WELCOME
TABLE OF CONTENTS
Thank you for choosing the up-to-date CDM-8910, our new
model, developed by top researchers to support the
CDMA2000 1X system through Qualcomm-manufactured
MSM6050 chips and CDMA technologies. This product allows
for high speed communication services, such as web browsing,
data services, and a GUI animation menu.
Among its many advanced features, T9 Input Mode makes it
easier to enter letters, and VR (Voice Recognition) allows you
to make a call using your voice.
Other features include:
Full graphic display with 9 text input lines and 1 icon line
with variable font size.
Easy to dial through the VR feature.
Enhanced web browsing & data services (i.e.; wireless
internet access, UP browser)
GUI & Animation display compliant with CDMA2000 1X.
CSTN 65K Color LCD.
Navigation Key and 21 keys aligned for more convenience.
Speaker phone, and voice recognition.
Text messaging, web browsing, authentication, call
forwarding, call transfer and call waiting.
IMPORTANT INFORMATION
This CDM-8910 user guide contains very important
information about how to handle and use the phone. So
please read this manual thoroughly, pay attention to the
warranty on the back page and be alert to the exclusions and
limitations of your warranty, which are related with the
unauthorized use of components.
CHAPTER 1. BEFORE USING YOUR PHONE .................................5
INSIDE THE PACKAGE .....................................................................................6
HANDSET DESCRIPTION.................................................................................7
THE FUNCTION KEYS.............................................................................................8
DISPLAY INDICATORS ...........................................................................................9
BATTERY USAGE...........................................................................................11
BATTERY INSTALLATION ....................................................................................11
BATTERY REMOVAL.............................................................................................11
BATTERY CHARGING ...........................................................................................12
POWER CONNECTION ......................................................................................12
Chapter 1
BATTERY TALK TIME .........................................................................................13
BATTERY LIFE TIME (FOR NEW BATTERY) ......................................................13
BATTERY HANDLING INFORMATION..........................................................14
DOs.........................................................................................................................14
DON’Ts...................................................................................................................14
CHAPTER 2. BASIC OPERATION ..................................................15
TURNING THE PHONE ON / OFF ..................................................................16
TURNING THE PHONE ON...................................................................................16
TURNING THE PHONE OFF..................................................................................16
ACCESSING THE MENU................................................................................17
MENU SUMMARY .........................................................................................18
BASIC FUNCTIONS ........................................................................................21
MAKING A CALL ...................................................................................................21
SPEAKER PHONE..................................................................................................22
PAUSE FEATURE ..................................................................................................22
ANSWERING A CALL............................................................................................23
3 WAY CALL FUNCTION ......................................................................................23
CALLER ID FUNCTION..........................................................................................24
CALL WAITING FUNCTION ..................................................................................24
ADJUSTING VOLUME ..........................................................................................24
ETIQUETTE ............................................................................................................25
KEY GUARD...........................................................................................................25
Chapter 2
DURING A CALL .............................................................................................26
MUTE (UNMUTE)..................................................................................................26
SPEAKER MODE ...................................................................................................26
SILENT (SILENT QUIT) .........................................................................................26
SEND MY PHONE # ..............................................................................................26
LOCATION .............................................................................................................26
PHONE INFO..........................................................................................................27
PHONEBOOK.........................................................................................................27
CALL HISTORY ......................................................................................................27
MESSAGES ...........................................................................................................27
MAKING AN EMERGENCY CALL..................................................................28
911 IN LOCK MODE ..............................................................................................28
911 USING ANY AVAILABLE SYSTEM ...............................................................28
CHAPTER 3. MEMORY FUNCTION...............................................29
STORING A PHONE NUMBER ......................................................................30
ENTERING LETTERS, NUMBERS & SYMBOLS ...........................................31
STANDARD INPUT MODE....................................................................................32
T9 INPUT MODE....................................................................................................33
NUMERIC MODE...................................................................................................34
Chapter 3
SYMBOL MODE ....................................................................................................34
MAKING A CALL THROUGH THE PHONE BOOK ........................................35
SPEED DIAL#’S......................................................................................................35
CHAPTER 4. MENU FUNCTION ....................................................37
MY ACCOUNT ................................................................................................38
CHECKING YOUR ACCOUNT BALANCE.............................................................38
TOP-UP YOUR ACCOUNT ....................................................................................38
PICTURES .......................................................................................................39
TAKE A PHOTO .....................................................................................................39
TAKING A PICTURE THROUGH THE MENU......................................................39
Chapter 4
TAKING A PICTURE IN IDLE MODE...................................................................39
TAKING A PICTURE WITH THE PHONE CLOSED .............................................40
CAMERA MODE OPTIONS ................................................................................41
1
TABLE OF CONTENTS TABLE OF CONTENTS
MY PICTURES .......................................................................................................42
ONLINE ALBUMS..................................................................................................43
ACCOUNT INFO ....................................................................................................43
MY STUFF.......................................................................................................44
START MY STUFF.................................................................................................44
RINGTONES ..........................................................................................................44
SCREEN SAVERS ..................................................................................................45
GAMES ..................................................................................................................46
APPLICATIONS......................................................................................................47
OTHERS .................................................................................................................48
CALL HISTORY ...............................................................................................49
ALL CALLS.............................................................................................................49
OUTGOING CALLS ...............................................................................................50
INCOMING CALLS ................................................................................................51
MISSED CALLS .....................................................................................................52
ERASE HISTORY ...................................................................................................53
ALL CALLS..........................................................................................................53
OUTGOING CALLS .............................................................................................53
INCOMING CALLS..............................................................................................53
MISSED CALLS ..................................................................................................54
AIR TIME ................................................................................................................55
LAST CALL..........................................................................................................55
ALL CALLS..........................................................................................................55
PHONE BOOK .................................................................................................56
FIND .......................................................................................................................56
NEW ENTRY ..........................................................................................................57
SPEED DIAL#’S......................................................................................................58
MY PHONE # .........................................................................................................58
GROUP...................................................................................................................59
ADD NEW GROUP .............................................................................................59
CHANGE GROUP NAME ....................................................................................59
ERASE GROUP ...................................................................................................60
TOOLS.............................................................................................................61
SCHEDULE.............................................................................................................61
Chapter 4
ADD NEW PLAN.................................................................................................61
VIEW PLAN.........................................................................................................62
MEMO PAD............................................................................................................63
ADD MEMO........................................................................................................63
VIEW MEMO ......................................................................................................63
SETTINGS ...........................................................................................................64
ALARM...................................................................................................................65
CALCULATOR........................................................................................................67
STOPWATCH.........................................................................................................68
WORLD CLOCK .....................................................................................................69
SETTINGS .......................................................................................................70
SOUNDS ................................................................................................................70
VOLUME.............................................................................................................70
RINGERS.............................................................................................................73
ALERTS...............................................................................................................74
ROAM RINGER...................................................................................................75
TONE LENGTH ...................................................................................................75
DISPLAY.................................................................................................................76
MENU STYLE......................................................................................................76
GRAPHICS ..........................................................................................................76
SUB LCD.............................................................................................................77
GREETING ..........................................................................................................78
BACKLIGHT ........................................................................................................78
CONTRAST .........................................................................................................79
ROAMING ..............................................................................................................80
GAMES/TOOLS .....................................................................................................81
BACKLIGHT ........................................................................................................81
VOLUME.............................................................................................................81
MSG ALERT........................................................................................................81
LOCATION .............................................................................................................82
SECURITY ..............................................................................................................83
LOCK PHONE ....................................................................................................83
CHANGE LOCK...................................................................................................83
2
SPECIAL #’S .......................................................................................................84
LIMIT USE...........................................................................................................84
ERASE PBOOK ...................................................................................................86
ERASE DOWNLOADS ........................................................................................86
RESET PICTURE ACCOUNT ...............................................................................87
RESET PHONE....................................................................................................87
AIRPLANE MODE ..................................................................................................88
OTHERS .................................................................................................................89
CALL ANSWER...................................................................................................89
ACTIVE FLIP........................................................................................................89
AUTO ANSWER..................................................................................................90
AUTO REDIAL.....................................................................................................90
Chapter 4
LANGUAGE.........................................................................................................91
TTY MODE..........................................................................................................91
VOICE SETTING..................................................................................................92
KEY GUARD........................................................................................................92
PHONE INFO..........................................................................................................93
VERSION.............................................................................................................93
ICONS .................................................................................................................93
CHAPTER 5. VOICE TOOLS ...........................................................95
VOICE RECOGNITION MODE ........................................................................96
NAME.....................................................................................................................96
VOICE TOOLS MENU.....................................................................................97
VOICE MEMO ........................................................................................................97
VOICE DIAL............................................................................................................98
TRAIN WORDS ......................................................................................................99
Chapter 5
YES .....................................................................................................................99
NO.......................................................................................................................99
WAKE-UP..........................................................................................................100
UNDO TRAIN ALL.............................................................................................100
CHAPTER 6.
WHEN A NEW MESSAGE ARRIVES ...........................................................102
VOICE MAIL ..................................................................................................102
SEND TEXT .............................................................................................................103
SEND PICTURE MSG..............................................................................................104
INBOX ......................................................................................................................105
OUTBOX ..................................................................................................................107
SAVED .....................................................................................................................109
WEB ALERTS...........................................................................................................110
QUICK TEXT ............................................................................................................111
ERASE ALL ..............................................................................................................112
SETTINGS................................................................................................................113
VOICE MAIL, TEXT MESSAGE AND PICTURE MESSAGE
REPLY ...............................................................................................................105
REPLY WITH COPY ..........................................................................................105
FORWARD........................................................................................................106
ERASE...............................................................................................................106
SAVE TO CONTACT..........................................................................................106
SAVE TO SAVED...............................................................................................106
SAVE TO QUICK TEXT......................................................................................106
LOCK & UNLOCK .............................................................................................106
CHECKING SENT TEXT MESSAGES .................................................................107
RESEND............................................................................................................107
SEND TO...........................................................................................................107
ERASE...............................................................................................................108
Chapter 6
SAVE TO CONTACT..........................................................................................108
SAVE TO SAVED...............................................................................................108
LOCK & UNLOCK .............................................................................................108
STATE ...............................................................................................................108
SAVED..................................................................................................................109
WEB ALERTS.......................................................................................................110
QUICK TEXT ........................................................................................................111
ERASE ALL ..........................................................................................................112
SAVE SENT MSG ................................................................................................113
DEFAULT CALLBACK..........................................................................................113
REMINDER...........................................................................................................113
...101
3
TABLE OF CONTENT
AUTO ERASE.......................................................................................................114
INBOX ...............................................................................................................114
OUTBOX ...........................................................................................................114
ENTRY MODE......................................................................................................114
MESSAGE LOG ...................................................................................................115
INCOMING LOG ...............................................................................................115
OUTGOING LOG...............................................................................................115
Chapter 6
RESET LOG.......................................................................................................115
RETRY TIME ........................................................................................................116
PUSH SETTING ...................................................................................................116
CHAPTER 7. VXL ..........................................................................117
VXL ................................................................................................................118
ACCESSING & NAVIGATING VXL .....................................................................118
CHAPTER 8. SAFETY AND WARRANTY ....................................119
SAFETY INFORMATION FOR WIRELESS HANDHELD PHONES ..............120
EXPOSURE TO RADIO FREQUENCY SIGNALS...............................................120
ANTENNA CARE...............................................................................................120
DRIVING SAFETY ................................................................................................121
ELECTRONIC DEVICES .......................................................................................122
PACEMAKERS ..................................................................................................122
OTHER MEDICAL DEVICES .............................................................................122
POSTED FACILITIES.........................................................................................122
OTHER SAFETY GUIDELINES ............................................................................123
AIRCRAFT .........................................................................................................123
BLASTING AREAS ............................................................................................123
Chapter 8
POTENTIALLY EXPLOSIVE ATMOSPHERES ...................................................123
PRECAUTIONS ....................................................................................................124
SAFETY INFORMATION FOR FCC RF EXPOSURE ....................................125
CAUTIONS...........................................................................................................125
BODY-WORN OPERATION ..............................................................................125
VEHICLE MOUNTED EXTERNAL ANTENNA (OPTIONAL, IF AVAILABLE)......125
SAR INFORMATION.....................................................................................126
FDA CONSUMER UPDATE ..........................................................................128
PROTECT YOUR WARRANTY .....................................................................132
12 MONTH LIMITED WARRANTY...............................................................133
Chapter 1
BEFORE USING
YOUR PHONE
This chapter provides important information about using the
CDM-8910 including:
INSIDE THE PACKAGE
HANDSET DESCRIPTION
BATTERY USAGE
BATTERY HANDLING INFORMATION
C
H
1
“Licensed by QUALCOMM Incorporated under one or more of the following Patents : U.S.Patent No.
4,901,307 U.S.Patent No. 5,056,109 U.S.Patent No. 5,099,204 U.S. Patent No. 5,101,501 U.S. Patent No.
5,103,459 U.S. Patent No. 5,107,225 U.S.Patent No. 5,109,390.”
4
5
INSIDE THE PACKAGE
HANDSET DESCRIPTION
This package should include all items pictured below.
C
If any are missing or different, immediately contact the retailer
H
where you purchased the phone.
1
Handset
AC Charger
The CDM-8910 weighs 3.7oz. And the dimensions are 1.83” x 4.48” x
0.97”.
Antenna
Headphone
Jack
Camera
Key
Camera
Lens
Volume Key
Function Keys
Navigation Key &
Camera/OK Key
Send Key
Earpiece
LCD Screen
END/
Power Key
C
H
1
User Manual
6
Standard Battery
Silencer Key
Microphone
7
HANDSET DESCRIPTION HANDSET DESCRIPTION
C
H
1
Display Indicators
See page 9 for a list of icons.
Text & Graphic area
DISPLAY INDICATORS
Signal Strength - Current signal strength: the
more lines, the stronger the signal.
C
H
1
Roaming
Phone is out of home area.
Service Indicator
Indicates call is in progress, indicates the
phone cannot receive a signal from the system.
Message
New text or voice message.
Digital Mode
Phone is operating in digital mode.
Analog Mode
Menu
Soft Key Indications
Shows the functions currently
assigned to each soft key and
displays some icons.
Find
Short Press : Camera Menu.
Long Press : Camera
Preview.
Phone is operating in analog mode.
THE FUNCTION KEYS
My Account
MessagingVXL
Call History
Press to make or receive a call.
Press and hold to turn on VR mode.
Press to turn the phone on/off, to terminate a call
or to return to the initial page.
(Left Soft Key) Press to access the menu or
function displayed on bottom line.
(Right Soft Key) Press to access the phone
book find or function displayed on bottom line.
Press to clear a digit from the display or to return
to the previous page.
Press and hold to enable speaker phone mode.
Press and hold to enter Etiquette Mode.
At the main screen
- Press up to access My Account, down to
access Call History, right for Messaging
and left for VXL.
Inside the menu
- Within a menu, use to scroll through
menu options, or to select a function
displayed on the screen.
