User’s Manual

5.8 GHz Corded/Cordless Telephone/Answering System E5908

with Caller ID & Call Waiting

Congratulations on your purchase

of this AT&T product.

Before using this telephone system, please read

Important safety instructions

on pages 52 to 54 of this manual.

NEED HELP?

Our representatives are here

to help you with any questions concerning the

operation of this product, available accessories,

or any other related issues.

Call toll free

1 (800) 222-3111

In Canada, call

1 (866) 288-4268

or visit our website at

www.telephones.att.com

Model No: E5908

Product Name: 5.8GHz Corded/Cordless Telephone/Answering System

Serial No:

(found on the bottom of the telephone base)

Purchase Date:

Place of Purchase:

IMPORTANT

Information about Caller ID with Call Waiting

This product has a Caller ID with Call Waiting feature that works with services from your local phone service provider.

Caller ID with Call Waiting lets you see who is calling before you answer the phone, even when you’re on another call.

You may need to change your phone service to use this feature. Contact your phone service provider if:

• You have both Caller ID and Call Waiting, but as separate services (you may need combined service).

• You have only Caller ID service, or only Call Waiting service.

• You don’t subscribe to any Caller ID or Call Waiting services.

You can use this product with regular Caller ID service, and you can use this product’s other features without subscribing to either Caller ID or combined Caller ID with Call Waiting service.

There are fees for Caller ID services, and these services may not be available in all areas.

Depending on your service, you may see the caller’s number, or the caller’s name and number. This product can provide information only if both you and the caller are in areas offering Caller ID service, and if both telephone companies use compatible equipment. The time and date are sent by the service provider along with the call information.

AT&T and the Globe Design are trademarks of AT&T Corp.,

licensed to Advanced American Telephones.

You must install and charge the battery before using the telephone.

For customer service or product information, visit our website at

STOP!

See page 7

for easy instructions.

www.telephones.att.com

or call 1 (800) 222-3111. In Canada, call 1 (866) 288-4268.

CAUTION: To reduce the risk of fire or injury to persons or damage to the telephone, read and follow these instructions carefully:

• Use only Replacement Battery 3301 (SKU 91076. Part Number 80-5071-00-00).

• Do not dispose of the battery in a fire. Like other batteries of this type, it could explode if burned. Check with local codes for special disposal instructions.

• Do not open or mutilate the battery. Released electrolyte is corrosive and may cause damage to the eyes or skin. It may be toxic if swallowed.

• Exercise care in handling batteries in order not to create a short circuit. Do not allow conductive materials such as rings, bracelets, or keys to touch the battery. The battery or conductor may overheat and cause harm.

• Charge the battery provided with or identified for use with this product only in accordance with the instructions and limitations specified in this manual.

• Observe proper polarity orientation between the battery and battery charger.

Do not disassemble your telephone. There are no user-serviceable parts inside. Refer to qualified service personnel for servicing.

User’s Manual

5.8 GHz Corded/Cordless

Telephone/Answering System E5908

With Caller ID & Call Waiting

Table of contents

Getting Started

Quick reference guide ........................2

Parts checklist ......................................4

Before you begin .................................. 5

Telephone base installation ................ 6

Battery installation & charging ..........7

Wall mounting ......................................8

Belt clip & optional headset ....................9

Telephone Operation

Handset settings.................................10

Base settings .......................................13

Basic cordless handset operation ..15

Basic base operation .........................16

Options while on calls ......................17

Intercom calls .....................................19

Directories

Directories ..........................................22

Speed dialing .......................................23

Entering names into directories .....25

Directory search ................................27

To copy, edit or delete an entry .....28

Caller ID Operation

Caller ID operation ........................... 29

CID memory ......................................31

Call waiting .............................................. 35

Answering System Operation

Answering system operation ..........36

Day and time announcements ........37

Outgoing announcements ................38

Changing feature options ................. 39

Message playback ...............................40

Recording and playing memos ........41

Message counter displays .................42

Remote access ...................................43

Appendix

Display screen messages, lights and

tones ......................................................... 44

Troubleshooting ................................. 46

Important safety instructions .......... 52

FCC part 68 and ACTA ....................55

FCC part 15 ........................................56

Limited warranty ...............................57

Index ..................................................... 60

Technical specifications .....................61

Remote access wallet card .................62

Getting Started

Quick reference guide

Cordless Handset

SELECT

Press to store a programming option (see pages 10-12), or to store a directory entry in memory (see page 22).

V (volume down)

CID

When phone is idle, press CIDV to display Caller ID information (see page 29).

While entering names or phone numbers, press to delete last character entered. While programming, press to change menu item or value (see pages 10-12).

During a call, press CIDV to adjust listening volume.

^DIR (volume up)

When phone is idle, press ^DIR to display Directory entries (see page 27).

While entering letters in names, press to advance or press twice to enter space.

While programming, press to change menu item or value (see pages 10-12).

During a call, press ^DIR to adjust listening volume.

OFF/CLEAR

During a call, press to hang up.

While using menus, press to cancel an operation, back up to the previous menu, or exit the menu display.

INT/DELETE

PHONE/FLASH

Press to make or answer a call (see page 15).

During a call, press to receive an incoming call if Call Waiting is activated (see page 17).

HOLD

Press to place a call on hold. Press again to resume your call (see page 17).

MENU/CHAN

Press to customize the handset’s operation (see pages 10-12).

During a call, press to switch to another channel if there is interference.

While phone is idle, press to page base (see page 19) or press and hold to delete all Caller ID entries (see page

34).

While a Caller ID entry is displayed, press to delete displayed entry (see page 33).

REDIAL/PAUSE

Before dialing, press to display last number called (see page 15).

While dialing or entering numbers into your directory, press to insert a four-second dialing pause (see page 26).

