SRC
MEM
USER’S
MANUAL
rev. 1.1
USER’S MANUAL
bit Nove /
Index
1. PRODUCT DESCRIPTION / PRECAUTIONS .........................................................................................................................3
2. PACKAGE CONTENTS ............................................................................................................................................................... 3
3. BIT NOVE and DRC INSTALLATION ...................................................................................................................................... 4
4. CONNECTION PANEL DESCRIPTION ....................................................................................................................................5
1 LOGO STATUS .......................................................................................................................................................................5
2 POWER AND CONTROL CABLE. ........................................................................................................................................ 6
3 PRE INPUT ............................................................................................................................................................................. 7
4 SPEAKER OUT. ......................................................................................................................................................................7
5 OPTICAL IN 1/2: S/PDIF DIGITAL INPUTS. ....................................................................................................................8
6 AUX: LOW-LEVEL AUXILIARY STEREO INPUT. ..............................................................................................................8
7 PRE OUT: LOW-LEVEL ANALOG SIGNAL (4 Volts RMS) ..............................................................................................8
8 INPUT LEVEL ........................................................................................................................................................................8
9 DRC . .................................................................................................................................................................................. 8
10 USB . .................................................................................................................................................................................. 8
11 UPGRADE MODE. ................................................................................................................................................................. 8
12 ASC-C . .................................................................................................................................................................................. 8
5. CONNECTIONS ........................................................................................................................................................................... 9
5.1 POWER SUPPLY AND REMOTE TURN ON......................................................................................................................9
5.2 INPUT SIGNALS ..................................................................................................................................................................10
5.3 DIGITAL OPTICAL IN INPUT SIGNALS...........................................................................................................................14
5.4 OUTPUT SIGNALS ..............................................................................................................................................................15
5.5 PERSONAL COMPUTER AND DIGITAL REMOTE CONTROL (DRC). ........................................................................16
6. GUIDE FOR INSTALLING/UNINSTALLING BIT NOVE SOFTWARE AND DRIVERS ....................................................17
6.1 GUIDED PROCEDURE FOR PC SOFTWARE INSTALLATION .....................................................................................17
6.2 GUIDED PROCEDURE FOR DRIVER INSTALLATION ..................................................................................................19
6.3 UNINSTALLING BIT NOVE SOFTWARE .........................................................................................................................19
7. HOW TO SET UP THE BIT NOVE USING A PC ...................................................................................................................20
7.1 OFFLINE MODE ...................................................................................................................................................................20
7.2 TARGET MODE ...................................................................................................................................................................21
7.3 ADJUSTING ACOUSTIC REPRODUCTION ....................................................................................................................27
7.3.1 DEVICE INFO. ..........................................................................................................................................................27
7.3.2 FILE MAIN MENU ................................................................................................................................................... 28
7.3.3 MEMORIES MAIN MENU ...................................................................................................................................... 28
7.3.4 SETTINGS MAIN MENU ........................................................................................................................................29
7.3.5 DEVICE MAIN MENU ............................................................................................................................................. 31
7.3.6 HELP MAIN MENU .................................................................................................................................................32
7.3.7 SELECTED INPUT ..................................................................................................................................................32
7.3.8 CHANNEL MAP ......................................................................................................................................................32
7.3.9 SELECT CHANNEL ................................................................................................................................................. 33
7.3.10 FILTER SETTINGS ..................................................................................................................................................33
7.3.11 SET DISTANCE AND DELAY ................................................................................................................................35
7.3.12 PARAMETRIC EQUALIZER ...................................................................................................................................38
7.3.13 OUTPUT LEVEL ...................................................................................................................................................... 39
7.3.14 MEMORY .................................................................................................................................................................39
7.3.15 STATUS BAR ...........................................................................................................................................................39
8. TROUBLESHOOTING ...............................................................................................................................................................40
8.1 SYNCHRONIZATION WITH A PC .....................................................................................................................................40
8.2 BACKGROUND NOISE .......................................................................................................................................................40
8.3 FIRMWARE UPGRADE .......................................................................................................................................................41
8.3.1 TATRGET MODE UPDATE. ...................................................................................................................................41
8.3.2 RESCUE MODE UPDATE .......................................................................................................................................42
9. TECHNICAL SPECIFICATIONS ..............................................................................................................................................44
2
USER’S MANUAL
bit Nove /
1/2
1. PRODUCT DESCRIPTION / PRECAUTIONS
The bit Nove is a digital signal processor essential to maximize the acoustic performance of a car audio system.
It features a 32-bit DSP processor with 24-bit A/D and D/A converters. It can be interfaced to any OEM system, even on
vehicles equipped with integrated sound processor, since thanks to the de-equalization function, the bit Nove will
deliver a linear signal. It is equipped with 10 input signals, 6 Hi-Level/ Pre In, 1 Aux stereo, 2 digital Tos Link S-PDIF and
provides 9 PRE OUT analog outputs.
Each output channel is provided with: an equalization group graphically adjustable, a 68 steps frequency electronic
crossover and Butterworth or Linkwitz-Riley type filters with slopes from 6 to 24 dB / Oct and a time-delay line.
The bit Nove also features preset configurations which can be selected by the user via the remote control device DRC AB.
WARNING: 1.ToinstallthesoftwareandconguretheproductitisnecessarytouseaPCwithWindowsVista,Windows7or
Windows 8 operating system, minimum 2 GHz processor, 1 GB RAM and a graphic card with a minimum resolution
of 1024 x 600 pixel and 512 MB hard disk memory available or more.
2. Read this manual carefully before connecting the product. Failure to comply with the instructions herein may cause
damage to the bit Nove or the car audio system speakers.
2. PACKAGE CONTENTS
- bit Nove
- Multipolar cable, Inputs:
- Multipolar cable, Power:
- 1.8 m USB cable:
- 4 4.2 x 50 mm self-tapping, cross head mounting screws:
- CD ROM containing:
bit Nove Software
This owner’s manual (.pdf)
Audio Test Tracks
- Quick start guide
- Warranty
OPTIONAL:
- DRC AB + Mounting Kit
MEM
SRC
+ +
3
USER’S MANUAL
3. BIT NOVE AND DRC INSTALLATION
External Size
199 mm / 7.83 in.
Mounting Size
130 mm / 5.11 in.
How to mount
bit Nove /
3
34,5 mm / 1.35 in.
106 mm / 4.17 in.
DRC AB (optional)
Installation
SRC
M
E
M
SRC
M
E
M
175 mm / 6.9 in.
SRC
MEM
36 mm / 1.4 in
63 mm / 2.48 in
12 mm / 0.47 in
Fixing
OK
4,5 m / 177.17 in
NO
to DRC
4
Bi-adhesive tape
DRC/ACLink cable
USER’S MANUAL
4. CONNECTION PANELS - DESCRIPTION
7 6
bit Nove /
4
10
2 3 4 59
12
11
81
LOGO STATUS
1
The logo led light indicates the processor status:
- BLUE Logo On: bit Nove is switched on.
- Flashing BLUE Logo: product mode set to Upgrade Mode ON, or product being updated (see section 4.11).
5
USER’S MANUAL
POWER and CONTROL CABLE
2
bit Nove /
The bit Nove is equipped with a 6-pole multipolar connector to manage the power supply and the different
control connections.
200 mm 10 mm
4
Yellow
Black
Red
Blue
Brown
Pink
A
+ BATT
B
- BATT
C
REM IN
REM OUT
SEL OPTICAL 2
SEL MEM D
D
E
F
A) + BATT (11-15 VDC): terminal to connect the power supply positive pole to the bit Nove.
B) – BATT (Ground): terminal to connect the processor’s power supply negative pole. Connect the negative battery
cable or a cable connected to the car’s chassis.
To fix the ground connection (-) correctly use a screw already available on the vehicle’s chassis; remove any paint
or grease residue if necessary, ensuring that there is a continuity between the negative terminal (-) of the battery
and the fixing point. If possible, connect all audio components grounds to the same point as this solution is
necessary to reduce the majority of parasitic noises which may arise during reproduction.
WARNING: observing the polarity of the connection as indicated on the terminals is essential. An incorrect connection may
cause damage to the bit Nove. After switch on, wait at least 10 seconds before turning the processor on.
C) REM IN: terminal to turn on the bit Nove via the Remote Out output of the audio signal source. The applied voltage
must be between 7 and 14.5 VDC. If you are using a source with BTL amplified outputs, the bit Nove can turn on
automatically (see section 7.3.4.6), so you will not need to connect the REM IN terminal.