Battery
Battery charging level – the more blocks, the
stronger the charge.
Mute
Phone is mute during a call.
Silence
Appears when Silent is selected as the ring mode.
Emergency Call
Blinks when an emergency call is in progress.
Auto Answer
Phone is in answering machine mode.
Speaker Phone
Phone is in speaker phone mode.
Etiquette
Phone will vibrate when call is received.
Schedule
Appears when either an event or an alarm is set.
Ring Mode
Appears when a ringer is selected for the
ringer mode.
Press and hold to enter Key guard mode.
Press to turn on backlight.
Press and hold to activate Camera Mode.
8
Dormant
Indicates the phone is disconnected while on
“Server Connection”.
9
HANDSET DESCRIPTION BATTERY USAGE
C
H
1
GPS Icon
Indicates the Location Service of your cellular
telephone
1X
Phone is in the digital service area.
Silent
Displays when Silent is in use during a call.
Web Msg
Phone has a Web Alert message.
Web + Text Msg
Phone has new Web Alert Msg and Text Msg.
Web + Voice Msg
Phone has new Web Alert Msg and Voice Msg.
Web + Text + Voice Msg - Phone has new Web
Alert Msg, Text Msg and Voice Msg.
Web Browser
Phone is in the progress of Browser.
TTY Mode
is disabled/enabled.
Indicates your phone is in TTY mode is active,
indicates your phone is in TTY mode is off.
BATTERY INSTALLATION
Place the battery on the back of the handset
1
u
and slide into place.
v
until it locks into place.
BATTERY REMOVAL
Pull down the release latch, lift up the
1
u
battery and
remove the battery from the
v
Push the battery down
C
H
1
handset.
10
If the battery is not correctly placed in the compartment, the
handset will not turn on and/or the battery may detach during use.
11
BATTERY USAGE BATTERY USAGE
C
H
1
BATTERY CHARGING
POWER CONNECTION
Plug the AC charger into a standard outlet.
1
Plug the other end of the AC Charger into the
2
bottom of your cellular telephone. The battery
must be attached to to the cellular telephone.
•
When you charge the battery with the phone turned off, you
will see a charging status screen. You cannot operate the
phone until it is turned on.
•
The battery is not charged at the time of purchase.
•
Fully charge the battery before use.
•
It is more efficient to charge the battery with the handset
turned off.
•
The battery must be connected to the phone in order to
charge it.
•
Battery operating time gradually decreases over time.
•
If the battery fails to perform normally, you may need to
replace the battery.
BATTERY TALK TIME
The operating time is subject to your handset usage and configuration.
Battery Capacity
STD 1000 mAh
EXT 1700 mAh
PCS
Up to 3 hours
Up to 5 hours
BATTERY STANDBY TIME (FOR NEW BATTERY)
The operating time is subject to your handset usage and configuration.
Battery Capacity
STD 1000 mAh
EXT 1700 mAh
•
These times are for a new battery. Talking and Standby time
may decrease over time.
•
These talk times are the maximum times possible and vary
substantially based on regional network signal strength. With
talk time usage, standby time will decrease proportionally.
Up to 190 hours (7 days)
Up to 300 hours (12 days)
PCS
C
H
1
12
13
BATTERY HANDLING INFORMATION
C
H
1
DOs
l Only use the battery and charger approved by the
manufacturer.
l Only use the battery for its original purpose.
l Try to keep batteries in a temperature between
41ºF (5ºC ) and 95ºF (35ºC).
l If the battery is stored in temperatures above or
below the recommended range, give it time to
warm up or cool down before using.
l Completely drain the battery before recharging.
It may take one to four days to completely drain.
l Store the discharged battery in a cool, dark, and
dry place.
l Purchase a new battery when its operating time
gradually decreases after fully charging.
l Properly dispose of the battery according to local
laws.
DON’Ts
l Don’t attempt to disassemble the battery –
it is a sealed unit with no serviceable parts.
l Don’t accidentally short circuit the battery by
carrying it in your pocket or purse with other
metallic objects such as coins, clips and pens.
This may critically damage the battery.
l Don’t leave the battery in hot or cold temps.
Otherwise, it could significantly reduce the
capacity and lifetime of the battery.
l Don’t dispose of the battery into a fire.
Chapter 2
BASIC OPERATION
This chapter addresses and explains the basic features of your
cellular telephone including:
TURNING THE PHONE ON / OFF
ACCESSING THE MENU
MENU SUMMARY
BASIC FUNCTIONS
DURING A CALL
MAKING AN EMERGENCY CALL
C
H
2
14
15
TURNING THE PHONE ON / OFF
ACCESSING THE MENU
TURNING THE PHONE ON
Press and hold , until “Power On” Logo
1
appears and the tone sounds.
C
H
2
•
To select a logo, refer to page 76.
(Settings>Display>Graphics) for more detail.
•
If “Password” appears on the display, enter your 4-digit
password to unlock your phone.
•
The default password is the last 4 digits of your phone number.
TURNING THE PHONE OFF
Press and hold , until your “Power Off” Logo
1
appears.
•
Immediately change or recharge the battery when
“Low Battery Warning Power Off” appears on the display.
Memory may possibly be damaged if the phone turns off
due to the battery completely draining.
•
Turn the phone off before removing or replacing the battery.
If the phone is on, unsaved data may be lost.
Your Cellular Telephone can be customized via the menu. Each
function can be accessed by scrolling with the Navigation Key or by
pressing the number that corresponds with the menu item.
My Account
Messaging
Pictures
VXL
My Stuff
To access the menu in the idle mode,
1
Call History
Phonebook
Voice Tools
Tools
Settings
press [MENU].
To scroll through the menu options use the
2
Navigation Key.
l To search through the menu in numerical order, press the
Navigation Key down.
To return to the previous page, press .
3
To exit the current menu and return to the idle
mode, press .
Press the Navigation Key to enter a function
4
C
H
2
when its main page is displayed or press its
assigned number to have direct access to
the function.
16
Hotkeys
At the main screen, press and hold the Navigation Key as follows
to access these functions:
• Up : My Account
• Down : Call History
• Right : Messaging
• Left : VXL
17
C
H
2
MENU SUMMARY MENU SUMMARY
Level 1 Level 2 Level 3 Level 4 Level 1 Level 2 Level 3 Level 4
1. My Account
2. Messaging
3. Pictures
4. VXL
5. My Stuff
6. Call History
1. Send Text
2. Send Picture Msg
3. Voicemail
4. Inbox
5. Outbox
6. Saved
7. Web Alerts
8. Quick Text
9. Erase All
10. Settings
1. Camera
2. My Pictures
3. Online Albums
4. Account Info
1. Ringtones
2. Screen Savers
3. Games
4. Applications
5. Others
1. All Calls
2. Outgoing Calls
3. Incoming Calls
4. Missed Calls
5. Erase History
6. Air Time
18
1. From My Pictures
2. Take New Picture
1. Voicemail
2. Inbox
3. Outbox
4. Saved
5. Web Alerts
6. Quick Text
1. Save Sent MSG
2. Default Callback
3. Reminder
4. Auto Erase
5. Entry Mode
6. Message Log
7. Retry Time
8. Push Setting
1. In Camera
2. Save to Phone
1. All Calls
2. Outgoing Calls
3. Incoming Calls
4. Missed Calls
1. Last Call
2. All Calls
1. Read Msg
2. Entire Msg
1. Inbox
2. Outbox
1. Incoming Log
2. Outgoing Log
3. Reset Log
7. Phonebook
8. Voice Tools
9. Tools
10. Settings
1. Find
2. New Entry
3. Speed Dial #’s
4. My Phone #
5. Group
1. Voice Memo
2. Voice Dial
3. Train Words
1. Schedule
2. Memo Pad
3. Alarm
4. Calculator
5. Stopwatch
6. World Clock
1. Sounds
2. Display
1. Record
2. Play
3. Play Speaker
4. Erase All
1. Record
2. Play
3. Play Speaker
4. Erase All
1. Yes
2. No
3. Wake-Up
4. Undo Train All
1. Add New Plan
2. View Plan
1. Add Memo
2. View Memo
3. Settings
1. Alarm 1
2. Alarm 2
3. Alarm 3
1. Volume
2. Ringers
3. Alerts
4. Roam Ringer
5. Tone Length
1. Menu Style
2. Graphics
19
1. Ringer
2. Voice Call
3. Key Beep
4. Messages
5. Speaker
6. Power On
7. Power Off
1. Voice Call
2. Messages
3. Voicemail
1. Service
2. Minute
3. Connect
4. Fade
5. Low Signal
1. Screen Saver
2. Power On
3. Power Off
4. Incoming Call
C
H
2
MENU SUMMARY
BASIC FUNCTIONS
Level 1 Level 2 Level 3 Level 4
3. Sub LCD
4. Greeting
5. Backlight
3. Roaming
C
H
2
4. Games/Tools
5. Location
6. Security
7. Airplane Mode
8. Others
9. Phone Info.
6. Contrast
1. Backlight
2. Volume
3. Msg Alert
1. Lock Phone
2. Change Lock
3. Special #’s
4. Limit Use
5. Erase PBook
6. Erase Downloads
7. Reset Picture
Account
8. Reset Phone
1. Call Answer
2. Active Flip
3. Auto Answer
4. Auto Redial
5. Language
6. TTY Mode
7. Voice Setting
8. Key Guard
1. Version
2. Icons
1. Special #1
2. Special #2
3. Special #3
1. Outgoing Calls
2. Call History
3. Pictures
4. Data Calls
5. Long Distance
MAKING A CALL
Enter a phone number.
1
To modify the phone number you have entered :
•
To erase one digit at a time press .
•
To erase the entire number, press and hold .
Press .
2
The indicator , appears on the display.
•
If “CALL FAILED” appears on the display or the line is
busy, press or .
•
If you activate the “AUTO REDIAL” function, the phone
will automatically redial for the number of times you have
selected. (Refer to page 90).
•
When you place or receive a call from stored phone
numbers, both the name and phone number will be
displayed.
•
There is another way to make a call through the VR mode,
which is called “VAD (Voice Activated Dialing)”.
Please refer to page 98 (Voice Service) for more details.
To end a call, press .
3
C
H
2
20
21
BASIC FUNCTIONS BASIC FUNCTIONS
SPEAKER PHONE
The speaker phone feature lets you listen to audio through the speaker
and talk without holding the phone.
C
H
To activate the speaker phone in idle, answering
1
or calling modes, press and hold .
2
The phone returns to normal (speaker phone off)
2
after ending a call or when the phone is turned off
and back on.
PAUSE FEATURE
Pauses are used for automated systems (i.e., voice mail, calling cards).
Insert a pause after a phone number then enter another group of
numbers. The second set of numbers is dialed automatically after the
pause. This feature is useful for dialing into systems that require a code.
To insert a pause, enter a phone number then
1
press [OPTIONS]. Select either a Hard Pause
(“P” appears) or a Timed Pause (“T” appears).
Press to dial or to store.
2
Please refer to page 30 for more details about
storing a phone number.
ANSWERING A CALL
To answer a call, press any key except , ,
1
or .
l By pressing , you can select either “Any Key”
or “Send Key” to answer a call. lf “Send Key” is selected, the
phone can only be answered by pressing .
See page 89 for more information.
To end the call, press .
2
In Auto Answer Mode a call is automatically answered after a
preset time of ring tones. See page 90 for more details.
3 WAY CALL FUNCTION
With 3-Way Calling, you can talk to two people at the same time. When
using this feature, the normal airtime rates will be applied for each of the
two calls.
Enter the number you wish to call then press .
1
Once you have established the connection,
2
enter the second number you wish to call then
press .
C
H
2
22
When you’re connected to the second party,
3
press again to begin your 3-Way call.
If one of the people you called hangs up during your call, you
and the remaining caller stay connected. If you initiated the call
and are the first to hang up, all three callers are disconnected.
23
BASIC FUNCTIONS BASIC FUNCTIONS
CALLER ID FUNCTION
Identifies caller by displaying their phone number. If the caller’s name
and number are already stored in your phone book, they both will
appear.
C
H
The caller ID is stored in the call history.
2
CALL WAITING FUNCTION
Notifies you of an incoming call when you are already on a call by
sounding a beep tone and displaying the caller’s phone number.
To answer another call while on the phone,
1
press . This places the first call on hold.
To switch back to the first caller, press
again.
Call Waiting is a system dependent feature. Please contact your
service provider for details.
ADJUSTING VOLUME
Adjusts the volume of the ringer, voice call, key beep, messages,
speaker, power on and power off.
Press [MENU] then select one
1
of the following.
l
Ringer : Controls the ringer volume.
l
Voice Call : Controls the earpiece volume.
l
Key Beep : Controls the key pad tone.
l
Messages : Controls the received messages alert volume.
l
Speaker : Controls the speaker volume.
l
Power On : Controls the power on volume.
l
Power Off : Controls the power off volume.
ETIQUETTE
Mutes key tones and activates the vibration mode to alert you of an
incoming call or message.
To turn Etiquette Mode on/off, press and hold .
1
will be displayed to indicate Etiquette Mode
is active.
KEY GUARD
The Key guard feature of your cellular telephone locks the keypad to
protect against accidental key presses when the phone is turned on
and no call is in progress. You can still answer or silence an incoming
call.
To enter Key Guard mode, press and hold .
1
To unlock Key Guard mode, press 1, 2, 3.
2
Key Guard feature will deactivate when the phone is
l
powered off. Upon next power up, you will need to
press to activate Key Guard again.
C
H
2
Adjust volume then press to save it.
2
To adjust earpiece volume during a call, press the Navigation
Key up or down.
24
25
DURING A CALL DURING A CALL
To display menu options during a call, press [MENU].
MUTE (UNMUTE)
The caller cannot hear you or any sounds from your side but you can
still hear them.
C
H
2
Press [MENU] .
1
l
To deactivate, press [MENU] .
l
The phone will automatically unmute in Emergency
Call or Callback mode.
SPEAKER MODE
Activates the speaker phone when you are on a call. The phone
returns to normal (speaker phone off) after ending a call or when the
phone is turned off and back on.
Press [MENU] .
1
SILENT (SILENT QUIT)
Prevents the other end from hearing tones if any key is accidentally
pressed during a call.
Press [MENU] .
1
l
To deactivate it, press [MENU] .
SEND MY PHONE #
Automatically transmits your phone number to a pager during a call.
(Dependent on pager service)
PHONE INFO.
Notifies you of your handset information.
Please see page 93 for more details.
Press [MENU] .
1
PHONEBOOK
Display the Phonebook menu.
Press [MENU] .
1
CALL HISTORY
Display the Call History menu.
Press [MENU] .
1
MESSAGES
Enables you to send a message (SMS) during a call.
(Refer to page 103 for more details.)
Press [MENU] .
1
C
H
2
Press [MENU] .
1
LOCATION
Enables the network to locate your current location through Global
Positioning System (GPS). (Refer to page 82 for more details.)
Press [MENU] .
