AT&T TL 7600 User Manual
User’s manual
TL7600
DECT 6.0
accessory cordless headset
Congratulations
on your purchase of this AT&T product. Before using this AT&T
product, please read Important safety information on
pages 35-38 of this manual. Please thoroughly read the user’s
manual for all the feature operations and troubleshooting
information necessary to install and operate your new AT&T
product. You can also visit our website at
www.telephones.att.com
In Canada, dial
Model number: TL7600 (Headset and headset charger)
Type: DECT 6.0 accessory cordless headset
Serial number:
Purchase date:
Place of purchase:
Both the model and serial numbers of your AT&T product can be
found on the bottom of the headset charger.
Save your sales receipt and original packaging in case it is necessary
to return your product for warranty service.
1 (866) 288-4268
or call
1 (800) 222-3111
.
.
© 2008-2012 Advanced American Telephones. All Rights Reserved. AT&T and
the AT&T logo are trademarks of AT&T Intellectual Property licensed to
Advanced American Telephones, San Antonio, TX 78219. Printed in China.
User’s manual
TL7600
DECT 6.0
accessory cordless headset
Parts checklist
Check to make sure the headset package includes the following
items. Save your sales receipt and original packaging in the
event warranty service is necessary.
User's manual
Headset charger
Cordless headset
Battery compartment cover Battery for headset
Charger power adapter Behind the neck band Over the head band
Over the ear hook
User’s manual
TL7600
DECT 6.0
accessory cordless headset
Table of contents
Getting started
Quick reference guide -
headset ............................................1
Headset lights .......................... 1
Headset alert tones ..............3
Quick reference guide -
headset charger .......................... 4
Installation preparation ...........5
Charger installation ...................6
Battery installation .................... 7
Battery charging ......................... 8
Registering the headset ..........9
To register a headset to
the DECT headset base .... 10
To register the headset
to an AT&T DECT cordless
telephone base .................... 11
Headset attachments ............ 12
Over the ear hook .............. 12
Over the head band ........... 15
Behind the neck band ...... 17
Operation
Headset operation .................. 19
Making a call ......................... 19
Answering a call on the
headset ..................................... 20
Ending a call on
the headset ............................ 20
Auto off .................................... 20
Temporary ring tone
silencing ................................... 21
Intercom calls and
transfers ................................... 21
Options while on calls .......... 22
Volume control ..................... 22
Call waiting ............................ 22
Switching a call between
handset and headset ......... 23
Multiple headset/
handset use ............................ 24
Mute ........................................... 24
Replacing a headset .............. 25
To deregister all
headsets from your
TL7610/TL7611/TL7612
headset base ......................... 25
To deregister all headsets
from an AT&T cordless
telephone base .................... 26
Appendix
Troubleshooting ....................... 27
Important safety
information ................................. 35
Especially about cordless
headsets .................................. 36
Precautions for users
of implanted cardiac
pacemakers ............................ 38
Pacemaker patients ........... 38
Maintenance............................... 39
FCC Part 68 and ACTA.......... 40
FCC Part 15 ................................ 43
Limited warranty ...................... 45
Technical specifications ....... 49
DECT 6.0 digital
technology .............................. 49
Operating range ................... 49
Extended range and
clarity ........................................ 49
Index
Index .............................................. 50
5
Getting started
Quick reference guide - headset
ON/OFF
Press to make, answer, or end a call.
Headset lights
ON/OFF light status
On Headset is charging in the headset charger.
Flash Flashes slowly when incorrect battery is installed.
•
Headset is trying to register to the headset base or
•
telephone base.
Headset is searching for the headset base.
•
•
Flashes three times, followed by a pause. This cycle
•
then repeats three more times and then shuts down to
indicate the battery level is very low.
Flashes twice every five seconds to indicate the
•
headset is not registered.
Flashes every 20 seconds to indicate the battery is low
•
and needs to be charged in the headset charger.
Flashes every three seconds to indicate the headset
•
is in use.
Flashes quickly when there is an incoming call.
•
1
Getting started
Quick reference guide - headset
VOLUME /+ –
Press the volume keys on the
side of the headset to adjust the
listening volume when on a call
(page 22).
