AT&T E5934B User Manual
User's Manual
5.8 GHz Cordless
Telephone/Answering
System E5933B/E5934B
with Caller ID/Call Waiting
Congratulations on your purchase
of this AT&T product.
Before using this telephone system, please
read Important safety instructions
on pages 49 to 51 of this manual.
NEED HELP?
Our representatives are here
to help you with any questions concerning the
operation of this product, available accessories,
or any other related issues.
Call toll free
1 (800) 222-3111
In Canada, call
1 (866) 288-4268
or visit our web site at
www.telephones.att.com
Model #: E5933B/E5934B
Product name: 5.8GHz Cordless Telephone/Answering System
Serial #:
(found on the bottom of the telephone base)
Purchase date:
Place of purchase:
IMPORTANT
Information about caller ID with call waiting
This product has a caller ID with call waiting feature that works with
service from your local phone service provider.
Caller ID with call waiting lets you see who is calling before you answer
the phone, even when you’re on another call.
You may need to change your phone service to use this
feature. Contact your telephone service provider if:
• You have both caller ID and call waiting, but as separate services (you
may need combined service).
• You have only caller ID service, or only call waiting service.
• You don’t subscribe to any caller ID or call waiting services.
You can use this product with regular caller ID service, and you can use
this product’s other features without subscribing to either caller ID or
combined caller ID with call waiting service.
There are fees for caller ID services, and they may not be available in all
areas.
Depending on your service, you may see the caller’s number, or the caller’s name and
number. This product can provide information only if both you and the caller are in areas
offering caller ID service, and if both telephone companies use compatible equipment.
The time and date are sent by the service provider along with the call information.
Copyright © 2006 Advanced American Telephones. All rights reserved.
AT&T and the Globe Design are trademarks of AT&T Corp.,
licensed to Advanced American Telephones.
You must install and
charge the battery before
using the telephone.
For customer service or product
information, visit our web site at
STOP!
See page 8
for easy instructions.
www.telephones.att.com
or call 1-800-222-3111.
In Canada, call 1-866-288-4268.
Add new handsets to make your phone more versatile (see page 41)
Your telephone can accommodate up to four cordless handsets. You can add new
handsets (Model E597-2, sold separately) at any time, but each must be registered
with the base before use.
The E5933B has three handsets automatically registered as handsets 1, 2 and 3.
You can register one additional handset, which will then be assigned number 4.
The E5934B has four pre-registered handsets. You cannot register any additional
handsets.
Handset 1 Handset 2 Handset 3 Handset 4
NOTE: At a time, a maximum of two handsets can be used on an outside call, and the other two handsets
can be used on an intercom call.
User's Manual
5.8 GHz Cordless
Telephone/Answering
System E5933B/E5934B
with Caller ID/Call Waiting
Table of contents
Getting started
Quick reference guide ......................... 2
Parts checklist ........................................ 4
Before you begin ................................... 6
Telephone base installation ................. 7
Battery installation & charging ........... 8
Wall mounting ....................................... 9
Belt clip & optional headset ...................10
Telephone operation
Basic operation ....................................11
Options while on calls .......................13
Intercom calls .......................................15
Call forward .........................................16
Call transfer..........................................17
Handset settings ..................................18
Directory
Directory ..............................................20
New directory entries ....................... 21
Directory search .................................23
To dial, delete or change entries......24
Caller ID operation
Caller ID log .........................................25
To review the call log, return a call .....27
Answering system operation
Answering system operation ............ 28
Day and time announcements ..........29
Outgoing announcements .................30
Announcement only mode ...............31
Changing feature options .................. 32
Message playback ................................33
Recording and playing memos..........34
Message counter displays ..................35
Remote access .....................................36
Appendix
Screen icons, indicator
lights & tones ...........................................38
Handset display screen messages ......39
Adding new handsets ............................41
Replacing a handset ................................42
Troubleshooting ..................................43
Important safety instructions ...........49
FCC Part 68 and ACTA ..................... 52
FCC Part 15 .........................................53
Limited warranty .................................54
Technical specifications ......................57
Index ......................................................58
Remote access wallet card ...............59
1
Getting started
Quick reference guide
Cordless handset
V CID
Press to scroll down while in menus.
Press to display caller ID information
(see page 27). While entering names
or numbers, press to move the cursor
to the left.
PHONE/FLASH
Press to make or answer a call.
During a call, press to receive an
incoming call if call waiting is activated
(see page 13).
MUTE/DELETE
While on a call, press to mute microphone
(see page 14).
