Audiovox CDM8940 User Manual

AUDIOVOX

CDM8940

Digital CDMA2000 1X EV-DO Handheld Portable Telephone

Welcome to the world of EVDO!! Developed by top engineers and equipped with Qualcomm MSM6500, CDM8940 supports full EVDO. With CDM8940, you now have the highest speed and the largest bandwidth that supports the most up-to-date data applications and services. Moreover, its intuitive and user friendly GUI brings complicated applications such as web browsing, data services, right at your fingertips. Among its many advanced features, the T9 input mode makes it much easier to enter letters. In addition, the VR (Voice Recognition) makes it more user friendly, with proven technologies including:

Full graphic display of 9 text input lines and 1 icon line with variable font size. Easy to dial through the VR feature. Easy to enter letters through the T9 text input mode. Enhanced for web browsing & data services (i.e.; wireless internet Downloads, WAP browser) GUI & Animation display compliant with CDMA2000 1X. Full graphic main display - 260K color TFT LCD. Mobile Camera (SXGA 1.3 Mega Pixel) Navigation Key and 22 keys aligned for more convenience. Sophisticated features of speaker phone, and voice recognition. Additional services including text messaging, Web browsing on top of authentication, call forwarding, call transfer, call waiting.

Important Information

This CDM8940 user guide contains very important information about how to properly use the phone. So please read this manual thoroughly, pay attention to the warranty on the back page and be alert to the exclusions and limitations of your warranty, which are related to the unauthorized use of components.