Getting Started

Quick reference guide

Telephone Base

RINGER VOLUME: Set switch on side of base (Off, Low, High). (see page 14)

• CLOCK: Press to review or set clock

• SETUP: Press repeatedly to hear setup

• INTERCOM/CID DEL:

Press to delete displayed Caller ID entry (see page 33). While phone is idle, press to page handset (see page 16), or press and hold to delete all Caller ID entries (see page 34).

• MENU: Press to customize the

telephone’s operation (see page

13).

• FLASH: During a call, press to

receive an incoming call if Call Waiting is activated (see page

17).

• REDIAL/PAUSE: Before

dialing any numbers, press to display last number called (see page 16).

While dialing or entering num-

bers into your directory, press to insert a 4-second dialing pause (see page 26).

• ANNC: Press to review or record

• RECORD: Press to record a memo

•

• DELETE: Press to delete message

• ANSWER ON: Press to turn answer-

• REPEAT : Press to repeat message;

• SKIP: Press to skip message (see

CONTRAST: Press to adjust screen contrast.

(see page 37).

options (see page 39).

announcement; press again to quit (see page 38).

(see page 41) or after pressing ANNC to record an outgoing announcement (see page 38).

PLAY/STOP: Press to start or stop

message playback (see page 40).

currently playing; hold to delete all old messages (see page 40).

ing system on or off.

press twice to play previous message (see page 40).

page 40).

INDICATOR LIGHTS:

See page 45.

• CLEAR: While using

menus, press to cancel an operation, back up to the previous menu, or exit the menu display.

• CIDV: Press when

phone is idle to display Caller ID information (see page 31). While entering numbers or letters, press to delete last character entered.

• SELECT: Press to store

a programming option (see page 13), or to store a directory entry in memory (see page 22).

• ^DIR: Press when

phone is idle to display directory entries (see page

27). While entering or modifying names, press to advance cursor.

• DISP DIAL: Press to

dial number currently displayed.

• HOLD: Press to place

call on hold. Press again to resume call (see page

17).

• VOLUME : During a

call, press ^ or V to adjust listening volume (see page 17).

• MUTE: Press to silence

microphone; press again to resume your conversation (see page 17).

• SPEAKER: Press

to turn speaker on or off (begin or end a call).

Getting Started

Parts checklist

Save your sales receipt and original packaging in case you need to ship your telephone for warranty service.

Base handset Telephone base

Cordless

handset

Battery compartment

Handset cord

cover

Belt clip

Battery pack for

cordless handset

Telephone line cords (1 long, 1 short)

Charger for cordless

handset

Base power adapter

Charger power

adapter

Getting Started

Before you begin

About Caller Identification

Caller ID with Call Waiting features in this telephone let you see who’s calling before you answer the phone, even when you’re on another call. These features require services provided by your local telephone company.

Contact your telephone service provider if:

• You have both Caller ID and Call Waiting, but as separate services (you may need combined service).

• You have only Caller ID service, or only Call Waiting service.

• You don’t subscribe to any Caller ID or Call Waiting services.

You can use this phone with regular Caller ID service, and you can use its other features without subscribing to either Caller ID or combined Caller ID with Call Waiting service. There may be fees for these services, and they may not be available in all areas.

Caller ID features will work only if both you and the caller are in areas offering Caller ID service, and if both telephone companies use compatible equipment.

Telephone operating range

This cordless telephone operates with the maximum power allowed by the Federal Communications Commission (FCC). Even so, the handset and base can communicate over only a certain distance — which can vary with the locations of the base and handset, the weather, and the construction of your home or office.

If you receive a call while you are out of range, the cordless handset

might not ring — or if it does ring, the call might not connect when you press

PHONE/FLASH. Move closer to the

telephone base, then press PHONE/

FLASH to answer the call.

If you move out of range during a telephone conversation, you might

hear noise or interference. To improve reception, move closer to the base.

If you move out of range without pressing OFF/CLEAR, your telephone

will be left off the hook. To hang up properly, walk back toward the telephone base, periodically pressing

OFF/CLEAR until the call is discon-

nected.

See Caller ID Operation, beginning on page 29, for more details about how these features work.

Getting Started

Telephone base installation

Install the telephone base as shown below. Choose a location within the home:

• Away from any other cordless (wireless) device such as cordless telephones, 802.11 wireless router (for example, WiFi).

• Away from other electronic equipment, microwave oven, television, computer, etc. Avoid excessive heat, cold, dust, and moisture.

• If you need to install your phone within the same room as other cordless phones or wireless products, you may need to select a different channel for your router and or change the channel on your phone’s cordless handsets (see page 18).

Plug the large power adapter into an electrical outlet not controlled by a wall switch.

Plug the long telephone line cord into telephone jack.

Plug handset cord into handset and jack at the bottom of the telephone base.

NOTE: Use only the power adapter supplied with this product. If you need a replacement, call 1 (800) 222-3111.

In Canada, call 1 (866) 288-4268.

NOTE: Be sure to use an electrical outlet not controlled by a wall switch.

Getting Started

Battery installation & charging

After battery installation, place the cordless handset in the charger and allow to charge for at least 16 hours before use. You can keep the battery charged by returning the cordless handset to the charger after each use. When the battery is fully depleted, a recharge takes about 12 hours. The average talk time on a fully charged battery is about five hours depending on environmental conditions, and the standby time is approximately five days.

Press in and downward on the tab to open the battery compartment cover.

Plug the battery pack connector into handset.

Place the battery pack and wires in the compartment.

Slide battery compartment cover up until it clicks closed.

LOW BATTERY

0 8/12 10:06

then

NEEDS RECHARGING

0 8/12 10:06

Plug power adapter into jack on underside of charger as shown, then plug into an electrical outlet not controlled by a wall switch.