1
26
27
MAKING AN EMERGENCY CALL
This 911 feature puts the phone in the Emergency Call Mode when
you dial the preprogrammed emergency number, 911.
It also operates in the lock mode and out of the service area.
911 IN LOCK MODE
C
The 911 call service is available even in the lock mode.
H
2
Enter “911” then press .
1
Chapter 3
The call connects.
2
The phone exits the Lock Mode for 5 minutes.
3
When the call ends, the phone returns to the Lock Mode.
l
911 USING ANY AVAILABLE SYSTEM
Enter “911” then press .
1
The call connects.
2
The phone maintains the Emergency Mode
3
for 5 minutes.
l
While the phone is in the emergency mode for 5 minutes,
the phone can receive an incoming call from any available
system. However, it can’t make a call.
MEMORY FUNCTION
This chapter addresses memory functions including:
STORING A PHONE NUMBER
ENTERING LETTERS, NUMBERS & SYMBOLS
MAKING A CALL THROUGH THE PHONE BOOK
C
H
3
28
29
STORING A PHONE NUMBER
ENTERING LETTERS, NUMBERS & SYMBOLS
The phone book stores up to 300 entries.
Enter phone number then press .
1
Choose “New Entry” or “Existing Entry”.
2
Press [OK] to select.
If “New Entry” is selected, the phone # will
3
appear above a list of icons. The name of the
C
H
.
3
icon is displayed below the list.
Press the Navigation Key left or right to choose
the type of # you’re adding, as indicated by the
icon. Press [OK] to select.
If “Existing Entry” is selected, the Find screen
will appear. Select the contact name you are
editing then press . The new number will
appear above the list of icons. Select the type
of # you’re adding then press [OK].
Enter a name then press .
4
Please refer to page 31 for more details on
entering letters, numbers & symbols.
To change the input mode, press [Abc].
Press the Navigation Key down to select the
group. To select other options, press the
Navigation Key down.
Group : Family, Friends, Work, Etc.
l
l
Ringer.
Graphic.
l
Memo.
l
l
Set Secret : Lock, Unlock.
l
The other fields are set to Numeric mode as a default.
To store the entry, press [SAVE].
5
“Phone Book Entry Saved!” or “Entry edited!”
will be displayed.
30
The input mode (Alpha editor) will be automatically activated when
necessary to enter letters and numbers. As shown below, there are
4 available modes: Standard input mode (Abc), T9 input mode
(T9Word), Numeric mode (NUM), and Symbol mode (Symbols).
The input mode indicator appears on the lower right
of the display when letters and numbers are entered.
To select the desired input mode among the 4 modes
below, press [MODE], then enter letters and
numbers.
Input mode indicator
T9Word : T9 mode
Abc : Abc mode
NUM : Number mode
Symbols : Symbol mode
The following illustrates the function assigned to each key in the
Alpha Editor.
KEY FUNCTION
Press to change mode.
Mode
Next
Space
Caps Lock
Clear
Save
[T9Word][Abc][NUM][Symbols]
Press to view the next matching word if
the highlighted word is not the word you
intended.
Press to accept a word and add a space.
Press to select a letter case of the
standard text input or T9 text input mode.
[Abc], [ABC], and [abc] indicate the
standard text input.
[T9Word], [T9WORD], and [T9word]
indicate the predictive text input.
Press to delete a character to the left of
the cursor.
Press to store the letters and numbers you
enter.
31
C
H
3
ENTERING LETTERS, NUMBERS & SYMBOLS
ENTERING LETTERS, NUMBERS & SYMBOLS
STANDARD INPUT MODE
Use the digit keys to enter letters, numbers and characters.
Enter letters using the key pad as follows:
1
1
Key Pad
1
2ABC
C
H
3
3DEF
4GHI
:
9WXYZ
Time
1
A
D
G
W
Repetitions
:
2 times
.
B
E
H
:
X
Repetitions
3 times
@
C
F
Y
To change the input mode, press [Abc].
To enter a space, press . The cursor will
2
automatically move to the next column.
Repeat until letters are entered.
3
Text Messages have a 140-character limit.
To delete one digit, press . To delete the
4
entire entry, press and hold .
To change from lowercase to uppercase,
5
press .
Select Abc mode by pressing [Abc].
When you select this mode, the Abc icon appears as a visual
confirmation.
- Find the key that corresponds to the letter you want to enter.
- Press it as many times as needed for the letter to appear on the
screen.
- To enter the name “John”:
Press [ ] J
Press [ ] o
Press [ ] h
Press [ ] n
I
:
Repetitions
4 times
-
2
3
4
:
Z
Repetitions
5 times
’
A
D
G
:
9
T9 INPUT MODE
The T9 input mode incorporates a built-in-dictionary to determine a
word based on the entered characters. A word can be entered more
quickly by pressing a key once per character.
Select the T9Word mode by pressing [Abc].
1
Press a digit key once to enter the character
2
you want then enter all the characters to input
the word you want.
To view the next matching word, press .
3
To accept the matching word then enter a space,
4
press .
To enter a compound word:
•
Enter the first part of the word then press to accept it.
•
Enter the last part of the word then press to enter the word.
To enter “hilltop” in the T9 input mode:
- Press [Abc] to select the T9 input mode and to choose the
small letter case (T9Word).
- Press and you will see “hill” highlighted.
Press to select it.
- Press and you will see “top” highlighted.
Press to select it.
C
H
3
32
33
ENTERING LETTERS, NUMBERS & SYMBOLS
MAKING A CALL THROUGH THE PHONE BOOK
NUMERIC MODE
Allows you to enter numbers.
To enter Numeric Mode, press [Abc] then
1
select “NUM”.
To enter a number, press a digit key.
2
C
H
3
SYMBOL MODE
Allows you to enter symbols.
To enter Symbol Mode, press [Abc]
1
then select “Symbols”.
Select the symbol you want to enter with the
2
Navigation Key.
l Use the Navigation Key to view a different line of symbols.
Press [ ],
or
Press [ ],
SPEED DIAL#’S
Press [MENU] .
1
To assign a phone number to a location, select
2
the location then press [SET].
If a phone number is already assigned to the
l
location, press [ERASE] and or [YES] to delete.
Select the entry with the Navigation Key then
3
press .
If the entry is set to secret, you will be asked for your
l
password.
•
“Unassigned” appears if the location is available.
•
If a phone number is set as Secret, you will have to enter the
password.
•
To call an assigned number, press & hold the last digit of the
speed dial #.
“Speed Dial # number edited” will be displayed.
4
C
H
3
34
35
MEMO
Chapter 4
C
H
3
This chapter addresses accessing the menu and using its functions
and features to customize your cellular telephone.
MENU FUNCTION
MY ACCOUNT
PICTURES
MY STUFF
CALL HISTORY
PHONE BOOK
TOOLS
SETTINGS
C
H
4
36
37
PICTURESMY ACCOUNT
You can manage your Virgin Mobile account from your phone. The
basic tasks are summarized below. For more information about your
Virgin Mobile account, visit virgin.com/mobile.
CHECKING YOUR ACCOUNT BALANCE
You can check the amount of money remaining in your Virgin Mobile
account right from your phone.
From the main screen, press [MENU]
1
“My Account”.
TOP-UP YOUR ACCOUNT
You can Top-Up your account over the air.
To Top-Up your account over the air using your phone, you need a
C
credit card registered with Virgin Mobile and service on your phone.
H
Top-Up is how you add money to your Virgin Mobile account. It’s like
filling up your gas tank before you hit the road. You can Top-Up your
4
account right from your phone, but first you’ll have to buy a Top-Up
card from one of the thousands of stores that carry them or register a
credit card with Virgin Mobile.
Press [MENU] “My Account”.
1
2
Press [OK] to proceed.
TAKE A PHOTO
Taking pictures with your phone’s working integrated camera is as simple
as choosing a subject, pointing the lens, then pressing a button. You can
activate the Camera Mode and take pictures when the phone is open.
TAKING A PICTURE THROUGH THE MENU
Press [MENU] .
1
Point the camera lens at your subject.
2
You can check the picture framing through the
main display screen.
To take the picture, press or the Side
3
Camera button.
To send the picture to someone, press [NEXT]
4
then select “Send Picture”.
You can receive a call while in the Camera Mode, but not
when sending a picture to someone. When this occurs, all
incoming calls will be automatically forwarded to voice mail.
TAKING A PICTURE IN IDLE MODE
To activate Camera Mode, press the Side
1
Camera button.
C
H
4
38
Point the camera lens at your subject.
2
You can check the picture framing through the
main display screen.
To take the picture, press the Side Camera
3
button.
To send the picture to someone, press [NEXT]
4
then select “Send Picture”.
39
PICTURESPICTURES
TAKING A PICTURE WITH THE PHONE CLOSED
To activate camera mode, press and hold the
1
side camera button.
Point the camera lens at your subject.
2
You can check the picture framing through
the sub display screen.
To take the picture, press the Side Camera
3
button.
C
H
4
40
CAMERA MODE OPTIONS
When the phone is open and in Camera Mode, several user options
are available.
RESOLUTION
Press the Navigation Key up or down to adjust the picture size from
High (640x480 pixels) to Med (320x240 pixels) to Low (160x120 pixels).
The current picture size appears at the top left of the display screen.
ZOOM
Press the Navigation Key left or right to change the magnification.
(Zoom to 1x, 2x or 4x magnification.). The Zoom Magnification appears
at the top right of the display screen.
UNDER [OPTIONS]
SELF PORTRAIT
Switch the viewfinder to the Sub LCD. (Take a picture of yourself by
checking the view on the Sub LCD.)
FLASH
Activate the flash function. (Off / On this shot / Always On)
SELF TIMER
Activate the camera’s timer function. (Off / 5 Secs / 10 Secs)
FUN FRAME
Select your favorite fun picture frame to decorate your picture then
press [SEL]. (Off / Angel Heart / Birthday / Bohemian / Bubble Bath /
Celebration / Circular Eyes / Coffee / Cupid / Enamored / Enlargement /
Female / Flower Frame / Flower Mirror / Frog / Funny Lips / Gentleman / Gift /
Ice Cream / Koala / Love Frame / Love Heart / Love Tree / Magic
Santaclause / Male / My Christmas / Noon Window / Postage Stamp /
Princess Frame / Red Man / Rose Grove / Santaclause / Seashore / Sexy
Lips / Sexy Woman / Sunflower / Sunglasses / Tree Frame / White Christmas
/ White Window / Winter Frame)
IMAGE CONTROLS
Select an option from the following. (Brightness / Image Effect / Quality)
SHUTTER SOUND
Select a shutter sound. (Shutter 1 / Shutter 2 / Say “Cheese” / Ready 123)
DATE
Display date on the take picture. (On/Off)
GO TO MY PICTURES
Go to your phone’s picture storage folder.
41
C
H
4
PICTURESPICTURES
MY PICTURES
Press [MENU] .
1
Select an option from the following then
2
ONLINE ALBUMS
Press [MENU] .
1
Select a picture from your online Picture Mail.
2
press [OK].
To access the in online camera options, press
In Camera: To view photos you have captured with your camera.
l
Save to Phone: To view the folder storing pictures you have
l
To access the in camera options, press
3
downloaded or assigned.
[OPTIONS].
Upload to Albums: To select an option to upload pictures saved
C
H
4
l
Assign: To assign the selected picture to display for specific
l
l
l
l
l
tasks: (Picture ID / Screen Saver / Incoming Call)
Take New Picture: To return to Camera mode to take
Erase: To erase selected pictures, select an option and then
press [OK].
Edit Caption: To enter or edit a caption for the picture.
Picture Info: To display picture information such as caption,
in your phone to the Picture Mail Website.
another picture.
time/date, size, etc.
3
[OPTIONS].
Download: To download the selected picture file to your
l
Edit/Erase: Copy/Move-To copy or move pictures to a
l
Picture Info: To display information on the selected picture,
l
New Album: To create a new album.
l
Album List: To display album list.
l
Goto Picture: To take a new picture.
l
Expand: To switch the display from thumbnail to full-screen
l
mobile phone.
selected album.
Edit Caption-To edit the picture’s caption.
Erase-To erase pictures saved in the current
album (or Uploads). Select This Picture,
Selected Pictures, or All Pictures.
Rotate Picture-To rotate the selected picture.
such as title,time/date,size,etc.
view.
C
H
4
To access the save to phone options, press
[OPTIONS].
Assign Picture ID: To display the picture for incoming calls from a
l
Assign Screen Saver: To display the picture as an LCD screen
l
Assign Incoming Call: To display the selected picture for all
l
Erase: Erase the current picture from your mobile phone.
l
Expand: To switch the display from thumbnail to full-screen view.
l
specific Contacts list entry.
saver.
incoming calls.
ACCOUNT INFO
After storing the data [Picture and Other files] on the MMS server, the
user can check the downloaded information on the web through their
account.
Press [MENU] .
1
4
To access “Send Picture Msg” from the
“In Camera” menu option, press [SEND].
42
43
MY STUFFMY STUFF
Your cellular telephone provides a unique feature -My Stuff- that
enables you to download games, ringtones, images, applications and
more from your network to your cellular telephone. Please contact
your service provider for the availability of these services.
START MY STUFF
To launch “My Stuff” from the standby mode,
1
press [MENU] .
When five or more icons appear on the screen,
2
select an application with Navigation Key.
To start the application, press .
3
C
H
4
To end the application, press .
4
The phone will return to the standby mode.
RINGTONES
You can download the latest ringtones right to your phone.
Charges apply. See virgin.com/mobile
Press [MENU] .
1
Select “Get New” then press [OK].
2
You will be taken to the “Ringtones” download
menu.
for details.
SCREEN SAVERS
You can download the latest screen savers right to your phone.
Charges apply. See virgin.com/mobile for details.
Press [MENU] .
1
Select “Get New” then press [OK].
2
You will be taken to the “Screen Savers”
download menu.
Use the Navigation Key to select the Screen
3
Savers you wish to download.
From the item information page, select “Buy”.
4
Verify your password at the prompt.
A confirmation page will notify you that the
5
Screen Savers have been purchased.
To download the Screen Savers, select
“Download”.
C
H
4
Use the Navigation Key to select the ringtones
3
you wish to download.
From the item information page, select “Buy”.
4
Verify your password at the prompt.
A confirmation page will notify you that the
5
ringtone has been purchased. To download the
ringtone, select “Download”.
4544
MY STUFFMY STUFF
GAMES
You can download the latest games and play them right on your
phone. Charges apply. See virgin.com/mobile for details.
Press [MENU] .
1
Select “Get New” then press [OK].
2
You will be taken to the “Games” download
menu.
Use the Navigation Key to select the game you
3
wish to download.
C
H
4
From the item information page, select “Buy”.
4
Verify your password at the prompt.
A confirmation page will notify you that the game
5
has been purchased. To download the game,
select “Download”.
APPLICATIONS
You can download the latest applications right to your phone. Charges
apply. See virgin.com/mobile for details.
Press [MENU] .
1
Select “Get New” then press [OK].
2
You will be taken to the “Applications” download
menu.
