WELCOME
TABLE OF CONTENTS
Thank you for choosing the up-to-date CDM-8615, our new
model, developed by top researchers to support the
CDMA2000 1X system through Qualcomm-manufactured
MSM6050 chips and CDMA technologies. This product allows
for high speed communication services, such as web browsing,
data services, and a GUI animation menu.
T9 input mode makes it much easier to enter text, while VR
(Voice Recognition) makes the CDM-8615 more user friendly.
Other proven technologies include:
Full graphic display with 9 text input lines and 1 icon line
with variable font size.
Easy to dial through the VR feature.
Enhanced for web browsing & data services (i.e.; wireless
internet access, UP browser)
GUI & Animation display compliant with CDMA2000 1X.
CSTN 65K Color LCD.
Navigation Key and 21 keys aligned for more convenience.
Sophisticated features of speaker phone, and voice
recognition.
Additional services of text messaging and Web browsing on
top of authentication, call forwarding, call transfer, call
waiting.
IMPORTANT INFORMATION
This CDM-8615 user guide contains very important
information about how to handle and use the product.
Please read this manual thoroughly, pay attention to the
warranty on the back page and be alert to the exclusions and
limitations of your warranty, which are related with the
unauthorized use of components.
CHAPTER 1. BEFORE USING YOUR PHONE .................................5
INSIDE THE PACKAGE .....................................................................................6
HANDSET DESCRIPTION.................................................................................7
THE FUNCTION KEYS.............................................................................................8
DISPLAY INDICATORS ...........................................................................................9
BATTERY USAGE...........................................................................................11
BATTERY INSTALLATION ....................................................................................11
BATTERY REMOVAL.............................................................................................11
BATTERY CHARGING ...........................................................................................12
Chapter 1
POWER CONNECTION ......................................................................................12
PCS AND 1X BATTERY TIMES ...........................................................................13
BATTERY LIFE (FOR NEW BATTERY) ................................................................13
BATTERY HANDLING INFORMATION..........................................................14
DOs.........................................................................................................................14
DON’Ts...................................................................................................................14
CHAPTER 2. BASIC OPERATION ..................................................15
TURNING THE PHONE ON / OFF ..................................................................16
TURNING THE PHONE ON...................................................................................16
TURNING THE PHONE OFF..................................................................................16
ACCESSING THE MENU................................................................................17
MENU SUMMARY .........................................................................................18
BASIC FUNCTIONS ........................................................................................21
MAKING A CALL ...................................................................................................21
SPEAKER PHONE..................................................................................................22
PAUSE FEATURE ..................................................................................................22
ANSWERING A CALL............................................................................................23
3-WAY CALLING ...................................................................................................23
CALLER ID FUNCTION..........................................................................................24
CALL WAITING FUNCTION ..................................................................................24
ADJUSTING VOLUME ..........................................................................................24
ETIQUETTE ............................................................................................................25
PHONE LOCK.........................................................................................................25
Chapter 2
DURING A CALL .............................................................................................26
MESSAGING .........................................................................................................26
MUTE (UNMUTE)..................................................................................................26
SCRATCHPAD .......................................................................................................26
SEND MY PHONE # ..............................................................................................26
MY PHONE # .........................................................................................................27
VOICE PRIVACY.....................................................................................................27
LOCATION .............................................................................................................27
PHONE INFO..........................................................................................................27
MAKING AN EMERGENCY CALL..................................................................28
911 IN LOCK MODE ..............................................................................................28
911 USING ANY AVAILABLE SYSTEM ...............................................................28
CHAPTER 3. MEMORY FUNCTION...............................................29
STORING A PHONE NUMBER ......................................................................30
ENTERING LETTERS, NUMBERS & SYMBOLS ...........................................31
STANDARD INPUT MODE....................................................................................32
T9 INPUT MODE....................................................................................................33
NUMERIC MODE...................................................................................................34
SYMBOL MODE ....................................................................................................34
MAKING A CALL THROUGH THE PHONE BOOK ........................................35
Chapter 3
ONE-TOUCH/TWO-TOUCH DIALING...................................................................35
ONE-TOUCH DIALING:.......................................................................................35
TWO-TOUCH DIALING: ......................................................................................35
CHAPTER 4. MENU FUNCTION ....................................................37
PHONE BOOK .................................................................................................38
FIND .......................................................................................................................38
FIND BY NAME...................................................................................................38
FIND BY NUMBER..............................................................................................39
ADD NEW ..............................................................................................................40
Chapter 4
GROUP...................................................................................................................40
ADD NEW GROUP .............................................................................................40
CHANGE GROUP NAME ....................................................................................41
1
TABLE OF CONTENTS TABLE OF CONTENTS
ERASE GROUP ...................................................................................................41
SPEED DIAL ...........................................................................................................42
MSG. GROUP ........................................................................................................43
ADD NEW MSG. GROUP ...................................................................................43
CHANGE MSG. GROUP NAME..........................................................................43
SEND TEXT MSG. GROUP .................................................................................44
ERASE MSG. GROUP.........................................................................................44
MY PHONE # .........................................................................................................45
RECENT CALLS ..............................................................................................46
ALL CALLS.............................................................................................................46
MISSED CALLS .....................................................................................................47
RECEIVED CALLS ..................................................................................................48
DIALED CALLS ......................................................................................................49
CALL TIMERS ........................................................................................................50
LAST CALL..........................................................................................................50
ALL CALLS..........................................................................................................50
HOME CALLS .....................................................................................................50
ROAM CALLS .....................................................................................................51
CUMULATIVE CALLS .........................................................................................51
@ METRO .......................................................................................................52
START @ METRO .................................................................................................52
DOWNLOADING APPLICATIONS ........................................................................52
DOWNLOADING MELODIES/WALLPAPERS.......................................................52
APPLYING MELODIES/WALLPAPERS .................................................................53
CHECKING DATA FOLDER MEMORY..................................................................53
ERASING AN APPLICATION ................................................................................53
MOBILE WEB ..................................................................................................54
CONNECT WEB .....................................................................................................54
MEDIA GALLERY............................................................................................55
IMAGES .................................................................................................................55
GRAPHICS ..........................................................................................................55
ANIMATIONS......................................................................................................55
TONES ...................................................................................................................56
SETTINGS .......................................................................................................57
Chapter 4
SOUNDS ................................................................................................................57
RINGER TYPE .....................................................................................................57
VOLUME.............................................................................................................58
ALERT .................................................................................................................59
ROAM RINGER...................................................................................................60
TONE LENGTH ...................................................................................................60
ETIQUETTE .........................................................................................................60
DISPLAY.................................................................................................................61
MENU STYLE......................................................................................................61
GRAPHICS ..........................................................................................................61
SUB SCREEN......................................................................................................63
GREETING MESSAGE ........................................................................................64
CONTRAST .........................................................................................................64
BACKLIGHT ........................................................................................................65
DATA SVC..............................................................................................................66
CONNECTION.....................................................................................................66
SECURITY ..............................................................................................................67
PHONE LOCK .....................................................................................................67
RESTRICT ...........................................................................................................67
CHANGE CODE ..................................................................................................69
SPECIAL #’S .......................................................................................................70
ERASE ALL .........................................................................................................70
RESET PHONE....................................................................................................70
OTHERS .................................................................................................................71
ANSWER OPTIONS ............................................................................................71
AUTO RETRY ......................................................................................................72
LANGUAGE.........................................................................................................73
VOICE PRIVACY..................................................................................................73
TTY MODE..........................................................................................................74
LOCATION ..........................................................................................................74
SYSTEM.................................................................................................................75
SET MODE..........................................................................................................75
NAM SETTING ....................................................................................................75
PRL ID.................................................................................................................76
PHONE INFO..........................................................................................................77
S/W VERSION.....................................................................................................77
H/W VERSION ....................................................................................................77
@ METRO VERSION ...........................................................................................77
MY METRO .....................................................................................................78
MONTHLY BILL .....................................................................................................78
METROCONNECT .................................................................................................78
METROPCS CARD.................................................................................................79
UTILITIES ........................................................................................................80
EVENT ....................................................................................................................80
ADD NEW PLAN.................................................................................................80
Chapter 4
VIEW PLAN.........................................................................................................81
ALARM...................................................................................................................81
MEMO PAD............................................................................................................83
ADD MEMO........................................................................................................83
VIEW MEMO ......................................................................................................83
SETTINGS ...........................................................................................................83
CALCULATOR........................................................................................................84
WORLD CLOCK .....................................................................................................84
STOP WATCH........................................................................................................85
CHAPTER 5. VOICE SERVICE ........................................................87
VOICE TOOLS MENU.....................................................................................88
VOICE MEMO ........................................................................................................88
VOICE DIAL............................................................................................................89
TRAIN WORDS ......................................................................................................90
YES .....................................................................................................................90
NO.......................................................................................................................90
WAKE-UP............................................................................................................91
UNDO TRAIN ALL...............................................................................................91
Chapter 5
VOICE SETTING ....................................................................................................92
SET ACTIVE ........................................................................................................92
HFK MODE .........................................................................................................92
VOICE RECOGNITION MODE ........................................................................93
NAME.....................................................................................................................93
CHAPTER 6. VOICE MAIL AND TEXT MESSAGE ........................95
WHEN A NEW MESSAGE ARRIVES .............................................................96
VOICE MAIL ....................................................................................................96
NEW TEXT MSG .......................................................................................................97
INBOX ........................................................................................................................98
REPLY .................................................................................................................98
REPLY WITH COPY ............................................................................................98
FORWARD..........................................................................................................99
SAVE TO CONTACT............................................................................................99
SAVE TO SAVED.................................................................................................99
SAVE TO QUICK TEXT........................................................................................99
BLOCK SENDER .................................................................................................99
LOCK & UNLOCK ...............................................................................................99
OUTBOX ..................................................................................................................100
CHECKING SENT TEXT MESSAGES .................................................................100
Chapter 6
RESEND............................................................................................................100
EDIT MESSAGE ................................................................................................100
SAVE TO CONTACT..........................................................................................101
SAVE TO SAVED...............................................................................................101
LOCK & UNLOCK .............................................................................................101
STATE ...............................................................................................................101
WEB ALERTS...........................................................................................................102
SAVED .....................................................................................................................103
QUICK TEXT ............................................................................................................104
ERASE ALL ..............................................................................................................105
ERASE MESSAGES.............................................................................................105
2
3
TABLE OF CONTENT
SETTINGS................................................................................................................106
AUTO SAVE.........................................................................................................106
SAVE SENT MSG..............................................................................................106
AUTO ERASE.......................................................................................................106
INBOX ...............................................................................................................106
OUTBOX ...........................................................................................................106
DEFAULT CALLBACK..........................................................................................107
EDIT VOICE CALLBACK ......................................................................................107
Chapter 6
REMIND ...............................................................................................................107
EDIT SIGNATURE................................................................................................108
DIRECT VIEW.......................................................................................................108
ENTRY MODE......................................................................................................109
BLOCK OR UNBLOCK .........................................................................................109
CHAPTER 7. MOBILE WEB ..........................................................111
LAUNCHING MOBILE WEB .........................................................................112
ACCESS THE INTERNET.....................................................................................112
BROWSER MENU.........................................................................................112
HOME...................................................................................................................112
BACK ....................................................................................................................112
FORWARD ...........................................................................................................112
REFRESH..............................................................................................................113
HISTORY ..............................................................................................................113
Chapter 7
ADDRESS.............................................................................................................113
CLEAR MEMORY.................................................................................................113
SETTINGS............................................................................................................114
ADVANCED..........................................................................................................114
EXIT......................................................................................................................114
CHAPTER 8. SAFETY AND WARRANTY ....................................115
SAFETY INFORMATION FOR WIRELESS HANDHELD PHONES ..............116
DRIVING SAFETY ................................................................................................117
ELECTRONIC DEVICES .......................................................................................118
OTHER SAFETY GUIDELINES ............................................................................119
PRECAUTIONS ....................................................................................................120
SAFETY INFORMATION FOR FCC RF EXPOSURE ....................................121
CAUTIONS...........................................................................................................121
Chapter 8
SAR INFORMATION.....................................................................................122
FDA CONSUMER UPDATE ..........................................................................124
PROTECT YOUR WARRANTY .....................................................................128
12 MONTH LIMITED WARRANTY...............................................................129
Chapter 1
BEFORE USING
YOUR PHONE
This chapter provides important information about using the
CDM-8615 including:
INSIDE THE PACKAGE
HANDSET DESCRIPTION
BATTERY USAGE
BATTERY HANDLING INFORMATION
C
H
.
1
“Licensed by QUALCOMM Incorporated under one or more of the following Patents : U.S.Patent No.
4,901,307 U.S.Patent No. 5,056,109 U.S.Patent No. 5,099,204 U.S. Patent No. 5,101,501 U.S. Patent No.
5,103,459 U.S. Patent No. 5,107,225 U.S.Patent No. 5,109,390.”
4
5
INSIDE THE PACKAGE
HANDSET DESCRIPTION
This package should include all items pictured below.
C
If any are missing or different, immediately contact the retailer
H
where you purchased the phone.
1
AC Travel Charger
Handset
Standard Battery
User Manual
This phone is a CDMA2000 1X digital (800 MHz CDMA, 1900 MHz
PCS) phone with web browsing capabilities. The CDM-8615 weighs
3.7oz. And the dimensions are 1.83” x 4.48” x 0.97”.
Antenna
Earjack
Earpiece
LCD Screen
Volume
Clock/
Voice Memo Key
At Flip Closed:
Use Button to change
Sub LCD display.
At Flip Open:
Long Press: Voice Memo.
Key
Function Keys
Navigation
Key
END/
Power Key
C
H
1
Handstrap
Holster
Send Key
6
7
Microphone
HANDSET DESCRIPTION HANDSET DESCRIPTION
C
H
1
Display Indicators
See page 9 for a list of icons.
Text & Graphic area
DISPLAY INDICATORS
Signal Strength - Current signal strength: the
C
H
1
more lines, the stronger the signal.
Roaming
Phone is out of home area.
Service Indicator
Indicates call is in progress, indicates the
phone cannot receive a signal from the system.
Message
Menu
Soft Key Indications
Shows the functions currently
assigned to each soft key and
displays some icons.
