PROFESSIONAL DRUM AND
FP5
FP5
OVERVIEW
Audix revolutionized drum and percussion miking by designing instrument
specific microphones. With the introduction of the Fusion Series, Audix created two
attractively priced packages for todays up and coming professionals.
The FP5 Drum Pack contains a combination of f2, f5 and f6 dynamic microphones.
The f5 is tuned for snare drum and can be used as well for bongos, timbales, guitar
cabinets and acoustic instruments; the f2 is ideally suited for rack and floor toms,
congas, djembe, bongos, timbales, brass and woodwind instruments. The f6, with its
extended bass response, is designed for kick drum, bass cabinets, cajon and other low
frequency instruments.
Built to withstand the rigors of live stage applications, the Fusion Series mics are
also excellent for rehearsal, school, House of Worship and a wide variety of home
recording applications.
PERCUSSION MIC PACKAGE
INCLUDES
SUPPLIED ACCESSORIES
DCLIP - Heavy duty mic clip provided with D
& SCX Series (4)
MC1 - Nylon mic clip (1)
DFLEX - Dual pivot rim mounted clip with extra wide butterfly jaws (4)
OPTIONAL ACCESSORIES
DVICE - Flexible mini-gooseneck with spring loaded rim mount clamp
DCLAMP - Flexible mini-gooseneck with drum tension lug mount
CBL20 - 20’ premium XLR-XLR balanced mic cable. Quad conductor, twisted pair with
braided shield for maximum conductivity. 6mm PVC jacketed.
CBLDR25 - 25’ premium right angle XLR-XLR balanced mic cable. Quad conductor,
twisted pair with braided shield for maximum conductivity. 6mm PVC jacketed.
STANDKD - Short pedestal stand with telescoping boom arm
PACKAGED SET OF 5 DRUM MICS
Aluminum road case
3 x f2 rack and floor tom mics
1 x f5 snare mic
1 x f6 kick drum mic
DCLIP DFLEX DVICE DCLAMP CBL20 CBLDR25 STANDKD
MC1
SPECIFICATIONS
FP5
f2 f5
Transducer
Frequency Response
Polar Pattern
Output Impedance
Sensitivity
Maximum SPL
OFF-axis rejection
Power Requirements
Materials / Finish
Weight
Length
Dynamic Dynamic Dynamic
52 Hz - 15 kHz 55 Hz - 15 kHz 40 Hz - 16 kHz
Hypercardioid Hypercardioid Hypercardioid
580 ohms 580 ohms 580 ohms
2 mV / Pa @ 1k 2.2 mV / Pa @ 1k 1.2 mV / Pa @ 1k
≥139 dB ≥137 dB ≥140 dB
≥20 dB ≥20 dB ≥23 dB
None None None
Zinc Alloy/ Black Finish Zinc Alloy/ Black Finish Zinc Alloy/ Black Finish
247 g / 8 oz 283 g / 10 oz 311 g / 11 oz
104 mm / 4.09 in 145 mm / 5.7 in 121 mm / 4.76 in
USER TIPS
The f2 and f6 microphones are supplied with the DCLIP, a heavy
duty nylon stand adapter with snap-to-fit design; the f5 is supplied
with the MC1 mic clip. Each clip comes with a 3/8” thread adapter
which is mainly used with European mic stands.
The following are some ideas as to how the microphones in the
packs interact with each other.
Kick drum: The f6 is the kick drum mic. A great accessory to help
position the f6 is the STANDKD, which is specifically designed for
that application. To position the f6, a good starting point is to place
the mic inside the front hole of the kick drum, pointing toward the
beater. (Tip: be sure that the grill is completely inside the hole). For
more attack, move the mic closer toward the head, making sure not
to position the mic right in front of the beater.
f6
Snare and toms: The f2 (snare) and f5 (toms) are designed to be close miked. A
good starting point is two inches above the rim with the mic pointing toward the
center of the head. For more “rim” sound, pull the mic back closer to the rim. For
more resonance and depth of field, pull the mic further away from the head. The
trick is to find the right balance between resonance while controlling bleed from
the other drums.
For more tips on miking your kit, please refer to the Audix DVD on “H
ow to Mic your
Drums” or visit the www.audixusa.com.
PRODUCT REGISTRATION: Please register your product online at www.audixusa.com/docs_12/about/product_registration.shtml.
SERVICE AND WARRANTY:
or workmanship, Audix will repair or replace said product at no charge with proof of purchase. Audix does not pay or reimburse shipping costs for warranty repairs or returns. The warranty excludes
any causes other than manufacturing defects, such as normal wear, abuse, environmental damage, shipping damage or failure to use or maintain the product per the supplied instructions. No
Implied Warranties: All implied warranties, including but not limited to implied warranties of merchantability and fitness for a par
for damages relating to allegedly defective products shall be limited to the actual price paid by Dealer for such products and shall in no event include incidental or consequential damages of
any kind. Should your microphones fail in any way, please contact the Audix Ser vice department at 503.682.6933. A Return Authorization is required before returning any product. OTHER THAN
THIS WARRANTY, AUDIX MAKES NO WARRANTIES, EXPRESS OR IMPLIED, WITH RESPECT TO THE PRODUCTS, THE USE OF THE PRODUCTS, THE PERFORMANCE OF THE PRODUC TS. AUDIX SHALL
NOT BE LIABLE FOR SPECIAL INCIDENTAL, CONSEQUENTIAL, INDIRECT OR SIMILAR DAMAGES ARISING FROM OR BASED ON THE SALE, USE, STORAGE OR DISPOSAL OF THE PRODUCTS, AUDIX’S
SERVICE WORK, BREACH OF WARRANTY, BREACH OF CONTRACT. NEGLIGENCE, OR ANY OTHER THEORY OF LIABILITY, EVEN IF AUDIX HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES.
ALL SPECIFICATIONS SUBJECT TO CHANGE WITHOUT NOTICE.
These microphones are under warranty for a period of 3 years to be free of defects in material and workmanship. In the event of a product failure due to materials
ticular purpose are hereby excluded. The liability of Audix, if any,
www.audixusa.com
Audix Corporation 9400 SW Barber St. Wilsonville, OR 97070
503.682.6933 Fax: 503.682.7114