D) REM OUT: output terminal for the remote turn on of other devices/amplifiers connected to the bit Nove. The processor
takes 2 seconds to provide the REM OUT to the output, but you can manually set this delay with the
software (see section 7.3.4.6). This output has a current capacity of 150 mA and can drive an automotive relay.
E) OPTICAL 2 SELECT: function to select the OPTICAL IN 2 input. This command is enabled by connecting the terminal at + 12V.
F) SEL MEM D: function to enable the manual selection of the processor’s preset D. This command is enabled by connecting
the terminal to ground.
6
USER’S MANUAL
3
PRE INPUT
bit Nove /
4
The bit Nove features 6 Pre IN signal inputs to connect the preamplified signal cables from the analog Master
source. The PC Software provides the ability to customize the inputs by assigning the desired input (see 7.2.5).
Adjustable sensitivity from 1.2 to 8 V RMS (see 4.8). The cable provided to be connected to the source Pre Out outputs
must be wired with RCA connectors, or replaced with an optional input cable.
200 mm 10 mm
RCA CABLE ADAPTER
(NOT SUPPLIED)
12: white IN1+
6: white/black IN1-
11: gray IN2+
5: gray/black IN2-
10: green IN3+
4: green/black IN3-
9: violet IN4+
3: violet/black IN4-
8: cyan IN5+
2: cyan/black IN5-
7: orange IN6+
1: orange/black IN6-
IN1
IN2
IN3
IN4
IN5
IN6
IN1-
IN1+
IN2-
IN2+
IN3-
IN3+
IN4-
IN4+
IN5-
IN5+
IN6-
IN6+
4
SPEAKER INPUT
The bit Nove features 6 SPEAKER IN signal inputs to connect the amplified signal cables from the analog master
source. The PC Software provides the ability to customize the inputs by assigning the desired input (see 7.2.5).
Adjustable sensitivity from 3 to 20 V RMS (see 4.8).
12: white IN1+
6: white/black IN1-
11: gray IN2+
5: gray/black IN2-
10: green IN3+
4: green/black IN3-
9: violet IN4+
3: violet/black IN4-
8: cyan IN5+
2: cyan/black IN5-
7: orange IN6+
1: orange/black IN6-
7
USER’S MANUAL
OPTICAL IN 1/2: S/PDIF digital inputs
5
bit Nove /
The bit Nove accepts PCM input signals with a maximum sampling frequency of up to 192 kHz 24 bits, therefore it
is not possible to reproduce DOLBY DIGITAL (AC3) coded multichannel signals from audio/video sources (such as
the audio from a movie on DVD) or DTS (see section 4.2). The selection of these inputs is possible by using the DRC
external control or by activating it through the terminals.
OPTICAL 1. Connect a fiber optical cable with TOSLINK connector.
OPTICAL 2. Connect a fiber optical cable with TOSLINK connector.
Remark: during the fiber optical cables wiring, the minimum curve radius should be 40 mm.
A bending above this value will cause the cable to break and the consequent interruption of the digital signal.
AUX: low-level auxiliary STEREO input
6
For RCA cables coming from additional analog signal sources. Adjustable sensitivity from 0.2 to 4.2 V RMS (point 8).
PRE OUT: low-level analog signal (4 Volts RMS)
7
Ch1 - Ch2 - Ch3 - Ch4 - Ch5 - Ch6 - Ch7 - Ch8 - Ch9. For RCA cables directed to the system amplifiers (see 5.4).
WARNING: by default, the bit Nove outputs are customized as described in (see 5.4). Therefore, before connecting
theamplierstothebitNove,checktheoutputscongurationorperformanewcongurationdependingon
your audio system.
4
8
INPUT LEVEL:
A
B
A. CLIP: input clipping indicator (see 7.2.6). The led light on indicates the presence of clipping on the selected input.
B. IN level: input signal level controls. Turning the sliders anti-clockwise the input sensitivity decreases, turning them clockwise
it increases. This adjustment is important for obtaining a good noise/signal ratio and optimizing your audio system.
9
DRC: connection socket for the DRC (DRC MP optional) to set up the most important functions of the processor.
10
USB: USB (B type) connection socket to connect the processor to a PC and manage the functions through the bit Nove
software.
11
UPGRADE MODE: the switch to ON position enables the update of the product in RESCUE MODE (see 8.3.1).
12
ASC-C: socket not enabled, to be used for future applications.
8
USER’S MANUAL
5. CONNECTIONS
5.1 POWER SUPPLY AND REMOTE TURN ON
POWER
bit Nove /
5
GROUND
Yellow
Black
Red
Blue
Brown
Pink
Fuse Holder
suggested fuse
3A Delayed
(Not supplied)
REM OUT to Amplifier REMOTE IN
+12V
Battery
REM IN from HEAD UNIT
OPTICAL 2 SEL
MEM D SEL
Ground
Ground
+ 12 V
Ground
Turn bit Nove on and off
bit Nove is on when the logo is lit blue. It can be turned on/off using the following methods:
1. By pressing on the main DRC SRC key. By holding down the DRC SRC key (OFF).
In this case, no other Remote In connections are needed, but they can co-exist.
2. By connecting the REMOTE IN terminal with a Remote Out signal coming from an after market audio source.
3. Through the Hi Level MASTER (IN 1 - IN 2) input. The AUTO TURN ON (ART) function is activated by connecting
the output of an amplified source to the INPUT IN 1 - IN 2 input channel. This function can be enabled/disabled
using the bit Nove PC software (see sec. 7.3.4.6).
9
USER’S MANUAL
5.2 INPUT SIGNALS
1. HI-LEVEL INPUTS FRONT + REAR
PCSoftwareconguration (see sec. 7.2.5)
Hi-Level Speaker Output
Front Left +
Front Left Front Right +
Front Right Rear Left +
Rear Left Rear Right +
Rear Right -
IN 1 +
IN 1 IN 2 +
IN 2 IN 3 +
IN 3 IN 4 +
IN 4 -
bit Nove /
Input sensitivity
3 ÷ 20 VRMS
5
HEAD UNIT
2. HI-LEVEL INPUTS TWO WAY FRONT + REAR
PCSoftwareconguration (see sec. 7.2.5)
HEAD UNIT
Hi-Level Speaker Output
Front Left TW +
Front Left TW Front Right TW +
Front Right TW Front Left WF +
Front Left WF Front Right WF +
Front Right WF -
Rear Left +
Rear Left Rear Right +
Rear Right -
IN 1 +
IN 1 IN 2 +
IN 2 IN 3 +
IN 3 IN 4 +
IN 4 -
IN 5 +
IN 5 IN 6 +
IN 6 -
Input sensitivity
3 ÷ 20 VRMS
10
USER’S MANUAL
3. HI-LEVEL INPUTS THREE WAY FRONT + REAR
bit Nove /
5
PCSoftwareconguration (see sec. 7.2.5)
Front Left TW +
Front Left TW Front Right TW +
Front Right TW Front Left Mid +
Front Left Mid Front Right Mid +
Front Right Mid Front Left WF +
Front Left WF Front Right WF +
Front Right WF Rear Left +
Rear Left Rear Right +
Rear Right -
HEAD UNIT
Hi-Level Speaker Output
4. HI-LEVEL INPUTS TWO WAY FRONT + REAR + CENTER + SUB
SPM 4
IN 3 +
IN 3 IN 4 +
IN 4 IN 5 +
IN 5 IN 6 +
IN 6 -
IN 1 +
IN 1 IN 2 +
IN 2 -
Input sensitivity
3 ÷ 20 VRMS
PCSoftwareconguration (see sec. 7.2.5)
HEAD UNIT
Front Left TW +
Front Left TW Front Right TW +
Front Right TW Front Left WF +
Front Left WF Front Right WF +
Front Right WF -
Rear Left +
Rear Left Rear Right +
Rear Right Center +
Center Sub +
Sub -
Hi-Level Speaker Output
SPM 4
IN 3 +
IN 3 IN 4 +
IN 4 IN 5 +
IN 5 IN 6 +
IN 6 -
IN 1 +
IN 1 IN 2 +
IN 2 -
Input sensitivity
3 ÷ 20 VRMS
11
USER’S MANUAL
5. HI-LEVEL INPUTS FRONT + REAR + CENTER + SUB
PCSoftwareconguration (see sec. 7.2.5)
HEAD UNIT
Front Left TW + IN 1 +
Front Left TW - IN 1 Front Right TW + IN 2 +
Front Right TW - IN 2 Front Left WF +
Front Left WF Front Right WF +
Front Right WF -
Rear Left +
Rear Left Rear Right +
Rear Right -
Hi-Level Speaker Output
IN 3 +
IN 3 IN 4 +
IN 4 -
IN 5 +
IN 5 IN 6 +
IN 6 -
bit Nove /
Input sensitivity
3 ÷ 20 VRMS
5
6. PRE INPUTS FRONT + REAR
PCSoftwareconguration (see sec. 7.2.5)
HEAD UNIT
*
Input sensitivity
1.2 ÷ 8 VRMS
Front Left IN 1
Front Right
Rear Left
Rear Right
PRE OUT
IN 2
IN 3
IN 4
*When using the Master-Pre inputs disable, via PC software, the ART function
(Auto Remote Turn-On),
see section 7.3.4.6.
