Audiovox CDM8940VW User Manual

AUDIOVOX
AUDIOVOX
CDM8940
CDM8940
Digital CDMA2000 1X EV-DO Handheld Portable Telephone
Welcome to the world of EVDO! Developed by top engineers and equipped with Qualcomm MSM6500, CDM8940 supports full EVDO. With CDM8940, you now have the highest speed and the largest bandwidth that supports the most up-to-date data applications and services. Moreover, its intuitive and user friendly GUI brings compli­cated applications such as web browsing, data services, right at your fingertips. Among its many advanced features, the T9 input mode makes it much easier to enter letters. In addition, the VR (Voice Recognition) makes it more user friendly, with proven technologies including:
Full graphic display of 9 text input lines and 1 icon line with variable font size. Easy to dial through the VR feature. Easy to enter letters through the T9 text input mode. Enhanced for web browsing & data services (i.e.; wireless internet Downloads, WAP browser) GUI & Animation display compliant with CDMA2000 1X. Full graphic main display - 260K color TFT LCD. Mobile Camera (SXGA 1.3 Mega Pixel) Navigation Key and 22 keys aligned for more convenience. Sophisticated features of speaker phone, and voice recognition. Additional services including text messaging, Web browsing on top of authentication, call forwarding, call transfer, call waiting.
Important Information
This CDM8940 user guide contains very important information about how to properly use the phone. So please read this manual thor­oughly, pay attention to the warranty on the back page and be alert to the exclusions and limitations of your warranty, which are related to the unauthorized use of components.
Preface
ABLE OF CONTENTS
TTABLE OF CONTENTS
CHAPTER 1 BEFORE USING YOUR PHONE .........7
Inside the Package .................................................8
Handset Description ..............................................9
Function Keys.......................................................10
Display Indicators.................................................11
Using the Battery..................................................13
Installing the Battery ...........................................13
Removing the Battery .........................................13
Charging the Battery............................................14
Power Connection...............................................14
Battery Standby Times........................................15
Battery Usage Times...........................................15
Battery Information ..............................................16
Do’s .....................................................................16
Don’ts ..................................................................16
CHAPTER 2 BASIC OPERATION ...........................17
Using the Phone ...................................................18
Turning the Phone On.........................................18
Turning the Phone Off.........................................18
Using the Main Menu ...........................................19
Accessing the Menu............................................19
Menu Summary.....................................................20
Basic Functions....................................................23
Making a Call ......................................................23
Pause Feature.....................................................24
Speaker Phone ...................................................24
Answering a Call .................................................25
3-Way Call Function............................................25
Call Waiting Function ..........................................26
Adjusting Volume.................................................26
Lock.....................................................................27
Caller ID Function ...............................................27
Music Player........................................................27
Functions During a Call .........................................28
Messaging...........................................................28
Mute (Unmute) ....................................................28
Table of Contents - Page 1
ABLE OF CONTENTS
TTABLE OF CONTENTS
ABLE OF CONTENTS
TTABLE OF CONTENTS
Scratchpad ..........................................................28
Send My Phone # ...............................................29
My Phone #.........................................................29
Voice Privacy.......................................................29
Location...............................................................30
Phone Info...........................................................30
Making an Emergency Call....................................31
911 in Lock Mode................................................31
911 Using Any Available System ........................31
Using the mini SD Card .........................................32
Installing the mini SD Card .................................32
Removing the mini SD Card ...............................32
CHAPTER 3 MEMORY FUNCTION .......................35
Storing Phone Numbers ......................................36
Text Input Methods ..............................................37
Entering Characters............................................37
Alpha Mode [ABC] ..............................................37
TM
T9
Predictive Text Mode [T9TMABC] .................38
Numeric Mode [NUM] .........................................40
Symbol Mode [SYM] ...........................................40
Speed Dialing .......................................................41
Speed Dial ..........................................................41
One-Touch/Two-Touch Dialing ............................41
Phone Book ..........................................................42
Find.....................................................................42
Add New .............................................................43
Group..................................................................44
Msg. Group .........................................................45
My Phone #.........................................................48
Recent Calls .........................................................49
All Calls ...............................................................49
Missed Calls .......................................................50
Received Calls....................................................51
Dialed Calls.........................................................52
Call Timers..........................................................53
1X Packet Counter..............................................56
CHAPTER 4 SETTINGS ..........................................57
Settings .................................................................58
Sounds................................................................58
Display ................................................................63
Data SVC............................................................67
Security ...............................................................68
Others .................................................................75
System ................................................................80
Phone Info ..........................................................82
Media Gallery........................................................83
Pix .......................................................................83
Flix ......................................................................83
Music...................................................................84
Tones ..................................................................85
Images ................................................................85
CHAPTER 5 SUPPLEMENTARY FUNCTIONS......87
Voice Tools............................................................88
Voice Dialing.......................................................88
Voice Memo........................................................89
Voice Dial............................................................90
Train Words.........................................................91
Voice Setting.......................................................93
Schedule ...............................................................94
Add New Plan .....................................................94
View Plan List .....................................................95
Alarm .....................................................................96
Memo Pad.............................................................98
Calculator............................................................100
World Clock ........................................................101
Stop Watch .........................................................102
Camera (Use Camera) .......................................103
Getting Ready...................................................103
Taking a Picture From the Menu.......................104
Taking a Picture In Idle Mode ...........................105
Page 2 - Table of Contents Table of Contents - Page 3
ABLE OF CONTENTS
TTABLE OF CONTENTS
ABLE OF CONTENTS
TTABLE OF CONTENTS
Camera (Take Flix)..............................................107
Camera (Pix Gallery) ..........................................109
Camera (Flix Gallery)..........................................110
Camera (Help).....................................................111
CHAPTER 6 VOICE MAIL AND TXT, PIX, FLIX
MESSAGES ......................................113
When a New Message Arrives..........................114
TXT, Pix, Flix Message .....................................114
Voice Mail..........................................................114
New MSG ............................................................115
New TXT Msg ...................................................115
New Pix Msg .....................................................117
New Flix Msg ....................................................119
Inbox....................................................................121
Sent .....................................................................124
Web Alerts...........................................................126
Draft.....................................................................127
Quick Text ...........................................................128
Erase All ..............................................................129
Erase Messages ...............................................129
Settings ...............................................................130
Auto Save .........................................................130
Auto Erase ........................................................130
Auto Receive.....................................................131
Default CB# ......................................................131
Voice CB#.........................................................131
Remind..............................................................132
Signature...........................................................132
Direct View........................................................133
Entry Mode .......................................................133
Block or Unblock...............................................134
CHAPTER 7 GET IT NOW & INTERNET..............135
Get It Now...........................................................136
Starting Get It Now ...........................................136
Downloading Applications.................................136
Downloading Melodies/Wallpapers...................137
Applying Melodies/Wallpapers..........................137
Checking Data Folder Memory.........................137
Erasing an Application......................................138
Video Clips........................................................139
Starting Internet Browser..................................142
Launching Mobile Web 2.0 ...............................142
Browser Menu ....................................................142
Browser Menu...................................................142
CHAPTER 8 SAFETY INFORMATION...................145
Safety Information for Wireless Handheld Phones
Exposure to Radio Frequency Signals .............146
Antenna Care....................................................147
Phone Operation...............................................147
Driving Safety ...................................................147
Electronic Devices ............................................148
Other Safety Guidelines....................................150
Precautions and Warnings................................151
Operating Procedures.......................................152
Safety Information for FCC RF Exposure........153
Caution..............................................................153
SAR Information .................................................154
FDA Consumer Update......................................156
CHAPTER 9 WARRANTY .....................................165
Protect Your Warranty .......................................166
12 Month Limited Warranty...............................167
.146
Page 4 - Table of Contents
“Licensed by QUALCOMM Incorporated under one or more of the following Patents : U.S.Patent No. 4,901,307 U.S.Patent No. 5,056,109 U.S.Patent No. 5,099,204 U.S. Patent No. 5,101,501 U.S. Patent No. 5,103,459 U.S. Patent No. 5,107,225 U.S.Patent No. 5,109,390.”
Table of Contents - Page 5
Chapter 1
BEFORE USING
YOUR PHONE
Please read and fully understand this manual before using your phone.
This chapter addresses your phone, its keys and display icons, and covers the charging and proper use of the battery.
Inside the Package Handset Description Function Keys Display Indicators Using the Battery Charging the Battery Battery Information
Page 6
Chapter 1 - Page 7
INSIDE THE P
INSIDE THE P
ACKAGE
ACKAGE
HANDSET DESCRIPTION
HANDSET DESCRIPTION
This package should include all items pictured below. If any are missing or different, immediately contact the retailer where you purchased the phone.
Standard Battery
Handset
User Manual
Travel Charger
Hand strap
Stereo Headset
mini SD Card (Optional)
The CDM8940 weighs 3.89 oz. and the dimensions are
1.82” x 3.56” x 0.92”.
Antenna
Camera Lens
Music Play/Pause Key
(Camera long key to music stop)
Function
Send Key
Key Pad
Keys
Camera Lens Key
Earjack
Volume Key
Camera Key
Earpiece
LCD Display
Volume Key
Adjusts the earpiece and ringer volume.
END/ Power Key
Camera Key
NOTE: Immediately report any product defects or
missing items to the place of purchase.
Page 8 - Chapter 1
Microphone
Chapter 1 - Page 9
FUNCTION KEYS
FUNCTION KEYS
DISPLA
DISPLA
Y INDICA
Y INDICA
TORS
TORS
SEND KEY: Press to make or receive a call. Press and hold to turn on Voice Recognition mode.
END KEY: Press to turn the phone on, to terminate a call or to return to the initial page. Press and hold to turn off the phone.
NAVIGATION KEY: In Idle Mode - Press up to access the
Short Cut Key, down to access the Messaging Menu, right to access Get It Now and left to access Mobile Web.
Inside the menu - Within a menu, use to
scroll through menu options. To select an option, press .
SOFT KEY: (Left Key) Press to access the main menu or function displayed on the bottom line. (Right Key) Press to access your contacts. Press to access the function displayed on the bottom line.
LOCK KEY: Press and hold to enter lock mode.
INTERNATIONAL CALL: Press and hold until “+” is displayed. “+” sign in front of phone number is required for making international calls.
CLR KEY: Press to clear a digit from the display, to return to the previous page, or to enable speaker phone mode.
Signal Strength
Current signal strength - the more lines, the stronger the signal.
Roaming
Phone is out of home area.
Service Indicator
Indicates call is in progress, indicates the phone cannot receive a signal from the system.
Message
Text, Voice, Urgent, Web Alerts messages.
Digital Mode
Phone is in the digital service area.
Battery
Battery charging level - the more blocks, the stronger the charge.
Mute
Phone is mute during a call.
Ringer Mode
Appears when the ringer is set as a ringer mode.
Emergency Call
Blinks when an emergency call is in progress.
ScratchPad
Displays when the scratchpad is in use during a call.
Auto Answer
Phone is in answering machine mode.
Page 10 - Chapter 1
Chapter 1 - Page 11
DISPLA
DISPLA
Y INDICA
Y INDICA
TORS
TORS
USING THE BA
USING THE BA
TTERYY
TTER
Alarm to Schedule
Appears when either an plan or an alarm is set.
Dormant
Indicates the phone is in disconnection condition while on “Server Connection”.
Speaker Phone
Phone is in speaker phone mode.
Data Only
Receives an async. call as a voice call.
GPS Icon
Indicates the Location Service of your phone is disabled/enabled.
1X
Phone is in the 1x service area.
Network
Phone is in the progress of “UP Browser”.
TTY
TTY mode is active.
Voice Privacy
“Voice Privacy” mode.
Phone Lock
Phone is locked.
INSTALLING THE BATTERY
1. 1 Place the battery on the back of the handset and slide into place. 2 Push the battery down until it locks into place. 3 Battery lock latch automatically locks into place.
NOTE: Make sure the battery is securely placed to avoid
slipping off during a call.
REMOVING THE BATTERY
1. 1 Slide the latch over to the right, lift up the battery and 2 remove the battery from the handset.
Ear Jack
A headset is connected.
Secure
Phone is in “Secure” mode.
EVDO
Phone is in “EVDO” mode.
Page 12 - Chapter 1
NOTE: If the battery is not correctly placed in the battery
compartment, the handset will not turn on and/or the battery may detach during use.
Chapter 1 - Page 13
CHARGING THE BA
CHARGING THE BA
TTERYY
TTER
CHARGING THE BA
CHARGING THE BA
TTERYY
TTER
POWER CONNECTION
1. Plug the AC charger into a standard outlet.
Charging is in progress
NOTE: 1. The times in the following tables are for a new
battery. Usage and Standby times may decrease over time.
2. Fully charge the battery before using – it is not charged when purchased.
3. It is more efficient to charge the battery with the phone turned off.
Charging is
completed
BATTERY STANDBY TIMES
The operating time is subject to your handset usage and configuration.
CDMA
STD 1000 mAh
EXT 1350 mAh
Up to 270 hours
Up to 360 hours
BATTERY USAGE TIMES
The operating time is subject to your handset usage and configuration.
DCS
STD 1000 mAh
EXT 1350 mAh
NOTE: These times are for a new battery.
Usage and standby time may decrease over time.
Up to 220
minutes
Up to 290
minutes
PCS
Up to 210
minutes
Up to 280
minutes
Page 14 - Chapter 1
Chapter 1 - Page 15
BA
BA
TTER
TTER
Y INFORMA
Y INFORMA
TION
TION
Do’s
l Only use the battery and charger approved by the
manufacturer.
l Only use the battery for its original purpose. l Try to keep batteries in a temperature between
O
F (5OC ) and 95OF (35OC).
41
l If the battery is stored in temperatures above or
below the recommended range, give it time to warm up or cool down before using.
l Completely drain the battery before recharging.
It may take one to four days to completely drain.
l Store the discharged battery in a cool, dark, and
dry place.
l Purchase a new battery when its operating time
gradually decreases after fully charging.
l Properly dispose of the battery according to local
laws.
Chapter 2
BASIC OPERATION
This chapter addresses the phone’s basic functions including menus, volume levels, and call features.
Don’ts
l Don’t attempt to disassemble the battery – it is a
sealed unit with no serviceable parts.
l Don’t accidentally short circuit the battery by carrying
it in your pocket or purse with other metallic objects such as coins, clips and pens. This may critically damage the battery.
l Don’t leave the battery in hot or cold temps.
Otherwise, it could significantly reduce the capacity and lifetime of the battery.
l Don’t dispose of the battery into a fire.
Page 16 - Chapter 1
Using the Phone Using the Main Menu Menu Summary Basic Functions Functions During a Call Making an Emergency Call Using the mini SD Card
Chapter 2 - Page 17
USING THE PHONE
USING THE PHONE
USING THE MAIN MENU
USING THE MAIN MENU
TURNING THE PHONE ON
1. Press and hold until your “Power On” logo appears and the melody begins to play.
If “Password” appears on the display, enter your 4-digit password to unlock your phone.
The default password is the last 4 digits of your phone number.
TURNING THE PHONE OFF
1. Press and hold until “Power Off” animation appears.
NOTE: 1. Immediately change or recharge the battery
when “Low Battery Warning Power Off” appears on the display. Memory may possibly be damaged if the phone turns off due to the battery completely draining.
2. Turn the phone off before removing or replacing the battery. If the phone is on, unsaved data may be lost.
ACCESSING THE MENU
Your phone can be customized via the menu. Each function can be accessed by scrolling with the Navigation Key or by pressing the number that
corresponds with the menu item.
1. To access the menu from the idle screen, press [MENU].
2. To scroll through the menu, press the Navigation Key up and down.
3. To return to the previous page, press . To exit the current menu and return to the idle mode, press .
4. To enter a function when its main page is displayed, press [OK].
Hotkey
In idle mode, move the Navigation Key as follows to access these functions:
• Upward movement: Short Cut Key
• Downward movement: Messaging
• Rightward movement: Get It Now
• Leftward movement: Mobile Web
If you are in a second-level menu, you may also navigate to the next or previous second-level menu by pressing the Navigation Key right or left.
