Personal Video Recorder
PVR1000
Owner’s Manual
128-7114
WARNINGS
CAUTION
Keep product out of direct sunlight. Exposure to direct sunlight or extreme
heat may cause damage or malfunction.
To prevent fire or shock hazard, do not expose to rain or moisture.
CAUTION WHILE DRIVING
Use of headphones while operating an automobile or moving vehicle is not
recommended. Be careful and attentive on the road. Stop operation of the
unit if you find it disruptive or distracting while driving.
IMPORTANT BATTERY INFORMATION
The battery used in this unit may present a risk of fire or chemical burn if
not used as directed. Do not separate, recharge, disassemble, or heat above
100C (212F).
Battery replacement should be performed by qualified technicians.
Do not attempt to open the unit. No user serviceable parts inside.
Keep the unit away from children. Do not disassemble or dispose product
in fire.
Use only the specified chargers which were packaged with the product. Use
of a different charger may present a risk of fire or explosion.
Keep the charger plugged in to the unit for at least 30 minutes before
attempting to operate unit if battery is completely run down and is
insufficient to power up unit.
2 PVR User Guide
Table of Contents
First Time Use >>-------------------------------------------------------------- 4
Identifying the Parts >>------------------------------------------------------ 5
Software Installation >>----------------------------------------------------- 7
Synchronizing Files between PC and PVR >>-------------------------- 8
Converting and Transferring Files >>-------------------------------------- 8
Mass Storage Mode >>------------------------------------------------------ 9
Disconnecting the PVR from your COMPUTER>>------------------ 10
OSD Menu >>------------------------------------------------------------------ 12
A. Photo Player >>---------------------------------------------------------- 13
B. Video Player >>-----------------------------------------------------------16
C. Voice Player >>----------------------------------------------------------- 19
D. MP3 Player >>----------------------------------------------------------- 23
E. AV Recorder >>---------------------------------------------------------- 27
F. Slide Show >>------------------------------------------------------------ 29
G. Calendar >>-------------------------------------------------------------- 30
H. Game >>------------------------------------------------------------------ 33
I. Setup Menu >>------------------------------------------------------------35
Direct Print >>---------------------------------------------------------------- 37
Specifications >>-------------------------------------------------------------
PVR User Guide 3
40
First Time Use
Thank you for purchasing this product. This multi-function portable
Personal Video Recorder (PVR) enables you to:
• Play MPEG-4 videos
• View JPEG images
• Record digital videos
• Record digital audio
• Listen to MP3 files
• Use it as an USB Portable Disk
• Use it as a SD/MMC card reader
• Record TV shows (MPEG 4 compatible ASF file format)
• Print photos directly without attaching to a PC (DPS-ready)
• Use it as an alarm clock
• Convert multiple video file formats into MPEG4 compatible ASF format
4 PVR User Guide
Identifying the Parts
1. Function Scroller
[Play/Pause] : Press the center button of the scroller to start or pause the
playing in Video/Voice/MP3 Player Mode.
Note: The center button of the scroller serves as the OK button on the PVR front panel. You
may press the OK button when you have to press the center button.
[Previous/Next] : Scroll up/down and release the scroller to go to
previous/next item in Photo/Video/Voice/MP3 Player Mode.
[F.Fwd/F.Bwd] : Scroll up/down and hold the scroller to speed up the
playing of advancing/reversing in Video/Voice/MP3 Player Mode.
[Volume Up/Down] : Press the button and then scroll up/down to
adjust the volume during playback in Video/Voice/MP3 Player mode.
2. Hold
Switch to
the PVR.
3. DC IN jack
[Power Supply] :
[Charge] :
/ to lock/unlock the buttons (including the scroller) on
Connect the power adapter to DC IN jack while using PVR.
Connect the power adapter to DC IN jack to charge the battery.
PVR User Guide 5
4. Strap Holder
5. AV IN jack
Connect the AV cable to this AV IN jack while recording TV programs.
6. Earphone jack
7. USB port
8. SD/MMC CARD slot
9. Battery Cover
10. Mode button
Press the Mode button to switch to different modes.
11. Speaker
12. Record/Vol button
13. Microphone
A built-in microphone for voice record.
14. Power button
15. Menu/Stop button
Use this button to call up the menu under each mode.
16. Play/Pause/OK button
6 PVR User Guide
Software Installation
The installation CD bundled with the PVR contains all the necessary
software and useful information (PVR User Guide PDF) you need before
operating PVR. Please follow the instructions below to complete the software installation.
