AUTOMATIC TRANSMISSION REMOTE STARTER
COMBO WITH FULL ALARM SYSTEM
AS-6010 TW-
A
User Guide
A note concerning the battery inside the transmitter:
Depending on the usage of the transmitter, the battery can last anywhere
between 3 to 6 months. When the battery is low, the transmitter will emit two
beeps in a repetitive cycle. At that point you should replace the battery with a
new one. That is why we recommend that you keep a spare battery somewhere
handy such as the glove compartment.
INDUSTRY CANADA USER NOTICE:
Operation is subject to the following two conditions: (1) this device may not cause interference, and
(2) this device must accept any interference, including interference that may cause undesired
operation of the device. To reduce potential radio interference to other users, the antenna type and
its gain should be so chosen that the equivalent isotropically radiated power (EIRP) is not more
than that required for successful communication.
FCC USER NOTICE (U.S.A.):
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) this device may not cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause undesired operation. NOTE: The
manufacturer is not responsible for any radio or TV interference caused by unauthorized
modifications to this equipment. Such modifications could void the user's authority to operate the
equipment.
DOC:.1.00 CA Lp November 3, 2004 Manufactured in Canada by Autostart
AS-6010 TW User Guide P. 2
Table of Contents
Introduction............................................. 3
Using the Remote Control ...................... 3
LCD Remote Functions .......................... 3
Basic Vehicle Operation.................... 3
Alarm Clock....................................... 4
Time Adjust Mode ............................. 4
Countdown Timer.............................. 4
Parking Countdown........................... 4
Melody Selection............................... 4
Vibration Mode .................................. 4
Power Saving Mode .......................... 4
Remote Control Finder...................... 4
Door and Hood Monitoring ................ 5
LCD Transmitter Operation (First Car
Control)
................................................... 5
Basic Vehicle Operation.................... 5
Transmitter Mode Selection .............. 5
Time or Alarm Clock Adjustments ..... 5
Cold Weather Mode .......................... 6
Home ValetTM.................................... 6
Countdown Timer.............................. 7
Parking Countdown........................... 7
Safe Start Mode ................................ 7
*Runtime (Cannot be programmed.
Serves as indication only.)
................ 7
LCD Transmitter Operation (Second
Car Control)
............................................ 8
Basic Vehicle Operation.................... 8
Start and Stop While in Safe Start
Mode
................................................. 8
Remote-Starting Your Vehicle ................ 8
Remote-starting................................. 8
Vehicle Presets ................................. 8
Driving Off ......................................... 8
Using the System.................................... 9
Arming and Disarming the System.... 9
Idle Mode........................................... 9
Turbo Mode....................................... 9
Valet Mode with the Valet Switch .... 10
Ignition Valet.................................... 10
Start Attempts Indicator (Valet
Mode)
.............................................. 10
“Home ValetTM” Mode...................... 10
Remote Valet Mode......................... 11
Panic Mode ..................................... 11
Quick LockoutTM.............................. 11
Cold Weather Mode ........................ 11
Temporary Chirp Delete.................. 12
Advanced Features: Installationprogrammable Options
......................... 12
Remote Door Locks......................... 12
Priority Door Access........................ 12
Active or Passive Arming ................ 12
The Starter Kill and the Anti-grind
Feature
............................................ 13
Shock Sense, Warn-away Sense.... 13
Disarmed Notification ...................... 13
Siren or Horn Chirps........................ 13
Car Finder ....................................... 13
Siren or Horn Chirp Timing.............. 13
Safe Start ........................................ 13
Home Valet TM................................. 14
Ignition-controlled Door Locks......... 14
Ignition Re-lock................................ 14
Secure Lock .................................... 14
Turbo Mode..................................... 14
Remote Trunk Release ................... 14
Engine Run Time............................. 14
Multi-car Operation.......................... 14
L.E.D. Intrusion Codes.......................... 14
Troubleshooting Poor Transmitting
Range
................................................... 15
Diagnostics – Chirps Table................... 15
Diagnostics – Parking Light Flash
Table
..................................................... 16
Introduction
This System is a state-of-the-art remote car starter and alarm combo system. The system is
packed with advanced features such as priority access to the driver’s door and Car Finder
(commodity features), last armed state memory in case of power failure (which ensures that the
vehicle remains protected after a power failure recovery) and the Safe Start children safety feature.
With many advanced functions, this product will satisfy any one your expectations from high-end
commodity and security systems, without neglecting any standard feature commonly offered by
entry-level starters.