Use the Navigation Key to select the “Applications”
3
you wish to download.
From the item information page, select “Buy”.
4
Verify your password at the prompt.
A confirmation page will notify you that the
5
application has been purchased. To download
the application, select “Download”.
C
H
4
4746
MY STUFF
CALL HISTORY
OTHERS
You can download other information right to your phone. Charges
apply. See virgin.com/mobile for details.
Press [MENU] .
1
Select “Get New” then press [OK].
2
You will be taken to the “Others” download
menu.
Use the Navigation Key to select the item you
3
wish to download.
C
H
4
From the item information page, select “Buy”.
4
If you have not previously purchased an item,
you will be prompted to enter your account
password and create your purchasing profile.
A confirmation page will notify you that the item
5
has been purchased and is stored in the “My
Downloads” folder.
In idle mode, you can access call history by pressing [MENU] .
ALL CALLS
Displays information about the 60 most recent incoming, outgoing or
missed calls.
To see a list of the 60 most recent incoming,
1
outgoing or missed calls, press [MENU]
or . If the number is already stored in
your phone book, only the name appears. If the
number is not stored, only the phone number
appears.
To view call details, press .
2
Call details include date, time, and phone number.
Press [OPTIONS]. Select “SAVE” to save it
3
or press [ERASE] to delete it.
Save: Stores the phone number in your phone book.
l
Send Text: To send a text message to the phone number.
l
Send Picture: To send a picture to the phone number
l
Prepend: Adds numbers to the beginning of the phone
l
Erase All: To erase the recent calls list.
l
(Virgin Mobile phone numbers only).
number.
C
H
4
48
48
After 20 incoming, outgoing or missed calls, the oldest
call will automatically be erased from the history.
49
CALL HISTORYCALL HISTORY
OUTGOING CALLS
Displays information of the 20 most recent outgoing calls.
Place a call to a outgoing call by simply pressing .
To see a list of the 20 most recent outgoing
1
calls, press [MENU] or .
If the number is already stored in your phone
book, only the name appears. If the number is
not stored, only the phone number appears.
To view outgoing call details, press .
2
C
H
4
Call details include date, time, and phone number.
Press [OPTIONS]. Select “SAVE” to save it
3
or press [ERASE] to delete it.
Save: Stores the phone number in your phone book.
l
Send Text: To send a text message to the phone number.
l
Send Picture: To send a picture to the phone number
l
Prepend: Adds numbers to the beginning of the phone
l
Erase All: To erase the outgoing calls list.
l
After 20 outgoing calls, the oldest call will automatically be
erased from the history.
(Virgin Mobile phone numbers only).
number.
INCOMING CALLS
Displays information of the 20 most recent incoming calls.
Place a call to a incoming call by simply pressing .
To see a list of the 20 most recent incoming
1
calls, press [MENU] or .
If the number is already stored in your phone
book, only the name appears. If the number is
not stored, only the phone number appears.
To view incoming call details, press .
2
Call details include date, time, and phone number.
Press [OPTIONS]. Select “SAVE” to save it
3
or press [ERASE] to delete it.
Save: Stores the phone number in your phone book.
l
Send Text: To send a text message to the phone number.
l
Send Picture: To send a picture to the phone number
l
Prepend: Adds numbers to the beginning of the phone
l
Erase All: To erase the incoming calls list.
l
After 20 incoming calls, the oldest call will automatically be
erased from the history.
(Virgin Mobile phone numbers only).
number.
C
H
4
50
51
CALL HISTORY CALL HISTORY
MISSED CALLS
Displays information of the 20 most recent missed calls.
Place a call to a missed call by simply pressing .
To see a list of the 20 most recently missed
1
calls, press [MENU] or .
If the number is already stored in your phone
book, only the name appears. If the number is
not stored, only the phone number appears.
To view missed call details, press .
2
C
H
4
Call details include date, time, and phone number.
Press [OPTIONS]. Select “SAVE” to save it
3
or press [ERASE] to delete it.
Save: Stores the phone number in your phone book.
l
Send Text: To send a text message to the phone number.
l
Send Picture: To send a picture to the phone number
l
Prepend: Adds numbers to the beginning of the phone
l
Erase All: To erase the missed calls list.
l
After 20 missed calls, the oldest call will automatically be
erased from the history.
(Virgin Mobile phone numbers only).
number.
ERASE HISTORY
Erases individual Call History entries.
ALL CALLS
Press [MENU] or .
1
You will see a message on the display
2
(Erase All calls?).
Select [YES] or [NO]. Select “Yes” to
3
erase all of the entries from your Call History list.
OUTGOING CALLS
Press [MENU] or .
1
You will see a message on the display
2
(Erase Outgoing calls?).
Select [YES] or [NO]. Select “Yes” to
3
erase all outgoing calls from your Call History list.
INCOMING CALLS
Press [MENU] or .
1
C
H
4
52
You will see a message on the display
2
(Erase Incoming calls?).
Select [YES] or [NO]. Select “Yes” to
3
erase all incoming calls from your Call History list.
53
CALL HISTORY CALL HISTORY
MISSED CALLS
C
H
4
Press [MENU] or .
1
You will see a message on the display
2
(Erase Missed calls?).
Select [YES] or [NO]. Select “Yes” to
3
erase all missed calls from your Call History list.
AIR TIME
Checks the usage time and manages your calls within the limit you set.
LAST CALL
Displays usage time of last call.
Press [MENU] or .
1
The last call time appears on the display.
2
To return to the previous page, press [OK].
3
ALL CALLS
Displays usage time of all incoming and outgoing calls, excluding web
access calls.
Press [MENU] or .
1
View the time of the following items:
2
Voice Call : To display the total number of voice calls and
l
Data/Fax Call : To display the total number of data/fax
l
total air time.
calls and total air time.
C
H
4
54
To return to the previous page, press [OK].
3
55
PHONE BOOK PHONE BOOK
Stores up to 300 entries, each of which can be assigned to a group.
Entries can be retrieved by name or group.
FIND
Retrieves an entry by name and calls by simply pressing [FIND].
You can review all the entries stored in your phone book list or find an
entry quickly by entering a name or its character string.
Press [MENU] .
1
2
The list of names in your phone book is
displayed alphabetically.
Use Navigation Key to select the name.
Enter a name or its character string or scroll
C
H
4
3
through the list with the Navigation Key.
Please refer to page 31 for more details on
entering letters, numbers & symbols.
All matching entries will be displayed. Highlight
4
an entry. To edit the entry, press .
Press [OPTIONS] to view options.
If the contact has a mobile phone number your
options will be 1. Send Text, 2. Send Picture,
3. Prepend, 4. View or 5. Erase. If only an email or
web address is saved for the contact, your
options will be 1. Send Text, 2. Send Picture,
3. View or 4. Erase.
l
If the entry is set to secret, you will be asked for your password.
(Refer to page 83 for password information.)
Please refer to page 103 or page 104 for more
details on “Send Text” & “Send Picture Msg”.
To call the selected number, press .
5
NEW ENTRY
Adds a new entry.
To add a new entry to the phone book,
1
press [MENU] .
To enter a name or number, use the Navigation
2
Key to select the phone book field.
PHONE BOOK FIELDS :
l
Name/Mobile/Home/Office/Pager/Fax/E-Mail/Group/Ringer
/Graphic/Memo/Set Secret.
Please refer to page 31 for more details on entering
letters, numbers & symbols.
3.1 To save the entry, press [SAVE].
3
3.2 To return to the previous page, press .
C
H
4
56
57
PHONE BOOK PHONE BOOK
SPEED DIAL#’S
In idle mode, calls can be placed to numbers stored in speed dial by
pressing & holding the location number on the key pad. For a 2-digit
location number, press the first number, then press and hold the
second number.
Press [MENU] .
1
To assign a phone number to a location, select
2
the location then press [SET].
If a phone number is already assigned to the
l
location, press [ERASE] and [OK] to delete.
Select the entry with the Navigation Key then
C
H
4
3
press .
If the entry is set to secret, you will be asked for your
l
password.
•
“1 Key” is used for One-Touch voicemail dial feature.
•
“Unassigned” appears if the location is available.
•
If a phone number is set as Secret, you will have to enter
the password. (Refer to page 83 for password information.)
•
To call an assigned number, press & hold the last digit of
the speed dial #.
“Speed Dial # number edited” will be displayed.
4
GROUP
Allows you to classify phone entries into groups. Existing groups
include Family, Friends, Work, Etc. and All. A maximum of seven
groups is allowed.
ADD NEW GROUP
To add a new group, press [MENU] .
1
A maximum of seven groups is allowed.
Press [OPTIONS] to select “Add Group”,
2
then press .
Input a new group name.
3
To save, press .
4
CHANGE GROUP NAME
Press [MENU] .
1
Select an existing group name with the
2
Navigation Key.
To select “Rename”, press [OPTIONS].
3
C
H
4
MY PHONE #
To display your phone number and service provider:
Press [MENU] .
1
To return to the previous page, press [OK].
2
58
Input a new group name.
4
To save, press .
5
59
PHONE BOOK TOOLS
ERASE GROUP
1
2
3
4
C
H
4
Press [MENU] .
Use the Navigation Key to select, then delete
the group.
To delete it, press [ERASE].
To erase it, press or [YES].
The default group names (All, Etc.) cannot be erased.
SCHEDULE
Sets schedule and reminds you of that event.
ADD NEW PLAN
Press [MENU] .
1
Move the Navigation Key left, right, up or down to
2
choose a date in the calendar then press .
To select the following alarm options, press the
3
Navigation Key down:
DATE
Use the keypad to change or enter the date
then press [OK].
TIME
Use the keypad to set a time to select “AM”
or “PM”, then press .
PLAN
Use the keypad to input a plan message then
press .
SETTING
Using the Navigation Key select an alert time
interval option (On Time, 10 Min Before,
30 Min Before, 1 Hour Before, No Alarm).
C
H
4
60
RINGER
To set a Ringer, press [OPTIONS], then select
“Default” or “Change” using the Navigation Key.
To save it press .
Default : To set default ringer type.
Change : To set custom ringer type.
To select “Music Bells” or “Tones” with Navigation Key.
Press to play or pause sound.
61
TOOLS
TOOLS
C
H
4
Press [SAVE] to save it or [CLR] to
4
return to the calendar.
The date of the event will be marked on your
5
calendar.
VIEW PLAN
To view the Event List,
1
press [MENU] .
Move the Navigation Key to choose an event
2
then press or [ERASE].
Press [OPTIONS], then select “Add Plan” or
“Erase All” using the Navigation Key.
If you select “Add Plan” using the Navigation
Key. To add a new event.
If you select “Erase All” using the Navigation
Key. “Erase all plans?” will appear, then select
“Yes” or “No”.
Press to delete.
MEMO PAD
Your cellular telephone includes an internal memo pad that can be
used to compose and store reminders and notes.
ADD MEMO
To compose a memo (there is an 80-letter limit):
Press [MENU] .
1
Input a new text memo.
2
(Please refer to page 31 for more details on entering letters,
numbers & symbols.)
To save memo, press .
3
VIEW MEMO
To view a saved memo:
1.1. Press [MENU] .
1
1.2. To erase a memo, press [ERASE].
1.3. To add a new memo, press [OPTIONS]
“New Memo”.
1.4. To erase all memos, press [OPTIONS]
“Erase All”.
The list of all memos, in saved order, is displayed.
2
Select a memo then press .
C
H
4
62
62
The selected memo will appear. To edit it,
3
press [OPTIONS], select “Edit” and input a
new text memo.
Press to save edited memo.
4
63
TOOLS
TOOLS
SETTINGS
To select memo pad background image:
Press [MENU] .
1
Select (Paper/Pattern/Sea/Sky/Flower) with the
2
Navigation Key (left or right) then press [OK].
C
H
4
ALARM
You can set up to 3 alarms.
To display alarm entries, press [MENU] .
1
Select one of the entries using the Navigation Key.
2
To set a new alarm, choose alarm 1, 2 or 3.
To edit an existing alarm, select that alarm.
Press .
To erase an existing alarm, press [ERASE].
Press the Navigation Key down to select alarm
3
options.
SETTING
Use the Navigation Key to select a setting for the
alarm (Daily/Weekly/Monthly/Off/Once).
Once : Select the single date of the alarm.
Daily : Select the alarm for the same time each day.
Weekly : Select “Monday”, “Tuesday”, “Wednesday”,
“Thursday”, “Friday”, “Saturday”, “Sunday”.
Monthly : Select day 1-31
Off
DATE
Use the keypad to change or enter the date for
the alarm then press [OK].
C
H
4
64
64
TIME
Use the keypad to set a time for the event
to select “AM” or “PM”, then press .
SNOOZE SETTING
Use the Navigation Key to select a Snooze Setting
(No use, 1 time after 5 min, 1 time after 10 min,
3 times by 5 min).
65
TOOLS TOOLS
RINGER
To set a “Ringer” press [MENU], then select
“Default” or “Change” using the Navigation Key.
To save it, press .
Default : To set default ringer type.
Change : To select a custom ringer from the list.
CALCULATOR
To access the calculator:
Press [MENU] .
1
Follow the instructions below to calculate
2
(8*6)/4-2.5=9.5
PLAN
Using the keypad, input an alarm message then
press .
To save an alarm setting press [SAVE].
4
C
H
4
Input 8.
Move the Navigation Key rightward.
Input 6 then press the Navigation Key.
Move it leftward.
Input 4 then press the Navigation Key.
Move it downward.
Input 2 then press the to input (.).
Press 5.
Press to see the answer.
: X, : -, : /, : +, : ., : Reset, : =.
To reset, press [RESET].
3
C
H
4
66
67
TOOLS TOOLS
STOPWATCH
Simultaneously times up to six different events. To operate the
stopwatch:
Press [MENU] .
1
To measure a time period.
2
1. To start the stop watch, press or [START].
2. To pause it, press or [STOP].
3. To resume it, press . To Reset it press
[RESET]. To return to the previous page,
press .
To time up to six events at once:
C
H
4
3
1. To start, press or [START].
2. To stop a time period and continue
measuring another one, press [CONT].
3. To stop the second and continue measuring
a third one, press [CONT].
4. To measure up to six time periods, repeat the
above steps.
5. To stop the stop watch, press [STOP].
6. To review the results, press [VIEW].
7. To return to the stop watch, press [OK].
8. To reset it, press [RESET].
WORLD CLOCK
To display the time and date in pre-programmed cities:
Press [MENU] .
1
Select a city.
2
The world map appears with the city, its date
3
and time.
Use the Navigation Key to select another city.
Since Daylight Savings Time (DST) is not applied, the actual time
during DST may be different.
To return to the previous page, press [OK].
4
C
H
4
68
69
SETTINGS
SETTINGS
Customizes your cellular telephone and optimizes performance
through a variety of settings.
SOUNDS
Sets Volume, Ringers, Alerts, Roam Ringer, Tone Length.