1. Insert the Installation CD into CD-ROM. The
box appears.
2. Select your preferred language and click “
to continue.
Welcome dialog box appears. Click “Next”.
3. A
4. The
Select Components dialog box appears.
Click and select the software you want to
install and then click “Next“.
5. The
Select Program Folder dialog box appears telling you that setup program is about
to add a program icon to your system, you can
change the folder name listed in the text box,
or simply click “Next” to continue.
6. The
Start Copying Files dialog box appears
confirming that the listed software will be
installed. Click “Next” to continue.
7. Follow the on-screen instructions to continue
and complete the installation.
Select Language dialog
OK”
PVR User Guide 7
Synchronizing files between PC and
PVR
Converting and Transferring Files
To synchronize the files between a PC and your PVR, read and follow the
instructions below.
1. Power on the PVR. Connect the PVR to the computer with the USB cable
provided in the package. The following appears. Then the Multimedia
Converter dialog box appears.
2. Press Browse button to select the path where your files reside. The
files will be listed as thumbnails in the Source field.
3. Press Browse button to select the path where you temporary files
will reside before uploading to PVR.
4. Press Convert button. The conversion starts.
Note: The Multimedia Convert program is for Windows98 SE/ME/2000/XP only.
8 PVR User Guide
5. The Convert Progress dialog box appears listing the conversion detail. To
cancel the conversion, press button to stop.
Mass Storage Mode
For IBM-PC Compatible Users
Connect your PVR to a computer and extra disk drive (USB Portable Disk)
will appear. Your PVR is now in Mass Storage Mode. In this mode, you can
copy, move or delete files (pictures) exactly the way you manipulate files in
Windows user interface.
Note: Do not put the files you want to play on the PVR via Mass Storage Mode. For those files
you want to play on the PVR, use only the Multimedia Converter to convert and upload.
For MAC Users
(Mac OS: 9.x and 10.1 above)
By connecting your PVR to a MAC computer (refer to the previous page),
it will automatically detect Mass Storage drive. You can easily manipulate
your files the way you do in MAC user interface.
PVR User Guide 9
Disconnecting the PVR from your
Computer
We strongly recommend you disconnect the PVR from your computer when
it is not in use.
Windows XP
1. Click “Safely Remove Hardware” ( ) icon in the taskbar.
2. Select Safely remove USB Mass Storage
Device from the menu.
Windows 2000/ME
1. Click “Unplug or Eject Hardware” ( ) icon in the taskbar.
2. Select “Stop USB Mass Storage Device”
from the menu (Windows 2000).
Select “Stop USB Disk” from the menu
(Windows ME).
Windows 98SE
1. In My computer, right click on the removable disk corresponding to the player.
2. Select “Eject” from the menu.
Mac OS 9.1 and 10.X above
1. Select the player icon (shown as ‘NO_NAME’or ‘untitled’
drive) on the desktop.
2. Drag and drop the drive to the Trash.
10 PVR User Guide
Note:
• If the PVR is not connected to your PC while opening the Multimedia Con-
verter program, a “no device” dialog box will
appear, simply click to continue.
The program will launch and all the converted
file(s) will be saved and placed in the temporary
folder.
Once the PVR is connected to your PC, the
previously converted files will then automatically be uploaded to the PVR.
• If you don’t want to keep the files on your PC for backup, check the option
lete temporary file(s) after the transfer?”, then the files saved in the temporary
files folder will be deleted after uploading to PVR.
• The Destination window will be disabled if there is no PVR connected.
If the PVR is connected to your PC, you will see 4 folders labeled PHOTO,
VIDEO, AUDIO and MP3 in this window. The folders are automatically built
by the system. All the converted files will be sorted and saved to these folders
according to their type.
• To delete the files in PVR, select the file in the Destination window and then
click .
PVR User Guide 11
“de-
O SD Menu
Apply power to the PVR and a startup screen appears, then the OSD (onscreen display) menu comes up. The OSD menu contains 9 categories. Each
of them provides different functions for users to select. We will introduce
how to use the versatile PVR via OSD menu.
Before operating the PVR, please read the following points:
• All the files (.asf/.jpg/.mp3/.wav) to be played on the PVR must be converted by
Multimedia Converter first.
• The PVR has internal memory, if you want to save the file in the internal
memory, do not insert external memory card. If an external memory card is
inserted in the PVR, only the external memory can be read.
• For better playback speed and viewing quality, all the photos converted by
Multimedia Converter will be resized to 640 x 480 pixels to fit the PVR screen
resolution.
• The PVR calendar can record the date up to the year 2036.