12
USER’S MANUAL
7. PRE INPUTS TWO WAY FRONT + CENTER + SUB
bit Nove /
5
PCSoftwareconguration (see sec. 7.2.5)
HEAD UNIT
8. PRE INPUTS FRONT + REAR + CENTER + SUB
*
Front Left TW + IN 1
Front Left TW - IN 2
Front Left WF + IN 3
Front Left WF - IN 4
Center IN 5
Subwoofer IN 6
PRE OUT
Input sensitivity
1.2 ÷ 8 VRMS
*When using the Master-Pre inputs disable, via PC software, the ART function
(Auto Remote Turn-On),
see section 7.3.4.6.
PCSoftwareconguration (see sec. 7.2.5)
HEAD UNIT
*
Front Left IN 1
Front Right IN 2
Rear Left IN 3
Rear Right IN 4
Center IN 5
Subwoofer IN 6
PRE OUT
Input sensitivity
1.2 ÷ 8 VRMS
*When using the Master-Pre inputs disable, via PC software, the ART function
(Auto Remote Turn-On),
see section 7.3.4.6.
13
USER’S MANUAL
9. AUX, ANALOG STEREO SIGNAL
Input sensitivity
0.2 ÷ 4 VRMS
Auxiliary
Stereo
Source
bit Nove /
5
5.3 DIGITAL OPTICAL INPUT SIGNALS
DRC AB (optional)
bit Play HD
OPTICAL
OUT
Optical cable
(not supplied)
TOSLINK
CONNECTOR
Optical cable
(not supplied)
bit DMI
OPTICAL
OUT
REM OUT
to
OPTICAL
2 SEL
WARNING: the digital input accepts up to 192 kHz / 24 bit stereo PCM signals. So DOLBY DIGITAL (AC3)
multi-channel signals coming from audio/video sources (such as the audio of a film in DVD) or DTS can
not be reproduced. The output of these devices will therefore have to be set in STEREO mode for the
signal to be reproduced.
How to select OPTICAL input:
1. Using the DRC, selecting the OPTICAL 1/2 input.
2. Using the OPTICAL 2 SEL terminal to select the OPTICAL 2 INPUT.
This command is activated by connecting the terminal to + 12V.
14
USER’S MANUAL
5.4 OUTPUT SIGNALS
CH 1 CH 5CH 4 CH 8 CH 9
AP 4D AP 4D AP 1D
bit Nove /
5
CH1
POWER
CH2 CH3 CH4
CH5 CH6 CH7
OUTPUT AUX IN
DRC
PRE INPUT
CH8 CH9 LR
OPTICAL IN
SPEAKER INPUT
12ASC-C
USB
OFFON
MODE
UPGRADE
SRC
MEM
DRC AB (optional)
OUTPUT TYPE CUT FILTER FILTER TYPE CUT FREQUENCY TIME ALIGNMENT
CH 1 Front Left TW HI PASS LINKWITZ 3000HZ@12dB 0 cm
CH 2 Front Right TW HI PASS LINKWITZ 3000HZ@12dB 0 cm
CH 3 Front Left Mid BAND PASS LINKWITZ 500Hz@12dB / 3000HZ@12dB 0 cm
CH 4 Front Right Mid BAND PASS LINKWITZ 500Hz@12dB / 3000HZ@12dB 0 cm
CH 5 Front Left WF BAND PASS LINKWITZ 80Hz@12dB / 500HZ@12dB 0 cm
CH 6 Front Right WF BAND PASS LINKWITZ 80Hz@12dB / 500HZ@12dB 0 cm
CH 7 Rear Left HI PASS LINKWITZ 80Hz@12dB 0 cm
CH 8 Rear Right HI PASS LINKWITZ 80 Hz@12dB 0 cm
CH 9 SUBWOOFER LO PASS LINKWITZ 8 0Hz @12d B 0 cm
MASTER INPUT
CONFIGURATION
IN 1 Front Left
IN 1 Front Right
IN 3 Rear Left
AUXILIARY
INPUTS
OPTICAL 1 Input ENABLED
OPTICAL 2 Input ENABLED
AUX Input ENABLED
IN 4 Rear Right
IN 5 Not Connected
IN 6 Not Connected
15
USER’S MANUAL
5.5 PERSONAL COMPUTER AND DIGITAL REMOTE CONTROL (DRC)
1. Connecting the bit Nove to the PC and DRC
CH1
CH2 CH3 CH4
CH5 CH6 CH7
OUTPUT AUX IN
CH8 CH9 LR
USB
OFFON
MODE
UPGRADE
USB cable
(provided)
SRC
MEM
bit Nove /
5
POWER
DRC
PRE INPUT
DRC IN
SPEAKER INPUT
OPTICAL IN
12ASC-C
DRC AB (optional)
SRC
M
E
M
SRC
M
E
M
DRC/ACLink cable
OK
NO
16
USER’S MANUAL
6. GUIDE FOR INSTALLING/UNINSTALLING Prima SOFTWARE
AND DRIVERS
6.1 GUIDED PROCEDURE FOR PC SOFTWARE INSTALLATION
1. Insert the "bit Nove Setup CD 1.0" in the drive on the PC you wish to use.
2. Windows Vista: access Computer from the Windows START menu;
Windows 7: access Computer from the Windows START menu;
Windows 8 / 10: access the Desktop from Windows 8 / 10 MAIN menu;
bit Nove /
6
Windows Vista Windows 7 Windows 8 / 10
3. Windows Vista: right click on the icon for the "bit Nove Setup CD 1.0" and click on Explore;
Windows 7: right click on the icon for the "bit Nove Setup CD 1.0" and click on Open;
Windows 8 / 10: access Computer from the Windows 8 / 10 menu;
Windows Vista Windows 7 Windows 8 / 10
4. Windows Vista: double click on the setup icon;
Windows 7: double click on the setup icon;
Windows 8 / 10: select the CD drive and double click on the setup icon;
Windows Vista Windows 7 Windows 8 / 10
Remark: to remove any restrictions on Windows Vista 7/8/10 operating systems, right-click on the setup icon and
select the option “Run as Administrator”. Then select Yes to continue with the installation from the next window
“User Account Control”.
17
USER’S MANUAL
5. Windows Vista: select I AGREE to continue with the installation or CANCEL to interrupt it;
Windows 7: select I AGREE to continue with the installation or CANCEL to interrupt it;
Windows 8 / 10: select I AGREE to continue with the installation or CANCEL to interrupt it;
6. Windows Vista: select INSTALL on the tab and then NEXT;
Windows 7: select INSTALL on the tab and then NEXT;
Windows 8 / 10: select INSTALL on the tab and then NEXT;
bit Nove /
6
8. Windows Vista: follow and complete the installation
procedure and click CLOSE at the end of the installation;
Windows 7: follow and complete the installation
procedure and click CLOSE at the end of the installation;
Windows 8 / 10: follow and complete the installation
procedure and click CLOSE at the end of the installation;
18
USER’S MANUAL
6.2 GUIDED PROCEDURE FOR DRIVER INSTALLATION
1. Turn the bit Nove on.
2. Connect the USB cable on the bit Nove connector to a free USB port on the PC.
bit Nove /
6
WARNING: when connecting a laptop via USB to the bit Nove while it is turned on, the laptop has to work with its
own battery and stay disconnected from the mains adapter (external power supply). Once the connection
between the laptop and bit Nove has been established, you can immediately connect the computer, if
necessary, to the mains adapter.
3. Windows Vista: the PC will recognize the bit Nove interface and installation will start automatically;
Windows 7: the PC will recognize the bit Nove interface and installation will start automatically;
Windows 8 / 10: the PC will recognize the bit Nove interface and installation will start automatically;
4. The peripheral device has been installed correctly and is ready for use.
*Remark: bit Nove uses the HID drivers already built into Windows. For this reason, they are not included on the
CD
6.3 UNINSTALLING bit Nove SOFTWARE
Procedure 1
To uninstall the bit Nove PC software you can use the link in the menu:
Start / All programs / bit Nove / uninstall
Procedure 2
To uninstall the bit Nove PC software, you can also use the standard procedure:
Start / Control Panel / Uninstall or change a program / bit Nove / remove.
and will always install automatically.
