Page 1
PBS-FS
Wood Style Piano Bench
With Storage Compartment
Owner’s Manual
Page 2
Introduction
Thank you for choosing the Auray PBS-FS wood-style
piano bench with storage compartment. This sturdy piano
bench is an elegant accessory for use with a keyboard or
piano. The traditional style features a one-inch leather seat
providing comfort through many hours at the keyboard.
A storage compartment for sheet music and other
accessories is located inside the bench.
Warnings
This product has been tilt-stability tested. Auray is not responsible
for injury due to improper use. Bench must be on a level surface
with all four legs touching the surface at the same time.
• Please read and follow these instructions, and keep this
manual in a safe place.
• Make sure that this product is intact and that there are
no missing parts.
• Make sure all parts are secure before using.
• All photos are for illustrative purposes only.
!
Page 3
Overview
1
Seat
1
Corner brackets
Legs (4)
Attachment bolts
Washers (4)
2
3
4
5
Locking washers (4)
Nuts (4)
Wrench
7
8
2
6
3
4
5
6
7
8
Owner’s Manual Owner’s ManualOwner’s Manual
3 42 PBS-FS PBS-FSPBS-FS
Page 4
Instructions
Assembling the PBS-FS
1. Place the piano bench on
its side on a stable surface.
Position it so that the
open seat lays flat on the
surface exposing the corner
brackets inside the storage
compartment.
2. Attach each leg to the corner
brackets by aligning the bolt
with the hole and inserting it
through the corner bracket.
3. Attach a washer, locking
washer and a nut to the end of
the bolt and tighten them by
2
hand.
4. Once all legs have been
attached, place the bench
in the upright position on a
flat surface, and complete
tightening the nuts with the
included wrench.
Do not over-tighten the nut.
Over tightening can damage
the piano bench.
3
1
2
1
3
Page 5
Specifications
Height: 19.25" (48.9 cm)
Width: 13.2" (33.5 cm)
Length: 22.5" (57.2 cm)
Weight: 13.95 lbs. (6.33 kg)
Seat dimensions (W x L): 13.2" × 22.5" (33.5 × 57.2 cm)
Storage compartment dimensions
(H × W × L):
Weight Capacity: Up to 250 lbs. (113.4 kg)
3" × 10.2" × 19" (7.6 × 25.9 × 48.3 cm)
Page 6
One-Year Limited Warranty
This AURAY product is warranted to the original purchaser to be
free from defects in materials and workmanship under normal
consumer use for a period of one (1) year from the original purchase
date or thirty (30) days after replacement, whichever occurs later.
The warranty provider’s responsibility with respect to this limited
warranty shall be limited solely to repair or replacement, at the
provider’s discretion, of any product that fails during normal use of
this product in its intended manner and in its intended environment.
Inoperability of the
the warranty provider. If the product has been discontinued, the
warranty provider reserves the right to replace it with a model of
equivalent quality and function.
This warranty does not cover damage or defect caused by misuse,
neglect, accident, alteration, abuse, improper installation or
maintenance. EXCEPT AS PROVIDED HEREIN, THE WARRANTY
PROVIDER MAKES NEITHER ANY EXPRESS WARRANTIES NOR
ANY IMPLIED WARRANTIES, INCLUDING BUT NOT LIMITED TO
ANY IMPLIED WARRANTY OF MERCHANTABILITY OR FITNESS
FOR A PARTICULAR PURP
specific legal rights, and you may also have additional rights that
vary from state to state.
To obtain warranty coverage, contact the Auray Customer Service
Department to obtain a return merchandise authorization (“RMA”)
number, and return the defective product to Auray along with the
RMA number and proof of purchase. Shipment of the defective
product is at the purchaser’s own risk and expense.
product or part(s) shall be determined by
OSE. This warranty provides you with
For more information or to arrange service, visit www.aurayaudio.com
or call Customer Service at 212-594-2353.
Product warra
nty provided by the Gradus Group.
www.gradusgroup.com
AURAY is a registered trademark of the Gradus Group.
© 2014 Gradus Group LLC. All Rights Reserved.