• The timer record and alarm clock setting can be preset within 24 hours.
• Only one song can be set for alarm clock music. If you pick up a song in AU-
DIO menu and pick up another song in MP3 menu, the system will only choose
the most up-to-date one for alarm clock music.
• It’s strongly recommended to turn off the LCD display and plug in the AC
adapter while using the PVR for timer record.
• When you choose to format the data in the built-in memory, do not insert a
memory card in the PVR, otherwise PVR will erase the data in the memory card
instead.
12 PVR User Guide
A. Photo Player
To view photos, you have to enter Photo Player category. In this category
you can review photos, record voice clip, add special effects to photos and
more.
To enter the Photo Player category:
Press OK button or press the center button of the scroller.
• Scroll up/down the scroller to select previous/next photo
• Press OK button to magnify/shrink the selected photo
• Press MENU button to enter the Photo Menu. To exit the menu, press
MENU again
The Photo menu contains the following:
Display
Attach Voice
MULTIPLE / SINGLE photo display
Press OK button to enter Display setting. Scroll up/down
to select the preferred setting and press the center button of the scroller to confirm.
Scroll down and press the center button of the scroller
to enter Attach Voice setting. A
show on the bottom of the screen. Scroll up/down to
select the photo you want to attach voice narration and
press the RECORD button to start recording. A
icon will then show on the top of the screen. To stop
recording, press STOP button.
When the recording completes, a icon will appear
on the photo to which the voice narration has been attached.
message will
PVR User Guide 13
To view the photo with recorded voice, press MENU
button and scroll down to select and then press the
center button. Scroll up/down to select the photo attached with voice narration and press
To return to a normal play without recorded voice, press
MENU button again and scroll down to select and
then press the center button to confirm.
Effects
Information
NEG. ART/SEPIA/B&W/MOSAIC/NORMAL
Scroll down and press the center button of the scroller
to enter Effects setting. Scroll up/down to select your
preferred effect and then press the center button to
confirm. PVR will then apply the effect to the selected
photo. Once the effect has applied, it can’t be cancelled
or restored to the previous mode.
ON/OFF
Scroll down and press the center button of the scroller to
enter Information setting.
Scroll up/down to select either to enable or disable the
information display and then press the center button of
the scroller to confirm.
When the information display is disabled, there won’t be
any indicators or key instructions shown on the screen
(except low-battery indicator ).
14 PVR User Guide
button to play.
Delete One
Delete All
Scroll up/down and press the center button of the
scroller to select a photo you want to delete. Press
MENU button and scroll to “Delete One”. Press the
center button of the scroller to enter Delete One setting.
A message will prompt asking if you want to delete the
photo, press the center button of the function scroller
to delete. Otherwise you may press STOP button to
cancel.
Scroll down and press the center button of the scroller
to enter Delete All setting. A message will prompt asking
if you want to delete all the photos in this folder, press
the center button of the scroller to delete all. Otherwise
press STOP button to cancel.
PVR User Guide 15
B. Video Player
In this category you can play videos.
To enter the Video Player category:
Press the MODE button or scroll down the scroller to select and then
press the center button of the scroller to enter.
• Scroll up/down the scroller to select previous/next video
• Press
button to start playing video
• Press button to stop playing during playback
• Scroll up/down and hold the scroller to speed up the playing of
advancing/reversing during playback. To return to the normal play,
release the scroller.
• Scroll up/down and release the scroller to go to previous/next video clip
during playback.
• Press
button to pause the playing during playback
• Press the button and scroll up/down the scroller to adjust the volume
during playback. Press button again to complete the volume adjustment.
• Press MENU button to enter the Video Menu. To exit the menu, press
MENU button again
The Video menu contains the following:
16 PVR User Guide
Display
Repeat
MULTIPLE / SINGLE video display
Press the center button of the scroller to enter Display
setting. Scroll up/down to select the preferred setting and
press the center button of the scroller to confirm.
Note: Only the first frame will be displayed here.
NORMAL/ ONE/ ALL/ A-B
To repeat one: Scroll up/down and press the center
button of the scroller to select a video you want to repeat
playback. Press MENU button and scroll to “ONE”.
Press the center button of the scroller to start. The se
lected song will then be repeated playing back.
To return to a normal play, select NORMAL in Repeat
setting.
To repeat A-B: Scroll down and press the center but-
ton of the scroller to enter Repeat setting. Scroll to “A-B“
and press the center button of the scroller to confirm.
Press MENU button to exit.
Scroll up/down to select a video you want to review.