Page 18 - Chapter 2
Chapter 2 - Page 19
MENU SUMMARYY
MENU SUMMAR
MENU SUMMARYY
MENU SUMMAR
PHONE BOOK
RECENT CALLS
MESSAGING
Page 20 - Chapter 2
1 : Find
u
2 : Add New 3 : Group 4 : Speed Dial 5 : Msg. Group 6 : My Phone #
1 : All Calls
u
2 : Missed Calls 3 : Received Calls 4 : Dialed Calls 5 : Call Timers
6 : 1x Packet Counter
1 : New Msg
u
2 : Voice Mail 3 : Inbox 4 : Sent 5 : Web Alerts 6 : Draft 7 : Quick Text 8 : Erase All
9 : Settings
1 : Last Call 2 : All Calls 3 : Home Calls 4 : Roam Calls 5 : Cumulative Calls 1 : Received 2 : Transmitted 3 : Total
1 : New Text Msg 2 : New Pix Msg 3 : New Flix Msg
1 : All Folder 2 : Inbox 3 : Sent 4 : Draft 5 : Web Alerts 1 : Auto Save 2 : Auto Erase 3 : Auto Receive 4 : Default CB# 5 : Voice CB# 6 : Remind 7 : Signature 8 : Direct View 9 : Entry Mode 10 : Block or Unblock
GET IT NOW
MOBILE WEB
MEDIA GALLERY
SETTINGS
1 : Get It Now
u
1 : Connect Web
u
1 : Pix
u
2 : Flix 3 : Music 4 : Tones 5 : Images
1 : Sounds
u
2 : Display
3 : Data Svc. 4 : Security
5 : Others
Get It Now Settings Help
1 : Ringer Type 2 : Volume 3 : Alerts 4 : Roam Ringer 5 : Tone Length 6 : Power On/Off 1 : Menu Style 2 : Graphics 3 : Sub Screen 4 : Greeting Message 5 : Backlight 1 : Connection 1 : Phone Lock 2 : Restrict 3 : Change Code 4 : Special #’s 5 : Erase All 6 : Reset Phone 7 : SD Card 1 : Answer Options 2 : Auto Retry 3 : Language 4 : Voice Privacy 5 : TTY Mode 6 : Location 7 : Lantern 8 : Short Cut Key
Chapter 2 - Page 21
MENU SUMMARYY
MENU SUMMAR
BASIC FUNCTIONS
BASIC FUNCTIONS
UTILITIES
CAMERA
6 : System
7 : Phone Info
1 : Voice Tools
u
2 : Schedule
3 : Alarm
4 : Memo Pad 5 : Calculator 6 : World Clock 7 : Stop Watch
1 : Take Pix
u
2 : Take Flix 3 : Pix Gallery 4 : Flix Gallery 5 : Help
1 : Set Mode 2 : Nam Setting 3 : PRL ID 4 : ERI Banner 1 : S/W Version 2 : H/W Version 3 : Get It Now Version
1:Voice Memo 2 : Voice Dial 3 : Train Words 4 : Voice Setting 1 : Add New Plan 2 : View Plan List 1 : Alarm 1 2 : Alarm 2 3 : Alarm 3
MAKING A CALL
1. Enter a phone number.
To modify the phone number you have entered:
• To erase one digit at a time, press .
• To erase the entire number, press and hold .
2. Press . The indicator, , appears on the display.
If “CALL FAILED” appears on the display or the line is busy, press or .
If you activate the “AUTO RETRY” function, the phone will automatically retry for the number of times you have selected. (Refer to page 76)
If the number you’re calling is stored in the phone book, the name and number will appear when the call is placed.
There is another way to make a call through the VR mode, which is called “VAD (Voice Activated Dialing)”. Please refer to page 90 (Voice Service) for details on making calls using VAD.
3. To end a call, press .
NOTE: Please refer to page 36 for more details about
storing a phone number.
Page 22 - Chapter 2
Chapter 2 - Page 23
BASIC FUNCTIONS
BASIC FUNCTIONS
BASIC FUNCTIONS
BASIC FUNCTIONS
PAUSE FEATURE
You can dial or save a phone number with pauses for use in the automated systems where you need to enter a credit card number, a social security number, or other numbers. This feature will be convenient when you are linked to an ARS (Advanced Record System).
1. To insert a pause, enter a phone number then press [MENU]. Select either a Hard Pause (“P” appears)
or a Timed Pause (“T” appears).
2. Press to dial the number and to store the
number.
Hard Pause: When connected to the ARS, it will not progress to the next number until you press or .
Time Pause: When connected to the ARS, it automatically progresses to the next number after three seconds.
SPEAKER PHONE
The speaker phone feature allows you to hear audio through the speaker and talk without holding the phone.
1. To activate the speaker phone when the phone is in idle mode, answering mode, or calling mode, press and hold .
2. The phone returns to normal (speaker phone off) after ending or call or when the phone is turned off and back on.
ANSWERING A CALL
1. To answer a call, press any key except , , , or .To enable a call, press .
In the Settings menu, you can select either “Any Key” or “Send Key” to answer a call. lf “Send Key” is selected, the phone can only be answered by pressing . See page 75 for more information.
2. To end the call, press .
NOTE: In Auto Answer Mode, a call is automatically
answered after a preset number of rings. See page 76 for more details.
3-WAY CALL FUNCTION
With 3-Way Calling, you can talk to two people at the same time. When using this feature, the normal airtime rates will be applied for each of the two calls.
1. Enter the number you wish to call then press .
2. Once you have established the connection, enter the second number you wish to call then press .
3. When you’re connected to the second party, press
again to begin your 3-Way call.
NOTE: If one of the people you called hangs up during
your call, you and the remaining caller stay connected. If you initiated the call and are the first to hang up, all three callers are disconnected.
Page 24 - Chapter 2
Chapter 2 - Page 25
BASIC FUNCTIONS
BASIC FUNCTIONS
BASIC FUNCTIONS
BASIC FUNCTIONS
CALL WAITING FUNCTION
Notifies you of an incoming call when you’re on a call by sounding a beep and displaying the caller’s phone number on the screen.
1. To answer another call while on the phone press . This places the first call on hold.
2. To switch back to the first caller, press again.
Since Call Waiting is system dependant, the displayed Caller ID may be different from the actual caller.
ADJUSTING VOLUME
Volume can be adjusted by using the volume control keys on the side of the handset, or by using the menu.
1. Press [MENU] then select one of the following. To increase the volume, press the Navigation Key to the right. To lower the volume, press it to the left.
Ringer: Controls the ringer volume.
Key Tone: Controls the key pad tone volume.
Voice Call: Controls the earpiece volume.
Speaker Phone: Controls the speaker volume
in speaker phone mode.
2. Adjust volume then press [OK] to save it.
NOTE: To adjust the volume of the microphone during
a call, press the volume keys on the side of the phone or the Navigation Key (left or right).
Page 26 - Chapter 2
LOCK
Locks your phone and prevents unauthorized use. Phone can only be used after inputting the password.
1. To lock the phone, press and hold .
2. To unlock the phone, press or [UNLOCK]
then input the password.
Lock feature will deactivate when the phone is powered off. Upon next power up, you will need to press to lock phone again.
The default password is the last 4 digits of your
phone number.
CALLER ID FUNCTION
Identifies caller by displaying their phone number. If the caller’s name and number are already stored in your phone book, they both will appear. This feature is system dependent. Please contact your service provider for details.
NOTE: The caller ID is stored in the call history.
MUSIC PLAYER
Music Player is for playing MP3 files saved on the mini SD Card. To display music list with the phone closed, press and hold and select a music file with the Navigation Key, press [PLAY], then press [PAUSE] or in order to stop the music player while it is playing with shell closed, it is required to open the shell and press .
Verizon Wireless shall not be responsible for any action
or liability as a result of any breach of copyright or other misuse of music contents.
Chapter 2 - Page 27
FUNCTIONS DURING A CALL
FUNCTIONS DURING A CALL
FUNCTIONS DURING A CALL
FUNCTIONS DURING A CALL
To display menu options during a call, press [MENU]. These menu items are available while you are on a call.
MESSAGING
Enables you to send a message (SMS) during a call.
1. Press [MENU] .
MUTE (UNMUTE)
Mutes the microphone while you are on a call so the other party cannot hear you when you speak.
1. Press [MENU] .
To deactivate, press [MENU] .
The phone will automatically un-mute during an
Emergency Call or in Callback mode.
SCRATCHPAD
Allows you to enter a phone number during a call so it can be dialed later. The other party cannot hear the key presses.
1. Press [MENU] .
SEND MY PHONE #
Automatically transmits your phone number to a pager during a call without manually entering the number.
1. To transmit your phone number during a call, press [MENU] .
MY PHONE #
Enables you to see your phone number while on a call. Please see page 48 for more details.
1. Press [MENU] .
VOICE PRIVACY
Enhances voice privacy during a call.
1. Press [MENU] .
2. Select “Enhanced” or “Standard” then press
to save it.
NOTE: Enhanced voice privacy is a network dependent
feature. Standard voice privacy is the default setting.
[OK]
To deactivate it, press [MENU] .
Page 28 - Chapter 2
Chapter 2 - Page 29
FUNCTIONS DURING A CALL
FUNCTIONS DURING A CALL
MAKING AN EMERGENCY CALL
MAKING AN EMERGENCY CALL
LOCATION
Enables the network to locate your current location through Global Positioning System (GPS).
1. Press [MENU] .
2. Select “911 Only” or “Location On” and press
911 Only: Your location will be hidden from network &
Location On: Your location is now available to the
[OK] to save it.
applications except 911.
network.
PHONE INFO.
Enables you to view software and hardware version while on a call. Please see page 82 for more details.
1. Press [MENU] .
This 911 feature automatically places your phone in the Emergency Call Mode when you dial the preprogrammed emergency number, 911. This feature is functional even in the lock mode and in an out od service area.
911 IN LOCK MODE
The “911” call service is available even in the lock mode.
1. Enter “911” then press .
2. The call connects.
3. The phone exits the Lock Mode for 5 minutes.
4. To exit emergency mode, press .
When the call ends, the phone returns to the Lock Mode.
911 USING ANY AVAILABLE SYSTEM
1. Enter “911” then press .
2. The call connects.
3. The phone remains in Emergency Mode for 5 minutes.
Page 30 - Chapter 2
4. To exit emergency mode, press .
The phone continuously attempts to receive service from any available system.
NOTE: 1. The 911 call is not recorded in the Call History.
2. You can not make an E911 call while you are in a BREW application.
Chapter 2 - Page 31
USING THE MINI SD CARD
USING THE MINI SD CARD
USING THE MINI SD CARD
USING THE MINI SD CARD
INSTALLING THE MINI SD CARD
1. Open the card hole cover, and insert the mini SD like the arrow indicates.
NOTE: Please keep mini-SD slot closed at all times
whether mini-SD card is inserted or not to prevent possible damages.
REMOVING THE MINI SD CARD
1. To remove the mini SD card, press and release the card so that it is disengaged from the slot. Then slide it out.
When you insert the mini-SD card, make sure contact terminals face down.
File names storing each media in the mini SD Card are “Pix” for pictures, “Flix” for motion pictures and "MP3" for Mp3.
Memory used for the mobile phone is not the general SD card but the mini SD cards.
For the mini SD card contents, file names of MP3 should be less than 40 characters of English.
Pix and Flix's file name should be less than 12 characters of English.
Do not remove the miniSD Card while reading or writing files. Otherwise it could be damaged.
“Mini SD” card is recognized as a mobile disk when connected to a personal computer.
When disconnecting from PC, please remove the USB storage equipment on your PC. Otherwise, the stored files on the miniSD Card could be damaged.
Page 32 - Chapter 2
REMOVABLE MEMORY STORAGE FUNCTIONALITY
The following grid shows what types of files can be transferred to the removable memory card.
RINGTONES
Memory Usage Ring tone
Download via “Get It Now”
application
Saved to a removable SD
Saving a sound attachment to the SD
card and assigning it as a ring tone
memory card
YES
Stored to the phone only
Stored to the phone only
NO
NO
Stored to the phone only
PIX
Memory Usage Pix
Pictures received from other
Download via a Get It Now
users
application
Stored to the phone onlyYES
Stored to the phone only
YES
Information can be stored
YESUser generated picture
to phone or memory card
Files are lockedNOInformation/files viewable on PC
Chapter 2 - Page 33
USING THE MINI SD CARD
USING THE MINI SD CARD
FLIX
Memory Usage Flix
Video clips received from other
Video clips downloaded via
Video clips downloaded via
Packet Video (PV) Ex: NBC
users
Get It Now
Stored to the phone onlyYES
Stored to the phone only
YES
Stored to the phone onlyYES
Information can be stored
YESUser generated video
to phone or memory card
Files are lockedNOInformation/files viewable on PC
MP3/MUSIC
Memory Usage MP3/Music
Move MP3 files from PC to the
memory card
Move MP3 files off the card to
the phone’s memory
Are other music file types
available for use?
NOTE: 1. When pictures, taken with built in camera, are
moved to SD card, they are stored in the SD directory. In the same manner, video clips are stored in Flix directory, and MP3 files are stored in the MP3 drectory.
2. CDM-8940VW can playback music files,
downloaded from a PC and stored in the SD card.
YES
User can play MP3 files
from the card
NO
NO
Chapter 3
MEMORY
FUNCTION
This chapter addresses numerous functions including saving phone numbers to the internal phone book, entering text and accessing call logs.
Storing Phone Numbers Text Input Methods Speed Dialing Phone Book Recent Calls
Page 34 - Chapter 2
Chapter 3 - Page 35
STORING PHONE NUMBERS
STORING PHONE NUMBERS
TEXT INPUT METHODS
TEXT INPUT METHODS
The phone book stores up to 300 entries.
1. Enter phone # then press [SAVE].
2. Choose “New Contact” or “Existing Contact”. To select, press [OK].
3. If “New Contact” is selected, the phone number will appear above a list of icons. The name of the icon is displayed below the list. Press the Navigation Key right or left to choose the type of number you’re adding, as indicated by the icon. Press [OK] to select. If “Existing Contact” is selected, your phone book list is displayed. Choose the entry to add the phone number to, then press [OK]. You will then see the phone number listed about a list of icons and the name of the currently selected icon below the list. Press [OK] to select.
4. Enter a name then press [OK]. Follow instructions for entering text on page 37. To change the input mode, press [Abc].
5. Use the Navigation Key to scroll through more options for the entry (group, other numbers, ringer, etc.).
Mobile/ Home/ Office/ Pager/ FAX E-Mail: Enter E-Mail address. Wireless Addr.: Enter Wireless address. Group: Personal, Business, Etc. Ringer: Select Ringer Type. Msg. Ringer: Select Msg. Ringer Type. Graphic: Select take a picture Image. Memo: Enter memo./ Set Secret: Lock, Unlock.
6. To store the entry, press [SAVE]. “New contact added!” or “Contact edited!” will be displayed.
Page 36 - Chapter 3
ENTERING CHARACTERS
Your phone offers several text input methods for conven­ient entry of memory location names and text messages:
Abc mode: Enters words by repeatedly tapping the corresponding
T9Word: Tap each corresponding key only once and the phone
Numeric mode: Only enters numbers. Symbol mode: Enters symbols like @, #, %.
ALPHA MODE [ABC]
Use the digit keys to enter letters, numbers and characters. Enter letters using the key pad as follows:
Key Pad
2ABC
3DEF
4GHI
5JKL
6MNO
7PQRS
8TUV
9WXYZ
To change the input mode, press [Abc].
To enter a space, press . The cursor will automatically
Repeat until letters are entered. (Name or Group is a
To delete one digit, press .
To change from lowercase to uppercase, press .
key until the desired character is displayed.
predicts the word you are entering.
1
1 Repetition
1
A
D
G
J
M
P
T
W
2 Repetitions
.
B
E
H
K
N
Q
U
X
3 Repetitions
@
C
F
I
L
O
R
V
Y
4 Repetitions
-
2
3
4
5
6
S
8
Z
5 Repetitions
...
...
...
...
...
7
...
9
move to the next column.
16-letter limit, E-mail or Wireless Address is a 48-letter limit).
To delete the entire entry, press and hold .
Chapter 3 - Page 37
TEXT INPUT METHODS
TEXT INPUT METHODS
TEXT INPUT METHODS
TEXT INPUT METHODS
T9TMPREDICTIVE TEXT MODE [T9TMABC]
To choose T9TMmode from the Editor screen press [Abc], then choose [T9Word]. This mode predicts the words you are entering using a built-in dictionary. With
TM
predictive text input, you press each key only once
T9 for each letter. The chart below outlines how to use
TM
mode.
T9
KEY FUNCTION
Press to change mode.
Mode
Next
Space
Shift
[Abc][T9Word][NUM][Symbols].