Preface

ABLE OF CONTENTS

TTABLE OF CONTENTS

CHAPTER 1 BEFORE USING YOUR PHONE .........7

Inside the Package.................................................8

Handset Description ..............................................9

Function Keys.......................................................10

Display Indicators.................................................11

Using the Battery..................................................13

Installing the Battery ...........................................13

Removing the Battery .........................................13

Charging the Battery ............................................14

Power Connection ...............................................14

Battery Standby Times........................................15

Battery Usage Times...........................................15

Battery Information ..............................................16

Do’s.....................................................................16

Don’ts..................................................................16

CHAPTER 2 BASIC OPERATION...........................17

Using the Phone...................................................18

Turning the Phone On.........................................18

Turning the Phone Off.........................................18

Using the Main Menu ...........................................19

Accessing the Menu............................................19

Menu Summary.....................................................20

Basic Functions....................................................23

Making a Call......................................................23

Pause Feature.....................................................24

Speaker Phone ...................................................24

Answering a Call.................................................25

3-Way Call Function............................................25

Call Waiting Function..........................................26

Adjusting Volume.................................................26

Lock.....................................................................27

Caller ID Function...............................................27

Music Player........................................................27

Functions During a Call.........................................28

Messaging...........................................................28

Mute (Unmute)....................................................28

Table of Contents - Page 1

ABLE OF CONTENTS

TTABLE OF CONTENTS

ABLE OF CONTENTS

TTABLE OF CONTENTS

Scratchpad..........................................................28

Send My Phone # ...............................................29

My Phone #.........................................................29

Voice Privacy.......................................................29

Location...............................................................30

Phone Info...........................................................30

Making an Emergency Call....................................31

911 in Lock Mode................................................31

911 Using Any Available System........................31

Using the mini SD Card .........................................32

Installing the mini SD Card.................................32

Removing the mini SD Card...............................32

CHAPTER 3 MEMORY FUNCTION .......................35

Storing Phone Numbers......................................36

Text Input Methods..............................................37

Entering Characters ............................................37

Alpha Mode [ABC] ..............................................37

Predictive Text Mode [T9TMABC].................38

Numeric Mode [NUM].........................................40

Symbol Mode [SYM]...........................................40

Speed Dialing .......................................................41

Speed Dial..........................................................41

One-Touch/Two-Touch Dialing............................41

Phone Book..........................................................42

Find.....................................................................42

Add New .............................................................43

Group..................................................................44

Msg. Group.........................................................45

My Phone #.........................................................48

Recent Calls .........................................................49

All Calls...............................................................49

Missed Calls .......................................................50

Received Calls ....................................................51

Dialed Calls.........................................................52

Call Timers..........................................................53

1X Packet Counter..............................................56

CHAPTER 4 SETTINGS..........................................57

Settings.................................................................58

Sounds................................................................58

Display................................................................63

Data SVC............................................................67

Security...............................................................68

Others.................................................................75

System................................................................80

Phone Info ..........................................................82

Media Gallery........................................................83

Pix.......................................................................83

Flix ......................................................................83

Music...................................................................84

Tones ..................................................................85

Images................................................................85

CHAPTER 5 SUPPLEMENTARY FUNCTIONS ......87

Voice Tools............................................................88

Voice Dialing.......................................................88

Voice Memo........................................................89

Voice Dial............................................................90

Train Words.........................................................91

Voice Setting.......................................................93

Schedule ...............................................................94

Add New Plan.....................................................94

View Plan List.....................................................95

Alarm.....................................................................96

Memo Pad .............................................................98

Calculator............................................................100

World Clock........................................................101

Stop Watch .........................................................102

Camera (Use Camera) .......................................103

Getting Ready...................................................103

Taking a Picture From the Menu.......................104

Taking a Picture In Idle Mode...........................105

Page 2 - Table of Contents Table of Contents - Page 3

ABLE OF CONTENTS

TTABLE OF CONTENTS

ABLE OF CONTENTS

TTABLE OF CONTENTS

Camera (Take Flix)..............................................107

Camera (Pix Gallery)..........................................109

Camera (Flix Gallery)..........................................110

Camera (Help).....................................................111

CHAPTER 6 VOICE MAIL AND TXT, PIX, FLIX

MESSAGES

When a New Message Arrives..........................114

TXT, Pix, Flix Message .....................................114

Voice Mail..........................................................114

New MSG............................................................115

New TXT Msg ...................................................115

New Pix Msg.....................................................117

New Flix Msg ....................................................119

Inbox....................................................................121

Sent .....................................................................124

Web Alerts...........................................................126

Draft.....................................................................127

Quick Text...........................................................128

Erase All..............................................................129

Erase Messages...............................................129

Settings...............................................................130

Auto Save .........................................................130

Auto Erase ........................................................130

Auto Receive.....................................................131

Default CB# ......................................................131

Voice CB#.........................................................131

Remind..............................................................132

Signature...........................................................132

Direct View........................................................133

Entry Mode .......................................................133

Block or Unblock ...............................................134

...........................................113

CHAPTER 7 GET IT NOW & INTERNET..............135

Get It Now ...........................................................136

Starting Get It Now...........................................136

Downloading Applications.................................136

Downloading Melodies/Wallpapers...................137

Applying Melodies/Wallpapers ..........................137

Checking Data Folder Memory .........................137

Erasing an Application......................................138

Video Clips........................................................139

Starting Internet Browser..................................142

Launching Mobile Web 2.0...............................142

Browser Menu....................................................142

Browser Menu...................................................142

CHAPTER 8 SAFETY INFORMATION...................145

Safety Information for Wireless Handheld Phones

Exposure to Radio Frequency Signals.............146

Antenna Care ....................................................147

Phone Operation...............................................147

Driving Safety ...................................................147

Electronic Devices............................................148

Other Safety Guidelines....................................150

Precautions and Warnings................................151

Operating Procedures.......................................152

Safety Information for FCC RF Exposure........153

Caution..............................................................153

SAR Information.................................................154

FDA Consumer Update......................................156

CHAPTER 9 WARRANTY....................................165

Protect Your Warranty.......................................166

12 Month Limited Warranty...............................167

.146

Page 4 - Table of Contents

“Licensed by QUALCOMM Incorporated under one or more of the following Patents : U.S.Patent No. 4,901,307 U.S.Patent No. 5,056,109 U.S.Patent No. 5,099,204 U.S. Patent No. 5,101,501 U.S. Patent No. 5,103,459 U.S. Patent No. 5,107,225 U.S.Patent No. 5,109,390.”

Table of Contents - Page 5

Chapter 1

BEFORE USING

YOUR PHONE

Please read and fully understand this manual before using your phone.

This chapter addresses your phone, its keys and display icons, and covers the charging and proper use of the battery.

Inside the Package Handset Description Function Keys Display Indicators Using the Battery Charging the Battery Battery Information

Page 6

Chapter 1 - Page 7

INSIDE THE P

ACKAGE

HANDSET DESCRIPTION

This package should include all items pictured below. If any are missing or different, immediately contact the retailer where you purchased the phone.

Standard Battery

Handset

User Manual

Travel Charger

Hand strap

Stereo Headset

mini SD Card (Optional)

This phone is a tri-mode CDMA2000 1X digital phone with Camera capabilities. The CDM8940 weighs 3.89 oz. and the dimensions are 1.82” x 3.56” x 0.92”.

Antenna

Camera Lens

Music Play/Pause Key

(Camera long key to music stop)

Function

Send Key

Key Pad

Keys

Camera Lens Key

Earjack

Volume Key

Camera Key

Earpiece

LCD Display

Volume Key

Adjusts the earpiece and ringer volume.

END/ Power Key

Camera Key

NOTE: Immediately report any product defects or

missing items to the place of purchase.

Page 8 - Chapter 1

Microphone

Chapter 1 - Page 9

FUNCTION KEYS

DISPLA

Y INDICA

TORS

SEND KEY: Press to make or receive a call. Press and hold to turn on Voice Recognition mode.

END KEY: Press to turn the phone on, to terminate a call or to return to the initial page. Press and hold to turn off the phone.

NAVIGATION KEY: In Idle Mode -Press up to access the

Short Cut Key, down to access the Messaging Menu, right to access Get It Now and left to access Mobile Web.

Inside the menu -Within a menu, use to

scroll through menu options. To select an option, press .

SOFT KEY: (Left Key) Press to access the main menu or function displayed on the bottom line. (Right Key) Press to access your contacts. Press to access the function displayed on the bottom line.

LOCK KEY: Press and hold to enter lock mode.

INTERNATIONAL CALL: Press and hold until “+” is displayed. “+” sign in front of phone number is required for making international calls.

CLR KEY: Press to clear a digit from the display, to return to the previous page, or to enable speaker phone mode.

Signal Strength

Current signal strength - the more lines, the stronger the signal.