Contacts
New text or voice message.
Digital mode
Phone is operating in digital mode.
Battery
THE FUNCTION KEYS
Phone Book
@ MetroMobile Web
Messaging
Press to make or receive a call.
Press and hold to turn on VR mode.
Press to turn the phone on/off, to terminate a call
or to return to the initial page.
(Left Soft Key) Press to access the menu or
function displayed on bottom line.
(Right Soft Key) Press to access contact menu
or function displayed on bottom line.
Press to clear a digit from the display or to return
to the previous page.
Press and hold to enable speaker phone mode.
Press and hold to enter etiquette mode.
Press and hold to enter lock mode.
In Idle Mode
- Press Up to access the Phone Book,
Down to access the Messaging, Right
for @ Metro and Left for Mobile Web.
Inside the menu
- Within a menu, use to scroll through
menu options, or to select a function
displayed on the screen.
Battery charging level – the more blocks, the
stronger the charge.
Mute
Phone is mute during a call.
Silent
Appears when Silent is selected as the ring mode.
Emergency Call
Blinks when an emergency call is in progress.
Auto Answer
Phone is in answering machine mode.
Speaker phone
Phone is in speaker phone mode.
Etiquette
Phone will vibrate when call is received.
Event
Appears when either an event or an alarm is set.
Ring Mode
Appears when ringer is selected as the ring
mode.
Data Only
Receives an async. call as a voice call.
8
9
HANDSET DESCRIPTION BATTERY USAGE
C
H
1
Dormant
Indicates your phone is in a dormant state during a
data call. Your phone goes to Dormant mode
when you have no had any activity on a page for
some time - your connection is still active and now
you can make and receive calls.
GPS Icon
Indicates the Location Service of your phone is
disabled/enabled.
1X
Phone is in the 1x service area.
Scratch Pad
Displays when scratchpad is in use during a call.
Unread Web Message
Phone has new Web Alert message.
Web Message + Text Message
Phone has Web Alert Msg and Text Msg.
Web Message + Voice Message
Phone has Web Alert Msg and Voice Msg.
Web Message + Text Message + Voice Message
Phone has Web Alert Msg, Text Msg and
Voice Msg.
UP Browser
UP Browser is in progress.
BATTERY INSTALLATION
1
Place the battery on the back of the handset
u
and slide into place.
v
until it locks into place.
BATTERY REMOVAL
1
Pull down the release latch, lift up the
u
battery and
remove the battery from the
v
handset.
Push the battery down
C
H
1
10
If the battery is not correctly placed in the compartment, the
handset will not turn on and/or the battery may detach during use.
11
BATTERY USAGE BATTERY USAGE
C
H
1
BATTERY CHARGING
POWER CONNECTION
Plug the AC Charger into a standard outlet.
1
Plug the other end of the AC Charger into the
2
bottom of your phone. The battery must be
attached to the phone.
• When you charge the battery with the phone power off, you
will see a charging status screen. You cannot operate the
phone until it is powered on.
• The battery is not charged at the time of purchase.
• Fully charge the battery before use.
• It is more efficient to charge the battery with the handset
powered off.
• The battery must be connected to the phone in order to charge it.
• Battery operating time gradually decreases over time.
• If the battery fails to perform normally, you may need to replace
the battery.
PCS AND 1X BATTERY TIMES
The operating time is subject to your handset usage and configuration.
Battery Capacity
STD 1000 mAh
EXT 1700 mAh
DCS
200m
330m
PCS
190m
310m
BATTERY LIFE (FOR NEW BATTERY)
The operating time is subject to your handset usage and configuration.
Battery Capacity
STD 1000 mAh
EXT 1700 mAh
These times are for a new battery. Usage and Standby time may
decrease over time.
CDMA
190 Hours
310 Hours
C
H
1
12
13
BATTERY HANDLING INFORMATION
C
H
1
DOs
l Only use the battery and charger approved by the
manufacturer.
l Only use the battery for its original purpose.
l Try to keep batteries in a temperature between 41ºF
(5ºC ) and 95ºF (35ºC).
l If the battery is stored in temperatures above or
below the recommended range, give it time to warm
up or cool down before using.
l Completely drain the battery before recharging.
It may take one to four days to completely drain.
l Store the discharged battery in a cool, dark, and dry
place.
l Purchase a new battery when its operating time
gradually decreases after fully charging.
l Properly dispose of the battery according to local
laws.
DON’Ts
l Don’t attempt to disassemble the battery –
it is a sealed unit with no serviceable parts.
l Don’t accidentally short circuit the battery by
carrying it in your pocket or purse with other
metallic objects such as coins, clips and pens.
This may critically damage the battery.
l Don’t leave the battery in hot or cold temps.
Otherwise, it could significantly reduce the capacity
and lifetime of the battery.
l Don’t dispose of the battery into a fire.
Chapter 2
BASIC OPERATION
This chapter addresses and explains the basic features of your phone
including:
TURNING THE PHONE ON / OFF
ACCESSING THE MENU
MENU SUMMARY
BASIC FUNCTIONS
DURING A CALL
MAKING AN EMERGENCY CALL
C
H
2
14
15
TURNING THE PHONE ON / OFF
ACCESSING THE MENU
TURNING THE PHONE ON
Press and hold until your “Power On” logo
1
appears and the tone sounds.
C
H
2
• To select a logo, refer to page 61 for more details.
(Settings>Display>Graphics) for more detail.
• If “Password” appears on the display enter your 4-digit
password to unlock your phone.
• The default password is the last 4 digits of your
phone number.
TURNING THE PHONE OFF
Press and hold until your “Power Off” logo
1
Your phone can be customized via the menu. Each function can be
accessed by scrolling with the Navigation Key or by pressing the
number that corresponds with the menu item.
Phone Book
Recent Calls
Messaging
@ Metro
Mobile Web
To access the menu in the idle mode,
1
Media Gallery
Settings
My Metro
Tools
Utilities
press [MENU].
Use the Navigation Key to scroll through the
2
menu.
C
H
2
appears.
l To search through the menu in numerical order, press the
• Immediately change or recharge the battery when
“Low Battery Warning Power Off” appears on the display.
Memory may possibly be damaged if the phone turns off
due to the battery completely draining.
• Turn the phone off before removing or replacing the battery.
If the phone is on, unsaved data may be lost.
Navigation Key down.
To return to the previous page, press [CLR].
3
To exit the current menu and return to the idle
mode, press .
Press the Navigation Key to enter a function
4
when its main page is displayed or press its
assigned number to have direct access to
the function.
16
Hotkey
In idle mode, move the Navigation Key as follows to access
these functions:
• Upward movement : Phone Book
• Downward movement : Messaging
• Rightward movement : @ Metro
• Leftward movement : Mobile Web
17
MENU SUMMARY MENU SUMMARY
C
H
2
1. Phone Book
2. Recent Calls
3. Messaging
4. @ Metro
5. Mobile Web
1. Find
2. Add New
3. Group
4. Speed Dial
5. Msg. Group
6. My Phone #
1. All Calls
2. Missed Calls
3. Received Calls
4. Dialed Calls
5. Call Timers
1. New Text Msg
2. Voice Mail
3. Inbox
4. Outbox
5. Web Alerts
6. Saved
7. Quick Text
8. Erase All
9. Settings
1. Connect web
1. By Name
2. By Number
1. Last Call
2. All Calls
3. Home Calls
4. Roam Calls
5. Cumulative Calls
1. Inbox
2. Outbox
3. Saved
1. Auto Save
2. Auto Erase
3. Default Callback
4. Edit Voice C.B
5. Remind
6. Edit Signature
7. Direct View
8. Entry Mode
9. Block or Unblock
1. Old Inbox
2. Entire Inbox
1. Save sent MSG
1. Inbox
2. Outbox
1. Block
2. Unblock
3. View List of
Blocked Address
6. Media Gallery
7. Settings
1. Images
2. Tones
1. Sounds
2. Display
3. Data Svc
4. Security
5. Others
1. Graphics
2. Animations
1. Ringer Type
2. Volume
3. Alert
4. Roam Ringer
5. Tone Length
6. Etiquette
1. Menu Style
2. Graphics
3. Sub Screen
4. Greeting Message
5. Contrast
6. Backlight
1. Connection
1. Phone Lock
2. Restrict
3. Change Code
4. Special #’s
5. Erase All
6. Reset Phone
1. Answer Options
2. Auto Retry
3. Language
4. Voice Privacy
5. TTY Mode
6. Location
1. Ringer
2. Messages
3. Voice Mail
1. Ringer
2. Key Tone
3. Voice Call
4. Speaker Phone
1. Minute
2. Roam
3. Connect
4. Fade
1. Wallpaper
2. Power On
3. Power Off
4. Received
5. Dialed
6. Screen Saver
1. Dialed
2. Recent Calls
3. Phone Book
4. Data Call
5. 900#s
6. Long Distance
1. Special #1
2. Special #2
3. Special #3
1. Call Answer
2. Active Flip
3. Auto Answer
C
H
2
18
19
MENU SUMMARY
BASIC FUNCTIONS
C
H
2
8. My Metro
9. Tools
10. Utilities
6. System
7. Phone Info
1. Monthly Bill
2. MetroConnect
3. metroPCS Card
1. Voice Memo
2. Voice Dial
3. Train Words
4. Voice Setting
1. Event
2. Alarm
3. Memo Pad
4. Calculator
5. World Clock
6. Stop Watch
1. Set Mode
2. Nam Setting
3. PRL ID
1. S/W Version
2. H/W Version
3. @ Metro Version
1. Request Balance
2. Pay Monthly Bill
1. Record
2. Play
3. Play Speaker
4. Erase All
1. Record
2. Play
3. Play Speaker
4. Erase All
1. Yes
2. No
3. Wake-Up
4. Undo Train All
1. Add New Plan
2. View Plan
1. Alarm 1
2. Alarm 2
3. Alarm 3
1. Add Memo
2. View Memo
3. Settings
1. Auto NAM
2. Change NAM
1. Credit Card
2. metroPCS Card
3. Other options
MAKING A CALL
Enter a phone number.
1
To modify the phone number you have entered :
• To erase one digit at a time press .
• To erase the entire number, press and hold .
Press .
2
The indicator, , appears on the display.
• If “CALL FAILED” appears on the display or the line is busy,
press or .
• If you activate the “AUTO RETRY” function, the phone will
automatically retry for the number of times you have
selected. (refer to page 72).
• When you place or receive a call from stored phone
numbers, both the name and phone number will be
displayed.
• There is another way to make a call through the VR mode,
which is called “VAD (Voice Activated Dialing)”.
Please refer to page 89 (Voice Service) for more details.
To end a call, press .
3
C
H
2
20
21
BASIC FUNCTIONS BASIC FUNCTIONS
SPEAKER PHONE
The speaker phone feature lets you hear audio through the speaker and
talk without holding the phone.
C
H
To activate the speaker phone in idle, answering
1
or calling modes, press and hold .
2
The phone returns to normal (speaker phone off)
2
after ending a call or when the phone is turned off
and back on.
PAUSE FEATURE
Pauses are used for automated systems (i.e., voice mail, calling cards).
Insert a pause after a phone number then enter another group of
numbers. The second set of numbers is dialed automatically after the
pause. This feature is useful for dialing into systems that require a code.
To insert a pause, enter a phone number then
1
press [MENU]. Select either a Hard Pause
(“P” appears) or a Timed Pause (“T” appears).
Press to dial or [SAVE] to store the
2
number.
Please refer to page 30 for more details about
storing a phone number.
ANSWERING A CALL
To answer a call, press any key except , ,
1
or .
l By pressing , you can select either “Any
Key” or “Send Key” to answer a call. lf “Send Key” is selected,
the phone can only be answered by pressing .
See page 71 for more information.
To end the call, press .
2
In Auto Answer Mode a call is automatically answered after a
preset number of ring tones. See page 72 for more details.
3-WAY CALLING
With Three-Way Calling, you can talk to two people at the same time.
When using this feature, the normal airtime rates will be applied for
each of the two calls.
Enter the number you wish to call then press .
1
Once you have established the connection,
2
enter the second number you wish to call then
press .
C
H
2
22
When you’re connected to the second party,
3
press again to begin your three-way call.
If one of the people you called hangs up during your call, you
and the remaining caller stay connected. If you initiated the call
and are the first to hang up, all three callers are disconnected.
23
BASIC FUNCTIONS BASIC FUNCTIONS
CALLER ID FUNCTION
Identifies caller by displaying their phone number. If the caller’s name
and number are already stored in your phone book, they both will
appear.
C
H
The caller ID is stored in the call history.
2
CALL WAITING FUNCTION
Notifies you of an incoming call when you are already on a call by
sounding a beep tone and displaying the caller’s phone number.
To answer another call while on the phone,
1
press . This places the first call on hold.
To switch back to the first caller, press
again.
Call Waiting is a system dependent feature. Please contact your
service provider for details.
ADJUSTING VOLUME
Adjusts the volume of the ringer, key beep and speaker.
Press [MENU] then select one
1
of the following.
l
Ringer : Controls the ringer volume.
l
Key Tone : Controls the key pad tone.
l
Voice Call : Controls the earpiece volume.
l
Speaker Phone : Controls the speaker volume.
ETIQUETTE
Mutes key tones and activates the vibration mode to alert you of an
incoming call or message.
To turn etiquette mode on/off, press and hold .
1
will be displayed to indicate etiquette mode
is active an audible tone sounds when etiquette
is turned off.
PHONE LOCK
The Key guard feature of your cellular telephone locks the keypad to
protect against accidental key presses when the phone is turned on
and no call is in progress. You can still answer or silence an incoming
call.
To lock the phone, press and hold .
1
To unlock the phone, press or then
2
input your password.
C
H
2
Adjust volume then press [OK] to save it.
2
To adjust earpiece volume during a call, press the
Navigation Key up or down.
24
25
DURING A CALL DURING A CALL
To display menu options during a call, press [MENU].
MESSAGING
Enables you to send a message (SMS) during a call.
C
H
Press [MENU] .
1
2
MUTE (UNMUTE)
The caller cannot hear you or any sounds from your side but you can
still hear them.
Press [MENU] .
1
l
To deactivate, press [MENU] .
l
The phone will automatically un-mute in Emergency
Call or Callback mode.
