Page 1

Owner’s Manual

Undercounter Refrigerator

Models: AFR152SSRH, AFR152SSLH

www.avallon.com

V1.0 -03122021

Page 2

Important Safety Information

Improper handling can cause serious damage to the Avallon refrigerator and / or injury to the user. This

refrigerator is designed for domesc indoor use only. Do not use the unit for industrial or commercial use. Any other use may invalidate the warranty. Please review the rang label located inside and on the rear panel of the unit for electrical and other technical data related to this unit. The unit must be used with a properly

grounded wall outlet.

Please read and follow the safety informaon listed below to reduce the risk of re, electric shock, or injury.

Electrical Safety

• Do not exceed the power outlet rangs.

• It is recommended the refrigerator be connected on its own circuit.

• The unit must be installed in accordance with state and local electrical codes.

• A standard electrical supply (115 V, 60Hz), that is properly grounded in accordance with the Naonal Electrical Code and local codes and ordinances is required.

• Use outlets that cannot be turned o by a switch or pull chain.

• Always turn the unit o and unplug it from the outlet when cleaning.

• Unplug the unit if it is not going to be used for an extended period of me.

• Do not operate the unit with a power plug missing the ground plug, a damaged cord, or a loose socket.

• Be sure the refrigerator is properly grounded.

• Never plug or unplug the unit with wet hands.

• Do not bypass, cut, or remove the grounding plug.

• Do not use extension cords or power strips with this unit. You may need to contact your electrician if it is necessary to use a longer cord or if you do not have a grounded outlet. Do not modify the power cord’s length or share the outlet with other appliances.

• Do not start or stop the unit by switching the circuit’s power on and o.

• If the power cord is damaged, it must be replaced by the manufacturer or a qualied technician.

• Never repair the unit while it is plugged in.

• Immediately unplug the unit if it makes strange sounds, emits smells, or smoke comes out of it, and contact customer service.

• Do not remove any part of the casing unless you are instructed to do so by an authorized technician.

• You should never aempt to repair the unit yourself.

• Contact customer service for service opons if the unit needs service.

Warning: Flammable Refrigerant Used! When handling, moving, and using the refrigerator, make

sure to avoid either damaging the refrigerant tubing or increasing the risk of a leak.

Page 3

Import Safety Information

General Safety

• To prevent injuries, use at least two people to move and install the refrigerator.

• This appliance is not intended for use by persons, including children, with reduced physical, sensory or

mental capabilies, unless they have been given supervision or instrucon concerning the use of the appliance by the person(s) responsible for their safety.

• Install the refrigerator in a well-venlated area where the ambient temperature is above 50° F and below 90° F.

• The temperature range for this refrigerator is opmized for perishable food items.

• Do not place hot or warm items into the refrigerator before they cool down to room temperature.

• This unit is designed to be installed indoors, and protected from rain, sleet, snow, and / or moisture.

• This unit is not intended to be used by children.

• Children should be supervised to ensure that they do not play with this product.

• Never allow children to crawl inside the refrigerator. If you are disposing of the unit, remove the door.

• Do not use this appliance near ammable gas or combusbles such as gasoline, benzene, or thinner.

• Do not store explosive substances such as aerosol cans with a ammable propellant in this appliance.

• Do not place the unit near heat sources such as ovens, grills, or direct sunlight.

• Only use in an upright posion on a at, level surface and provide proper venlaon.

• Do not pinch or kink the power supply line between the unit and cabinet.

• Do not leave any cleaning soluons in the unit.

• Do not use solvent-based cleaning agents or abrasive soluons to clean the unit as they may damage the interior and exterior.

• Do not place any other appliances on top of the unit.

• Do not turn the unit upside down, on its side, or at an angle o level.

• If your model of refrigerator is equipped with a lock, keep the keys away from children.

• Do not move the unit without emptying the contents and securing the door in a closed posion.

• This appliance is meant for use in the household or similar sengs.

• Keep all venlaon openings clear of obstrucon.

• Do not use mechanical devices or other means to accelerate the defrosng process.

• Do not damage the refrigerant circuit.

• Do not use other appliances inside the refrigerator unless recommended by the manufacturer.

• If the supply cord is damaged, it must be replaced by the manufacturer, its service agent, or a similarly

qualied individual.