Press to view the next matching word if the highlighted word is not the word you intended.
Press to accept a word and add a space.
Press to select a letter case of the standard text input or T9 text input mode. [Abc], [ABC], and [abc] indicate the standard text input. [T9word], [T9Word], and [T9WORD] indicate the predictive text input.
1. Press each key once for each letter of the word you are writing.
To write John with the English dictionary selected:
1. Press 5 once - (for - K)
2. Press 6 once - (for - Km)
3. Press 4 once - (for - Log)
4. Press 6 once - (for - John)
NOTE:
The display will change each time a key is pressed.
2. Press until the correct word is displayed.
3. To select the correct word, press
[OK].
If the T9 mode does not recognize or suggest the word you want to enter, re-enter the name in the
Alpha ABC mode.
NOTE:
When entering more than one word in T9Word Mode, enter the first word than press to insert a space and start the next word.
Clear
Save
Page 38 - Chapter 3
Press to delete a character to the left of the cursor.
Store the letters and numbers you enter.
Chapter 3 - Page 39
TEXT INPUT METHODS
TEXT INPUT METHODS
SPEED DIALING
SPEED DIALING
NUMERIC MODE [NUM]
Numeric mode allows you to add a number to your entry/message. To select numeric mode from the Editor screen press [Abc], then select [NUM].
SYMBOL MODE [SYM]
Symbol mode allows you to add various symbols to your entry. Whether you are adding an e-mail address to your phone book or sending an expressive message, symbols make these entries easier. To select symbol mode from the Editor screen press
[Abc] then choose [Symbols]. The symbols will appear on the display. The corresponding key number for that symbol will appear as well. You can press the key to select the symbol . To move to the next screen of symbols press .
Page 40 - Chapter 3
SPEED DIAL
Dials a number simply by pressing and holding its Speed Dial location number. For a 2-digit location number, press the first number then press and hold the second number. To store a number in Speed Dial:
1. Press [MENU] .
2. To assign a phone number to a location, select the location then press [SET].
If a phone number is already assigned to the location,
press [ERASE] then the Navigation Key to delete.
3. The phone book list will be displayed alphabetically. Select a name then press [OK].
4. “Speed dial # X Edited!” will be displayed.
If the entry is set to secret, you will be asked for your password.
ONE-TOUCH/TWO-TOUCH DIALING
Ideal for frequently dialed numbers, this feature allows phone book entries to be dialed via the key pad with only one or two key presses.
ONE-TOUCH/TWO-TOUCH DIALING:
1-9 : Press the corresponding memory number and hold
for more than 1 second.
01-09/10-20 : Press the first digit and second digits of the
memory number short and long respectively.
If no phone number is stored in the location entered,
“There is no number” will appear on the screen.
If the entry is set to secret, you will be asked for your
password.
To One-Touch voicemail (*86 feature), press “1” or “01”.
Chapter 3 - Page 41
PHONE BOOK
PHONE BOOK
PHONE BOOK
PHONE BOOK
Stores up to 300 entries, each of which can be assigned to a group. Entries can be retrieved by name, phone number or group.
FIND
Retrieves an entry by name or number, and calls the number by simply pressing . On Standby Screen, you may press [CONTACTS] as well.
all the entries stored in your phone book list or find an entry quickly by entering a name or its character string.
1. Press [MENU] .
2. The list of names in your phone book is displayed alphabetically. Use Navigation Key to select the name.
3. Enter a name or its character string or scroll through the list with the Navigation Key. Please refer to page 37 for instructions on entering letters, numbers and symbols.
4. The list beginning with the letter you entered is displayed. Highlight an entry. Press [OK] to preview list the entry. Press [MENU] to view options. If the contact has a mobile phone number your options will be 1. Send Text Msg, 2. Send Pix Msg, 3. Send Flix Msg, 4. Erase or 5. Prefix. If no mobile number is saved for the contact, your options will be 1. Erase, 2. Prefix. If only an e-mail or wireless address is saved for the contact, your options will be 1. Send Text Msg, 2. Send Pix Msg,
3. Send Flix Msg, 4. Erase.
If the entry is set to secret, you will be asked for your
password.
Page 42 - Chapter 3
You can review
5. To call the selected number, press .
ADD NEW
Adds a new entry to the phone book. Please refer to page 36 for alternate ways to add an entry to the phone book.
1. To add a new entry to the phone book, press [MENU] .
2. The first field highlighted is Name. Enter the name for the entry, then press [OK].
PHONE BOOK FIELD: Name/Mobile/Home/Office/Pager/Fax/
E-Mail/Wireless Addr./Group/Ringer/Msg.Ringer/Graphic/ Memo/Set Secret.
3. Press the Navigation Key down to enter all the other information (group, phone number, etc.).
4. To save the entry after all the information is entered, press [SAVE].
Chapter 3 - Page 43
PHONE BOOK
PHONE BOOK
PHONE BOOK
PHONE BOOK
GROUP
Allows you to classify phone entries into groups. Existing groups include Personal, Business, Etc. and All.
ADD NEW GROUP
1. To add a new group, press [MENU] . A maximum of seven groups is allowed.
2. Press [MENU] then select “Add Group”.
3. Input a new group name.
4. To save it, press [OK].
CHANGE GROUP NAME
1. Press [MENU] .
Select an existing group name.
NOTE:
2. Press [MENU] then select “Rename”.
3. Input a new group name.
4. To save it, press [OK].
Default group name(All, Personal, Business, Etc.) cannot be changed.
ERASE GROUP
1. Press [MENU] . Select an existing group name.
2. Press [ERASE] to delete it. “Erase this group?” will be displayed.
3. Press [OK] again to confirm it.
When executing erase group, the saved entries are
moved to the Etc. group.
The default group names (All, Personal, Business, Etc.)
cannot be changed.
MSG. GROUP
Allows the user to group up to 10 phone numbers. The user can add, change, and delete Msg.Groups.
ADD NEW MSG. GROUP
1. To add a new group, press [MENU] .
A maximum of five groups is allowed.
2. Press [MENU] then select “Add Group”.
3. Input a new group name.
4. To save it, press [OK].
Page 44 - Chapter 3
Chapter 3 - Page 45
PHONE BOOK
PHONE BOOK
PHONE BOOK
PHONE BOOK
CHANGE MSG. GROUP NAME
1. Press [MENU] . Select an existing group name.
2. Press [MENU] then select “Rename”.
3. Input a new group name.
4. To save it, press [OK].
SEND TEXT MSG.
1. Press [MENU] . Select an existing group name.
2. Press [MENU] then select “Send Text Msg.”.
3. Complete the “Message”, “Default CB#”, “Priority”, and “Insert Signature” fields.
4. Press [MENU] then select “Send” or “Save Msg”.
Press [OK]. Please refer to page 115 for more details on
“New TXT Msg”.
SEND PIX MSG.
1. Press [MENU] . Select an existing group name.
2. Press [MENU] then select “Send Pix Msg.”.
3. Complete the “Message”, “Subject”, “CC”, “BCC”, “Priority” and “Insert Signature” fields.
4. Press [MENU] then select “Send”, “Preview” or “Save Msg”. Press [OK]. Please refer to page 117 for more details on “New Pix Msg”.
SEND FLIX MSG
1. Press [MENU] . Select an existing group name.
2. Press [MENU] then select “Send Flix Msg”.
3. Complete the “Message”, “Subject”, “CC”, “BCC”, “Priority” and “Insert Signature” fields.
4. Press [MENU] then select “Send”, “Preview” or “Save Msg”. Press [OK]. Please refer to page 119 for more details on “New Flix Msg”.
Page 46 - Chapter 3
Chapter 3 - Page 47
PHONE BOOK
PHONE BOOK
RECENT CALLS
RECENT CALLS
ERASE MSG. GROUP
1. Press [MENU] . Select the group name to be deleted.
2. To delete it, press [ERASE]. “Erase this message group?” will be displayed.
3. Press [OK]. “This message group erased” will be displayed.
MY PHONE #
To display your phone number and service provider:
1. Press [MENU] .
2. Your phone number and service provider appears. To return to the previous page, press [OK].
To access Recent Calls from the idle mode, press [MENU] .
ALL CALLS
Displays information about the 60 most recently dialed, missed and received numbers. Place a call to a select­ed number by simply pressing .
1. To see a list of the 60 most recent numbers, press [MENU] . If the number is already stored in your phone book, only the name appears. If the number is not stored, only the phone number appears.
2. To view call details, press
NOTE:
• Call details include date, time, and phone number.
• If the phone number is set to secret, the name is not displayed.
3. To save the number, press [MENU], [SAVE] or press [ERASE] to delete it.
Save: To store the phone number in your phone book.
Prefix: Allows user to add an additional number before the
Send Text Msg: To send a message to the phone number.
Send Pix Msg: To send a photo message to the phone
Send Flix Msg: To send a video mail message to the phone
Erase All: To erase all recent calls list.
NOTE:
stored number such as an area code or “1” before a long distance call.
number.
number.
After the 60 received, dialed or missed calls, the oldest call will automatically be erased from the history.
[OK].
Page 48 - Chapter 3
Chapter 3 - Page 49
RECENT CALLS
RECENT CALLS
RECENT CALLS
RECENT CALLS
MISSED CALLS
Displays information about the 20 most recently missed calls. Place a call to a missed call number by simply pressing .
1. To see a list of the 20 most recently missed calls, press [MENU] . If the number is already stored in your phone book, only the name appears. If the number is not stored, only the phone number appears.
2. To view missed call details, press
NOTE:
Call details include date, time and phone number.
3. To save the number, press [MENU], [SAVE] or press [ERASE] to delete it.
Save: To store the phone number in your phone book.
Prefix: Allows user to add an additional number before the
Send Text Msg.: To send a message to the phone number.
Send Pix Msg.: To send a photo message to the phone
Send Flix Msg.: To send a video mail message to the
Erase All: To erase all missed calls list.
NOTE:
stored number such as an area code or “1” before a long distance call.
number.
phone number.
After the 20 missed calls, the oldest call will automatically be erased from the history.
[OK].
RECEIVED CALLS
Displays information about the 20 most recently answered calls. Place a call to a received number by simply pressing .
1. To see a list of the 20 most recently received calls, press [MENU] . If the number is already stored in your phone book, only the name appears. If the number is not stored, only the phone number appears.
2. To view received call details, press
NOTE: Call details include date, time and phone number.
3. To save the number, press [MENU], [SAVE] or press [ERASE] to delete it.
Save: To store the phone number in your phone book.
Prefix: Allows user to add an additional number before the
stored number such as an area code or “1” before a long distance call.
Send Text Msg.: To send a message to the phone number.
Send Pix Msg.: To send a photo message to the phone
number.
Send Flix Msg.: To send a video mail message to the
phone number.
Erase All: To erase all received calls list.
NOTE: After the 20 received calls, the oldest call will
automatically be erased from the history.
[OK].
Page 50 - Chapter 3
Chapter 3 - Page 51
RECENT CALLS
RECENT CALLS
RECENT CALLS
RECENT CALLS
DIALED CALLS
Displays information about the 20 most recently dialed calls. Place a call to a received number by simply pressing .
1. To see a list of the 20 most recently dialed calls, press [MENU] . If the number is already stored in your phone book, only the name appears. If the number is not stored, only the phone number appears.
2. To view dialed call details, press
NOTE: Call details include date, time and phone number.
3. To save the number, press [MENU], [SAVE] or press [ERASE] to delete it.
Save: To store the phone number in your phone book.
Prefix: Allows user to add an additional number before the
stored number such as an area code or “1” before a long distance call.
Send Text Msg.: To send a message to the phone number.
Send Pix Msg.: To send a photo message to the phone
number.
Send Flix Msg.: To send a video mail message to the
phone number.
Erase All: To erase all dialed calls list.
NOTE: After the 20 dialed calls, the oldest call will
automatically be erased from the history.
[OK].
CALL TIMERS
Checks the usage time and manages your calls within the limit you set. The five timers include:
LAST CALL
Displays usage time of last call.
1. Press [MENU] .
2. To return to the previous page, press [OK].
ALL CALLS
Displays usage time of all incoming and outgoing calls, excluding web access calls.
1. Press [MENU] .
2. The time of the following items is displayed.
Voice Calls, Data Calls
3. To return to the previous page, press [OK].
NOTE: You cannot reset this timer.
NOTE: You may also navigate to the next or previous
second-level menu (Last Calls, All Calls, Home Calls, Roam Calls, Cumulative Calls) by pressing the Navigation Key right or left.
Page 52 - Chapter 3
Chapter 3 - Page 53
RECENT CALLS
RECENT CALLS
RECENT CALLS
RECENT CALLS
HOME CALLS
Displays usage time of all calls made within Home area.
1. Press [MENU] .
2. The time of the following items is displayed:
Voice Calls, Data Calls
3. To reset the timer, press [RESET]. To return to the previous page, press [OK].
ROAM CALLS
Displays usage time of roaming calls.
1. Press [MENU] .
2. The time of the following items is displayed:
Voice Calls, Data Calls
3. To reset the timer, press [RESET]. To return to the previous page, press [OK].
NOTE: You may also navigate to the next or previous
second-level menu (Last Calls, All Calls, Home Calls, Roam Calls, Cumulative Calls) by pressing the Navigation Key right or left.
CUMULATIVE CALLS
Displays usage time of all incoming and outgoing calls, excluding web access calls.
1. Press [MENU] .
2. The time of the following items is displayed:
Voice Calls, Data Calls
3. To reset the timer, press [RESET]. To return to the previous page, press [OK].
NOTE: You may also navigate to the next or previous
second-level menu (Last Calls, All Calls, Home Calls, Roam Calls, Cumulative Calls) by pressing the Navigation Key right or left.
Page 54 - Chapter 3
Chapter 3 - Page 55
RECENT CALLS
RECENT CALLS
1X PACKET COUNTER
Checks the log of all kilobyte data transmissions.
RECEIVED
To show the received kilobyte usage on a user definable interval:
1. Press [MENU] .
2. To reset the counter, press [RESET]. To return to the previous page, press [OK].
TRANSMITTED
To show the transmitted kilobyte usage on a user definable interval:
1. Press [MENU] .
2. To reset the counter, press [RESET]. To return to the previous page, press [OK].
TOTAL
To show the received or transmitted kilobyte usage on a user definable interval:
1. Press [MENU] .
2. To return to the previous page, press [OK].
Chapter 4
SETTINGS
This chapter addresses customizing your phone by adjusting backlighting, volume, ring tones and other user-friendly features.
Settings Media Gallery
Page 56 - Chapter 3
Chapter 4 - Page 57
SETTINGS
SETTINGS
SETTINGS
SETTINGS
SOUNDS
Sets Ringer Type, Volume, Alerts, Roam Ringer, Tone Length and Power On/Off.
RINGER TYPE
To select a ringer type for incoming calls:
RINGER
1. Press [MENU] .
2. Select one of the pre-installed 20 music bells and 5 ring tones.
3. To confirm, press [OK].
MESSAGES
To select a ringer type for receiving messages:
1. Press [MENU] .
2. Select a tone (1-5).
3. To confirm, press [OK].
VOICE MAIL
To select a ringer type for receiving voice mail:
1. Press [MENU] .
2. Select a tone (1-5).
VOLUME
Controls the Ringer, Key Tone, Voice Call and Speaker Phone volume and alerts you to incoming calls in a variety of modes.
RINGER
Controls the Ringer volume and alerts you to incoming calls in the following modes.
1. Press [MENU] .
2. Select one of the following options:
Silent: Mute the ringer, press [Min].
Ringer Off
Vibrate On
Ringer Mode: Volume Levels 1-5.
High & Vib: The ringer sounds with vibration,
Vib to High: The ringer sounds after vibration,
press [Max].
3. To confirm, press [OK].
KEY TONE
To adjust key pad tone:
1. Press [MENU] .
2. Adjust the key pad tone.
Off/Level1-5 (Min- , Max- )
3. To save, press [OK].
3. To confirm, press [OK].
Page 58 - Chapter 4
Chapter 4 - Page 59
SETTINGS
SETTINGS
SETTINGS
SETTINGS
VOICE CALL
To adjust earpiece volume:
1. Press [MENU] .
2. Adjust the earpiece volume.
Level1-5 (Min- , Max- )
3. To save, press [OK].
SPEAKER PHONE
To adjust speaker volume:
1. Press [MENU] .
2. Adjust the speaker phone volume.
Level1-5 (Min- , Max- )
3. To save, press [OK].
ALERTS
Allows you to set an alert that sounds when the following handset changes occur.
