SAFETY PRECAUTIONS
AVIS
WARNING : TO REDUCE THE RISK OF
ELECTRIC SHOCK, DO NOT REMOVE COVER
(OR BACK). NO USERSERVICEABLE PARTS
INSIDE. REFER SERVICING TO QUALIFIED
SERVICE PERSONNEL.
The lightning flash with arrowhead symbol,
within an equilateral triangle, is intended
to alert the user to the presence of
uninsulated “dangerous voltage” within the product’s
enclosure that may be of sufficient magnitude to
constitute a risk of electric shock to persons.
The exclamation point within an equilateral
triangle is intended to alert the user to the
presence of important operating and
maintenance (servicing) instructions in the literature
accompanying the appliance.
This product
contains a low
power laser device.
The symbol for Class II
(Double Insulation)
INVISIBLE LASER RADIATION WHEN UNIT IS
OPENED AND INTERLOCKS ARE DEFECTED.
AVOID EXPOSURE TO LASER BEAM.
CAUTION
• DANGER OF EXPLOSION IF BATTERY IS
INCORRECTLY REPLACED. REPLACE ONLY
WITH THE SAME OR EQUIVALENT TYPE.
• TO PREVENT ELECTRIC SHOCK, MATCH
WIDE BLADE OF PLUG TO WIDE SLOT OF
WALL OUTLET, THEN FULLY INSERT.
WARNING :
• TO PREVENT FIRE OR SHOCK HAZARD, DO
NOT EXPOSE THIS UNIT TO RAIN OR
MOISTURE. DO NOT PLACE OBJECTS
FILLED WITH LIQUIDS ON OR NEAR THIS
UNIT.
• SHOULD ANY TROUBLE OCCUR,
DISCONNECT THE AC POWER CORD AND
REFER SERVICING TO A QUALIFIED
TECHNICIAN.
CAUTION
E
1
CLASS 1 LASER PRODUCT
APPAREIL À LASER DE CLASSE 1
PLACEMENT INFORMATION
• Do not use this unit in places which are
extremely hot, cold, dusty or humid.
• Do not restrict the air flow of this unit by placing
it somewhere with poor air flow, by covering it
with a cloth, by placing it on bedding or carpeting.
SAFETY INFORMATION
• When connecting or disconnecting the AC power
cord, grip the plug and not the cord itself. Pulling
the cord may damage it and create a hazard.
• When you are not going to use the unit for a
long period of time, disconnect the AC power
cord.
CONDENSATION INFORMATION
• When left in a heated room where it is warm
and damp, water droplets or condensation may
form inside the equipment. When there is
condensation inside the unit, the unit may not
function normally. Let the unit stand for 1-2 hours
before turning the power on or gradually heat
the room and let the unit dry before use.
RATING PLATE LOCATION
The rating plate is located on the rear of unit.
FCC STATEMENTS
NOTE: This unit has been tested and found to
comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits
are designed to provide reasonable protection
against harmful interference in a residential
installation. This unit generates, uses and can
radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may
cause harmful interference to radio communication.
However, there is not guarantee that interference
will not occur in a particular installation. If this unit
does cause harmful interference to radio or
television reception, which can be determined by
turning the unit off and on, the user is encouraged
to try to correct the interference by one or more of
the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the unit and
receiver.
- Connect the unit into an outlet on a circuit
different from that to which the receiver is
connected.
- Consult the dealer or an experienced radio/TV
technician for help.
WARNING: Changes or modifications to this unit
not expressly approved by party responsible for
compliance could void the user authority to operate
unit.
IMPORTANT SAFETY INSTRUCTIONS
1) Read these instructions.
2) Keep these instructions.
3) Heed all warnings.
4) Follow all instructions.
5) Do not use this apparatus near water.
6) Clean only with dry cloth.
7) Do not block any ventilation openings.
Install in accordance with the
manufacturer’s instructions.
8) Do not install near any heat sources such
as radiators, heat registers, stoves, or
other apparatus (Including amplifiers)
that produce heat.
9) Do not defect the safety purpose of the
polarized or grounding-type plug. A
polarized plug has two blades with one
wider than the other. A grounding type plug
has two blades and a third grounding
prong. The wide blade or the third prong
are provided for your safety. If the provided
plug does not fit into your outlet, consult
an electrician for replacement of the
obsolete outlet.
10) Protect the power cord from being walked
on or pinched particularly at plugs,
convenience receptacles, and the point
where they exit from the apparatus.
11) Only use detachments / accessories
specified by the manufacturer.
12) Use only with the cart, stand, tripod,
bracket, or table specified by the
manufacturer, or sold with the app aratus.
When a cart is used, use
caution when moving the
cart / apparatus
combination to avoid
injury form tip-over.
13) Unplug this apparatus during lightning
storms or when unused for long periods
of time.
14) Refer all servicing to qualified service
personnel. Servicing is required when the
apparatus has been damaged in any way ,
such as power-supply cord or plug is
damages, liquid has been spilled or
objects have fallen into the apparatus, the
apparatus has been exposed to rain or
moisture, does not operate normally, or
has been dropped.
MAINTENANCE
CLEANING THE DISC
A defective or dirty disc inserted into the unit can cause sound to drop out during playback.
Handle the disc by holding its inner and outer edges.
• Do NOT touch the surface of the unlabeled side of the disc.
• Do NOT stick paper or tape on the surface of the disc.
• Do NOT expose the disc to direct sunlight or excessive heat.
• Clean the disc before playback. Wipe the disc from the center outward
with a cleaning cloth.
• NEVER use solvents such as benzine or alcohol to clean the disc.
• Do NOT use irregular shape discs (example : heart shaped, octagonal, etc.). They may cause
malfunctions.
CLEANING THE UNIT
• Be sure to turn the unit off and disconnect the AC power cord before cleaning the unit.
• Wipe the unit with a dry soft cloth. If the surfaces are extremely dirty, wipe clean with a cloth which has
been dipped in a weak soap-and-water solution and wrung out thoroughly. Then wipe it with a dry
cloth.