Press
be labeled “SET A“ at this time, press the button to set
the start point of the repeat playback. The
be labeled “SET B“, press
of the playback. The video will be repeated playing back
between point A and B. To cancel the playback, press
to stop.
button to start the playback. The
button again to set the end
-
button will
will then
PVR User Guide 17
To repeat all: Scroll down and press the center button
of the scroller to enter Repeat setting. Scroll to “ALL“ and
press the center button of the scroller to confirm. Press
MENU button to exit. Press
playback. The videos will be repeated playing back from
the first one to the last endlessly.
To return to a normal play, select NORMAL in Repeat
setting.
Information
Delete One
ON/OFF
Scroll down and press the center button of the scroller to
enter Information setting.
Scroll up/down to select either to enable or disable the
information display and then press the center button of
the scroller to confirm.
When the information display is disabled, there won’t be
any indicators or key instructions shown on the screen
(except low-battery indicator ).
Scroll up/down and press the center button of the scroller
to select a video you want to delete. Press MENU button
and scroll to “Delete One”. Press the center button of
the scroller to enter Delete One setting. A message will
prompt asking if you want to delete the video, press the
center button of the scroller to delete. Otherwise you may
press STOP button to cancel.
18 PVR User Guide
button to start the
Delete All
Scroll down and press the center button of the scroller to
enter Delete All setting. A message will prompt asking if
you want to delete all the videos in this folder, press the
center button of the scroller to delete all. Otherwise press
STOP to cancel.
C. Voice Player
In this category you can listen to WAV music, choose a song for alarm clock
music, or add sound effects.
To enter the Voice Player category:
Press the MODE button or scroll down the scroller to select and then
press the center button of the scroller to enter.
• Scroll up/down the scroller to select previous/next song
• Press
• Press button to stop playing during playback
• Scroll up/down and hold the scroller to speed up the playing of
advancing/reversing during playback. To return to the normal play,
release the scroller.
• Scroll up/down and release the scroller to go to previous/next audio clip
during playback.
• Press
• Press button to start recording audio clip (.wav file)
• Press button and scroll up/down the scroller to adjust the volume dur-
ing playback. Press button again to complete the volume adjustment.
• Press MENU button to enter the Voice Menu. To exit the menu, press
button to start playing music
button to pause the playing during playback
MENU again
PVR User Guide 19
The Voice menu contains the following:
Quality
Search
Repeat
LOW QUALITY / HIGH QUALITY
Press the center button of the scroller to enter Quality
setting. Scroll up/down to select the preferred setting and
press the center button of the scroller to confirm.
Scroll down and press the center button of the scroller to
select Search.
Press
each of the songs in this folder for 5 seconds.
NORMAL/ ONE/ ALL/ A-B
To repeat one: Scroll up/down and press the center
button of the scroller to select a song you want to repeat.
Press MENU button and scroll to “ONE”. The selected
song will then be repeated.
To return to a normal play, select NORMAL in Repeat
setting.
To repeat all: Scroll down and press the center button of the scroller to enter Repeat setting. Scroll to “ALL“
and press the center button of the scroller to confirm.
Press MENU button to exit. Press
the playback. All the songs will be repeated from the first
one to the last continuo sly.
To return to normal play, select NORMAL in Repeat
setting.
20 PVR User Guide
button, the search starts. The PVR will play
button to start
Alarm Clock
To repeat A-B: Scroll down and press the center but-
ton of the scroller to enter Repeat setting. Scroll to “A-B“
and press the center button of the scroller to confirm.
Press MENU button to exit.
Scroll up/down to select a song you want to listen. Press
button to start the playback. The
labeled “SET A“ at this time, press the button to set the
start point of the repeat playback. The
labeled “SET B“, press
of the playback. The song will be repeated playing back
between point A and B. To cancel the playback, press
to stop.
Scroll up/down and press the center button of the scroller
to select a song. Press MENU button and scroll to
Alarm Clock setting and then press the center button of
the scroller to enter. Again, press the center button of the
scroller to set the time. Scroll up/down to set the HOUR
and then press the center button of the scroller to confirm
and continue. Scroll up/down to set the MINUTE and
then press the center button of the scroller to confirm and
continue. Scroll up/down to set the SECOND and then
press the center button of the scroller to confirm.
Scroll down to SAVE and press the center button of the
scroller to keep the setting.
button again to set the end
button will be
will then be
PVR User Guide 21
BASS/ROCK/JAZZ/CLASSIC/POP/NORMAL
EQ
Delete One
Delete All
Scroll down and press the center button of the scroller
to enter EQ (equalizer) setting. Scroll up/down to select
the preferred setting and press the center button of the
scroller to confirm.