VOLUME
Controls the Ringer, Voice Call, Key Beep, Messages, Speaker,
Power On and Power Off. Volume setting can be changed by using
one of the following (Navigation Key, Side buttons, “Min”, “Max”
Selection).
RINGER
Controls the Ringer volume and alerts you to incoming calls in the
following modes.
C
H
Press [MENU] .
1
4
Select one of the following options by pressing the
2
Navigation Key to the right then press [OK].
Silence All : Mute all of the sounds, press [Min].
Ringer Off : Mute the ringer only.
Vibrate On : Vibrate instead of the ringer and sms alert.
Ringer Mode : Up & Down (Level 1~5)
High & Vib : Play the sounds and vibrate as the ringer
at the same time, press [Max].
VOICE CALL
To adjust earpiece volume:
KEY BEEP
To adjust key pad tone:
Press [MENU] .
1
Adjust the key pad tone with the Navigation Key
2
then press [OK].
Off (Min- )
Level 1 - 5 (level 5, Max- )
MESSAGES
To adjust messages volume:
Press [MENU] .
1
Adjust the message volume using the
2
Navigation Key then press [OK].
Ringer Off (Min- )
Vibrate On
1-Beep
Ringer Mode : Up & Down (Level 1~5, Max- )
SPEAKER
To adjust speaker phone volume:
Press [MENU] .
1
C
H
4
Press [MENU] .
1
Adjust the earpiece volume with the
2
Navigation Key then press [OK].
Level 1-5 (Min- , Max- )
70
Adjust the speaker phone volume using the
2
Navigation Key then press [OK].
Level 1-5 (Min- , Max- )
71
SETTINGS
SETTINGS
POWER ON
To adjust power on volume:
Press [MENU] .
1
Adjust the power on volume using the
2
Navigation Key then press [OK].
POWER OFF
To adjust power off volume:
Press [MENU] .
C
H
4
1
Adjust the power off volume using the
2
Navigation Key then press [OK].
Off (Min- )
Level 1 - 5 (level 5, Max- )
Off (Min- )
Level 1 - 5 (level 5, Max- )
RINGERS
To select a ringer type for incoming calls:
VOICE CALL
Press [MENU] .
1
Select “With Caller ID” or “No Caller ID” then
2
press [OK].
Select your desired ringer type.
3
Music Bells : Radetzky March, Peer Gynt Suite No.1, Opera
from La Traviata, A theme by Mozart, Behind story, Funky,
My friend rudy, Virgin Mobile, music1, music2, music3.
Ring Tones : Ring Tone 1~5.
Downloads : Downloaded ringer types and familiar music.
Press to play or pause sound.
Select one of the available ring types.
4
To confirm, press [OK].
MESSAGES
To select a ringer type for receiving messages:
Press [MENU] .
1
Select your desired ringer type.
2
Music Bells : Radetzky March, Peer Gynt Suite No.1, Opera
from La Traviata, A theme by Mozart, Behind story, Funky,
My friend rudy, Virgin Mobile, music1, music2, music3.
Tones : Tone 1~10.
Downloads : Downloaded ringer types and familiar music.
Press to play or pause sound.
C
H
4
72
Select one of the available ring types.
3
To confirm, press [OK].
73
SETTINGS
SETTINGS
VOICEMAIL
To select a ringer type for receiving voicemail:
Press [MENU] .
1
Select your desired ringer type.
2
Music Bells : Radetzky March, Peer Gynt Suite No.1, Opera
from La Traviata, A theme by Mozart, Behind story, Funky,
My friend rudy, Virgin Mobile, music1, music2, music3.
Tones : Tone 1~10.
Downloads : Downloaded ringer types and familiar music.
Press to play or pause sound.
Select one of the available ring types.
3
To confirm, press .
C
ALERTS
H
4
When selected, this setting alerts you to the following handset changes:
SERVICE
Sounds an alert when leaving a service area and entering a roaming
service area.
Press [MENU] .
1
Select “Off” or “On” with the Navigation Key then
2
press [OK] to save it.
MINUTE
Sounds an alert every minute during a call.
Press [MENU] .
1
FADE
Sounds an alert when the signal begins to fade.
Press [MENU] .
1
Select “Off” or “On” with the Navigation Key then
2
press [OK] to save it.
LOW SIGNAL
Sounds an alert when you encounter low signal strength during a call.
Press [MENU] .
1
Select “Off” or “On” with the Navigation Key then
2
press [OK] to save it.
ROAM RINGER
Sounds a different ringer when you are in a roaming service area.
Press [MENU] .
1
Select “Normal” or “Distinctive” with the
2
Navigation Key then press [OK] to save it.
Normal : Sounds the same ringer type as used in Home area.
l
Distinctive : Sounds a different ringer type in a roaming service
l
area.
C
H
4
Select “Off” or “On” with the Navigation Key then
2
press [OK] to save it.
CONNECT
Notifies you that a call has been successfully placed.
Press [MENU] .
1
Select “Off” or “On” with the Navigation Key then
2
press [OK] to save it.
74
TONE LENGTH
To adjust tone length:
Press [MENU] .
1
Select “Normal” or “Long” with the Navigation
2
Key then press [OK] to save it.
75
SETTINGS
SETTINGS
DISPLAY
Allows you to customize display.
MENU STYLE
To select a display menu style:
Press [MENU] .
1
Select “Fold”, “Grid” or “List” with the
2
Navigation Key then press [OK] to save it.
GRAPHICS
To select an LCD display:
C
H
SCREEN SAVER
4
Press [MENU] .
1
Select Default to choose a pre-installed display,
2
or Downloads or Saved to Phone to choose a
display you have downloaded to your phone.
To save it, press [SELECT].
3
POWER ON
POWER OFF
Press [MENU] .
1
Select Default to choose a pre-installed display,
2
or Downloads or Saved to Phone to choose a
display you have downloaded to your phone.
To save it, press [SELECT].
3
INCOMING CALL
Press [MENU] .
1
Select Default to choose a pre-installed display,
2
or Downloads or Saved to Phone to choose a
display you have downloaded to your phone.
To save it, press [SELECT].
3
SUB LCD
To change the sub LCD display clock image setting only:
Press [MENU] .
1
C
H
4
Press [MENU] .
1
Select Default to choose a pre-installed display,
2
or Downloads or Saved to Phone to choose a
display you have downloaded to your phone.
To save it, press [SELECT].
3
76
Select “Digital” or “Analog” with the
2
Navigation Key then press [OK].
77
SETTINGS
SETTINGS
GREETING
To input a personal greeting:
Press [MENU] .
1
Select “Setting”, “Font”, “Bg” or “Entry Message”
2
with the Navigation Key then press [SAVE].
Setting : On/Off.
l
Font : White, Blue, Dark blue, Magenta, Gray, Black.
l
Bg : Transparent, White, Blue, Yellow, Gray, Black.
l
Entry Message : Enter message (Maximum 16-string).
l
BACKLIGHT
C
H
Backlights the display and key pad for easy viewing in dark places.
4
LCD/KEY PAD
Press [MENU] .
1
Select “LCD” or “Key Pad” select the duration
2
with the Navigation Key, then press [OK].
LCD : 8 Secs/15 Secs/30 Secs/Always On.
l
Key Pad : 8 Secs/15 Secs/30 Secs/Always On/Always Off.
l
When the Subscriber terminal is connected to external power
(Hands Free Car Kit), the backlight setting automatically changes
to”Always On”.
CONTRAST
To adjust the display contrast:
MAIN LCD/SUB LCD
Press [MENU] .
1
Select “Main LCD” or “Sub LCD” then select one
2
of the following options with the Navigation Key
then press [OK].
Main LCD : Level 1~5.
l
Sub LCD : Level 1~5.
l
C
H
4
78
79
SETTINGS
SETTINGS
ROAMING
Your Cellular Telephone allows you to control your ability to roam.
By using the Roaming menu option, you can determine which signals
your cellular telephone accepts.
Press [MENU] .
1
Select one of the following options by pressing
2
the Navigation Key then press [OK].
Home Only: Only within your home area or home
Analog Only: Stays in the analog setting until the
C
H
4
Analog Home Only: Analog only within your home
Digital Only: Stays in the digital setting until the
Automatic: Scan the radio channels based on the
affiliated area.
hand set is powered on after being
powered off.
area or home affiliated area.
handset is powered on after being
powered off.
Automatic setting.
GAMES/TOOLS
BACKLIGHT
While playing a game, select how long the display screen and
keypad are backlit after pressing any key.
Press [MENU] .
1
Select one of the following options,
2
then press [OK].
8 Secs / 15 Secs / 30 Secs / Always On
VOLUME
Controls game volume while playing.
Press [MENU] .
1
Select one of the following options,
2
then press [OK].
Off (Min- )
Level 1 - 5 (level 5, Max- )
MSG ALERT
Displays the received SMS/Voice mail alert while playing a game.
C
H
4
80
Press [MENU] .
1
Select “On” or “Off” by pressing the Navigation
2
Key then press [OK].
81
SETTINGS
SETTINGS
LOCATION
Your Cellular telephone is equipped with a Location feature for use in
connection with location-based services that may be available in the
future. The Location feature allows the network to detect your
position. Turning Location off will hide your location from everyone
except 911.
Press [MENU] .
1
Read the message then press [OK].
2
Turning location “on” lets the network detect your geographic
location using GPS, making some features easier to use.
Turing location “off” disables GPS, but some features may
still detect your whereabouts using cell tower technology.
C
H
Except for basic telephone and 911 service, your location
information will only be used with your consent.
4
Select “On” or “Off” by pressing the
3
Navigation Key then press [OK].
On: Turning location “on” lets the network detect your
whereabouts using GPS.
Off: Turning location “off” disables GPS –except for 911 –but
cell tower technology may still used to detect your
whereabouts for some features and basic telephone
service.
SECURITY
Prevents unauthorized use of your cellular telephone. The following
settings can be restricted:
LOCK PHONE
Prevents the phone from being used without entering the password first.
Press [MENU] then enter “Password”.
1
The default password is the last 4 digits of your phone number.
Press then select “Lock Now”, “Lock On
2
Power Up” or “Unlock” then press [OK].
Lock Now : Lock the phone now.
l
Lock On Power Up : Do not lock the phone now, but it is
l
Unlock : Do not lock the phone.
l
automatically locked when power
recycled.
CHANGE LOCK
Changes your 4-digit password.
Press [MENU] then enter “Password”.
1
C
H
4
82
Press .
2
Enter a new password then press .
3
Enter the new password again then
4
press [OK].
83
SETTINGS SETTINGS
SPECIAL #’S
Stores 3 phone numbers that can be called even in the lock mode.
Press [MENU] then enter “Password”.
1
Press , select a location with the Navigation
2
Key, then press .
Input a phone number, press again to
3
save.
You can delete a special number by selecting it,
C
H
4
pressing [ERASE], then press [OK].
LIMIT USE
OUTGOING CALLS
Restricts all outgoing calls – except emergency calls – but allows an
incoming call to be placed.
Press [MENU] then enter “Password”.
1
Press select “Allow” or “Restrict” with
2
the Navigation Key, then press [OK].
Allow : Allows a dialed call.
l
Restrict : Restricts a dialed call.
l
Refer to page 83 for password information.
CALL HISTORY
Restricts access to call history.
Press [MENU] then enter “Password”.
1
Press select “Allow” or “Restrict” with
2
the Navigation Key, then press [OK].
Allow: Allow access to call history menu.
l
Restrict: Restrict access to call history menu.
l
PICTURES
Restricts access to pictures.
Press [MENU] then enter “Password”.
1
Press select “Allow” or “Restrict” with
2
the Navigation Key, then press [OK].
Allow : Allows access to the pictures menu.
l
Restrict : Restricts access to the pictures menu.
l
DATA CALLS
Restrict a data call from being placed.
Press [MENU] then enter “Password”.
1
Press select “Allow” or “Restrict” with
2
the Navigation Key, then press [OK].
Allow : Allows data calls.
l
Restrict : Restricts data calls.
l
C
H
4
84
85
SETTINGS SETTINGS
LONG DISTANCE
Restricts calling long distance numbers – the phone is limited to
calling numbers within the area.
Press [MENU] then enter “Password”.
1
Press select “Allow” or “Restrict” with
2
the Navigation Key, then press [OK].
Allow : Allows a long distance call.
l
Restrict : Restricts a long distance call.
l
ERASE PBOOK
C
To erase all the names and phone numbers in your internal
H
Phone Book:
4
Press [MENU] then enter “Password”.
1
Press .
2
Read the message (Erase Phone Book?) then
3
press [YES] or [NO].
ERASE DOWNLOADS
To erase all downloaded items:
RESET PICTURE ACCOUNT
To erase all photo album entries.
Press [MENU] then enter “Password”.
1
Press .
2
Read the message (Clear Token?) then
3
press [YES] or [NO].
RESET PHONE
Resetting the phone restores all the factory defaults, including the
ringer types and display settings. The internal Phone Book, Call
History, Scheduler, and Messaging are not affected.
Press [MENU] then enter “Password”.
1
Press .
2
Read the message (It'll be erase all data on your
3
phone. Reset Phone?) then press [YES] or
[NO].
When you select “Yes” you will see “Phone Reset! Your phone
will reboot now” on the display and your cellular telephone will
reset all settings to the factory defaults.
C
H
4
Press [MENU] then enter “Password”.
1
Press .
2
Read the message (Erase Downloads?) then
3
press [YES] or [NO].
86
87
SETTINGS
SETTINGS
AIRPLANE MODE
When your cellular telephone is in Airplane Mode, it cannot send or
receive any calls or access online information. In this mode you may
still use the phone’s other features such as Games and Voice Memos.
To set your cellular telephone to Airplane Mode:
Press [MENU] .
1
Read the message then press [OK].
2
Turn on airplane mode will prevent any outgoing and
l
Incoming calls as well as any online access.
You can make emergency calls regardless of airplane mode
l
setting.
C
H
4
Select “On” or “Off” by pressing the Navigation
3
Key.
To save your Airplane Mode setting,
4
press [OK].
While in Airplane Mode, your phone’s standby screen will display
“Phone off” and the Time/Date display disappears.
OTHERS
CALL ANSWER
To select an answer mode:
Press [MENU] .
1
Select “Any Key” or “Send Key” with the
2
Navigation Key then press [OK].
Any Key : Press any key to answer an incoming call except
l
Send Key : Press only to answer a call.
l
, , , and .
ACTIVE FLIP
Selects an Active Flip Answer mode as follows:
Press [MENU] .
1
Select “On” or “Off” with the Navigation Key
2
then press [OK].
When Active Flip On is selected, an incoming phone call can
l
be answered simply by opening the phone.
When Active Flip Off is selected, you will need to open the
l
phone and follow the Answer Mode you have selected.
C
H
4
88
89
SETTINGS
SETTINGS
AUTO ANSWER
To answer calls when your cellular telephone is connected to an
optional hands-free car kit or headset:
Press [MENU] .
1
Select “Hands Free Kit” or “Headset” with the
2
Navigation Key.
Select one of the following options then
3
press [OK].