Roaming

Phone is out of home area.

Service Indicator

Indicates call is in progress, indicates the phone cannot receive a signal from the system.

Message

Text, Voice, Urgent, Web Alerts messages.

Digital Mode

Phone is in the digital service area.

Battery

Battery charging level - the more blocks, the stronger the charge.

Mute

Phone is mute during a call.

Ringer Mode

Appears when the ringer is set as a ringer mode.

Emergency Call

Blinks when an emergency call is in progress.

ScratchPad

Displays when the scratchpad is in use during a call.

Auto Answer

Phone is in answering machine mode.

Page 10 - Chapter 1

Chapter 1 - Page 11

DISPLA

Y INDICA

TORS

USING THE BA

TTERYY

TTER

Alarm to Schedule

Appears when either an plan or an alarm is set.

Dormant

Indicates the phone is in disconnection condition while on “Server Connection”.

Speaker Phone

Phone is in speaker phone mode.

Data Only

Receives an async. call as a voice call.

GPS Icon

Indicates the Location Service of your phone is disabled/enabled.

Phone is in the 1x service area.

Network

Phone is in the progress of “UP Browser”.

TTY

TTY mode is active.

Voice Privacy

“Voice Privacy” mode.

Phone Lock

Phone is locked.

INSTALLING THE BATTERY

1. 1 Place the battery on the back of the handset and slide into place. 2 Push the battery down until it locks into place. 3 Battery lock latch automatically locks into place.

NOTE: Make sure the battery is securely placed to avoid

slipping off during a call.

REMOVING THE BATTERY

1. 1 Slide the latch over to the right, lift up the battery and 2 remove the battery from the handset.

Ear Jack

A headset is connected.

Secure

Phone is in “Secure” mode.

EVDO

Phone is in “EVDO” mode.

Page 12 - Chapter 1

NOTE: If the battery is not correctly placed in the battery

compartment, the handset will not turn on and/or the battery may detach during use.

Chapter 1 - Page 13

CHARGING THE BA

TTERYY

TTER

CHARGING THE BA

TTERYY

TTER

POWER CONNECTION

1. Plug the AC charger into a standard outlet.

Charging is in progress

NOTE: 1. The times in the following tables are for a new

battery. Usage and Standby times may decrease over time.

2. Fully charge the battery before using – it is not charged when purchased.

3. It is more efficient to charge the battery with the phone turned off.

Charging is

completed

BATTERY STANDBY TIMES

The operating time is subject to your handset usage and configuration.

CDMA

STD 1000 mAh

EXT 1350 mAh

Up to 270 hours

Up to 360 hours

BATTERY USAGE TIMES

The operating time is subject to your handset usage and configuration.

DCS STD 1000 mAh EXT 1350 mAh

NOTE: These times are for a new battery.

Usage and standby time may decrease over time.

Up to 220

minutes

Up to 290

minutes

PCS

Up to 210

minutes

Up to 280

minutes

Page 14 - Chapter 1

Chapter 1 - Page 15

TTER

Y INFORMA

TION

Do’s

l Only use the battery and charger approved by the

manufacturer.

l Only use the battery for its original purpose. l Try to keep batteries in a temperature between

F (5OC ) and 95OF (35OC).

l If the battery is stored in temperatures above or

below the recommended range, give it time to warm up or cool down before using.

l Completely drain the battery before recharging.

It may take one to four days to completely drain.

l Store the discharged battery in a cool, dark, and

dry place.

l Purchase a new battery when its operating time

gradually decreases after fully charging.

l Properly dispose of the battery according to local

laws.

Chapter 2

BASIC OPERATION

This chapter addresses the phone’s basic functions including menus, volume levels, and call features.

Don’ts

l Don’t attempt to disassemble the battery – it is a

sealed unit with no serviceable parts.

l Don’t accidentally short circuit the battery by carrying

it in your pocket or purse with other metallic objects such as coins, clips and pens. This may critically damage the battery.

l Don’t leave the battery in hot or cold temps.

Otherwise, it could significantly reduce the capacity and lifetime of the battery.

l Don’t dispose of the battery into a fire.

Page 16 - Chapter 1

Using the Phone Using the Main Menu Menu Summary Basic Functions Functions During a Call Making an Emergency Call

Chapter 2 - Page 17

USING THE PHONE

USING THE MAIN MENU

TURNING THE PHONE ON

1. Press and hold until your “Power On” logo appears and the melody begins to play.

● If “Password” appears on the display, enter your

4-digit password to unlock your phone.

● The default password is the last 4 digits of your

phone number.

TURNING THE PHONE OFF

1. Press and hold until “Power Off” animation appears.

NOTE: 1. Immediately change or recharge the battery

when “Low Battery Warning Power Off” appears on the display. Memory may possibly be damaged if the phone turns off due to the battery completely draining.

2. Turn the phone off before removing or replacing the battery. If the phone is on, unsaved data may be lost.

ACCESSING THE MENU

Your phone can be customized via the menu. Each function can be accessed by scrolling with the Navigation Key or by pressing the number that

corresponds with the menu item.

