Installation Guide
M3
TRI-ELEMENT HANGING
CEILING MICROPHONE
Installation Guide
IN THE PACKAGE
1 2
4
1 M3 Tri-element Hanging Ceiling Microphone
2 JBM3 - Plenum rated junction box circuitry
3 Junction box lid
4 Breakout cable consisting of RJ45 female to three terminal block connectors
5 Seismic / Fire restraint cable
3
5
OPTIONAL ACCESSORIES
6
7
8
PLENHSEM3 brass plenum bell housing (patent pending). This brass housing is
specifically designed to provide a plenum seal when threaded on to the plenum
junction box. The bell housing is included with all Audix CAT 7 prepackaged
interface cables (see below for models), and may be purchased separately for bulk
cable runs.
CBLM3XLR breakout cable consisting of an RJ45 female to three XLR male
connectors. This cable is designed to be used in conjunction with Audix CAT 7
interface cable, keeping the shielded and balanced audio path intact when
connecting to the three mic level XLR inputs of a DSP Controller.
CAT7 Interface cable. Audix manufactures a high quality CAT 7 cable optimized for
balanced audio and cross talk elimination. The cable is LS0H (low smoke zero halogen)
and consists of four twisted pairs that are individually shielded, RJ45 male connectors
and a brass housing to further seal the cable at the plenum rated junction box. The
interface cable is available in prepackaged lengths or in bulk (see below for models).
CBLM307 - Interface Cable 7 meters (23’)
CBLM310 - Interface Cable 10 meters (33’)
CBLM315 - Interface Cable 15 meters (49’)
CBLM320 - Interface Cable 20 meters (66’)
CBLM325 - Interface Cable 25 meters (82”)
Note: The Audix M3 also works with CAT 5 and CAT 6 cable, however, Audix recommends
using shielded cable.
CBLM330 - Interface Cable 30 meters (98”)
CBLM350 - Bulk cable. 50 meters (162’).
Use with brass plenum bell housing #6
for best results.
CBLM3100 - As above. 100 meters (325’)