Using the Remote Control
Your Remote Car Starter is equipped with a 5-button multi-channel remote control. It can operate
two independent vehicles equipped with a Remote Car Starter (see Multi-Car Operation section,
later in this Guide, for second-car transmitter functions).
The functions of the transmitter are as follows:
LCD Remote Functions
The Transmitter offers several command-confirmation and timer features. This
section explains some of the key functions available on the Remote Control. Next
section gives a summary of the button combinations used to access the functions
(see LCD Remote Operation Tables).
Note:
If you wish to exit a function while still in the process of accessing it, simply stop and wait for at
least 10 seconds: the Remote Control will return to its normal state.
Basic Vehicle Operation
The vehicle can be remote-started and stopped using the
START/STOP ( ) button. The
TRUNK ( ) button will open the Trunk (if this feature is installed on the vehicle). The LOCK
(
) and UNLOCK ( ) buttons will lock and unlock the Doors of the vehicle (if the Remote
Door Lock feature is installed on the vehicle) and arm or disarm the Starter Kill (if installed).
User Guide P. 3
The FUNCTION ( ) button is used to access all advanced functions of the Remote Control.
(Refer to the LCD Operation and Confirmations tables.)
Alarm Clock
The LCD Remote Control has a built-in Alarm Clock which can be set up using the
but-
ton. Use the
and buttons to switch the Alarm Clock on and off (refer to the tables).
Time Adjust Mode
Use Time Adjust Mode to set the current time on your Remote Control using the
button
(refer to the tables).
Countdown Timer
This feature allows set up a countdown of a duration entered by the user in hours and
minutes using the button (refer to the tables).
Parking Countdown
This version of the Countdown feature is particularly useful for keeping track of parking
meter time: the user may quickly set up the countdown in slices of 10 or 30 minutes using
the
and buttons (refer to the tables).
Melody Selection
The Remote Control allows the user to select which melodies are to be used upon the
following events: remote starting of the vehicle, the Alarm, ending of the countdown,
entering Cold Weather Mode. Melodies for these various events can be selected using the
button (refer to the tables).
Vibration Mode
Use this feature to replace audible signals with a vibration signal. Use the
and
buttons to switch Vibration Mode ON and OFF (refer to the tables).
Power Saving Mode
When set to Power Saving Mode, the Remote Control will cease polling the Remote Starter
Module on a regular basis for status information. This will extend battery life. Use the
and buttons to switch Power Saving Mode ON and OFF (refer to the tables).
Remote Control Finder
This function allows the user to locate the Remote Control when it has been accidentally
dropped near the vehicle. Pressing the Valet Button and holding it down for 3 seconds (or
until the Parking Lights flash five times) will cause the Remote Control to start beeping for
one minute. The beeping will stop by itself after one minute, or it can be switched off by
pressing the Lock (
) or the Unlock ( ) button on the Remote Control.
P. 4 User Guide
Door and Hood Monitoring
The remote control will warn the user when any sensor zone is either open or under attack:
If a door is left open, the remote control will beep once and the door will start flashing on the
Vehicle icon of the display. After If the door is closed, the remote control will beep a second
time and the door image will stop flashing after five seconds.
If the hood is left unclosed, the remote control will beep once and the hood will start flashing
on the Vehicle icon of the display. After If the hood is closed, the remote control will beep a
second time and the hood image will stop flashing after five seconds.
If the alarm detects an intrusion either through a door or through the hood, the alarm will be
triggered. This event will be reported on the remote control by the Intrusion Icon (
) which
will start flashing on the display. This will go on until either the Lock (
) or
the Unlock ( ) button is pressed on the remote control.
LCD Transmitter Operation (First Car Control)
Basic Vehicle Operation
FUNCTION BUTTON PRESSED ICON BUZZER INSTRUCTIONS /DESCRIPTION
LOCK
1 Beep
Locks the doors
and arms the Starter Kill (if
installed) and the alarm.
UNLOCK
2 Beep
Unlocks the doors and disarms
the Starter Kill (if installed) and
the alarm.
TRUNK or AUX 3
1 Beep Trunk output
START *
(see Runtime
Options below)
+
Melody Starts the engine
STOP
None Melody Stops the engine
Light ON
ON for 10 seconds
Press the
button once.
Transmitter Mode Selection
FUNCTION BUTTON PRESSED ICON BUZZER INSTRUCTIONS /DESCRIPTION
POWER-SAVING
MODE
+
Melody
VIBRATION MODE
+
Vibrates twice
ALARM CLOCK
MODE ON/OFF
+
Melody
Press once to switch the Alarm
Clock ON
Press twice to switch the Alarm
Clock OFF
Time or Alarm Clock Adjustments
User Transmitter
1. Press and hold the FUNCTION button until a
beep is heard
The backlight will turn on the moment the
FUNCTION button is pressed.