SCRATCHPAD
Stores a new phone number during a call without the calling party
hearing the key pad tones.
Press [MENU] .
1
To deactivate it, press [MENU] .
l
SEND MY PHONE #
Automatically transmits your phone number to a pager during a call.
(Dependent on pager service)
MY PHONE #
Displays your phone number.
Press [MENU] .
1
VOICE PRIVACY
Increases security during a call.
Press [MENU] .
1
LOCATION
Enables the network to locate your current location through Global
Positioning System (GPS). (Refer to page 74 for more details.)
Press [MENU] .
1
PHONE INFO.
Displays the software and hardware version of your phone.
Press [MENU] .
1
C
H
2
Press [MENU] .
1
26
27
MAKING AN EMERGENCY CALL
This 911 feature puts the phone in the Emergency Call Mode
when you dial the preprogrammed emergency number, 911. It also
operates in the lock mode and out of the service area.
911 IN LOCK MODE
The 911 call service is available even in the lock mode.
C
H
Enter “911” then press .
2
1
The call connects.
2
The phone exits the Lock Mode for 5 minutes.
3
When the call ends, the phone returns to the Lock Mode.
l
911 USING ANY AVAILABLE SYSTEM
Chapter 3
MEMORY FUNCTION
C
H
3
Enter “911” then press .
1
The call connects.
2
The phone maintains the Emergency Mode
3
for 5 minutes.
l
The phone returns to the Lock Mode.
l
While the phone is in the emergency mode for 5 minutes,
the phone can receive an incoming call from any available
system. However, it can't make a call.
The 911 call is not recorded in the recent call list.
28
This chapter addresses memory functions including:
STORING A PHONE NUMBER
ENTERING LETTERS, NUMBERS & SYMBOLS
MAKING A CALL THROUGH THE PHONE BOOK
29
STORING A PHONE NUMBER
ENTERING LETTERS, NUMBERS & SYMBOLS
The phone book stores up to 300 entries.
Enter phone # then press [SAVE].
1
Choose “New Contact” or “Existing Contact”.
2
Press [OK] to select.
The Phone # will appear above a list of icons.
3
C
H
.
3
The name of the icon is displayed below the list.
Use the Navigation Key to choose the type of #
you’re adding, as indicated by the icon.
Press [OK] to select.
Enter a name then press [OK].
4
Please refer to page 31 for more details on
entering letters, numbers & symbols.
To change the input mode, press [Abc].
Press the Navigation Key down to select the
group. Press the Navigation Key down to select
other options (secret, email).
To store the entry, press [SAVE]. “New contact
5
added!” or “Contact edited!” will be displayed.
The input mode (Alpha editor) will be automatically activated when
necessary to enter letters and numbers. As shown below, there are
4 available modes ; Standard input mode (Abc), T9 input mode
(T9Word), Numeric mode (NUM), and Symbol mode (Symbols).
The input mode indicator appears on the upper right
of the display when letters and numbers are entered.
To select the desired input mode among the 4 modes
below, press [Abc], then enter letters and numbers.
Input mode indicator
T9Word : T9 mode
Abc : Abc mode
NUM : Number mode
Symbols : Symbol mode
The following illustrates the function assigned to each key in the
Alpha Editor.
KEY FUNCTION
Press to change mode.
Abc
Next
Space
Caps Lock
Clear
[T9Word][Abc][NUM][Symbols]
In T9 mode press to view the next
matching word if the highlighted word is
not the word you intended.
Press to accept a word and add a space.
Press to select a letter case of the
standard text input or T9 text input mode.
[Abc], [ABC], and [abc] indicate the
standard text input.
[T9Word], [T9WORD], and [T9word]
indicate the predictive text input.
Press to delete a character to the left of
the cursor.
C
H
3
30
Save
Store the letters and numbers you enter.
31
ENTERING LETTERS, NUMBERS & SYMBOLS
ENTERING LETTERS, NUMBERS & SYMBOLS
STANDARD INPUT MODE
Use the digit keys to enter letters, numbers and characters.
Enter letters using the key pad as follows:
1
1
Key Pad
1
2ABC
C
H
3
3DEF
4GHI
:
9WXYZ
Time
1
A
D
G
W
Repetitions
:
2 times
.
B
E
H
:
X
Repetitions
3 times
@
C
F
Y
To change the input mode, press [Abc].
To enter a space, press . The cursor will
2
automatically move to the next column.
Repeat until letters are entered.
3
There is a 16-letter limit.
To delete one digit, press . To delete the
4
entire entry, press and hold .
To change from lowercase to uppercase,
5
press .
Select Abc mode by pressing [Abc].
When you select this mode, the Abc icon appears as a visual
confirmation.
- Find the key that corresponds to the letter you want to enter.
- Press it as many times as needed for the letter to appear on the
screen.
- To enter the name “John”:
Press [ ] J
Press [ ] o
Press [ ] h
Press [ ] n
I
:
Repetitions
4 times
-
2
3
4
:
Z
Repetitions
5 times
’
A
D
G
:
9
T9 INPUT MODE
The T9 input mode incorporates a built-in-dictionary to determine a
word based on the entered characters. A word can be entered more
quickly by pressing a key once per character.
Select the T9Word mode by pressing [Abc].
1
Press a digit key once to enter the character
2
you want then enter all the characters to input
the word you want.
To view the next matching word, press .
3
To accept the matching word then enter a
4
space, press .
To enter a compound word:
• Enter the first part of the word then press to accept it.
• Enter the last part of the word then press to enter the word.
To enter “Fun fare” in the T9 input mode.
- After you enter the 1stletter, press [Abc] to select T9 mode
and to choose the lower case (T9Word).
- Press and you will see “Fun” highlighted.
Press to select it.
- Press and until you see “ease” highlighted.
Press to select the next matching word, you will see “fare”
then enter a space.
C
H
3
32
33
ENTERING LETTERS, NUMBERS & SYMBOLS
MAKING A CALL THROUGH THE PHONE BOOK
NUMERIC MODE
Allows you to enter numbers.
To enter Numeric Mode, press [Abc] and
1
select “NUM.”
To enter a number, press a digit key.
2
C
H
3
SYMBOL MODE
Allows you to enter symbols.
To enter Symbol Mode, press [Abc] and
1
select “Symbols.”
Select symbol you want to enter with the
2
Navigation Key.
l Use the Navigation Key to view a different line of symbols.
Press [ ],
or
Press [ ],
ONE-TOUCH/TWO-TOUCH DIALING
Ideal for frequently dialed numbers, this feature allows phone book
entries to be dialed via the keypad with only one or two key presses.
ONE-TOUCH DIALING:
1-9 : Press and hold the corresponding memory
number for more than 1 second.
TWO-TOUCH DIALING:
10-20 : Press the first digit and second digits of the
memory number short and long respectively.
• If no phone number is stored in the location entered,
“There is no number” will appear on the screen.
• If a phone number is stored in secret, you will have to enter
the password to make a call.
C
H
3
34
35
MEMO
Chapter 4
C
H
3
This chapter addresses accessing the menu and using its functions
and features to customize your phone.
MENU FUNCTION
PHONE BOOK
RECENT CALLS
@ METRO
MOBILE WEB
MEDIA GALLERY
SETTINGS
MY METRO
UTILITIES
C
H
4
36
37
PHONE BOOK PHONE BOOK
Stores up to 300 entries, each of which can be assigned to a group.
Entries can be retrieved by name, phone number or group.
FIND
Retrieves an entry by name and calls by simply pressing .
You can review all the entries stored in your phone book list or
quickly find an entry by entering a name or phone number.
FIND BY NAME
Lists contacts alphabetically so you can quickly find a name.
Press [MENU] .
1
The list of names in your phone book is
2
C
H
4
displayed alphabetically.
Enter a name or its character string or scroll
3
through the list with the Navigation Key.
Please refer to page 31 for more details on
entering letters, numbers & symbols.
All matching entries will be displayed. Highlight
4
an entry. To edit the entry, press [OK].
Press [MENU] to 1. Send Text Msg, 2. Prefix
or 3. Erase.
l
If the entry is set to secret, you will be asked for your password.
Please refer to page 97 for more details on
“New Text Msg”.
FIND BY NUMBER
Lists contacts numerically so you can quickly find a number.
Press [MENU] .
1
The list of phone numbers saved in your phone
2
book will be displayed in numerical order.
Enter a part of the phone number or scroll
3
through the list with the Navigation Key.
The name associated with that number will be
displayed at the bottom of the screen.
All matching entries will be displayed. Highlight
4
an entry. To edit the entry, press [OK].
Press [MENU] to 1. Send Text Msg, 2. Prefix
or 3. Erase.
l
If the entry is set to secret, you will be asked for your password.
Please refer to page 97 for more details on
“New Text Msg”.
To call the selected number, press .
5
C
H
4
To call the selected number, press .
5
38
39
PHONE BOOK PHONE BOOK
ADD NEW
Adds a new entry.
To add a new entry to the phone book,
1
press [MENU] .
To enter a name or number, use the Navigation
2
Key to select the phone book field.
PHONE BOOK FIELDS :
l
Name/Mobile/Home/Office/Pager/Fax/E-Mail/ Wireless
Addr./Group/Ringer/Msg.Ringer/Graphic/Memo/
Set Secret.
Please refer to page 31 for more details on entering
C
H
4
letters, numbers & symbols.
3.1 To save the entry, press [SAVE].
3
3.2 To return to the previous page, press .
GROUP
Allows you to classify phone entries into groups. Existing groups
include Personal, Business, Etc. and All. A maximum of seven groups
is allowed.
ADD NEW GROUP
To add a new group, press [MENU] .
1
A maximum of seven groups is allowed.
To select “Add Group”, press [MENU].
2
Input a new group name.
3
To save it, press [OK].
4
CHANGE GROUP NAME
Press [MENU] .
1
Select an existing group name that you have
2
added with the Navigation Key.
To select “Rename”, press [MENU].
3
Input a new group name.
4
To save it, press [OK].
5
The default group names (All, Personal, Business, Etc.) cannot
be changed.
ERASE GROUP
Press [MENU] .
1
Use the Navigation Key to select, then delete
2
the group.
To delete it, press [ERASE].
3
To erase it, press [OK].
4
• The default group names (All, Personal, Business, Etc.)
cannot be erased.
• When executing erase group, the saved entries are moved
to the Etc. group.
C
H
4
40
41
PHONE BOOK PHONE BOOK
SPEED DIAL
In idle mode, calls can be placed to numbers stored in speed dial by
pressing & holding the location number on the key pad. For a 2-digit
location number, press the first number, then press and hold the
second number.
Press [MENU] .
1
To assign a phone number to a location, select
2
the location then press [SET].
If a phone number is already assigned to the
l
location, press [ERASE] and [OK] to delete.
C
H
4
Select the entry with the Navigation Key and
3
press [OK].
If the entry is set to secret, you will be asked for your password.
l
• “Unassigned” appears if the location is available.
• If a phone number is set as Secret, you will have to enter the
password.
• To call an assigned number, press & hold the last digit of the
speed dial #.
• “1” key is used for One-Touch voicemail feature.
“Speed dial # X edited” will be displayed.
4
MSG. GROUP
Allows the user to group up to 10 phone number. The user can add,
change, and delete Msg.Group.
ADD NEW MSG. GROUP
To add a new group, press [MENU] .
1
A maximum of five groups is allowed.
To select “Add Group”, press [MENU].
2
Input a new group name.
3
To save it, press [OK].
4
CHANGE MSG. GROUP NAME
Press [MENU] .
1
Select an existing group name with the
2
Navigation Key.
To select “Rename”, press [MENU].
3
Input a new group name.
4
C
H
4
42
To save it, press [OK].
5
43
PHONE BOOK PHONE BOOK
SEND TEXT MSG. GROUP
Press [MENU] .
1
Select an existing group name with the
2
Navigation Key.
To select “Send Text Msg.”, press [MENU].
3
Input a “Message”, “Default CB#”, “Priority”,
4
and “Insert Signature”.
5.1. To send the text message, press [MENU],
5
C
H
4
ERASE MSG. GROUP
1
2
select “Send” then press [OK].
5.2. To send the text message, press [MENU],
select “Save to Outbox” then press [OK].
Please refer to page 97 for more details on
“New Text Msg”.
Press [MENU] .
Select an existing group name with the
Navigation Key.
MY PHONE #
To display your phone number and service provider:
Press [MENU] .
1
To return to the previous page, press [OK].
2
C
H
4
To delete it, press [ERASE].
3
To erase it, press [OK].
4
44
45
RECENT CALLS RECENT CALLS
In idle mode, you can access recent calls by pressing [MENU] .
ALL CALLS
Displays information about the most recent incoming, outgoing and
missed calls.
To see a list of the 60 most recent incoming,
1
outgoing and missed calls, press [MENU]
. If the number is already stored in your
phone book, only the name appears. If the
number is not stored, only the phone number
appears.
2
C
H
4
To view details, press [OK].
Call details include type of call, date, time and phone number.
Press [MENU] then select “SAVE” to save it
3
or press [ERASE] to delete it.
Save: To store the phone number in your phone book.
l
Prefix: The user may add the desired number before the number.
l
l
l
It is useful when you add “1” during a long distance call.
You may save it in the phone book after entering the Prefix.
Send Text Msg: To send a Text message, insert the phone number.
Erase All: To erase all recent calls list.
MISSED CALLS
Displays information about the 20 most recently missed calls.
Place a call to a missed call number by simply pressing .
To see a list of the 20 most recently missed
1
calls, press [MENU] . If the number
is already stored in your phone book, only the
name appears. If the number is not stored,
only the phone number appears.
To view missed call details, press [OK].
2
Call details include date, time and phone number.
Press [MENU] then select “SAVE” to save it
3
or press [ERASE] to delete it.
Save: To store the phone number in your phone book.
l
Prefix: The user may add the desired number before the number.
l
l
l
After 20 missed calls, the oldest call will automatically
be erased from the history.
It is useful when you add “1” during a long distance call.
You may save it in the phone book after entering the Prefix.
Send Text Msg: To send a Text message, insert the phone number.
Erase All: To erase all missed calls list.
C
H
4
After the 20threceived, dialed or missed call, the oldest call will
automatically be erased from the history.
