Keyless Entry And Alarm System
CT-1010
Installation Guide
Table of Contents
Included in the Kit........................... 1
Installation Points to Remember .. 2
Programmable Features.................. 2
Harness Description......................... 3
How to Flash the Hood Pin........... 4
Programming a Transmitter........... 4
Programming Options .................... 4
Included in the Kit
Please review the installation guide before beginning the installation, especially the wiring diagram and the
programming options. It is very important that you familiarize yourself with the programming and operation of
the system, even if you have already installed an alarm system in the past. There are many great new features
that may be overlooked if the manual is not read: you would therefore not maximize the unit’s potential. Prior to
the installation, make sure that all the hardware components required to install the system are in the box.
Dome Light Delay............................ 7
Retain Accessory Output............... 7
Zone 2 Disable Output .................. 7
Multi-car Operation ........................ 7
Resetting the Module...................... 7
Diagnostics - Parking Lights Flash
Rate ..................................................... 8
Closing Up......................................... 8
Notice
The manufacturer will accept no responsibility for any electrical damage resulting from
improper installation of the product, be that either damage to the vehicle itself or to the Unit.
This Unit must be installed by a certified technician using all safety devices supplied. Only
registered technicians will be eligible to use the Prostart technical support telephone
service. Please review the Installation Guide carefully before beginning any work.
DOC: 1.06 November 10, 2006 TL Manufactured in Canada by Autostart
The following is a list of components included in the kit:
o 1 – Control unit.
o 2- CT-200 transmitters
o 1 – plug-in L.E.D
o 1 – Hood-pin switch
o 1 – user guide
o 1 – installation guide.
o 1 – plug-in valet button.
The kit also includes the following harnesses:
o 1 – 2 pin Wire harness.
o 1 – 5 pin Main harness.
o 1 – 12 pin principal auxiliary
harness
o 1 – 3 pin connector cable
Installation Points to Remember
o When working on a vehicle always leave a
window open.
o Never leave the keys in the car. Leave them
on a workbench with a window rolled down.
o If possible, remove courtesy light fuse to
prevent battery drain.
o Inspect vehicle for any body damage or
electrical problems.
o Make sure that all the switches and controls
operate properly.
o Verify that the vehicle starts and idles
properly.
o Never install control unit where it could
interfere with normal operation or obstruct
service technicians.
o Do not disconnect the battery on vehicles
equipped with air bags and anti-theft radios.
o Always use a grommet when running wires
into the engine compartment.
o Never run wires through bare or sharp metal.
o Always solder and tape all connections.
o Never ground the control unit to the steering
column of the vehicle.
o When you probe /test the wires of a harness,
make sure you check the plug-in connector.
o The wires for the air bags aren’t always
identified on the harness (split loom or a
yellow tape). However they are always
identified on the connector.
o Keep the Transceiver away from other types
of antennas (GPS/Onstar).
o Make sure all security equipment is installed:
the Valet switch, the hood pin and the warning
label.
Programmable Features
The unit was designed with flexibility and OEM integration in mind. The system gives installers the output
flexibility that every good installer is looking for; this unit can be customized and used for almost every possible
application.
With the integration of timed-latched and ON / OFF outputs, this unit can single-handedly control virtually any
electrical system in the car!
The programmable features are as follows:
1. Ignition-Controlled Door Locks
• OFF by default. This feature will LOCK all the Doors of the vehicle while the Ignition Key is in the
IGNITION ON (RUN) position and only when all the doors are closed (there is no recurrence of this
action). The unit will UNLOCK all Doors when the Ignition Key is turned back to the OFF position.
• If Ignition Lock Only is selected, the system will only LOCK all Doors while the Ignition Key is in the
IGNITION ON (RUN) position and only when all the doors are closed (there is no recurrence of this
action).
• If option Ignition Unlock Only is selected, the system will UNLOCK all Doors when the key is turned to
the OFF position (provided that the Ignition key was in the IGNITION ON (RUN) position).
2. Passive or Active Arming
• (Passive with a 1-min. time out by default.) The alarm system on this unit can be set to active mode (in
which it will not arm itself automatically) or to passive mode (arms itself automatically) with a 1-minute
timeout.
3. Door Lock Pulse Duration
• (¾-sec. lock and ¾-sec. unlock pulses by default.) This system can be programmed to give either 3.5-
sec. lock /unlock pulses (this is used to control vacuum door-lock system, for instance on Mercedes) or a
single ¾ -sec. lock pulse with a double ¼-sec. unlock pulse (this is used for double-pulse disarm/unlock
systems, as in the Maxima, Pathfinder, and Volkswagen…)
P. 2 Installation Guide Alarm-050
4. Relock
• If you unlock the doors with the remote transmitter, but do not open any door or trunk within 60 seconds,
the doors will automatically relock.