Scroll up/down and press the center button of the scroller
to select a song you want to delete. Press MENU button
and scroll to “Delete One”. Press the center button of
the scroller to enter Delete One setting. A message will
prompt asking if you want to delete the song, press the
center button of the scroller to delete. Otherwise press
STOP button to cancel.
Scroll down and press the center button of the scroller to
enter Delete All setting. A message will prompt asking if
you want to delete all the songs in this folder, press the
center button of the scroller to delete all. Otherwise press
STOP to cancel.
22 PVR User Guide
D. MP3 Player
In this category you can play MP3 music, select choose a song for alarm
clock, add sound effects and more.
To enter the MP3 Player category:
Press the MODE button or scroll down the scroller to select and then
press the center button of the scroller to enter.
• Scroll up/down the scroller to select previous/next song
• Press
• Press button to stop playing during playback
• Scroll up/down and hold the scroller to speed up the playing of
advancing/reversing during playback. To return to the normal play,
release the scroller.
• Scroll up/down and release the scroller to go to previous/next song dur-
ing playback.
• Press
• Press button and scroll up/down the scroller to adjust the volume dur-
ing playback. Press button again to complete the volume adjustment.
• Press MENU button to enter the MP3 Menu. To exit the menu, press
MENU again
The MP3 menu contains the following:
button to start playing music
button to pause the playing during playback
PVR User Guide 23
Press the center button of the scroller to enter Alarm
Alarm Clock
Search
Repeat
Clock setting.
Press the center button of the scroller to set the time.
Scroll up/down to set the HOUR and then press the center button of the scroller to confirm and continue.
Scroll up/down to set the MINUTE and then press the
center button of the scroller to confirm and continue.
Scroll up/down to set the SECOND and then press the
center button of the scroller to confirm.
Scroll down the scroller to “SAVE” and press the center
button of the scroller to keep the setting.
Scroll down and press the center button of the scroller to
select Search.
Press
each of the songs in this folder for 5 seconds.
NORMAL/ ONE/ ALL/ A-B
To repeat one: Scroll up/down and press the center
button of the scroller to select a song you want to repeat
listening. Press MENU button and scroll to “ONE”. The
selected song will then be repeated playing back.
To return to a normal play, select NORMAL in Repeat
setting.
24 PVR User Guide
button, the search starts. The PVR will play
EQ
To repeat all: Scroll down and press the center but-
ton of the scroller to enter Repeat setting. Scroll to “ALL“
and press the center button of the scroller to confirm.
Press MENU button to exit. Press
the playback. All the songs will be repeated playing back
from the first one to the last endlessly.
To return to a normal play, select NORMAL in Repeat
setting.
To repeat A-B: Scroll down and press the center but-
ton of the scroller to enter Repeat setting. Scroll to “A-B“
and press the center button of the scroller to confirm.
Press MENU button to exit.
Scroll up/down to select a song you want to listen. Press
button to start the playback. The
labeled “SET A“ at this time, press the button to set the
start point of the repeat playback. The
labeled “SET B“, press
of the playback. The song will be repeated playing back
between point A and B. To cancel the playback, press
to stop.
BASS/ROCK/JAZZ/CLASSIC/POP/NORMAL
Scroll down and press the center button of the scroller
to enter EQ (equalizer) setting. Scroll up/down to select
the preferred setting and press the center button of the
scroller to confirm.
button again to set the end
button to start
button will be
will then be
PVR User Guide 25
Scroll up/down and press the center button of the scroller
Delete One
Delete All
to select a song you want to delete. Press MENU button and scroll to “Delete One”. Press the center of the
scroller or press OK button to enter Delete One setting.
A message will prompt asking if you want to delete the
song, press the center button of the scroller to delete or
press STOP button to cancel.
Scroll down and press the center button of the scroller to
enter Delete All setting. A message will prompt asking if
you want to delete all the songs in this folder, press the
center button of the scroller to delete all. Otherwise press
STOP to cancel.
26 PVR User Guide
E. AV Recorder
In this category you can record your favorite TV show directly with PVR or
set the timer to schedule a record time.
To enter the AV Recorder category:
Press the MODE button or scroll down the scroller to select and then
press the center button of the scroller to enter.
• Press button to start recording
• Press button to stop recording during playback
• Press MENU button to enter the AV Recorder Menu. To exit the menu,
press MENU again
The AV Recorder menu contains the following:
Timer
Record
TIME / LENGTH
Press the center button of the scroller to enter Alarm
Clock setting.