46
47
RECENT CALLSRECENT CALLS
RECEIVED CALLS
Displays information about the 20 most recently answered calls.
Place a call to a received call by simply pressing .
To see a list of the 20 most recently answered
1
calls, press [MENU] . If the number is
already stored in your phone book, only the
name appears. If the number is not stored, only
the phone number appears.
To view incoming call details, press [OK].
2
Call details include date, time and phone number.
C
H
4
Press [MENU] then select “SAVE” to save it
3
or press [ERASE] to delete it.
Save: To store the phone number in your phone book.
l
Prefix: The user may add the desired number before the number.
l
l
l
After 20 received calls, the oldest call will automatically
be erased from the history.
It is useful when you add “1” during a long distance call.
You may save it in the phone book after entering the Prefix.
Send Text Msg: To send a Text message, insert the phone number.
Erase All: To erase all received calls list.
DIALED CALLS
Displays information about the 20 most recently dialed numbers.
Place a call to a dialed call by simply pressing .
To see a list of the 20 most recently dialed
1
numbers, press [MENU] .
If the number is already stored in your phone
book, only the name appears. If the number is
not stored, only the phone number appears.
To view dialed call details, press [OK].
2
Call details include type of call, date, time and phone number.
Press [MENU] then select “SAVE” to save it
3
or press [ERASE] to delete it.
Save: To store the phone number in your phone book.
l
Prefix: The user may add the desired number before the number.
l
l
l
After 20 dialed calls, the oldest call will automatically
be erased from the history.
It is useful when you add “1” during a long distance call.
You may save it in the phone book after entering the Prefix.
Send Text Msg: To send a Text message, insert the phone number.
Erase All: To erase all dialed calls list.
C
H
4
4948
RECENT CALLS
RECENT CALLS
CALL TIMERS
Checks the usage time and manages your calls within the limit you
set. The five timers include:
LAST CALL
Displays usage time of last call.
Press [MENU] .
1
2
To return to the previous page, press [OK].
ALL CALLS
Displays usage time of all incoming and outgoing calls, excluding
web access calls.
C
H
4
Press [MENU] .
1
2
View the time of the following items:
Voice Call
l
Data Call
l
3
To return to the previous page, press [OK].
HOME CALLS
Displays usage time of all calls made within Home area.
ROAM CALLS
Displays talk time of roaming calls.
Press [MENU] .
1
View the time of the following items:
2
Voice Call
l
Data Call
l
To reset the timer, press [RESET].
3
To return to the previous page, press [OK].
CUMULATIVE CALLS
Displays talk time of all incoming and outgoing calls, excluding web
access calls.
Press [MENU] .
1
View the time of the following items:
2
Voice Call
l
Data Call
l
To reset the timer, press [RESET].
3
To return to the previous page, press [OK].
C
H
4
Press [MENU] .
1
2
View the time of the following items:
Voice Call
l
Data Call
l
3
To reset the timer, press [RESET].
To return to the previous page, press [OK].
50
50
51
@ METRO
@ METRO
Your phone provides a unique feature “@ Metro” that enables you to
download melody ringers, wallpapers, games and more from your
network to your phone.
Please contact your service provider for the availability of these
services.
START @ METRO
To launch “@ Metro” from the standby mode,
1
press [MENU] or press .
The @ Metro application icons will appear.
2
The shopping cart icon is @ Metro, the checkmark
is for Settings, and the question mark is for Help.
Choose an application, then press .
C
H
4
3
DOWNLOADING APPLICATIONS
Press [MENU] or press .
1
Select @ Metro then press .
2
Select a folder in the catalog then press .
3
The phone will access your service provider’s
4
server. Follow the prompt to download
applications.
To select an option, highlight it then press .
l
When a prompt appears, press to proceed or
to cancel.
DOWNLOADING MELODIES/WALLPAPERS
Before downloading melody ringers and wallpapers, you need to
download the dedicated downloader.
Please contact your service provider for details.
APPLYING MELODIES/WALLPAPERS
Downloaded melody ringers apply to several functions including the
incoming call alert, new text message alert, alarm clock and
scheduler alarm.
See Ringer Type on page 57.
Downloaded wallpapers apply to the standby mode.
See Wallpaper on page 61.
CHECKING DATA FOLDER MEMORY
Downloaded melody ringers, wallpapers and applications are saved
to the data folder in your phone.
Press [MENU] or press .
1
Select “Settings” then press .
2
Select “Manage Apps” then press .
3
The memory status will be displayed.
To exit, press .
4
ERASING AN APPLICATION
Press [MENU] or press .
1
Select “Settings” then press .
2
Select “Manage Apps” then press .
3
The memory status will be displayed.
Select the application to be erased then press .
4
Select “Remove” then press [OK].
5
C
H
4
52
52
53
MOBILE WEB
MEDIA GALLERY
CONNECT WEB
Your CDM-8615 allows you to browse various Internet websites
directly from your phone. This provides you with access to up-to-date
information such as news, sports, weather and stock quotes when
you subscribe to Internet service with your service provider. Please
contact your service provider for a list of available websites and
service details.
Press [MENU] or .
1
For more information, see Chapter 7: Mobile
2
Web, on page 111.
C
H
4
IMAGES
GRAPHICS
To display the list of downloaded still images:
Press [MENU] .
1
Press [MENU] to select 1.Erase, 2.Erase All, 3.Change Title.
Scroll through the captured pictures to display the
2
picture you want to send then press [SEND].
Enter your picture message.
3
4.1 To send the text message, press [MENU],
4
select “Send” then press [OK].
4.2 To send the text message, press [MENU],
select “Save to Outbox” then press [OK].
ANIMATIONS
To display the list of downloaded animations:
Press [MENU] .
1
Press [MENU] to select 1.Erase, 2.Erase All, 3.Change Title.
Scroll through the captured pictures to display the
2
picture you want to send then press [SEND].
C
H
4
54
54
Enter your picture message.
3
4.1 To send the text message, press [MENU],
4
select “Send” then press [OK].
4.2 To send the text message, press [MENU],
select “Save to Outbox” then press [OK].
55
MEDIA GALLERY
SETTINGS
TONES
Press [MENU] .
1
Scroll to the saved voice memo you want to send
2
then press [SEND].
Enter your picture message,
3
3.1 To send the text message, press [MENU],
select “Send” then press [OK].
3.2 To send the text message, press [MENU],
select “Save to Outbox” then press [OK].
C
H
4
Customizes your phone and optimizes performance through a variety
of settings.
SOUNDS
Sets Ringer Type, Volume, Alert, Roam Ringer, Tone Length and Etiquette.
RINGER TYPE
To select a ringer type for incoming calls:
RINGER
Press [MENU] .
1
Select your desired ringer type.
2
Left or Right key : Select “Ring Tones”, “Music Bells” or
“Downloads.”
Up or Down key : Select “Ringer.”
Downloads : Downloaded ringer types and familiar music.
Select one of the available ring types.
3
To confirm, press [SELECT].
MESSAGES
To select a ringer type for receiving messages:
Press [MENU] .
1
Press the Navigation Key up or down to select
2
“Tone 1, 2, 3, 4, 5”.
3
To confirm, press [SELECT].
C
H
4
56
56
VOICE MAIL
To select a ringer type for receiving voice mail:
Press [MENU] .
1
Press the Navigation Key up or down to select
2
“Tone 1, 2, 3, 4, 5”.
3
To confirm, press [SELECT].
57
SETTINGS SETTINGS
VOLUME
Controls the Ringer, Key tone, Voice Call and Speaker Phone volume.
RINGER
Controls the Ringer volume and alerts you to incoming calls in the
modes listed in the gray box below.
Press [MENU] .
1
Select one of the following options by pressing
2
the Navigation Key to the right or left.
Silent : Mute the ringer, press (Min).
Ringer Off
Vibrate On
Ringer Mode : Level 1~5
C
H
4
High & Vib : The ringer sounds after vibration,
To confirm, press [OK].
3
press (Max).
KEY TONE
To adjust key pad tone:
Press [MENU] .
1
Adjust the key pad tone with the Navigation Key.
2
Off (Min- )
Level 1 - 5 (level 5, Max- )
To save, press [OK].
3
VOICE CALL
To adjust earpiece volume:
Press [MENU] .
1
SPEAKER PHONE
To adjust speaker phone volume:
Press [MENU] .
1
Adjust the speaker phone volume using the
2
Navigation Key.
Level 1 - 5 (Min- , Max- )
To save, press [OK].
3
ALERT
When selected, this setting alerts you to the following handset changes:
MINUTE
Sounds an alert every minute during a call.
Press [MENU] .
1
Select “Off” or “On” with the Navigation Key then
2
press [OK] to save it.
ROAM
Sounds an alert when leaving a service area and entering a roaming
service area.
Press [MENU] .
1
Select “Off” or “On” with the Navigation Key then
2
press [OK] to save it.
CONNECT
Notifies you that a call has been successfully placed.
C
H
4
Adjust the earpiece volume with the Navigation Key.
2
Level 1 - 5 (Min- , Max- )
To save, press [OK].
3
58
Press [MENU] .
1
Select “Off” or “On” with the Navigation Key then
2
press [OK] to save it.
59
SETTINGS SETTINGS
FADE
Sounds an alert when entering an area where calls cannot be made
due to weak signal strength.
Press [MENU] .
1
Select “Off” or “On” with the Navigation Key then
2
press [OK] to save it.
ROAM RINGER
Sounds a different ringer when you are in a roaming service area.
Press [MENU] .
1
C
H
4
Select “Distinctive” or “Normal” with the
2
Navigation Key then press [OK] to save it.
Normal : Sounds the same ringer type as used in Home area.
l
Distinctive : Sounds a different ringer type.
l
TONE LENGTH
To adjust tone length:
Press [MENU] .
1
Select “Normal” or “Long” with the Navigation
2
Key then press [OK] to save it.
ETIQUETTE
To place the phone in Etiquette Mode so all phone sounds are muted:
Press [MENU] .
1
Select “On” or “Off” with the Navigation Key,
2
then press [OK] to save it.
On : Etiquette Mode on.
l
Off : Etiquette Mode off.
l
60
DISPLAY
Allows you to customize display.
MENU STYLE
To select a display menu style:
Press [MENU] .
1
Select “Fold”, “Grid” or “List” with the
2
Navigation Key then press [OK] to save it.
GRAPHICS
To select an LCD display:
WALLPAPER
Press [MENU] .
1
Select Default to choose a pre-installed display,
2
or Downloads to choose a display you have
downloaded to your phone.
3
Select a display from the Animation and the
Graphic list using the Navigation Key and
press [SELECT] to save it.
POWER ON
Press [MENU] .
1
Select Default to choose a pre-installed display,
2
or Downloads to choose a display you have
downloaded to your phone.
3
Select a display from the Animation and the
Graphic list using the Navigation Key and
press [SELECT] to save it.
61
C
H
4
SETTINGS SETTINGS
C
H
4
POWER OFF
Press [MENU] .
1
Select Default to choose a pre-installed display,
2
or Downloads to choose a display you have
downloaded to your phone.
3
Select a display from the Animation and the
Graphic list using the Navigation Key and
press [SELECT] to save it.
RECEIVED
Press [MENU] .
1
Select Default to choose a pre-installed display,
2
or Downloads to choose a display you have
downloaded to your phone.
3
Select a display from the Animation list using
the Navigation Key then press [SELECT] to
save it.
DIALED
Press [MENU] .
1
SCREEN SAVER
Sets the time of Screen Saver and selects the images to be displayed
on the LCD.
Press [MENU] .
1
Select “Time Setting” or “Screen Saver” with
2
the Navigation Key.
Time Setting : Off, 5 Secs, 10 Secs, 20 Secs, 30 Secs.
l
Screen Saver : Select picture image.(Multimedia/Images).
l
By pressing [MENU], the user can choose from the following:
1. Erase: To erase pictures saved in the current album.
2. Erase All: To erase all pictures saved in the current album.
3. Change Title: To edit the title of a picture file.
To save, press [SELECT].
3
SUB SCREEN
Press [MENU] .
1
2
Select “Digital” or “Analog” with the
Navigation Key.
To save, press [OK].
3
C
H
4
Select “Default” with the Navigation Key.
2
Press [SELECT] to save it.
3
62
63
SETTINGS
SETTINGS
GREETING MESSAGE
To input a personal greeting:
Press [MENU] .
1
The Message field will be highlighted. Press the
2
Navigation Key left or right to choose between
on and off. Press the Navigation Key down to
move to the next field, font. Press the Navigation
Key left or right to choose a font color. Press the
Navigation Key down to move to the next field,
Bg. Press the Navigation Key left or right to
choose a Bg color. Repeat for both fields. Press
C
H
4
the Navigation Key down for the entry message
field. Enter your greeting.
l
l
l
l
To save, press [SAVE].
3
CONTRAST
To adjust the display contrast:
MAIN LCD/SUB LCD
Message : On/Off.
Font : White, Blue, Dark blue, Magenta, Gray, Black.
Bg : Transparent, White, Blue, Yellow, Gray, Black.
Entry Message : Enter message (Default-Metro PCS).
BACKLIGHT
Backlights the display and key pad and activates dimming for easy
viewing in dark places.
LCD/KEY PAD/DIMMING
Press [MENU] .
1
Select “LCD”, “Key Pad” or “Dimming” then
2
select one of the following options with the
Navigation Key.
LCD : 5 Secs/15 Secs/30 Secs/60 Secs/Always On.
l
Key Pad : 5 Secs/15 Secs/30 Secs/60 Secs/
l
l
To save, press [OK].
3
Always On/Always Off.
Dimming : On/Off.
C
H
4
Press [MENU] .
1
Select “Main LCD” or “Sub LCD” then select one
2
of the following options with the Navigation Key.
Main LCD : Level 1~5.
l
Sub LCD : Level 1~5.
l
To save, press [OK].
3
64
65
SETTINGS
SETTINGS
DATA SVC.
CONNECTION
Choose the connection mode for the usage of your phone.
Press [MENU] .
1
Select one of the following connection modes
2
with the Navigation Key.
Voice Call : To receive a voice call.
l
Data Only : To receive data when connected to PC.
l
C
H
4
To save it, press [OK].
3
This function is available only when the phone is connected
to a data cable.