19
USER’S MANUAL
bit Nove /
7
7. HOW TO SET UP THE BIT NOVE USING A PC
7.1 OFFLINE MODE
OFFLINE mode can be used to analyze the software without connecting the bit Nove to the PC to become familiar
with the numerous functions of the processor. (For specific functions, see TARGET mode section 7.2). To activate the OFFLINE
mode, the device must be disconnected from the PC. The software is preset to start with a 3 way active FRONT +
REAR full multi-amplified system. To set a new "virtual" system and thus change the inputs and select the outputs,
select the function Configuration Wizard in the SETTINGS window of the software main menu.
Remark: Change the size of the window for the PC software.
• To make the window full-screen, click on the Enlarge button or
double click on the title bar of the PC Software window.
• To restore the previous size from full-screen, click on the Reset
button or double click on the title bar on the window.
• To resize the PC Software window (make it smaller or larger),
position the mouse pointer on one edge or corner of the window.
When the mouse pointer becomes an arrow with a double point, drag
the edge or corner to make the window larger or smaller.
20
USER’S MANUAL
7.2 TARGET MODE
In order to configure the inputs, amplified and pre-amplified power outputs, EQ and time delays for bit Nove, it must
be interfaced with the PC. When you get to this point you must already be aware of what type of system you intend to
set up. In order to change these choices at a later date, you will need to perform the guided procedure again.
The guided procedure will request:
- The type of specialization for the main input channels used. The guided procedure changes according
to your choice.
- The type of signals that will be assigned to the main inputs (e.g.: Front Left or Center or Subwoofer, etc.).
- The speakers in the system (e.g.: 3 way Front or Sub Stereo or 2 way Rear, etc.).
- If there are passive crossovers that manage groups of speakers (e.g.: 3 way systems with active midrange).
- If you intend to use an external monophonic amplifier to drive a Subwoofer or an external amplified subwoofer.
- If you intend to use the bit Nove amplified outputs in BRIDGE configuration, thus increasing the power
on the output.
bit Nove /
7
WARNING: during this operation, we recommend disconnecting the PRE OUT connection.
1. Connect the speaker outputs or the source Pre Out outputs to the bit Nove INPUTS terminal (see sec. 5.2). Before
turning the system on, make sure the PRE outputs are disconnected from the bit Nove to avoid damaging the
speakers during calibration.
The input calibration operation must be performed with the vehicle engine running. In this case, the voltage is
about 14.0 V. The source will provide an undistorted output signal at higher volume.
2. Turn the bit Nove on and connect the USB cable to the PC. Start the bit Nove software by clicking on the icon on
the PC Desktop that was created upon installation.
3. If synchronization is successful, a communication window will appear showing the data exchange between the
processor and software. Wait a few seconds.
4. Click on the Settings menu and select Configuration Wizard.
Press Start to continue with the configuration.
Press Cancel to exit the procedure.
21
USER’S MANUAL
5. Input Configuration
Any of the input channels on bit Nove can be given the name corresponding to the signal coming from the source.
In this phase it is possible to activate/deactivate the turn on from Speaker (ART) and choose how to reconstruct
the SUBWOOFER output channel.
IMPORTANT REMARK: when the PRE IN inputs are used, the “ART Enable” must be disabled.
bit Nove /
7
*
REMARK: disable the “ART Enable”, when PRE IN inputs are used.
**
REMARK: use the drop down menu to select how to reconstruct the SUBWOOFER output channel.
The bit Nove will use these names to reconstruct a full band signal coming from an OEM source with a dedicated
multichannel amplifier and to assign the corresponding signal to the respective output.
Press BACK to return to the previous step.
Press NEXT to continue with the configuration.
Press CANCEL to exit the procedure.
22
USER’S MANUAL
6. Input Level Setup
- Play track 1 from the CD provided with bit Nove.
- Set all tone controls to zero (flat).
- Set balance and fader to center.
- Adjust the head unit volume to the maximum undistorted output level.
- If the head unit provides an adjustable equalizer, make sure that the controls are set to zero (flat).
Press BACK to return to the previous step.
Press GO to continue with the configuration.
Press CANCEL to exit the procedure.
Press SKIP to skip the level calibration procedure.
bit Nove /
7
The input level calibration procedure is a delicate operation and must be performed very carefully. If not performed
correctly, it can nullify the final acoustic results.
WARNING: the head unit level must be adjusted to the maximum undistorted level. If the initial head unit
distortion level can not be determined, adjust the volume to approximately 80% of its maximum. If the
head unit output level is set too low, the device may produce ground noise (hissing sound) when playing
music tracks. This is due to the low signal / noise ratio provided by the head unit to the bit Nove input. If
you experience this problem, after calibrating the amplifiers sensitivity levels, increase the head unit
volume and repeat the bit Nove calibration procedure as detailed in point 9 of this paragraph.
IN LEVEL calibration for MASTER inputs
This operation is delicate and must be performed with utmost accuracy. An incorrect execution can invalidate the
final acoustic results.
• When track 1 of the CD is playing, rotate the first potentiometer to the highest sensitivity (position +).
• As soon as the orange LED lights up or blinks, stop the rotation, turn slightly backwards until the LED turns off.
• Perform the same operation for the other inputs used in the bit Nove.
• Brief activations of the LED lights can be considered normal and indicate the correct calibration of the sensitivity.
• Repeat the operation for the other 3 Front / Rear potentiometers.
• Note down the calibration level indicated by the source volume controller.
23
USER’S MANUAL
7. De-equalization
De-equalization of the OEM source, operation not required and
not necessary if using low level inputs (Pre out).
During the high level input configuration procedure, this function
can be used to maximize use of the OEM head units, even if
they were equalized to adapt best to the acoustics of the car
they are installed in. The de-equalization procedure performs
an analysis of the electrical frequency response coming from
the various channels on the OEM head unit and automatically
applies an equalization opposite to the original one, generating
a linear signal that is much more suitable to driving high quality
audio systems. Regardless of the input channels used,
the de-equalization will be performed by functional groups.
E.g.: even if using Front Left Full and Front Right Full as inputs, the software will also perform the de-equalization
on the Rear, Center and Subwoofer since the processor must use the signals identified as Front to also control
any possible Rear, Center and Subwoofer outputs.
If you decide to perform this procedure, follow the instructions below:
- Insert the supplied Setup CD if the source used is an audio CD player;
- Play track 2 (press Play);
- Set all tone controls to zero (0);
- Set the balance and fader to the center (0);
- Don’t change the adjusted volume previously set through the automatic input level calibration;
bit Nove /
7
Press BACK to return to the previous step.
Press GO to continue with the configuration.
Press SKIP to abandon the procedure.
Press CANCEL to exit the program.
The software uses a progress bar and specific messages to
show how the procedure is being executed.
At the end of the procedure, the window will show the
equalization curves for the head unit.
Press BACK to return to the previous step.
Press NEXT to continue with the configuration.
Press CANCEL to exit the program.
24
USER’S MANUAL
8. Speaker Connection Setup
The speakers in the system can be activated
by simply clicking on them.
The software assumes that if the Left tweeter, midrange or
woofer are selected, the Right ones are also activated.
Once the software is started, this choice will affect
the crossover type and frequencies with Default settings.
If passive crossover filters are not used, each speaker
corresponds to an output channel.
Selection of passive crossovers for groups of speakers
The presence of passive crossovers managing functional speaker
groups can be indicated.
E.g.: if the audio system features passive crossovers, the software will
ask you to set them by clicking on , otherwise press NEXT.
A 2 or 3 way passive crossover occupies a single output channel.
If the sum of the crossovers and/or speakers exceeds
the occupation of 8 PRE output channels, the software will not
allow you to proceed with the next operation. Check the crossovers
configuration again or, using BACK, the speakers setup.
bit Nove /
7
WARNING: one coaxial speaker is considered a as
Tweeter + Woofer + 2 way passive crossover.
9. Output Configurations
bit Nove features 9 output channels. In this specific step
of the procedure you can assign any signal to one
of the output channels.
E.g.: The 3 way front can be controlled as:
- multi amplified (6 output channels are needed);
- passive midrange + woofer amplified separately
(4 output channels are needed);
- 3 way passive (2 output channels are needed).