Harness Description
5 PIN HARNESS
WIRE Wire colour
1 BLACK
2 RED +12V POWER INPUT
3 GREY
YELLOW /
4
BLACK
5 YELLOW
12 PIN HARNESS
WIRE Wire colour
1 PINK
2 PURPLE NA
GREY /
3
Light BLUE
GREY /
4
GREEN
WHITE /
5
RED
WHITE /
6
BLUE
GREY /
7
BLACK
GREY /
8
RED
BLACK /
9
Light BLUE
BLACK /
10
BROWN
BLACK /
11
GREEN
BLACK /
12
PINK
Function Description
(-) CHASSIS GROUND
INPUT
(–) HOOD SWITCH
INPUT
PARKING LIGHT
INPUT
PARKING LIGHT
OUTPUT
Function Description
(+) IGINITION
INPUT
(-) TRUNK INPUT Connect to the wire that tests ground with trunk open
(-) NEGATIVE
TRIGGER INPUT
N/A
N/A
(-) DOOR TRIGGER
INPUT
(+) DOOR TRIGGER
INPUT
(–) AUX 1
output
(–) AUX 2
output
(–) AUX 3
output
(–) Zone 2 Disable
Output (armed output)
This wire must be connected to bare, unpainted metal (the
chassis or true body ground). It is preferable that you use a
factory ground bolt rather than a self-tapping screw.
Connect to the +12 V power feed of the vehicle, at the Ignition
harness. The source wire should have +12 V without Ignition
key in the cylinder.
Connect this wire to the installed hood pin switch supplied.
Connect to ground or +12 V for polarity control on pin #5
Connect to parking lights circuit of the vehicle. This wire will
give either a positive or a negative output; depending on the
polarity of pin #4.
Connect to the Ignition wire of the vehicle. The source wire
should have +12 V with the ignition key in the IGNITION ON
(RUN) and CRANK positions.
When connected to the wire that provides ground when remote
started this input will cause the alarm system to ignore the
ignition and shock sense while running by remote start.
(Trigger alarm input — selected by Default)
Connect to the wire that tests ground with a door open. Note:
This wire should monitor all the doors.
Connect to the circuit of the car giving +12 V when a door is
opened (usually the dome-light circuit).
This wire will provide 500mA ground output depending on the
configuration of Mode 1, Function 5 (see programming options)
This wire will provide 500mA ground output depending on the
configuration of Mode 1, Function 4 (see programming options)
This wire will provide 500mA ground output depending on the
configuration of Mode 1, Function 3 (see programming options)
This wire will provide a constant 500mA output when the
system is armed (locked by remote control). It can be
connected to an external starter interrupt relay.
This wire should be connected to a single pole double-throw
relay: this wire will connect to pin 85 on the relay, and pin 86
will be connected to the ignition wire.
Installation Guide P. 3
3 PIN CONNECTOR – 2 WIRE HARNESS
Wire Wire colour
1 GREEN (–) Unlock output
2 No wire (+) 12V This pin provides +12V output for INV-200 module
3 BROWN (–) Lock output
Function Description
Programmable 500mA negative output: 1/10-sec., 7/10-sec., 4sec. or double 1/4-sec. pulse (ON 250 ms, OFF 500 ms, ON
250 ms)
Programmable 500mA negative output: 1/10-sec., 7/10-sec. or
4-sec. pulse
2 PURPLE WIRES
These wires serve as a starter kill. Cut the factory starter wire (from the vehicle) in half and connect the two cut
wires to the 14 AWG purple wires on the module.
How to Flash the Hood Pin
THE INSTALLER … THE MODULE …
• Press and hold the hood pin for 4 seconds.
• Release the hood pin. Parking Lights “ON”
• While the parking lights are on, press down the hood pin once more
and release the hood pin immediately.
• You now have 20 seconds to select one of the sub-menus
“ON” for 20 seconds
Programming a Transmitter
The transmitter does not come pre-programmed and must be programmed after the wiring of the module is
completed. The system can retain up to 4 different transmitter codes; if a fifth transmitter is programmed, the
code of the first transmitter in memory will be lost. To erase all transmitters from memory, perform a module
reset.
Proceed as follows to program a new transmitter:
1. Flash the hood pin (see above) - the parking lights will stay on for up to 20 seconds.
2. Before the lights go out, turn the ignition key to the ON (RUN) position
3. When the lights are off, turn the key to the OFF position.
4. Press and hold the
5. The transmitter has been stored in memory.
6. To exit: close the hood.
or button until the parking lights flash 5 times quickly.