SECURITY
Prevents unauthorized use of your phone. The following settings can
be restricted:
PHONE LOCK
Prevents the phone from being used without entering the password
first.
Press [MENU] then enter your password.
1
The default password is the last 4 digits of your phone number.
Press then select “Lock Now”, “Lock On
2
Power Up” or “Unlock”.
Lock Now : Lock the phone now.
l
Lock On Power Up : Not locked, but it is automatically
l
Unlock : Do not lock the phone.
l
To save, press [OK].
3
locked when power is recycled.
RESTRICT
When you attempt to make a restricted call, “This phone is restricted”
appears on the screen.
DIALED
Blocks all dialed calls – except emergency calls – but allows an
incoming call to be placed.
C
H
4
66
Press [MENU] then enter your password.
1
Press then select “Allow” or “Restrict”
2
with the Navigation Key.
Allow : Allows a dialed call.
l
Restrict : Restricts a dialed call.
l
To save, press [OK].
3
67
SETTINGS
SETTINGS
RECENT CALLS
Blocks access to Recent Call List.
Press [MENU] then enter your password.
1
Press then select “Allow” or “Restrict”
2
with the Navigation Key.
l
Allow: Allow access to the recent call list.
l
Restrict: Restrict access to the recent call list.
To save, press [OK].
3
PHONE BOOK
Blocks access to, and protects data in your phone book.
C
H
4
Press [MENU] then enter your password.
1
Press and select “Allow” or “Restrict”.
2
Allow: Allows access to the phone book.
l
Restrict: Restricts access to the phone book.
l
To save, press [OK].
3
DATA CALL
Restrict a data call from being placed.
Press [MENU] then enter your password.
1
900#S
Restricts calling 900 dial service numbers.
Press [MENU] then enter your password.
1
Press then select “Allow” or “Restrict”
2
with the Navigation Key.
Allow : Allows calls to a 900-dial service.
l
Restrict : Restricts calls to a 900-dial service.
l
To save, press [OK].
3
LONG DISTANCE
Restricts calling long distance numbers – the phone is limited to
calling numbers within the area.
Press [MENU] then enter your password.
1
Press then select “Allow” or “Restrict”
2
with the Navigation Key.
Allow : Allow a long distance call.
l
Restrict : Restrict a long distance call.
l
To save, press [OK].
3
CHANGE CODE
Changes your 4-digit password.
C
H
4
Press then select “Allow” or “Restrict”
2
with the Navigation Key.
Allow : Allows a data call.
l
Restrict : Restricts a data call.
l
To save, press [OK].
3
68
Press [MENU] then enter your password.
1
Press .
2
Enter a new password then press [OK].
3
Enter the new password again and
4
press [OK].
69
SETTINGS
SETTINGS
SPECIAL #’S
Stores 3 phone numbers that can be called even in the lock mode.
Press [MENU] then enter your password.
1
Press then select a location with the
2
Navigation Key.
Press [SET] and input a phone number,
3
press [OK] again to save.
ERASE ALL
C
Clears all phone book entries and downloaded entries.
H
Press [MENU] then enter your password.
4
1
Press .
2
Press to check “Phonebook” or “Downloads”
3
then press [OK] to erase all the items in
those categories.
RESET PHONE
Resets phone to default settings.
OTHERS
ANSWER OPTIONS
CALL ANSWER
To select an answer mode:
Press [MENU] .
1
Select “Any Key” or “Send Key” with the
2
Navigation Key.
Any Key : Press any key to answer an incoming call except
l
Send Key : Press only to answer a call.
l
To save, press [OK].
3
ACTIVE FLIP
To select Active Flip Answer mode:
Press [MENU] .
1
Select “On” or “Off” with the Navigation Key.
2
To save, press [OK].
3
, , and .
C
H
4
Press [MENU] then enter your password.
1
Press .
2
Select “Yes” or “No” with the Navigation Key.
3
Press [OK].
When you select "Yes" and [OK], you will see “Reset
Phone! this will reset to default settings” on the display.
70
When Active Flip On is selected, an incoming phone call can
l
be answered simply by opening the phone.
When Active Flip Off is selected, you will need to open the
l
phone and use the Answer mode you have selected.
71
SETTINGS
SETTINGS
AUTO ANSWER
Automatically answers a call after a preset amount of time.
Auto Answer only works when the phone is open.
Press [MENU] .
1
Select one of the following with the Navigation Key.
2
Off/5 Secs/10 Secs/18 Secs.
l
This function will not be active when you select Vibrate, Silent,
Etiquette or Ringer off as a ringer mode.
To save, press [OK].
C
H
4
3
AUTO RETRY
Automatically redials a call up to 5 times after a set time interval.
Press [MENU] .
1
The Retry Time field is displayed. Press the
2
Navigation Key left or right to choose the amount
of time. (Off, 3 Secs, 5 Secs, 7 Secs or 10 Secs.)
When a time is chosen for retry time, the repeat
3
field is shown. Press the Navigation Key down to
highlight the repeat field. Press the Navigation
Key left or right to choose the number of
repeats. (1 time, 3 times or 5 times).
LANGUAGE
Selects the language in which letters are displayed on screen.
Press [MENU] .
1
Select either “English” or “Spanish” with the
2
Navigation Key.
To save, press [OK].
3
VOICE PRIVACY
Enhances voice privacy and avoids tapping during a call.
Press [MENU] .
1
Select “Standard” or “Enhanced” with the
2
Navigation Key.
To save, press [OK].
3
“Enhanced” : Makes it more difficult to wire tap.
l
C
H
4
To save, press [OK].
4
72
73
SETTINGS SETTINGS
TTY MODE
Your phone is able to operate with a TTY (Teletypewriter) device in
both analog and digital modes. This feature is system dependent and
may not be available in all areas.
Press [MENU] .
1
Select one of the following options (TTY Off /
2
TTY+TALK / TTY+HEAR / TTY Full) with the
Navigation Key then press [OK].
LOCATION
To determine whether or not the network system can detect your
position:
C
H
Press [MENU] .
4
1
Select “911 Only” or “Location On” with the
2
Navigation Key.
911 Only : Your location will be hidden from network
l
Location On : Your location is now available to the network.
l
To save, press [OK].
3
& application except 911.
SYSTEM
SET MODE
Selects the Preferred System.
Press [MENU] .
1
Select one of the following options (Automatic B
2
/Automatic A /Home only) with the Navigation
Key then press [OK].
Automatic B : Scan the radio channels based on the
l
Automatic A : Scan the radio channels based on the
l
Home only : Only within your home area or home affiliated
l
Automatic B setting.
Automatic A setting.
area.
NAM SETTING
Enables Auto NAM (Number Assignment Modules) or manually selects
a NAM.
AUTO NAM
Automatically switches phone to proper NAM when you have multiple
NAM registrations.
Press [MENU] .
1
C
H
4
74
Select “Yes” or “No” then, press [OK] to
2
save it.
75
SETTINGS SETTINGS
CHANGE NAM
Changes the NAM used by the phone when you have multiple
registrations.
Press [MENU] .
1
Select “NAM1-Metro PCS” or “NAM2-Metro PCS”
2
then press [OK] to save it.
PRL ID
Displays the phone’s PRL (Preferred Roaming List).
Press [MENU] .
1
C
H
4
To return to the previous page, press [OK].
2
PHONE INFO.
Displays the version of your phone:
S/W VERSION
Press [MENU] .
1
The software version appears.
2
Press [OK].
3
H/W VERSION
Press [MENU] .
1
The hardware version appears.
2
Press [OK].
3
@ METRO VERSION
Press [MENU] .
1
C
H
4
76
The “@ Metro” software version appears.
2
Press [OK].
3
77
MY METRO MY METRO
My Metro shows users their balance, account information, and
payment options.
MONTHLY BILL
This is where the Billing Message is saved and shows the user the
balance, due date and account information.
Press [MENU] .
1
Press [PAY]. “Credit Card”, “MetroPCS Card”
2
and “Other Options” appear on the display.
After making your selection, the call will be placed
3
C
H
4
to make the payment.
METROCONNECT
Press [MENU] .
1
When MetroConnect is selected, the message
2
“Call now to request balance or add money?”
appears. To complete the call, press [OK].
METROPCS CARD
Press [MENU] .
1
When the MetroPCS Card is selected, “Request
2
Balance” and “Pay Monthly Bill” appear on the
display.
When you select Request Balance, “Call now to
3
request your MetroPCS Card balance?” will
appear. To complete the call, press [OK].
If the user selects Pay Monthly Bill, the user can
4
choose from an option of Credit Card, MetroPCS,
and other options. The payment will be made
accordingly to the option selected.
C
H
4
78
79
UTILITIES
UTILITIES
EVENT
Sets an event and reminds you of that event.
ADD NEW PLAN
Press [MENU] .
1
Move the Navigation Key left, right, up or down to
2
choose a date in the calendar then press [OK].
The date field is highlighted. Press the Navigation
3
Key down to set the alarm options.
DATE SETTING
C
H
4
Use the keypad to change or enter the date
then press [OK].
TIME SETTING
Use the keypad to set a time and to select
“AM” or “PM” then press [OK].
PLAN SETTING
Use the keypad to input a plan message then
press [OK].
SETTING
Select an alert time interval option (On Time, 10 Min
Before, 30 Min Before, 1 Hour Before, No Alarm) by
pressing the Navigation Key left or right.
RINGER SETTING
To set a Ringer, press [MENU], then select
“Default” or “Change” using the Navigation Key.
To save it press [SELECT].
Default : To set default ringer type.
Change : Choose a ringer type from the list.
Press [SAVE] to save it or [CLR] to
4
return to the calendar.
The date of the event will be marked on your
5
calendar.
VIEW PLAN
To view the Event List,
1
press [MENU] .
Use the Navigation Key to choose an event
2
then press [OK] or [ERASE].
Press [MENU], then select “Erase All” using
the Navigation Key, “Erase all plans?” will
appear. Press [OK] to delete.
ALARM
You can set up to 3 alarms.
To display alarm entries, press [MENU] .
1
Select one of the entries using the Navigation Key.
2
To set a new alarm, choose alarm 1, 2 or 3.
To edit an existing alarm, select that alarm.
Press [OK].
The setting field will be highlighted. Press the
3
Navigation Key down to select alarm options.
SETTING
Use the Navigation Key to select a setting for the
alarm (Once, Daily, Weekly, Monthly, Off).
C
H
4
80
81
UTILITIES
UTILITIES
DATE SETTING
Use the keypad to change or enter the date for the
alarm then press [OK].
If weekly is chosen for setting, date field becomes
day of the week field.
Once: Enter a date.
Daily: Select a time.
Weekly: To select “Monday”, “Tuesday”, “Wednesday”,
“Thursday”, Friday”, “Saturday”, “Sunday”.
Monthly: Select 1st– 31
Off
st
TIME SETTING
Use the keypad to set a time for the event and
C
H
4
to select “AM” or “PM”, then press [OK].
SNOOZE SETTING
Use the Navigation Key to select a Snooze setting
(Off, 1 time after 5 min, 1 time after 10 min, 3 times
by 5 min).
MEMO PAD
Your phone includes an internal memo pad that can be used to
compose and store reminders and notes.
ADD MEMO
To compose a memo (there is an 80-letter limit):
Press [MENU] .
1
Input a new text memo.
2
(Please refer to page 31 for more details on entering
letters, numbers & symbols.)
To save memo, press [OK].
3
VIEW MEMO
To view a saved memo:
1.1. Press [MENU] .
1
1.2. To erase a memo, press [ERASE].
C
H
4
1.3. To add a new memo, press [MENU]
RINGER SETTING
To set a “Ringer” press [MENU], then select
“Default” or “Change” using the Navigation Key.
To save it, press [SELECT].
Default : To set default ringer type.
Change : To select a custom ringer from the list.
PLAN SETTING
Using the keypad, input an alarm message then
press [OK].
To save an alarm setting press [SAVE].
4
2
3
SETTINGS
To select memo pad background image:
1
“New Memo”.
1.4. To erase all memos, press [MENU]
“Erase All”.
The list of all memos, in saved order, is displayed.
Select a memo then press [OK].
The selected memo will appear. To edit it,
press [MENU], select “Edit” and input a new
text memo, then press [OK] to save it.
Press [MENU] .
82
Select (Paper/Pattern/Sea/Sky/Flower) by pressing
2
Navigation Key left or right then press [OK].
83
UTILITIES
UTILITIES
CALCULATOR
To access the calculator:
Press [MENU] .
1
Follow the instructions below to calculate
2
8*6
4-2.5=9.5
Input 8.
Move the Navigation Key rightward.
Input 6 then press the Navigation Key.
Move it leftward.
Input 4 then press the Navigation Key.
Move it downward.
Input 2 then press the to input (.).
C
H
4
Press 5.
Then press and you will see the answer.
: X, : -, : /, : +, : ., : Reset, : =.
To reset, press [RESET].
3
WORLD CLOCK
To display the time and date in pre-programmed cities:
Press [MENU] .
1
Select a city with the Navigation Key.
2
STOP WATCH
Simultaneously times up to six different events. To operate the
stop watch:
Press [MENU] .
1
To measure a time period.
2
1. To start the stop watch, press [START].
2. To pause it, press [STOP].
3. To resume it, press .
To reset it, press [RESET].
To return to the previous page, press [EXIT].
To time up to six events at once:
3
1. To start, press [START].
2. To stop a time period and continue
measuring another one, press [CONT].
3. To stop the second and continue measuring
a third one, press [CONT].
4. To measure up to six time periods, repeat the
above steps.
5. To stop the stop watch, press [STOP].
6. To review the results, press [VIEW].
7. To return to the stop watch, press [OK].
8. To reset it, press [RESET].
C
H
4
The world map appears with the city, its date
3
and time.
Use the Navigation Key to select another city.
As the daylight saving time is not applied, the time may be different
from the actual time during DST.
To return to the previous page, press [OK].
4
84
85
MEMO
Chapter 5
VOICE SERVICE
C
H
4
This chapter addresses Voice Service, an advanced feature that
allows you to place calls using your voice. With Voice Memo (VM)
you can record voice messages and set the Answering Machine.
