Page 1
PBS-AP
Premium Wood Piano Bench
With Adjustable Height
Owner’s Manual
Page 2
Introduction
Thank you for choosing the Auray PBS-AP premium wood
piano bench with adjustable height. This elegant, concertstyle piano bench is suitable for use in a concert hall,
studio, or at home. It features wood construction and an
antique-style leather seat for comfort through many hours
at the keyboard. The seat height can be precisely set by the
performer, even while seated at the keyboard, by using the
dual height adjustment knobs.
Warnings
This product has been tilt-stability tested. Auray is not responsible
for injury due to improper use. Bench must be on a level surface
with all four legs touching the surface at the same time.
• Please read and follow these instructions, and keep this
manual in a safe place.
• Make sure that this product is intact and that there are
no missing parts.
• Make sure all parts are secure before using.
• All photos are for illustrative purposes only.
!
Page 3
Overview
1
Seat
Height adjustment
2
knobs
Corner brackets
Legs (4)
3
4
Threaded socket
Bolts (4)
Washers (4)
Wrench
6
7
8
2
5
1
3
4
5
6
7
8
Owner’s Manual Owner’s ManualOwner’s Manual
3 42 PBS-AP PBS-APPBS-AP
Page 4
Instructions
Assembling the PBS-AP
1. Place the piano bench upside
down on a stable surface.
2. Align the threaded socket of
the leg with the hole on the
corner bracket.
3. Insert the washer and bolt
through the metal bracket,
and screw it into the threaded
socket of the leg.
4. Complete tightening the bolt
to the leg with the included
wrench until it is securely in
2
place.
Do not over-tighten the bolt.
Over tightening can damage
the piano bench.
5. Stand the bench upright and
place it on a flat surface.
1
Adjusting the height
1. To adjust the height of the
PBS-AP, turn one or both of the
side height adjustment knobs.
3
1
2
3
Note: Adjusting the height with one knob or both adjusts
the overall height of the seat. The height of the legs does not
adjust independently.
Page 5
Specifications
Height: 19" - 22" (48.3 - 55.9 cm)
Width: 13.25" (33.7 cm)
Length: 26" (66.0 cm)
Weight: 15.85 lbs. (7.19 kg)
Seat dimensions (W x L): 13.25" × 22" (33.7 × 55.9 cm)
Weight Capacity: Up to 360 lbs. (163.3 kg)
Page 6
One-Year Limited Warranty
This AURAY product is warranted to the original purchaser to be
free from defects in materials and workmanship under normal
consumer use for a period of one (1) year from the original purchase
date or thirty (30) days after replacement, whichever occurs later.
The warranty provider’s responsibility with respect to this limited
warranty shall be limited solely to repair or replacement, at the
provider’s discretion, of any product that fails during normal use of
this product in its intended manner and in its intended environment.
Inoperability of the
the warranty provider. If the product has been discontinued, the
warranty provider reserves the right to replace it with a model of
equivalent quality and function.
This warranty does not cover damage or defect caused by misuse,
neglect, accident, alteration, abuse, improper installation or
maintenance. EXCEPT AS PROVIDED HEREIN, THE WARRANTY
PROVIDER MAKES NEITHER ANY EXPRESS WARRANTIES NOR
ANY IMPLIED WARRANTIES, INCLUDING BUT NOT LIMITED TO
ANY IMPLIED WARRANTY OF MERCHANTABILITY OR FITNESS
FOR A PARTICULAR PURP
specific legal rights, and you may also have additional rights that
vary from state to state.
To obtain warranty coverage, contact the Auray Customer Service
Department to obtain a return merchandise authorization (“RMA”)
number, and return the defective product to Auray along with the
RMA number and proof of purchase. Shipment of the defective
product is at the purchaser’s own risk and expense.
product or part(s) shall be determined by
OSE. This warranty provides you with
For more information or to arrange service, visit www.aurayaudio.
com or call Customer Service at 212-594-2353.
Product
warranty provided by the Gradus Group.
www.gradusgroup.com
AURAY is a registered trademark of the Gradus Group.
© 2014 Gradus Group LLC. All Rights Reserved.
GG1
Owner’s ManualOwner’s Manual
65 PBS-APPBS-AP