MINUTE
Sounds an alert every minute of a phone call.
1. Press [MENU] .
ROAM
Sounds an alert when leaving a service area, change System ID and entering a roaming service area.
1. Press [MENU] .
2. Select “Off” or “On” then press [OK] to save it.
CONNECT
Notifies you that a call has been successfully placed.
1. Press [MENU] .
2. Select “Off” or “On” then press [OK] to save it.
FADE
To notify you when your phone loses a signal during a call.
1. Press [MENU] .
2. Select “Off” or “On” then press [OK] to save it.
FLIP SOUND
Sounds an alert when phone is opened or closed.
1. Press [MENU] .
2. Select “Off” or “On” then press [OK] to save it.
2. Select “Off” or “On” then press [OK] to save it.
Page 60 - Chapter 4
Chapter 4 - Page 61
SETTINGS
SETTINGS
SETTINGS
SETTINGS
ROAM RINGER
Sounds a different ringer when you are in a roaming service area.
1. Press [MENU] .
2. Select “Distinctive” or “Normal” then press [OK] to save it.
TONE LENGTH
To adjust key tone length:
1. Press [MENU] .
2. Select “Normal” or “Long” then press [OK] to save it.
POWER ON/OFF
To set sound “ON” or “OFF” when powering ON/OFF.
POWER ON
1. Press [MENU] .
2. Select “On” or “Off” then press [OK] to save it.
POWER OFF
1. Press [MENU] .
2. Select “On” or “Off” then press [OK] to save it.
DISPLAY
This feature allows you to customize and personalize your phone display.
MENU STYLE
To select a display menu style:
1. Press [MENU] .
2. Select “Grid” or “List” then press [OK] to save it.
GRAPHICS
To select an LCD display:
WALLPAPER
1. Press [MENU] .
2. Select “Camcoder”, “Digital Clock1,2”, “Analog Clock 1,2”, “Pix #”, “Downloads” or “Animations” through Network or received picture by Picture Msg.
3. To save it, press [OK].
RECEIVED
1. Press [MENU] .
2. Select “Default”, “Pix #” or “Downloads” with the Navigation Key.
Page 62 - Chapter 4
3. To save it, press [OK].
Chapter 4 - Page 63
SETTINGS
SETTINGS
SETTINGS
SETTINGS
DIALED
1. Press [MENU] .
2. Select “Default” with the Navigation Key.
3. To save it, press [OK].
SCREEN SAVER
Set the time of Screen Saver and select the images, the image will then be displayed on the LCD.
1. Press [MENU] .
2. Select “Time Setting” to set the amount of time the screensaver is displayed (Off, 5 Secs, 10 Secs, 20 Secs, 30 Secs).
3. Select a “Screen Saver” from the list. (Pix/Downloads/Animations).
4. To save it, press [OK].
SUB SCREEN
EXTERNAL CLOCK
1. Press [MENU] .
WALLPAPER
1. Press [MENU] .
2. Select “Digital 1”, “Analog 1” or “Analog 2” with the Navigation Key.
3. To save, press [OK].
GREETING MESSAGE
To input a personal greeting:
1. Press [MENU] .
2. Select “Message”, “Font” or “Entry Message” to personalize your greeting. Press [OK].
Message: On/Off.
Font: White, Blue, Dark Blue, Magenta, Gray, Black.
Entry Message: Enter message (Default-Verizon).
3. To save, press [SAVE].
2. Select “Analog1”, “Analog2”, “Digital1” or “Digital2” with the Navigation Key.
3. To save, press [OK].
Page 64 - Chapter 4
Chapter 4 - Page 65
SETTINGS
SETTINGS
SETTINGS
SETTINGS
BACKLIGHT
Backlights the display and key pad for easy viewing in dark places.
1. Press [MENU] .
2. Select “LCD” or “Key Pad” then select one of the following options.
LCD: 5 Secs/15 Secs/30 Secs/60 Secs/Always On.
Key Pad: 5 Secs/15 Secs/30 Secs/60 Secs/Always On/
Always Off.
3. To save, press [OK].
DATA SVC.
Allows you to transfer data when your phone is connected to a PC.
CONNECTION
Select a connection mode based on the handset usage.
1. Press [MENU] .
2. Select one of the following connection modes:
Voice Call: To receive a voice call.
Data Only: To receive data when connected to a PC.
3. To save, press [OK].
Page 66 - Chapter 4
Chapter 4 - Page 67
SETTINGS
SETTINGS
SETTINGS
SETTINGS
SECURITY
Prevents others from using the phone without permission and allows access to security features only after inputting a password.
PHONE LOCK
Prevents others from using your phone without permission. When locked, calls cannot be made and the menu cannot be accessed without entering the password.
1. Press [MENU] then enter “Password”.
NOTE: The default password is the last 4 digits of your
phone number.
2. Press then select “Lock Now”, “Lock On Power Up” or “Unlock”.
Lock Now: Lock the phone now.
Lock On Power Up: Do not lock the phone now, but
automatically lock phone when power is recycled.
Unlock: Do not lock the phone.
3. To save, press [OK].
RESTRICT
When you attempt to make a restricted call, “This phone is restricted” appears on the screen.
DIALED
Blocks all dialed calls – except emergency or special # calls – but allows incoming calls to be answered.
1. Press [MENU] then enter “Password”.
2. Press then select “Allow” or “Restrict”.
Allow: Allows dialed calls.
Restrict: Restricts dialed calls.
3. To save, press [OK].
RECENT CALLS
Blocks access to Recent Call List.
1. Press [MENU] then enter “Password”.
2. Press then select “Allow” or “Restrict”.
Allow: Allows access to the recent calls menu.
Restrict: Restricts access to the recent calls menu.
3. To save, press [OK].
Page 68 - Chapter 4
Chapter 4 - Page 69
SETTINGS
SETTINGS
SETTINGS
SETTINGS
CAMERA
Restricts access to camera mode.
1. Press [MENU] then enter “Password”.
2. Press then select “Allow” or “Restrict”.
Allow: Allows access to the camera.
Restrict: Restricts access to the camera.
3. To save, press [OK].
900#S
Restricts calling 900 dial service numbers.
1. Press [MENU] then enter “Password”.
2. Press then select “Allow” or “Restrict”.
Allow: Allows calls to 900-dial services.
Restrict: Restricts calls to 900-dial services.
3. To save, press [OK].
LONG DISTANCE
Restricts calling long distance numbers – the phone is limited to calling numbers within the area.
1. Press [MENU] then enter “Password”.
2. Press then select “Allow” or “Restrict”.
Allow: Allows a long distance call.
Restrict: Restricts a long distance call.
CHANGE CODE
Changes your 4-digit password.
1. Press [MENU] then enter “Password”.
NOTE: The default password is the last 4 digits of your
phone number.
2. Press .
3. Enter a new password then press [OK].
4. Re-enter the new password then press [OK].
SPECIAL #’S
Stores 3 phone numbers that can be called even in the lock mode.
1. Press [MENU] then enter “Password”.
NOTE: The default password is the last 4 digits of your
phone number.
2. Press then select a location.
3. Press ~ , input a phone number then, press [OK] again to save.
NOTE: You can delete a special number by selecting it,
pressing [ERASE], then [Ok].
3. To save, press [OK].
Page 70 - Chapter 4
Chapter 4 - Page 71
SETTINGS
SETTINGS
SETTINGS
SETTINGS
ERASE ALL
Clears all Phonebook entries, Downloads, Pix Gallery, Flix Gallery and SD Card entries.
1. Press [MENU] then enter “Password”.
NOTE: The default password is the last 4 digits of your
phone number.
2. Press .
3. Select “Phonebook”, “Downloads”, “Pix Gallery”, “Flix Gallery” or “SD Card” with the [CHECK] and press [OK] to erase all the items in those categories.
NOTE: Since the data cannot be retrieved once it is
erased, a warning will appear on the display before erasing everything.
RESET PHONE
Resets phone to default settings.
1. Press [MENU] then enter “Password”.
NOTE: The default password is the last 4 digits of your
phone number.
2. Press .
3. A message, asking for your confirmation, will appear as following. “It will erase all data on your phone. Reset Phone?”.
4. Press [OK].
When you press “OK” you will see “Phone Reset! Your Phone will reboot now” on the display and your phone will reset all settings to the factory defaults.
Page 72 - Chapter 4
Chapter 4 - Page 73
SETTINGS
SETTINGS
SETTINGS
SETTINGS
SD CARD
FORMAT
You can format a mini SD card, if you want to delete all information.
1. Press [MENU] then enter “Password”.
2. Press .
TRANSFER TO NEW PHONE
With the mini SD card, you can move your saved information to a new phone.
1. Press [MENU] then enter “Password”.
2. Press .
OTHERS
ANSWER OPTIONS
CALL ANSWER
To select an answer mode:
1. Press [MENU] .
2. Select “Any Key” or “Send Key”.
Any Key: Press any key to answer an incoming call
except , , , and .
Send Key: Calls can only be answered by pressing .
3. To save, press [OK].
ACTIVE FLIP
To select Active Flip Answer mode:
1. Press [MENU] .
2. Select “On” or “Off”.
3. To save, press [OK].
When Active Flip On is selected, an incoming phone call can be answered simply by opening the phone.
When Active Flip Off is selected, you will need to open the phone and follow the Answer mode you have selected.
Page 74 - Chapter 4
Chapter 4 - Page 75
SETTINGS
SETTINGS
SETTINGS
SETTINGS
AUTO ANSWER
Automatically answers a call after a preset number of rings. An ideal setting for the hands-free car kit. When Auto Answer is enabled, call is automatically answered even when ear-mic or car kit is not connected to CDM8940.
1. Press [MENU] .
2. Select “Handset”, “Headset”, or “Hands Free Kit”, then select one of the following options:
Off/5 Secs/10 Secs/18 Secs.
NOTE: 1. This function will not be active when you
select Vibrate, Silent as a ringer mode.
2. Even if auto answer is set to the handset,
auto answer setting for headset and HFK will be activated while they are in use.
3. To save, press [OK].
AUTO RETRY
Automatically redials your call up to 5 times after a set time interval.
1. Press [MENU] .
LANGUAGE
Selects the language in which letters are displayed on the screen.
1. Press [MENU] .
2. Select either “English” or “Spanish”.
3. To save, press [OK].
VOICE PRIVACY
Enhances voice privacy and avoids tapping during a call.
1. Press [MENU] .
2. Select “Standard” or “Enhanced”.
3. To save, press [OK].
“Enhanced”: Makes it more difficult to wire tap.
2. Under Retry Time, select a time interval option (Off, 3 Secs, 5 Secs, 7 Secs, 10 Secs). The Repeat Category will appear when a time frame is chosen.
3. Under Repeat, select a time interval option (1 Time, 3 Times, 5 Times).
4. To save, press [OK].
Page 76 - Chapter 4
Chapter 4 - Page 77
SETTINGS
SETTINGS
SETTINGS
SETTINGS
TTY MODE
Your phone is able to operate with a TTY (Teletypewriter) device in both analog and digital modes. This feature is system dependent and may not be available in all areas.
1. Press [MENU] .
2. Select one of the following options.
TTY Off/TTY+TALK/TTY+HEAR/TTY Full
3. To save, press [OK].
LOCATION
To determine whether or not the network system can detect your position:
1. Press [MENU] .
2. Select “911 Only” or “Location On”.
911 Only: Your location will be hidden from network & application except 911.
Location On: Your location is now available to the
network.
3. To save, press [OK].
LANTERN
To use for easy viewing in dark places or emergency.
1. Press [MENU] .
2. Select a time Lantern option (10 Secs, 15 Secs, 30 Secs, 60 Secs).
3. To save, press [OK].
To activate the “Lantern On”, press and hold Side Volume Down Key (Depends on User’s setting time).
SHORT CUT KEY
Your phone offers you the option of assigning a short­cut key (UP Navigation Key) to a favorite or often-used function. To assign a shortcut to the key:
1. Press [MENU] .
2. Select your desired menu option then press [OK].
Phone Book/Schedule/Display/Sounds/Media Gallery
/Alarm
3. The Shortcut can now be accessed by pressing up on the Navigation Key.
Page 78 - Chapter 4
Chapter 4 - Page 79
SETTINGS
SETTINGS
SETTINGS
SETTINGS
SYSTEM
SET MODE
Selects the Preferred System.
1. Press [MENU] .
2. Select one of the following options: Automatic B, Automatic A, Home Only.
Automatic B: Scans the radio channels based on the Automatic B setting.
Automatic A: Scans the radio channels based on the
Automatic A setting.
Home Only: Only within your home area or home
affiliated area.
3. To save, press [OK].
NAM SETTING
Enables Auto NAM (Number Assignment Modules) or manually selects a NAM.
AUTO NAM
Automatically switches phone to proper NAM when you have multiple NAM registrations.
1. Press [MENU] .
CHANGE NAM
Changes the NAM used by the phone when you have multiple registrations.
1. Press [MENU] .
2. Select “NAM1-VERIZON” or “NAM2-VERIZON”.
3. To save, press [OK].
PRL ID
Displays the phone’s “PRL (Preferred Roaming List) ID”, “ERI Version”.
1. Press [MENU] .
2. To return to the previous page, press [OK].
ERI BANNER
1. Press [MENU] .
2. Select “Off” or “On”.
3. To save, press [OK].
2. Select “Yes” or “No”.
3. To save, press [OK].
Page 80 - Chapter 4
Chapter 4 - Page 81
SETTINGS
SETTINGS
MEDIA GALLERYY
MEDIA GALLER
PHONE INFO
To display the version of your phone:
S/W VERSION
1. Press [MENU] .
2. The software version appears.
3. Press [OK].
H/W VERSION
1. Press [MENU] .
2. The hardware version appears.
3. Press [OK].
GET IT NOW VERSION
1. Press [MENU] .
2. The Get It Now version appears.
3. To return to the previous page, press [OK].
Page 82 - Chapter 4
PIX
This menu displays the list of Pix taken with the Camera.
1. Press [MENU] .
Press [MENU] to select 1. Edit Title, 2. Assign,
3. Erase, 4. Information.
If “mini SD Card” is connected to your phone, your options will be 1. Edit Title, 2. Assign, 3. Move to SD Card. 4. Erase, 5. Information.
2. Scroll through the downloaded images to display the image you want to send then press [SEND].
3. To send the “MMS” message, press [MENU], then select “Send”, then press [OK].
FLIX
This menu displays the list of Flix taken with the Camera or Video Clip with the Download.
1. Press [MENU] .
Press [MENU] to select 1. Edit Title, 2. Erase,
3. Information.
If “Video Clips” is selected, network will launch “Get It Now” and take you see a new video clip. (Refer to page 139 for more details). If “Download Clip” is selected, press [MENU] to select 1. Erase, 2. Information.
If “mini SD Card” is connected to your phone, your options will be 1. Edit Title, 2. Move to SD Card.
3. Erase, 4. Information.
2. Scroll through the captured flix to display the flix you want to send then press [SEND].
3. To send the “MMS” message, press [MENU], then select “Send”, then press [OK].
Chapter 4 - Page 83
MEDIA GALLERYY
MEDIA GALLER
MEDIA GALLERYY
MEDIA GALLER
MUSIC
This menu needs to be supported by mini SD Card. It plays the music stored in the mini SD Card. Copy the downloaded music from PC to mini SD Card, and play the music stored in the mini SD Card through your mobile phone.
1. Press [MENU] .
“mini SD Card” is connected to your phone, press [MENU] to select 1. Setting, 2. Erase (Erase This/ Erase All), 3. Information.
2. Scroll through the downloaded music to display the music you want.
3. Select the music you want to play then press [PLAY] or press [MENU]. Then select “Setting”, press [OK], then 1.All Repeat, 2.Repeat,
3.Random. Press [OK].
Verizon Wireless shall not be responsible for any action or liability as a result of any breach of copyright or other misuse of music contents.
TONES
This menu displays the list of downloaded ringtones or saved voice memos.
1. Press [MENU] .
Press [MENU] to select 1.Edit Title, 2.Erase,
3.Information.
Voice memo : Press [MENU] to select 1. Information.
2. Scroll to the saved voice memo you want to send then press [SEND].
IMAGES
This menu displays the list of downloaded still images.
1. Press [MENU] .
Press [MENU] to select 1.Edit Title, 2.Assign,
3.Erase, 4.Information.