During the selection, the software will automatically notify that
the 9 output channel limit has been respected, the warning
message will disappear and the NEXT button will appear.
For convenience, if output 1 is assigned to the left Tweeter, the
software will automatically assign output 2 to the
right Tweeter. During the procedure, if the left midrange speakers
are also assigned to output 1, the software will display a warning
message. Simply change the assignment of one of the two
numbers in red and the software will automatically position it to
the first available channel.
Press BACK to return to the previous step.
Press NEXT to continue with the configuration.
Press CANCEL to exit the procedure.
25
USER’S MANUAL
10. Finish
Stop playing the Test track and remove the
setup CD from the source player.
Press BACK to return to the previous step.
Press CANCEL to exit the procedure.
Press FINISH to end the configuration.
11. Software startup
The software transfers the settings selected during the guided
procedure to the central processor memory.
At the end of this operation, an update confirmation will appear.
Press OK.
The product will now have to be finalized to avoid losing the data
saved during calibration (see sec. 7.3.5.2).using the function FINALIZE
the device.
bit Nove /
7
26
USER’S MANUAL
7.3 ADJUSTING ACOUSTIC REPRODUCTION
The following paragraphs describe the functions to adjust the system and its acoustic fine tuning.
bit Nove /
7
WARNING: when exploring the functions, do not change the parameters on bit Nove. Take your time to get familiar
with the possibilities the software offers.
If you choose to leave the speakers/amplifiers connected to the bit Nove, remember to make adjustments with a
general volume that won’t damage the other speakers in the system. (see sec. 7.3.13.6)
2
3 4 5 6
1
13
14
7
9
10
12
8
11
15
7.3.1 DEVICE INFO
This window shows whether the bit Nove is properly interfaced with the PC and the DRC. It also shows the Firmware
version for the device and the Serial Number.
1
27
USER’S MANUAL
bit Nove /
7
7
7.3.2 FILE MAIN MENU
By clicking on the File tab, a drop-down menu appears with the
entries shown in the image:
2
1. Load: it loads the entire bit Nove configuration from
a previously saved file (e.g.: “bit Nove setup1.bt9”).
This function is present in both TARGET mode
and in OFF LlNE mode.
In TARGET mode it can reload all of the previously
saved settings. This function is useful if you wish
to install another bit Nove with the same settings.
The input level calibration and, possibly, the De-Eq
levels must be repeated.
In OFF LINE mode, you can check the previously
saved settings.
2. Save Setup: it saves the entire bit Nove configuration
for bit Nove in one file (e.g.: “bit Nove setup1.bt9”), that
can be reloaded on the bit Nove later using the Load
Setup function. This function is available in both
TARGET mode and in OFF LINE mode.
1
2
3
4
5
3. More setup files (online): this function requires an
internet connection. By clicking on this entry, a link to
download new installation setups appears.
4. Preferences: it allows you to display the context
messages in the chosen “Language” (Italian or English).
The PC Software automatically defaults to English.
To change the language, select language from the
menu and restart the PC Software.
Remark: other languages may also be available. Verify through "Check for Updates"
5. Exit: exits the PC software.
7.3.3 MEMORIES MAIN MENU
By clicking on this item, a drop-down menu appears
with the entries shown in the image:
3
1. Copy memory.
2. Reset current memories: resets the crossover and
standard equalizer values, the ones proposed
at the end of the configuration procedure.
3. Load memory from file: it loads a previously saved
memory, by placing it in one of the two available memories.
1
2
3
28
USER’S MANUAL
bit Nove /
7
7.3.4 SETTINGS MAIN MENU
By clicking on this item, a drop-down menu appears with the
entries shown in the image:
4
1. I/O Configuration Wizard: sets up the system,
and puts the bit Nove in the conditions needed to be able to
perform this operation (see sec. 7.2).
WARNING: whenever performing the I/O Configuration Wizard, the values
set in the Options menu are set to the default values.
Bass boost Sub Woofer
2. Controlled bass-boost: if enabled, through
this function you can operate on the
equalization of the sub channel and woofers.
By clicking on Settings you can choose
the parametric equalizer pole where you can
operate and vary the “Q” factor by acting
on the mouse wheel when available or using
the keys “+” and “-“ on the PC keyboard.
Remark: to select the frequency parametric pole in FINE mode,
use the PC keyboard keys “CTRL + →” o “CTRL + ←”.
When heavy equalization is set, the software will activate
through soft clipping eliminating the subsequent distortions.
This function can also be enabled and disabled via DRC MP.
1
2
3
4
5
6
Bass boost Woofer
3. De-Equalizer: if activated (Enabled), this function enables the
de-equalization curve calculated during the Configuration
Wizard. If the function is deactivated (Disabled) no
source de-equalization curve is applied.
The Reset command deletes the de-equalization curve
calculated during the Configuration Wizard.
4. Working Mode: the software can work in two modes, acting on the
crossover filter section.
Standard: simplified mode with some restrictions easing the use
of the software (see sec. 7.3.10).
Expert: there are no restrictions in the use of software functions
(see sec. 7.3.10).
WARNING: switching from one mode to another resets the configuration
of the filters to their original Default setting.
5. Input configuration: shows the specialization assigned to the inputs
on bit Nove during the Configuration wizard.
29
USER’S MANUAL
6. ON / OFF settings: function to set up the bit Nove turn on parameters.
• ART (auto remote turn on / off) enable: selecting Enabled the bit Nove is turned
on through the amplified output (BTL) of a source connected to the FL-FR inputs.
This function can be deactivated by selecting Disabled.
• Turn On delay (sec): it is the delay between turning on the device and activating
the output audio. Each amplifier, upon turn on, has its own delay before being
operational. Setting Turn On delay to a value equal or higher than the longest of
these delays, you will have a synchronized activation of the entire audio system.
• Turn Off delay (sec): it is the delay between the REMOTE OUT signal deactivation
and the bit Nove shut down. It is not usually essential to manage this parameter
but it can be useful to decrease it in case there are amplifiers producing a
“bump” noise upon switch off.
bit Nove /
7
• OEM integration: function to set up the automated commutation of the audio
system Master input.
Auto select Master input (muted Head Unit): this function is activated by
selecting Enabled and allows the automated commutation on the Master input
when the signal is available.
Return delay (sec): function to set up the automated deactivation delay for the
Master input.
Master Input level (db): set up of the signal level for the Master input when it is
enabled by the “Auto select master input” function. It is possible to select among
levels of intervention from 0 dB to -18 dB.
Preferential memories: this control panel enables the assignment of a memory
for each input available on the bit Nove.
30
USER’S MANUAL
bit Nove /
7
7.3.5 DEVICE MAIN MENU
By clicking on this item, a drop-down menu appears with the entries
shown in the image:
5
1. Synchronize: this function synchronizes the PC with the bit Nove
and vice versa due to communication losses caused by the
device shutting down or for other reasons.
Read from Device: the PC loads the settings present
in the bit Nove memory to the PC Software.
Write to device: the PC loads the current settings
on the bit Nove memory.
2. Finalize the device: it allows you to load all of the parameters set during
system calibration in the internal memory, letting the bit Nove
operate without being connected to the PC.
1
2
3
4
When Finalize to bit Nove is performed, the software provides a warning
message that the data previously saved in the bit Nove will be overwritten.
- Click on YES to load the data.
- Click on NO to interrupt the procedure.
3. Update firmware: this allows
firmware updates on bit Nove (see sec. 8.3.2).
4. Reset factory default: performs full reset of bit Nove
returning the product to its original conditions, deleting all
previously saved data from the processor memory.
31
USER’S MANUAL
bit Nove /
7
7.3.6 HELP MAIN MENU
By clicking on this item, a drop-down menu appears with the entries shown
in the image:
1) Help (online): this function requires an internet connection.
By activating this function and moving the mouse pointer to the various
sections of the graphic interface for the PC software, the concerned
area will be highlighted in red. By clicking on the red area, a link will
activate, opening up the default browser, displaying the paragraph of the
manual related to that specific area. The manual will be displayed in the
language selected in FILE-> PREFERENCES (see sec. 7.3.2)
2) Tutorials (online): this function requires an internet connection. Clicking
on this item activates a youtube link to consult audio/video information
regarding the product.
3) User’s Manual (online): the internet browser installed in your PC will open
up and a research for the URL www.audisonbitdrive.eu will automatically
start, offering the possibility to check the product manual online.
4) Diagnostic: this function must be used exclusively if requested by the
Audison authorized service centre. It generates a file named
“xxxxxxxxxxx.dng”
product. This function is useful to fix installation issues remotely.