Caution: Use only the supplied rechargeable battery pack or AT&T replacement battery model 3301 (SKU 91076. Part number 80-5071-00-00).

NOTE: If you need a battery pack replacement, call 1 (800) 222-3111. In Canada, call 1 (866) 288-4268.

Place handset in charger for at least 16 hours before first use.

Low battery indicator

Return handset to charger when this symbol appears.

Getting Started

Wall mounting

The telephone base can be installed on any standard wall-phone outlet as shown below. Choose a location away from electronic equipment such as personal computers, computer routers, television sets or microwave ovens. Avoid excessive heat, cold, dust or moisture.

Connect short telephone line cord and power adapter as shown on page 6, then grasp and squeeze to open hinged wall mount.

Press and slide down firmly so the telephone base is held securely on outlet mounting pegs.

Rotate wall mount and lock in place.

Plug the short telephone line cord into telephone jack.

Remove handset cradle tab, rotate and replace to hold corded handset securely in place when telephone base is wall mounted.

Getting Started

Belt clip & optional headset

Install belt clip as shown below if desired.

Snap belt clip into notches on side of handset. Rotate and pull to remove.

For hands-free telephone conversations, use any industry standard 2.5 mm headset (purchased separately). For best results, use an AT&T 2.5 mm headset.

Plug 2.5 mm headset into jack on side of handset (beneath small rubber flap).

LANGUAGE

Telephone Operation

Handset settings

You can change settings to program how the cordless handset works.

• Press

• Press OFF/CLEAR anytime to cancel an operation

Follow the steps below to program the cordless handset. To stop anytime, press OFF/CLEAR. If the telephone rings, programming stops automatically so you can answer the call.

Choose handset language

At this menu you can select the language used in all menus and screen displays.

• Press MENU/CHAN to begin programming.

• Press CIDV once. The screen displays

• Press SELECT to see the current setting flashing.

• Press CIDV or ^DIR to scroll through the available

• Press SELECT to select the displayed language and

MENU/CHAN, then use the CIDV or ^DIR but-

tons to scroll to the feature to be changed. Press

SELECT to select the displayed item.

and exit the menu display.

LANGUAGE

options of ENGLISH, ESPANOL and FRANCAIS.

exit.

DATE/TIME

1/01 12:00

Telephone Operation

Handset settings

Set handset date and time

The handset displays the date and time when idle. You can set the time manually, or you can allow it to be set automatically with incoming Caller ID information. The time will be set automatically only if you subscribe to Caller ID service provided by your local telephone company (see page 5).

• Press

• Press CIDV twice. The screen shows DATE/TIME.

• The month in the displayed date starts to flash. Use

• The date starts to flash. Use CIDV and ^DIR to scroll

• The hour starts to flash. Use CIDV and ^DIR to scroll

• The minute starts to flash. Use CIDV and ^DIR to

• The AM/PM starts to flash. Use CIDV and ^DIR to

MENU/CHAN to begin programming.

Press SELECT to confirm.

CIDV and ^DIR to scroll through the numbers 1, (for

January,) -12, (for December.) Press SELECT when the appropriate month is flashing.

through the numbers 1-31. Press SELECT when the appropriate date is flashing.

through the numbers 1-12. Press SELECT when the appropriate hour is flashing.

scroll through the numbers 00-59. Press SELECT when the appropriate minute is flashing.

toggle between AM and PM. Press SELECT when the appropriate option is flashing, save the selection, and exit.

NOTE: You can choose to set the time manually, or you can allow it to

be set automatically with incoming Caller ID information. The time will be set automatically only if you subscribe to Caller ID service provided by your local telephone company .

RINGER: 1

Telephone Operation

Handset settings

Set handset ringer tone

This feature allows you to choose one of 4 ringing tones, (1-4) or turn the ringer off ( 0 ). Use the or ^DIR button to hear an example of each ringer tone, then press SELECT to select the one you prefer.

• Press MENU/CHAN to begin programming.

• Press ^DIR twice. The screen displays

setting.

• Press SELECT to change current setting.

• Press CIDV or ^DIR to display 1, 2, 3, 4, or OFF. You

will hear a sample of each ringer tone.

• Press SELECT to select the displayed ringer tone and exit.

Set handset ringer volume

• Press and hold CIDV or ^DIR for about 2 seconds.

• When the screen displays OFF LOW HIGH, the current setting will flash.

• Press CIDV or ^DIR to select your preference.

• Press SELECT, PHONE/FLASH, OFF/CLEAR, or

MENU/CHAN to confirm and save your selection, and

exit to idle mode.

CIDV

RINGER:

and

NOTE: Handset ringer volume can also be temporarily adjusted by

pressing CIDV or ^DIR (OFF LOW HIGH) or pressing

OFF/CLEAR to temporarily mute ringing during incoming ringing.

The next call will ring normally.

LANGUAGE

DIAL MODE: TONE

Telephone Operation

Base settings

You can change settings to program how the telephone base works.

Follow the steps below to program the telephone base. To stop at any time, press gramming stops automatically so you can answer the call.

Choose telephone base language

At this menu you can select the language used in all menus and screen displays.

• Press MENU to begin programming.

• Press CIDV or DIR^until screen displays

LANGUAGE

• Press SELECT to change current setting.

• Press CIDV or DIR^ to scroll through the available

options of ENGLISH, ESPANOL and FRANCAIS.

• Press SELECT to select the displayed language and exit.

CLEAR. If the phone rings, pro-

NOTE: This sets the dial mode

for both the handset(s) and the telephone base.

NOTE: During a power failure,

only the corded handset can be used to make and answer calls. The dial mode will default to pulse dial. To change to tone dial temporarily, press

* on the telephone base (see page

17). When the power is restored, the dial mode will return to the programmed setting.