Topics include:
VOICE TOOLS MENU
VOICE RECOGNITION MODE
C
H
5
86
87
87
VOICE TOOLS MENU
VOICE TOOLS MENU
VOICE MEMO
Voice Memo allows you to record a reminder message that can be up
to 60 seconds. To record a memo:
To start Tools menu, press [MENU] .
1
To enter a voice memo, press .
2
1.1.To record a voice memo, press .
3
Instructions will be displayed and you will
hear “Please record at the tone.”
1.2.To stop recording a memo, press [STOP]
or [PAUSE/RESUME].
1.3. Press [MENU] after recording a voice memo
to “Review” or “Re-record.”
1.4. Press [SAVE] to input a “Voice Memo” title,
then press [OK]. (See page 31 for more
C
H
5
information on entering letters, numbers and
symbols.)
2.To play voice memo, press .
Select the message you want to play then
press [PLAY] or press [MENU] to
1. Edit Title.
Press [ERASE] to erase the memo.
3.To play speaker mode, press .
Select the message you want to play then
press [PLAY] or press [MENU] to
1. Edit Title.
Press [ERASE] to erase the memo.
VOICE DIAL
Voice Dial allows you to call a person by simply saying their name.
To access Voice Dial:
To start Voice Tools menu, press [MENU] .
1
To enter a voice dial, press .
2
1.1. To record a voice dial, press .
3
The phone book list will be displayed
alphabetically. Select a name then press
[OK]. Instructions will be displayed and you
will hear “Name Please”.
1.2. Say the name for the voice tag and repeat the
name when prompted. You will hear “Added”.
2. To play a voice dial, press .
Highlight the voice tag you want to play then
press [PLAY] or press [ERASE].
3. To play speaker mode, press .
Highlight the voice tag you want to play then
press [PLAY] or press [ERASE].
4. To erase all voice dials, press .
“Removing all voice tags Proceed?” will be
displayed.
Press [OK] to erase all voice dials.
C
H
5
4.To erase all voice memos, press .
“Erase all voice memos?” will be displayed.
Press [OK] to erase all voice memos.
88
89
VOICE TOOLS MENU
VOICE TOOLS MENU
TRAIN WORDS
Train allows you to use Control words to make a call without using the
keypad.
YES
Use to train or untrain the Voice Recognition with the control word,
“Yes”.
Press [MENU] .
1
“Please listen closely to hear instructions”
2
will be displayed and you will hear “Now
training control words. Please say the word
yes”.
Say “Yes”. You will hear “Again”. Say “Yes”
3
again. You will hear “Training word successful”.
NO
C
H
Use to train or untrain the Voice Recognition with the control word,
5
“No”.
Press [MENU] .
1
“Please listen closely to hear instructions” will
2
be displayed and you will hear “Now training
control words. Please say the word no”.
WAKE-UP
Use to train or untrain the Voice Recognition with the control word,
“Wake-Up”.
Press [MENU] .
1
“Please listen closely to hear instructions” will
2
be displayed and you will hear “Now training
control words. Please say the word WakeUp”.
Say “Wake-Up”. You will hear “Again”.
3
Say “Wake-Up” again. You will hear “Training
word successful”.
UNDO TRAIN ALL
Undo Train All erases all “trained” words.
Press [MENU] .
1
“Undo voice recognition for all procedures?”
2
will be displayed. Press [OK] to undo all
trained words.
C
H
5
Say “No”. You will hear “Again”. Say “No” again.
3
You will hear “Training word successful”.
90
91
VOICE TOOLS MENU
VOICE RECOGNITION MODE
VOICE SETTING
SET ACTIVE
Allows the user to activate or deactivate voice dial service.
Press [MENU] .
1
Select “Active Flip” or “Send Key” by
2
pressing the Navigation Key left or right.
To save, press [OK].
3
HFK MODE
While using the Hands Free Kit, activates or deactivates the voice
recognition function.
Press [MENU] .
1
C
H
5
Scroll to HFK Mode. Select “On” or “Off” by
2
pressing the Navigation Key left or right.
To save, press [OK].
3
Voice Recognition (VR) enables you to place calls using your voice
and to record voice memos.
Only phone numbers with saved voice tags can be called in VR mode.
See page 91 for more on creating voice tags.
Press and hold until your phone turns to
1
Voice Recognition mode.
If there are no recorded voice dials, “No entries recorded” message
will be displayed.
“Please say the name after the
2
prompt tone” will be displayed
and you will hear “Name please”.
NAME
Press and hold until your phone turns to
1
Voice Recognition mode.
If you say a name or tag that is already in the
2
phone book, the number and name will be
displayed and you will hear “Calling (name).”
C
H
5
92
93
MEMO
Chapter 6
VOICE MAIL AND TEXT
MESSAGE
This chapter addresses Voice Mail and Text Messaging functions
C
H
5
including:
WHEN A NEW MESSAGE ARRIVES
VOICE MAIL
NEW TEXT MSG
INBOX
OUTBOX
WEB ALERTS
SAVED
QUICK TEXT
ERASE ALL
SETTINGS
C
H
6
94
95
95
WHEN A NEW MESSAGE ARRIVES NEW TEXT MSG
The following display appears
1
when a new message arrives.
To display the message, press [READ].
2
VOICE MAIL
Displays the number of voice mails and accesses them by pressing .
To access your voice mail,
1
press [MENU] or .
FIRST TIME USER
Dial *86 then press [SEND].
1
C
H
6
At the recording, press .
2
To set up your account follow the voice tutorial.
3
EXISTING USER
To send a new message:
Press [MENU] or .
1
Under “Send To”, input the phone number and
2
press [OK].
By pressing [MENU], you can choose from the following:
1. Find : Search the phone number which is stored in the
phone book.
2. Save : Stores the phone number the message was sent to.
3. Msg. Group : Select all the phone numbers in a group.
Under “Message”, input a new text message
3
then press [OK].
(Please refer to page 31 for more details on entering letters,
numbers and symbols.)
By pressing [MENU], in the message input screen you can
choose from the following:
1. Insert Quick Text: Inserts canned text into a Text Msg.
2. Insert Sound: Inserts sound in Text Msg.
3. Insert Picture: Inserts picture in Text Msg.
4. Insert Animation: Inserts Animation in Text Msg.
5. Save to Quick Text: Saves the written sentences into
The default call back number is automatically
4
included into the Default CB# field. You can
scroll to the number and edit it or simply
press [EDIT].
Press the Navigation Key down for more fields.
5
Under “Priority”, select “Normal’ or “Urgent”.
Quick Text.
C
H
6
Dial *86 then press [SEND].
1
At the recording, enter your 4 digit password,
2
then press .
To listen to new messages, press .
3
96
Under “Insert Signature”, select “On” or “Off”.
6
7.1. To send the text message press [MENU],
7
select “Send”, then press [OK].
7.2. To save the text message press [MENU],
select “Save to Outbox”, then press [OK].
97
INBOX INBOX
The Inbox manages received text messages. To access:
Press [MENU] or .
1
: Urgent New Msg (not read)
: Urgent Read Msg
: New Msg (not read)
: Old Msg (already read)
: Lock (already read and locked)
Select a message then press [OK].
2
The message is displayed. To delete a message,
press [ERASE].
3
Press [MENU].
REPLY
Type your reply then press [OK].
1
REPLY WITH COPY
To reply to a received message and include the
C
H
6
1
received message into the message:
The default call back number is automatically
2
included into the Default CB# field.
You can scroll to the number and edit it.
Under “Insert Signature”, select “On” or “Off”.
3
To send the text message, press [MENU] then
4
select “Send”, then press [OK].
FORWARD
To forward the text message:
1
Input the phone number of the person you are
2
sending the message, then press [OK].
Input any text message to go along with the
3
forwarded message, then press [OK].
SAVE MEDIA
Select to save a picture to the media gallery folder.
1
“Save Media" menu appears only when you receive a picture
message or EMS message.
SAVE TO CONTACT
Select to save number to contacts.
1
SAVE TO SAVED
Select to save the text message to your phone.
1
SAVE TO QUICK TEXT
Select to save received text msg to “Quick Text”.
1
BLOCK SENDER
Select to block all incoming messages from
1
addresses on block list.
LOCK & UNLOCK
C
H
6
To save the text message, press [MENU] and
5
select “Save to Outbox”, then press [OK].
98
Select “Lock” to lock the message or “Unlock”
1
to unlock the message, then press .
99
OUTBOX OUTBOX
Manages sent text messages or messages waiting to be sent.
CHECKING SENT TEXT MESSAGES
Press [MENU] or .
1
: Auto resend
: Delivered
: Fail
: Not Sent
: Read
: Sent
2.1. Select a message, then press [OK].
2
The text message is displayed.
2.2. To erase message, press [ERASE].
Press [MENU].
3
RESEND
Resends a text message.
1
C
H
EDIT MESSAGE
6
To send a message to another person:
1
SAVE TO CONTACT
Select to save number to contacts.
1
SAVE TO SAVED
Select to save the text message to your phone.
1
LOCK & UNLOCK
Select “Lock” to lock the message or “Unlock”
1
to unlock the message, then press [OK].
STATE
Select to display the status of an outbox
1
message.
"State" menu appears only when you receive a text message.
C
H
6
Input a text message then press .
2
Input the phone number then press .
3
100
101
SAVEDWEB ALERTS
WEB ALERTS
Press [MENU] or .
1
To select GoTo, press .
2
To select Erase Message, press .
3
The Web Alerts message will be displayed.
• [ ] : Read Message.
V
• [ ] : Unread Message.
• [ ] : Displays the remaining text.
• GoTo : Connecting to Selected Site.
• Erase : Erase Selected Message.
SAVED
Manages saved messages from the Inbox/Outbox.
Press [MENU] or .
1
2.1. Select a text message then press [OK].
2
The text message is displayed.
2.2. To erase message, press [ERASE].
Press [MENU].
3
The following menu options will appear, if the
4
text message is saved from the “Inbox” menu.
To select inbox menu : Reply, Reply With Copy, Forward,
Save to Quick Text, Block Sender,
Save to Contact, Lock & Unlock
The following menu options will appear, if the
text message is saved from the “Outbox” menu.
To select outbox menu : Resend, Edit Message,
C
H
6
Select one by pressing [OK].
5
Save to Contact, Lock & Unlock,
State
C
H
6
102
• "Save Media" menu appears only when you receive a picture
message or EMS message.
• "State" menu appears only when you receive a text message.
103
ERASE ALLQUICK TEXT
QUICK TEXT
To edit the Quick Text message you have saved:
Press [MENU] or .
1
2.1. Select a message from the list.
2
3
C
H
6
Press [MENU].
2.2. To add a new Quick Text message,
press [ADD NEW]. To edit the Quick
Text message you have selected,
press [EDIT].
To erase the saved Quick Text message,
press [ERASE].
ERASE MESSAGES
Press [MENU] or .
1
1. To erase all the inbox messages, press .
2
Old Inbox : To erase all messages already read.
(However, the locked Message(s) will not be deleted).
Entire Inbox : To erase all messages.
2. To erase all the outbox messages, press .
3. To erase the saved messages, press .
Select “OK” or “Cancel” with [OK]
3
or [CANCEL].
C
H
6
104
105
SETTINGSSETTINGS
Manages messaging features through various features.
AUTO SAVE
SAVE SENT MSG
Press [MENU] or .
1
Press .
2
Select either “Off”, “On” or “Prompt” with the
Navigation Key.
Press [OK].
3
AUTO ERASE
Automatically erases inbox/outbox messages when new messages
arrive.
INBOX
Press [MENU] or .
1
Press .
2
C
H
6
Select “Disable” or “Enable” with Navigation Key.
Press [OK].
3
DEFAULT CALLBACK
Edits a default callback number so that the recipient can callback or
reply.
Press [MENU] or .
1
Press .
2
Input a callback number, then press [OK].
You can look it up from the phone book by
pressing [FIND].
EDIT VOICE CALLBACK
Press [MENU] or .
1
Press .
2
Input a new voice call back number or edit
voice call back number.
You can look it up from the phone book by
pressing [FIND].
Press [OK].
3
C
H
6
OUTBOX
1
Press [MENU] or .
Press .
2
Select “Disable” or “Enable” with Navigation Key.
Press [OK].
3
106
REMIND
Press [MENU] or .
1
Press .
2
Select “On” or “Off” with the Navigation Key.
Press [OK].
3
107
SETTINGSSETTINGS
EDIT SIGNATURE
Create a signature that can be automatically inserted at the end of a
message.
1
Press [MENU] or .
Press .
2
To input “Signature”, put the cursor on Edit
Signature then enter Signature Edit window by
using right or left direction keys.
To activate Signature function, put the cursor on
3
Insert Signature then select “On” by using right
or left direction keys. To deactivate Signature
function, select “Off”.
Press [OK].
4
DIRECT VIEW
If the Direct View is set to on, the user will be able to view the
message by pressing the read key. If the Direct View is set to off,
the user can view the message by entering SMS Menu-> Inbox.
C
H
6
Press [MENU] or .
1
Press .
2
Select “On” or “Off” with the Navigation Key.
ON : Set to read msg without entering inbox in SMS menu.
OFF : Set to read msg after entering inbox in SMS menu.
ENTRY MODE
Sets an Entry Mode as a default. For example, if T9 Mode is the
default, its icon will appear.
1
Press [MENU] or .
Press .
2
Select “Alpha Mode” or “T9 Mode” with
the Navigation Key.
Press [OK].
3
BLOCK OR UNBLOCK
Press [MENU] or .
1
Then press .
2
Select “Block”, “Unblock” or “View List of
Blocked Address” with the Navigation Key.
BLOCK : Enter the address to block.
UNBLOCK : Enter the address to remove from block.
VIEW LIST OF BLOCKED ADDRESS : Display the blocked
Press [OK].
3
list on LCD.
C
H
6
Press [OK].
3
108
109
MEMO
Chapter 7
MOBILE WEB
This chapter addresses Internet services and web browsing.
For more detailed information contact your service provider.
LAUNCHING MOBILE WEB
BROWSER MENU
C
H
6
110
111
C
H
7
LAUNCHING MOBILE WEB BROWSER MENU
ACCESS THE INTERNET
To start your Internet browser and access
1
websites through your wireless handset press
[MENU] or .
BROWSER MENU
The browser menu lists the actions necessary to operate the browser.