Warning: Risk of child entrapment. Before you throw away your old refrigerator or freezer, take o

the doors and leave the shelves in place so that children may not easily climb inside.

Page 4

Table of Contents

Important Safety Informaon .................................................................................................................................2

First-Time Operang Instrucons ........................................................................................................................... 5

Introducon ............................................................................................................................................................5

Parts Idencaon .................................................................................................................................................6

Installaon ..............................................................................................................................................................8

Unpacking the Refrigerator ............................................................................................................................8

Types of Installaon ........................................................................................................................................8

Clearance Requirements ................................................................................................................................ 9

Electrical Requirements ................................................................................................................................ 10

Recommended Grounding Method .............................................................................................................. 10

Leveling the Refrigerator .............................................................................................................................. 11

Installing the Door Handle ............................................................................................................................ 11

Installing the Shelves .................................................................................................................................... 12

Removing the Shelves ..................................................................................................................................12

Operaon .............................................................................................................................................................13

Installaon Checklist before Operaon ........................................................................................................13

Using the Temperature Control Panel ..........................................................................................................13

Sabbath Mode .............................................................................................................................................. 14

Internal Light ................................................................................................................................................14

Normal Sounds ............................................................................................................................................. 14

Temperature Alarm ...................................................................................................................................... 15

Door Ajar Alarm ............................................................................................................................................ 15

Defrosng ..................................................................................................................................................... 15

Preparing the Refrigerator for Storage ......................................................................................................... 15

Cleaning and Maintenance ...................................................................................................................................16

Troubleshoong ................................................................................................................................................... 17

Specicaons ........................................................................................................................................................ 19

Product Warranty ................................................................................................................................................. 20

Page 5

First-Time Operating Instructions

Before use, make sure all packaging labels and materials are removed from the unit. Be sure to keep track of all included parts and pieces before discarding the packaging materials. It is advised that you keep the original box and packaging materials in case you ever need to move or ship the appliance in the future.

Let the unit stand for at least 24 hours before you use it; this allows the cooling components me to sele from transit. The instrucon manual should be read before use.

Introduction

Thank you for purchasing this Avallon refrigerator. We hope that this purchase will be the beginning of a lasng and rewarding relaonship between you and Avallon. We will provide the customer support and exemplary products necessary to nurture that relaonship. This manual contains important informaon regarding the proper installaon, use, and maintenance of your refrigerator. Following this manual will ensure that your product will work at its peak performance and eciency.

Please save the original product packaging in case you need to safely transport your refrigerator.

For Your Records: Please write down the model number and serial number below for future reference. Both numbers are located on the rangs label on the inside and back of your unit and are needed to obtain warranty service. You may also want to staple your receipt to this manual as it is the proof of your purchase, and is also needed for service under

your warranty.

Model Number: ________________________________

Serial Number: ________________________________

Date of Purchase: ______________________________

For a more ecient experience, please do the following before contacng customer service:

• If you received a damaged product, immediately contact the retailer or dealer that sold you the product.

• Read and follow this instrucon manual carefully to help you install, use, and maintain your refrigerator.

• Read the troubleshoong secon of this manual as it will help you diagnose and solve common issues.

• Visit us on the web at www.avallon.com to register your product, download product guides, and access

addional troubleshoong resources and up-to-date informaon.

• If you need warranty service, customer service representaves are available via email at service@avallon.

com.

Page 6

Parts Identication

Control Panel

Leveling Leg

Open View:

Carbon Filter

Internal Fan

Shelf

RUN

Door Rack

Closed View:

Handle

Front Vent

Stainless Door

Door Lock

Page 7

Back View:

Ra�ng Label

Cabinet

Power Cord

Carbon Filter:

A built-in carbon lter protects your contents by acng as a natural barrier against harmful odors.

Internal Fan:

This is an air-cooled unit equipped with an internal fan that maintains a consistent internal temperature.

Note: The carbon lter should be replaced every 3 - 6 months depending on the unit’s exposure level to odor. If the unit is placed in the kitchen, regular replacement every 3 months is ideal.