2. Scroll through the downloaded images to display the image.
Page 84 - Chapter 4
Chapter 4 - Page 85
MEMO
MEMO
Chapter 5
SUPPLEMENTARY
FUNCTIONS
This chapter addresses supplemental functions including the voice tools, camera, schedule, memo pad, calculator, alarm, world clock and stop watch features.
Voice Tools Schedule Alarm Memo Pad Calculator World Clock Stop Watch Camera
Page 86 - Chapter 4
Chapter 5 - Page 87
VOICE TOOLS
VOICE TOOLS
VOICE TOOLS
VOICE TOOLS
Voice Recognition (VR) enables you to place calls using your voice and to record voice memos.
VOICE DIALING
1. Press and hold until your phone turns to Voice Recognition mode.
2. Say the indicator, such as a person’s name you saved for the number you are calling.
NOTE: When there is no registered voice dial,
voice recognition mode is disabled.
VOICE MEMO
Voice Memo allows you to record a reminder message that can be up to 60 seconds. To record a memo:
1. To start Tools menu, p
2. To enter a voice memo, press .
3. 1.1. To record a voice memo, press . Instructions will be displayed and you will hear “Please record at the tone”.
1.2. To stop recording a memo, press [STOP] or [PAUSE/RESUME].
1.3. Press to “Rerecord” or “Review”.
1.4. Press [SAVE] and input a “Voice Memo” title, then press [OK] or press [SEND] to access the “New Pix Msg”. See “New Pix Msg” on page
117.
2. To play voice memo, press .
Select the message you want to play then press
[PLAY] or press
2. Send, press [ERASE].
[MENU] after recording a voice memo
ress [MENU] .
[MENU] to 1. Edit Title,
Page 88 - Chapter 5
3. To play in speaker mode, press .
Select the message you want to play then press [PLAY] or press
2. Send, press [ERASE].
4. To erase all voice memos, press .
“Erase all voice memos?” will be displayed.
To erase all voice memos, press [OK].
[MENU] to 1. Edit Title,
Chapter 5 - Page 89
VOICE TOOLS
VOICE TOOLS
VOICE TOOLS
VOICE TOOLS
VOICE DIAL
Voice Dial allows you to call a person by simply saying their name. To access Voice Dial:
1. To start Tools menu, p
2. To enter a voice dial, press .
3. 1.1. To record a voice dial, press . The phone book list will be displayed
alphabetically. Select a name then press
[OK]. Instructions will be displayed and you will hear “Name Please”.
1.2. Say the name for the voice tag and repeat the name when prompted. You will hear “Added”.
2. To play voice dial, press .
Select the message you want to play then press [PLAY] or press [ERASE].
3. To play in speaker mode, press .
Select the message you want to play then press [PLAY] or press [ERASE].
4. To erase all voice dials, press .
“Removing all voice tags Proceed?” will be displayed. To erase all voice memos, press [OK].
ress [MENU] .
TRAIN WORDS
Train allows you to use Control words to make a call without using the key pad.
YES
Use to train or untrain the Voice Recognition with the control word, “Yes”.
1. Press [MENU] .
2. “Please hold phone to ear and follow instructions” will be displayed and you will hear “Now training control words. Please say the word yes”.
3. Say “Yes”. You will hear “Again”. Say “Yes” again. You will hear “Training word successful”.
NO
Use to train or untrain the Voice Recognition with the control word, “No”.
1. Press [MENU] .
2. “Please hold phone to ear and follow instructions” will be displayed and you will hear “Now training control words. Please say the word no”.
Page 90 - Chapter 5
3. Say “No”. You will hear “Again”. Say “No” again. You will hear “Training word successful”.
Chapter 5 - Page 91
VOICE TOOLS
VOICE TOOLS
VOICE TOOLS
VOICE TOOLS
WAKE-UP
Use to train or untrain the Voice Recognition with the control word, “Wake-Up”.
1. Press [MENU] .
2. “Please hold phone to ear and follow instructions” will be displayed and you will hear “Now training control words. Please say the word wake-up”.
3. Say “Wake-up”. You will hear “Again”. Say “Wake-up” again. You will hear “Training word successful”.
UNDO TRAIN ALL
Undo Train All erases all “trained” words.
1. Press [MENU] .
2. “Undo voice recognition for all procedures?” will be displayed. To undo all trained words, press
[OK].
VOICE SETTING
After turning on Set Active, open the flip to go on to VR mode. After turning on HFK mode, put Hands-free kit and say “wake up” to go on to VR mode.
SET ACTIVE
Set Active allows the user to activate or deactivate voice dial service.
1. Press [MENU] and select “Set Active”.
2. Select “Active Flip” or “Send Key” with the Navigation Key.
3. To save, press [OK].
HFK MODE
HFK Mode activates or deactivates the voice recognition function while using the Hands Free Kit.
1. Press [MENU] and select “HFK Mode”.
2. Select “On” or “Off” with the Navigation Key.
Page 92 - Chapter 5
3. To save, press [OK].
Chapter 5 - Page 93
SCHEDULE
SCHEDULE
SCHEDULE
SCHEDULE
Sets a scheduled plan and reminds you of that plan.
ADD NEW PLAN
1. Press [MENU] .
2. Move the Navigation Key left, right, up or down to choose a date in the calendar then press [OK].
3. To select plan options, press the Navigation Key downwards.
DATE
Use the key pad to change or enter the date, then press [OK].
TIME
Use the key pad to set a time and to select “AM” or “PM”, then press [OK].
PLAN
Use the key pad to input a plan message, then press [OK].
SETTING
Select an alert time interval option (On Time, 10 Min Before, 30 Min Before, 1 Hour Before, No Alarm) using the Navigation Key.
4. To save it, press [SAVE] or [CLR] to return to the calendar.
5. The date of the Schedule will be marked on your calendar.
VIEW PLAN LIST
1. Press [MENU] .
2. Move the Navigation Key to choose an event and press [OK] or [ERASE]. Press [MENU], then select “Erase All” using the Navigation Key.
RINGER
To set a Ringer, press [MENU], then select “Default” or “Change” using the Navigation Key. To save it press
[OK].
Default: To set default ringer type.
Change: To set custom ringer type.
Page 94 - Chapter 5
Chapter 5 - Page 95
ALARM
ALARM
ALARM
ALARM
You can set up to 3 alarms.
1. To display alarm entries, press [MENU] .
2. Select one of the entries using the Navigation Key. To set a new alarm, choose alarm 1, 2 or 3. To edit an existing alarm, select that alarm. Press [OK].
3. To select alarm options, press the Navigation Key down.
SETTING
Use the Navigation Key to select a setting for the alarm (Once, Daily, Weekly, Monthly, Off).
DATE
Use the key pad to change or enter the date for the alarm then press [OK].
Once: Enter a date.
Daily: Select a time.
Weekly: Select “Monday”, “Tuesday”, “Wednesday”,
“Thursday”, “Friday”, “Saturday”, “Sunday”.
Monthly: Select 1 ~31.
Off
RINGER
To set a “Ringer” press [MENU], then select “Default” or “Change” with Navigation Key. To save it press
[OK].
Default: To set default ringer type.
Change: To set custom ringer type.
PLAN
Edit alarm message with key pad, then press [OK].
4. To save an alarm setting press [SAVE].
TIME
Use the key pad to set a time for the event and to select “AM” or “PM” then press [OK].
SNOOZE
Use the Navigation Key to select a Snooze setting (Off, 1 time after 5 min, 1 time after 10 min, 3 times by 5 min).
Page 96 - Chapter 5
Chapter 5 - Page 97
MEMO P
MEMO P
AD
AD
MEMO P
MEMO P
AD
AD
Your phone includes an internal memo pad that can be used to compose and store reminders and notes.
ADD MEMO
To compose a memo (there is an 80-letter limit):
1. Press [MENU] .
2. Input a new text memo.
(Please refer to page 37 for more details on entering letters, numbers and symbols.)
3. To save, press [OK].
VIEW MEMO
To view a saved memo:
1. 1.1. Press [MENU] .
1.2. To erase a memo, press [ERASE].
1.3. To add a new memo, press [MENU]
“New Memo”.
SETTINGS
To select memo pad background image:
1. Press [MENU] .
2. Select “Drop”, “Sky”, “Snow”, “Candy”, or “Pattern”, then press [OK].
1.4. To erase all memos, press [MENU] “Erase All”.
2. The list of all memos, in saved order, is displayed. Select a memo and press [OK].
3. The selected memo will appear. To edit it, press
[MENU], select “Edit” and input a new text memo.
Page 98 - Chapter 5
Chapter 5 - Page 99
CALCULA
CALCULA
TOR
TOR
WORLD CLOCK
WORLD CLOCK
To access the calculator:
1. Press [MENU] .
2. Follow the instructions below to calculate 8*6/4-2.5
Input 8. Move the Navigation Key to the right. Input 6 then press the Navigation Key to the left. Input 4 then press the Navigation Key down. Input 2 then press to input dot (.). Press 5. Then press and you will see the answer.
3. To reset, press [RESET].
NOTE: : , : , : , : , : ,
: Reset, : .
To display the time and date in pre-programmed cities:
1. Press [MENU] .
2. Select a city.
3. The world map appears with the city, its date and time.
Use the Navigation Key to select another city.
NOTE: As the daylight saving time is not applied, it may
be different from the actual time during DST.
Page 100 - Chapter 5
Chapter 5 - Page 101
STOP WAA
STOP W
TCH
TCH
CAMERA (USE CAMERA)
CAMERA (USE CAMERA)
Simultaneously times up to six different events. To operate the stop watch:
1. Press [MENU] .
2. To measure a time period:
1. To start the stop watch, press [START].
2. To pause it, press [STOP].
3. To resume it press [RESET], to return to the previous page, press [EXIT].
3. To time up to six events at once:
1. To start, press [START].
2. To stop a time period and continue measuring another one, press [CONT].
3. To stop the second and continue measuring a third one, press [CONT].
4. To measure up to six time periods, repeat the above steps.
5. To stop the stop watch, press [STOP].
6. To review the results, press [VIEW].
7. To return to the stop watch, press [OK].
8. To reset it, press [RESET].
When the phone is open, taking pictures with your phone’s built-in camera is as simple as choosing a subject, pointing the lens, and pressing a button. You can activate the Camera Mode and take pictures or take videos.
GETTING READY
1. Camera is located on the back of CDM8940 and protected by sliding cover. Please open the cover to expose camera.
2. Camera angle can be adjusted by sliding a button
on the side of CDM8940. This unique feature of the CDM8940 gives you more flexibility and diverse angles for your convenience.
Page 102 - Chapter 5
Chapter 5 - Page 103
CAMERA (USE CAMERA)
CAMERA (USE CAMERA)
CAMERA (USE CAMERA)
CAMERA (USE CAMERA)
TAKING A PICTURE FROM THE MENU
1. Press [MENU] or press and hold the right side camera button, then press .
2. Press [OK] or the right side camera button to take the picture.
3. To save the picture, press [SAVE].
To go back to idle mode without saving the picture,
press . To send the picture to someone, press [SEND]. Please refer to page 117 for more details on
“New Pix Msg”.
If you receive an incoming call while taking a picture, the camera mode will turn off. You may not receive a warning before the incoming call.
ZOOM Control: zoom in/ zoom out
Resolution Control: / .
To select a resolution for a picture. (960X1280/768X1024/480X640/
240X320/144X176/120X160)
TAKING A PICTURE IN IDLE MODE
1. To activate Camera Mode, press the right side camera button.
2. To take the picture, press [OK] or the right side camera button.
3. To save the picture, press [SAVE].
To go back to idle mode without saving the picture,
press . To send the picture to someone, press [SEND]. Please refer to page 117 for more details on
“New Pix Msg”.
If you receive an incoming call while taking a picture, the camera mode will turn off. You may not receive a warning before the incoming call.
ZOOM Control: zoom in/ zoom out
Resolution Control: / .
To select a resolution for a picture. (960X1280/768X1024/480X640/
240X320/144X176/120X160)
Page 104 - Chapter 5
Chapter 5 - Page 105
CAMERA (USE CAMERA)
CAMERA (USE CAMERA)
CAMERA (
CAMERA (
AKE FLIX)
TTAKE FLIX)
CAMERA MODE OPTIONS
To access the camera mode options, press [MENU].
Self Portrait: Take a picture of yourself by checking the view
Flash: To activate the flash function.
Self Timer: To activate the camera’s timer function.
Add Frames: Select your favorite fun picture frame to
Image Controls:
1. Brightness : Press (0~+2) or press (0~-2) to
2. White Balance : To select a white tone balance.
Pix Effect: To select picture effects.
Quality: To select a picture quality. (High/Medium/Low)
Shutter Sound: To select a shutter sound.
Save Location: To select a save location. (Phone/SD Card)
To enter Review Mode, p
on the Sub LCD.
(Off/Auto Flash/Always On/On This Shot)
(Off/5 Secs/10 Secs)
decorate your picture.
(Flower/Mask/Sweet Heart/Fist-Punch/
Sports/Stars/Candle/Event/Roses/Lips/ Sea/Sky/Snowman/Tropics/Window)
select brightness control.
(Auto/Sunny/Tungsten/Fluorescent)
(Normal/Gray/Sepia/Negative)
(Off/Sound 1/Sound 2)
This menu appears only when connecting mini SD Card.
ress [GALLERY].
From there you can view the captured pictures, view a running count of stored pictures and more.
1. Press [MENU] or press and hold the right side camera button then press .
2. Point the camera lens at your subject. You can check the picture framing through the main display screen.
3.1 To take the video, press [REC].
3.2 To pause/resume the video record,
press [PAUSE/RESUME].
3.3 To stop recording, press [STOP].
4.1 To save the video, press [SAVE].
4.2 To replay video, press [REPLAY].
4.3 To send flix message, press [SEND].
Please refer to page 119 for more details on “New Flix Msg”.
4.4 To return to picture mode, press .
If you receive an incoming call while taking a picture, the camera mode will turn off. You may not receive a warning before the incoming call.
ZOOM Control: zoom in/ zoom out
Page 106 - Chapter 5
Chapter 5 - Page 107
CAMERA (
CAMERA (
AKE FLIX)
TTAKE FLIX)
CAMERA (
CAMERA (
PIX GALLERY)Y)
PIX GALLER
CAMERA MODE OPTIONS
To access the camera mode options, press [MENU].
Self Portrait: Take a video of yourself by checking the view
Movie Light: To activate the movie flash function.
Self Timer: To activate the camera’s timer function.
Brightness: Press (0~+2) or press (0~-2) to select
White Balance: To select a white tone balance.
Mute(Unmute): Phone is mute while recording a video.
Save Location: To select a saved location. (Phone/SD Card)
To enter Review Mode, p
on the Sub LCD.
(Off/Always On)
(Off/5 Secs/10 Secs)
brightness control.
(Auto/Sunny/Tungsten/Fluorescent)
This menu appears only when connecting mini SD Card.
ress [GALLERY].
From there you can view the captured video, view a running count of stored video and more.
1. Press [MENU] or press and hold the right side camera button then press .
2. In Review Mode, you can view all the pictures you have taken and stored.
3. Select photo image with the Navigation Key then press [OK].
4. To send pix message, press [SEND].
Please refer to page 117 for more details on “New Pix Msg”.
PIX GALLERY OPTIONS
To access the in pix options, press [MENU].
Edit Title: To edit the picture’s title.
Assign: To assign the picture image.
(Wallpaper/Pix Caller ID/Screen Saver/Incoming Call)
Take New Pix: To return to Camera mode to take another picture.
Move to SD Card: To move the selected picture to the other
save location.
Go to SD Card: To switch save location from pictures to the
phone list or SD Card.
Erase: To erase selected pictures.
Information: To display picture information such as
resolution, picture quality, file size, etc.
Page 108 - Chapter 5
NOTE: “Move to SD Card”, “Go to SD Card” menu
appears only when you connect the mini
Chapter 5 - Page 109
SD Card.
CAMERA (
CAMERA (
FLIX GALLERY)Y)
FLIX GALLER
CAMERA (
CAMERA (
HELP)
HELP)
1. Press [MENU] or press and hold the right side camera button then press .
2. In “Flix Gallery”, list you can view all the videos you have recorded.
3. Select record video with the Navigation Key then press [OK].
4. To send flix message, press [SEND].
Please refer to page 119 for more details on “New Flix Msg”.
FLIX GALLERY OPTIONS
To access the in video options,
Playback: To play back the video you just took.
Edit Title: To edit the video’s title.