Choose dial mode

At this menu you can choose tone or pulse dialing. The factory default setting is TONE. Change this to PULSE only if you do not have touch-tone dialing service.

• Press MENU to begin programming.

• Press CIDV or DIR^ until screen displays

MODE

& setting.

DIAL

• Press SELECT to change current setting.

• Press CIDV or DIR^ to display TONE or PULSE.

• Press SELECT to select displayed dial mode and exit.

Telephone Operation

Base settings

Choose base ringer volume

The base ringer volume can be set to OFF, LOW, or HI, by adjusting the switch on the left side of the telephone base. This switch affects only the telephone base ringer volume; the handset ringer volume remains unchanged.

PAT JOHNSON

908-555-0100

8/12 10:06

Telephone Operation

Basic cordless handset operation

Making and answering calls

To answer an incoming call, press any key except OFF/CLEAR, CIDV or ^DIR). If you have Caller ID service, the caller’s number and/or name will appear on the display screen after the first or second ring (see page 29 for Caller ID features and options).

To make a call, press PHONE/FLASH, then dial a number. Press OFF/CLEAR or place in charger, (Auto Off,) to hang up.

To preview numbers before dialing, enter numbers first, then press PHONE/FLASH to dial. Press CIDV anytime to make corrections when entering numbers.

Last number redial

Press REDIAL/PAUSE on the handset to display the last number called (up to 32 digits). To dial the number displayed, press PHONE/FLASH. You can also press

PHONE/FLASH and then REDIAL/PAU SE to dial the last

number called without previewing it.

To delete this number, press REDIAL/PA USE twice. This will clear the redial memory and leave it blank.

PHONE/FLASH (or

Ring silencing

The handset ringer can be temporarily turned off by pressing OFF/CLEAR during incoming ringing. You can answer the call, or let the caller leave a message. This will silence the ringer without disconnecting the call. If your answering system is on, the caller will be asked to leave a message (see page 36). The next call will ring normally.

NOTE: Pressing OFF/CLEAR will only temporarily silence the ring-

er on the handset. The telephone base will continue to ring normally.

Lift handset, or press SPEAKER

PAT JOHNSON 908-555-0100

8/12 10:06

12345678901

Telephone Operation

Basic base operation

Making and answering calls

To answer a call, lift the corded handset or press

SPEAKER. To answer a call, lift the corded handset,

or press SPEAKER. If you have Caller ID service, the caller’s number and/or name will appear on the display screen after the first ring (see page 29 for Caller ID features and options).

To make a call, lift the corded handset, (or press SPEAKER) then dial a number.

To preview numbers before dialing, first enter telephone number. Press CIDV to make corrections if necessary.

When the number is entered, press DISP DIAL to activate the speakerphone and dial automatically. You can continue using the speakerphone, or lift the corded handset to switch to the handset.

To hang up, replace the corded handset or press

SPEAKER.

Redial

Press INTERCOM/ handset

NOTE: If the handset battery is

dead or the ringer is turned off this feature will not work.

CID DEL to locate

Last number redial

Press REDIAL/PAUSE on the telephone base to display the last number called (up to 32 digits). To dial the number displayed, press DISP DIAL to activate the speakerphone and dial automatically. You can also call a redial number by pressing SPEAKER and then REDIAL/PAUSE . You can continue using the speakerphone, or lift the corded handset to switch to the handset.

To delete the displayed number, press REDIAL/PAUS E again. This will clear the redial memory and leave it blank.

Handset locator

If the cordless handset is misplaced, press the

INTERCOM/CID DEL button on the telephone base. The

handset will beep for 60 seconds to help you find it. When the handset is found, press OFF/CLEAR to stop the beeping (or press the INTERCOM/CID DEL button on the telephone base).

Flash

Tone

Hold

Flash

Channel

Volume

Telephone Operation

Options while on calls

To adjust volume

CIDV or ^DIR buttons on the handset or the

Press

VOLUME button on the telephone base to adjust

listening volume.

Call waiting

If you subscribe to a Call Waiting service with your local telephone service provider, you will hear a beep if someone calls while you are already on a call. Press

PHONE/FLASH on the cordless handset or FLASH on

the base to put your current call on hold and take the new call. You can press PHONE/FLASH on the cordless handset or FLASH on the base anytime to switch back and forth between calls.

Hold

Tone

Volume

Mute

Speaker

Press HOLD to place a call on hold.

When a call is on hold, resume the conversation on the cordless handset by pressing HOLD or PHONE/FLASH. Resume a conversation at the telephone base by lifting the handset or pressing SPEAKER or HOLD on the telephone base.

When a call is on hold, you can replace either handset in the telephone base or charger, and retrieve the call from another telephone.

Mute

While using the telephone base, you can press MUTE to silence the microphone during a conversation. You will be able to hear the caller, but your caller will not be able to hear you until you press MUTE again to resume speaking.

Telephone Operation

Options while on calls

SCANNING...

Phone

Hold

Intercom

INT

Speaker

Channel (Cordless handset only)

If a call is noisy or unclear, or if words fade out, press

MENU/CHAN on the cordless handset to scan for a bet-

ter communication channel between the handset and the telephone base.

Temporary tone dialing

If you have dial pulse (rotary) service, you can switch to touch tone dialing during a call by pressing *. This can be useful if you need to send tone signals for access to answering systems or long-distance services.

After you hang up or press PHONE/FLASH on the cordless handset or FLASH on the base to access services with your local telephone service provider, the telephone automatically returns to dial pulse (rotary) service.

3-way conference calls

During a call, someone at the telephone base or another handset can join in the conversation.

• On the cordless handset: Press PHONE/FLASH to join a conversation begun at the telephone base.

• At the telephone base: Lift the handset (or press

SPEAKER) to join a conversation begun at the

cordless handset.