1. To access the menu from the idle screen, press [MENU].

2. To scroll through the menu, press the Navigation Key up and down.

3. To return to the previous page, press . To exit the current menu and return to the idle mode, press .

4. To enter a function when its main page is displayed, press [OK].

● Hotkey

In idle mode, move the Navigation Key as follows to access these functions:

• Upward movement: Short Cut Key

• Downward movement: Messaging

• Rightward movement: Get It Now

• Leftward movement: Mobile Web If you are in a second-level menu, you may also navigate

to the next or previous second-level menu by pressing the Navigation Key right or left.

Page 18 - Chapter 2

Chapter 2 - Page 19

MENU SUMMARYY

MENU SUMMAR

MENU SUMMARYY

MENU SUMMAR

PHONE BOOK

RECENT CALLS

MESSAGING

Page 20 - Chapter 2

1 : Find

2 : Add New 3 : Group 4 : Speed Dial 5 : Msg. Group 6 : My Phone #

1 : All Calls

2 : Missed Calls 3 : Received Calls 4 : Dialed Calls 5 : Call Timers

6 : 1x Packet Counter

1 : New Msg

2 : Voice Mail 3 : Inbox 4 : Sent 5 : Web Alerts 6 : Draft 7 : Quick Text 8 : Erase All

9 : Settings

1 :Last Call 2 :All Calls 3 :Home Calls 4 :Roam Calls 5 :Cumulative Calls 1 :Received 2 :Transmitted 3 :Total

1 :New Text Msg 2 :New Pix Msg 3 :New Flix Msg

1 :All Folder 2 :Inbox 3 :Sent 4 :Draft 5 :Web Alerts 1 :Auto Save 2 :Auto Erase 3 :Auto Receive 4 :Default CB# 5 :Voice CB# 6 :Remind 7 :Signature 8 :Direct View 9 :Entry Mode 10 :Block or Unblock

GET IT NOW

MOBILE WEB

MEDIA GALLERY

SETTINGS

1 : Get It Now

1 : Connect Web

1 : Pix

2 : Flix 3 : Music 4 : Tones 5 : Images

1 : Sounds

2 : Display

3 : Data Svc. 4 : Security

5 : Others

Get It Now Settings Help

1 :Ringer Type 2 :Volume 3 :Alerts 4 :Roam Ringer 5 :Tone Length 6 :Power On/Off 1 :Menu Style 2 :Graphics 3 :Sub Screen 4 :Greeting Message 5 :Backlight 1 :Connection 1 :Phone Lock 2 :Restrict 3 :Change Code 4 :Special #’s 5 :Erase All 6 :Reset Phone 7 :SD Card 1 :Answer Options 2 :Auto Retry 3 :Language 4 :Voice Privacy 5 :TTY Mode 6 :Location 7 :Lantern 8 :Short Cut Key

Chapter 2 - Page 21

MENU SUMMARYY

MENU SUMMAR

BASIC FUNCTIONS

UTILITIES

CAMERA

6 : System

7 : Phone Info

1 : Voice Tools

2 : Schedule 3 : Alarm

4 : Memo Pad 5 : Calculator 6 : World Clock 7 : Stop Watch

1 : Take Pix

2 : Take Flix 3 : Pix Gallery 4 : Flix Gallery 5 : Help

1 :Set Mode 2 :Nam Setting 3 :PRL ID 4 :ERI Banner 1 :S/W Version 2 :H/W Version 3 :Get It Now Version

1:Voice Memo 2 :Voice Dial 3 :Train Words 4 :Voice Setting 1 :Add New Plan 2 :View Plan List 1 :Alarm 1 2 :Alarm 2 3 :Alarm 3

MAKING A CALL

1. Enter a phone number.

● To modify the phone number you have entered:

• To erase one digit at a time, press .

• To erase the entire number, press and hold .

2. Press . The indicator, , appears on the display.

● If “CALL FAILED” appears on the display or the line is

busy, press or .

● If you activate the “AUTO RETRY” function, the phone will

automatically retry for the number of times you have selected. (Refer to page 76)

● If the number you’re calling is stored in the phone book,

the name and number will appear when the call is placed.

● There is another way to make a call through the VR

mode, which is called “VAD (Voice Activated Dialing)”. Please refer to page 90 (Voice Service) for details on making calls using VAD.

3. To end a call, press .

NOTE: Please refer to page 36 for more details about

storing a phone number.

Page 22 - Chapter 2

Chapter 2 - Page 23

BASIC FUNCTIONS

PAUSE FEATURE

You can dial or save a phone number with pauses for use in the automated systems where you need to enter a credit card number, a social security number, or other numbers. This feature will be convenient when you are linked to an ARS (Advanced Record System).

1. To insert a pause, enter a phone number then press [MENU]. Select either a Hard Pause (“P” appears)

or a Timed Pause (“T” appears).

2. Press to dial the number and to store the

number.

● Hard Pause: When connected to the ARS, it will not

progress to the next number until you press or .

● Time Pause: When connected to the ARS, it automatically

progresses to the next number after three seconds.

SPEAKER PHONE

The speaker phone feature allows you to hear audio through the speaker and talk without holding the phone.

1. To activate the speaker phone when the phone is in

idle mode, answering mode, or calling mode, press and hold .