Take New Flix: To return to Video mode to take another
video.
Move to SD Card: To move the selected video to the other save location.
Go to Downloads: To switch save location from videos to the phone list or Downloads.
Go to SD Card: To switch save location from videos to the
phone list or SD Card.
Erase: To erase the video you just took.
Information: To display video information such as resolution,
time/date, size, etc.
press [MENU].
1. Press [MENU] or press and hold the right side camera button then press .
NOTE: “Move to SD Card”, “Go to SD Card” menu
appears only when you connect the mini
Page 110 - Chapter 5
SD Card.
Chapter 5 - Page 111
MEMO
MEMO
Chapter 6
VOICE MAIL AND TXT,
PIX, FLIX
MESSAGES
This chapter addresses checking voice mail messages, as well as sending and receiving TXT, Pix or Flix messages.
When a New Message Arrives New MSG Inbox Sent Web Alerts Draft Quick Text Erase All Settings
Page 112 - Chapter 5
Chapter 6 - Page 113
WHEN A NEW MESSAGE ARRIVES
WHEN A NEW MESSAGE ARRIVES
NEW MSG
NEW MSG
TXT, PIX, FLIX MESSAGE
1. The following display appears when
a new message arrives.
2. To display the message,
press [READ].
VOICE MAIL
Displays the number of voice mails. You can access them by pressing .
To access your voice mail,
1.
p
ress [MENU]
or press .
NEW TXT MSG
To send a new message:
1.
ress [MENU] or press .
P
2. Under “Send To”, input the phone number and press [OK].
By pressing [MENU], the user can choose from the following:
1. Find: Allows the user to search the phone number which is
2. Save to Contact: Stores the phone number the message
3. Msg Group: Allows the user select all the phone numbers
3. Under “Message”, input a new TXT message and press [OK]. (Please refer to page 37 for more details on entering
letters, numbers and symbols.)
By pressing [MENU], in the message input screen you can choose from the following:
1. Insert Quick Text: Inserts pre-programmed Text into a
2. Insert Sound: Inserts sound in TXT Msg.
3. Insert Picture: Inserts picture in TXT Msg.
4. Insert Animation: Inserts Animation in TXT Msg.
5. Save to Quick Text: Saves the written sentences into
stored in the phone book.
was sent to.
in a “Msg Group”.
Text Msg.
Quick Text.
Page 114 - Chapter 6
4. Press the Navigation Key down for more fields. Under “Default CB#”, Select “No” or “Yes”. If select “Yes”. The default call back number is automatically inputted into the Default CB# field.
You can scroll to the number and edit it or simply
press [OK].
Chapter 6 - Page 115
NEW MSG
NEW MSG
NEW MSG
NEW MSG
5. Under “Priority”, select “Normal” or “Urgent”.
6. Under “Insert Signature”, select “On” or “Off”.
7. To send the text message, press [MENU] and select the “Send”, then press [OK].
To save the text message, press [MENU],
select “Save Msg”, then press [OK].
NEW PIX MSG
To send a new picture message:
1.
ress [MENU] or press .
P
2. Under “Send To”, input the phone number and press [OK].
By pressing [MENU], the user can choose from the following:
1. Find: Allows the user to search for a number stored in
2. Save to Contact: Stores the phone number the message
3. Msg Group: Allows the user select all the phone numbers
4. Online Album: Upload pictures using digital album.
3. Under “Message”, input a message text and press [OK].
By pressing [MENU], the user can choose from the following:
1. New Pix: To take a new photo.
2. Saved Pix: To insert a saved photo.
3. Delete Pix: Delete an existing photo.
4. Voice Record: To record a voice memo.
5. Insert Quick Text: Inserts pre-programmed text into a
6. Insert Sound: Inserts sound in pix Msg.
7. Insert Slide: Insert other pix messages
8. Slide Duration: To select a slide duration time.
the phone book.
was sent to.
in a “Msg Group”.
(Pix Place/Digital Album)
Pix Msg.
(To insert a maximum of 3 picture message).
Page 116 - Chapter 6
Chapter 6 - Page 117
NEW MSG
NEW MSG
NEW MSG
NEW MSG
4. Under “Subject”, input a subject text and press [OK]. (Please refer to page 37 for more details on entering
letters, numbers and symbols.)
5. To send a message to another person, select “CC” or “BCC”, input the phone numbers, then press [OK].
6. Press the Navigation Key down for more fields. Under “Priority”, select “Normal” or “High”.
7. Under “Insert Signature”, select “On” or “Off”.
8. To send the pix message, press [MENU], select “Send” then press [OK].
To preview the written pix message, press
[MENU], select “Preview” then press [OK].
To save the pix message, press [MENU],
select “Save Msg” then press [OK].
NEW FLIX MSG
To send a new video message:
1.
ress [MENU] or press .
P
2. Under “Send To”, input the phone number and press [OK].
By pressing [MENU], the user can choose from the following:
1. Find: Allows the user to search the phone number which is
2. Save to Contact: Stores the phone number the message
3. Msg Group: Allows to select all the phone numbers in a
4. Online Album: Upload video clips using digital album.
3. Under “Message”, input the message text and press [OK].
By pressing [MENU], the user can choose from the following:
1. New Flix: To take a new video.
2. Saved Flix: To insert a saved video.
3. Delete Flix: Delete an existing video.
4. Insert Quick Text: Inserts pre-programmed text into a
stored in the phone book.
was sent to.
“Msg Group”.
(Pix Place/Digital Album)
Flix Msg.
Page 118 - Chapter 6
Chapter 6 - Page 119
NEW MSG
NEW MSG
INBOX
INBOX
4. Under “Subject”, input a subject text and press [OK]. (Please refer to page 37 for more details on entering
letters, numbers and symbols.)
5. To send a message to another person, select “CC” or “BCC”, input the phone numbers, then press [OK].
6. Press the Navigation Key down for more fields. Under “Priority”, select ‘“Normal” or “High”.
7. Under “Insert Signature”, select “On” or “Off”.
8. To send the flix message, press [MENU], select “Send” then press [OK].
To preview the written flix message, press
[MENU], select “Preview” then press [OK].
To save the flix message, press [MENU],
select “Save Msg” then press [OK].
The Inbox manages received messages. To access:
1.
Press [MENU] or press .
2. Select a message then press [OK]. The message is displayed. To delete a message, press [ERASE].
3.
Press [MENU].
Menu options include:
PIX/FLIX INFO
1. To show received pix/flix message information.
PLAY FLIX
1. To play received flix message, select “Play Flix”.
Please refer to page 111 for more details on “Camera (HELP-Flix Play Mode)”.
REPLY
1. Type your reply then press .
“Pix/flix Info” menu only appears when you receive
a “Pix” or “Flix” message.
“Play Flix” menu only appears when you receive a flix
message.
Page 120 - Chapter 6
Chapter 6 - Page 121
INBOX
INBOX
INBOX
INBOX
REPLY WITH COPY
1. To reply to a received message and include the received message into the message.
2. To send the text message, press [MENU], then select “Send” then press [OK].
3. To save the text message, press [MENU], then select “Save Msg” then press [OK].
FORWARD
1. To forward the text message, select “Forward”.
2. Input the phone number of the person you are sending the message to then press [OK].
3. Input any text message to go along with the forwarded message, then press [OK].
4. To send the text message, press [MENU], then select “Send” then press [OK].
SAVE MEDIA
1. Saves an object to the media gallery folder.
“Reply with Copy” menu only appears when you
receive a text message.
“Save Media” menu only appears when you receive
a “Pix” or “Flix” message.
SAVE TO CONTACT
1. To save the number to contacts, select “Save to Contact”.
SAVE TO Q.TEXT
1. To save received text msg to “Quick Text”, select “Save to Q.Text”.
BLOCK SENDER
To block the currently viewed message from the phone number or email address of the sender.
1. Select to block a incoming message from
addresses on block list.
LOCK (UNLOCK)
1. Select “Lock” to lock the message or “Unlock” to unlock the message, then press [OK].
PLAY SLIDE SHOW
1. To play all slides in a slide show from a pix/flix message. Depending on the settings, the phone may also display message (Default-5 seconds). Please refer to page 125 under Note.
Page 122 - Chapter 6
Chapter 6 - Page 123
SENT
SENT
SENT
SENT
Manages sent text messages or messages waiting to be sent.
1.
Press [MENU] or press .
2.1. Select a message, then press [OK]. The text message is displayed.
2.2. To Erase Message, press [ERASE].
3. Press [MENU].
RESEND
1. To resend a text message.
EDIT MESSAGE
1. To send a message to another person:
2. Input a text message then press [OK].
3. You can edit or add phone numbers to send the
message to, then edit the default CB#, Priority, and Insert fields. Press [MENU] then “Send” to send the message.
LOCK & UNLOCK
1. Select “Lock” to lock the message or “Unlock” to unlock the message, then press [OK].
STATE
1. To display the status of a sent message.
PIX/FLIX INFO
1. To show pix or flix message information.
PLAY SLIDE SHOW
1. To play all slides in a slide show from a pix/flix message. There is a 5 second interval between slides.
NOTE: While receiving Pix Msg with 2 pages of slides,
Play Slide Show menu substitutes the right softkey and Play Slide Show menu disappears from the menu.
SAVE TO CONTACT
1. To save number to contacts, press [OK].
Page 124 - Chapter 6
Chapter 6 - Page 125
WEB ALER
WEB ALER
TS
TS
DRAFT
DRAFT
WEB ALERTS
1. Press [MENU] or press .
2. To select “GoTo”, press .
To select “Erase Message”, press
The text message will be displayed.
3.
: Read Message.
V
: Unread Message.
: Displays the remaining text.
GoTo : Connecting Selected Site.
Erase : Erase Selected Message.
.
DRAFT
Draft Folder contains any draft messages or saved messages. If message composition is interrupted by a voice call or other interrupting event, the text of the current composition is automatically saved to the draft folder.
1.
Press [MENU] or press .
2.1. Select a message, then press [OK].
The text message is displayed.
2.2. To Erase Message, press [ERASE].
2.3. To Edit Message, press [EDIT].
3. Press [OK]
.
Page 126 - Chapter 6
Chapter 6 - Page 127
QUICK TEXT
QUICK TEXT
ERASE ALL
ERASE ALL
QUICK TEXT
To view/edit the Quick Text messages:
1. Press [MENU] or press .
2.1. Select a Quick Text message from the list. Press [MENU].
2.2. To add a new Quick Text message, press
[ADD NEW]. To edit the Quick Text message you have selected, press [EDIT].
3.
To erase the saved Quick Text message,
press
[ERASE].
ERASE MESSAGES
1. Press [MENU] or press .
2.1. To erase all folder messages, press .
2.2. To erase all inbox messages, press .
Old inbox: To erase messages already read.
Entire inbox: To erase all messages.
2.3. To erase all the sent messages, press .
2.4. To erase the draft messages, press .
2.5. To erase the web alerts messages, press .
3.
Select “Ok” or “Cancel” with [OK] or [CANCEL].
NOTE: The locked Message(s) will not be deleted.
Page 128 - Chapter 6
Chapter 6 - Page 129
SETTINGS
SETTINGS
SETTINGS
SETTINGS
Manages messaging settings through various features.
AUTO SAVE
Select if you want to automatically save a message after sending it.
1. Press [MENU] or press .
Press “Auto Save”.
2. Select “Off”, “On”, or “Prompt” with the Navigation Key.
3. Press [OK].
AUTO ERASE
Automatically erases inbox messages when already read messages.
1. Press [MENU] or press .
Press “Auto Erase”.
2. Select “Disable” or “Enable” with the Navigation Key.
3. Press [OK].
AUTO RECEIVE
Select if you want to automatically retrieve a message as soon as you receive it.
ress [MENU] or press .
1. P
Press “Auto Receive”.
2. Select “Automatic” or “Prompt” with the
Navigation Key.
3. Press [OK].
NOTE: “Auto Receive” menu only use when you
receive a “Pix”, “Flix” or “Push” message.
DEFAULT CB#
Edits a default call back number so that the recipient can call back or reply.
1. Press [MENU] or press .
Press “Default CB#”.
2. Input a call back number, then press [OK].
Press [FIND] to find a number from the phone book.
NOTE: The locked Message(s) will not be deleted.
Page 130 - Chapter 6
VOICE CB#
1. Press [MENU] or press .
Press “Voice CB#”.
2. Input a voice call back number, then press [OK].
Chapter 6 - Page 131
SETTINGS
SETTINGS
SETTINGS
SETTINGS
REMIND
When “Remind” is set, CDM8940 periodically alerts the user until all the received messages are checked by the user.
1. Press [MENU] or press .
Press “Remind”.
2. Select “On” or “Off” with the Navigation Key.
3. Press [OK].
NOTE: When an SMS message is received. If you do not
press any key, your phone sends a reminder at 2 minute intervals.
SIGNATURE
Create a signature that can automatically be inserted at the end of a message.
1. Press [MENU] or press .
Press “Signature”.
2. To input, put the cursor on Edit Signature then enter
Signature Edit window by using right or left direction keys.
3. To activate Signature function, put the cursor on
“Insert” then select “On” by using right or left direction
keys. To inactivate Signature function, select “Off”.
DIRECT VIEW
If the Direct View is set to on, the user will be able to view the message by pressing the read key. If the Direct View is set to off, the user can view the message by entering SMS Menu-> Inbox.
1. Press [MENU] or press .
Press “Direct View”.
2. Select “Off” or “On” with the Navigation Key.
OFF: Read msg after entering inbox in SMS menu.
ON: Read msg without entering inbox in SMS menu.
3. Press [OK].
ENTRY MODE
Sets an Entry Mode as a default. The T9 mode indicator will appear whenever the input mode is activated if the T9 mode is the default.
1. Press [MENU] or press .
Press “Entry Mode”.
2. Select “Alpha Mode” or “T9 Mode” with the
Navigation Key.
3. Press [OK].
Press [OK].
4.
Page 132 - Chapter 6
Chapter 6 - Page 133
SETTINGS
SETTINGS
BLOCK OR UNBLOCK
To block all incoming messages from the phone number or email address of the sender.
1. Press [MENU] or press .
Press “Block or Unblock”.
Chapter 7
2. Select “Block”, “Unblock”, or “View List of Blocked
Addresses” with the Navigation Key.
3. Press [OK].
GET IT NOW &
INTERNET
This chapter addresses using your handset to access the Wireless Internet.
Get It Now Starting Internet Browser Browser Menu
Page 134 - Chapter 6
Chapter 7 - Page 135
GET IT NOW
GET IT NOW
GET IT NOW
GET IT NOW
Your phone provides a unique feature -Get It Now- that enables you to download melody ringtones, wallpapers, games and more from your network to your phone. Please contact your service provider for the availability of these services.
STARTING GET IT NOW
1. To launch “Get It Now” from the standby mode,
press [MENU] or .
2. When three or more icons appear on the screen, select an application with the Navigation Key.
3. To start the application,
4. To end the application, press . The phone will return to the standby mode.
press .
DOWNLOADING APPLICATIONS
1. Press [MENU] or .
2. Select “Start” with the Navigation Key then press .
3. The phone will access your service provider’s server. Follow the prompt to download applications.
DOWNLOADING MELODIES/WALLPAPERS
Before downloading melody ringtones and wallpapers, you need to download the dedicated downloader. Please contact your service provider for details.
APPLYING MELODIES/WALLPAPERS
Downloaded melody ringtones apply to several functions including the incoming call alert, new text message alert, alarm clock and scheduler alarm. Downloaded wallpapers apply to the standby mode.
CHECKING DATA FOLDER MEMORY
Downloaded melody ringtones, wallpapers and applications are saved to the data folder in your phone.
1. Press [MENU] or .
2. Select “Settings” with Navigation Key and press .
3. Select “Manage Apps” with Navigation Key and press .
4. To exit, press .
To select an option, press then press .
When a prompt appears, press to proceed or
to cancel.
Page 136 - Chapter 7
Chapter 7 - Page 137
GET IT NOW
GET IT NOW
GET IT NOW
GET IT NOW
ERASING AN APPLICATION
1. Press [MENU] or .
2. Select “Settings” with Navigation Key and press .
3. Select “Manage Apps” and press .
4. Select the application to be erased with Navigation key then press .
5. Select “Remove” then press .
6. Select “YES” then press .
VIDEO CLIPS
Video Clips brings the world to your mobile phone with full-motion video and sound. Catch up with what’s happening with Video Clips from news, entertainment, sports or weather.