Off / 5 Secs / 10 Secs / 18 Secs
C
H
4
This function will not be active when you select Vibrate, Silence All
or Etiquette as a ringer mode.
AUTO REDIAL
Automatically redial a call up to 5 times after a set time interval.
Press [MENU] .
1
Select a redial time option (Off, 3 Secs, 5 Secs,
2
7 Secs, 10 Secs). The Repeat Category will
appear when a time frame is chosen.
LANGUAGE
Selects the language in which letters are displayed on screen.
Press [MENU] .
1
Select either “English” or “Français” with the
2
Navigation Key then press [OK].
TTY MODE
A TTY (also known as a TDD or Text Telephone), is a
telecommunications device that allows people who are deaf or hard
of hearing, or who have speech or language disabilities, to
communicate via telephone.
Your cellular telephone is compatible with select TTY devices.
Please check with the manufacturer of your TTY device to ensure that
it supports digital wireless transmission. Your cellular telephone and
TTY device will connect via special cable that plugs into your phone’s
headset jack. If this cable was not provided with your TTY device,
contact your TTY device manufacturer to purchase the connector
cable.
Press [MENU] .
1
Read the message, then press .
2
Enabling TTY may impair headset use and non-TTY accessory
performance.
C
H
4
Under Repeat, select a time interval option
3
(1 Time, 3 Times, 5 Times).
When Redial Time s set to “Off” the “Repeat” field disappears.
To save, press [OK].
4
90
Select one of the following options (Enable TTY
3
/ Disable TTY) with the Navigation Key then
press [OK].
91
SETTINGS
SETTINGS
VOICE SETTING
To answer calls when your cellular telephone is connected to an
optional hands-free car kit or headset:
Press [MENU] .
1
Select “Set Active” or “HFK Mode” with the
2
Navigation Key.
Select one of the following options then
3
press [OK].
Set Active : Send Key / Active Flip / Off
C
H
4
KEY GUARD
HFK Mode : On, Off
Press [MENU] .
1
Select “Off” or “On” with the Navigation Key.
2
To save, press [OK]. (“Key Guard Mode is
3
now on” displays.)
PHONE INFO
VERSION
Displays the (Phone Number/Software Ver/PRL/Hardware Ver/
Decimal ESN/Hex ESN/MSID/Browser Ver/Browser Name) version.
Press [MENU] .
1
The hardware and software versions appear.
2
To return to the previous page, press [OK].
3
ICONS
Displays the Indicator Icons of your cellular telephone.
(3G Status/3G Dormant/Location/Roaming/New Text Msg/New Voice
Msg/Text&Voice Msg/TTY/Emergency/New Web msg/Web&Text msg
/Web&Voice msg/Web&Text&Voice/Network)
Press [MENU] .
1
Your cellular phone icons appear.
2
To return to the previous page, press [OK].
3
C
H
4
Press 1,2,3 to unlock your keypad.
4
92
93
MEMO
Chapter 5
VOICE TOOLS
C
H
4
This chapter addresses Voice Tools, an advanced feature that allows
you to place calls using your voice. With Voice Memo (VM)
you can record voice messages and set the Answering Machine.
Topics include:
VOICE RECOGNITION MODE
VOICE TOOLS MENU
C
H
5
94
95
95
VOICE RECOGNITION MODE
VOICE TOOLS MENU
Voice Recognition (VR) enables you to place calls using your voice
and to record voice memos.
Press and hold until your cellular telephone
1
turns to Voice Recognition mode.
If there are no recorded voice dials, “No entries recorded”
will be displayed. (Refer to page 98 for how to set one up.)
“Please say the name after the
2
prompt tone” will be displayed
and you will hear “Name please”.
NAME
C
H
5
Press and hold until your cellular telephone
1
turns to Voice Recognition mode.
If you say a name or tag that is already in the
2
phone book, the number and name will be
displayed and you will hear “Calling (name)”.
VOICE MEMO
Voice Memo allows you to record a reminder message that can be up
to 60 seconds. To record a memo:
To start Tools menu, press [MENU] .
1
To enter a voice memo, press .
2
1. To record a voice memo, press .
3
Instructions will be displayed and you will
hear “Please record at the tone.”
1.1. To stop recording a memo, press or
[STOP] or [PAUSE/RESUME].
1.2. Press [OPTIONS] after recording a voice
memo to “Re-record”, “Review” or “Save”.
1.3. Select “Save” to input a “Voice Memo” caption,
then press . If you do not name the voice
memo it will be called “untitled”.
(See page 31 for more information on
entering letters, numbers and symbols.)
2. To play voice memo, press .
Select the message you want to play.
Press [OPTIONS] for “Play” or “Edit Caption”.
To erase the memo, press [ERASE].
C
H
5
96
3. To play in speaker mode, press .
Select the message you want to play.
Press [OPTIONS] for “Play” or “Edit Caption”.
To erase the memo, press [ERASE].
4. To erase all voice memos, press .
“Erase all voice memos?” will be displayed.
Press [YES] or [NO].
97
VOICE TOOLS MENU
VOICE TOOLS MENU
VOICE DIAL TRAIN WORDS
Voice Dial allows you to call a person by simply saying their name.
To access Voice Dial:
Train allows you to use Control words to make a call without using the
keypad.
To start Voice Tools menu, press [MENU] .
1
To enter a voice dial, press .
2
1.1. To record a voice dial, press .
3
C
H
5
The phone book list will be displayed
alphabetically. Select a name then press .
Instructions will be displayed and you will
hear “Name Please”.
1.2. Say the name for the voice tag and repeat the
name when prompted. You will hear “[Name]
Added”.
2. To play a voice dial, press .
Highlight the message you want to play then
press [PLAY] or press [ERASE].
3. To play a voice dial speaker mode, press .
Highlight the message you want to play then
press [PLAY] or press [ERASE].
4. To erase all voice dials, press .
“Removing all voice tags Proceed?” will be
displayed.
Press [YES] or [NO].
YES
Use to train or untrain the Voice Recognition with the control word,
“Yes”.
Press [MENU] .
1
“Please hold phone to ear and follow
2
instructions” will be displayed and you will hear
“Now training control words. Please say the
word yes”.
Say “Yes”. You will hear “Again”. Say “Yes”
3
again. You will hear “Training was Successful”.
NO
Use to train or untrain the Voice Recognition with the control word,
“No”.
Press [MENU] .
1
“Please hold phone to ear and follow
2
instructions” will be displayed and you will hear
“Now training control words. Please say the
word no”.
Say “No”. You will hear “Again”. Say “No” again.
3
You will hear “Training was Successful”.
C
H
5
98
99
VOICE TOOLS MENU
WAKE-UP
Use to train or untrain the Voice Recognition with the control word,
“Wake-Up”.
Press [MENU] .
1
“Please hold phone to ear and follow
2
instructions” will be displayed and you will hear
“Now training control words. Please say the word
Wake-Up”.
Say “Wake-Up”. You will hear “Again”.
3
Say “Wake-Up” again. You will hear “Training
was Successful”.
UNDO TRAIN ALL
Undo Train All erases all “trained” words.
C
H
5
Press [MENU] .
1
“Undo voice recognition for all procedures?”
2
will be displayed. Press [YES] or [NO].
Chapter 6
VOICE MAIL, TEXT
MESSAGE AND
PICTURE MESSAGE
This chapter addresses Voice Mail and Text Messaging or Picture
message functions including:
WHEN A NEW MESSAGE ARRIVES
VOICE MAIL
SEND TEXT
SEND PICTURE MSG
INBOX
OUTBOX
SAVED
WEB ALERTS
QUICK TEXT
ERASE ALL
SETTINGS
C
H
6
100
101
101
WHEN A NEW MESSAGE ARRIVES SEND TEXT
The following display appears
1
when a new message arrives.
To display the message, press [READ].
2
VOICE MAIL
Displays the number of voice mails and accesses them by pressing .
To access your voice mail, press [MENU]
1
C
H
6
or .
To send a new text message:
Press [MENU] or .
1
Under “Send To”, input the phone number then
2
press [OK].
By pressing [OPTIONS], the user can choose from the
following:
Find : Search for a phone number stored in the phone book.
Save : Stores the phone number the message was sent to.
Under “Message”, input a new text message
3
then press [OK].
(Please refer to page 31 for more details on entering letters,
numbers and symbols.)
By pressing [OPTIONS], the user can choose from the
following:
Insert Quick Text: Inserts canned text into a Text Msg.
Save to Quick Text: Saves the written sentences into
The default call back number is automatically
4
Quick Text.
included into the Default CB# field. You can scroll
to the number and edit it or simply press [OK].
Your phone number is the automatic default.
Press the Navigation Key down for more fields.
5
Under “Priority”, select “Normal” or “Urgent”.
C
H
6
102
6.1. To send the text message, press [SEND].
6
6.2. To save the text message press [OPTIONS],
select “Save to Outbox,” then press [OK].
103
SEND PICTURE MSG INBOX
To send a new picture message:
Press [MENU] or .
1
2.1. Press for “From My Pictures”. Looking for
2
a saved photo, scroll through the captured
pictures to select the picture you want to
send, then press [SEL].
2.2. Press for “Take New Picture”. Phone goes
into camera mode automatically.
Take a picture then press [OK].
Under “Send To”, input the phone number then
3
press [OK].
By pressing [OPTIONS], the user can choose from the
following:
Find : Search for a phone number stored in the phone book.
Save : Stores the phone number the message was sent to.
Press [OPTIONS] then select “Record” then
4
press [OK].
4.1. Under “Voice Memo:” To record a memo,
press [RECORD] or [SKIP].
C
H
6
4.2. To stop recording a memo, press [STOP]
or [PAUSE/RESUME].
4.3. Press [OPTIONS] after recording a voice
memo to “Play” or “Erase”.
Under “Message”, input a new text message then
5
press [OK].
(Please refer to page 31 for more details on entering letters,
numbers and symbols.)
By pressing [OPTIONS], the user can choose from the
following:
Insert Quick Text: Inserts canned text into a Text Msg.
Save to Quick Text: Saves the written sentences into Quick Text.
The Inbox manages received text messages. To access:
Press [MENU] or .
1
: Urgent New Msg (not read)
: Urgent Read Msg
: New Msg (not read)
: Old Msg (already read)
: Lock (already read and locked)
Select a message then press [OK].
2
The message is displayed.
Press [OPTIONS]. To reply to the text message,
3
press [REPLY].
REPLY
To reply to a message, type your response
1
then press [OK].
REPLY WITH COPY
To reply to a received message and included the received message
into the message.
The default call back number is automatically
1
inputted into the Default CB# field.
You can scroll to the number and edit it.
To send the text message, press [SEND].
2
To save the text message, press [OPTIONS]
3
select “Save to Outbox”, then press [OK].
C
H
6
To send the picture message, press [SEND].
6
104
105
INBOX OUTBOX
FORWARD
To forward the text message, select “Forward”.
1
Input the phone number of the person you are
2
sending the message, then press [OK].
Input any text message to go along with the
3
forwarded message, then press [OK].
To send the text message, press [SEND].
4
ERASE
To erase this message, select “Erase”.
1
“Erase This Message?” will be displayed.
2
Press [YES] or [NO].
SAVE TO CONTACT
To save number to contact, select “Save to
1
Contact”.
SAVE TO SAVED
C
H
6
To save the text message in your cellular
1
telephone, select “Save to Saved”.
SAVE TO QUICK TEXT
To save received text msg to “Quick Text”,
1
select “Save to Quick Text”.
LOCK & UNLOCK
To lock or unlock the text message, select
1
“Lock & Unlock”.
Select “Lock” to lock the message or “Unlock”
2
to unlock the message, then press [OK].
106
Manages sent text messages or messages waiting to be sent.
CHECKING SENT TEXT MESSAGES
Press [MENU] or .
1
: Auto resend
: Fail
: Not Sent
: Sent
: Canceled
2.1. Select a message, then press [OK].
2
The text message is displayed.
2.2. To erase message, press [ERASE].
Press [OPTIONS]. To resend the text message,
3
press [SEND TO].
RESEND
To resend a text message, select “Resend”.
1
SEND TO
To forward the text message, select “Send to”.
1
Input the phone number of the person you are
2
sending the message, then press [OK].
Input any text message to go along with the
3
forwarded message, then press [OK].
To send the text message, press [SEND].
4
107
C
H
6
OUTBOX SAVED
ERASE
To erase this message, select “Erase”.
1
“Erase this message?” will be displayed.
2
Press [YES] or [NO].
SAVE TO CONTACT
To save number to contact, select “Save to
1
Contact”.
SAVE TO SAVED
To save the text message in your cellular
1
telephone, select “Save to Saved”.
LOCK & UNLOCK
To lock or unlock the text message, select
1
“Lock & Unlock”.
Select “Lock” to lock the message or “Unlock”
2
C
H
6
to unlock the message, then press [OK].
STATE
SAVED
Manages saved messages from the Inbox/Outbox.
Press [MENU] or .
1
2.1. Select a text message then press [OK].
2
3
4
5
The text message is displayed.
2.2. To erase message, press [ERASE].
Press [OPTIONS].
If the text message is saved from the “Inbox”
menu, this screen will be displayed.
To select inbox menu : Reply, Reply with Copy, Forward,
Erase, Save to Contact,
Save to Quick Text, Lock & Unlock
If the text message is saved from the “Outbox”
menu, this screen will be displayed.
To select outbox menu : Resend, Send to, Erase, Save to
Contact, Lock & Unlock, State
Select one by pressing [OK].
C
H
6
To display the status of an outbox message,
1
select “State”.
To return to the previous page, press [OK].
2
108
109
WEB ALERTS
QUICK TEXT
WEB ALERTS
Press [MENU] or .
1
To select GoTo, press then press to
2
connect to the selected site.
To erase the selected message, press .
The Web Alert message will be displayed.
3
[ ] : Read Message.
[ ] : Unread Message.
GoTo : Connecting Selected Site.
Erase : Erase Selected Message.
C
H
6
QUICK TEXT
To edit the Quick Text message you have saved:
Press [MENU] or .
1
2.1. Select a message from the list.
2
3
Press [OPTIONS].
2.2. To add a new Quick Text message,
select “Add New”. To edit the Quick Text
message you have selected, select “Edit”.
To erase the saved Quick Text message,
press [ERASE].
C
H
6
110
111
SETTINGSERASE ALL
ERASE ALL
Manages messaging features through various features.
SAVE SENT MSG
Press [MENU] or .
1
Press [MENU] or .
1
1. To erase all voicemails, press .
2
Select one from “Off”, “On” or “Prompt” with
2. To erase all the Inbox messages, press .
Read Msg : To erase messages already read.
(However, the locked Message(s) will not be deleted).
Entire Msg : To erase all messages.
3. To erase all the Outbox messages, press .
4. To erase all the Saved messages, press .
5. To erase all the Web Alerts, press .
6. To erase all the Quick Text, press .
Press [YES] or [NO].
3
C
H
6
2
the Navigation Key then press [OK].
