AT&T MOTO Q Q 9H User Manual

Getting Started Guide

Moto Q 9h

MOTO

Contents

Welcome to AT&T 5

What’s in the Box? 5

Set Up Your MOTO Q 9h 6

Insert the SIM Card & Battery 6 Charge the Battery 7 Insert a Memory Card 8 Get to Know Your MOTO Q 9h 9

Use Your MOTO Q 9h 13

Learn to Navigate & Type 13 Connect to AT&T 15 Make Phone Calls 16 Set Up Voicemail 17

Internet 18

Browse the Web 18

Email & Messaging 19

Set Up Personal Email 19 Set Up Corporate Email 22 Send and Receive Email 25 Text & MMS Messages 26 Instant Messaging 28

MOTO Q 9h 3

Contents

Sync Your Phone With Your Computer 29

Sync Contacts, Calendar, Email, Music, & More 29

Photos & Videos 32

Take a P h oto & Sen d It 32 View Your Pictures 33 Record a Video Clip 33 Picture and Video Options 34 Play a Video Clip 34

Music 36

AT&T M usic™ 36

Tips & Tr icks 38 Troubleshooting 40

4 MOTO Q 9h

Welcome to AT&T

AT&T Staff Meeting

10:00 AM Meeting Room A Profile: Normal

12:00 PM

12/31/2008

Start Contacts

Getting Started Disc

(includes User’s Guide and

synchronization software)

Charger

BT90 Extra

Capacity Battery

and

cover

and

Cover

BT60 Standard

Battery

Micro-to-Mini USB

Adapter

Micro USB to 3.5mm

Headset Adapter

USB Data Cable

MOTO Q™ 9h

Welcome to AT&T

What’s in the Box?

Thank you for purchasing the MOTO Q™ 9h.

Take note of the components in the box, pictured on the right.

To get started, we recommend the following:

• Carefully follow the

step-by-step Instructions in this guide to set up your MOTO Q 9h phone.

• To learn more or if you

need help with your MotoQ 9h, review the user's guide on the Getting Started Disc

att.com/tutorials

or visit

MOTO Q 9h 5

Set Up Your MOTO Q 9h

Steps? 6

Takes? 2 minutes

Set Up Your MOTO Q 9h

Insert the SIM Card & Battery

Caution: Don’t bend or scratch

from static electricity, water, and dirt.

Your SIM card contains your phone number and information like your list of contacts.

1. 2. 3. 4.

5. 6. Your MOTO Q 9h comes with two

6 MOTO Q 9h

Subscriber Identity Module

(SIM) card. Keep it away

batteries and two battery covers. The BT60 standard battery uses the narrow cover, while the BT90 extra capacity battery requires the larger cover.

Set Up Your MOTO Q 9h

Steps? 1

Takes? 1 minute (to start) Full charge time varies.

Charge the Battery

New batteries are not fully charged.

Plug the battery charger into your phone and an electrical outlet. It might take several seconds for charging to start.

During charging, you should see a light around the navigation key. When charging is complete, your display shows a full

battery icon

MOTO Q 9h 7

. You can’t overcharge your battery.

empty

charging

full

Set Up Your MOTO Q 9h

Steps? 3

Takes? 2 minutes

Insert a Memory Card

You can use a removable microSD memory card to store music, pictures, videos, and other files. To see the files, press Start > Applications > File Manager. For the maximum card size your phone supports, check

1. Open the memory slot cover by gently lifting the cover away

att.com/support/

from the phone as shown. The cover remains attached to the phone.

2. Insert the memory card into its slot, with the card’s metal contacts facing the front of the phone.

3. Put the memory slot cover back in place and push it to close it. The cover clicks into place.

Caution: Do not remove your memory card while your phone is using it. Don’t bend or scratch your memory card. Keep it away from static electricity, water, and dirt.

8 MOTO Q 9h

Set Up Your MOTO Q 9h

Get to Know Your MOTO Q 9h

Turn On Your Phone

To turn on your phone, press and releaseO. If

prompted, enter your password or SIM unlock code.