• Never use alcohol, benzine, paint-thinner, cleaning fluid or other chemicals. Do NOT use compressed
air to remove dust.
IMPORTANT NOTE
Before shipping the unit, remove any disc from the disc compartment.
E
2
CONTENTS
SAFETY PRECAUTIONS ................ 1
IMPORTANT SAFETY
INSTRUCTIONS ............................... 2
MAINTENANCE ................................ 2
CONTENTS ...................................... 3
DISC FORMATS .............................. 4
ACCESSORIES ................................ 5
USING OF REMOTE CONTROL ...... 5
CONTROL REFERENCE GUIDE . 6-7
CONNECTIONS .............................. 8-9
Connecting a TV Antenna ................ 8
Connecting to other Equipment with
Video Output (VCR, Camcorder, Video
Game System, Cable, Satellite system,
etc.) .................................................. 8
Connecting to another TV with A/V Input
.......................................................... 9
Connecting the AC Power Cord ........ 9
INSTALLA TION .................................. 10
Removing the Base Sand ................ 10
Mounting on the wall ....................... 10
USING HEADPHONES .................... 10
SCREEN VIEWING ANGLE
ADJUSTMENT ................................ 1 1
UNIT OPERATION .......................... 11
SOUND SYSTEM ............................ 1 1
USING THE TV ................................... 12
Searching for TV Channels
Automatically ................................... 12
Manual Searching for TV Channels
......................................................... 12
Watching Television ......................... 12
Resetting the TV Channels .............. 12
TV SETUP .................................... 13-15
Picture Setting .................................. 13
Sound Setting .................................. 13
Timer Setting .................................... 14
Misc Setting ...................................... 14
TV Channel Setting .......................... 15
PLAYING A DISC ......................... 16-17
Playing a Disc .................................. 16
Playing a Picture File Disc ................ 16
Pausing Playback (still mode) .......... 16
Stopping Playback ........................... 16
Skipping to a different Track ............ 16
Fast Forward / Fast Reverse .......... 17
Audio Selection (DVD) ..................... 17
Subtitle Selection (DVD) ................... 17
Angle Selection (DVD) ..................... 17
SPECIAL FUNCTION ..................... 18
Display ............................................ 18
Locating a Specific tTtle (DVD) ........ 18
Locating s Specific Chapter / Track .. 18
Locating a Specific Time (DVD) ....... 18
REPEA T PLAYBACK ....................... 19
Repeating a Chapter / Title (DVD) .... 19
Repeating a Single Track / an Entire Disc
(CD) ................................................ 19
DVD/CD PROGRAMMABLE
PLA YBACK .................................... 20
Title / Chapter Programmed Playback
(DVD) .............................................. 20
Track Programmed Playback (CD)
........................................................ 20
CUSTOMIZING THE FUNCTION
SETTINGS ................................. 20-21
Language Setup .............................. 20
Video Setup .................................... 21
System Setup ................................. 21
TROUBLESHOOTING GUIDE .......... 22
E
3
DISC FORMATS
Chapter 1
Titel 1 Titel 2
Chapter 2 Chapter 1 Chapter 2Chapter 3
Track 1 Track 2 Track 3 Track 4 Track 5
NOTES ON COPYRIGHT
It is forbidden by law to copy, broadcast, show,
broadcast on cable, play in public or rent
copyrighted material without permission.
Apparatus Claims of U.S. Patent Nos. 4,907,093;
5,315,448 and 6,516,132 licensed for limited
viewing uses only.
DVD video discs are copy protected, and any
recordings made from these discs will be
distorted. This product incorporates copyright
protection technology that is protected by method
claims of certain U.S. patents and other
intellectual property rights owned by Macrovision
Corporation and other rights owners. Use of this
copyright protection technology must be
authorized by Macrovision Corporation, and is
intended for home and other limited viewing uses
only, unless otherwise authorized by Macrovision
Corporation. Reverse engineering or disassembly
is prohibited.
The unit can play:
DVDs [8cm/
12cm disc]
Audio CDs [8cm/
12cm disc]
CD-R CD-RW
Compatible
REGION MANAGEMENT INFORMATION
Region Management Information: This unit is
designed and manufactured to respond to the
Region Management Information that is encoded
on DVD discs. If the Region number printed on
the DVD disc does not correspond to the Region
number of this unit, this unit cannot play that disc.
The region number of this equipment is 1.
1
DISC FUNCTION OR OPERATION THAT
IS NOT AVAILABLE
When the symbol appears on the screen, it
indicates that the function or operation attempted
is not available at that time. This occurs because
the DVD disc manufacturer determines the
specific functions. Certain functions may not be
available on some discs. Be sure to read the
documentation provided with the DVD.
ICONS USED ON DVDs
Sample Icons:
1. English
2
2. French
1. English
2
2. French
LB
2
1
Language selections for audio
Language selections for subtitles
Screen aspect ratio
Multiple camera angles
Region code indicator
NOTE:
When playing back a CD-G (Graphics) or CD
EXTRA disc, the audio portion will be played, but
the graphic images will not be shown.
TITLES, CHAPTERS AND TRACKS
• DVDs are divided into “TITLES” and
“CHAPTERS”. If the disc has more than one
movie on it, each movie would be a separate
“TITLE”. “CHAPTER” are sections of titles.
• Audio CDs are divided into “TRACKS”. A
“TRACK” is usually one song on an audio CD.
NOTE
Numbers identify each title, chapter and track on
a disc. Most discs have these numbers record on
them, but some do not.
NOTES ON UNAUTHORIZED DISCS
Y ou may not able to playback some DVD discs on
this equipment if they were purchased from outside
your geographic area or made for business
purpose.
E
4
ACCESSORIES
Please check and identify the supplied accessories.