Press the center button of the scroller to set the time.
Scroll up/down to set the HOUR and then press the center button of the scroller to confirm and continue. Scroll
up/down to set the MINUTE and then press the center
button of the scroller to confirm and continue. Scroll
up/down to set the SECOND and then press the center
button of the scroller to confirm.
Scroll down the scroller to “SAVE” and press the center
button of the scroller to keep the setting.
PVR User Guide 27
LOW QUALITY / HIGH QUALITY
Quality
Information
LCD Off
Scroll down and press the center button of the scroller to
enter Quality setting.
Scroll up/down to select the preferred setting and press
the center button of the scroller to confirm.
ON/OFF
Scroll down and press the center button of the scroller to
enter Information setting.
Scroll up/down to select either to enable or disable the
information display and then press the center button of
the scroller to confirm.
When the information display is disabled, no indicators or
key instructions will be shown on the screen (except lowbattery indicator ).
It’s recommended to turn the LCD display off to conserve
power during the timed recording. While the PVR is waiting for timed recording, the blue LED will keep blinking
reminding you that the timed record has been activated.
To turn the LCD off
button of the scroller to enter LCD setting. A message will
prompt you asking if you want to turn off the LCD display.
Press the center button of the scroller to confirm. Otherwise press STOP button to cancel.
28 PVR User Guide
, scroll down and press the center
F. Slide Show
In this category you can view photos as a slide show.
To enter the Slide Show mode:
Press the MODE button or scroll down the function scroller to select
and then press the center of the function scroller or press OK button to
enter.
• Scroll up/down the function scroller to select a photo as the beginning of
the slide show
• Press
• Press button to stop the slide show during playback
• Press MENU button to enter the Slide Show Menu. To exit the menu,
press MENU again
The Slide Show menu contains the following:
Interval
button to start the slide show
Press the center button of the scroller to enter Interval
setting.
The default timing between slides is set to 5 seconds. To
change the setting, press the center button of the scroller
and then scroller up/down to increase/decrease the time.
When the setting is done, press again the center button
to confirm.
To keep the new setting, scroll down the scroller to SAVE
and press the center button of the scroller.
PVR User Guide 29
Information
ON/OFF
Scroll down and press the center button of the scroller to
enter Information setting.
Scroll up/down to select either to enable or disable the
information display and then press the center button of
the scroller to confirm.
When the information display is disabled, there won’t be
any indicators or key instructions shown on the screen
(except low-battery indicator ).
G. Calendar
This PVR can serve as an electronic calendar.
To enter the Calendar category:
Press the MODE button or scroll down the scroller to select and then
press the center button of the scroller to enter. The calendar will display. To
switch to clock view, press MENU button.
The Calendar menu contains the following:
Press the center button of the scroller to enter Calendar/
Calendar/
Clock
Clock setting.
Scroll up/down to select either to display calendar or
clock and then press the center button of the scroller to
confirm.
30 PVR User Guide
Date/Time
DATE
Scroll down and press the center button of the scroller to
enter Date/Time setting.
To change the date setting, press the center of the
scroller or press OK button again.
Step 1. Scroll up/down to change the YEAR and then
press the center button of the scroller to confirm and
continue.
Step 2. Scroll up/down to change the MONTH and then
press the center button of the scroller to confirm and
continue.
Step 3. Scroll up/down to change the DAY and then
press the center button of the scroller to confirm.
To record the change you’ve made, scroll down to SAVE
and press the center button of the scroller to keep the
setting.
PVR User Guide 31
TIME
Scroll down and press the center of the scroller to enter
Date/Time setting.
To change the time setting, scroll down to TIME adjustment item, and then press the center button of the
scroller.
Step 1. Scroll up/down to change the HOUR and then
press the center of the scroller or press OK button to
confirm and continue.
Step 2. Scroll up/down to change the MINUTE and then
press the center of the scroller or press OK button to
confirm and continue.
Step 3. Scroll up/down to change the SECOND and then
press the center of the scroller or press OK button to
confirm.
To record the change you’ve made, scroll down to SAVE
and press the center button of the scroller to keep the
setting.
To exit the menu, press MENU button.
32 PVR User Guide
H. Game
There are two 2 games available on the PVR: Puzzle and Tic-Tac-Toe.
To enter the Game category:
Press the MODE button or scroll down the scroller to select and then
press the center button of the scroller to enter.
