Autostart CT-5060 User Manual

MANUAL TRANSMISSION MULTI-CHANNEL REMOTE

STARTER AND FULL-FEATURED ALARM SYSTEM

CT-5060

User Guide

Introduction......................................... 1

Basic Remote Operation..................... 1

Remote-starting Your Vehicle............. 2

Remote-starting............................ 2

Setting the system to Ready Mode..... 2

Remaining in Ready Mode...........2

Vehicle Presets............................. 3

Driving Off..................................... 3

Idle Mode............................................ 3

Valet Mode.......................................... 4

Ignition Valet....................................... 4

Remote Valet...................................... 4

Panic Mode......................................... 4

Quick LockoutTM.................................. 5

Cold Weather Mode............................ 5

Priority Door Access........................... 6

Chirp Delete........................................ 6

User-selectable Options.....................6

Safe Start...................................... 6

Introduction

This Module is a state-of-the-art combination of an Alarm system and a remote car starter. It represents a major breakthrough in vehicle security technology and remote starter systems.

Remote Door Locks...................... 6

Passive or Active Arming.............. 7

Disarmed Notification.................... 7

Shock Sense And Warn-Away

Sense............................................ 7

Siren Chirps.................................. 7

Open Zone Notification:................ 7

Ignition-Controlled Door Locks.....7

Ignition Re-Lock............................ 8

Secure Lock.................................. 8

Remote Trunk Release.................8

Starter Kill..................................... 8

Engine Run Time.......................... 8

Multi-Car Operation......................8

Car Finder........................................... 9

Diagnostics – Chirps Diagnostics –

Parking Lights..................................... 9

Parking Lights Flash Rate (Normal

Operation)........................................... 9

Basic Remote Operation

This system is equipped with a 4-button multi-channel two-way transmitter. It can operate two independent identically-equipped vehicles (see Multi-Car Operation for second-car transmitter functions).

The functions of the transmitter are as follows:

DOC.3.55 CA – September 9, 2004 Manufactured in Canada by Autostart

Note: Pressing the

Remote-starting Your Vehicle

Remote-starting

LOCK and UNLOCK buttons at the same time will activate the AUX 2 output.

Press the START/STOP button for approx. 1 second. The parking lights will come ON, informing you that the unit has received your signal. The engine will start approx. 5 seconds later. The parking lights will remain ON during the pre-programmed run time. If the vehicle doesn’t start at the first attempt, the system will shut down, wait a few seconds, and try to start the engine again. It will try to start the engine 3 times before giving up.

Setting the system to Ready Mode

This unit is designed for Manual Transmissions only. In order to remote-start the vehicle, the Unit must first be set to Ready mode. If the Unit is not set to Ready Mode, it cannot remote-start the vehicle. Once the system has been set to Ready Mode, the vehicle can be remote started and stopped at will (as long as the Unit never exits Ready Mode).

1. Ensure that all the Doors are closed and that the Gear Lever is in the Neutral

position.

2. With the Engine already running, apply the Parking Brake.

3. Within 20 sec. press LOCK, UNLOCK or START/STOP on the Transmitter.

The Parking Lights will flash 3 times quickly and remain lit.

4. Remove the key: the Engine will go on running.

5. Exit the vehicle and close the Door.

6. Press either: a. LOCK to lock the Doors, arm the Alarm and shut down the Engine; b. UNLOCK to unlock the Doors and shut down the Engine; c. START/STOP to shut down the Engine without affecting the Doors or; d. TRUNK to lock all Doors and engage idle mode.

Remaining in Ready Mode

Once the vehicle is in Ready Mode you can start and stop the vehicle at wish. However, if any one of the following events occurs, the vehicle will exit Ready Mode – thus eliminating the remote start option until Ready Mode is restored:

CT-5060 User Guide P. 2

• Door opened;

• Hood opened;

• Brakes pressed;

• Parking Brake disengaged;

• Key turned to the IGNITION ON (RUN) position.

Should any of the above occur, Ready Mode will be cancelled. Note: The unit will notify the user that it has exited Ready Mode by giving three slow

flashes of the vehicle’s Parking Lights.

Vehicle Presets

Heater & Heated Seat

When leaving the vehicle it is recommended to preset the accessory controls in preparation for the next remote start. Settings for the blower motor (fan), front and rear, as well as heated seats (if equipped) should not be left on

HIGH. It is recommended to

leave the settings on LOW or MEDIUM instead.

Windshield Wipers & Radio & Headlights

Certain vehicles require the radio and / or windshield wiper and / or headlight circuits to become energized while running under remote start. When leaving the vehicle you must ensure that the windshield wiper and headlight switches are switch

ON on certain vehicles could cause them to remain ON even after remote starter

OFF. Leaving the headlight

shut down, resulting in a dead battery.

Driving Off

With the vehicle running under remote control, press the UNLOCK button to DISARM and

UNLOCK the doors. Enter the vehicle and do the following:

• Turn the ignition key to the IGNITION ON (RUN) position. (Do not turn the key to the START position while the engine is running. This will cause the starter motor to re-engage.)

• Press the brakes to disengage the remote starter unit.

You are now ready to drive off.

Idle Mode

This feature allows you to remove the key from the ignition and leave the vehicle running for its pre-programmed run time while you are away from your vehicle. This feature is handy if you need to stop for a quick delivery, or at a convenience store.

To enable the Idle Mode:

1. Press and hold LOCK, UNLOCK or START/STOP on your transmitter while the engine is

running.

2. The parking lights will come ON.

3. Remove the key, exit the vehicle;

• Press the LOCK button if you need to lock the doors while the engine is running.

Caution: Do not leave children or pets unattended in a car running in Idle Mode.

P. 3 User Guide CT-5060
