinera. Para evitar que los tornillos nivelantes se
averíen, gírelos completamente hacia la base.

Algunas reglas importantes para el uso correcto de la vinera.

• Las bebidas deben guardarse en botellas cerradas.

• No sobrecargue el compartimiento interior.

• No abra la puerta a menos que sea necesario.

• Nunca cubra los estantes del compartimiento para vinos con papel de aluminio o cualquier otro

material para cubrir estantes que puedan obstruir la circulación del aire.

18

Registration Information

-------------------------------------------------------(detach here)--------------------------------------------------------------

Name

Model # Serial #

Address

Date Purchased Store / Dealer Name

City State Zip

E-mail Address

Area Code Phone Number

Occupation

Did You Purchase An Additional Warranty

As your Primary Residence, Do You:

 Extended

 Own  Rent

 None

Your Age:

Reason for Choosing This Avanti Product:

this product:

under 18  18-25  26-30

 Married  Single

Price

 Other: ____________ _______

Comments:

Thank you for purchasing this fine Avanti product. Please fill out this form and return it to the

following address within 100 days from the date of purchase and receive these important benefits:

Avanti Products LLC.

P.O.Box 520604 – Miami, Florida 33152

 Protect your product:

We will keep the model number and date of purchase of your new Avanti product on file to
help you refer to this information in the event of an insurance claim such as fire or theft.

 Promote better products:

We value your input. Your responses will help us deve lop products designed to best meet
your future needs.

Avanti Registration Card

Please indicate the most important factors
That influenced your decision to purchase



 Product Features
 Avanti Reputation
 Product Quality
 Salesperson Recommendation
 Other: ___________________
 Friend / Relative Recommendation
 Warranty



 31-35  36-50  over 50

Marital Status:

Is This Product Used In The:

 Home  Business

How Did You Learn About This Product:

 Advertising
 In-Store Demo
 Personal Demo

19

EWC18N2PD - 10312014

PRINTED IN CHINA

20