AC Power Cord .................................................................................................... x 1
AC Adapter ........................................................................................................ x 1
Remote Control (with batteries) .............................................................................. x 1
USING OF REMOTE CONTROL
USING THE REMOTE CONTROL
• This remote control is magnetic and can be
attached to most refrigerators. Some
refrigerator panels are not metallic. In this
case, try attaching the magnetic remote control
to the side of the refrigerator.
• Point the remote control at the remote sensor
located on the unit.
• When there is a strong ambient light source,
the performance of the infrared remote sensor
may be degraded, causing unreliable
operation.
• The recommended effective distance for
remote operation is about 16 feet (5 meters).
TO INSTALL BATTERIES
1. Open the battery door.
2. Insert 2 “AAA” batteries.
+
_
_
+
E
5
BATTERY REPLACEMENT
When the batteries become weak, the operating
distance of the remote control is greatly reduced
and you will need to replace the batteries.
CAUTION: Danger of explosion if battery is
incorrectly replaced. Replace only with the
same or equivalent type.
NOTES
• Do not place the remote control near
magnetic devices.
• If the remote control is not going to be used
for a long time, remove the batteries to avoid
damage caused by battery leakage corrosion.
• Do not mix old and new batteries. Do not mix
ALKALINE, standard (CARBON-ZINC) or
rechargeable (NICKEL-CADMIUM) batteries.
• Always remove batteries as soon as they
become weak.
• Weak batteries can leak and severely damage
the remote control.
• WARNING : Do not dispose of batteries in a
fire. Batteries may explode or leak.
CONTROL REFERENCE GUIDE
REMOTE CONTROL
1
2
3
4
5
6
7
8
9
10
11
12
1. FUNCTION button
Switch between TV / AV IN / DVD.
2. Number (0 - 9) buttons
3. MEMORY button
Set predetermined playback.
• [dot] button
Digital TV channels (i.e. 11.3 or 12.7)
4. EXIT button
Press to exit the TV menu and return directly
to normal viewing.
RETURN button
Return to normal operation after using the
SETUP menu of a DVD.
5. CURSOR (
Use to highlight selections on a menu screen
and adjust certain settings.
ENTER button
Press to confirm selections on a menu screen.
CH+ / CH- buttons
Press + / - button to move the TV channels.
6. DVD MENU button
Press to enter the main menu of the DVD
you are watching.
, , , ) buttons
13
14
15
16
17
18
19
20
21
22
23
24
7. VOLUME (- / +) buttons
Press to adjust the volume level. Use to
highlight selections on a menu screen and
adjust certain settings.
8. GOTO button
Skip directly to a specific location on a DVD/
CD.
PREV button
9.
Select previous chapters or tracks on a disc.
10. ANGLE button
Switch the camera angle of the video
presentation when scenes with multiple
camera angles are recorded on a DVD.
11. AUDIO button
Select audio soundtracks of a DVD or change
the output mode of a CD.
MTS button
Press to select MONO sound, STEREO sound
and Secondary Audio Program (SAP).
12. FORMAT button
Press to select the picture format.
13. PICTURE button
Select from preset screen display settings to
match the type of show you are watching.
/ ON button
14.
Press to turn ON the unit or put it in STANDBY
(OFF) mode.
15. LAST CH button
Press to switch repeatedly between the last
two channels displayed.
16. TV MENU button
Press to display the on-screen TV menu.
17. MUTE
Press to turn off the sound.
18.
Stop playing a disc.
Press to start and resume playback of a disc.
Pause playback and single frame advance.
19. SEARCH
20. SUBTITLE button
Select one of the subtitle languages
programmed on a DVD.
21. NEXT
Select next title, chapter or track on a disc.
22. SOUND button
Press to select from preset sound settings to
match the type of show you are watching.
23. REPEAT button
Repeat chapter or title of a DVD.
Repeat single track or whole CD.
SETUP button
Enter and exit the SETUP menu of the DVD.
24. DISP (DISPLAY) button
Change disc status information displayed on
the screen.
button
STOP button
PLA Y button
PAUSE button
: Fast reverse playback.
: Fast forward playback.
/ buttons
button
E
6
CONTROL REFERENCE GUIDE
FRONT & BACK VIEWS
1
23
22
21
20
19
18
17
16
15
1. Color LCD screen
2. Remote sensor
Point the remote control here.
Standby indicator
3. Right speaker
4. Removable stand
5. MENU button
Enters the on-screen TV menu.
/ ON button
6.
Turns the unit on and off.
7. DVD DOOR OPEN button
Open the disc door.
8. AUDIO / VIDEO OUT jacks (DVD out)
Connects to another TV.
9.
PREV button
Press PREV button to go back to previous
chapters / tracks.
Press and hold fast reverse playback.
NEXT button
10.
Press NEXT button to advance chapters / tracks.
Press and hold to fast forward playback.
11. PAUSE button
Pause playback and single frame advance.
E
7
2
3
4
5
6
7
8
1314
12
1011
9
12. STOP button
Stop playing a disc.
PLA Y button
13.
Press to start and resume playback of a disc.
14. Wall mounting holes
15. DC IN 12V jack
16. Headphones jack
17. AUDIO IN (Left/Right)/ VIDEO IN jacks
18. TV ANTENNA terminal
Connects a TV antenna or CATV cable.
19. - VOL + controls
Adjusts the volume level and highlights
selections (Left & Right) on the TV menu
screen.
CH buttons
20.
Press to confirm selections on the TV menu
screen and
21. FUNCTION button
Selects TV / AV IN / DVD
22. Left speaker
23. DVD door
Close by pushing the disc door.
/ to move the TV channels.
CONNECTIONS
CONNECTING A TV ANTENNA
To view television channels correctly, a signal must be received from one of the following sources:
- An indoor or outdoor aerial antenna
- A cable system
- A satellite system
To TV
Antenna
terminal
To Home
Antenna
terminal
NOTE
For receiving over-the-air TV broadcasts, we recommend that you use an external fixed antenna.
Should you require the use of a temporary antenna, please ensure that you purchase an antenna with
sufficient ability to receive in weak signal areas. Only when you are in close proximity to a transmitter
will a temporary antenna reproduce a signal as strongly as a fixed antenna.