2. Upon hearing the beep, release the
FUNCTION button,
.............................. is displayed
3. Press and hold the FUNCTION button once
more
User Guide P. 5
4. Release the FUNCTION button when a beep
is heard,
.............................. is displayed
5. Press and hold the FUNCTION button once
more until a beep is heard,
6. Release the FUNCTION button .............................. is displayed
7. At that point, press and hold the FUNCTION
button until 2 beeps are heard.
............ The hour setting will start to flash.
Pressing the FUNCTION button
1X ...........................................Adjust hour (current time)
2X ...........................................Adjust minutes (current time)
3X ...........................................Adjust hour (Alarm)
4X ...........................................Adjust minutes (Alarm)
5X ...........................................Melody selection for the ringing of the alarm
6X ...........................................Activate (ON) / Deactivate (OFF) Alarm
7X ...........................................Adjust hour (countdown)
8X ...........................................Adjust minutes (countdown)
9X ...........................................Melody selection for the countdown
10X .........................................Activate (ON) / Deactivate (OFF) countdown
a. Press the button to increase the value or to activate or deactivate a function or to
toggle through the melodies.
b. Press the to decrease the value or to activate or deactivate a function or to toggle
through the melodies.
c. To save modifications, do not touch any buttons for approx 5 to 10 seconds. There
will be a beep and the
display will return to the time.
Cold Weather Mode
FUNCTION BUTTON PRESSED ICON BUZZER INSTRUCTIONS /DESCRIPTION
TO ENTER COLD
WEATHER MODE
1 Beep
Press and hold
for 3 seconds.
TO EXIT COLD
WEATHER MODE
None None
Press and hold
for 3 seconds
TO ENTER COLD
WEATHER MODE
IN SAFE START
MODE
X 2
1 Beep
Press
twice within 3 seconds.
Or: press and hold for 1 second
(melody) then press and hold for
3 seconds.
TO EXIT COLD
WEATHER MODE
IN SAFE START
MODE
X 2
None None
Press
twice within 3 seconds.
Or: press and hold for 1 second
(melody) then press and hold for
3 seconds.
Home ValetTM
FUNCTION BY PRESSING ICON BUZZER INSTRUCTIONS / DESCRIPTION
TO ENTER HOME
VALET ™ MODE
Step 1 : or
Step 2 :
+
simultaneously within 5 sec.
1 BEEP
Press
or ; within 5 seconds,
press
+
:
The remote control will display the
icon and you will hear 1 beep.
TO EXIT HOME
VALET ™ MODE
NONE NONE NONE
Insert the key in the ignition switch
and turn it to the IGNITION ON / RUN
position. The icon will disappear.
P. 6 User Guide
Countdown Timer
FUNCTION BY PRESSING ICON BUZZER
INSTRUCTIONS /
DESCRIPTION
COUNTDOWN
TIMER ADJUST
MODE (HOUR)
6 times
COUNTDOWN
TIMER ADJUST
MODE (MIN)
7 times
COUNTDOWN
TIMER ENDING
MELODY
SELECTION 1
8 times
5 Selections
1,2,3,4,5
COUNTDOWN
TIMER MODE
(ON / OFF)
9 times
/
button: press for upward
adjustment or for switching the
function ON.
button: press for downward
adjustment or for switching the
function OFF.
Parking Countdown
FUNCTION BY PRESSING ICON BUZZER
INSTRUCTIONS /
DESCRIPTION
1 time
Melody 10 MIN COUNT DOWN
2 times
Melody 20 MIN COUNT DOWN
3 times
Melody 30 MIN COUNT DOWN
4 times
Melody 60 MIN COUNT DOWN
5 times
Melody 90 MIN COUNT DOWN
6 times
Melody 120 MIN COUNT DOWN
FOR
PARKING
COUNTDOWN:
PRESS AND HOLD
THEN PRESS:
7 times
Melody PARKING COUNT DOWN OFF
Safe Start Mode
FUNCTION BY PRESSING ICON BUZZER
INSTRUCTIONS /
DESCRIPTION
START ON SAFE
START MODE
X 2
+
Melody
Press the button twice within
3 seconds. Or:
Press for 1 second (melody) then
press again for 1 second.