2. The phone returns to normal (speaker phone off)

after ending or call or when the phone is turned off and back on.

ANSWERING A CALL

1. To answer a call, press any key except , , , or .To enable a call, press .

● In the Settings menu, you can select either “Any Key” or

“Send Key” to answer a call. lf “Send Key” is selected, the phone can only be answered by pressing . See page 75 for more information.

2. To end the call, press .

NOTE: In Auto Answer Mode, a call is automatically

answered after a preset number of rings. See page 76 for more details.

3-WAY CALL FUNCTION

With 3-Way Calling, you can talk to two people at the same time. When using this feature, the normal airtime rates will be applied for each of the two calls.

1. Enter the number you wish to call then press .

2. Once you have established the connection, enter

the second number you wish to call then press .

3. When you’re connected to the second party, press

again to begin your 3-Way call.

NOTE: If one of the people you called hangs up during

your call, you and the remaining caller stay connected. If you initiated the call and are the first to hang up, all three callers are disconnected.

Page 24 - Chapter 2

Chapter 2 - Page 25

BASIC FUNCTIONS

CALL WAITING FUNCTION

Notifies you of an incoming call when you’re on a call by sounding a beep and displaying the caller’s phone number on the screen.

1. To answer another call while on the phone press . This places the first call on hold.

2. To switch back to the first caller, press again.

Since Call Waiting is system dependant, the displayed Caller ID may be different from the actual caller.

ADJUSTING VOLUME

Volume can be adjusted by using the volume control keys on the side of the handset, or by using the menu.

1. Press [MENU] then select one of the following. To increase the volume, press the Navigation Key to the right. To lower the volume, press it to the left.

● Ringer: Controls the ringer volume.

● Key Tone: Controls the key pad tone volume.

● Voice Call: Controls the earpiece volume.

● Speaker Phone: Controls the speaker volume

in speaker phone mode.

2. Adjust volume then press [OK] to save it.

NOTE: To adjust the volume of the microphone during

a call, press the volume keys on the side of the phone or the Navigation Key (left or right).

Page 26 - Chapter 2

LOCK

Locks your phone and prevents unauthorized use. Phone can only be used after inputting the password.

1. To lock the phone, press and hold .

2. To unlock the phone, press or [UNLOCK]

then input the password.

● Lock feature will deactivate when the phone is

powered off. Upon next power up, you will need to

press to lock phone again.

The default password is the last 4 digits of your

●

phone number.

CALLER ID FUNCTION

Identifies caller by displaying their phone number. If the caller’s name and number are already stored in your phone book, they both will appear. This feature is system dependent. Please contact your service provider for details.

NOTE: The caller ID is stored in the call history.

MUSIC PLAYER

Music Player is for playing MP3 files saved on the mini SD Card. To display music list with the phone closed, press and hold and select a music file with the Navigation Key, press [PLAY], then press [PAUSE] or in order to stop the music player while it is playing with shell closed, it is required to open the shell and press .

● Verizon Wireless shall not be responsible for any

action or liability as a result of any breach of copyright or other misuse of music contents.

Chapter 2 - Page 27

FUNCTIONS DURING A CALL

To display menu options during a call, press [MENU]. These menu items are available while you are on a call.

MESSAGING

Enables you to send a message (SMS) during a call.

1. Press [MENU] .

MUTE (UNMUTE)

Mutes the microphone while you are on a call so the other party cannot hear you when you speak.

1. Press [MENU] .

● To deactivate, press [MENU] .

● The phone will automatically un-mute during an

Emergency Call or in Callback mode.

SCRATCHPAD

Allows you to enter a phone number during a call so it can be dialed later. The other party cannot hear the key presses.

1. Press [MENU] .

SEND MY PHONE #

Automatically transmits your phone number to a pager during a call without manually entering the number.

1. To transmit your phone number during a call, press [MENU] .

MY PHONE #

Enables you to see your phone number while on a call. Please see page 48 for more details.

1. Press [MENU] .

VOICE PRIVACY

Enhances voice privacy during a call.

1. Press [MENU] .

2. Select “Enhanced” or “Standard” then press

to save it.

NOTE: Enhanced voice privacy is a network dependent

feature. Standard voice privacy is the default setting.

[OK]

● To deactivate it, press [MENU] .

Page 28 - Chapter 2

Chapter 2 - Page 29

FUNCTIONS DURING A CALL

MAKING AN EMERGENCY CALL

LOCATION

Enables the network to locate your current location through Global Positioning System (GPS).

1. Press [MENU] .

2. Select “911 Only” or “Location On” and press

● 911 Only: Your location will be hidden from network &

● Location On: Your location is now available to the

[OK] to save it.

applications except 911.

network.

PHONE INFO.

Enables you to view software and hardware version while on a call. Please see page 82 for more details.

1. Press [MENU] .

This 911 feature automatically places your phone in the Emergency Call Mode when you dial the preprogrammed emergency number, 911. This feature is functional even in the lock mode and in an out od service area.

911 IN LOCK MODE

The “91 1” call service is available even in the lock mode.

1. Enter “911” then press .

2. The call connects.

3. The phone exits the Lock Mode for 5 minutes.

4. To exit emergency mode, press .

● When the call ends, the phone returns to the

Lock Mode.