CONNECTING TO OTHER EQUIPMENT WITH VIDEO OUTPUT
To connect to other equipment such as a VCR, camcorder, video game system, cable or satellite system
etc.
Connecting to a VCR /
Camcorder / Video Game
To AUDIO /
VIDEO IN jacks
System / Cable / Satellite
System
Connects the AUDIO / VIDEO cable
(not included) as shown:
Make sure you connect the cable from
the other equipment (AUDIO/VIDEO
OUT) to this unit (AUDIO/VIDEO IN).
NOTE
Please refer to the user manual for the
other equipment for more information.
VCR / CAMCORDER /
VIDEO GAME SYSTEM / CABLE /
SATELLITE SYSTEM etc.
To AUDIO / VIDEO OUT jacks
Cable without a CATV
converter
Combination VHF/UHF
antenna
(ATSC / NTSC signal)
Separate VHF/UHF
antenna
(ATSC / NTSC signal)
L
AUDIO IN
R
VIDEO IN
E
8
VIDEO
OUT
AUDIO
OUT
DVD
TV
CONNECTIONS
CONNECTING TO ANOTHER TV WITH A/V INPUT
Connecting to another TV
Connects the AUDIO / VIDEO cable
(not included) as shown:
Make sure you connect the cable from
another TV (AUDIO/VIDEO IN) to this
unit (AUDIO/VIDEO OUT).
NOTE
• Please refer to your another TV user
manual for more information.
CONNECTING THE AC POWER CORD
This AC adapter operates on AC 110240V .
1. Connect the AC power cord to the
AC adapter.
2. Plug the AC adapter cord into the
DC-IN 12V on the unit.
3. Connect the AC adapter and AC
power cord into a wall outlet.
NOTES
• The included AC adapter and AC
power cord are for use with this unit
only. Do not use them with other
equipment.
• TO PREVENT ELECTRIC SHOCK,
MA TCH WIDE BLADE OF PLUG TO
WIDE SLOT OF WALL OUTLET,
THEN FULLY INSERT.
• When the AC power cord is plugged
in, the unit is not completely
disconnected from the main, even when the power is turned off.
• Be sure the AC power cord is disconnected and all functions are off before making connections.
• Make sure that all the components are connected correctly.
• When you are not going to use the unit for a long period of time, disconnect the AC power cord.
To DC
IN 12V
T o AUDIO /
VIDEO OUT
jacks
To AUDIO /
VIDEO IN jacks
AC adapter
T o AC wall
outlet
E
9
INSTALLATION
REMOVING THE BASE STAND
WARNING: The LCD display is very
fragile, and must be protected at all
times when removing the base stand.
Be sure that no hard or sharp objects,
or anything that could scratch or
damage the LCD display, come in
contact with it. Do NOT place pressure
on the rear of the unit at anytime
because the screen could crack.
1. Disconnect any cables or cords
connected to the unit.
2. Lay the unit down on a flat surface,
so the back side is facing up, making
sure to place a soft cushioned material
(such as a pillow or thick piece of
foam) beneath the screen.
3. Remove the 3 screws and then
remove the BASE STAND from the
unit.
MOUNTING ON THE WALL
This unit is VESA-compliant, and is
designed to be wall-mounted with a
VESA-compliant 1.375” x 2.9375”
(35mm x 75mm) mounting kit designed
for flat-panel TVs (sold separately).
Mount this unit according to the
directions included with the mounting
kit.
NOTE
Remove the base stand before
mounting the unit on the wall.
WALL MOUNTING HOLES : 35 X 75 MM
WALL MOUNTING HOLES :35 X 75 MM
WALL MOUNTING HOLES :35 X 75 MM
USING HEADPHONES
• Turn down the volume before
connecting headphones to the unit,
then adjust the volume to your
desired level.
• When headphones are connected, no
sound will come from the front
speakers.
NOTE
Avoid listening to sound at high levels
for prolonged periods of time. This may
be harmful to you and may cause
hearing loss.
Headphones
(1/8” [3.5mm]
diameter plug)
E
10
+16° -8°
SCREEN VIEWING ANGLE ADJUSTMENT
The unit is designed to allow users to have a comfortable
viewing angle.
1. Hold the stand firmly.
2. Gently adjust the TV.
CAUTION
Do not force the LCD screen over the maximum viewing
angle settings as stated above. Attempting this will result
in damage to the unit.
UNIT OPERATION
TURNING THE UNIT ON
When the AC power cord is connected, press the /ON button to turn it on.
Press the FUNCTION button to select the desired mode (TV / AV IN / DVD).
If you select DVD, the DVD logo will appear on the screen.
NOTE
When the unit is not going to be used for a long time, disconnect the AC power
cord from the AC wall outlet.
SOUND SYSTEM
2
1
DOLBY DIGITA L (FOR DVD)
Dolby Digital is a sound system developed by Dolby Laboratories Inc. that gives movie theatre ambience
to audio output when the unit is connected to a Dolby Digital 5.1 channel processor or amplifier.
This unit automatically recognises DVDs that have been recorded with Dolby Digital.
Not all Dolby Digital sources are recorded with 6 channels.
Some sources marked Dolby Digital may be recorded in Dolby Surround, 1 2 channel system. Look for
this logo on your unit.
Manufacturer under license from Dolby Laboratories.
“Dolby” and
E
11
the double-D symbol are trademarks of Dolby Laboratories.
USING THE TV
RF CH 13
Press “MENU” ToExit AutoScan
Found 0
: SELECT
“ENTER” : CONFIRM
PROCEED WITH AUTO SCAN?
NO
YES
: SELECT
“ENTER” : CONFIRM
PLEASE SELECT ANTENNA TYPE.