BROWSING, SELECTING AND PLAYING VIDEO CLIPS
1. Press [MENU] or .
2. Select “vzw media player” with Navigation Key and press .
3. Press Navigation Key Left or Right to view Video Clip categories including News, Entertainment, Sports and Weather.
4. Select content provider, press .
Page 138 - Chapter 7
5. If applicable, Select sub category, press .
Chapter 7 - Page 139
GET IT NOW
GET IT NOW
GET IT NOW
GET IT NOW
TO VIEW A STREAMING VIDEO
1. Press [MENU] or .
2. Select “Video Clips” with Navigation Key and press .
3. Read the description of the video clip, and select one you want to view.
4. Select Yes to accept changes.
5. The video clip will begin playback shortly after being selected.
DOWNLOADING A VIDEO CLIP
1. Read the description of the video clip and press Options.
2. Select Save Video and press .
3. Select Yes to accept the charges.
Press and the Video Clip will begin to download.
4. Once video is downloaded, a message will appear on your phone, “Download Complete. Play video now?”
5. Select Yes and press to view video.
DELETING VIDEO CLIPS
1. Press for “GET PIX & FLIX”.
2. Select Video Clips and press .
3. Press Options.
4. Select My Clips and press .
5. Select to Erase Video.
6. Press Options and select Erase and press .
7. Select Yes and press to erase video.
CONFIGURE ALERTS FOR NEW VIDEO CLIPS
1. From Video Clips Catalog, select category of content desired.
2. Select Content Provider.
3. Select Options by pressing .
4. Select Alerts.
6. The video clip will automatically be saved in My Clips and the Flix Gallery.
All videos are not downloadable. Only videos that have the option to save can be downloaded. Additional charges for each video clip viewed may apply. Video Clips service is not available in all areas. Check www website for details.
.verizonwireless.com/getitnow/videoclips
5. Click down to Configure Alerts and select .
6. Select content for alerts desired and select to save.
NOTE: Fees apply for text messages/alerts both sent and
received.
Chapter 7 - Page 141Page 140 - Chapter 7
ST
ST
AR
TING INTERNET BROWSER
AR
TING INTERNET BROWSER
BROWSER MENU
BROWSER MENU
LAUNCHING MOBILE WEB 2.0
Now you can access news, sports, weather, and e-mail from your CDM8940. Mobile Web 2.0 keeps you updated by providing access to up-to-date information such as news, sports, weather and stock quotes when you subscribe to Internet service with your service provider. Please contact your service provider for a list of available websites and service details.
1. To start your Internet browser and access websites through your wireless handset press [MENU]
or press .
BROWSER MENU
BROWSER MENU
BROWSER MENU
The browser menu lists the actions necessary to operate the browser. To access the browser menu, press [MENU] , or press then press [MENU].
VZW HOME
When the home item is selected from the browser menu, the phone displays the home page.
To display the homepage, press [MENU] then
press .
BACK
To return to the previous page, press [MENU]
then press .
FOR
WARD
To forward to the next page, press [MENU]
then press .
REFRESH
Selecting the refresh item from the browser menu refreshes the current page.
To select “Refresh”, press [MENU] then press .
HISTORY
When the history item is selected from the browser menu, the browser is displayed with the browser version and copyright information. The device layer version is also displayed.
To select “History”, press [MENU] then press .
ADDRESS
Selecting the “Address” action displays the URL of the current page.
To select “Address”, press [MENU] then press .
Chapter 7 - Page 143Page 142 - Chapter 7
BROWSER MENU
BROWSER MENU
CLEAR MEMORY
To clear browser memory, press [MENU]
then press .
SETTINGS
To select “Settings”, press [MENU] then press .
Chapter 8
Downloads
Restart Browser
Scroll Mode
Send Referrer
Key Press Timeout
Connection Timeout
ADVANCED
Selecting the advanced item in the browser menu displays the advanced menu items.
To select “Advanced”, press [MENU]
then press .
About...
Encryption: 1. Authentication
2. Root Certificate
3. Current Certificate
EXIT
To exit browser, press [MENU] then press .
SAFETY
INFORMATION
Safety Information for Wireless Handheld Phones Safety Information for FCC RF Exposure SAR Information FDA Consumer Update
Page 144 - Chapter 7
Chapter 8 - Page 145
SAFETY INFORMA
SAFETY INFORMA
WIRELESS HANDHELD PHONES
WIRELESS HANDHELD PHONES
TION FOR
TION FOR
SAFETY INFORMA
SAFETY INFORMA
WIRELESS HANDHELD PHONES
WIRELESS HANDHELD PHONES
TION FOR
TION FOR
Read This Information Before Using Your Handheld
Portable Cellular Telephone
EXPOSURE TO RADIO FREQUENCY SIGNALS
Your wireless handheld portable telephone is a low power radio transmitter and receiver. When it is ON, it receives and also sends out radio frequency (RF) signals.
In August 1996, the Federal Communications Commissions (FCC) adopted RF exposure guidelines with safety levels for handheld wireless phones. Those guidelines are consistent with the safety standards previously set by both U.S. and inter­national standards bodies:
ANSI C95.1 (1992) * NCRP Report 88 (1986) * ICNIRP (1996) *
Those standards were based on comprehensive and periodic evaluations of the relevant scientific literature. For example, over 120 scientists, engineers, and physicians from universi­ties, government health agencies, and industry reviewed the available body of research to develop the ANSI Standard (C951).
The design of your phone complies with the FCC guidelines (and those standards).
;
˙
American National Standards Institute; National Council on Radiation Protection and Measurements; International Commission on Nonionizing Radiation Protection.
ANTENNA CARE
Use only the supplied or an approved replacement antenna. Unauthorized antennas, modifications, or attachments could damage the phone and may violate FCC regulations.
PHONE OPERATION
Normal Position: Hold the phone as you would any other telephone with the antenna pointed up and over your shoulder.
Tips on efficient operation:
- Extend your antenna fully.
- Do not touch the antenna unnecessarily when the phone is in use. Contact with the antenna affects call quality and may cause the phone to operate at a higher power level than otherwise needed.
DRIVING SAFETY
Talking on the phone while driving is extremely dangerous and is illegal in some states. Remember, safety comes first. Check the laws and regulations on the use of phones in the areas where you drive. Always obey them.
Also, if using your phone while driving please:
- Give full attention to driving. Driving safely is your first responsibility.
- Use hands-free operation, if available.
- Pull off the road and park before making or answering a
call, if driving conditions require.
Page 146 - Chapter 8
Chapter 8 - Page 147
SAFETY INFORMA
SAFETY INFORMA
WIRELESS HANDHELD PHONES
WIRELESS HANDHELD PHONES
TION FOR
TION FOR
SAFETY INFORMA
SAFETY INFORMA
WIRELESS HANDHELD PHONES
WIRELESS HANDHELD PHONES
TION FOR
TION FOR
ELECTRONIC DEVICES
Most modern electronic equipment is shielded from RF energy. However, certain electronic equipment may not be shielded against the RF signals from your wireless phone.
Pacemakers
The Health Industry Manufacturers Association recommends that a minimum separation of six (6”) inches be maintained between a handheld wireless phone and a pacemaker to avoid potential interference with the pacemaker. These rec­ommendations are consistent with the independent research by and recommendations of Wireless Technology Research.
If you have a pacemaker:
l ALWAYS keep the phone more than six inches from
your pacemaker when the phone is turned on.
l Do not carry the phone in a breast pocket.
l Use the ear opposite the pacemaker to minimize the
potential for interference.
l If you have any reason to suspect that interference is
taking place, turn your phone OFF immediately.
Hearing Aids
ELECTRONIC DEVICES
Other Medical Devices
If you use any other personal medical device, consult the man­ufacturer of your device to determine if they are adequately shielded from external RF energy Your physician may be able to assist you in obtaining this information.
Turn your phone OFF in healthcare facilities when any regula­tions posted in these areas instruct you to do so. Hospitals or healthcare facilities may be using equipment that could be sen­sitive to external RF energy.
Vehicles
RF signals may affect improperly installed or inadequately shielded electronic systems in motor vehicles. Check with the manufacturer or its representative regarding your vehicle. You should also consult the manufacturer of any equipment that has been added to your vehicle.
An airbag inflates with great force. DO NOT place objects, including both installed or portable wireless equipment, in the area over the airbag or in the air bag deployment area. If in-vehicle wireless equipment is improperly installed and the air bag inflates, serious injury could result.
Some digital wireless phones may interfere with some hearing aids. In the event of such interference, you may want to consult your service provider (or call the customer service line to discuss alternatives).
Page 148 - Chapter 8
Posted Facilities
Turn your phone OFF where posted notices so require.
Chapter 8 - Page 149
SAFETY INFORMA
SAFETY INFORMA
WIRELESS HANDHELD PHONES
WIRELESS HANDHELD PHONES
TION FOR
TION FOR
SAFETY INFORMA
SAFETY INFORMA
WIRELESS HANDHELD PHONES
WIRELESS HANDHELD PHONES
TION FOR
TION FOR
OTHER SAFETY GUIDELINES
Aircraft
FCC Regulations prohibit using your phone while in the air. Switch OFF your phone before boarding an aircraft.
Blasting Areas
To avoid interfering with blasting operations, turn your phone OFF when in a “blasting area” or in areas posted: “Turn off two­way radio.” Obey all signs and instructions.
Potentially Explosive Atmospheres
Turn your phone OFF when in any area with a potentially explo­sive atmosphere and obey all signs and instructions. Sparks in such areas could cause an explosion or fire resulting in bodily injury or even death.
Areas with a potentially explosive atmosphere are often, but not always, clearly marked. They include fueling areas such as gas stations; below deck on boats; fuel or chemical transfer or stor­age facilities; vehicles using liquefied petroleum gas (such as propane or butane); areas where the air contains chemicals or particles, such as grain, dust, or metal powders; and any other area where you would normally be advised to turn off your vehicle’s engine.
PRECAUTIONS AND WARNINGS
Please read and understand all of the Precautions and Warnings contained in this manual before attempting to oper­ate your phone.
1. DO NOT use this equipment in an extreme environment
where high temperature or high humidity exists, such as near a heater or in a closed car parked in the sun.
2. DO NOT abuse the equipment. Avoid striking, shaking or
shocking. When not using the unit, lay down the unit to avoid possible damage due to instability.
3. DO NOT expose this equipment to liquids such as rain or
spilled beverages.
4. DO NOT use unauthorized accessories. Use of unautho-
rized accessories may result in fire, electric shock or other bodily injury.
5. DO NOT disassemble the phone or its accessories.
If service or repair is required, return the unit to an author­ized Audiovox service center. If unit is disassembled, the risk of electric shock or fire may result.
6. DO NOT short-circuit the battery terminals with metal
items etc.
7. DO NOT use harsh chemicals, cleaning solvents or strong
detergents to clean this phone. Always clean it with a soft, damp cloth.
Page 150 - Chapter 8
8. DO NOT paint this phone. This can clog moving parts.
Chapter 8 - Page 151
SAFETY INFORMA
SAFETY INFORMA
WIRELESS HANDHELD PHONES
WIRELESS HANDHELD PHONES
TION FOR
TION FOR
SAFETY INFORMA
SAFETY INFORMA
FCC RF EXPOSURE
FCC RF EXPOSURE
TION FOR
TION FOR
OPERATING PROCEDURES
Never violate any of the following Rules and Regulations of the FCC when using your phone. The following offenses are punishable by fine, imprisonment, or both:
- Using obscene, indecent, or profane language.
- Using the unit to give off false distress calls.
- Wiretapping or otherwise intercepting a telephone call, unless that person has first obtained the consent of the parties participating in the call.
- Making anonymous calls to annoy, harass, or molest other people.
- Charging to an account without authorization to avoid payment for service.
- Refusing to yield a party line when informed that it is needed for an emergency call (It is also unlawful to take over a party line by stating falsely that it is needed for an emergency).
WARNING! Read this information before using
your phone
CAUTION
In August 1996, the Federal Communications Commission (FCC) of the United States with its action in Report and Order FCC 96-326 adopted an updated safety standard for human exposure to radio fre­quency electromagnetic energy emitted by FCC regulated transmit­ters. Those guidelines are consistent with the safety standard previ­ously set by both U.S. and international standards bodies. The design of this phone complies with the FCC guidelines and these internation­al standards.
Use only the supplied or an approved antenna. Unauthorized anten­nas, modifications, or attachments could impair call quality, damage the phone, or result in violation of FCC regulations.
Do not use the phone with a damaged antenna. If a damaged anten­na comes into contact with the skin, a minor burn may result. Please contact your local dealer for replacement antenna.
Body-worn Operation (Holster Part Number : 2H020665002)
This device was tested with holster (Part No:2H020665002) for body­worn operation with the back of the phone kept 0.59 inchs (15mm) from the body. To comply with FCC RF exposure requirements, a min­imum separation distance of 0.59 inchs (15mm) must be maintained between the user's body and the back of the phone, including the antenna, whether extended or retracted. All belt-clips, holsters and similar accessories used by this device must not contain any metallic components. Body-worn accessories that do not meet these require­ments may not comply with FCC RF exposure limits and should be avoided.
Page 152 - Chapter 8
Note: For more information about RF exposure, please visit the FCC website at www
.fcc.gov.
Chapter 8 - Page 153
SAR
SAR
INFORMA
INFORMA
TION
TION
SAR
SAR
INFORMA
INFORMA
TION
TION
THIS MODEL PHONE MEETS THE GOVERNMENT’S REQUIREMENTS FOR EXPOSURE TO RADIO WAVES.
Your wireless phone is a radio transmitter and receiver. It is designed and manufactured not to exceed the emission limits for exposure to radiofrequency (RF) energy set by the Federal Communications Commission of the U.S. Government. These limits are part of com­prehensive guidelines and establish permitted levels of RF energy for the general population. The guidelines are based on standards that were developed by independent scientific organizations through peri­odic and thorough evaluation of scientific studies. The standards include a substantial safety margin designed to assure the safety of all persons, regardless of age and health.
The exposure standard for wireless mobile phones employs a unit of measurement known as the Specific Absorption Rate, or SAR. The SAR limit set by the FCC is 1.6 W/kg.* Tests for SAR are conducted with the phone transmitting at its highest certified power level in all tested frequency bands. Although the SAR is determined at the high­est certified power level, the actual SAR level of the phone while oper­ating can be well below the maximum value. This is because the phone is designed to operate at multiple power levels so as to use only the power required to reach the network. In general, the closer you are to a wireless base station antenna, the lower the power output.
Before a phone model is available for sale to the public, it must be test­ed and certified to the FCC that it does not exceed the limit established by the government-adopted requirement for safe exposure. The tests are performed in positions and locations (e.g., at the ear and worn on the body) as required by the FCC for each model. The highest SAR value for this model phone when tested for use at the ear is 1.15 W/kg and when worn on the body,
as described in this user guide, is 0.633 W/kg. (Body-worn measure­ments differ among phone models, depending upon available acces­sories and FCC requirements). While there may be differences between the SAR levels of various phones and at various positions, they all meet the government requirement for safe exposure.
The FCC has granted an Equipment Authorization for this model phone with all reported SAR levels evaluated as in compliance with the FCC RF exposure guidelines. SAR information on this model phone is on file with the FCC and can be found under the Display Grant section of http://www.fcc.gov/oet/fccid after searching on FCC ID PP4TX-160C.
Additional information on Specific Absorption Rates (SAR) can be found on the Cellular Telecommunications & Internet Association (CTIA) web-site at http://phonefacts.net.
* In the United States and Canada, the SAR limit for mobile phones used by the public is 1.6 watts/kg (W/kg) averaged over one gram of tissue. The standard incorporates a substantial margin of safety to give additional protection for the public and to account for any variations in measurements.
Page 154 - Chapter 8
Chapter 8 - Page 155
U.S. Food and Drug Administration ­Center for Devices and Radiological Health Consumer Update on Mobile Phones
1. Do wireless phones pose a health hazard?
The available scientific evidence does not show that any health problems are associated with using wireless phones. There is no proof, however, that wireless phones are absolutely safe. Wireless phones emit low levels of radiofrequency energy (RF) in the microwave range while being used. They also emit very low levels of RF when in the standby mode. Whereas high levels of RF can produce health effects (by heating tissue), exposure to low level RF that does not produce heating effects causes no known adverse health effects. Many studies of low level RF exposures have not found any biological effects. Some studies have suggested that some biological effects may occur, but such findings have not been confirmed by additional research. In some cases, other researchers have had difficulty in reproducing those studies, or in determining the reasons for inconsistent results.