To program a transmitter on the second vehicle for multi-car operation, you must press the button
(instead of or ) in step 4 of the transmitter programming procedure.
Programming Options
The system is equipped with two custom programming menus that allow the installer to custom-fit the outputs of
the system according to the requirements of each vehicle.
Proceed as follows to enter custom programming:
1. Flash the hood pin switch (see above) the parking lights will stay on for up to 20 seconds.
2. Before the lights go out, press and hold the valet button and then press one of the following
buttons:
............................................to access mode 1;
3. The parking lights will flash to confirm entry into a mode.
4. Release the valet button
P. 4 Installation Guide0
............................................to access mode 2;
After selecting the function, press one of the corresponding buttons to select the option.
for Option 1,
for Option 2,
+ for Option 5.
+ for Option 6.
for Option 3;
for Option 4;
Programming Options
MODE 1
FUNCTION 1 – Ignition-controlled door locks
FUNCTION 2 – Door lock pulse timing
FUNCTION 3 – AUX3 Programming – Press the button for 4 seconds (for options 1 through 5)
FUNCTION 4 – AUX2 Programming – Use with button (for options 1 through 4 and car finder)
FUNCTION 5 – AUX1 Programming
* INDICATES DEFAULT SETTING
OPTION 1* Ignition lock disabled
OPTION 2 Ignition lock enabled
OPTION 3 Ignition unlock ONLY
OPTION 4 Ignition lock ONLY
OPTION 1* 7/10-sec. lock/unlock pulses
OPTION 2 4-sec. lock/unlock pulses
OPTION 3 7/10-sec. lock pulse and two ¼ -sec. unlock pulses
OPTION 4 1/10-sec. lock/unlock pulses
OPTION 1* Constant while button is pressed
OPTION 2 Toggle ON – Toggle OFF
OPTION 3 60-second pulse
OPTION 4 1-second pulse with Unlock pulse and Disarm pulse
OPTION 5 1-second pulse with Disarm pulse. Once the Trunk is closed, Arm pulse after 5-sec. delay.
OPTION 6 Disarm function (with UNLOCK button)
OPTION 1* Constant while button is pressed – Car finder disabled
OPTION 2 Toggle ON – Toggle OFF with 30 seconds timeout or until ignition ON – Car finder
disabled
OPTION 3 30-second pulse - Car finder disabled
OPTION 4 60-second pulse - Car finder disabled
OPTION 5 Retain accessory output - Car finder enabled
OPTION 6 Arm output - Car finder enabled
OPTION 1* Priority door
OPTION 2 Dome light output for 60 seconds
OPTION 3 Arm output
OPTION 4 Disarm output
OPTION 5 Retain accessory output
Installation Guide P. 5
MODE 2
FUNCTION 1 – Re-lock
FUNCTION 2 – Siren / Horn Chirps (Available only on some models)
FUNCTION 3 – Arming
FUNCTION 4 – Ignition monitoring with Siren / Horn mode (Available only on some models)
FUNCTION 5 – Negative trigger
* INDICATES DEFAULT SETTING
OPTION 1 Disabled
OPTION 2* Enabled – Relock all doors 60 seconds after unlocking and no door nor trunk is
opened
OPTION 1 Warning chirp only – Lock confirmation if Lock button is pressed more than once
- 3 chirps if a door is opened and Lock button pressed
- 4 chirps if Unlock button is pressed and an intrusion occurred
OPTION 2* Chirp enabled
OPTION 3 Chirp enabled with open-zone notification
(Siren / Horn warning 10sec after arming if a door is opened)
OPTION 4 Chirp disabled – Lock confirmation if Lock button is pressed more than once
OPTION 1 Active arming
OPTION 2* Passive arming – 60 seconds rearm
OPTION 3 Passive arming – 60 seconds rearm. No TWO-STAGE disarm.
OPTION 4 Active arming with disarm notification (ignition ON to OFF, door opened and then closed)
OPTION 1 Siren mode with ignition monitoring disabled
OPTION 2* Siren mode with ignition monitoring enabled
OPTION 3 Horn mode with ignition monitoring disabled
OPTION 4 Horn mode with ignition monitoring enabled
OPTION 1 Ignition and shock bypass under remote start.
OPTION 2* Trigger alarm input
Siren / Horn Chirp Duration Adjustment
(Available only on some models)
The default horn chirp duration is 25 ms. In order to adjust the timing for the Siren, select MODE 2 –
FUNCTION 4 – OPTION 1 or 2. To adjust the timings for the Horn, select MODE 2 – FUNCTION 4 – OPTION 3
or 4. The siren/horn chirp duration can be configured by following these steps:
1. Flash the hood pin switch (see on page 4) - the parking lights will stay on for up to 20 seconds.
2. Within 20 sec. press and hold the valet button.
3. Press the
button to enter horn chirp duration adjustment – Siren or Horn will chirp 5 times.