AIR
CATV
2.3 Xxxxxxx Xxxx
AUDIO 1/1(L+R) FTA
2007/01/31 07:38 07:00-08:00 TV LEVEL: Good
Xxxx xx xxxxxx xx xxxx xx xxxxxxxx x xxxx xxxxx xxx xx xxx
xxxxxxxxxxx xx xxxx xxxxx xx x xxxxx xxx xxxxxx x xxxxxx xxx
xxxxxx xx xxxx xx xxxxxxxx x xxxx xxxxx xxx xx xxx
xxxxxxxxxxx xx xxxx xxxxx xx x xxxxx xxx xxxxxx x xxxxxx xxx
Position no.
Time information
Audio
information
ATSC data information
(only ATSC)
Signal
strength
(only ATSC)
Rating
information
ATSC data
information
(only ATSC)
Connect an antenna or CATV cable or Satellite system to the TV antenna terminal
before searching TV channels.
Searching for TV channels automatically
(Only appears to the first time Power ON)
1. Connect the TV antenna.
2. Connect the AC adapter and AC cord.
3. Press the
4. Press the ENTER button.
5. Press the
ENTER button to start auto scan.
6. The unit will immediately search all channels for those with adequate
signal strength and store those channels with signals in memory. The
unit will take a short minutes to finish auto scan and aftter this is
completed, the unit will switch to the first channel found.
Manual searching for TV channels
1. Press the TV MENU button, then press the button to TV
CHANNEL SETTING.
2. Press the button to select ANTENNA. Use the or button to
select AIR or CATV.
3. Use the
4. Press the ENTER button to enter sub menu of Auto Scan.
5. Use the button to select “Start to Scan” in the sub menu.
6. Press the ENTER button to start the search for TV channels.
7. The screen will show the first received channel when auto search is completed.
Watching television
Viewing a television station after the auto/manual search for channels.
1. Press the FUNCTION button to TV mode.
2. Press the CH+ or CH- button to select a channel, or press the number button on the remote to
select the channel you want to watch.
• For channels 1 to 9, enter one-digit channel number.
• For channels 10 to 99, enter two-digit channel number.
• For channels 100 or over, enter three-digit channel number.
NOTE
• When a channel is selected, the channel number is displayed on the top right corner of the screen.
This number will disappear after a few seconds.
A TSC TV mode:
Press the DISPLAY button, the upper
window will pop up, then press the
DISPLAY button again, the lower window
will pop up. Press the DISPLAY button
once to exit.
NTSC TV mode:
Press the DISPLAY button, the upper
window will pop up, then press the
DISPLAY button once to exit.
/ ON button to turn on the unit.
or button to select “Air” or “CATV”, then press the
button to select Auto Scan.
E
12
TV SETUP
Brightness
UP/DOWN
ADJUST “MENU”:EXIT
Sharpness
Tint
Color
Picture Mode
Contrast
Standard
50
50
50
50
0
PICTURE SETTING
1. Press the TV MENU button.
2. Use the
(Picture Mode / Contrast / Brightness /
Sharpness / Tint / Color).
3. Use
screen will change to your selected mode
immediately. Press the TV MENU button to
return to the previous menu.
4. Repeat steps 2 and 3 to adjust other options.
5. To exit the TV SETUP MENU and return to the
normal screen, press the EXIT button on the
remote control.
NOTE
You can also access these setting by pressing
the PICTURE button.
or button to select the options
or button to make adjustment. The
Picture Mode: Select from preset screen display settings to match the type of show you are watching
Contrast: Adjust to sharpen the picture quality. The black portions of the picture become richer in
Brightness: Adjust to brighten or darken the whole picture.
Sharpness: Adjust the sharpness level to improve detail in the picture.
Tint: Adjust natural skin tones in the picture quality.
Color: Adjust the color of the picture.
(Standard, Dynamic, Soft & Personal).
darkness and the white become brighter.
SOUND SETTING
1. Press the TV MENU button.
2. Use the
SETTING.
3. Use the or button to select the options
(Sound Mode / Bass / Treble / Balance).
4. Use the or button to make adjustment.
Press the TV MENU button to return to the
previous menu.
5. Repeat steps 2 to 4 to adjust other options.
6. To exit the TV SETUP MENU and return to the
normal screen, press the EXIT button on the
remote control.
NOTE
You can also access these setting by pressing
the SOUND button.
Sound Mode: Select from preset sound
Bass: Adjust the bass range.
Treble: Adjust the treble range.
Balance: Adjust the balance level toward the left or right speakers.
Audio Language: Use the
E
13
or button to select SOUND
Sound Mode
Standard
Bass
Treble
Balance
Audio Language
UP/DOWN
settings (Standard, Music,
Movie, Personal) to match the type of show you are watching.
English
ADJUST “MENU”:EXIT
or button to select English, French or Spanish (Available for Digital
TV system only).
NOTE
Only for DTV/ATSC input source mode, thus it is not available in other input source
mode.
50
50
0
TV SETUP
UP/DOWN
ADJUST “MENU”:EXIT
Restore Setting
Language
Color Mode
English
Normal
TIMER SETTING
1. Press the TV MENU button.
2. Use the
SETTING.
3. Use the
(OSD Duration / Sleep Timer / Time Zone /
Day Saving Time).
4. Use the
Press the TV MENU button to return to the
previous menu.
5. Repeat steps 2 to 4 to adjust other options.
6. To exit the TV SETUP MENU and return to the
normal screen, press the EXIT button on the
remote control.
OSD Duration:Select amount the time of TV
Sleep Timer: Set the LCD TV to turn itself
Time Zone / Day Saving Time / Clock
1. Set the local Time Zone, eg. Pacific.
2. After selecting the time zone, the Day Saving Time must be activated for those areas observing
such change.
3. The clock will be recoded automatically (for ATSC only).
MISC SETTING
1. Press the TV MENU button.
2. Use the
3. Use the or button to select the options
(Language / Color Mode / Restore Setting).
4. Use the
The screen will change to your selected mode
immediately. Press the TV MENU button to
return to the previous menu.
5. Repeat steps 2 to 4 to adjust other options.
6. To exit the TV SETUP MENU and return to
the normal screen, press the EXIT button on
the remote control.