The screen on the left appears:
Press the center button of the scroller to enter TIC-TACTOE game or scroll down to select PUZZLE game.
TIC-TAC-TOE
• Scroll up/down and then press the center of the scroller or press OK
button to choose if you want to start the game first or let
the PVR go first
• The first player is “ ”. The other one is “ “
• Press the center of the function scroller or press OK
button to start
• Select the square you want to place your symbol (“ ” or “ “) in by
scrolling up/down and then press the center of the function scroller or
press OK to confirm
• The first player to complete a row of three squares is the winner
• You can’t occupy a square that is already occupied
• To stop the game during playing, press button anytime
PVR User Guide 33
PUZZLE
• Scroll up/down to select a numbered square you want to move with the
floating frame and then press the center of the function scroller or press
OK button to confirm
• Players have to arrange all the numbered square in
sequence within 50 seconds
• Only the squares next to the empty frame can be moved
• To stop the game during playing, press button any-
time
34 PVR User Guide
I. Setup Menu
In the Setup Menu you can change the factory default setting to fit your
needs and format the data stored in the external memory card/internal
memory.
To enter the Setup Menu:
Press the MODE button or scroll down the scroller to select and then
press the center button of the scroller to enter.
The Setup Menu appears. Scroll up/down and press the center button of the
scroller to enter each item.
The Setup Menu contains the following:
STARTUP SOUND OFF/ON
STARTUP SCRN
AUTO LCD OFF
Scroll up/down to turn off/on the startup sound
and then press the center button of the scroller
to confirm.
OFF/IMAGE
Scroll up/down to disable/enable startup
screen and then press the center button of the
scroller to confirm.
30 Sec/1 Min/1.5 Min/2 Min/NEVER
Scroll up/down to set up the timing you want to
turn off the LCD display and press the center
button of the scroller to confirm.
PVR User Guide 35
AUTO POWER OFF
BEEP
FORMAT
36 PVR User Guide
1.5 Min/3 Min/5Min/NEVER
Scroll up/down to set up the timing you want to
power off the PVR when it is not in use.
Press the center button of the scroller to
confirm.
ON/OFF
Scroll up/down to turn on/off the beep and
press the center button of the scroller to
confirm.
When you choose the format option, a message will prompt asking if you want to format
or not, press the center button of the scroller
to confirm. Otherwise press
cancel.
STOP button to
Direct Print provides a direct connect solution for the PVR to communi-
Direct Print
cate with the printers. If you connect PVR to a printer which supports DPS
(Direct Print Services), then the photos stored in the PVR can be printed
directly without needing a PC. It’s that easy!
Follow the steps below to print your photos:
Step 1. Connecting to a printer
Power on the PVR. Connect one end of the included USB
cable to the USB port of the PVR, the other end to the USB
port of your printer.
Step 2. Selecting DIRECT PRINT
Upon connecting the PVR to your printer, a mode selection
screen appears. Press the MODE button to enter DIRECT
PRINT.
Step 3. Selecting Photos
A message appears reminding you not to connect to PC.
Press the OK button to continue. The DPS menu appears.
Press the OK button to enter SELECT PIC menu.
PVR User Guide 37
Selecting Particular Photos
Press the OK button twice and scroll up/down to pick up
the photos and then press the OK button to confirm. A
printer icon will appear on the photos being selected. When
the selection is done, press the button
to return.
Select All Photos
Press the OK button and scroll down to ALL and then
press the center button of the scroll to confirm. All the photos will then be
selected.
Step 4. Enhancing Photo Quality
Scroll down to OPTIMAL. The default is set to “OFF”. To
change the setting, press the center button of the scroller
and scroll down to select “ON“. Press again the center button to confirm.
Note: If you don’t want to change the setting, you may skip
this step or select CANCEL in its menu.
Step 5. Setting the Number of Copies
Scroll down to COPIES. The default setting is set to “1“. To
change the setting, press the center button of the scroller
and scroll up to increase the number of copies.
38 PVR User Guide
Step 6-1. Setting Paper Size
Scroll down to PAPER SET. You can
change the paper size, paper type, and
border settings. To change the paper size
setting, press the center button and scroll
up/down the scroller to the preferred size.
Press again the center button to confirm.
Step 6-2. Setting Paper Type
Scroll down to PAPER. To change the paper type, press the
center button and scroll up/down the scroller to the pre-
ferred paper. Press again the center button to confirm.
Step 6.3. Setting Borders
Scroll down to BORDER. To change the border setting,
press the center button and scroll up/down the scroller to
either add the border, cancel the border or keep the photo
in its original. Press again the center button to confirm.