DEFAULT CALLBACK
Edits a default callback number so that the recipient can call back or
reply.
Press [MENU] or .
1
Input a callback number, then press .
2
You can look it up from the phone book by
pressing [FIND].
REMINDER
Press [MENU] or .
1
C
H
6
112
2
Select “On” or “Off” with the Navigation Key
then press [OK].
113
SETTINGSSETTINGS
AUTO ERASE
Automatically erases inbox/outbox messages when new messages
arrive.
INBOX
Press [MENU] or .
1
Press .
2
Select “Disable” or “Read Msg” with Navigation
Key then press [OK].
OUTBOX
1
Press [MENU] or .
Press .
2
Select “Disable” or “Old Msg” with Navigation Key
then press [OK].
ENTRY MODE
Sets an Entry Mode as a default. For example, if T9 Mode is the
default, its icon will appear.
C
H
1
6
Press [MENU] or .
Select “Alpha Mode” or “T9 Mode” with
2
the Navigation Key then press [OK].
MESSAGE LOG
INCOMING LOG
Press [MENU] or .
1
Press .
2
Displays information on the incoming messages
including “Stored Msg/Read Msg”.
To return to the previous page, press [OK].
3
OUTGOING LOG
Press [MENU] or .
1
2
Press .
Displays information on the outgoing messages
such as “Sent Msg”.
To return to the previous page, press [OK].
3
RESET LOG
Press [MENU] or .
1
2
Press .
Select “Incoming Log” or “Outgoing Log” with
Navigation Key.
C
H
6
114
3
“Reset Incoming/Outgoing Log?” will be
displayed. Press [YES] or [NO].
115
SETTINGS
RETRY TIME
Sets redialing options when dialing has failed. Automatically redials
a call up to 5 times after the time interval set by a user.
Press [MENU] or .
1
Select on of the following with the Navigation Key
2
then press [OK].
3 mins / 5 mins / 10 mins / 30 mins.
l
PUSH SETTING
When handset gets the SL Push Message from the server, users
can connect the browser through assigned URL by selecting the
Push Settings on.
Press [MENU] or .
1
Select one from “Yes” or “No” with the
2
Navigation Key then press [OK].
C
H
6
Chapter 7
VXL
This chapter explains how to access VXL - a collection of features
including downloadable ringtones and games, as well as other fun
stuff. For details, visit virgin.com/mobile.
VXL
116
117
C
H
7
VXL
ACCESSING & NAVIGATING VXL
VXL is a fun collection of features which you can access directly
from your phone - music, movies, and more. Charges may apply.
Visit virgin.com/mobile for details.
To access VXL, press .
1
Or, press [MENU] .
Scroll down the page using the
2
Navigation Key .
To select one of the options at the bottom of
3
the display, press or .
To return to the previous menu, press .
4
To exit VXL, press .
5
When you select VXL, a session is initiated.
You cannot receive incoming calls when a VXL session is in
progress.
C
H
7
Chapter 8
SAFETY AND
WARRANTY
This chapter addresses the safety guidelines and precautions to
follow when operating your cellular telephone. Before operating your
cellular telephone, please be aware of all the safety details.
This chapter contains the terms and conditions of services and the
warranty for your cellular telephone. Please review them thoroughly.
SAFETY INFORMATION FOR WIRELESS
HANDHELD PHONES
SAFETY INFORMATION FOR FCC RF EXPOSURE
SAR INFORMATION
FDA CONSUMER UPDATE
PROTECT YOUR WARRANTY
12 MONTH LIMITED WARRANTY
C
H
8
118
119
SAFETY INFORMATION FOR WIRELESS
HANDHELD PHONES
SAFETY INFORMATION FOR WIRELESS
HANDHELD PHONES
Read This Information Before Using Your Handheld
Portable Cellular Telephone
EXPOSURE TO RADIO FREQUENCY SIGNALS
Your wireless handheld portable telephone is a low power radio
transmitter and receiver. When it is ON, it receives and also sends out
radio frequency (RF) signals.
In August 1996, the Federal Communications Commissions (FCC)
adopted RF exposure guidelines with safety levels for handheld wireless
phones. Those guidelines are consistent with the safety standards
previously set by both U.S. and international standards bodies:
ANSI C95.1 (1992) *
NCRP Report 86 (1986) *
ICNIRP (1996) *
Those standards were based on comprehensive and periodic evaluations
of the relevant scientific literature. For example, over 120 scientists,
engineers, and physicians from universities, government health agencies,
and industry reviewed the available body of research to develop the ANSI
Standard (C951).
The design of your cellular telephone complies with the FCC guidelines
(and those standards).
ANTENNA CARE
Use only the supplied or an approved replacement antenna. Unauthorized
antennas, modifications, or attachments could damage the phone and
may violate FCC regulations.
DRIVING SAFETY
Talking on the phone while driving is extremely dangerous and is illegal in
some areas. Remember, safety comes first. Check the laws and regulations
on the use of phones in the areas where you drive. Always obey them.
Also, if using your cellular telephone while driving, please:
l Give full attention to driving. Driving safely is your first responsibility.
l Use hands-free operation, if available.
l Pull off the road and park before making or answering a call, if driving
conditions so require.
If you must use the phone while driving, please use one-touch, speed dialing,
and auto answer modes.
An airbag inflates with great force. DO NOT place objects, including both
installed or portable wireless equipment, in the area over the airbag or in the
air bag deployment area. If in-vehicle wireless equipment is improperly
installed and the air bag inflates, serious injury could result.
WARNING: Failure to follow these instructions may lead to serious
personal injury and possible property damage.
C
H
8
1* : American National Standards Institute.
2* : National Council on Radiation protection and measurements.
3* : International Commission on Nonionizing Radiation Protection.
120
121
C
H
8
SAFETY INFORMATION FOR WIRELESS
HANDHELD PHONES
SAFETY INFORMATION FOR WIRELESS
HANDHELD PHONES
ELECTRONIC DEVICES
Most modern electronic equipment is shielded from RF energy. However,
certain electronic equipment may not be shielded against the RF signals
from your wireless phone.
PACEMAKERS
The Health Industry Manufacturers Association recommends that a
minimum separation of six (6”) inches be maintained between a handheld
wireless phone and a pacemaker to avoid potential interference with the
pacemaker. These recommendations are consistent with the independent
research by and recommendations of Wireless Technology Research.
Persons with pacemakers :
l ALWAYS keep the phone more than six inches from your
pacemaker when the phone is turned on.
l Do not carry the phone in a breast pocket.
l Use the ear opposite the pacemaker to minimize the potential for
interference.
l If you have any reason to suspect that interference is taking place,
turn your cellular telephone OFF immediately.
OTHER MEDICAL DEVICES
If you use any other personal medical device, consult the manufacturer of
your device to determine if they are adequately shielded from external RF
energy. Your physician may be able to assist you in obtaining this
information.
Turn your cellular telephone OFF in healthcare facilities when any
regulations posted in these areas instruct you to do so. Hospitals or
healthcare facilities may be using equipment that could be sensitive to
external RF energy.
OTHER SAFETY GUIDELINES
AIRCRAFT
FCC and Transport Canada Regulations prohibit using your cellular
telephone while in the air. Turn your cellular telephone OFF before boarding
an aircraft.
BLASTING AREAS
To avoid interfering with blasting operations, turn your cellular telephone
OFF when in a “blasting area” or in areas posted: “Turn off two-way
radio.” Obey all signs and instructions.
POTENTIALLY EXPLOSIVE ATMOSPHERES
Turn your cellular telephone OFF when in any area with a potentially
explosive atmosphere and obey all signs and instructions. Sparks in
such areas could cause an explosion or fire resulting in bodily injury
or even death.
Areas with a potentially explosive atmosphere are often, but not
always, clearly marked. They include fueling areas such as gas
stations; below deck on boats; fuel or chemical transfer or storage
facilities; vehicles using liquefied petroleum gas (such as propane or
butane); areas where the air contains chemicals or particles, such as
grain, dust, or metal powders; and any other area where you would
normally be advised to turn off your vehicle’s engine.
POSTED FACILITIES
C
H
Turn your cellular telephone OFF where posted notices so require.
8
122
123
C
H
8
SAFETY INFORMATION FOR WIRELESS
HANDHELD PHONES
SAFETY INFORMATION FOR
FCC RF EXPOSURE
PRECAUTIONS
Your Handheld Portable Telephone is a high quality piece of
equipment. Before operating, read all instructions and cautionary
markings on (1) AC Adaptor (2) Battery and (3) Product Using Battery.
DO NOT use this equipment in an extreme environment where
high temperature or high humidity exists.
DO NOT abuse the equipment. Avoid striking, shaking or
shocking. When not using, lay down the unit to avoid possible
damage due to instability.
DO NOT expose this equipment to rain or spilled beverages.
DO NOT use unauthorized accessories.
DO NOT disassemble the phone or its accessories. If service
or repair is required, return unit to an authorized Audiovox
cellular service center. If unit is disassembled, the risk of
electric shock or fire may result.
DO NOT short-circuit the battery terminals with metal items etc.
C
H
8
WARNING! Read this Information before using
CAUTIONS
In August 1996 the Federal Communications Commission (FCC) of
the United States with its action in Report and Order FCC 96-326
adopted an updated safety standard for human exposure to radio
frequency electromagnetic energy emitted by FCC regulated
transmitters. Those guidelines are consistent with the safety standard
previously set by both U.S. and international standards bodies. The
design of this phone complies with the FCC guidelines and these
international standards.
Use only the supplied or an approved antenna. Unauthorized
antennas, modifications, or attachments could impair call quality,
damage the phone, or result in violation of FCC regulations.
Do not use the phone with a damaged antenna. If a damaged
antenna comes into contact with the skin, a minor burn may result.
Please contact your local dealer for replacement antenna.
BODY-WORN OPERATION
This device was tested for typical body-worn operations with the
back of the phone kept 2.0 cm. from the body. To maintain
compliance with FCC RF exposure requirements, use only belt-clips,
holsters or similar accessories that maintain a 2.0 cm. separation
distance between the user’s body and the back of the phone,
including the antenna. The use of belt-clips, holsters and similar
accessories should not contain metallic components in its assembly.
The use of accessories that do not satisfy these requirements may
not comply with FCC RF exposure requirements, and should be
avoided.
VEHICLE MOUNTED EXTERNAL ANTENNA
(OPTIONAL, IF AVAILABLE)
A minimum separation distance of 7.9 inches (20cm) must be
maintained between the user/bystander and the vehicle mounted
external antenna to satisfy FCC RF exposure requirements.
For more information about RF exposure, please visit the FCC
website at www.fcc.gov.
C
H
8
124
125
SAR INFORMATION SAR INFORMATION
THIS MODEL PHONE MEETS THE GOVERNMENT’S
REQUIREMENTS FOR EXPOSURE TO RADIO WAVES.
Your wireless phone is a radio transmitter and receiver. It is designed
and manufactured not to exceed the emission limits for exposure to
radiofrequency (RF) energy set by the Federal Communications
Commission of the U.S. Government. These limits are part of
comprehensive guidelines and establish permitted levels of RF energy
for the general population. The guidelines are based on standards that
were developed by independent scientific organizations through
periodic and thorough evaluation of scientific studies. The standards
include a substantial safety margin designed to assure the safety of all
persons, regardless of age and health.
The exposure standard for wireless mobile phones employs a unit of
measurement known as the Specific Absorption Rate, or SAR. The SAR
limit set by the FCC is 1.6 W/kg. * Tests for SAR are conducted with the
phone transmitting at its highest certified power level in all tested
frequency bands. Although the SAR is determined at the highest
certified power level, the actual SAR level of the phone while operating
can be well below the maximum value. This is because the phone is
designed to operate at multiple power levels so as to use only the
power required to reach the network. In general, the closer you are to a
wireless base station antenna, the lower the power output.
Before a phone model is available for sale to the public, it must be
tested and certified to the FCC that it does not exceed the limit
established by the government adopted requirement for safe exposure.
The tests are performed in positions and locations (e.g., at the ear and
worn on the body) as required by the FCC for each model. The highest
SAR value for this model phone when tested for use at the ear is 1.15
W/Kg and when worn on the body, as described in this user guide, is
0.393W/Kg. (Body-worn measurements differ among phone models,
depending upon available accessories and FCC requirements). While
there may be differences between the SAR levels of various phones
and at various positions, they all meet the government requirement for
safe exposure.
The FCC has granted an Equipment Authorization for this model phone
with all reported SAR levels evaluated as in compliance with the FCC
RF exposure guidelines. SAR information on this model phone is on file
with the FCC and can be found under the Display Grant section of
C
http://www.fcc.gov/ oet/fccid after searching on PP4TX-110C.
H
8
Additional information on Specific Absorption Rates (SAR) can be found
on the Cellular Telecommunications Industry Association (CTIA) website
at http://www.wow-com.com.
* In the United States and Canada, the SAR limit for mobile phones
used by the public is 1.6 watts/kg (W/kg) averaged over one gram of
tissue. The standard incorporates a sub-stantial margin of safety to give
additional protection for the public and to account for any variations in
measurements.
C
H
8
126
127
FDA CONSUMER UPDATE FDA CONSUMER UPDATE
U.S. Food and Drug Administration -Center for Devices and
Radiological Health Consumer Update on Wireless Phones
1. Do wireless phones pose a health hazard?
The available scientific evidence does not show that any health problems are
associated with using wireless phones. There is no proof, however, that wireless
phones are absolutely safe. Wireless phones emit low levels of radiofrequency
energy (RF) in the microwave range while being used. They also emit very low
levels of RF when in the stand-by mode. Whereas high levels of RF can produce
health effects (by heating tissue), exposure to low level RF that does not produce
heating effects causes no known adverse health effects. Many studies of low level
RF exposures have not found any biological effects. Some studies have suggested
that some biological effects may occur, but such findings have not been confirmed
by additional research. In some cases, other researchers have had difficulty in
reproducing those studies, or in determining the reasons for inconsistent results.
2. What is FDA’s role concerning the safety of wireless phones?
Under the law, FDA does not review the safety of radiation-emitting consumer
products such as wireless phones before they can be sold, as it does with new
drugs or medical devices. However, the agency has authority to take action if wireless phones are shown to emit radiofrequency energy (RF) at a level that is
hazardous to the user. In such a case, FDA could require the manufacturers of
wireless phones to notify users of the health hazard and to repair, replace or recall
the phones so that the hazard no longer exists. Although the existing scientific data
do not justify FDA regulatory actions, FDA has urged the wireless phone industry
to take a number of steps, including the following:
• Support needed research into possible biological effects of RF of the type
emitted by wireless phones;
• Design wireless phones in a way that minimizes any RF exposure to the user
that is not necessary for device function;
and
• Cooperate in providing users of wireless phones with the best possible
information on possible effects of wireless phone use on human health.