STOP ON SAFE
START MODE
None Melody
*Runtime (Cannot be programmed. Serves as indication only.)
FUNCTION BY PRESSING ICON GAS DIESEL
4 minutes 9 minutes
ENGINE RUNTIME
15 minutes 20 minutes
25 minutes 30 minutes
User Guide P. 7
LCD Transmitter Operation (Second Car Control)
Basic Vehicle Operation
FUNCTION BUTTON PRESS ICON BUZZER DESCRIPTION
LOCK
+
1 Beep
Locks the doors
and arms the Starter Kill (if
installed) and the alarm.
UNLOCK
+
2 Beep
Unlocks the doors and disarms
the Starter Kill (if installed) and
the alarm.
START
+
+
Melody Starts the engine
STOP
+
None Melody Stops the engine
Start and Stop While in Safe Start Mode
FUNCTION BUTTON PRESS ICON BUZZER DESCRIPTION
START ON SAFE
START MODE
+ X 2
+
Melody
Press the
and buttons
simultaneously twice within
3 seconds.
Press for 1 second (a melody
will be heard) then press 1sec
and a melody will be heard
again.
STOP ON SAFE
START MODE
+
None Melody
Remote-Starting Your Vehicle
Remote-starting
Press the START/STOP button for approx. 1 second. The parking lights will come ON and the remote
control will play a melody to inform you that the System has received your signal. Approximately 5
seconds later, the engine will start. The parking lights will remain
ON during the pre-programmed
run time of the engine.
If the vehicle does not start at the first attempt, the system will shut down, wait a few seconds and
try to start the engine again. There will be 3 start attempts before the system gives up.
Vehicle Presets
Heater & Heated Seat
When leaving the vehicle it is recommended to preset the accessory controls in preparation for the
next remote start. Settings for the blower motor (fan), front and rear, as well as heated seats (if
equipped) should not be left on
HIGH. It is recommended to leave the settings on LOW or MEDIUM
instead.
Windshield Wipers & Radio & Headlights
Certain vehicles require the radio and / or windshield wiper and / or headlight circuits to become
energized while running under remote start. When leaving the vehicle you must ensure that the
windshield wiper and headlight switches are
OFF. Leaving the headlight switch ON on certain types
of vehicles could cause them to remain
ON even after remote starter shut down, resulting in a dead
battery.
Driving Off
With the vehicle running under remote control, press the
UNLOCK button to disarm and unlock the
doors. Enter the vehicle and do the following:
P. 8 User Guide
User Guide P. 9
• Turn the ignition key to the IGNITION ON (RUN) position. (Do not turn the key to the CRANK
position while the engine is running. This would cause the starter motor to re-engage.)
• Press the brake pedal to disengage the remote starter unit.
You are now ready to drive off.
Using the System
Arming and Disarming the System
To disarm the alarm and Starter Kill (if installed) and unlock the doors (if installed):
1. Press and hold the UNLOCK button for approx. 1 sec.
You will hear two chirps if the Siren or Horn is so configured.
2. The icon will light up on the LCD display of the remote control. The parking lights will flash
twice and the L.E.D. will go out to confirm that the doors have been unlocked and that the
Starter Kill (if installed) and the alarm are disarmed.
In Passive Mode, the System will rearm automatically 30 seconds after unlocking unless the key is
meanwhile inserted in the ignition switch (see description of Passive Mode later in this Guide).
To arm the alarm and Starter Kill (if installed) and lock the doors (if installed):
1. Press and hold the LOCK button for approx. 1 sec.
You will hear one chirp if the Siren or Horn is so configured.
2. The icon will light up on the LCD display of the remote control. The parking lights will flash
once and the L.E.D. will flash slowly to confirm that the doors have been locked and that the
Starter Kill feature (if installed) and the alarm are armed.
Idle Mode
Convenience feature: Idle Mode allows you to keep the engine running and the doors
locked while you stop, for example, at a convenience store or for a short delivery.
This feature allows you to let the remote starter take over control of the vehicle (i.e. no Key in the
Ignition Switch) while the engine is running. For example, if you stop for a delivery or at a convenience store, lock your vehicle and leave it running for the length of a run cycle while you are away.
To leave the vehicle in Idle Mode:
1. With the engine running, press the LOCK or UNLOCK button (to unlock the doors) or the
START/STOP button on the remote control until the parking lights come on.
2. Remove the key and exit the vehicle. The engine will go on running.
3. Lock the doors if needed.
The engine will go on running until the user re-enters the vehicle or until the expiration of the
Engine Run Time .