911 USING ANY AVAILABLE SYSTEM

1. Enter “911” then press .

2. The call connects.

3. The phone remains in Emergency Mode for 5 minutes.

Page 30 - Chapter 2

4. To exit emergency mode, press .

● The phone continuously attempts to receive service

from any available system.

NOTE: 1. The 911 call is not recorded in the Call History.

2. You can not make an E911 call while you are in a BREW application.

Chapter 2 - Page 31

USING THE MINI SD CARD

INSTALLING THE MINI SD CARD

1. Open the card hole cover, and insert the mini SD like the arrow indicates.

NOTE: Please keep mini-SD slot closed at all times

whether mini-SD card is inserted or not to prevent possible damages.

REMOVING THE MINI SD CARD

1. To remove the mini SD card, press and release the card so that it is disengaged from the slot. Then slide it out.

● When you insert the mini-SD card, make sure contact

terminals face down.

● File names storing each media in the mini SD Card are “Pix”

for pictures, “Flix” for motion pictures and "MP3" for Mp3.

● Memory used for the mobile phone is not the general SD card

but the mini SD cards.

● For the mini SD card contents, file names of MP3 should be

less than 40 characters of English.

● Pix and Flix's file name should be less than 12 characters of

English.

● Do not remove the miniSD Card while reading or writing files.

Otherwise it could be damaged.

● “Mini SD” card is recognized as a mobile disk when connected

to a personal computer.

● When disconnecting from PC, please remove the USB storage

equipment on your PC. Otherwise, the stored files on the miniSD Card could be damaged.

Page 32 - Chapter 2

REMOVABLE MEMORY STORAGE FUNCTIONALITY

The following grid shows what types of files can be transferred to the removable memory card.

RINGTONES

Memory Usage Ring tone

Download via “Get It Now”

application

Saved to a removable SD

Saving a sound attachment to the SD

card and assigning it as a ring tone

memory card

YES

Stored to the phone only

NO NO

Stored to the phone only

PIX

Memory Usage Pix

Pictures received from other

Download via a Get It Now

users

application

Stored to the phone onlyYES Stored to the phone only

YES

Information can be stored

YESUser generated picture

to phone or memory card

Files are lockedNOInformation/files viewable on PC

Chapter 2 - Page 33

USING THE MINI SD CARD

FLIX

Memory Usage Flix

Video clips received from other

Video clips downloaded via Video clips downloaded via

Packet Video (PV) Ex: NBC

users

Get It Now

Stored to the phone onlyYES Stored to the phone only

YES

Stored to the phone onlyYES

Information can be stored

YESUser generated video

to phone or memory card

Files are lockedNOInformation/files viewable on PC

MP3/MUSIC

Memory Usage MP3/Music

Move MP3 files from PC to the

memory card

Move MP3 files off the card to

the phone’s memory

Are other music file types

available for use?

NOTE: 1. When pictures, taken with built in camera, are

moved to SD card, they are stored in the SD directory. In the same manner, video clips are stored in Flix directory, and MP3 files are stored in the MP3 drectory.

2. CDM-8940VW can playback music files,

downloaded from a PC and stored in the SD card.

YES

User can play MP3 files

from the card

NO NO

Chapter 3

MEMORY

FUNCTION

This chapter addresses numerous functions including saving phone numbers to the internal phone book, entering text and accessing call logs.

Storing Phone Numbers Text Input Methods Speed Dialing Phone Book Recent Calls

Page 34 - Chapter 2

Chapter 3 - Page 35

STORING PHONE NUMBERS

TEXT INPUT METHODS

The phone book stores up to 300 entries.

1. Enter phone # then press [SAVE].

2. Choose “New Contact” or “Existing Contact”. To select, press [OK].

3. If “New Contact” is selected, the phone number will appear above a list of icons. The name of the icon is displayed below the list. Press the Navigation Key right or left to choose the type of number you’re adding, as indicated by the icon. Press [OK] to select. If “Existing Contact” is selected, your phone book list is displayed. Choose the entry to add the phone number to, then press [OK]. You will then see the phone number listed about a list of icons and the name of the currently selected icon below the list. Press [OK] to select.

4. Enter a name then press [OK]. Follow instructions for entering text on page 37. To change the input mode, press [Abc].

5. Use the Navigation Key to scroll through more options for the entry (group, other numbers, ringer, etc.).

Mobile/ Home/ Office/ Pager/ FAX E-Mail: Enter E-Mail address. Wireless Addr.: Enter Wireless address. Group: Personal, Business, Etc. Ringer: Select Ringer Type. Msg. Ringer: Select Msg. Ringer Type. Graphic: Select take a picture Image. Memo: Enter memo./ Set Secret: Lock, Unlock.

6. To store the entry, press [SAVE]. “New contact added!” or “Contact edited!” will be displayed.

Page 36 - Chapter 3

ENTERING CHARACTERS

Your phone offers several text input methods for convenient entry of memory location names and text messages:

Abc mode: Enters words by repeatedly tapping the corresponding T9Word: Tap each corresponding key only once and the phone Numeric mode: Only enters numbers.

Symbol mode: Enters symbols like @, #, %.