FDA belongs to an interagency working group of the federal agencies that have
responsibility for different aspects of RF safety to ensure coordinated efforts at the
federal level. The following agencies belong to this working group:
• National Institute for Occupational Safety and Health
• Environmental Protection Agency
• Federal Communications Commission
• Occupational Safety and Health Administration
• National Telecommunications and Information Administration
The National Institutes of Health participates in some inter-agency working group
activities, as well. FDA shares regulatory responsibilities for wireless phones with
the Federal Communications Commission (FCC). All phones that are sold in the
United States must comply with FCC safety guidelines that limit RF exposure. FCC
relies on FDA and other health agencies for safety questions about wireless
phones. FCC also regulates the base stations that the wireless phone networks
rely upon. While these base stations operate at higher power than do the wireless
phones themselves, the RF exposures that people get from these base stations are
typically thousands of times lower than those they can get from wireless phones.
C
Base stations are thus not the subject of the safety questions discussed in this
H
document.
8
3. What kinds of phones are the subject of this update?
The term “wireless phone” refers here to hand-held wireless phones with built-in
antennas, often called “cell,” “mobile,” or “PCS” phones.
These types of wireless phones can expose the user to measurable radiofrequency
energy (RF) because of the short distance between the phone and the user’s head.
These RF exposures are limited by Federal Communications Commission safety
guidelines that were developed with the advice of FDA and other federal health and
safety agencies. When the phone is located at greater distances from the user, the
exposure to RF is drastically lower because a person’s RF exposure decreases
rapidly with increasing distance from the source. The so-called “cordless phones,”
which have a base unit connected to the telephone wiring in a house, typically
operate at far lower power levels, and thus produce RF exposures far below the
FCC safety limits.
4. What are the results of the research done already?
The research done thus far has produced conflicting results, and many studies
have suffered from flaws in their research methods. Animal experiments
investigating the effects of radiofrequency energy (RF) exposures characteristic of
wireless phones have yielded conflicting results that often cannot be repeated in
other laboratories. A few animal studies, however, have suggested that low levels
of RF could accelerate the development of cancer in laboratory animals. However,
many of the studies that showed increased tumor development used animals that
had been genetically engineered or treated with cancer-causing chemicals so as to
be pre-disposed to develop cancer in the absence of RF exposure. Other studies
exposed the animals to RF for up to 22 hours per day. These conditions are not
similar to the conditions under which people use wireless phones, so we don’t
know with certainty what the results of such studies mean for human health. Three
large epidemiology studies have been published since December 2000. Between
them, the studies investigated any possible association between the use of
wireless phones and primary brain cancer, glioma, meningioma, or acoustic neuroma, tumors of the brain or salivary gland, leukemia, or other cancers. None of the
studies demonstrated the existence of any harmful health effects from wireless
phone RF exposures. However, none of the studies can answer questions about
long-term exposures, since the average period of phone use in these studies was
around three years.
5. What research is needed to decide whether RF exposure from wireless
phones poses a health risk?
A combination of laboratory studies and epidemiological studies of people actually
using wireless phones would provide some of the data that are needed. Lifetime
animal exposure studies could be completed in a few years. However, very large
numbers of animals would be needed to provide reliable proof of a cancer
promoting effect if one exists. Epidemiological studies can provide data that is
directly applicable to human populations, but 10 or more years’ follow-up may be
needed to provide answers about some health effects, such as cancer. This is
because the interval between the time of exposure to a cancer- causing agent and
the time tumors develop - if they do -may be many, many years. The interpretation
of epidemiological studies is hampered by difficulties in measuring actual RF
exposure during day-to-day use of wireless phones. Many factors affect this
measurement, such as the angle at which the phone is held, or which model of
phone is used.
6. What is FDA doing to find out more about the possible health effects of
wireless phone RF?
FDA is working with the U.S. National Toxicology Program and with groups of
investigators around the world to ensure that high priority animal studies are
conducted to address important questions about the effects of exposure to
radiofrequency energy (RF). FDA has been a leading participant in the World Health
Organization International Electromagnetic Fields (EMF) Project since its inception
in 1996. An influential result of this work has been the development of a detailed
agenda of research needs that has driven the establishment of new research programs around the world.
129128
C
H
8
FDA CONSUMER UPDATE FDA CONSUMER UPDATE
The Project has also helped develop a series of public information documents on
EMF issues. FDA and the Cellular Telecommunications & Internet Association
(CTIA) have a formal Cooperative Research and Development Agreement (CRADA)
to do research on wireless phone safety. FDA provides the scientific oversight,
obtaining input from experts in government, industry, and academic organizations. CTIA-funded research is conducted through contracts to independent
investigators. The initial research will include both laboratory studies and studies of
wireless phone users. The CRADA will also include a broad assessment of
additional research needs in the context of the latest research developments
around the world.
7. How can I find out how much radiofrequency energy exposure I can get by
using my wireless phone?
All phones sold in the United States must comply with Federal Communications
Commission (FCC) guidelines that limit radiofrequency energy (RF) exposures. FCC
established these guidelines in consultation with FDA and the other federal health
and safety agencies. The FCC limit for RF exposure from wireless telephones is set
at a Specific Absorption Rate (SAR) of 1.6 watts per kilogram (1.6 W/kg). The FCC
limit is consistent with the safety standards developed by the Institute of Electrical
and Electronic Engineering (IEEE) and the National Council on Radiation Protection
and Measurement. The exposure limit takes into consideration the body’s ability to
remove heat from the tissues that absorb energy from the wireless phone and is
set well below levels known to have effects. Manufacturers of wireless phones
must report the RF exposure level for each model of phone to the FCC. The FCC
website (http://www.fcc.gov/oet/rfsafety) gives directions for locating the FCC
identification number on your cellular telephone so you can find your phone’s RF
exposure level in the online listing.
8. What has FDA done to measure the radiofrequency energy coming from
wireless phones ?
The Institute of Electrical and Electronic Engineers (IEEE) is developing a technical
standard for measuring the radiofrequency energy (RF) exposure from wireless
phones and other wireless handsets with the participation and leader-ship of FDA
scientists and engineers. The standard, “Recommended Practice for Determining
the Spatial-Peak Specific Absorption Rate (SAR) in the Human Body Due to
Wireless Communications Devices: Experimental Techniques,” sets forth the first
consistent test methodology for measuring the rate at which RF is deposited in the
heads of wireless phone users. The test method uses a tissue-simulating model of
the human head. Standardized SAR test methodology is expected to greatly
improve the consistency of measurements made at different laboratories on the
same phone. SAR is the measurement of the amount of energy absorbed in tissue,
either by the whole body or a small part of the body. It is measured in watts/kg (or
milliwatts/g) of matter. This measurement is used to determine whether a wireless
phone complies with safety guidelines.
9. What steps can I take to reduce my exposure to radiofrequency energy
from my wireless phone?
If there is a risk from these products—and at this point we do not know that there
is—it is probably very small. But if you are concerned about avoiding even
potential risks, you can take a few simple steps to minimize your exposure to
radiofrequency energy (RF). Since time is a key factor in how much exposure a
person receives, reducing the amount of time spent using a wireless phone will
C
reduce RF exposure.
H
• If you must conduct extended conversations by wireless phone every day, you
could place more distance between your body and the source of the RF, since
8
the exposure level drops off dramatically with distance. For example, you could
use a headset and carry the wireless phone away from your body or use a
wireless phone connected to a remote antenna.
Again, the scientific data do not demonstrate that wireless phones are harmful. But
if you are concerned about the RF exposure from these products, you can use
measures like those described above to reduce your RF exposure from wireless
phone use.
10.What about children using wireless phones?
The scientific evidence does not show a danger to users of wireless phones,
including children and teenagers. If you want to take steps to lower exposure to
radiofrequency energy (RF), the measures described above would apply to children
and teenagers using wireless phones. Reducing the time of wireless phone use
and increasing the distance between the user and the RF source will reduce RF
exposure. Some groups sponsored by other national governments have advised
that children be discouraged from using wireless phones at all. For example, the
government in the United Kingdom distributed leaflets containing such a
recommendation in December 2000. They noted that no evidence exists that using a wireless phone causes brain tumors or other ill effects. Their
recommendation to limit wireless phone use by children was strictly precautionary;
it was not based on scientific evidence that any health hazard exists.
11.What about wireless phone interference with medical equipment?
Radiofrequency energy (RF) from wireless phones can interact with some
electronic devices. For this reason, FDA helped develop a detailed test method to
measure electromagnetic interference (EMI) of implanted cardiac pacemakers and
defibrillators from wireless telephones. This test method is now part of a standard
sponsored by the Association for the Advancement of Medical instrumentation
(AAMI). The final draft, a joint effort by FDA, medical device manufacturers, and
many other groups, was completed in late 2000. This standard will allow
manufacturers to ensure that cardiac pacemakers and defibrillators are safe from
wireless phone EMI. FDA has tested hearing aids for interference from handheld
wireless phones and helped develop a voluntary standard sponsored by the
Institute of Electrical and Electronic Engineers (IEEE). This standard specifies test
methods and performance requirements for hearing aids and wireless phones so
that that no interference occurs when a person uses a “compatible” phone and a
“compatible” hearing aid at the same time. This standard was approved by the
IEEE in 2000. FDA continues to monitor the use of wireless phones for possible
interactions with other medical devices. Should harmful interference be found to
occur, FDA will conduct testing to assess the interference and work to resolve the
problem.
12.Where can I find additional information?
For additional information, please refer to the following resources:
• FDA web page on wireless phones (http://www.fda.gov/cdrh/ phones/index.html)
• Federal Communications Commission (FCC) RF Safety Program
(http://www.fcc.gov/oet/rfsafety)
• International Commission on Non-Ionizing Radiation Protection
(http://www.icnirp.de)
• World Health Organization (WHO) International EMF Project
(http://www.who.int/emf)
• National Radiological Protection Board (UK) (http://www.nrpb.org.uk/)
C
H
8
131130
PROTECT YOUR WARRANTY 12 MONTH LIMITED WARRANTY
Read your Warranty carefully, with the special consideration to
paragraph seven of the Limited Warranty for your unit.
“Warranty does not apply to... or to any product or part
thereof which has suffered through alteration... mishandling
misuse, neglect or accident”.
Many companies are making look alike accessories and in some
cases, promoting that their product is equal to or better than the
Audiovox product. Be careful. Some of these products may not be
compatible to use with your Audiovox product and may damage the
unit or cause it to malfunction. If service is required on your unit and it
is determined that a non-Audiovox accessory has created the
problem with your unit, the Warranty will not apply. In addition, if the
unit has already suffered irreversible damage by reason of a noncompatible accessory, the Warranty will be voided. To protect your
Warranty, use only compatible accessories which cannot damage or
interfere with the functioning of your Audiovox product.
UTSTARCOM/AUDIOVOX COMMUNICATIONS
555 Wireless Blvd., Hauppauge, New York 11788, 800-229-1235
16808 Marquardt Avenue, Cerritos, California 90703, 562-802-5100
UTStarcom Canada Company
5155 Spectrum Way, Unit #5, Mississauga, Ontario
Canada L4W 5A1, 800-465-9672
C
H
8
UTStarcom/Audiovox Communications (the Company) warrants to the
original retail purchaser of this Audiovox handheld portable cellular
telephone, that should this product or any part thereof during normal
consumer usage and conditions, be proven defective in material or
workmanship that results in product failure within the first twelve (12)
months period from the date of purchase, such defect(s) will be
repaired or replaced (with new or rebuilt parts) at the Company’s
option, without charge for parts or labor directly related to the defect(s).
The antenna, key pad, display, rechargeable battery and battery
charger, if included, are similarly warranted for twelve (12) months from
date of purchase.
This Warranty extends only to consumers who purchase the product in
the United States or Canada and it is not transferable or assignable.
This Warranty does not apply to:
(a) Product subjected to abnormal use or conditions, accident,
mishandling, neglect, unauthorized alteration, misuse, improper
installation or repair or improper storage;
(b) Product whose mechanical serial number or electronic serial number
has been removed, altered or defaced.
(c) Damage from exposure to moisture, humidity, excessive
temperatures or extreme environmental conditions;
(d) Damage resulting from connection to, or use of any accessory or
other product not approved or authorized by the Company;
(e) Defects in appearance, cosmetic, decorative or structural items such
as framing and non-operative parts;
(f) Product damaged from external causes such as fire, flooding, dirt,
sand, weather conditions, battery leakage, blown fuse, theft or
improper usage of any electrical source.
The Company disclaims liability for removal or reinstallation of the
product, for geographic coverage, for inadequate signal reception by
the antenna or for communications range or operation of the cellular
system as a whole.
To obtain repairs or replacement within the terms of this Warranty, the
product should be delivered with proof of Warranty coverage (e.g.
dated bill of sale), the consumer’s return address, daytime phone
number and/or fax number and complete description of the problem,
transportation prepaid, to the Company at the address shown below or
to the place of purchase for repair or replacement processing.
C
H
8
132
133
12 MONTH LIMITED WARRANTY
In addition, for reference to an authorized Warranty station in your area,
you may telephone in the United States (800) 229-1235, and in Canada
(800) 465-9672 (in Ontario call 905-712-9299).
THE EXTENT OF THE COMPANY’S LIABILITY UNDER THIS
WARRANTY IS LIMITED TO THE REPAIR OR REPLACEMENT
PROVIDED ABOVE AND, IN NO EVENT, SHALL THE COMPANY’S
LAIBILITY EXCEED THE PURCHASE PRICE PAID BY PURCHASER
FOR THE PRODUCT.
ANY IMPLIED WARRANTIES, INCLUDING ANY IMPLIED WARRANTY
OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE,
SHALL BE LIMITED TO THE DURATION OF THIS WRITTEN
WARRANTY. ANY ACTION FOR BREACH OF ANY WARRANTY MUST
BE BROUGHT WITHIN A PERIOD OF 18 MONTHS FROM DATE OF
ORIGINAL PURCHASE. IN NO CASE SHALL THE COMPANY BE
LIABLE FOR AN SPECIAL CONSEQUENTIAL OR INCIDENTAL
DAMAGES FOR BREACH OF THIS OR ANY OTHER WARRANTY,
EXPRESS OR IMPLIED, WHATSOEVER. THE COMPANY SHALL NOT
BE LIABLE FOR THE DELAY IN RENDERING SERVICE UNDER THIS
WARRANTY OR LOSS OF USE DURING THE TIME THE PRODUCT IS
BEING REPAIRED OR REPLACED.
No person or representative is authorized to assume for the Company
any liability other than expressed herein in connection with the sale of
this product.
Some states or provinces do not allow limitations on how long an
implied warranty lasts or the exclusion or limitation of incidental or
consequential damage so the above limitation or exclusions may not
apply to you. This Warranty gives you specific legal rights, and you may
also have other rights which vary from state to state or province
to province.
IN USA : UTStarcom/Audiovox Communications
555 Wireless Blvd.
Hauppauge, NY 11788
(800) 229-1235
IN CANADA : UTStarcom Canada Company
C
H
5155 Spectrum Way, Unit #5
Mississauga, Ontario L4W 5A1
(800) 465-9672
8
134
Model : CDM-8910
Loading...