While reviewing the call log, press to delete
an individual entry, or press and hold to
clear the caller ID log (see page 27).
While pre-dialing, press to delete digits
from a string (see page 11).
SPEAKER
Press to activate handset speakerphone.
Press again to resume normal handset
use (see page 11).
SELECT/MENU
Press to display menu, or to select
highlighted item from menu or save
an entry.
^ DIR
Press to scroll up while in menus.
Press to display directory entries (see
page 23). While entering names, press
to move the cursor to the right.
OFF/CLEAR
During a call, press to hang up.
While using menus, press to cancel
an operation, back up to the previous
menu, or exit the menu display.
REDIAL/PAUSE
Press to view redial memory (see page
11). While entering numbers, press
and hold to insert a dialing pause (see
page 21).
INTERCOM
Press to initiate an intercom conversation, transfer or forward a call (see
pages 15-17).
Feature menu
> shows highlighted item
>DIRECTORY
CALL LOG
Menu
Feature menu
DIRECTORY ...........See page 21
CALL LOG .............. See page 25
RINGER VOLUME .See page 18
RINGER TONE .......See page 18
KEY TONE ..............See page 18
LANGUAGE ............ See page 19
CLR VOICE MAIL ...See page 19
DIAL TYPE .............See page 19
2
2
Press V or ^ to scroll
through menu items.
Press SELECT to select or
modify a highlighted item.
Press OFF/CLEAR to cancel
an operation, back up to the
previous menu, or exit the menu
display.
Getting started
Quick reference guide
Telephone base
HANDSET LOCATOR
Press to make handset(s) beep (see page 12).
CHARGE
On when the cordless handset is
properly positioned to charge in
the telephone base.
VOLUME
Press to adjust message playback volume.
IN USE
On when handset is in use or you are registering a handset. Flashes when another phone is in use on the same
line, or the answering system is answering an incoming
call, or you are de-registering a handset from the base.
Answering system controls (see pages 28-37)
Press to play or stop playing messages.
Press to repeat message.
Hold to slow playback.
Press twice to hear
previous message.
ANSWER ON/OFF .... Press to turn answering system on or off.
DELETE .................... Press to delete a message during play back. Hold to
TIME/SET .................. Press to review or set the answering system clock.
SETUP ....................... Press to review or change answering system options.
CHANGE ................... Press to change a menu option.
REC/MEMO ............... Press to record a memo, or after pressing SETUP, to
delete all old messages when set is idle.
record an outgoing announcement.
3
3
Press to skip to next
message. Hold to
speed up playback.
Getting started
Parts checklist for E5933B
Save your sales receipt and original packaging in case you need to ship your telephone
for warranty service.
Check to make sure the telephone package includes the following:
Telephone base
Belt clips for cordless
handsets
Chargers for cordless
handsets
Cordless handsets
Power adapter for
telephone base
Battery packs for cordless
handsets
Wall mount bracket
for telephone base
Power adapters for
handset chargers
Telephone line cord
4
Getting started
Parts checklist for E5934B
Save your sales receipt and original packaging in case you need to ship your telephone
for warranty service.
Check to make sure the telephone package includes the following:
Telephone base
Belt clips for cordless
Chargers for cordless
handsets
handsets
Cordless handsets
Power adapter for
telephone base
Battery packs for cordless
handsets
Wall mount bracket
for telephone base
Power adapters for
handset chargers
Telephone line cord
5
Getting started
Before you begin
About caller identification
Caller ID with call waiting features in
this telephone let you see who’s calling before you answer the phone, even
when you’re on another call. These
features require services provided by
your local telephone company.
Contact your telephone service provider if:
• You have both caller ID and call
waiting, but as separate services
(you may need combined service).
• You have only caller ID service, or
only call waiting service.
• You don’t subscribe to any caller ID
or call waiting services.
You can use this telephone with regular caller ID service, and you can use
its other features without subscribing
to either caller ID or combined caller
ID with call waiting service. There may
be fees for these services, and they
may not be available in all areas.
Caller ID features will work only if
both you and the caller are in areas
offering caller ID service, and if both
telephone companies use compatible
equipment.
See caller ID operation, beginning
on page 25, for more details about
how these features work.
Telephone operating range
This cordless telephone operates with
the maximum power allowed by the
Federal Communications Commission
(FCC). Even so, the handset(s) and
base can communicate over only a
certain distance — which can vary
with the locations of the base and
handset(s), the weather, and the construction of your home or office.