ALPHA MODE [ABC]

Use the digit keys to enter letters, numbers and characters. Enter letters using the key pad as follows:

Key Pad

2ABC 3DEF 4GHI 5JKL

6MNO

7PQRS

8TUV

9WXYZ

To change the input mode, press [Abc].

● To enter a space, press . The cursor will automatically

● Repeat until letters are entered. (Name or Group is a

● To delete one digit, press .

● To change from lowercase to uppercase, press .

key until the desired character is displayed.

predicts the word you are entering.

1 Repetition

1 A D

P T

2 Repetitions

. B E H K N Q U X

3 Repetitions

C F

I L O R V Y

4 Repetitions

2 3 4 5 6 S 8 Z

5 Repetitions

’ ... ... ... ... ...

...

move to the next column.

16-letter limit, E-mail or Wireless Address is a 48-letter limit).

To delete the entire entry, press and hold .

Chapter 3 - Page 37

TEXT INPUT METHODS

T9TMPREDICTIVE TEXT MODE [T9TMABC]

To choose T9TMmode from the Editor screen press [Abc], then choose [T9Word]. This mode predicts the words you are entering using a built-in dictionary. With

predictive text input, you press each key only once

T9 for each letter. The chart below outlines how to use

mode.

KEY FUNCTION

Press to change mode.

Mode

Space

Shift

[Abc][T9Word][NUM][Symbols]. Press to view the next matching

word if the highlighted word is not the word you intended.

Press to accept a word and add a space.

Press to select a letter case of the standard text input or T9 text input mode. [Abc], [ABC], and [abc] indicate the standard text input. [T9word], [T9Word], and [T9WORD] indicate the predictive text input.

1. Press each key once for each letter of the word you are writing.

●

To write John with the English dictionary selected:

1. Press 5 once - (for - K)

2. Press 6 once - (for - Km)

3. Press 4 once - (for - Log)

4. Press 6 once - (for - John)

NOTE:

The display will change each time a key is pressed.

2. Press until the correct word is displayed.

3. To select the correct word, press

[OK].

If the T9 mode does not recognize or suggest the word you want to enter, re-enter the name in the

Alpha ABC mode.

NOTE:

When entering more than one word in T9Word Mode, enter the first word than press to insert a space and start the next word.

Clear

Save

Page 38 - Chapter 3

Press to delete a character to the left of the cursor.

Store the letters and numbers you enter.

Chapter 3 - Page 39

TEXT INPUT METHODS

SPEED DIALING

NUMERIC MODE [NUM]

Numeric mode allows you to add a number to your entry/message. To select numeric mode from the Editor screen press [Abc], then select [NUM].

SYMBOL MODE [SYM]

Symbol mode allows you to add various symbols to your entry. Whether you are adding an e-mail address to your phone book or sending an expressive message, symbols make these entries easier. To select symbol mode from the Editor screen press

[Abc] then choose [Symbols]. The symbols will appear on the display. The corresponding key number for that symbol will appear as well. You can press the key to select the symbol . To move to the next screen of symbols press .

Page 40 - Chapter 3

SPEED DIAL

Dials a number simply by pressing and holding its Speed Dial location number. For a 2-digit location number, press the first number then press and hold the second number. To store a number in Speed Dial:

1. Press [MENU] .

2. To assign a phone number to a location, select the location then press [SET].

● If a phone number is already assigned to the location,

press [ERASE] then the Navigation Key to delete.

3. The phone book list will be displayed alphabetically. Select a name then press [OK].

4. “Speed dial # X Edited!” will be displayed.

●

If the entry is set to secret, you will be asked for your password.

ONE-TOUCH/TWO-TOUCH DIALING

Ideal for frequently dialed numbers, this feature allows phone book entries to be dialed via the key pad with only one or two key presses.

ONE-TOUCH/TWO-TOUCH DIALING:

1-9 : Press the corresponding memory number and hold

for more than 1 second.

01-09/10-20 : Press the first digit and second digits of the

memory number short and long respectively.

● If no phone number is stored in the location entered,

“There is no number” will appear on the screen.

● If the entry is set to secret, you will be asked for your

password.

● To One-Touch voicemail (*86 feature), press “1” or “01”.

Chapter 3 - Page 41

PHONE BOOK

Stores up to 300 entries, each of which can be assigned to a group. Entries can be retrieved by name, phone number or group.

FIND

Retrieves an entry by name or number, and calls the number by simply pressing . On Standby Screen, you may press [CONTACTS] as well.

all the entries stored in your phone book list or find an entry quickly by entering a name or its character string.

1. Press [MENU] .

2. The list of names in your phone book is displayed alphabetically. Use Navigation Key to select the name.

3. Enter a name or its character string or scroll through the list with the Navigation Key. Please refer to page 37 for instructions on entering letters, numbers and symbols.

4. The list beginning with the letter you entered is displayed. Highlight an entry. Press [OK] to preview list the entry. Press [MENU] to view options. If the contact has a mobile phone number your options will be 1. Send Text Msg, 2. Send Pix Msg, 3. Send Flix Msg, 4. Erase or 5. Prefix. If no mobile number is saved for the contact, your options will be 1. Erase, 2. Prefix. If only an e-mail or wireless address is saved for the contact, your options will be 1. Send Text Msg, 2. Send Pix Msg,

3. Send Flix Msg, 4. Erase.

● If the entry is set to secret, you will be asked for your

password.