4. Proceed as follows to change the horn chirp duration:
a. Every time you press the
button, the system will increase horn chirp duration by
3 ms. When chirp duration reaches its maximum value (250 ms the siren / horn will
sound 1 long chirp.
b. Every time you press the
button, the system will increase horn chirp duration by
10 ms. When chirp duration reaches its maximum value (250 ms) the siren / horn will
sound 1 long chirp.
c. Every time you press the
button, the system will decrease the horn chirp duration
by 3 ms. When chirp duration reaches its minimum value (10 ms), the siren / horn will
sound 1 long chirp.
d. Every time you press the
button, the system will decrease the horn chirp duration
by 10 ms. When chirp duration reaches its minimum value (10 ms), the siren / horn will
sound 1 long chirp.
e. To save the settings and exit horn chirp duration adjustment, press the
buttons simultaneously (or the press
button on the two-way remote). The siren /
+
horn will sound 3 chirps. Then turn the ignition key to the OFF position.
P. 6 Installation Guide0
Note: As a rule, you will hear only one short chirp for each adjustment of the horn chirp duration. Nevertheless,
you will hear a long chirp (approx. 1 second long) if either the minimum value (10 ms) or maximum value
(250 ms) is reached.
Dome Light Delay.
When the doors are being closed and the vehicle is armed, the module will check the dome light to detect
whether a door has been left open. If the dome light is on, the system will generate three chirps to warn the
user that a door has been left open (There is one chirp if Mode 1 – Function 5 – Option 2 is selected)
Retain Accessory Output
Retain Accessory output is activated as soon as key is turned to the ON position. When the key goes from ON
to OFF position, the accessory output stays ON and a countdown period of 10 minutes is set. The output is
turned OFF after 10 minutes or if a door is opened anytime during the countdown period.
Note: The Accessory Output is also turned off while starting the car.
Zone 2 Disable Output
The unit is equipped with a zone-2 disable output that can be used to immobilize the vehicle when the system is
armed. Zone-2 disable operates in addition to the built-in starter kill.
The unit will give a negative output when the system is armed (locked by remote); this wire can therefore
control an external relay to interrupt the fuel pump or the Ignition.
The starter kill circuit can be configured to passive mode (to arm automatically) with a 1-minute timeout.
Otherwise it can be configured to active mode (in which it must be armed by the user).
Note: Installation of a 2
nd
-zone disable requires an external relay (not included!).
Multi-car Operation
This allows the user to control two systems with one transmitter. (Both vehicles must be equipped with identical
modules)
The remote transmitter of the primary vehicle can control the starter kill system, the door lock and unlock
operations of the second vehicle. The remote transmitter of the second vehicle can also operate the primary
vehicle.
*To program a transmitter for a second vehicle under multi-car operation, you must press on button of the
transmitter in step 4 of transmitter programming procedure (see page 4).
Resetting the Module
The system is equipped with a reset function that allows the installer to erase all transmitter codes and return all
programming options to their factory defaults.
To reset the module:
1. Flash the hood pin switch (see on page 4) - the parking lights will stay on for up to 20 seconds.
2. Immediately press and release the valet button 5 times.
3. The parking lights will flash 8 times upon reset.
Note: After a reset has been performed, the system will set all options back to their default values (see the
programming page for default values) and all transmitters will need to be programmed again.
Installation Guide P. 7
Diagnostics - Parking Lights Flash Rate
FLASHES RATE DESCRIPTION
1 Quick
2 Quick
3 Quick
• Locked by transmitter, system armed (starter kill, alarm)
• Unlocked by transmitter, system disarmed (starter kill, alarm)
• System has exited valet mode
• Locked by transmitter while a door opened
• System has entered valet mode
5 Quick New transmitter programmed
8 Quick Unit reset: Occurs when the unit is reset to factory defaults
Closing Up
Use tie-wraps or screws to properly secure the starter Module and keep the wiring away from any moving parts
such as the Parking Brakes or Steering Column Shafts. Mount all switches in good and accessible locations
where they do not risk getting kicked or hit accidentally.
Most comebacks are the result of misunderstandings about how a product works or performs. Take the time to
properly explain all functions and features to the customers before they leave the premises. Doing this will save
time and money.
Always make all your connections before plugging in the Module, and be sure to test all functions properly
before closing up the installation.
P. 8 Installation Guide0
Loading...