To access press [MENU] or press .
HOME
When the home item is selected from the browser menu, the phone
displays the home page.
To display the homepage, press [MENU]
1
BACK
To return to the previous page, press [MENU]
C
H
7
1
FORWARD
or , then press .
or , then press .
REFRESH
Selecting the refresh item from the browser menu refreshes the current
page.
To select “Refresh”, press [MENU]
1
or , then press .
HISTORY
When the history item is selected from the browser menu, the browser is
displayed with the browser version and copyright information.
The device layer version is also displayed.
To select “History”, press [MENU]
1
or , then press .
ADDRESS
Selecting the “Address” action displays the URL of the current
page.
To select “Address”, press [MENU]
1
or , then press .
CLEAR MEMORY
To clear browser memory, press [MENU]
1
or , then press .
C
H
7
To forward to the next page, press [MENU]
1
or , then press .
112
113
BROWSER MENU
SETTINGS
To select “Settings”, press [MENU]
1
Downloads
Restart Browser
Scroll Mode
Send Referrer
Key Press Timeout
Connection Timeout
ADVANCED
Selecting the advanced item in the browser menu displays the
advanced menu items.
To select “Advanced”, press [MENU]
1
About...
Encryption: 1. Authentication
EXIT
To exit browser, press [MENU]
1
C
H
7
or , then press .
or , then press .
2. Root Certificate
3. Current Certificate
or , then press .
Chapter 8
SAFETY AND
WARRANTY
This chapter addresses the safety guidelines and precautions to
follow when operating your phone. Before operating your phone,
please be aware of all the safety details.
This chapter contains the terms and conditions of services and the
warranty for your phone. Please review them thoroughly.
SAFETY INFORMATION FOR WIRELESS
HANDHELD PHONES
SAFETY INFORMATION FOR FCC RF EXPOSURE
SAR INFORMATION
FDA CONSUMER UPDATE
PROTECT YOUR WARRANTY
12 MONTH LIMITED WARRANTY
C
H
8
114
115
SAFETY INFORMATION FOR WIRELESS
HANDHELD PHONES
SAFETY INFORMATION FOR WIRELESS
HANDHELD PHONES
Read This Information Before Using Your Handheld
Portable Cellular Telephone
EXPOSURE TO RADIO FREQUENCY SIGNALS
Your wireless handheld portable telephone is a low power radio
transmitter and receiver. When it is ON, it receives and also sends out
radio frequency (RF) signals.
In August 1996, the Federal Communications Commissions (FCC)
adopted RF exposure guidelines with safety levels for handheld wireless
phones. Those guidelines are consistent with the safety standards
previously set by both U.S. and international standards bodies:
ANSI C95.1 (1992) *
NCRP Report 86 (1986) *
ICNIRP (1996) *
Those standards were based on comprehensive and periodic evaluations
of the relevant scientific literature. For example, over 120 scientists,
engineers, and physicians from universities, government health agencies,
and industry reviewed the available body of research to develop the ANSI
Standard (C951).
The design of your phone complies with the FCC guidelines (and those
standards).
ANTENNA CARE
Use only the supplied or an approved replacement antenna. Unauthorized
antennas, modifications, or attachments could damage the phone and
may violate FCC regulations.
DRIVING SAFETY
Talking on the phone while driving is extremely dangerous and is illegal in
some states. Remember, safety comes first. Check the laws and regulations
on the use of phones in the areas where you drive. Always obey them.
Also, if using your phone while driving, please:
l Give full attention to driving. Driving safely is your first responsibility.
l Use hands-free operation, if available.
l Pull off the road and park before making or answering a call, if driving
conditions so require.
If you must use the phone while driving, please use one-touch, speed dialing,
and auto answer modes.
An airbag inflates with great force. DO NOT place objects, including both
installed or portable wireless equipment, in the area over the airbag or in the
air bag deployment area. If in-vehicle wireless equipment is improperly
installed and the air bag inflates, serious injury could result.
WARNING: Failure to follow these instructions may lead to serious
personal injury and possible property damage.
C
H
8
1* : American National Standards Institute.
2* : National Council on Radiation protection and measurements.
3* : International Commission on Nonionizing Radiation Protection.
116
117
C
H
8
SAFETY INFORMATION FOR WIRELESS
HANDHELD PHONES
SAFETY INFORMATION FOR WIRELESS
HANDHELD PHONES
ELECTRONIC DEVICES
Most modern electronic equipment is shielded from RF energy. However,
certain electronic equipment may not be shielded against the RF signals
from your wireless phone.
PACEMAKERS
The Health Industry Manufacturers Association recommends that a
minimum separation of six (6”) inches be maintained between a handheld
wireless phone and a pacemaker to avoid potential interference with the
pacemaker. These recommendations are consistent with the independent
research by and recommendations of Wireless Technology Research.
Persons with pacemakers :
l ALWAYS keep the phone more than six inches from your
pacemaker when the phone is turned on.
l Do not carry the phone in a breast pocket.
l Use the ear opposite the pacemaker to minimize the potential for
interference.
l If you have any reason to suspect that interference is taking place,
turn your phone OFF immediately.
OTHER MEDICAL DEVICES
If you use any other personal medical device, consult the manufacturer of
your device to determine if they are adequately shielded from external RF
energy. Your physician may be able to assist you in obtaining this
information.
Turn your phone OFF in healthcare facilities when any regulations posted
in these areas instruct you to do so. Hospitals or healthcare facilities may
be using equipment that could be sensitive to external RF energy.
OTHER SAFETY GUIDELINES
AIRCRAFT
FCC and Transport Canada Regulations prohibit using your phone while
in the air. Turn your phone OFF before boarding an aircraft.
BLASTING AREAS
To avoid interfering with blasting operations, turn your phone OFF when in
a “blasting area” or in areas posted: “Turn off two-way radio.” Obey all
signs and instructions.
POTENTIALLY EXPLOSIVE ATMOSPHERES
Turn your phone OFF when in any area with a potentially explosive
atmosphere and obey all signs and instructions. Sparks in such areas
could cause an explosion or fire resulting in bodily injury or even
death.
Areas with a potentially explosive atmosphere are often, but not
always, clearly marked. They include fueling areas such as gas
stations; below deck on boats; fuel or chemical transfer or storage
facilities; vehicles using liquefied petroleum gas (such as propane or
butane); areas where the air contains chemicals or particles, such as
grain, dust, or metal powders; and any other area where you would
normally be advised to turn off your vehicle's engine.
POSTED FACILITIES
Turn your phone OFF where posted notices so require.
C
H
8
118
119
C
H
8
SAFETY INFORMATION FOR WIRELESS
HANDHELD PHONES
SAFETY INFORMATION FOR
FCC RF EXPOSURE
PRECAUTIONS
Your Handheld Portable Telephone is a high quality piece of
equipment. Before operating, read all instructions and cautionary
markings on (1) AC Adaptor (2) Battery and (3) Product Using Battery.
DO NOT use this equipment in an extreme environment where
high temperature or high humidity exists.
DO NOT abuse the equipment. Avoid striking, shaking or
shocking. When not using, lay down the unit to avoid possible
damage due to instability.
DO NOT expose this equipment to rain or spilled beverages.
DO NOT use unauthorized accessories.
DO NOT disassemble the phone or its accessories. If service
or repair is required, return unit to an authorized Audiovox
cellular service center. If unit is disassembled, the risk of
electric shock or fire may result.
DO NOT short-circuit the battery terminals with metal items etc.
WARNING! Read this Information before using
CAUTIONS
In August 1996 the Federal Communications Commission (FCC) of
the United States with its action in Report and Order FCC 96-326
adopted an updated safety standard for human exposure to radio
frequency electromagnetic energy emitted by FCC regulated
transmitters. Those guidelines are consistent with the safety standard
previously set by both U.S. and international standards bodies. The
design of this phone complies with the FCC guidelines and these
international standards.
Use only the supplied or an approved antenna. Unauthorized
antennas, modifications, or attachments could impair call quality,
damage the phone, or result in violation of FCC regulations.
Do not use the phone with a damaged antenna. If a damaged
antenna comes into contact with the skin, a minor burn may result.
Please contact your local dealer for replacement antenna.
BODY-WORN OPERATION
This device was tested for typical body-worn operations with the
back of the phone kept 2.0 cm. from the body. To maintain
compliance with FCC RF exposure requirements, use only belt-clips,
holsters or similar accessories that maintain a 2.0 cm. separation
distance between the user’s body and the back of the phone,
including the antenna. The use of belt-clips, holsters and similar
accessories should not contain metallic components in its assembly.
The use of accessories that do not satisfy these requirements may
not comply with FCC RF exposure requirements, and should be
avoided.
For more information about RF exposure, please visit the FCC
website at www.fcc.gov
C
H
8
120
121
C
H
8
SAR INFORMATION SAR INFORMATION
THIS MODEL PHONE MEETS THE GOVERNMENT’S
REQUIREMENTS FOR EXPOSURE TO RADIO WAVES.
Your wireless phone is a radio transmitter and receiver. It is designed
and manufactured not to exceed the emission limits for exposure to
radiofrequency (RF) energy set by the Federal Communications
Commission of the U.S. Government. These limits are part of
comprehensive guidelines and establish permitted levels of RF energy
for the general population. The guidelines are based on standards that
were developed by independent scientific organizations through
periodic and thorough evaluation of scientific studies. The standards
include a substantial safety margin designed to assure the safety of all
persons, regardless of age and health.
The exposure standard for wireless mobile phones employs a unit of
measurement known as the Specific Absorption Rate, or SAR. The SAR
limit set by the FCC is 1.6 W/kg. * Tests for SAR are conducted with the
phone transmitting at its highest certified power level in all tested
frequency bands. Although the SAR is determined at the highest
certified power level, the actual SAR level of the phone while operating
can be well below the maximum value. This is because the phone is
designed to operate at multiple power levels so as to use only the
power required to reach the network. In general, the closer you are to a
wireless base station antenna, the lower the power output.
Before a phone model is available for sale to the public, it must be
tested and certified to the FCC that it does not exceed the limit
established by the government adopted requirement for safe exposure.
The tests are performed in positions and locations (e.g., at the ear and
worn on the body) as required by the FCC for each model. The highest
SAR value for this model phone when tested for use at the ear is 1.15
W/Kg and when worn on the body, as described in this user guide, is
0.393W/Kg. (Body-worn measurements differ among phone models,
depending upon available accessories and FCC requirements). While
there may be differences between the SAR levels of various phones
and at various positions, they all meet the government requirement for
safe exposure.
The FCC has granted an Equipment Authorization for this model phone
with all reported SAR levels evaluated as in compliance with the FCC
RF exposure guidelines. SAR information on this model phone is on file
with the FCC and can be found under the Display Grant section of
C
http://www.fcc.gov/ oet/fccid after searching on PP4TX-110C.
H
8
Additional information on Specific Absorption Rates (SAR) can be found
on the Cellular Telecommunications Industry Asso-ciation (CTIA) website at http://www.wow-com.com.
* In the United States and Canada, the SAR limit for mobile phones
used by the public is 1.6 watts/kg (W/kg) averaged over one gram of
tissue. The standard incorporates a sub-stantial margin of safety to give
additional protection for the public and to account for any variations in
measurements.
C
H
8
122
123
FDA CONSUMER UPDATE FDA CONSUMER UPDATE
U.S. Food and Drug Administration -Center for Devices and
Radiological Health Consumer Update on Wireless Phones
1. Do wireless phones pose a health hazard?
The available scientific evidence does not show that any health problems are
associated with using wireless phones. There is no proof, however, that wireless
phones are absolutely safe. Wireless phones emit low levels of radiofrequency
energy (RF) in the microwave range while being used. They also emit very low
levels of RF when in the stand-by mode. Whereas high levels of RF can produce
health effects (by heating tissue), exposure to low level RF that does not produce
heating ef-fects causes no known adverse health effects. Many studies of low level
RF exposures have not found any biological ef-fects. Some studies have
suggested that some biological ef-fects may occur, but such findings have not
been confirmed by additional research. In some cases, other researchers have had
difficulty in reproducing those studies, or in determining the reasons for
inconsistent results.
2. What is FDA’s role concerning the safety of wireless phones?
Under the law, FDA does not review the safety of radiation-emitting consumer
products such as wireless phones before they can be sold, as it does with new
drugs or medical de-vices. However, the agency has authority to take action if
wire-less phones are shown to emit radiofrequency energy (RF) at a level that is
hazardous to the user. In such a case, FDA could require the manufacturers of
wireless phones to notify users of the health hazard and to repair, replace or recall
the phones so that the hazard no longer exists. Although the existing scientific data
do not justify FDA regula-tory actions, FDA has urged the wireless phone industry
to take a number of steps, including the following:
• Support needed research into possible biological effects of RF of the type
emitted by wireless phones;
• Design wireless phones in a way that minimizes any RF ex-posure to the user
that is not necessary for device function;
and
• Cooperate in providing users of wireless phones with the best possible
information on possible effects of wireless phone use on human health.
FDA belongs to an interagency working group of the federal agencies that have
responsibility for different aspects of RF safety to ensure coordinated efforts at the
federal level. The following agencies belong to this working group:
• National Institute for Occupational Safety and Health
• Environmental Protection Agency
• Federal Communications Commission
• Occupational Safety and Health Administration
• National Telecommunications and Information Administration
The National Institutes of Health participates in some inter-agency working group
activities, as well. FDA shares regulatory responsibilities for wireless phones with
the Federal Communications Commission (FCC). All phones that are sold in the
United States must comply with FCC safety guidelines that limit RF exposure. FCC
relies on FDA and other health agencies for safety questions about wireless
phones. FCC also regulates the base stations that the wireless phone networks
rely upon. While these base stations operate at higher power than do the wireless
phones themselves, the RF expo-sures that people get from these base stations
C
are typically thousands of times lower than those they can get from wire-less
H
phones. Base stations are thus not the subject of the safety questions discussed in
this document.
8
3. What kinds of phones are the subject of this update?
The term “wireless phone” refers here to hand-held wireless phones with built-in
antennas, often called “cell,” “mobile,” or “PCS” phones.
These types of wireless phones can expose the user to measurable radiofrequency
energy (RF) because of the short distance between the phone and the user’s head.