Page 8

Installation

The refrigerator should be installed in accordance with local electrical code requirements. The refrigerator should also be placed in a locaon that is strong enough to support its total weight, keeping in mind that it will weigh substanally more when fully loaded than when empty. Before you plug the refrigerator into a power

supply, be sure to let it stand upright for at least 24 hours to allow the compressor’s oils to sele.

Unpacking the Refrigerator

Warning: Use two or more people to move and install the refrigerator. Failure to do so can result in back or other injury. Carefully remove the packaging materials. Remove any shipping tape and glue from your refrigerator before use. Do not use sharp instruments, rubbing alcohol,

ammable uids, or abrasive cleaners to remove tape or glue. These products can damage the

surface of your refrigerator.

Warning: Do not remove any safety, warning, or product informaon labels from your refrigerator.

Types of Installation

This refrigerator has been designed for freestanding or built-in installaon. In each case, there must be adequate venlaon and access for service.

Freestanding Installaon:

A freestanding installaon will allow you to install the refrigerator in almost any place you desire. You must follow the stated instrucons for electrical requirements and leveling the refrigerator.

Built-in Installaon:

A built-in installaon will allow you to install the refrigerator under a counter as long as the required clearance space around the refrigerator is provided. It is necessary to allow adequate venlaon space around the unit, including at the back of the unit.

The following addional items must be observed:

1. Place the refrigerator in front of the installaon locaon. Adjust the feet and place the unit at on the oor or on a plaorm depending on your installaon requirements.

2. If the electrical outlet for the refrigerator is behind the cabinet, plug in the refrigerator.

3. Push the refrigerator into posion.

Warning: DO NOT install the refrigerator behind a closed cabinet door.

Page 9

Clearance Requirements

1/4

Notes:

• To ensure proper service access and venlaon, allow between 1 - 2 inches of clearance at the back as shown in the diagram.

• The installaon should allow the unit to be pulled forward for servicing, if necessary.

• A standard electrical supply (115 VAC only, 60 Hz), properly grounded in accordance with

Naonal Electrical Code and local codes and ordinances, is required.

When installing the refrigerator under a counter, follow the recommended spacing dimensions shown.

To ensure proper service access and venlaon, allow at least 1-2” of clearance at the back, 1/4” at the top, and

/4” at the sides. If the door side is against a wall, allow at least 2 1/16” of clearance. The installaon should allow

the unit to be pulled forward for servicing, if necessary.

Top View: Side View:

1-2”

”

1/4”

15 5/8

1 /16 “

Door Swing

2 /”

1 - 2”

1/4”

Note: The refrigerator should be installed on a rm and level surface that will be able to support the enre weight of a fully loaded unit. It is important for the refrigerator to be level in order to work properly. If needed, you can adjust the height of the refrigerator by rotang the feet. See the “Leveling the Refrigerator” secon.

Note: A standard electrical supply (115 VAC only, 60 Hz), properly grounded in accordance with Naonal Electrical Code and local codes and ordinances, is required.

Page 10

Electrical Requirements

ELECTRIC SHOCK HAZARD!

• Plug into a grounded 3-prong outlet.

• Never remove the grounding prong from the plug.

• Never use an adapter to bypass the grounding prong.

• DO NOT use an extension cord.

• Failure to follow these instrucons can result in re, electrical shock, or death.

Before you move your refrigerator into its nal locaon, it is important to make sure you have the proper electrical connecon:

• A standard electrical supply (115 V, 60Hz), properly grounded in accordance with the Naonal Electrical Code and local codes and ordinances, is required.

• It is recommended that a separate circuit, serving only your refrigerator, be provided. Use receptacles that cannot be turned o by a switch or pull chain.

• The fuse (or circuit breaker) size should be 15 Amps.

Recommended Grounding Method

For your personal safety, this appliance must be grounded. It is equipped with a power supply cord that has a 3-pronged grounding plug. To minimize possible shock hazard, the cord must be plugged into a mang 3-pronged wall socket, and grounded in accordance with the Naonal Electrical Code and local codes and ordinances. If a mang wall socket is not available, it is the personal responsibility of the customer to have a properly grounded, 3-prong wall receptacle installed by a qualied electrician.