5) Check for Updates: connects to the website www.audisonbitrive.eu and
checks for updates to the bit Nove Software/Firmware in order to be
able to update the device in use (see sec. 8.3). To perform this operation, the
PC must have an active internet connection.
6) Check for Updates on startup: when enabled the availability of new
firmware/PC Software updates is checked automatically each time you
start the program.
7) Register product: this function requires an internet connection and
opens the default browser to the page for registering the product and
creating a personal account in the “bit Drive” portal. This operation only
needs to be performed once; then you can access your account through
the Login Account.
8) About: it shows information regarding the bit Nove software in use.
that is saved on the PC desktop, to diagnose the
6
1
2
3
4
5
6
7
8
7.3.7 SELECTED INPUT
The "Selected Input" window shows the active source during connection
with the PC. This can be used to select the desired source. Once disconnected
from the PC, you can select the input source through the DRC or through the
external functions "MASTER ENABLE" and "OPTICAL ENABLE".
7.3.8 CHANNEL MAP
This window shows the name attributed to the output channels. The window
is active. You can click on it to manage the individual channel that, once
selected, will be highlighted. If you hold down the CTRL key and click on
another channel, it will also be selected and highlighted. At the same time,
the filter curve will appear on the graph area.
Multiple selection is only allowed for functional groups,
except for the Subwoofer, which can be selected together with any group.
E.g.: front Left Full together with Subwoofer, but not with Rear Left Full.
32
7
8
USER’S MANUAL
bit Nove /
7
If you wish to check the electrical response of the Rear system together with
the Subwoofer, you must clear the Front system selection. However, the
software will only let you operate on a single channel and will show the
message “EDIT” in red to the side of the channel that you can operate on.
More specifically, the graph will show the electrical responses from the only
crossover related to the channel being edited in red. The overall electrical
response from all channels selected will be shown in yellow, taking into account
the crossover filters and equalizations. The final result will be shown in green.
To act on another channel without losing the selection, simply click to the right of the desired channel in the EDIT
column. The CHANNEL MAP window also lets you mute the individual channels by clicking on MUTE to the left of
the desired channel.
If MUTE is active on the channel, "m" is shown in red.
If the SOLO function is active, "s" is shown in green.
If there are time delays on the channel, "fds" is shown in yellow. A channel can also be selected as shown in the
outline in the image (see sec. 7.3.9).
7.3.9 SELECT CHANNEL
9
This window is enabled. You can click directly on the speaker or speaker
system to be able to display or set the parameters for the individual
channel. Once selected, the speaker(s) will be highlighted.
If you hold down the CTRL key and click on another channel, it will also
be selected and highlighted as occurs with the "Channel Map"
(see sec. 7.3.8)
.
Listening point visual indicator.
This window includes the position indicator (in red).
There are four preset points: driver, passenger, front center and rear
center for passengers.
The indication only acts as a reference, allowing you to display the
listening points for which the digital display calculation was optimized
(see sec. 7.3.11). If you set the delays in relation to the "driver" position and
then you wish to also optimize the system for the "passenger" position,
you must reset the distances in the specific menu since the system
does not update them automatically.
If used together with the presets (see sec. 7.3.14) it is useful to try different
setups according to the different listening points.
7.3.10 FILTER SETTINGS
10
bit Nove manages nine crossover filters, one for each output channel.
Each filter allows you to set the parameters of a single output channel.
1. Xover L/R Link: function to transfer the adjustments made on the Right
channel to the Left one and vice versa. To activate it, you must click
on the blue light, which will come on. Xover L/R Link acts on all of the
adjustments of the Filter Settings except for Set Distance (Delay).
2. Invert Phase: it inverts the phase of the channel under examination
by 180°. This can be done by selecting the green light which will turn
on. This can be useful to solve phase alignment problems among
the different filtered channels.
3. Filter Type: function to select the type of filter to assign
to the channels:
- Full Range
- Low Pass
- High Pass
- Band Pass
33
USER’S MANUAL
bit Nove /
7
In STANDARD mode:
Depending on the speaker or speaker system selected during
configuration, a suitable type of filter will be available.
E.g.: for the Front Woofer, only Low Pass or Band Pass will
be available. For Front Mid-Hi, only High Pass and Band
Pass will be available, etc.
In EXPERT mode:
Any speaker system selected has any type of filter available.
WARNING: in EXPERT mode, pay attention to the filter
selection. Speakers have mechanical limits that must
not be exceeded, otherwise it could lead to permanent
damage.
When a filter is selected, some optimized cut-off frequencies
are set by default to avoid breaking the speakers.
E.g.: if you select Low Pass for a tweeter, the default frequency
is suitable for a woofer but not for the tweeter, which
could be damaged.
4. Filter Model: function to select the type of filter to be applied.
- Linkwitz (default)
- Butterworth
STANDARD MODE
FILTER
TYPE ->
Full Range Low Pass High Pass Band Pass
Tweeter x x
Midrange x
Woofer x x
Mid-Hi x x
Subwoofer x x
Full x x x x
EXPERT MODE
FILTER
TYPE ->
Full Range Low Pass High Pass Band Pass
Tweeter x x x x
Midrange x x x x
Woofer x x x x
Mid-Hi x x x x
Subwoofer x x x x
Full x x x x
When launching the bit Nove software, Linkwitz is proposed as the filter
model for the speaker or speaker group connected to the related
channel. To apply the opposite (Left/Right), enable the Xover L/R Link.
If you change the model to Butterworth, the change will be applied.
5. Cut-off frequencies
- Hi-P Hz 10 ÷ 20000: High-Pass filter
- Lo-P Hz 10 ÷ 20000: Low-Pass filter
If you select the Band-Pass filter, both the
Hi-P Hz and the Lo-P Hz boxes will be enabled to be able to set the
band frequency.
You can select the cut-off frequency by:
- clicking on the related drop-down menu, selecting the frequency
range that includes the value to be set and then clicking on the
actual value.
- clicking on the related drop-down menu, selecting the pre-chosen
frequency range and then moving from value to value using the
arrow keys (up / down) on the PC keyboard.
- clicking twice on the related drop-down menu and then moving
from value to value by scrolling with the mouse.
34
USER’S MANUAL
bit Nove /
7
6. Filter slope
- Hi-P Slope 12/24 dB/Oct. (Linkwitz) 6/12/18/24dB/Oct (Butterworth)
- Lo-P Slope 12/24 dB/Oct. (Linkwitz) 6/12/18/24 dB/Oct (Butterworth)
When starting the bit Nove software, it offers Linkwitz with 12 dB/Oct.
slope.
E.g.: if you select Band Pass as the filter type, the same slope will be
applied to both the hi-pass and low-pass as the default slope, but
they can also be unbound.
The crossover filter response related to the selected channel is displayed graphically by a yellow curve, as shown
in the examples below.
E.g. Band Pass
Crossover Frequency 80 - 2000 Hz @ 12 dB Oct. Crossover Frequency 80 Hz @ 6 dB Oct. Hi-pass
Crossover Frequency 80 - 2000 Hz @ 24 dB Oct. Crossover Frequency 80 Hz @ 24 dB Oct. Hi-pass
7.3.11 SET DISTANCE AND DELAY
11
2000 Hz @ 24 dB Oct. Low-pass
2000 Hz @ 6 dB Oct. Low-pass
This setting is based on an automatic system that calculates the time
needed for the sound to get from the speaker to the listener's ear.
Preliminary remarks
Sound moves through the air at a speed of 343 m/sec (1.125 ft/sec.) at
a temperature of 20° C (68° F). If you know the distance from the sound
emission point, you can then calculate the time the sound takes to get
to the listener’s ear.
If you set the distances of the different speakers, the bit Nove will
automatically change them into time (ms - milliseconds). It does not
assign a delay (0.0 ms) to the farthest speaker (usually the Subwoofer)
and progressively growing delays as much as the other speakers get
closer to the listening point, in order for all the emission points to reach
the listening point at the same time.
SET DISTANCE
Function to set the distance between the speaker and the listening point. Choose cm (centimeters) or in (inches).
The "Set Distance" boxes can be set using the cursors.
DELAY ms/default
Displays the time in ms (milliseconds) calculated according to the distance.
DELAY ms/fine set
the bit Nove time delay calculation system also lets you perform manual fine tuning.
35
USER’S MANUAL
bit Nove /
7
Preliminary remarks
Fine set and Phase delay
Delay assignment according to distance calculation is theoretical.
Small variations must be applied due to small errors in distance measurement, back-wave reflections inside the car
and, primarily, the speaker phase problem.