You can also page the other parts of the system and ask another user to join the call.

From a cordless handset: Press HOLD, then press

INT/DELETE.

From the telephone base: Press HOLD, then press

Hold

INTERCOM/CID DEL.

Anyone at a cordless handset or telephone base can either join the call, (by pressing PHONE/FLASH or SPEAKER,) or talk to you first, (by answering the page), and then decide whether to join the call. When another user joins the call, the intercom call is terminated.

Press INT/ page the telephone base.

Press INTERCOM/CID DEL to page handset.

DELETE to

Telephone Operation

Intercom calls

You can use the intercom feature to have conversations between the handset and the telephone base. Press the

INTERCOM/CID DEL at the telephone base.

To answer an intercom page on a cordless handset, press INT/DELETE. At the telephone base, lift the handset or press INTERCOM/CID DEL.

To end an intercom call on a cordless handset, press

OFF/CLEAR. To end an intercom call at the tel-

ephone base, hang up the corded handset or press

INTERCOM/CID DEL.

Handling incoming calls

If you receive an outside call while using the intercom, the telephone will ring.

• On a cordless handset: Press any key except OFF/CLEAR, CID/V or ^/DIR to answer the out-

• At the telephone base: Lift the handset (or press

INT/DELETE button on a cordless handset or

side call.

SPEAKER) to answer the outside call.

NOTE: If your cordless handset

is missing, you can press INTERCOM/

CID DEL on the base to page the cord-

less handset up to 60 seconds. Press INTERCOM/CID DEL on the base again, press OFF/CLEAR on the cordless handset, or place the cordless handset in the charger to cancel the page.

NOTES:

1. You can also press HOLD before

starting to move the call.

2. Before the intercom call is answered, the person who originated the PAGE can press on the cordless handset, or press SPEAKER or lift the corded handset on the base, to cancel the page and resume the outside call.

PHONE/FLASH

switchhook

Telephone Operation

Intercom calls (cont.)

Intercom calls

During a telephone conversation, you can move the call to the telephone base from a cordless handset, or to a cordless handset from the telephone base.

To move a call from a cordless handset to the telephone base:

• To page the telephone base, press cordless handset (PAGING will show on the base and handset screens, the outside call will automatically be put on HOLD).

• To answer the PAGE, press the INTERCOM/CID DEL key on the telephone base. This will activate the intercom between the cordless handset and telephone base and allow you to speak to the person at the base.

• To answer the PAGE, lift the corded handset or press the INTERCOM/CID DEL key on the telephone base. This will activate the intercom between the cordless handset and telephone base and allow you to speak to the person at the base.

• To take the outside call at the base:

• If you are using the corded handset for the intercom call, press SPEAKER to be on the speakerphone, or press and release the corded switchhook and then press HOLD to be on the corded handset.

• If you are using the speaker for the intercom call, press SPEAKER to be on the speakerphone, or lift the corded handset.

• To take the outside call at the cordless handset, press

PHONE/FLASH.

The intercom call between the telephone base and cordless handset will automatically end.

INT/DELETE on the

NOTE: Before the intercom

call is answered, the person who originated the PAGE can press

PHONE/FLASH on the cordless

handset, or press SPEAKER or lift the corded handset on the base, to cancel the page and resume the outside call.

switchhook

Telephone Operation

Intercom calls (cont.)

Intercom calls

To move a call from the telephone base to the cordless handset:

• Press

• To page the cordless handsets, press INTERCOM/CID DEL

• To answer the PAGE, press INT/DELETE on a cordless

• To take the outside call at the cordless handset, press

• To take the outside call at the base:

The intercom call between the telephone base and cordless handset will automatically end.

HOLD. (If you are on the base Speakerphone,

this step is optional since the outside call will automatically be put on HOLD).

on the telephone base (PAGING will show on the base and handset screens).

handset. This will activate the intercom between the cordless handset and telephone base and allow you to speak to the person at the base.

PHONE/FLASH.

• If you are using the corded handset for the intercom call, press SPEAKER to be on the speakerphone, or press and release the corded switchhook and then press HOLD to be on the corded handset.

• If you are using the speaker for the intercom call, press SPEAKER to be on the speakerphone, or lift the corded handset.

Directories

PAT JOHNSON 5550100

CHRIS WILSON

Directories (handset and base)

There are two separate directories, one on the cordless handset and one on the telephone base. Each directory can store up to 30 entries. Each entry can contain a number up to 24 digits, and a name up to 15 letters. A convenient search feature can help you find and dial numbers quickly (see page 27).

The procedure for entering, editing and dialing directory entries is the same for both the cordless handset and the telephone base.

NOTE: If all memory locations are in use, an error tone will sound and

the screen will display MEMORY FULL when entering a number. This means the memory is full, and you will not be able to store a new number until you delete an existing one.

DIRECTORY

SPEED DIAL

ENTER 1-9

ENTER NAME

MENU/CHAN

CIDV or ^DIR

SELECT

Directories

Speed dialing

(cordless handset only)

On the cordless handset, numbers called most frequently can be stored in so that they can be dialed with only two button presses.

You can enter nine Speed Dial numbers up to 24 digits. Each entry is associated with a dialpad numeral key.

The nine speed dial numbers on the cordless handset will be automatically added to the handset directory. You can easily dial these telephone numbers by pressing and holding a dialpad key and then pressing

PHONE/FLASH.

You can also make existing directory entries speed dial entries.

(See Steps 3-7 on pages 25-26.)

NOTE: Speed Dial entries are part of the directory. If you have nine

Speed Dial entries, there will be room for another 21 directory entries.

To create a Speed Dial entry

• Press MENU/CHAN to begin programming.

• Press CIDV or ^DIR to display

SPEED DIAL

• Press SELECT.

• Press a number key on the dialpad to choose a memory location (1-9).