Caution!!! Do not leave children or pets unattended in a vehicle standing in Idle Mode.
Turbo Mode
If Turbo Mode is configured at installation, it will allow a turbocharger to idle down after the user
leaves the vehicle: the unit will take over the vehicle and keep it running for 60 seconds (or until it
is shut down by remote control), then shut down the engine.
Proceed as follows to set the system to Turbo Mode:
1. With the engine already running, press the LOCK button on the transmitter until the
parking lights come ON.
2. Remove the ignition key from the ignition switch. The engine will go on running.
3. Exit the vehicle and close the door.
P. 10 User Guide
Press the TRUNK button to lock the doors; the engine will shut down after
60 seconds of Turbo Mode.
Valet Mode with the Valet Switch
When your vehicle is in Valet Mode, the remote starter functionalities are disabled. If the vehicle
needs to be serviced, or if you park it indoors, the Valet Mode will prevent the engine from being
remote-started accidentally.
To put the system i n t o Valet Mode:
1. Turn the ignition key to the IGNITION ON (RUN) position.
2. Within 3 sec., press the valet button. The parking lights will flash 3X and the L.E.D.
will come ON solid.
To take the system o u t o f Valet Mode:
1. Turn the ignition key to the IGNITION ON (RUN) position.
2. Within 3 sec., press and release the valet button. The parking lights will flash 2X and
the L.E.D. will turn itself OFF .
Note: Once Valet Mode is activated, the remote starter and alarm functions will be disabled.
Ignition Valet
This feature will allow you to remotely put your system into Valet Mode by using the ignition key
instead of the Valet button as above. Ignition Valet can be used without a Valet button installed.
To put the system i n t o Valet Mode:
• Insert the ignition key into the ignition switch. Within 10 sec.,
turn the key 5 times successively into the IGNITION ON / RUN and OFF positions.
• The parking lights will flash three times to indicate that the vehicle is now in Valet Mode.
The L.E.D. will come ON solid.
To take the system o u t o f Valet Mode:
• Insert the ignition key into the ignition switch. Within 10 sec., turn the key 5 times
successively into the IGNITION ON / RUN and OFF positions.
• The parking lights will flash twice to indicate that the vehicle is out of the valet mode and
the L.E.D. will turn itself OFF.
Note: With the Remote Valet activated, the remote starter and alarm functions will be disabled.
Start Attempts Indicator (Valet Mode)
This reveals start attempts made while the vehicle was in Valet Mode. The parking lights will:
• Come ON, go OUT; then
• Flash twice.
“Home Valet
TM
” Mode
If configured at installation, this feature will remotely set the vehicle to a no-remote-start mode: if
the vehicle is parked indoors there is no danger of it starting accidentally by remote control.
Note: Once the Home Valet Mode is activated, the vehicle will not start by remote.
To take the system i n t o Home Valet Mode:
• Press the LOCK or UNLOCK button.
• Within 5 seconds, press the Lock and START/STOP button simultaneously.
The transmitter will beep once and the Home Valet icon will start flashing.
The icon will flash until the vehicle exits Home Valet Mode.
To take the system o u t o f Home Valet Mode:
• Turn the ignition key to the IGNITION ON (RUN) position.
The system will warn you if someone attempts to start your vehicle while it stands in Home Valet
Mode. The parking lights will:
• Go ON then OFF; then
• Flash twice, pause; then
• Flash twice again.
Remote Valet Mode
This feature will allow you to remotely put your system into Valet Mode by using the transmitter
instead of the Valet button as above.
Getting i n t o Valet Mode
• Hold the UNLOCK and START/STOP buttons simultaneously for 3 seconds.
• The Parking Lights will flash 3 times.
The Transmitter will BEEP once and will display the icon; the LED will remain on solid.
Getting o u t of Valet Mode
• Hold the UNLOCK and START/STOP buttons simultaneously for 3 seconds.
• The Parking Lights will flash 2 times.
The Transmitter will BEEP once and the icon will disappear; the LED will turn off.
Note:
With the Remote Valet activated, the remote starter function will be disabled.
Panic Mode
In an emergency situation, you can activate Panic Mode using the LOCK or UNLOCK button. This will:
• shut down the engine,
• unlock the doors (with the
UNLOCK button)
• or lock the doors (with the
LOCK button),
• disarm the Starter Kill and
• activate the activate the siren for 1 minute.
Note: See the description of the Starter Kill option later in this Guide.
To activate Panic Mode:
• Press and hold the UNLOCK button for approximately 3 sec. until the sound signal starts
and the parking lights flash: this will unlock the doors before the sound signal starts.