Two speakers reproducing two frequency areas that are close to each other (e.g.: Woofer and Midrange) will
simultaneously reproduce the same frequencies in their crossing area, at a attenuated level. Due to the different
nature of the speakers, they will have a phase difference that, for a short frequency interval, acts as a time delay.
By using "fine set", you can partly correct these Phase Delay problems.
By using the "fine set" button, you can change the
automatically set delay time.
The delay is increased (+x.xx) or decreased (-x.xx) by
the delay value shown in the window "Delay/default" and
does not change the value shown, which is the one that
is automatically assigned.
Assigning a positive value (+x.xx) using "fine delay"
means increasing the delay for that speaker and thus
moving it farther away from the listening point.
Likewise, assigning a negative value (-x.xx) means
decreasing the speaker delay and thus moving it closer
(Fig.1)
to the listening point.
In order for you to see how much “Fine Set” has been
manually changed, both delay values are shown. To see
the resulting delay, physically applied to the output, you
have to add the values shown in the “Delay / Default” and
“Delay / Fine Set” boxes. A negative value (decreasing
the delay) can not be assigned to the farthest speaker; it
can only be assigned to the other speakers as they are
all already delayed compared to the farthest one. If you
attempt to give the farthest speaker a negative value, a
warning message will appear (Fig. 1).
When using "fine set" "fds" will appear in green on the
corresponding channel on the "Channel Map" (Fig. 2)
Example of setting the time delay (Fig. 3):
1. Choose the system listening point.
To identify the listening point, choose an
ideal spot in the center of the listener's head
(driver or passenger).
For the front center and rear center, choose a
point between the two listeners.
2. Measure the distance in a straight line from each
speaker or group of speakers compared to the
listening point. For each speaker, choose the center of
the mobile membrane as the emission point.
For groups of speakers, choose a point between them.
It will then be possible to fine tune it using the Fine Set
function.
3. On the Channel Map, select the channel related to the
speaker under examination and enter the respective
distance in the Set Distance box in the Filter Settings menu.
4. Repeat step 3 for each channel.
106 cm
105 cm
90 cm
106 cm 116 cm
164 cm
(Fig.2)
106 cm
105 cm
90 cm
(Fig.3)
36
USER’S MANUAL
5. Once the time delay settings are complete, start the
musical reproduction and use the Fine Set box, moving
the values up or down (except for the subwoofer since it
is the farthest speaker) to fine tune the system for
optimal sound. We recommend listening to various
types of music (percussion, melodic, etc.) for better
evaluation of the coherence (spatial stability) of the
different musical instruments.
6. Once the time alignment procedure is complete, you can
work on the output equalizer (see sec. 7.3.12) to optimize
the system response based on the level alignment of the
various frequencies.
Remark: measurements for the above operations can also
be taken using a spectrum analyzer with a suitable
microphone. The results must be evaluated and
optimized through listening tests.
WARNING: if, once you have set the distances for the “driver”
listening point, you click on the “passenger” listening point,
the bit Nove will not re-calculate the delays for the new
reference point because the buttons available in the SELECT
CHANNEL diagram are merely descriptive. Their only purpose is
to remind you that you have set the delays for that listening point!
bit Nove /
7
37
USER’S MANUAL
bit Nove /
7
7.3.12 PARAMETRIC EQUALIZER
The bit Nove software provides an equalizer, that can be managed from
a maximum of 10 graphic control points which automatically place a
maximum of 10 parametric equalization points. The quantity of graphic
control points used doesn’t match the parametric poles quantity, which
is determined by the adapting software.
The equalizer works according to the functional groups and so
we have the following factory configuration:
- one equalizer for the Front Tweeter.
- one equalizer for the Front Mid
- one equalizer for the Front Woofer.
- one equalizer for the Rear.
To be able to change the parameters for the equalizer in order to set
an equalization curve, just choose the channel to equalize from the
“Channel Map” menu, positioning the mouse over the point to be set,
and shape the curve using the left mouse button (green curve), or with
the arrow keys “← → ↑ ↓” on the PC keyboard.
Remark: to select the frequency parametric pole in FINE mode,
use the PC keyboard keys “CTRL + →” o “CTRL + ←”.
In order to vary the “Q” factor of the equalization point selected, just
scroll using the mouse wheel featuring this function or using the keys
“+” and “-“ on the PC keyboard.
In order to delete the changes, just put the mouse over the point, select
it with the left button and press CANC on the PC keyboard.
12
1 4 5 3 2
The equalizer has specific functions that aid and ease the calibration.
1
Flat brings all the cursors back to the 0 dB position;
2
L/R Link, when active, applies the equalization curve to both the
right and left channel simultaneously.
3
EQ by Pass , when active, lets you disable the equalizer to check its
effect without losing its settings.
4
Filter lets you display the electrical response subject to
filtering (XOVER), by clicking on the box (red curve).
5
Filter + Eq lets you display the electrical response subject to
equalization, by clicking on the box (yellow curve).
Remark: in order to clearly display the set equalization curve, you can increase or decrease the vertical axis (dB)
and horizontal axis (Hz) by moving the cursors to the side of them. The default is set to +12 dB and 0-20 kHz.
+
1 4 5 3 2
+
-
-
-
38
+
USER’S MANUAL
bit Nove /
7
7.3.13 OUTPUT LEVEL
13
This section shows the settings related to the output levels of the bit Nove channels. The description of the points
shown in the figure is given below.
5
1
4
2
3
6 7
1. Using one of the sliders for the output channels, you can adjust the output level (-40÷0 dB) for each channel. The
sliders are enabled based on the output configuration.
2. This part of the display shows the output level for each individual channel (-40÷0 dB), referring to the position of
the Slider for the output channels.
3. By clicking on the "Mute" button you can mute the corresponding output channels. By clicking on the "Mute"
button again, the mute function will be disabled.
4. By clicking on the "Link" button you can simultaneously adjust all the bit Nove output levels. By clicking on the
"Link" button again, the function will be disabled.
5. By clicking on the "Solo" button you can mute the output channels except for the one enabled. By manually
clicking on the "Solo" button, the function will be disabled.
6. Using the "Volume" slider you can adjust the general output level for the system (-60÷0 dB).
7. Using the "Sub Volume" button you can adjust the output level of the subwoofer (-12÷0 dB), if the system
features a subwoofer.
7.3.14 MEMORY
14
The bit Nove controls the system configuration, operating by default on
memory A but gives the option to store and recall for memories (A, B, C, D).
7.3.15 STATUS BAR
15
It is an information area that can be found at the bottom of the PC software window. It shows in real time the
working status of the bit Nove PC software.
1
1
Indicates the working status of the bit Nove PC software.
2
Indicates the setup file loaded via PC software on the bit Nove.
Bass-Boost:
3
4
De-eq: when the LED is lit, the de-equalization curve of the source is enabled see sec. 7.3.4.3.
5
Mode: indicates whether it is in Expert (EXP) or Standard (STD) mode see sec. 7.3.4.4.
when the LED is lit, the Bass-Boost is enabled
see sec. 7.3.4.2.
32
4 5
39
USER’S MANUAL
bit Nove /
8. TROUBLESHOOTING
8.1 SYNCHRONIZATION WITH A PC
1. bit Nove operating problems
If, when calibrating the system with the bit Nove connected to a laptop there are operating problems, try
disconnecting the laptop power supply cable.
With the laptop working on battery power you avoid a possible voltage difference in the USB ground between
the vehicle (bit Nove) and the ground (PC).
2. Connection lost between bit Nove and the PC
If, while calibrating the system with the PC connected to the bit Nove, the amplifier is turned off and back on again,
the connection is lost and the software cannot finalize the adjustments that were set. To avoid losing the
settings, proceed as follows:
a. Save the setup to a file on the PC using the FILE / SAVE SETUP function.
b. Exit the software.
c. Turn the bit Nove on.
d. Launch the software again.
e. Load the setup file again that was saved using the FILE / LOAD SETUP function.
3. bit Nove does not respond
If calibrating the system with the PC connected to the bit Nove and the latter does not respond to the commands,
proceed as follows:
a. Turn off bit Nove by pressing the knob on the DRC or disconnecting the Remote IN or even disconnecting
the power cable for a second.
b. Save the setup to a file on the PC using the FILE / SAVE SETUP function.
c. Exit the software.
d. Turn the bit Nove on.
e. Launch the software again.
f. Load the setup file again that was saved using the FILE / LOAD SETUP function.
8
4. Settings not saved
To successfully complete the bit Nove configuration and not lose the work done, remember to store the settings
made. Access the "File" menu from the management software via the PC and choose “Finalize the device”.