MUTE/FLASH
Press to mute the microphone
during a call (page 24).
Press and hold to receive call
waiting during a call (page 22).
Press to mute the ring tone in
the earpiece when there is an
incoming call (page 21).
Battery compartment cover
Remove to install or replace the
battery (page 7).
EARPIECE
Microphone
2
Getting started
Quick reference guide - headset
Headset alert tones
Three quick beeps.
One short beep
every 20 seconds.
One short beep
every 15 seconds.
One long beep
repeated.
One short beep. The headset ON/OFF key is pressed to
A VOLUME /+ – key is pressed when
•
the volume is already at its highest or
lowest setting.
The headset is not registered and the
•
headset ON/OFF button is pressed.
The headset has gone out of range from
•
the headset base during a call.
Low battery warning.•
The call is muted.•
Call waiting alert tone.•
•
go on hook or off hook.
3
Getting started
Quick reference guide - headset charger
Charging cradle
Place the headset here for charging.
Power cord groove
Place the power cord here.
Power jack
Plug the small end
of the charger power
4
adapter here.
Getting started
Installation preparation
You must install and
charge the battery before
using the headset.
If you subscribe to high-speed Internet service (DSL - digital
subscriber line) through your telephone lines, you must install
a DSL filter between the telephone line cord and the telephone
wall jack. The filter prevents noise and caller ID problems caused
by DSL interference. Please contact your DSL service provider for
more information about DSL filters.
For customer service or product information, visit our website at
STOP!
See pages 6-8
for easy instructions.
www.telephones.att.com or call 1 (800) 222-3111.
In Canada, dial 1 (866) 288-4268.
Avoid placing the headset charger too close to:
Communication devices such as television sets, VCRs, or other
•
cordless telephones.
Excessive heat sources.
•
Noise sources such as a window with traffic outside, motors,
•
microwave ovens, refrigerators, or fluorescent lighting.
Excessive dust sources such as a workshop or garage.
•
Excessive moisture.
•
Extremely low temperature.
•
Mechanical vibration or shock such as on top of a washing
•
machine or work bench.
5
Getting started
Charger installation
Plug the charger power
Plug the small end of the
1.
charger power adapter into
the power jack at the bottom
of the headset charger. Place
the power cord in the power
cord slot.
IMPORTANT INFORMATION
Use only the power adapter supplied with this product. To
1.
order a replacement power adapter, visit our website at
www.telephones.att.com, or call 1 (800) 222-3111.
In Canada, dial 1 (866) 288-4268.
The power adapter is intended to be correctly oriented in a
2.
vertical or floor mount position. The prongs are not designed
to hold the plug in place if it is plugged into a ceiling,
under-the-table or cabinet outlet.
2.
adapter into a power
outlet not controlled by a
wall switch.
6
Getting started
Battery installation
Install the battery as shown below. For optimal performance,
charge the headset battery for at least six hours before use. When
fully charged, the headset battery provides approximately 10 hours
of talk time or 5 days of standby time. When the headset is not in
use, recharge by returning it to the headset base.
1
1. If the battery compartment covercompartment cover
is attached, press on both sides
of the battery compartment cover
and lift it up and off.
2. Insert the battery into the battery
compartment with the label THIS
2
SIDE UP facing up.
3
5
3. Push the battery plug into the
connector inside the compartment
according to the color-coded label
and place the wires neatly inside
the compartment.
4. Insert the tab on the bottom of
the battery compartment cover
into the battery compartment.
4
5. Press down gently on the battery
compartment cover until it snaps
into place.
NOTE: Remove the ear hook from the headset (see page 14) before
battery replacement.
7
Getting started
Battery charging
After installing the battery, charge the headset by placing it on
the headset charger as shown below. Before registration, the
headset ON/OFF light flashes twice every five seconds whether
the headset is charging or not. After registration, the headset
ON/OFF light is on when the headset is charging.
Push
ON/OFF light
Insert
1. Insert the headset into
the charging cradle.
2. Push the headset downward
until the ON/OFF light on the
headset turns on.
IMPORTANT INFORMATION
Use only the supplied rechargeable battery or replacement battery
(model BT191545). To obtain a replacement battery, visit our website at
www.telephones.att.com or call 1 (800) 222-3111.