Page 42 - Chapter 3

You can review

5. To call the selected number, press .

ADD NEW

Adds a new entry to the phone book. Please refer to page 36 for alternate ways to add an entry to the phone book.

1. To add a new entry to the phone book, press [MENU] .

2. The first field highlighted is Name. Enter the name for the entry, then press [OK].

● PHONE BOOK FIELD: Name/Mobile/Home/Office/Pager/Fax/

E-Mail/Wireless Addr./Group/Ringer/Msg.Ringer/Graphic/ Memo/Set Secret.

3. Press the Navigation Key down to enter all the other information (group, phone number, etc.).

4. To save the entry after all the information is entered, press [SAVE].

Chapter 3 - Page 43

PHONE BOOK

GROUP

Allows you to classify phone entries into groups. Existing groups include Personal, Business, Etc. and All.

ADD NEW GROUP

1. To add a new group, press [MENU] . A maximum of seven groups is allowed.

2. Press [MENU] then select “Add Group”.

3. Input a new group name.

4. To save it, press [OK].

CHANGE GROUP NAME

1. Press [MENU] .

Select an existing group name.

NOTE:

2. Press [MENU] then select “Rename”.

3. Input a new group name.

4. To save it, press [OK].

Default group name(All, Personal, Business, Etc.) cannot be changed.

ERASE GROUP

1. Press [MENU] . Select an existing group name.

2. Press [ERASE] to delete it. “Erase this group?” will be displayed.

3. Press [OK] again to confirm it.

● When executing erase group, the saved entries are

moved to the Etc. group.

● The default group names (All, Personal, Business, Etc.)

cannot be changed.

MSG. GROUP

Allows the user to group up to 10 phone numbers. The user can add, change, and delete Msg.Groups.

ADD NEW MSG. GROUP

1. To add a new group, press [MENU] .

A maximum of five groups is allowed.

2. Press [MENU] then select “Add Group”.

3. Input a new group name.

4. To save it, press [OK].

Page 44 - Chapter 3

Chapter 3 - Page 45

PHONE BOOK

CHANGE MSG. GROUP NAME

1. Press [MENU] . Select an existing group name.

2. Press [MENU] then select “Rename”.

3. Input a new group name.

4. To save it, press [OK].

SEND TEXT MSG.

1. Press [MENU] . Select an existing group name.

2. Press [MENU] then select “Send Text Msg.”.

3. Complete the “Message”, “Default CB#”, “Priority”, and “Insert Signature” fields.

4. Press [MENU] then select “Send” or “Save Msg”.

Press [OK]. Please refer to page 115 for more details on

“New TXT Msg”.

SEND PIX MSG.

1. Press [MENU] . Select an existing group name.

2. Press [MENU] then select “Send Pix Msg.”.

3. Complete the “Message”, “Subject”, “CC”, “BCC”, “Priority” and “Insert Signature” fields.

4. Press [MENU] then select “Send”, “Preview” or “Save Msg”. Press [OK]. Please refer to page 117 for more details on “New Pix Msg”.

SEND FLIX MSG

1. Press [MENU] . Select an existing group name.

2. Press [MENU] then select “Send Flix Msg”.

3. Complete the “Message”, “Subject”, “CC”, “BCC”, “Priority” and “Insert Signature” fields.

4. Press [MENU] then select “Send”, “Preview” or “Save Msg”. Press [OK]. Please refer to page 119 for more details on “New Flix Msg”.

Page 46 - Chapter 3

Chapter 3 - Page 47

PHONE BOOK

RECENT CALLS

ERASE MSG. GROUP

1. Press [MENU] . Select the group name to be deleted.

2. To delete it, press [ERASE]. “Erase this message group?” will be displayed.

3. Press [OK]. “This message group erased” will be displayed.

MY PHONE #

To display your phone number and service provider:

1. Press [MENU] .

2. Your phone number and service provider appears. To return to the previous page, press [OK].

To access Recent Calls from the idle mode, press [MENU] .

ALL CALLS

Displays information about the 60 most recently dialed, missed and received numbers. Place a call to a selected number by simply pressing .

1. To see a list of the 60 most recent numbers, press [MENU] . If the number is already stored in your phone book, only the name appears. If the number is not stored, only the phone number appears.

2. To view call details, press

NOTE:

• Call details include date, time, and phone number.

• If the phone number is set to secret, the name is not displayed.

3. To save the number, press [MENU], [SAVE] or press [ERASE] to delete it.

● Save: To store the phone number in your phone book.

● Prefix: Allows user to add an additional number before the

● Send Text Msg: To send a message to the phone number.

● Send Pix Msg: To send a photo message to the phone

● Send Flix Msg: To send a video mail message to the phone

● Erase All: To erase all recent calls list.

NOTE:

stored number such as an area code or “1” before a long distance call.

number.

After the 60 received, dialed or missed calls, the oldest call will automatically be erased from the history.

[OK].

Page 48 - Chapter 3

Chapter 3 - Page 49

+ 60 hidden pages