Page 11

Leveling the Refrigerator

The refrigerator should be installed on a rm and level surface that will be able to support the enre weight of a fully loaded unit. It is important for the refrigerator to be leveled in order to work properly. It can be raised or lowered by rotang the plasc sheaths around each of the feet on the boom of the machine. If you nd that the surface is not level, rotate the feet unl the refrigerator becomes level. You may need to make several adjustments to level it. We recommend using a carpenter’s level to check the machine. Turn the leveling feet to the right to lower that side of the refrigerator. Turn the leveling feet to the le to raise that

side of the refrigerator.

Important: Once you are ready to install the unit in a cabinet or directly on the oor, you must

adjust the feet to level the refrigerator.

Installing the Door Handle

To install the door handle:

1. Open the door and carefully pull the door gasket around the area where the handle is to be installed.

2. Insert each Phillips head screw through the gasket side of the door unl the screw passes through the door.

3. Align the handle with the screws and ghten using a Phillips head screwdriver unl the handle is ush against the door frame.

4. Carefully press the door gasket into its original posion.

Cauon: Do not over-ghten the screws as this may cause damage to the handle or to the stainless

steel door.

Page 12

Installing the Shelves

Metal Guide Post

To prevent damaging door gasket, make sure to open the door fully before pulling the shelves o their tracks.

1. Open the door completely.

2. Ensure that the metal guide posts are aached to the back of the shelf.

3. While liing the right side of the shelf up 45°, rest the le metal guide post on the shelf track.

4. Slowly push the shelf back unl the right metal guide post reaches the vercal indentaon in the cabinet.

5. Gently set the shelf down on the track.

Removing the Shelves

1. Open the door completely.

2. Remove all of the contents loaded on the shelf, if applicable.

3. Ensure that the shelf is pushed back completely.

4. Carefully li either the le or right side of the shelf up 45°.

5. Pull the shelf forward unl it is completely removed from the inner compartment.

Page 13

Operation

RUN

Installation Checklist before Operation

1. Have all packing materials and tape been removed from the interior and exterior of the refrigerator?

2. Have the installaon instrucons been followed, including connecng the machine to electricity? And has

proper grounding been installed for the refrigerator?

3. Has the machine been leveled?

4. Is the refrigerator in a site where the ambient temperature is between 50° F and 90° F all year round?

5. Is there a clearance of at least 1- 2” at the rear, 1/4” at the top, and 1/4” at the sides for proper air

circulaon?

Using the Temperature Control Panel

The refrigerator has a temperature range of 34° F to 65° F.

Power Buon: Turns the unit on and o. Press and hold this buon for approximately 3 seconds to adjust between power on and power o.

Light Buon: Press this buon to alternate between the three internal light colors: Blue, white, and amber. Please refer to the “Internal Light” secon for further details.

Up Buon: Press this buon on the control panel to increase the temperature by 1 degree

increments.

Down Buon: Press this buon on the control panel to lower the temperature by 1 degree

increments.

Run Light: When lit, the unit is in cooling mode.

The Celsius (C) or Fahrenheit (F) indicator will be lit depending on which unit of temperature measurement is being used. To switch between C and F, press and hold both the Up and Down buons simultaneously for approximately 3 seconds. A beep will sound and the indicator light will illuminate next to the desired temperature seng.

Page 14

Sabbath Mode

This refrigerator is programmed with a Sabbath Mode. In Sabbath Mode, the refrigerator will connue to cool and maintain temperature. However, the refrigerator will no longer respond to user interacons. All lights, display(s), and indicators are turned o, and all alarms are disabled. To enter Sabbath Mode, hold the Power buon and press the Up buon twice. The control panel will beep twice indicang that the refrigerator is in Sabbath Mode. To exit Sabbath Mode, perform the same acon and the control panel will beep twice indicang that the refrigerator is no longer in Sabbath mode. The refrigerator will return to normal operaon.

Cauon: If you turn the refrigerator o, please wait at least 5 minutes before turning it back on.

Note: The refrigerator is equipped with a temperature memory funcon. If power is suddenly lost,

the previously set temperature will be saved and the refrigerator will return to this seng once power is restored. Allow at least 24 hours for the seng temperature to be reached.

Internal Light

This refrigerator is equipped with top and side internal lights that can be set to a blue, white, or amber color. The internal lights will illuminate each me the door is opened and fade o once the door is closed. This feature is triggered by a sensor located on the front vent. This sensor allows the refrigerator to recognize

when the door is open or closed.