Language : Select from English /
Color Mode : Adjust the three color
Restore Setting :If you reset the TV to the factory settings, all your present settings on picture &
or button to select TIMER
or button to select the options
or button to make adjustment.
OSD Duration
Sleep Timer
Time Zone
Day Saving Time
Clock
menu showing on screen.
off within a certain time.
or button to select MISC SETTING.
or button to make adjustment.
Français / Español.
temperature of the picture.
Select Normal (balanced) /
Warm (red white) / Cool (blue white) mode.
sound will be erased and replaced by the factory’s default settings.
UP/DOWN
30 Sec
Off
Eastern
Off
----/--/-- --:--
ADJUST “MENU”:EXIT
E
14
TV SETUP
Cable System
Start to Scan
Auto
UP/DOWN
ADJUST “MENU”:EXIT
EDIT
SELECT
“MENU”:EXIT
123#
TV CHANNEL SETTING
1. Press the TV MENU button.
2. Use the
SETTING.
3. Use the
(Antenna / Auto Scan / Auto Scan Add CH
/ Channel Skip / Channel No. / Channel
Label).
4. Use the
The screen will change to your selected mode
immediately. Press the TV MENU button to
return to the previous menu.
5. Repeat steps 2 to 4 to adjust other options.
6. To exit the TV SETUP MENU and return to
the normal screen, press the EXIT button on
the remote control.
NOTE
Channel No. : 2-69 Channel for Air, 1-135
Channel for CATV.
Antenna : Select “CATV” to receive cable signal. Select
Auto Scan : Automatically search all channels for those
Auto Scan Add CH :The stored channels can not be cleared and
Channel Skip: You may switch ON/OFF the skip function of
Channel Label: You may edit one label for each channel.
1. Select the Channel Label item and press the
into the channel label edit screen.
2. Use the
3. Use the
4. After editting, press the DISPLAY button and the Channel &
Channel Label will be shown on the screen.
or button to select TV CHANNEL
or button to select the options
Antenna
or button to make adjustment.
Auto Scan
Auto Scan Add CH
Channel Skip
Channel No.
Channel Label
UP/DOWN
“AIR” to receive air singal.
with adequate signal strength.
the Auto Scan Channels will be added.
If you has selected CATV in TV CHANNEL
SETTING, then you can select Cable System
(AUTO / STD / HRC / IRC) in the sub menu
as the picture shown.
each stored channel by selecting the channel
with / button (and using / button to
select page if the amount of stored channels in
more than 1 page), and followed with pressing
the ENTER button.
or button to go
or button to enter the number or letter.
or button to move and edit for the next character.
Air
ADJUST “MENU”:EXIT
No. SkipProgram Name
2.0 Off
3.0 Off
“ENTER”:SELECT
“MENU”:EXIT
E
15
PLA YING A DISC
: SELECT
“ENTER” : CONFIRM
PROCEED WITH AUTO SCAN?
NO
YES
This owner’s manual explains the basic instructions of this unit. Some DVDs are produced with
limited operation during playback. For example, many DVDs do not allow users to skip government
warnings, or in some cases previews or other features. This is not a defect in the unit. Refer to the
instruction notes of discs.
” may appear on the screen during operation. A “ ” means that the desired operation is not
“
permitted by the unit or disc.
PLAYING A DISC
1. Press the /ON button to turn on the unit.
2. Use the
button.
3. Use FUNCTION button repeatedly to select DVD mode,
then press the ENTER button.
See CUSTOMIZING THE FUNCTION SETTINGS before
proceeding to step 4.
4. Press the
5. Hold the disc by its sides and carefully press onto the central support of compartment with the
printed side facing towards you until you hear a “click”.
6. Push the disc door to close it.
It takes a short while for your unit to load the disc. After loading, the unit will automatically either
bring you to the main menu of DVD, or start playing the DVD. If the unit does not automatically start
playing the DVD, press the
PLAYING A PICTURE FILE DISC
This unit can play JPEG files recorded on a CD-R or CD-ROM disc.
1. Press the
2. Hold a JPEG file disc by its edge and gently push it onto the spindle with label side facing towards you
until you hear a “click”.
3. Push the disc door to close it.
4. The unit will load the disc and automatically display the contents of the disc on the screen, while also
beginning to play the picture file. These files will then be played back one by one.
5. Press the RETURN button to folder list.
6. Use the
selected file.
NOTES
• You can press the
• You can press the
the previous picture. Press the
• You can press the ANGLE button to rotate direction of the picture by 90°.
button to select “NO”, then press the ENTER
(Only appears to the first time Power ON)
OPEN button to open the disc door.
PLAY button.
OPEN button to open the disc door.
, , or button to view and select desired file, then press the ENTER button to confirm the
PAUSE button to freeze the picture, and press the PLA Y button to resume slide show.
PREV or NEXT button to change the picture. Press the PREV button to view
NEXT button to view to the next picture.
PAUSING PLAYBACK (STILL MODE)
Press the PAUSE button. To resume normal playback, press the PLAY button. Each time you press
PAUSE button, the picture advances one frame.
the
STOPPING PLAYBACK
Press the STOP button at the location where you want to interrupt playback. To resume playback at
the position where the disc was stopped, press the
PLAY button.
SKIPPING TO A DIFFERENT TRACK
• Press the PREV button to skip to the start of the current/previous track.
• Press the
• For an audio CD, use the number buttons on the remote control to go directly to the desired track number.
NEXT button to skip to the next track.
E
16
PLA YING A DISC
: 1/3ENG 6CH
D
: 2/3 ESP
: [ 2 / 3 ]
FAST FORWARD / FAST REVERSE
1. Press the SEARCH or SEARCH button when a disc is playing.
• The disc begins a fast scan at two times normal (x2) speed.
• Four speeds are available. Each time the SEARCH button is pressed, the speed of the fast scan changes
2. Press the PLAY button when you have reached the desired point to resume playback at normal
speed.