If you receive a call while you are
out of range, the handset might not
ring — or if it does ring, the call might
not connect when you press PHONE.
Move closer to the base, then press
PHONE to answer the call.
If you move out of range during a
telephone conversation, you might
hear noise or interference. To improve
reception, move closer to the base.
If you move out of range without
pressing OFF, your telephone will be
left off the hook. To hang up properly,
walk back toward the telephone base,
periodically pressing OFF until the call
is disconnected.
6
6
Getting started
Telephone base installation
Install the telephone base as shown below. Choose a location in a central location
within the home and:
• Away from any other cordless (wireless) device such as cordless telephones, 802.11
wireless router (for example, WiFi).
• Away from other electronic equipment, microwave oven, television, computer, etc.
Avoid excessive heat, cold, dust or moisture.
• If you need to install your phone within the same room as other cordless phones or
wireless products, you may need to select a different channel for your router and or
other cordless phones.
Plug telephone
line cord into
telephone jack.
NOTE: Use only the power cord supplied with this product. If you need a replacement, call 1 (800) 222-3111. In
Canada, call 1 (866) 288-4268. Be sure to use an electrical outlet not controlled by a wall switch.
7
7
Plug the large power
adapter into an electrical
outlet not controlled by a
wall switch.
Getting started
Battery installation & charging
After battery installation, place each handset in the telephone base or a charger and allow
to charge for 16 hours before use. You can keep the battery packs charged by returning
the handsets to the telephone base or chargers after each use. When the battery is fully
depleted, a recharge takes about 12 hours. The average talk time on a fully charged battery
is about eight hours depending on environmental conditions, standby time is approximately
four days.
Press in and downward on
the tab to open the battery
compartment cover.
Plug power adapter into the jack
on the underside of charger as
shown, then plug into electrical
outlet.
Caution: Use only supplied rechargeable battery or replacement battery pack (part number 80-5848-00-00).
NOTE: Use only the power cord supplied with this product. If you need a replacement, call 1 (800) 222-3111. In
Canada, call 1 (866) 288-4268. Be sure to use an electrical outlet not controlled by a wall switch.
Plug the battery
pack connector
into handset.
Place the battery
pack and wires in
the compartment.
Place handset in base or
charger to charge for 16
hours before first use.
8
8
Slide battery compartment
cover up until it clicks closed.
LOW BATTERY
Low battery indicator
Return handset to base
or charger to recharge
when this symbol flashes.
(Handset will beep when
battery is low.)
Getting started
Wall mounting
The base can be installed on any standard wall phone outlet as shown below. Choose a
location away from electronic equipment, such as personal computers, computer routers, television sets or microwave ovens. Avoid excessive heat, cold, dust or moisture.
1) Connect telephone line cord and
power adapter to telephone jacks and
wall jacks, respectively, as shown on
page 7.
2) Install wall mount bracket onto set.
First put the two front wall mount
bracket tabs into the front notches
on bottom of telephone base, then
squeeze the rear tabs of the wall
mount bracket as you insert them into
the rear notches on the bottom of the
telephone base.
Plug power adapter into an electrical
outlet not controlled by a wall switch.
3) Position the wall mount bracket over the wall outlet mounting pegs, and press and slide
the wall mount bracket down
firmly so it is held securely on
the outlet mounting pegs.
Plug telephone line
cord into the telephone jack.
9
9
Getting started
Belt clip & optional headset
Install belt clip as shown below if desired.
For hands-free telephone conversations, you can use any industry standard 2.5 mm
headset (purchased separately). For best results use an AT&T 2.5 mm headset.
Snap belt clip into notches on
side of handset. Rotate and pull
to remove.
Plug 2.5 mm headset
into jack on side of
handset (beneath
small rubber cap).
10
10
Telephone operation
PHONE 00:00:12
SPEAKER 00:00:12
REDIAL
555-1234
Elapsed time
Basic operation
Making and answering calls
To answer an incoming call, press PHONE or SPEAKER,
or any dial-pad key (0-9, * or #). To make a call, press
PHONE or SPEAKER, then dial a number. Press OFF to
hang up.
To preview numbers before dialing, enter numbers first,
then press PHONE or SPEAKER to dial. Press DELETE
or OFF at any time to make corrections as you are
entering numbers.
The screen displays the elapsed time as you talk (in
hours, minutes and seconds).
Hands-free speakerphone calls
To answer a call, press SPEAKER. To make a call, press
SPEAKER, then dial a number. During a call you can press
SPEAKER to toggle between hands-free speakerphone
and normal handset use. Press OFF to hang up.