Note: We run test every unit that we produce in our factory. Because of this, your model may default to any of the above colors out of the box. Simply cycle through unl you reach your desired

internal light color.

Page 15

Normal Sounds

Your new refrigerator may make noise during normal operaon. Most of these sounds are normal. Hard surfaces like the oor and walls can make the sounds seem louder than they actually are.

The following describes several sounds you may hear and what may be making them:

• Raling noises may come from the ow of the refrigerant or the water line. Items stored on top of the refrigerator can also make noises.

• The high eciency compressor may make a pulsang or high-pitched sound.

• Water running from the evaporator to the water bin may make a splashing sound.

• As each cycle ends, you may hear a gurgling sound due to the refrigerant owing in your refrigerator.

• You may hear air being forced over the condenser by the condenser fan.

Temperature Alarm

If the interior temperature is higher than 73°F (23°C), “HI” is shown on the temperature control panel and the temperature alarm will sound connuously aer one (1) hour. This indicates that the inner temperature is too high. If the inner temperature is lower than 25°F (-4°C), “LO” is shown on the temperature display panel and the temperature alarm will sound connuously aer een minutes. If one of these situaons occurs please reference the troubleshoong secon found in this manual or contact Avallon for support.

Door Ajar Alarm

This refrigerator includes a door ajar alarm, which will sound if the door is open for more than three (3) minutes. Leaving the door open for extended periods of me will cause poor cooling performance and may shorten the life of the refrigerator. Keep the doors closed as much as possible.

Defrosting

Note that under most refrigerang sengs, the unit will automacally defrost under most ambient condions. However, on colder sengs, some frost may build up. Addionally, the more humid the ambient condions, the more frost may build up. Keep the door closed as much as possible and avoid opening the door unnecessarily to minimize frost build-up.

If frost is prevenng the door from closing properly, you may need to power the unit o unl the frost melts. Use a so absorbent towel to dry the unit.

Warning: Never aempt to remove frost with a sharp object!

Page 16

Preparing the Refrigerator for Storage

If the refrigerator will not be used for a long me, or is to be moved to another place, it will be necessary to

defrost the unit and dry the interior.

1. Disconnect the refrigerator from the power supply by removing the power plug from the wall socket.

2. Leave the door open to allow for air circulaon and to prevent mold, mildew, and unpleasant smells.

3. Once the interior is dry and clean the unit will be ready for storage.

Cauon: Store the unit out of reach from children. If you have children, you may want to take addional precauons such as removing the door to prevent a child from being trapped inside the

refrigerator.

Important:

• Do not touch the power plug when your hands are wet.

• Never unplug the unit by pulling on the cord.

Cleaning and Maintenance

Periodic cleaning and proper maintenance will ensure eciency, top performance, and long life.

Exterior Cleaning

The door and cabinet may be cleaned with a mild detergent and lukewarm water soluon such as 2 tablespoons of baking soda to 1 quart of water.

Do not use solvent based or abrasive cleaners. Use a so sponge and rinse with clean water. Wipe with a so clean towel to prevent water spong. If the door panel is stainless steel, it can discolor when exposed to chlorine gas and moisture. Clean stainless steel using a cloth dampened with a mild detergent and warm water soluon. Never use an abrasive or causc cleaning agent.

Interior Cleaning

The refrigerator’s interior should be cleaned occasionally.

1. Disconnect power to the unit.

2. Open the door and remove the contents and shelves.

3. Wait unl the unit defrosts.

4. With a clean cloth, wipe down the interior of the unit.

5. Reinsert the shelves and contents.

6. Reconnect power to the unit.

Page 17

Troubleshooting

Before Calling for Help:

If the unit appears to be malfunconing, read through the “Operaon” secon of this manual rst. If the problem persists, check the Troubleshoong Guide below and on the following page. The problem may be something that can easily be solved or explained.

Symptoms Possible Causes Soluons

The refrigerator turns on and

o frequently.

The refrigerator does not turn on.

The room temperature is higher than the recommended

ambient environment. The door is being opened too

oen.

The door is not completely closed.

The door gasket is not sealing

properly. The refrigerator does not have

the suggested venlaon.