AUDIO SELECTION (DVD)
On some discs, the sound is recorded in two or more formats. Follow the directions below to select the
type of playback.
1. While a disc is playing, press the AUDIO button to show the
current audio format number.
2. Press the AUDIO button repeatedly to select the desired audio format.
NOTES
• If only one audio format is recorded, the number does not change.
• About two seconds later, playback continues in the new audio format.
SUBTITLE SELECTION (DVD)
1. While a DVD is playing, press the SUBTITLE button to display the current language setting.
2. Press the SUBTITLE button repeatedly to select the desired subtitle language.
NOTES
• If only one language is recorded, the language does not change.
• About two seconds later, playback continues with the new subtitle you selected.
• The number of languages recorded differs depending on the disc.
• If no button is pressed within a few seconds, playback continues without changing the current subtitle.
• This function can only be used for discs on which subtitles have been recorded in multiple languages.
• On some DVDs, subtitles are activated from the main menu of the DVD. Press the DVD MENU button
to activate the main menu.
ANGLE SELECTION (DVD)
Some DVDs contain scenes which have been shot from a number of different angles. For these discs,
the same scene can be viewed from each of these different angles.
1. While you are playing a DVD with different angles
recorded, press the ANGLE button to view the number
of the current angle available.
2. Press the ANGLE button repeatedly to change the
scene to the next angle in those recorded.
• About two seconds later, playback continues from
the new angle you selected.
• If no button is pressed within 10 seconds, playback
continues without changing the current angle.
NOTES
• This function can only be used for discs on which scenes shot from multiple angles have been recorded.
• If only one angle is recorded, “
” is displayed.
1/1
Sequence of angle shots
(Example)
:[1/3]
:[2/3]
:[3/3]
E
17
SPECIAL FUNCTION
00:00:00
TRK 0 / 120
X
00:00: 00
TT 00/34CH
0 /02900
0 :00:001
TT 00/21 CH 029/029
00:00:0 0
TT 0/21 CH 029/0290
TT 1/21 CH 6/29 00:07:18
1/3 ENG
2/3 ESP
OFF
6D
TT 1/21 CH 11/29
-00:30:28
R
TT 1/21 CH 11/29
-01:00:28
T
DISPLAY
While the disc is playing, press the DISPLAY button
repeatedly to display information on operation status.
Title Chapter Elapsed time
Audio Subtitle Angle
Title Remaining time
Chapter
Title Total time
Chapter
LOCATING A SPECIFIC TITLE (DVD)
If a DVD disc contains title numbers, you can locate a specific title by directly selecting its title
number.
1. In STOP mode, press the GOTO button.
2. Press the
field and press the corresponding number button(s) for the title you want.
or button to highlight a specific
3. Press the ENTER button to confirm. The unit will start playback about 3 second later.
LOCATING A SPECIFIC CHAPTER / TRACK
If you know the chapter / track number you want to play, you can locate a specific chapter / track by
directly selecting a chapter / track number.
1. Press the GOTO button to search for your
desired chapter / track.
2. Press the
/ track and press the corresponding number
or button to highlight a chapter
button(s) for the chapter / track you want.
3. Press the ENTER button to confirm. The unit will start playback about 3 second later.
LOCATING A SPECIFIC TIME
You can move to a specific location by entering its corresponding time (hours, minutes, seconds)
1. Press the GOTO button.
2. Press the or button to highlight a time
and press the corresponding number button(s)
for the setting point you want.
3. Press the ENTER button to confirm. The unit will start playback about 3 second later.
NOTES
• Some discs may not respond to this process.
• This method of locating a title/chapter is available only on a DVD disc that contains title/chapter numbers.
• Some scenes may not be located as precisely as you specified.
• This method for accessing specific locations is available only within the current title of the DVD disc.
E
18
REPEA T PLAYBACK
You can play a specific title or chapter repeatedly.
(Title repeat, chapter repeat)
REPEATING A CHAPTER (DVD)
When you play the same chapter repeatedly.
1. While the DVD disc is playing, press the REPEAT button until the “REP : CHAPTER” indicator displays
on the screen. The current chapter is played repeatedly.
REPEATING A TITLE
When you play the same title repeatedly.
2. While the DVD disc is playing, press the REPEAT button until the “REP : TITLE” indicator displays on
the screen. The current title is played repeatedly.
To resume normal playback
3. While the DVD disc is playing, press the REPEAT button until the “REP : OFF” indicator displays on
the screen.
Y ou can play a single track or an entire disc repeatedly.
REPEATING A SINGLE TRACK (CD)
Y ou can play the same track repeatedly.
1. When the CD disc is playing, press the REPEAT button until the “REP : REP1” indicator displays on
the screen. The current track is played repeatedly.
REPEATING AN ENTIRE DISC
2. While the CD disc is playing, press the REPEAT button until the “REP : REP ALL” indicator displays
on the screen. The entire disc is played repeatedly.
To resume normal playback
3. Press the REPEAT button until the “REP : OFF” indicator display on the screen.
E
19
DVD / CD PROGRAMMABLE PLAYBACK
PROG
2 - - : - - 6 - - : - - 10 - - : - - 14 - - : - 3 - - : - - 7 - - : - - 11 - - : - - 15 - - : - -
1 - - : - - 5 - - : - - 9 - - : - - 13 - - : - -
4 - - : - - 8 - - : - - 12 - - : - - 16 - - : - -
T C
T C T C T C
PLAY CLEAR
PROG
1 - - - - 5 - - - - 9 - - - - 13 - - - 2 - - - - 6 - - - - 10 - - - - 14 - - - 3 - - - - 7 - - - - 11 - - - - 15 - - - 4 - - - - 8 - - - - 12 - - - - 16 - - - -
PLAY CLEAR
VIDEO SETUP
BRIGHTNESS
CONTRAST
PROGRAMMABLE MEMORY
The two types of programmed playback provided by this unit are title/chapter programmed playback and
track programmed playback.