• Or press and hold the LOCK button for approximately 3 seconds until the sound signal
starts and the parking lights flash: this will lock the doors before the sound signal starts.
Panic Mode will automatically shut down after 1 minute.
Note: To stop Panic Mode before the end of its delay, press the LOCK or UNLOCK button until
the sound signal stops.
Quick LockoutTM
(Also called Secure Panic.) For fast protection in emergency situations, the system will
LOCK all
doors when you press the brake pedal while you hear the sound signal. (Quick Lockout is
only available when Panic Mode has been set off.)
Cold Weather Mode
When Cold Weather Mode is active, the engine starts every 2 hours and runs for 4 minutes (or for
9 or 20 minutes with diesel engines). Cold Weather Mode automatically ends after 24 hours.
To enter Cold Weather Mode:
• Press and hold the START/STOP button for 3 seconds until the parking lights flash 3X.
The icon will appear on the display screen.
To exit Cold Weather Mode, do any one of the following actions:
• Open the hood.
User Guide P. 11
P. 12 User Guide
• Start the engine by remote.
• Turn the ignition key to the IGNITION ON (RUN) position.
• Press and hold the START/STOP button for 3 sec. (the parking lights will flash once).
Once any of the above conditions are true, the icon will disappear from the display upon
pressing the LOCK or UNLOCK button.
To verify whether the system is in Cold Weather Mode:
• Press and release the brake pedal:
If the vehicle is in Cold Weather Mode, the parking lights will stay on while the pedal is
pressed.
Temporary Chirp Delete
To temporarily disable the chirp confirmations of the siren upon arming and disarming (e.g. in a
quiet neighbourhood):
1. Press the TRUNK button.
2. Within 3 sec., press the LOCK or UNLOCK button to arm or disarm without any chirps.
Advanced Features: Installation-programmable Options
The System was designed with flexibility and OEM integration in mind. With its programmable
options, this unit can single-handedly control nearly any electrical system in your vehicle.
Caution: The programming of your system should be left to a professional. Changing any
one of the settings may affect the operation of your System.
The installation-programmable options are as follows:
• Remote Door Locks
• Priority Door Access
• Passive or Active Arming
• Starter Kill / Anti-grind feature
• Shock Sense and Warn-away
• Disarmed Notification
• Siren / Horn Chirps
• Car Finder
• Siren / Horn Chirp Timing
• Safe Start
• Ignition-controlled Door Locks
• Ignition Re-lock
• Secure Lock
• Turbo Mode
• Remote Trunk Release
• Engine Run Time
• Multi-car Operation
Remote Door Locks
If your System was installed with the Remote Door Locks option, you will have the convenience of
remote keyless entry. See section Arming and Disarming the System, earlier in this Guide, for
further instructions on remote door locking and unlocking.
Priority Door Access
(Enabled by default.) If the Remote Door Locks option is installed on your vehicle, this safety
feature allows you unlock solely the driver’s door with a single press of the
UNLOCK button on the
transmitter; upon a second press of the
UNLOCK button, all the other doors will unlock.
Active or Passive Arming
(Passive Mode by default.) The alarm and Starter Kill can be configured either to Passive Mode (so
as to arm automatically) or Active Mode (so as to require user intervention for arming). By default,
your System is configured to Passive Mode. In Passive Mode, the alarm and Starter Kill will
automatically arm 30 seconds after the last door is closed. The System will not arm if a door is left
open, or if you re-open a door within the 30-second delay.
Important note: When the System re-arms automatically or if there is an alarm condition, you
can disarm the When the System by simply pressing the UNLOCK button.
User Guide P. 13
The Starter Kill and the Anti-grind Feature
With this added security feature, the system will prevent your vehicle from starting with the ignition
key when the Starter Kill is armed. If your System was installed with the Starter Kill option, one will
not be able to start your vehicle with the key unless the system has been unlocked and disarmed
first, or put into Valet Mode.
Note: If the Starter Kill is installed, your vehicle will benefit from a protection against starter
motor damage that could occur after remote-starting the engine should the user, by force of
habit, turn the ignition key to the CRANK position.
Shock Sense, Warn-away Sense
(Both enabled by default.) Your System will react to a full shock by triggering the alarm; it can also
respond to a lighter shock (30 % of the strength of a full shock) by giving a warn-away (without
triggering an alarm condition). When the engine is running after a remote start, however, the
System will prevent any alarm condition to be triggered; it will still give a warn-away if this
feature has not been disabled at installation.