To turn off your phone, press and hold 3seconds, then release it.

Note: In the event your phone freezes up and does not

respond for more than 30 seconds, be sure that the battery if fully charged. If it is, remove and replace the battery, then turn the phone back on. If these do not help, you can do a hard reset to restart your phone, but this erases your personalized settings and any content stored in phone memory. To perform a hard reset, remove and replace the battery, then hold down the

and E keys for 5 seconds while turning the phone on.

MOTO Q 9h 9

for

Tip: To ch a n ge how long your backlight stays

“extend

on, see

battery life” on page 39

Set Up Your MOTO Q 9h

Network

Battery

Level

Profile

Signal

Strength

Call

Forward

Message /

Bluetooth

Voicemail

Missed

Call

Meet Your Icons

Status indicators can appear at the top of the home screen:

1. ShowsE when you missed a call.

2. Showsw when you have new voicemail.

3. ShowsC for a new message, or

E when Bluetooth power is

on.

4. ShowsD when call forwarding is on.

5. Shows whether your are using a 3G

6. Shows when your ring style is Silent ( for other ring styles.

Note: A % appears when the speakerphone is on.

7. Shows the battery charge level.

8. Shows the strength of your network connection.

10 MOTO Q 9h

, GPRSf, or EDGE\ network.

) or Vibrate (

). No indicator appears

Set Up Your MOTO Q 9h

Volume Up

Volume Down

Back Key

Side Select

Lock Your Phone Keypad

You can manually lock your phone to prevent accidental key presses

then

To lock your phone, press To unlock your keypad, press Unlock and enter your password. Your phone uses *

if you have not set a password.

To change your password and lock settings, press the Left Soft key to select Start > System Tools > Settings > More > Security > Device Lock. Choose a password you will remember. If you forget your password, you will have to perform a hard reset (see the note in the section “Turn On Your Phone”).

. Your left soft key becomes Unlock.

Change Your Ringer and Earpiece Volume

To change the other caller’s voice volume,

press volume up/down during a phone call.

Note: Bluetooth® accessories, such as headsets,

have their own volume controls.

MOTO Q 9h 11

Tip: You c an make emergency calls (such as 911 in the United States) on a locked phone. A locked phone still lets you answer incoming calls. Tip: To sil ence your phone when it’s ringing, just press the

volume keys

side

Set Up Your MOTO Q 9h

To change your ringer and sound profile

from the home screen, press and hold

open the Quick List. Then scroll to a profile, such as Normal, Silent, or Vibrate, and press the

center key

To change the sound for alerts or other events, press Start > MyStuff > Personalize My Q

> Sounds and Ringtones. Highlight the event and select the sound you want to associate with it.

12 MOTO Q 9h

Quick List

1 Power off

2 Wireless Manager 3 Lock 4 Normal 5 Silent 6 Vibrate 7 More...

Select Cancel

Use Your MOTO Q 9h

Start

Left Soft Key

Select the action in the bottom left

of the screen (like Start or Done).

Right Soft Key

Select the action in the bottom right of the screen (like Contacts or Menu).

Center Key

Select a highlighted item on the screen.

Navigation Key

Move up, down, left, or right on the

screen.

Back Key

Go back to the

previous screen.

Use Your MOTO Q 9h

Learn to Navigate & Type

Home Screen

AT&T

12:00 PM

12/31/2008

Staff Meeting 10:00 AM Meeting Room A

Profile: Normal

Start Contacts

Press Start (the left soft key) to open the main menu.

Press the Navigation Key up, down, left, or right (S) to

highlight a menu feature.

Tip: If you need help while using your phone,

att.com/

visit

tutorials

Menu Screen

Start

Messaging Contacts Calendar ActiveSync

ATT Music Cellular Video MEdia Net

ATT Mall

Press the Center Key s to select the highlighted

feature.

Tip: Press the Back Key n to go back one menu. Press the Power Key O to exit any menu or view without saving any changes.

MOTO Q 9h 13