Title / chapter programmed playback (DVD)
1. In STOP mode, press the MEMORY button.
2. Enter the title numbers in
. Use the or button to
move the highlight to chapter and enter the chapter numbers
in
.
3. Use the
, , or button to move to other fields.
4. Repeat steps 2 to 3.
5. Press the
PLAY button to start the programmed playback.
Title Chapter
Track programmed playback (CD)
1. In STOP mode, press the MEMORY button.
2. Enter the track numbers in
3. Use the
, , or button to move to other fields.
.
4. Repeat steps 2 to 3.
5. Press the
PLAY button to start the programmed playback.
CUSTOMIZING THE FUNCTION SETTINGS
LANGUAGE SETUP
1. Press the SETUP button in STOP mode.
2. Use the
or button to select a language, then press the ENTER
button The screen will change to your selected language
immediately.
3. To exit the SETUP MENU and return to the normal screen,
press the SETUP or RETURN button.
VIDEO SETUP
1. Press the SETUP button in STOP mode.
2. Use the
the
3. Use the
or CONTRAST), then press the
button to make adjustments, then press the ENTER button.
The screen will change to your selected setting.
4. Repeat steps 2 and 3 above to adjust other options.
5. To exit the SETUP MENU and return to the normal screen,
press the SETUP or RETURN button.
button to change the highlight cursor. Use the
button to select LANGUAGE SETUP , then press
or button repeatedly until VIDEO SETUP appears.
or button to select the option (BRIGHTNESS
button. Use the or
LANGUAGE SETUP
OSD LANGUAGE
Track
ENGLISH
DEUTSCH
FRANçAIS
Ñ
ESPA OL
ITALIANO
SVENSKA
PORTUGU S
Ê
E
20
CUSTOMIZING THE FUNCTION SETTINGS
SYSTEM SETUP
TVTYPE
DEFAULT
SYSTEM SETUP
1. Press the SETUP button in STOP mode.
2. Use the
the
3. Use the
DEFAULT), then press the
make adjustments, then press the ENTER button. The screen
will change to your selected setting.
4. Repeat steps 2 and 3 above to adjust other options.
5. To exit the SETUP MENU and return to the normal screen,
press the SETUP or RETURN button.
TV Ty pe
Pan Scan
• When wide-screen video is played, this mode clips the right
and left sides of the image so that it can be viewed on a
conventional screen.
• Some wide-screen DVDs that do not permit Pan Scan
playback are automatically played in Letter Box mode (black
bands at top and bottom of screen).
Letter Box
• When wide-screen video is played in this mode on a
conventional screen, black bands appear at the top and bottom
of the screen.
Wide-screen
• This is the correct mode for playing wide-screen videos on a
wide-screen.
NOTES
• The displayable picture size is preset on the DVD discs.
Therefore the playback picture of some DVDs may not
conform to the picture size you select.
• When you play DVDs recorded in the 4:3 aspect ratio, the
playback picture will always appear in the 4:3 aspect ratio
regardless of the TV shape setting.
Default
It takes 3-5 seconds to reset the unit to the factory default.
button to select LANGUAGE SETUP, then press
or button repeatedly until SYSTEM SETUP appears.
or button to select the option (TV TYPE or
button. Use the or button to
Cut off when a wide-screen
video image is played.
Wide-screen
Pan Scan
Letter Box
E
21
TROUBLESHOOTING GUIDE
SYMPTOM CAUSE (AND REMEDY)
No power.
The remote does not
function.
DVD
No sound or only a very
low-level sound is heard.
No picture.
The picture is not clear.
Severe hum or noise is
heard.
The disc does not play.
TV
Bad Picture (snow,
multipe images,
distortion, blurry)
Black and white picture.
No picture or sound.
Colored patches of
picture.
• Check that the AC adapter and AC power cord are connected.
• The unit is not turned on.
• Remove any obstacles between the remote and the unit.
• Use the remote near the unit.
• Point the remote at the remote sensor on the unit.
• Replace the batteries in the remote with new ones.
• Make sure that you select DVD mode.
• The system is in pause mode. Press the
normal PLAY mode.
• Fast-forward or fast-reverse is performed. Press the
return to normal play mode.
• Make sure that AUDIO / VIDEO output and AV IN input connections are
correct.
• The DTS DVD disc cannot be decoded to have speaker output.
• The unit is too hot, shut off the unit for 30 minutes to cool it down.
• The region number of the disc doesn't match the region number of this
unit.
1 2 3 456
• Clean the disc.
• The disc is scratched.
• The plugs and jacks are dirty. Wipe them with a cloth slightly moistened
with alcohol.
• Clean the disc.
• There is no disc inside ("No Disc" appears on the screen).
• Insert the disc correctly with the playback side facing down.
• Clean the disc.
• A non-valid disc has been inserted. The unit and disc region number are
incompatible.
• Condensation may have formed inside the unit due to a sudden change
in temperature. Wait about an hour for it to clear and try again.
• Check the location of the antenna and adjust it if necessary.
• Make sure the antenna cable is firmly connected.
• Make sure all input cables are firmly connected.
• Check the PICTURE SETTING within the TV SETUP MENU.
• Check to make sure the program you are watching is broadcast in Color
and not Black & White.
• Make sure the unit is plugged in and turned on.
• Make sure that TV mode is selected.
• Try a new channel to check for possible station trouble.
• Make sure the antenna is connected properly.
• Increase the volume.
• Make sure the antenna or audio video source device is working properly.
• Make sure all cables are firmly connected.
• Check for local interference.
• Make sure there are no unshielded electrical devices nearby that are
causing interference.
• Turn the unit off for 30 minutes, then try it again.
PLAY button to return to
PLAY button to
E
22
Unit : INCH
2 3/4
OPEN
VIDEO
OUT
DVD
AUDIO
OUT
3 15/16
14 3/4
7 1/16
8 5/8
5 7/8
41/2
5 11/16
8 5/8
Printed in China
E
811-210991W01 1
23
Loading...