• Enter a name (up to 15 characters), then press

SELECT (see page 25 for instructions on name

entry).

• Enter a telephone number (up to 24 digits), then press SELECT.

• Choose distinctive ringing (yes or no) by pressing

CIDV or ^DIR (see page 26 for information about

distinctive ring).

• Press MENU/CHAN or SELECT to store the number. You will hear a confirmation tone.

Directories

Speed dialing

(cordless handset only)

To create a directory entry

• Press

MENU/CHAN to begin programming.

• Press SELECT.

• Enter a name (up to 15 characters), then press

SELECT (see page 25 for instructions).

• Enter a telephone number (up to 24 digits), then press SELECT.

• Choose distinctive ringing (yes or no) by pressing

CIDV or ^DIR (see page 26 for distinctive ring).

• Press MENU/CHAN or SELECT to store the number.

You will hear a confirmation tone.

To call a Speed Dial number

To use speed dialing, press and hold a dialpad button (1-

9). When you see the number and name stored in that

speed-dial location, press PHONE/FLASH to dial.

To edit or delete a Speed Dial number

Press and hold a dialpad button (1-9) to display the entry you want. Press SELECT, then press CIDV or

^DIR until the option you want is displayed (see page

28).

NOTE: You can make any directory entry a speed dial entry (see page

28).

Directory dialing

To use directory dialing, press ^DIR, scroll or search to find the desired number, then press PHONE/FLASH to dial the number (see pages 25-28 to enter, edit or search for entries in your directory).

MENU/CHAN

DIRECTORY

SELECT

ENTER NAME

PAT JOHNSON_

Directories

Entering names into directories

To enter a name

• Press

• Press SELECT to confirm.

• The screen will show ENTER NAME.

• Enter the name (up to 15 alphanumeric characters)

• Use ^DIR to advance to the next space to the right,

• When finished entering the name, press SELECT.

Each press of a particular key causes characters to be displayed in the following order:

MENU/CHAN on cordless handset or MENU on

base to enter the main menu.

of the person using the table below.

or use CIDV to delete a mistake.

The cursor moves to the right when you press another dialpad button or the ^DIR button. Press ^DIR twice to enter a space. When finished, press SELECT.

Options while entering names:

• Press CIDV to erase letters .

• Press # repeatedly to enter an ampersand (&),

apostrophe ('), comma (,) hyphen (-), period (.), or pound sign (#).

SELECT

ENTER NUMBER

PAT JOHNSON 5556789_

SELECT

(Cordless handset only)

DISTINCT RING? N 5556789

SELECT

1/01 12:00

Directories

Entering phone number and assigning distinctive ring

To enter a number

Use the dialpad to enter up to 24 digits. When the number is complete, press

Options while entering numbers:

• Press CIDV to erase numbers if you make a mistake.

• Press REDIAL/PAUSE to enter a four-second dialing pause. The P will be inserted.

• When finished entering the telephone number, press

SELECT to confirm.

To assign a distinctive ring (cordless handset only) Press CIDV or ^DIR to select Y (yes) or N (no). If you

choose Yes (and if you have Caller ID service), a distinct ring tone will alert you when this person calls.

Press SELECT to choose the option displayed (Y or N)

and store this entry in the directory.

SELECT.

DIRECTORY

ADAM 5551234

^DIR

Directories

Directory search

Follow the steps on the left to browse through the directory, or search to find a specific entry. You can press at the base) anytime to exit the directory.

OFF/CLEAR on the cordless handset (or CLEAR

To display first entry

^DIR

BETH 5554321

To scroll name by name

JOHN 5550123

To search alphabetically

EDIT DIAL ERASE

5551234

NOTE: To place a call on the

corded handset using a directory entry, lift the corded handset, press the ^DIR button until you find the entry and press DISP DIAL.

To browse through the directory

To browse, press ^ DIR or CID V to scroll through all entries one by one.

A D appears in the display of each entry on the cordless handset that has been assigned a distinctive ring (see page 26).

To search alphabetically

To shorten your search, use the telephone dialpad to enter the first letter of a name, then press ^DIR to scroll forward or CIDV to scroll back until you find the desired name.

Press dialpad buttons once for the first letter, twice for the second, three times for the third, as shown on page

25.

To call a displayed number

When the desired entry is displayed, you can dial it immediately:

On the cordless handset, press PHONE/FLASH to dial.

At the base, press DISP DIAL or press SELECT twice to activate the speakerphone and dial the number. You can continue the call on speakerphone, or lift the corded handset.

^DIR

DIRECTORY

^DIR

ADAM 5551234

SELECT

SPEED EDIT ERASE

5551234

^DIR

SPEED EDIT ERASE

5551234

^DIR

SPEED EDIT ERASE 5551234

Directories

To copy, edit or delete an entry

You can make existing directory entries Speed Dial entries if they are stored in the handset. You can also change names, numbers and the distinctive ringing settings, or erase entries, that are stored in the cordless handset or the telephone base. When any entry is displayed, press to see the options. Press CIDV or ^DIR to highlight the option you want (blinking text), then press SELECT.

To make an entry a Speed Dial entry (cordless handset only)

When

SPEED

is blinking, press SELECT, then dial a memory location (1-9) to make this entry a Speed Dial entry.

If you choose a memory location that is already assigned to a different entry in the directory, that entry will remain in the directory, but will not have a SPEED DIAL location.

SELECT

Press SELECT to choose blinking option on the handset.

NOTE: Screens shown

above are displayed on the cordless handset. The telephone base display is slightly different, but the procedure is the same.

NOTE: See Page 27 for

instructions on dialing a directory entry from the base.

To edit an entry

Press CIDV or ^DIR until

SELECT. You can change the name and number (or dis-

EDIT

is blinking, then press

tinct ring setting on the cordless handset) by following the steps described on pages 25-26.