There is a power failure. Ensure that the refrigerator is plugged in

The refrigerator is not plugged in.

Run the refrigerator at the appropriate ambient temperature.

Minimize the number of mes the door is

opened.

Make sure the door is completely closed.

Make sure the door gasket is sealing

properly.

Read and follow the “Installaon Clearance Requirements” secon.

and the power outlet has power. Plug the unit in to a power outlet that has

sucient amperage.

The refrigerator will not reach the desired temperature.

A house fuse has blown or the circuit breaker is tripped.

The refrigerator is placed too close to a heat source.

The refrigerator does not have

sucient venlaon.

The door is opened too frequently or for a long period

of me.

Replace the broken fuse in your fuse box or reset the breaker.

Keep the refrigerator away from direct sunlight or other heat sources.

Read and follow the “Installaon Clearance Requirements” secon.

Close the door ghtly and do not open

the door too frequently or for a long

period of me.

Page 18

Symptoms Possible Causes Soluons

The refrigerator is making

strange noises.

The body of the refrigerator is electried.

Frost is forming in the refrigerator.

The door will not shut properly. The refrigerator is not level. Make sure the refrigerator is on a level

Certain sounds are normal. Read the “Normal Sounds” secon. The unit is not level or is

touching another appliance.

The unit is not grounded properly.

The environment is humid. Though the unit uses an “auto-defrost”

The ambient temperature is

too low.

The door is being opened too

frequently.

The door gasket is dirty. Clean the door gasket. The door gasket is not installed

correctly. The shelves are incorrectly

installed.

Check to make sure that the refrigerator is level, and that it is not in contact with

another appliance or furniture. Contact your local electrician to test your

electrical grounding system.

system, under certain condions, manual defrosng may be required. If frost builds up, you can try running the refrigerator on a warmer temperature seng, minimizing the number of mes you open the door, or unplugging the unit to allow

the frost to melt.

Move the refrigerator to a site with an ambient temperature at or above 50°F.

Close the door ghtly and do not open

the door too frequently or for a long

period of me.

surface.

Make sure the door gasket is correctly

installed. Install the shelves correctly.

Page 19

Specications

Note: Technical data and performance informaon are provided for reference only. Specicaons are subject to change. Check the rang label on the refrigerator for the most accurate informaon.

Product Type Undercounter Refrigerator

Model AFR152SSRH / AFR152SSLH

Voltage / Frequency AC 115V~60Hz

Amperage 1.5

Color Black Cabinet with Stainless Steel Door

Refrigerant R600a, 1.06 oz.

Temperature Range 34° F to 65° F

Dimensions

(Height x Width x Depth )

Note: Depth shown includes the handle. Depth without the handle is 23 5/8”.

34 1/8” X 15” X 25 7/16”

Page 20

Product Warranty

Warranty Period Avallon will be responsible for: Consumer will be responsible for:

1st year All costs for repairing or replacing parts and/or unit

which proves to be defecve. All transportaon costs in the rst 90 days.

Limited 2nd-5th year

(compressor only)

This product is warranted by Avallon and is subject to any condions set forth as follows:

Repairing or replacing any compressor which proves to be defecve. (Labor not included.)

WHAT IS COVERED:

One Year Parts and Labor: For one year from the date of original retail purchase, Avallon will repair or replace any part free of charge including labor that fails due to a defect in materials or workmanship. Avallon will be responsible for all transportaon costs for the rst 90 days from original purchase date, aer 90 days the consumer will be responsible. Labor will be performed free of charge at an authorized Avallon repair facility and will supply new, rebuilt, or refurbished parts free of charge. Avallon may request a defecve part be returned in exchange for the replacement part. Aer the 12 month period, Avallon will no longer be responsible for labor charges incurred or replacement parts. All defecve products and parts covered by this warranty will be repaired or replaced on a mail-in basis to an Avallon authorized repair facility.

Five Year Limited Warranty (Compressor- Labor Not Included): In the second through h year from the date of original retail purchase, Avallon will replace the compressor free of charge. The consumer will be responsible for all transportaon and labor costs. Avallon will supply a new, rebuilt, or refurbished compressor and may request for the defecve compressor to be returned in exchange. This limited 5-Year warranty is for the compressor only and does not include labor.