2. What is FDA’s role concerning the safety of wireless phones?
Under the law, FDAdoes not review the safety of radiation-emitting consumer products such as wireless phones before they can be sold, as it does with new drugs or medical devices. However, the agency has authority to take action if wireless phones are shown to emit radiofrequency energy (RF) at a level that is hazardous to the user. In such a case, FDA could require the manufacturers of wireless phones to notify users of the health hazard and to repair, replace or recall the phones so that the hazard no longer exists. Although the existing scientific data do not justify FDA regulatory actions, FDA has urged the wireless phone industry to take a num­ber of steps, including the following:
• Support needed research into possible biological effects of RF
of the type emitted by wireless phones;
• Design wireless phones in a way that minimizes any RF expo sure to the user that is not necessary for device function; and
• Cooperate in providing users of wireless phones with the best possible information on possible effects of wireless phone use on human health. FDA belongs to an interagency working group of the federal agen­cies that have responsibility for different aspects of RF safety to ensure coordinated efforts at the federal level. The following agen­cies belong to this working group:
• National Institute for Occupational Safety and Health
• Environmental Protection Agency
• Federal Communications Commission
• Occupational Safety and Health Administration
• National Telecommunications and Information Administration The National Institutes of Health participates in some interagency working group activities, as well. FDA shares regulatory responsibilities for wireless phones with the Federal Communications Commission (FCC). All phones that are sold in the United States must comply with FCC safety guidelines that limit RF exposure. FCC relies on FDA and other health agen­cies for safety questions about wireless phones. FCC also regulates the base stations that the wireless phone net­works rely upon. While these base stations operate at higher power than do the wireless phones themselves, the RF exposures that people get from these base stations are typically thousands of times lower than those they can get from wireless phones. Base stations are thus not the subject of the safety questions discussed in this document.
3. What kinds of phones are the subject of this update?
The term “wireless phone” refers here to handheld wireless phones with built-in antennas, often called “cell,” “mobile,” or “PCS” phones. These types of wireless phones can expose the user to measurable radiofrequency energy (RF) because of the short dis­tance between the phone and the user’s head. These RF expo­sures are limited by Federal Communications Commission safety
Page 156 - Chapter 8
Chapter 8 - Page 157
guidelines that were developed with the advice of FDA and other federal health and safety agencies. When the phone is located at greater distances from the user, the exposure to RF is drastically lower because a person’s RF exposure decreases rapidly with increasing distance from the source. The so-called “cordless phones,” which have a base unit connected to the telephone wiring in a house, typically operate at far lower power levels, and thus pro­duce RF exposures far below the FCC safety limits.
4. What are the results of the research done already?
The research done thus far has produced conflicting results, and many studies have suffered from flaws in their research methods. Animal experiments investigating the effects of radiofrequency energy (RF) exposures characteristic of wireless phones have yielded conflicting results that often cannot be repeated in other laboratories. A few animal studies, however, have suggested that low levels of RF could accelerate the development of cancer in laboratory animals. However, many of the studies that showed increased tumor development used animals that had been geneti­cally engineered or treated with cancer-causing chemicals so as to be predisposed to develop cancer in the absence of RF exposure. Other studies exposed the animals to RF for up to 22 hours per day. These conditions are not similar to the conditions under which people use wireless phones, so we don’t know with certainty what the results of such studies mean for human health. Three large epidemiology studies have been published since December 2000. Between them, the studies investigated any pos­sible association between the use of wireless phones and primary brain cancer, glioma, meningioma, or acoustic neuroma, tumors of the brain or salivary gland, leukemia, or other cancers. None of the studies demonstrated the existence of any harmful health effects from wireless phone RF exposures. However, none of the studies can answer questions about long-term exposures, since the aver­age period of phone use in these studies was around three years.
5. What research is needed to decide whether RF exposure from wireless phones poses a health risk?
A combination of laboratory studies and epidemiological studies of people actually using wireless phones would provide some of the data that are needed. Lifetime animal exposure studies could be completed in a few years. However, very large numbers of animals would be needed to provide reliable proof of a cancer promoting effect if one exists. Epidemiological studies can provide data that is directly applicable to human populations, but 10 or more years’ fol­low-up may be needed to provide answers about some health effects, such as cancer. This is because the interval between the time of exposure to a cancer-causing agent and the time tumors develop - if they do - may be many, many years. The interpretation of epidemiological studies is hampered by difficulties in measuring actual RF exposure during day-to-day use of wireless phones. Many factors affect this measurement, such as the angle at which the phone is held, or which model of phone is used.
6. What is FDA doing to find out more about the possible health effects of wireless phone RF?
FDA is working with the U.S. National Toxicology Program and with groups of investigators around the world to ensure that high priori­ty animal studies are conducted to address important questions about the effects of exposure to radiofrequency energy (RF). FDA has been a leading participant in the World Health Organization International Electromagnetic Fields (EMF) Project since its inception in 1996. An influential result of this work has been the development of a detailed agenda of research needs that has driven the establishment of new research programs around the world. The Project has also helped develop a series of public information documents on EMF issues. FDA and the Cellular Telecommunications & Internet Association (CTIA) have a formal Cooperative Research and Development Agreement (CRADA) to do research on wireless phone safety. FDA provides the scientific oversight, obtaining input from experts in government, industry, and academic organizations. CTIA-fund­ed research is conducted through contracts to independent inves­tigators.
Page 158 - Chapter 8
Chapter 8 - Page 159
The initial research will include both laboratory studies and studies of wireless phone users. The CRADA will also include a broad assessment of additional research needs in the context of the lat­est research developments around the world.
7. How can I find out how much radiofrequency energy exposure I can get by using my wireless phone?
All phones sold in the United States must comply with Federal Communications Commission (FCC) guidelines that limit radiofre­quency energy (RF) exposures. FCC established these guidelines in consultation with FDA and the other federal health and safety agencies. The FCC limit for RF exposure from wireless telephones is set at a Specific Absorption Rate (SAR) of 1.6 watts per kilogram (1.6 W/kg). The FCC limit is consistent with the safety standards developed by the Institute of Electrical and Electronic Engineering (IEEE) and the National Council on Radiation Protection and Measurement. The exposure limit takes into consideration the body’s ability to remove heat from the tissues that absorb energy from the wireless phone and is set well below levels known to have effects. Manufacturers of wireless phones must report the RF exposure level for each model of phone to the FCC. The FCC website (http://www.fcc.gov/oet/rfsafety) gives directions for locating the FCC identification number on your phone so you can find your phone’s RF exposure level in the online listing.
8. What has FDA done to measure the radiofrequency energy coming from wireless phones ?
The Institute of Electrical and Electronic Engineers (IEEE) is devel­oping a technical standard for measuring the radiofrequency ener­gy (RF) exposure from wireless phones and other wireless hand­sets with the participation and leadership of FDA scientists and engineers. The standard, “Recommended Practice for Determining the Spatial-Peak Specific Absorption Rate (SAR) in the Human Body Due to Wireless Communications Devices: Experimental Techniques,” sets forth the first consistent test
methodology for measuring the rate at which RF is deposited in the heads of wireless phone users. The test method uses a tissue­simulating model of the human head. Standardized SAR test methodology is expected to greatly improve the consistency of measurements made at different laboratories on the same phone. SAR is the measurement of the amount of energy absorbed in tis­sue, either by the whole body or a small part of the body. It is meas­ured in watts/kg (or milliwatts/g) of matter. This measurement is used to determine whether a wireless phone complies with safety guidelines.
9. What steps can I take to reduce my exposure to radiofrequency energy from my wireless phone?
If there is a risk from these products—and at this point we do not know that there is—it is probably very small. But if you are con­cerned about avoiding even potential risks, you can take a few sim­ple steps to minimize your exposure to radiofrequency energy (RF). Since time is a key factor in how much exposure a person receives, reducing the amount of time spent using a wireless phone will reduce RF exposure.
• If you must conduct extended conversations by wireless phone
every day, you could place more distance between your body and the source of the RF, since the exposure level drops off dramati­cally with distance. For example, you could use a headset and carry the wireless phone away from your body or use a wireless phone connected to a remote antenna. Again, the scientific data do not demonstrate that wireless phones are harmful. But if you are concerned about the RF exposure from these products, you can use measures like those described above to reduce your RF exposure from wireless phone use.
10. What about children using wireless phones?
The scientific evidence does not show a danger to users of wire­less phones, including children and teenagers. If you want to take steps to lower exposure to radiofrequency energy (RF), the meas­ures described above would apply to children and teenagers using wireless phones. Reducing the time of wireless phone use and
Page 160 - Chapter 8
Chapter 8 - Page 161
increasing the distance between the user and the RF source will reduce RF exposure. Some groups sponsored by other national governments have advised that children be discouraged from using wireless phones at all. For example, the government in the United Kingdom distributed leaflets containing such a recommen­dation in December 2000. They noted that no evidence exists that using a wireless phone causes brain tumors or other ill effects. Their recommendation to limit wireless phone use by children was strictly precautionary; it was not based on scientific evidence that any health hazard exists.
11. What about wireless phone interference with medical equipment?
Radiofrequency energy (RF) from wireless phones can interact with some electronic devices. For this reason, FDA helped devel­op a detailed test method to measure electromagnetic interference (EMI) of implanted cardiac pacemakers and defibrillators from wireless telephones. This test method is now part of a standard sponsored by the Association for the Advancement of Medical instrumentation (AAMI). The final draft, a joint effort by FDA, med­ical device manufacturers, and many other groups, was complet­ed in late 2000. This standard will allow manufacturers to ensure that cardiac pacemakers and defibrillators are safe from wireless phone EMI. FDA has tested hearing aids for interference from handheld wire­less phones and helped develop a voluntary standard sponsored by the Institute of Electrical and Electronic Engineers (IEEE). This standard specifies test methods and performance requirements for hearing aids and wireless phones so that that no interference occurs when a person uses a “compatible” phone and a “compat­ible” hearing aid at the same time. This standard was approved by the IEEE in 2000. FDA continues to monitor the use of wireless phones for possible interactions with other medical devices. Should harmful interfer­ence be found to occur, FDA will conduct testing to assess the interference and work to resolve the problem.
12. Where can I find additional information?
For additional information, please refer to the following resources:
- FDA web page on wireless phones: (http://www.fda.gov/cdrh/phones/index.html)
- Federal Communications Commission (FCC) RF Safety Program: (http://www.fcc.gov/oet/rfsafety)
- International Commission on Non-Ionizing Radiation Protection: (http://www.icnirp.de)
- World Health Organization (WHO) International EMF Project: (http://www.who.int/emf)
- National Radiological Protection Board (UK): (http://www.nrpb.org.uk/)
Page 162 - Chapter 8
Chapter 8 - Page 163
MEMO
MEMO
Chapter 9
WARRANTY
Protect Your Warranty 12 Month Limited Warranty
Page 164 - Chapter 8
Chapter 9 - Page 165
PROTECT YOUR W
PROTECT YOUR W
ARRANTY
ARRANTY
12 MONTH LIMITED W
12 MONTH LIMITED W
ARRANTY
ARRANTY
Read your Warranty carefully, with the special consideration to paragraph seven of the Limited Warranty for your unit.
“Warranty does not apply to... or to any product or part thereof which has suffered through alteration... mishandling, misuse, neglect or accident”.
Many companies are making look alike accessories and in some cases, promoting that their product is equal to or better than the Audiovox product. Be careful. Some of these products may not be compatible to use with your Audiovox product and may damage the unit or cause it to malfunction. If service is required on your unit and it is determined that a non-Audiovox accessory has created the problem with your unit, the Warranty will not apply. In addition, if the unit has already suffered irreversible damage by reason of a non-compatible accessory, the Warranty will be voided. To protect your Warranty, use only compatible interfere
with the functioning of your Audiovox product.
accessories which cannot damage or
UTStarcom/Audiovox Communications (the Company) war­rants to the original retail purchaser of this Audiovox Handheld Portable Cellular Telephone, that should this product or any part thereof during normal consumer usage and conditions, be proven defective in material or workmanship that results in product failure within the first twelve (12) month period from the date of purchase, such defect(s) will be repaired or replaced (with new or rebuilt parts) at the Company’s option, without charge for parts or labor directly related to the defect(s).
The antenna, key pad, display, rechargeable battery and bat­tery charger, if included, are similarly warranted for twelve (12) months from date of purchase.
This Warranty extends only to consumers who purchase the product in the United States or Canada and it is not assignable or transferable.
This Warranty does not apply to:
(a) Product subjected to abnormal use or conditions, accident,
mishandling, neglect, unauthorized alteration, misuse, improper installation or repair or improper storage;
(b) Product whose mechanical serial number or electronic serial
number has been removed, altered or defaced.
UTSTARCOM/AUDIOVOX COMMUNICATIONS
555 Wireless Blvd., Hauppauge, New York 11788, 800-229-1235
16808 Marquardt Avenue, Cerritos, California 90703, 562-802-5100
UTSTARCOM CANADA COMPANY
5155 Spectrum Way, Unit #5, Mississauga, Ontario
Canada L4W 5A1, 800-465-9672
Page 166 - Chapter 9
(c) Damage from exposure to moisture, humidity, excessive
temperatures or extreme environmental conditions;
(d) Damage resulting from connection to, or use of any accessory
or other product not approved or authorized by the Company;
Chapter 9 - Page 167
12 MONTH LIMITED W
12 MONTH LIMITED W
ARRANTY
ARRANTY
12 MONTH LIMITED W
12 MONTH LIMITED W
ARRANTY
ARRANTY
(e) Defects in appearance, cosmetic, decorative or structural
items such as framing and non-operative parts;
(f) Product damaged from external causes such as fire, flooding,
dirt, sand, weather conditions, battery leakage, blown fuse, theft or improper usage of any electrical source.
The Company disclaims liability for removal or reinstallation of the product, for geographic coverage, for inadequate signal reception by the antenna or for communications range or operation of the Cellular System as a whole.
To obtain repairs or replacement within the terms of this Warranty, the product should be delivered with proof of Warranty coverage (e.g. dated bill of sale), the consumer’s return address, daytime phone number and/or fax number and complete description of the problem, transportation prepaid, to the Company at the address shown below or to the place or purchase for repair or replacement processing. In addition, for reference to an authorized Warranty station in your area, you can telephone in the United States (800) 229-1235, and in Canada (800) 465-9672 (in Ontario call 905-712-9299).
THE EXTENT OF THE COMPANY’S LIABILITY UNDER THIS WARRANTY IS LIMITED TO THE REPAIR OR REPLACEMENT PROVIDED ABOVE AND, IN NO EVENT, SHALL THE COMPANY’S LIABILITY EXCEED THE PURCHASE PRICE PAID BY PURCHASER FOR THE PRODUCT.
ANY IMPLIED WARRANTIES, INCLUDING ANY IMPLIED WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE SHALL BE LIMITED TO THE DURATION OF THIS WRITTEN WARRANTY. ANY ACTION FOR BREACH OF ANY WARRANTY MUST BE BROUGHT
WITHIN A PERIOD OF 18 MONTHS FROM DATE OF ORIGINAL PURCHASE. IN NO CASE SHALL THE COMPANY BE LIABLE FOR ANY SPECIAL CONSEQUENTIAL OR INCIDENTAL DAMAGES FOR BREACH OF THIS OR ANY OTHER WARRANTY, EXPRESS OR IMPLIED, WHATSOEVER. THE COMPANY SHALL NOT BE LIABLE FOR THE DELAY IN RENDERING SERVICE UNDER THIS WARRANTY OR LOSS OF USE DURING THE TIME THE PRODUCT IS BEING REPAIRED OR REPLACED.
No person or representative is authorized to assume for the Company any liability other than expressed herein in connection with the sale of this product.
Some states or provinces do not allow limitations on how long an implied warranty lasts or the exclusion or limitation of incidental or consequential damage, so the above limitation or exclusions may not apply to you. This Warranty gives you specific legal rights, and you may also have other rights which vary from state to state or province to province.
IN U.S.A.: UTStarcom/Audiovox Communications
555 Wireless Blvd. Hauppauge, NY 11788 (800) 229-1235
IN CANADA: UTStarcom Canada Company
5155 Spectrum Way, Unit #5 Mississauga, Ontario L4W 5A1 (800) 465-9672
Page 168 - Chapter 9
Chapter 9 - Page 169
Loading...