To delete an entry

Press CIDV or ^DIR until

SELECT to display a confirmation screen (

YES

To delete the entry, press ^DIR to highlight

ERASE

is blinking, then press

ERASE NO

YES

, then

press SELECT.

To abort the procedure and leave the entry intact, press

CID CIDV to highlight NO, then press SELECT.

Caller ID Operation

PAT JOHNSON *

908-555-0100

8/12 10:06

CHRIS WILSON *

908-555-4321

8/12 10:06

How Caller ID works

If you subscribe to Caller ID service provided by your local phone company, information about each caller will be displayed at both the cordless handset and the telephone base after the first or second ring.

With most incoming calls, the screen shows the name of the caller (up to 15 alphanumeric characters including spaces) in the top row, and the caller's telephone number, including the area code (up to 11 digits including area code) in the second row. The third row shows the date and time of the call, the total number of Caller ID entries already stored in the handset memory, as well as the low-battery icon if the battery is low. The low battery icon will be displayed if the battery on the handset is low.

If the caller has made 2 or more consecutive calls, the repeat tag (*) will be displayed in the top right corner of the screen.

Caller ID and Call Waiting Functions

There may be a charge for the caller ID and call waiting services provided by your local telephone company.

Contact your telephone company if:

• you have both Caller ID and Call Waiting, but as separate services (you may need combined service),

• you have only Caller ID service, or only Call Waiting service, or

• you currently do not have Caller ID or Call Waiting services.

You can use this telephone with regular Caller ID service, and you can use its other features without subscribing to either Caller ID or combined Caller ID with Call Waiting service. There may be fees for these services, and they may not be available in all areas.

Caller ID features will work only if both you and the caller are in areas offering Caller ID service, and if both telephone companies use compatible equipment.

Caller ID Operation

There are also occasions when other information or no information is displayed for various reasons:

On-Screen Message Reason

PRIVATE NAME Caller prefers to remain anonymous.

PRIVATE CALLER Caller's name and telephone number are

not revealed at caller's request.

UNKNOWN NAME Your local telephone company is unable to

determine the caller's name.

UNKNOWN CALLER Your local telephone company is unable to

determine the caller's name and telephone number. Long-distance calls from overseas also generate this message.

Contrast Adjustment (telephone base only)

There are four levels of contrast on the screen of the telephone base which can be adjusted to suit different viewing angles for both desktop use or wall-mounting. Press CONTRAST on the telephone base to adjust the contrast on the screen.

NOTE: The cordless handset

and CID logs on the telephone base not shared. Action taken on one will not affect the other.

NOTE: Only the cordless

handset will show the order of the call in call history.

Caller ID Operation

CID memory

Memory Capacity

E5908 telephone can store up to 30 CID records in both the telephone base and the cordless handset respectively. These numbers are available for subsequent retrieval or for saving into the internal directory for long-term storage until they are deleted.

Caller information is stored chronologically with the latest call being assigned the next highest numerical value, i.e. if there are already 15 calls logged into the CID Memory, the next incoming call will be Call No. 16.

Reviewing the CID Memory

• Press

• Press the two arrow keys ( CIDV and DIR^ on the

• Consecutive incoming calls originating from the same

• When there are already 30 entries in the CID

CIDV on the telephone base or the cordless

handset to activate the CID Memory record on the respective unit.

telephone base or on the cordless handset) to scroll through the incoming records to review incoming calls and check for missed calls.

telephone number are identified by an asterisk at the top right corner of the screen and will be counted as one call in the CID memory.

Memory, the next incoming call will automatically cause the oldest entry to be deleted from the CID Memory of the handset (or base).

PAT JOHNSON

908-555-0100

8/12 10:06

AM NEW

NOTE: If there are new calls in the CID log already (NEW CALL light is

flashing), and an incoming call is answered on the corded handset at the telephone base, then the NEW CALL light will extinguish on the telephone base although there are still unreviewed CID records in the CID log.

Caller ID Operation

CID memory

Dialing from CID Memory

• Press

• Press CIDV or DIR^ on the telephone base or on

• Press DISP DIAL below the LCD screen on the tele-

Storing a record from the CID Memory into the directory

• Press CIDV on the telephone base or on the cord-

• Press CIDV or DIR^ on the telephone base or on

• When the desired entry is displayed, press SELECT.

• When the options DIAL and PROGRAM

• The cursor will flash on the last letter of the top row.

CIDV on the telephone base or on the cord-

less handset to activate the CID Memory.

the cordless handset to scroll to the desired number to be dialed.

phone base or press PHONE/FLASH on the cordless handset to contact the person whose name is displayed on the screen.

less handset to activate the CID Memory.

the cordless handset to scroll to the caller entry to be stored in the directory.

appear on the screen with the word PROGRAM flashing, press SELECT.

If it is necessary to edit the name before entering it into the directory, use the CIDV on the handset or the telephone base to delete existing characters, or use the keypad to make changes to the name to be used in the directory (see page 25).

NOTE: When there is an unanswered call, the NEW CALL light on the

telephone base will flash, and the LCD screen on the handset and the telephone base will show the number of missed calls.

NOTE: When only some of the missed calls have been reviewed, the

screen on the telephone base will continue to show the remaining number of unreviewed calls and the NEW CALL light will continue to flash.

Caller ID Operation

CID memory

• Press SELECT to edit the telephone number. You can make any changes to the number by using the CIDV button to erase characters, or using the dialpad to enter new ones (see pages 25-26 for instructions).