All warranes apply to the original purchaser only, and only covers defects in workmanship experienced during operaon of the product under normal service, maintenance, and usage condions. This warranty applies to the purchase and use of this product in residenal sengs within the United States of America. All products and parts replaced by Avallon under warranty service become the property of Avallon. All defecve products and parts covered by this warranty will be repaired or replaced on a mail-in basis to an Avallon authorized repair facility.

Excepons: Commercial or Rental Use Warranty: 90 days labor and parts from date of original purchase. No other warranty applies.

Consumer will be responsible for: All transportaon costs aer 90 days.

Labor and all transportaon costs.

WHAT IS NOT COVERED:

Labor charges for installaon, setup or training to use the product. Shipping damage, and any damage caused by improper packaging for shipment to an authorized service center, and any damaged caused by improper voltage or any other misuse, including abnormal service, handling, or usage. Cosmec damage such as scratches and dents. Normal wear and tear on parts or replacement of parts designed to be replaced, e.g. lters, cartridges, baeries. Service trips to deliver, pick-up, or repair, install the product, or to instruct in proper usage of the product. Damages or operang problems resulng from misuse, abuse, operaon outside environmental specicaons, uses contrary to instrucons provided in the owner’s manual, accidents, vermin, re, ood, improper installaon, unauthorized service, maintenance negligence, unauthorized installaon or modicaon, or commercial use. Labor, service transportaon, and shipping charges for the removal and replacement of defecve parts, beyond the inial 12-month period. Products that have been modied to perform outside of specicaons without the prior wrien permission of Avallon. Products lost in shipment, or the. Products sold AS IS or from an unauthorized reseller. Products that have had their serial numbers removed, defaced, or with serial numbers that have been invalidated. Damage from other than normal household use. Replacement or repair of household fuses, circuit breakers, wiring or plumbing. Damage to personal property from use of product. Damage from service other than from an authorized Avallon repair facility. Hoses, knobs, lint trays and all aachments, accessories and disposable parts. Any service charges not specically idened as normal such as normal service area or hours. Any special or consequenal damages arising out of the use of the product.

OBTAINING WARRANTY SERVICE:

If you believe your product is defecve, contact Avallon Customer Support for troubleshoong assistance and warranty service at www.avallon.com or call 1-866-471-7427. Before contacng Customer Support, you are required to have your model number, serial number and proof of purchase available upon request. Once an Avallon authorized representave has conrmed that your product is defecve and eligible for warranty service, the product must be returned to an Avallon authorized repair facility. Avallon is not responsible for damage resulng from shipper mishandling or improper packaging. Do not return a defecve product to the place of purchase. Products received without a return authorizaon number will be

refused.

THIS WARRANTY IS IN LIEU OF ANY OTHER WARRANTY, EXPRESS OR IMPLIED, INCLUDING WITHOUT LIMITATION, ANY WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. TO THE EXTENT ANY IMPLIED WARRANTY IS REQUIRED BY LAW, IT IS LIMITED IN DURATION TO THE EXPRESS WARRANTY PERIOD ABOVE. NEITHER THE MANUFACTURER NOR ITS DISTRIBUTORS SHALL BE LIABLE FOR ANY INCIDENTAL, CONSEQUENTIAL, INDIRECT, SPECIAL, OR PUNITIVE DAMAGES OF ANY NATURE, INCLUDING WITHOUT LIMITATION, LOST REVENUES OR PROFITS, OR ANY OTHER DAMAGE WHETHER BASED IN CONTRACT, TORT, OR OTHERWISE. IN NO EVENT AND UNDER NO CIRCUMSTANCE OF ANY TYPE OR KIND SHALL THE SELLER, MANUFACTURER AND/OR DISTRIBUTOR BE LIABLE FOR ANY REASON, UNDER ANY THEORY, FOR MORE THAN THE BASIC COST OF THE PRODUCT TO THE PURCHASER OR END USER. SOME STATES DO NOT ALLOW THE EXCLUSION OF INCIDENTAL OR CONSEQUENTIAL DAMAGES, SO THE ABOVE EXCLUSION MAY NOT APPLY TO YOU. THIS WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS. YOU MAY HAVE OTHER RIGHTS THAT VARY FROM STATE TO STATE.

Page 21