8.2 BACKGROUND NOISE
Loud hissing/background noise.
If there is excessive hissing/background noise, it may be necessary to repeat the setup for the input sensitivity and/or
correct the output level calibration. For more details see sec. 7.2.
40
USER’S MANUAL
8.3 FIRMWARE UPGRADE
8.3.1 TARGET MODE UPDATE
If there are product UPGRADES available online, proceed as follows:
- Save the previous setup (if you wish to consult it in OFFLINE mode);
- Start the bit Nove PC Software.
1. Access the "Help" menu in the PC management
software and choose "Check for Updates".
2. When you select "Check for Updates", the internet browser in the PC will
open up and will automatically search for the URL: www.audisonbitdrive.eu.
WARNING: the files must be manually downloaded from the website.
The software access method may be different from the following.
Refer to the instructions on the website.
3. Once the related page is open, click on the LINK for the product.
4. Identify the newest file whose name includes the
word Firmware followed by four numbers and click
on the specific symbol to start the download.
When requested, save the file to the PC.
bit Nove /
8
5. Select "Update Firmware". The program will ask you to
select the file that was just saved from the Download Area or
that was previously saved in the PC.
WARNING: the bit Nove Firmware update procedure may be tricky. It is
essential to perform it under the best possible conditions. If the
operation is started and prematurely interrupted (e.g.: PC locked up,
loss of power to bit Nove, accidental disconnection of the USB
cable during update), you might need to contact our Customer
Service for further support as the bit Nove may need to be
reprogrammed.
6. Before starting the bit Nove update, the program warns you to:
- not disconnect bit Nove from the PC;
- not disconnect bit Nove from power;
- temporarily disable the PC automatic stand-by processes;
- temporarily disable the screen saver on the PC;
- close all running applications;
- temporarily disable the anti-virus and anti-spyware systems.
7. Once you have clicked on OK, the Firmware update procedure starts.
This process will last between 30 seconds and 1 minute; the progress bar
and the flashing logo on the bit Nove will show the updating process
status.
WARNING: during the update, the updating process of the progress bar may
stop for a few seconds. Do not interrupt the process in any way.
8. When successfully completed, a notification window will appear. In order to be able to use the bit Nove again, you
must close the program on the PC and turn off the bit Nove.
9. Turn the bit Nove back on and restart the PC software. If the bit Nove firmware update was completed
correctly, the dialogue window will show:
- new bit Nove Firmware version.
10. Repeat the product calibration operations if necessary (see sec. 7.2).
41
USER’S MANUAL
8.3.2 RESCUE MODE UPDATE
In case the bit Nove update is not possible, due to interruptions during routine updates, please follow the
below instructions:
- Disconnect the Power supply connector on bit Nove.
- Set the product upgrade switch to the "ON" position
- Connect the Power supply connector on bit Nove
- Turn the bit Nove on. The logo will start flashing.
Start the bit Nove PC Software.
1. Access the "Help" menu in the PC management
software and choose "Check for Updates".
bit Nove /
8
2. When you select "Check for Updates", the internet browser
open up and will automatically search for the URL: www.audisonbitdrive.eu.
in the PC will
WARNING: the files must be manually downloaded from the website.
The software access method may be different from the following.
Refer to the instructions on the website.
3. Once the related page is open, click on the LINK for the product.
4. Identify the newest file whose name includes the
word Firmware followed by four numbers and click
on the specific symbol to start the download.
When requested, save the file to the PC.
5. Select "Update Firmware". The program will ask you to
select the file that was just saved from the Download Area or
that was previously saved in the PC.
WARNING: the bit Nove Firmware update procedure may be tricky. It is
essential to perform it under the best possible conditions. If the
operation is started and prematurely interrupted (e.g.: PC locked up,
loss of power to bit Nove, accidental disconnection of the USB cable
during update), you might need to contact our Customer Service for
further support as the bit Nove may need to be reprogrammed.
6. Before starting the bit Nove update, the program warns you to:
- not disconnect bit Nove from the PC;
- not disconnect bit Nove from power;
- temporarily disable the PC automatic stand-by processes;
- temporarily disable the screen saver on the PC;
- close all running applications;
- temporarily disable the anti-virus and anti-spyware systems.
7. Once you have clicked on OK, the Firmware update procedure starts.
This process will last between 30 seconds and 1 minute; the progress bar
and the flashing logo on the bit Nove will show the updating process
status.
WARNING: during the update, the updating process of the progress bar may stop
for a few seconds. Do not interrupt the process in any way.
42
USER’S MANUAL
8. When successfully completed, a notification window will appear.
In order to be able to use the bit Nove again, you must close
the program on the PC and turn the bit Nove off.
Disconnect the Power supply connector on the bit Nove.
9. Set the "UPGRADE" switch to the OFF position.
Connect the Power supply connector on bit Nove.
10. Turn the bit Nove back on and restart the PC software.
If the bit Nove firmware update was completed
correctly, the dialogue window will show:
- new bit Nove Firmware version.
11. Repeat the product calibration operations (see sec. 7.2).
bit Nove /
8
43
USER’S MANUAL
bit Nove /
8
9. TECHNICAL SPECIFICATIONS
POWER SUPPLY
Voltage 10.8÷15 VDC
Operating power supply voltage 7.5 ÷ 14.4 VDC
Idling current 0.53 A
Switched off without DRC 1 mA
Switched off with DRC 4.5 mA
Remote IN 4 ÷ 15 VDC (1mA)
Remote OUT 10 ÷ 15 VDC (130 mA)
ART
(Automatic Remote Turn on/off) - IN from OUTPUT BTL speakers
SIGNAL STAGE
Distortion - THD @ 1 kHz, 1 VRMS Output 0.005%
Bandwidth @ -3 dB 10 Hz ÷ 22 kHz
S/N ratio @ A weighted, 4 V Output, 2 V MASTER input 102 dBA
S/N ratio @ A weighted, 4 V Output, 2 V AUX input 101.5 dBA
S/N ratio @ A weighted, 4 V Output, OPTICAL IN1/IN2 input 110 dBA
Channel Separation @ 1 kHz 85 dBA
Input sensitivity PRE / MASTER 1.2 ÷ 8 VRMS
Input sensitivity Speaker / Master 3 ÷ 20 VRMS
Input sensitivity AUX 0.3 ÷ 5 VRMS
Input impedance Pre In / AUX In / Speaker In 15kΩ/15kΩ/12Ω
Max output Level 0,1% THD 4 VRMS
INPUT STAGE
Low level (Pre) Ch1 ÷ Ch6; AUX L/R
Hi level (Speaker In) Ch1 ÷ Ch6
Digital 2 x Optical S/PDIF; Max 192 kHz / 24 bit
OUTPUT STAGE
Low Level (Pre) Ch1 ÷ Ch9
CROSSOVER
Filter type Full / Hi pass / Low Pass / Band Pass
Filter mode and slope Linkwitz @ 12/24 dB - Butterworth @ 6/12/18/24 dB
Crossover frequency 68 steps @ 20 ÷ 20k Hz
Phase control 0° / 180°
Equalizer (20 Hz ÷ 20 kHz)
Analog Input Equalizer Automatic De-Equalization
Output Equalizer N.9 Parametrics Equalizers: ±12 dB;10 pole; 20 ÷ 20k Hz
Time Alignment
Distance 0 ÷ 510 cm / 0 ÷ 200.8 inches
Delay 0 ÷ 15 ms
Step 0,08 ms; 2,8 cm / 1.1 inch
CONNECTION
From / To Personal Computer 1 x Micro USB
To Audison DRC AB / DRC MP 1 x AC Link
Optical 2 sel Optical In 2 wire control +12 V enable
Mem D sel Memory D wire control GND enable
GENERAL REQUIREMENTS
PC connections USB 1.1 / 2.0 / 3.0 Compatible
Software/ PC requirements
Video resolution with screen resize min. 800 x 600
Ambient operating temperature range 0 °C to 55 °C (32 °F to 131 °F)
SIZE
W (Width) x H (Height) x D (Depth) mm/inch 130 x 34.5 x 199 / 5.11” x 1.35” x 7.83”
Weight kg/lbs 700 / 1.5
Microsoft Windows (32/64 bit): Vista, Windows 7, Windows 8, Windows 10
2 ÷ 7 VDC
44
All specications subject to change without notice
PART OF ELETTROMEDIA
62018 Potenza Picena (MC) Italy
T +39 0733 870 870 - F +39 0733 870 880
www.elettromedia.it
Loading...