Note: After a remote start, although the shock sensor is disabled, all the other alarmtriggering zones, such as the doors or the hood, may still trigger an alarm.
Disarmed Notification
(Off by default.) This feature will notify the user when the vehicle was left disarmed: after the
engine is shut down (with the key removed) and all doors are closed, the siren will chirp once after
a 10-sec. notification delay to warn the user that the vehicle was left unprotected. The notification
can be avoided by pressing the
LOCK or UNLOCK button on the transmitter.
The user will likewise be notified after the System is disarmed using the transmitter.
Siren or Horn Chirps
(
ON by default.) The siren will chirp to confirm basic operations on the System:
• By default, upon locking the doors the siren will give one chirp if no protection zone is active.
• If a zone is active as the doors are being locked, the siren will give three chirps.
• When the doors are being unlocked, the siren will give two chirps if no intrusion was detected.
• If an intrusion was detected, as the doors are being unlocked the siren will give four chirps.
The system can alternatively be set to:
Warning Mode: no chirp during lock/unlock…
• unless a zone is active when locking, in which case there will be 3 chirp upon locking
• or unless the alarm was triggered, in which case there will be 4 chirps when unlocking);
Open Zone Notification Mode: 3 warning chirps if a door is left open 10 sec. after arming.
No Chirp: the siren will not chirp under any circumstance.
Car Finder
(Enabled by default.) When enabled, the Car Finder option will help you locate your vehicle by
generating a pulsating signal through the horn or the siren. To hear the signal, press the
LOCK and
UNLOCK buttons simultaneously. This will cause a pulsating signal lasting for the time you keep the
buttons pressed.
Siren or Horn Chirp Timing
The duration of the chirps can be adjusted at installation (from 5 to 200 ms).
Safe Start
If this feature is enabled, the user must press the
START/STOP button 2 times within 3 seconds to
remote-start the vehicle. This will eliminate accidental remote starts, e.g. when children are playing
with the transmitter.
If Swap Start Mode is selected, to remote-start your vehicle press
LOCK and UNLOCK
simultaneously. The
AUX 2 output can be activated by pressing the START/STOP button.
P. 14 User Guide
Home Valet TM
If this feature is installed, the user will have the possibility to remotely set the vehicle to a noremote-start mode. See Home Valet section, earlier in this Guide, for full instructions.
Ignition-controlled Door Locks
This is an added security feature. If your Systems was installed with the Ignition-Controlled Door
Locks option, the doors will automatically be locked as soon as the ignition key is turned to the
IGNITION ON (RUN) position while the brakes are pressed. When the key is turned to the OFF position,
the doors will automatically be unlocked.
Ignition Re-lock
On Systems of this series, when Ignition-controlled Door Locks are enabled and the ignition key is
in the
IGNITION ON (RUN) position, should any door be unlocked and opened, all doors will be
relocked next time the brake pedal is pressed.
Secure Lock
Before it can remote-start your vehicle, the System must first disarm the factory security system.
The Secure Lock feature may be required on certain vehicle models with factory security systems
that automatically unlock the doors when the security system is disarmed.
To keep your vehicle protected when the factory security system is disarmed for a remote start,
Secure Lock will relock your doors as soon as the vehicle has started. Once the engine run cycle
ends, Secure Lock will rearm your factory security system.
Turbo Mode
When left in Turbo Mode, the System will keep the engine running for 60 seconds before shutting it
down. This is to allow a turbocharger to idle down after the user leaves the vehicle. See Turbo
Mode section earlier in this Guide.
Remote Trunk Release
If your system was installed with the Remote Trunk Release option, you can open your trunk by
pressing the
TRUNK button for 3 seconds on the remote transmitter or by pressing the TRUNK button
TWICE within 3 seconds.
Engine Run Time
If you have a gas engine, your System can be programmed to run the engine for 4, 15, or
25 minutes (15 minutes by default). If you have a diesel engine, the System can be programmed to
run the engine for 9, 20, or 30 minutes (20 minutes default).
Multi-car Operation
This option allows the owner of two vehicles, both equipped with System systems, to control both
systems with a single remote control. To control the second vehicle, simultaneously press the
TRUNK button and the button of the function you wish to use. See the transmitter operation table
earlier in this Guide. for full instructions on second car operation.
Note: Your remote control must be configured for second car operation by the installer.
L.E.D. Intrusion Codes
If an intrusion took place while your vehicle was locked and the system was armed, the L.E.D. will
provide feedback on the intrusion. The L.E.D. intrusion codes are flashed by the L.E.D. in
continuous loops and are as follows:
User Guide P. 15
1 flash = power-up reset: battery
disconnected and reconnected, or dead
battery.