These RF exposures are limited by Federal Communications Commission safety
guidelines that were developed with the advice of FDA and other federal health and
safety agencies. When the phone is located at greater distances from the user, the
exposure to RF is drastically lower because a person’s RF exposure decreases
rapidly with increasing distance from the source. The so-called “cordless phones,”
which have a base unit connected to the telephone wiring in a house, typically
operate at far lower power levels, and thus produce RF expo-sures far below the
FCC safety limits.
4. What are the results of the research done already?
The research done thus far has produced conflicting results, and many studies
have suffered from flaws in their research methods. Animal experiments
investigating the effects of radiofrequency energy (RF) exposures characteristic of
wire-less phones have yielded conflicting results that often cannot be repeated in
other laboratories. A few animal studies, how-ever, have suggested that low levels
of RF could accelerate the development of cancer in laboratory animals. However,
many of the studies that showed increased tumor develop-ment used animals that
had been genetically engineered or treated with cancer-causing chemicals so as to
be pre-dis-posed to develop cancer in the absence of RF exposure. Other studies
exposed the animals to RF for up to 22 hours per day. These conditions are not
similar to the conditions under which people use wireless phones, so we don’t
know with certainty what the results of such studies mean for human health. Three
large epidemiology studies have been published since December 2000. Between
them, the studies investigated any possible association between the use of
wireless phones and primary brain cancer, glioma, meningioma, or acoustic neuroma, tumors of the brain or salivary gland, leukemia, or other cancers. None of the
studies demonstrated the existence of any harmful health effects from wireless
phone RF exposures. However, none of the studies can answer questions about
long-term exposures, since the average period of phone use in these studies was
around three years.
5. What research is needed to decide whether RF expo-sure from wireless
phones poses a health risk?
A combination of laboratory studies and epidemiological stud-ies of people
actually using wireless phones would provide some of the data that are needed.
Lifetime animal exposure studies could be completed in a few years. However,
very large numbers of animals would be needed to provide reliable proof of a
cancer promoting effect if one exists. Epidemiological stud-ies can provide data
that is directly applicable to human popu-lations, but 10 or more years’ follow-up
may be needed to pro-vide answers about some health effects, such as cancer.
This is because the interval between the time of exposure to a can-cer- causing
agent and the time tumors develop - if they do -may be many, many years. The
interpretation of epidemiologi-cal studies is hampered by difficulties in measuring
actual RF exposure during day-to-day use of wireless phones. Many fac-tors affect
this measurement, such as the angle at which the phone is held, or which model of
phone is used.
6. What is FDA doing to find out more about the possible health effects of
wireless phone RF?
FDA is working with the U.S. National Toxicology Program and with groups of
investigators around the world to ensure that high priority animal studies are
conducted to address impor-tant questions about the effects of exposure to
radiofrequency energy (RF). FDA has been a leading participant in the World Health
Orga-nization International Electromagnetic Fields (EMF) Project since its inception
in 1996. An influential result of this work has been the development of a detailed
agenda of research needs that has driven the establishment of new research programs around the world.
125124
C
H
8
FDA CONSUMER UPDATE FDA CONSUMER UPDATE
The Project has also helped develop a series of public information documents on
EMF issues. FDA and the Cellular Telecommunications & Internet Asso-ciation
(CTIA) have a formal Cooperative Research and De-velopment Agreement
(CRADA) to do research on wireless phone safety. FDA provides the scientific
oversight, obtaining input from experts in government, industry, and academic organizations. CTIA-funded research is conducted through con-tracts to
independent investigators. The initial research will include both laboratory studies
and studies of wireless phone users. The CRADA will also include a broad
assessment of additional research needs in the context of the latest research
developments around the world.
7. How can I find out how much radiofrequency energy exposure I can get by
using my wireless phone?
All phones sold in the United States must comply with Federal Communications
Commission (FCC) guidelines that limit radiofrequency energy (RF) exposures. FCC
established these guidelines in consultation with FDA and the other federal health
and safety agencies. The FCC limit for RF exposure from wire-less telephones is
set at a Specific Absorption Rate (SAR) of 1.6 watts per kilogram (1.6 W/kg). The
FCC limit is consistent with the safety standards developed by the Institute of
Electri-cal and Electronic Engineering (IEEE) and the National Council on Radiation
Protection and Measurement. The exposure limit takes into consideration the
body’s ability to remove heat from the tissues that absorb energy from the wireless
phone and is set well below levels known to have effects. Manufacturers of
wireless phones must report the RF expo-sure level for each model of phone to the
FCC. The FCC website (http://www.fcc.gov/oet/rfsafety) gives directions for
locating the FCC identification number on your phone so you can find your
phone’s RF exposure level in the online listing.
8. What has FDA done to measure the radiofrequency en-ergy coming from
wireless phones ?
The Institute of Electrical and Electronic Engineers (IEEE) is developing a technical
standard for measuring the radiofrequency energy (RF) exposure from wireless
phones and other wireless handsets with the participation and leader-ship of FDA
scientists and engineers. The standard, “Recom-mended Practice for Determining
the Spatial-Peak Specific Absorption Rate (SAR) in the Human Body Due to
Wireless Communications Devices: Experimental Techniques,” sets forth the first
consistent test methodology for measuring the rate at which RF is deposited in the
heads of wireless phone users. The test method uses a tissue-simulating model of
the human head. Standardized SAR test methodology is expected to greatly
improve the consistency of measurements made at different laboratories on the
same phone. SAR is the mea-surement of the amount of energy absorbed in
tissue, either by the whole body or a small part of the body. It is measured in
watts/kg (or milliwatts/g) of matter. This measurement is used to determine
whether a wireless phone complies with safety guidelines.
9. What steps can I take to reduce my exposure to radiofrequency energy
from my wireless phone?
If there is a risk from these products—and at this point we do not know that there
is—it is probably very small. But if you are concerned about avoiding even
potential risks, you can take a few simple steps to minimize your exposure to
radiofrequency energy (RF). Since time is a key factor in how much exposure a
person receives, reducing the amount of time spent using a wireless phone will
C
reduce RF exposure.
H
• If you must conduct extended conversations by wireless phone every day, you
could place more distance between your body and the source of the RF, since
8
the exposure level drops off dramatically with distance. For example, you could
use a headset and carry the wireless phone away from your body or use a
wireless phone connected to a remote an-tenna.
Again, the scientific data do not demonstrate that wireless phones are harmful. But
if you are concerned about the RF exposure from these products, you can use
measures like those described above to reduce your RF exposure from wire-less
phone use.
10.What about children using wireless phones?
The scientific evidence does not show a danger to users of wireless phones,
including children and teenagers. If you want to take steps to lower exposure to
radiofrequency energy (RF), the measures described above would apply to children
and teenagers using wireless phones. Reducing the time of wire-less phone use
and increasing the distance between the user and the RF source will reduce RF
exposure. Some groups sponsored by other national governments have advised
that children be discouraged from using wireless phones at all. For example, the
government in the United King-dom distributed leaflets containing such a
recommendation in December 2000. They noted that no evidence exists that using a wireless phone causes brain tumors or other ill effects. Their
recommendation to limit wireless phone use by children was strictly precautionary;
it was not based on scientific evi-dence that any health hazard exists.
11.What about wireless phone interference with medical equipment?
Radiofrequency energy (RF) from wireless phones can inter-act with some
electronic devices. For this reason, FDA helped develop a detailed test method to
measure electromagnetic interference (EMI) of implanted cardiac pacemakers and
defibrillators from wireless telephones. This test method is now part of a standard
sponsored by the Association for the Ad-vancement of Medical instrumentation
(AAMI). The final draft, a joint effort by FDA, medical device manufacturers, and
many other groups, was completed in late 2000. This standard will allow
manufacturers to ensure that cardiac pacemakers and defibrillators are safe from
wireless phone EMI. FDA has tested hearing aids for interference from handheld
wireless phones and helped develop a voluntary standard sponsored by the
Institute of Electrical and Electronic Engi-neers (IEEE). This standard specifies test
methods and per-formance requirements for hearing aids and wireless phones so
that that no interference occurs when a person uses a “com-patible” phone and a
“compatible” hearing aid at the same time. This standard was approved by the
IEEE in 2000. FDA continues to monitor the use of wireless phones for pos-sible
interactions with other medical devices. Should harmful interference be found to
occur, FDA will conduct testing to assess the interference and work to resolve the
problem.
12.Where can I find additional information?
For additional information, please refer to the following re-sources:
• FDA web page on wireless phones (http://www.fda.gov/cdrh/ phones/index.html)
• Federal Communications Commission (FCC) RF Safety Pro-gram
(http://www.fcc.gov/oet/rfsafety)
• International Commission on Non-Ionizing Radiation Protec-tion
(http://www.icnirp.de)
• World Health Organization (WHO) International EMF Project
(http://www.who.int/emf)
• National Radiological Protection Board (UK) (http://www.nrpb.org.uk/)
C
H
8
127126
PROTECT YOUR WARRANTY 12 MONTH LIMITED WARRANTY
Read your Warranty carefully, with the special consideration to
paragraph seven of the Limited Warranty for your unit.
“Warranty does not apply to... or to any product or part
thereof which has suffered through alteration... mishandling
misuse, neglect or accident”.
Many companies are making look alike accessories and in some cases,
promoting that their product is equal to or better than the Audiovox
product. Be careful. Some of these products may not be compatible to
use with your Audiovox product and may damage the unit or cause it to
malfunction. If service is required on your unit and it is determined that
a non-Audiovox accessory has created the problem with your unit, the
Warranty will not apply. In addition, if the unit has already suffered
irreversible damage by reason of a non-compatible accessory, the
Warranty will be voided. To protect your Warranty, use only compatible
accessories which cannot damage or interfere with the functioning of
your Audiovox product.
AUDIOVOX COMMUNICATIONS CORP.
555 Wireless Blvd., Hauppauge, New York 11788, 800-229-1235
16808 Marquardt Avenue, Cerritos, California 90703, 562-802-5100
Audiovox Canada
5155 Spectrum Way, Unit #5, Mississauga, Ontario
Canada L4W 5A1, 800-465-9672
C
H
8
Audiovox Communications Corp. (the Company) warrants to the
original retail purchaser of this Audiovox handheld portable cellular
telephone, that should this product or any part thereof during normal
consumer usage and conditions, be proven defective in material or
workmanship that results in product failure within the first twelve (12)
months period from the date of purchase, such defect(s) will be
repaired or replaced (with new or rebuilt parts) at the Company’s
option, without charge for parts or labor directly related to the defect(s).
The antenna, key pad, display, rechargeable battery and battery
charger, if included, are similarly warranted for twelve (12) months from
date of purchase.
This Warranty extends only to consumers who purchase the product in
the United States or Canada and it is not transferable or assignable.
This Warranty does not apply to:
(a) Product subjected to abnormal use or conditions, accident,
mishandling, neglect, unauthorized alteration, misuse, improper
installation or repair or improper storage;
(b) Product whose mechanical serial number or electronic serial number
has been removed, altered or defaced.
(c) Damage from exposure to moisture, humidity, excessive
temperatures or extreme environmental conditions;
(d) Damage resulting from connection to, or use of any accessory or
other product not approved or authorized by the Company;
(e) Defects in appearance, cosmetic, decorative or structural items such
as framing and non-operative parts;
(f) Product damaged from external causes such as fire, flooding, dirt,
sand, weather conditions, battery leakage, blown fuse, theft or
improper usage of any electrical source.
The Company disclaims liability for removal or reinstallation of the
product, for geographic coverage, for inadequate signal reception by
the antenna or for communications range or operation of the cellular
system as a whole.
To obtain repairs or replacement within the terms of this Warranty, the
product should be delivered with proof of Warranty coverage (e.g.
dated bill of sale), the consumer’s return address, daytime phone
number and/or fax number and complete description of the problem,
transportation prepaid, to the Company at the address shown below or
to the place of purchase for repair or replacement processing.
C
H
8
128
129
12 MONTH LIMITED WARRANTY
In addition, for reference to an authorized Warranty station in your area,
you may telephone in the United States (800) 229-1235, and in Canada
(800) 465-9672 (in Ontario call 905-712-9299).
THE EXTENT OF THE COMPANY’S LIABILITY UNDER THIS
WARRANTY IS LIMITED TO THE REPAIR OR REPLACEMENT
PROVIDED ABOVE AND, IN NO EVENT, SHALL THE COMPANY’S
LAIBILITY EXCEED THE PURCHASE PRICE PAID BY PURCHASER
FOR THE PRODUCT.
ANY IMPLIED WARRANTIES, INCLUDING ANY IMPLIED WARRANTY
OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE,
SHALL BE LIMITED TO THE DURATION OF THIS WRITTEN
WARRANTY. ANY ACTION FOR BREACH OF ANY WARRANTY MUST
BE BROUGHT WITHIN A PERIOD OF 18 MONTHS FROM DATE OF
ORIGINAL PURCHASE. IN NO CASE SHALL THE COMPANY BE
LIABLE FOR AN SPECIAL CONSEQUENTIAL OR INCIDENTAL
DAMAGES FOR BREACH OF THIS OR ANY OTHER WARRANTY,
EXPRESS OR IMPLIED, WHATSOEVER. THE COMPANY SHALL NOT
BE LIABLE FOR THE DELAY IN RENDERING SERVICE UNDER THIS
WARRANTY OR LOSS OF USE DURING THE TIME THE PRODUCT IS
BEING REPAIRED OR REPLACED.
No person or representative is authorized to assume for the Company
any liability other than expressed herein in connection with the sale of
this product.
Some states or provinces do not allow limitations on how long an
implied warranty lasts or the exclusion or limitation of incidental or
consequential damage so the above limitation or exclusions may not
apply to you. This Warranty gives you specific legal rights, and you may
also have other rights which vary from state to state or province
to province.
IN USA : AUDIOVOX COMMUNICATIONS CORP.
555 Wireless Blvd.
Hauppauge, NY 11788
(800) 229-1235
IN CANADA : AUDIOVOX COMMUNICATIONS CANADA CO.
C
H
5155 Spectrum Way, Unit #5
Mississauga, Ontario L4W 5A1
(800) 465-9672
8
130
Model : CDM-8615MP
Loading...
