Audison APBMW X4E User Manual

www.audison.eu
APBMW X4E
Coaxial for BMW-MINI
TECHNICAL SPECIFICATIONS
Component Coax
Midrange size mm (in.) 100 (4)
Tweeter diaphragm mm (in.) 24 (0.9)
Power Handling
Impedance Ω 4
Frequency Response Hz 100 ÷ 22k
Magnet size D x d x h
Weight of one speaker kg (lb.) 0,5 (1.1)
Woofer Voice Coil Ø mm (in.) 25 (1)
Tweeter Voice Coil Ø mm (in.) 20 (0.8)
ELECTRO-ACOUSTIC PARAMETERS
D mm 80
Xmax mm ±0,5
Re Ω 3,4
Fs Hz 100
Le mH 0,32
Vas I 1,8
Mms g 5,8
Cms mm/N 0,5
BL T•m 5,4
Qts 0,38
Qes 0,4
Qms 6,2
Spl dB 88
W peak
W continuos8040
mm (in.)
50 (1.97) x 29 (1.14) x 3 (0.12)
the installation of a two-way system on the front or for rear seat upgrade;
2 Neodymium Magnetic group to maximize performance while
minimizing bulk and weight;
3 25 mm (1") berglass woofer voice coil for high power
dissipation and stiffness;
4 Waterproof pressed-paper cone for medium natural
frequencies free from any plastic resonance;
5 20 mm (0.8") Tetolon coil tweeter with dispersion
characteristics optimized with FEM simulations;
6 BMW-Mini compatible aluminium die-cast basket with Plug &
Play connectors;
7 30 cm extension provided featuring Plug & Play connectors,
for high flexibility of installation;
8 Damping removable motor cover.
BMW and MINI are trademarks of BMW AG (Bayerische Motoren Werke Aktiengesellschaft)
Elettromedia
62018 Potenza Picena (MC) Italy T +39 0733 870 870 - F +39 0733 870 880 www.elettromedia.it
A A3 B C D U
119 mm 143 mm 100 imm 67,5 mm 39 mm 129,5 mm
4.69 in. 5.63 in. 3.94 in. 2.66 in. 1.54 in. 5.1 in.
All specications subject to change without notice_18.B