2 flash = doors intrusion
3 flash = shock sense
4 flash = hood intrusion
5 flash = panic
6 flash = ignition
Troubleshooting Poor Transmitting Range
Many factors may affect the operating range of the transmitter. Some of these are:
• The condition of the battery in the transmitter.
• The operating environment (for example: downtown radio-frequency noise, airports, cellular
phone towers…)
• Metal: any type of metal will affect operating range. This includes the metal in the car.
• The shape of the vehicle can affect range as well; vans in general have an especially poor
range.
• The shape of the roof and A-pillars brings about considerable radio-frequency deflection (in
this case the signal from the remote control). As a result, the direction in which the vehicle is
facing in relation to the remote control can affect the range. Straight on – standing in front of
the vehicle – generally gives you the greatest range; the second best performance is from the
back. Using the remote control from either side of the vehicle will usually give the lowest
range.
• The range will be significantly lower in a crowded parking lot than in open space.
• Always hold the transmitter high, approximately at shoulder height. Holding the transmitter
against your chin will also increase your range: your head acts as an antenna.
• The operating range will be somewhat lower on vehicles equipped with an aftermarket or
factory alarm.
Diagnostics – Chirps Table
Chirps
Description
1
• Doors locked, alarm and starter kill armed.
•
LOCK confirmation.
• Entering mode 1 in the programming centre.
• Disarmed notification
2
• Doors unlocked, alarm and starter kill disarmed.
• Transmitter programmed.
• Entering mode 2 in the programming centre.
3
•
LOCK and arm while a zone is left unprotected.
• Entering mode 3 in the programming centre.
• Door zone left unprotected.
4
•
UNLOCK and disarm: an intrusion was detected (in warning chirps mode or
full chirps mode).
• Entering tach-programming mode.
5
• Siren or horn chirp timing adjustment
Constant up
to 30 seconds
• In horn mode: alarm condition generated by an intrusion, by panic mode or
when the system is powered up. The horn will sound for 30 sec.
Constant up
to 60 seconds
• In siren mode: alarm condition generated by an intrusion, by panic mode or
when the system is powered up. The siren will sound for 60 sec.
P. 16 User Guide
Diagnostics – Parking Light Flash Table
Flashes
Description
1
• Doors locked, alarm and starter kill armed.
• End of run time.
•
TRUNK button pressed
• Start signal received by the system.
• Cold weather mode cancelled.
• Cannot start after maximum number of attempts is reached.
2
• Doors unlocked, alarm and starter kill disarmed.
• Run time cancelled.
• Exit remote valet.
• Exit ignition valet
• Remote start attempt cancelled by remote.
3
• Entering cold weather mode.
• Entering remote valet.
• Entering ignition valet
4
• +12 V where detected on the brake line and cranking was cancelled.
• Entering tach-programming mode
5
• New transmitter programmed.
• Tach programmed.
6
• A remote start was attempted while a tach or a vacuum signal was detected
before cranking.
8
• Unit reset: occurs when the unit is reset to the factory defaults.
10
• The hood switch line went to ground during cranking or run time.
1 – pause – 2
• There was an attempt to start the vehicle while the system was in valet
mode.
2 – pause – 2
• There was an attempt to start the vehicle while the system was in home valet
mode.
ON solid
• Cold weather mode: the brake pedal is being held down.
ON 2 sec.
• The hood is up and the hood switch line went to ground. This is step one of
the programming centre procedure.
ON 3 sec.
• First press of the START/STOP button under safe start.
ON 4 sec.
• Locking or unlocking a door (with door pulses configured to 4 sec.)
ON 25 sec.
• The hood pin-switch has been pressed twice: the unit went into step 1 of the
programming centre procedure, and no transmitter activity was detected for
20 seconds.
• Or the Unit went into step 1 of the transmitter programming procedure and
no activity was detected for a few seconds. The unit has exited the
transmitter programming procedure.
Irregular
• If the unit gives irregular signals (1 to 10 flashes followed by a pause,
followed by further flashes), the system is playing back start failure codes.
This occurs when the hood pin-switch is pressed three times.
Constant
flashes
up to 30 sec.
• In horn mode: alarm condition generated by an intrusion, by panic mode or
when the system is powered up.
Constant
flashes
up to 60 sec.
• In siren mode: alarm condition generated by an intrusion, by panic mode or
when the system is powered up.
Loading...