If you are satisfied with the PAPER SET. settings, press
to DPS menu.
Step 7. Printing
Scroll down to PRINT. Press the OK button to start printing. To cancel the print, press button anytime.
PVR User Guide 39
button to return
Specifications
Product Function Digital Photo Player, Digital Video Player, Digital
Display 2.5” TFT LCD
Microphone Built-in
Speaker Built-in
TV System NTSC/PAL
DPS Support Yes, supports Direct Printer Services
Audio Effects POP/Jazz/Classic/Bass/Rock
Interface USB/AV In/Earphone/DC-in
Memory Card Slot SD/MMC
Internal Memory Built-in 32MB (Preformat Space)
File Format ASF(video)/JPEG(photo)/MP3/WAV(audio)
Power Rechargeable Li-ion Battery x1 ; Power Adapter
Mass Storage Windows 98SE/2000/Me/XP ; Mac OS 9.X and
Dimensions 96 (L) x 77 (W) x 20 (H) mm, 3.7 (L) x 3.0 (W) x
Weight 110g (without battery), .25
Video Recorder, Digital Voice Player, Digital Voice
Recorder, MP3 Player, USB Portable Disk, SD/
MMC Card Reader, Calendar, Clock and Games
10.1 above
.78 (H) inches
lbs (without battery)
40 PVR User Guide
90 DAY LIMITED WARRANTY
APPLIES TO AUDIOVOX INTERNET PRODUCTS
AUDIOVOX ELECTRONICS CORPORATION (the Company) warrants to
the original retail purchaser of this product that should this product or any part
thereof, under normal use and conditions, be proven defective in material or
workmanship within 90 days from the date of original purchase, such defect(s)
will be repaired or replaced with reconditioned product (at the Company’s op
tion) without charge for parts and repair labor.
To obtain repair or replacement within the terms of this Warranty, the product is
to be delivered with proof of warranty coverage (e.g. dated bill of sale), specification of defect(s), transportation prepaid, to an approved warranty station. For
the location of the nearest warranty station to you, call toll-free to our control
office: 1-800-290-6650
This Warranty does not extend to the elimination of externally generated static
or noise, to correction of antenna problems, to costs incurred for installation,
removal or reinstallation of the product, or damage to tapes, discs, speakers, accessories, or electrical systems.
This Warranty does not apply to any product or part thereof which, in the opinion
of the Company, has suffered or been damaged through alteration, improper
installation, mishandling, misuse, neglect, accident, or by removal or defacement of the factory serial number/bar code label(s). THE EXTENT OF THE
COMPANY’S LIABILITY UNDER THIS WARRANTY IS LIMITED TO THE
REPAIR OR REPLACEMENT PROVIDED ABOVE AND, IN NO EVENT,
SHALL THE COMPANY’S LIABILITY EXCEED THE PURCHASE PRICE
PAID BY PURCHASER FOR THE PRODUCT.
PVR User Guide 41
-
WARRANTY CONTINUED
This Warranty is in lieu of all other express warranties or liabilities. ANY
IMPLIED WARRANTIES, INCLUDING ANY IMPLIED WARRANTY OF
MERCHANTABILITY, SHALL BE LIMITED TO THE DURATION OF THIS
WRITTEN WARRANTY. ANY ACTION FOR BREACH OF ANY WARRANTY
HEREUNDER INCLUDING ANY IMPLIED WARRANTY OF MERCHANTABILITY MUST BE BROUGHT WITHIN A PERIOD OF 30 MONTHS FROM
DATE OF ORIGINAL PURCHASE. IN NO CASE SHALL THE COMPANY BE
LIABLE FOR ANY CONSEQUENTIAL OR INCIDENTAL DAMAGES FOR
BREACH OF THIS OR ANY OTHER WARRANTY, EXPRESS OR IMPLIED,
WHATSOEVER. No person or representative is authorized to assume for the
Company any liability other than expressed herein in connection with the sale of
this product.
Some states do not allow limitations on how long an implied warranty lasts or the
exclusion or limitation of incidental or consequential damage so the above limitations or exclusions may not apply to you. This Warranty gives you specific legal
rights and you may also have other rights which vary from state to state.
U.S.A. : AUDIOVOX ELECTRONICS CORPORATION, 150 MARCUS BLVD.,
HAUPPAUGE, NEW YORK 11788
CANADA : AUDIOVOX CANADA LTD., MISSASSAUGA, ONTARIO,
CANADA L4W5A1
128-6001
42 PVR User Guide
Loading...