Last number redial
Before pressing PHONE, press REDIAL to display the
most recently called numbers (up to 32 digits). Use the
V^ buttons or REDIAL repeatedly to view up to five
recently called numbers. The handset will beep at the
beginning or end of the list.
Press PHONE or SPEAKER to redial any displayed
number or press PHONE then REDIAL to call the most
recently called number (up to 32 digits).
Press DELETE to delete the number from the redial
memory.
11
11
Telephone operation
Basic operation
Handset locator
If you misplace the handset(s), press HANDSET LOCATOR
at the base. This starts the paging tone at the handset(s)
for 60 seconds to help you locate it. To stop the paging
tone, press PHONE, SPEAKER, or any dial-pad key (0-9,
*,or #) on the misplaced handset(s) (the handset(s) not
on the cradle), or press HANDSET LOCATOR at the base.
NOTES:
1. The handset ringer volume also determines the level of the paging tone.
If the handset ringer volume level is set to off (0), that handset will be
silenced for all calls and paging (see page 18).
2. During a page, if you press OFF on a handset the ringer of that handset will be silenced, but the page will not be cancelled.
12
12
Flash
Volume
Telephone operation
Options while on calls
Volume control
Press V or ^ on the VOLUME button on the side
of the handset to adjust listening volume. Each button
press raises or lowers volume by one level.
When you change the volume level, the new setting is
saved.
Call waiting
If you subscribe to call waiting service with your local
telephone service provider, you will hear a beep if
someone calls while you are already on a call. Press
FLASH to put your current call on hold and take the
new call. You can press FLASH at any time to switch
back and forth between calls.
Three-way conference calls
While a call is in progress, a person at another handset
can press PHONE or SPEAKER to join the call.
A person at either handset can press OFF, or place the
handset in the base or charger, to drop out of the conference call, but the call will not be terminated until all
handsets hang up.
Only two handsets are allowed to connect to an outside call.
13
13
Tone
Mute
Telephone operation
Options while on calls
Mute
Press MUTE to silence the microphone. You will be
able to hear the person at the other end, but they will
not be able to hear you until you press MUTE again and
resume speaking.
Ring
Silence
Temporary ring silencing
Press OFF or MUTE while the phone is ringing to silence
the ringer temporarily.
The next phone call will ring normally.
Temporary tone dialing
If you have dial pulse (rotary) service, you can switch
to touch tone dialing during a call by pressing *. This
can be useful if you need to send tone signals for access
to answering systems or long-distance services.
After you hang up or press FLASH (to receive a call
waiting call), the phone automatically returns to dial
pulse (rotary) service.
14
14
Telephone operation
Intercom calls
Intercom calls
If you have more than one handset, you can use the
intercom feature to have conversations between the
handsets.
• Press the INTERCOM button on a handset.
• You will see INTERCOM TO:
• Enter the handset number of the handset you want
to call. The display will show CALLING HANDSET
X.
• The called handset will ring and the display will show
HANDSET X IS CALLING.
• Press INTERCOM, PHONE, SPEAKER or any dial-pad
key (0-9, *, or #) on the handset being called to
answer the call.
To end the intercom call:
• Press OFF or INTERCOM at the handset.
— OR —
• Place the handset in the charger or base.
NOTE: The intercom feature cannot be used while a handset is in the
directory or call log. Pressing INTERCOM while on an outside call
will initiate Call Transfer (see page 17).
Handling incoming calls
The phone will beep if you receive an outside call during
an intercom conversation. You can either:
• Press PHONE to end the intercom call and answer the
incoming call.
— OR —
• Press INTERCOM or OFF to disconnect the intercom
connection without answering the incoming call. The
incoming call will continue to ring.
15
15
FORWARD TO:
Telephone operation
Call forward
Call forward
If you have more than one handset, during a conversation, you can forward an external call from one handset
to another handset.
• Press and hold INTERCOM. You will see FORWARD
TO:
• Enter the handset number (1, 2, 3, or 4) to which you
want to forward the call. The display will show CALL
FORWARDED.
• The destination set will ring and the display will show
INCOMING CALL.
• Press PHONE, SPEAKER or any dial-pad key (0-9, * or
#) on the destination handset to answer the call.
NOTE: If the forwarded call is not answered within 30 seconds, the
external call will be returned to the handset that originated the forward,
and its display will show CALL BACK. If the returned call is not answered within an additional 30 seconds, the external call will end automatically.
16
16
Loading...