In Canada, dial 1 (866) 288-4268.
8
Getting started
Registering the headset
You must register your new TL7600 headset with one of the
following models before use:
AT&T DECT cordless headset TL7610/TL7611/TL7612
•
(see page 10).
You can register a maximum of two headsets to each
headset base.
-OR-
A compatible AT&T DECT cordless telephone (see page 11).
•
You can register a maximum of two headsets to each
cordless telephone.
The telephone base recognizes and counts a headset the same
as a handset. Refer to your telephone user’s manual for the
maximum number of handsets that you can register to the
telephone base. If you have the maximum number of handsets
registered, you need to follow the deregistration information in
your telephone user’s manual.
Visit www.telephones.att.com/headsets for a list of
compatible telephones.
The first headset provided with your TL7610/TL7611/TL7612 has
a blue ON/OFF light. When you register a second headset, the
ON/OFF light of that headset turns orange to help you identify
the headsets.
You can only register the headset to one product at a time, so
the headset must not be already registered before registering to
a headset base or a cordless phone.
NOTE: See pages 25-26 for instructions on deregistration.
9
Getting started
Registering the headset
To register a headset to a TL7610/TL7611/TL7612 DECT
headset base
Make sure the battery is properly installed
1.
in the headset (see page 7). The ON/OFF
light flashes twice every five seconds to
indicate the headset is not registered.
Place the headset in the headset base or
2.
charger and allow it to charge for at least
five minutes before beginning registration.
Remove the headset from the headset
3.
base or charger.
On the headset base, press and hold
4.
the PAIR button until the MUTE light on
the headset base turns on (about four
seconds) and release the button.
Return the headset to the headset base
5.
for registration.
Registration may take about 30 seconds to complete. The MUTE
light on the headset base turns off. The headset ON/OFF light
turns blue on the first headset registered and orange on the
second headset registered.
To verify registration was successful, press the headset ON/OFF
button and check for a dial tone.
If the registration was not successful, the ON/OFF light on the
headset flashes twice every five seconds. To reset the headset,
remove the headset from the headset charger and try the
registration process again.
10
Getting started
Registering the headset
To register the headset to an AT&T DECT cordless telephone base
Make sure the battery is properly installed in the
1.
headset (see page 7). The ON/OFF light flashes
twice every five seconds to indicate the headset
is not registered.
Place the headset in the headset charger and
2.
allow it to charge for at least five minutes
before beginning registration. Remove the
headset from the charger and then place the
headset back into the charger.
On the telephone base of the cordless phone,
3.
press and hold the /HANDSET LOCATOR
button until the IN USE light turns on (about four
seconds) and release the button.
If your telephone base has no HANDSET
LOCATOR button:
Press and hold the HOLD button until the screen
displays Registering... Please wait, then release
the button.
-OR-
Press and hold the LOCATOR button until the screen
displays Registering handset..., then release the button.
The headset registers to the telephone base automatically; this
4.
may take about 30 seconds to complete. The headset ON/OFF
light turns blue on the first headset registered and orange on the
second headset registered. To verify registration was successful,
press the headset ON/OFF button and check for a dial tone.
NOTES:
If the registration fails, the ON/OFF light on the headset flashes twice every
•
five seconds. Reset the headset and try again. Remove the headset from
the headset base and press ON/OFF. Then place the headset back into the
headset base. Try the registration process again.
For users of Synapse , SynJ , MS2085 Console, or MS2015 Deskset, refer
•
to the user’s manual of your respective model for registration instructions.
Synapse and SynJ are trademarks of Advanced American Telephones.
11
Getting started
Headset attachments
Over the ear hook
To attach the ear hook to the headset:
Remove any headset attachment connected to the headset.
1.
Insert the earpiece into the ear hook, as shown in Figure 1.
2.
Press the ear hook onto the earpiece, as shown in Figure 2.
3.
Hook the headset onto the desired ear. Adjust the angle of
4.
the headset until the microphone is pointing towards your
mouth, as shown in Figure 3.
Figure 1
Figure 2
Figure 3
NOTE : Firmly grip the earpiece with one hand whenever adjusting the
headset microphone up or down, as shown in Figure 3.
12
Loading...