• Press

• Press SELECT again and a long beep sound signals

Deleting a number from the CID Memory

• Press CIDV on the telephone base or on the cord-

• Press CIDV or DIR^ on the telephone base or on

• When the desired record is displayed on the screen,

SELECT. You can now choose to assign a dis-

tinctive ringer to this entry. Press CIDV or ^DIR to choose Y (for yes) or N (for no). If you choose Yes (and if you have Caller ID service), a different ringing style will alert you when this person calls. (This step is for the cordless handset only).

that the information has been stored in the directory.

less handset to activate the CID Memory.

the cordless handset to scroll to the incoming call entry to be deleted.

press INTERCOM/CID DEL on the telephone base (INT/DELETE on the cordless handset) to delete the entry.

NOTE: Deleting an incoming call record on the telephone base does

not automatically delete the same record from the cordless handset. Likewise, deleting an incoming call record on the cordless handset does not automatically delete the same record from the telephone base.

NOTE: When an entry is deleted, the next oldest record is displayed.

NOTE: See Page 32 for instructions on dialing a CID entry.

ERASE ALL NO YES

Caller ID Operation

CID memory

Deleting all CID records

• Press and hold or INTERCOM/CID DEL on the telephone base for 2 seconds or longer to clear all entries in the call log memory.

• A message appears on the screen asking you to confirm that you want to delete all entries in the call log memory.

• If you press CIDV or ^DIR then SELECT to select YES, the call log will be cleared and the screen will return to the normal standby display, the telephone base displays NO MISSED CALLS, and the cordless handset displays the date and time only.

NOTE: The cordless handset and the telephone base call logs are

independent of each, so deleting the entire call log on one will not affect the call log of the other.

INT/DELETE on the cordless handset

NO MISSED CALLS

telephone base

1/01 12:00

cordless handset

Caller ID Operation

Call waiting

If you have subscribed to the Call Waiting service from your local telephone company, you will hear a beep if there is an incoming call while you are already on the phone.

The telephone number of the new incoming call will also be displayed on the screen.

• Press

• Press FLASH on the telephone base or PHONE/

FLASH on the telephone base or PHONE/

FLASH on the cordless handset to put your current

call on hold and take the new call.

FLASH on the cordless handset again to switch back

to the original call.

Message counter

Number of messages waiting (or during playback, message number currently playing)

Answering System Operation

Message capacity

The answering system can record up to 95 messages, depending on the length of each message. Individual messages can be up to four minutes long, and total maximum recording time is 15 minutes. Messages will remain available for replay until you delete them.

Press to start or stop message playback (see page 40).

Press to review or record announcement; press again to quit (see page 38).

Press to review or set clock (see page 37).

Press repeatedly to hear setup options (see page 39).

Press to delete message currently playing; hold to delete all old messages (see page 40).

Press to turn answering system on or off.

Press to repeat message; press

twice

previous message (see page 40).

to play

Press to record a memo (see page 41) or after pressing ANNC to record an outgoing announcement (see page 38).

Press to adjust playback volume (see page 40).

Press to skip message (see page 40).

The system will announce the current clock setting, then announces

"To set the clock, press CLOCK."

The system will announce the current day setting, then announces

"To change the day, press SKIP or REPEAT, to change the hour, press CLOCK."

until the system announces the correct day, then press CLOCK.

Press CLOCK

Press SKIP

or REPEAT

Answering System Operation

Day and time announcements

To set day and time

Before playing each message, the answering system announces the day and time the message was received.

Before using the answering system, follow the steps at left to set the day and time, so messages are dated correctly. If the clock is not set, before playing messages, the system will prompt "Time and date not set" each time.

The system uses voice prompts to guide you. Each time you press or year increases or decreases by one. When you hear the correct setting, press CLOCK to move to the next setting.

To check day and time

You can press CLOCK at any time to hear the current day and time without changing it.

SKIP or REPEAT, the day, hour, minute

until the system announces the correct hour, then press CLOCK.

until the system announces the correct minutes, then press CLOCK.

until the system announces the correct year, then press CLOCK. The system announces the current clock setting.

Press SKIP

or REPEAT

Press SKIP

or REPEAT

Press SKIP

or REPEAT

NOTE: You can press and hold SKIP or REPEAT to

increase or decrease the minute or year by ten.

NOTE: Caller ID provides the time and date. Set the year so that the

day of the week can be calculated from the Caller ID information. After you set the time once, it will thereafter be set automatically with incoming Caller ID information. The time will be set automatically only if you subscribe to Caller ID service provided by your local telephone company (see page 5).

Answering System Operation

Elapsed recording time (seconds).

ANNC

“Announcement. Press PLAY or press RECORD.”

(Plays announcement previously recorded).

-OR-

RECORD

“Record after the tone. Press STOP when you are done.”

Speak into microphone.

Press to stop recording.

(Play/Stop)

Outgoing announcements

Outgoing announcements are the messages callers hear when calls are answered by the answering system.

The telephone is pre-programmed with an announcement. If the telephone is set up to record messages, it answers calls with “Hello. Please leave a message after the tone.” You can use this announcement, or replace it with a recording of your own voice.

NOTE: Press ANNC to exit the announcement programming.

To play your outgoing announcement

Press ANNC until you hear "Announcement. Press PLAY or press RECORD." Then press PLAY/STOP.

You will hear the outgoing announcement.

To record your outgoing announcement

Press ANNC until you hear "Announcement. Press PLAY or press RECORD." Then press RECORD and begin speaking after you hear "Record after the tone. Press STOP when you are done." Speak fac-

ing the telephone base from about nine inches away. Press PLAY/STOP when you are done. Your recorded announcement will be played back.

Elapsed time (in seconds) will be shown in the message window when recording. You can record an announcement up to 90 seconds long. Announcements shorter than three seconds long will not be recorded.

Microphone

to exit announcement programming.

(Play/Stop)

(Announcement is played back).

ANNC

To delete your outgoing announcement

Press ANNC until you hear “Announcement. Press PLAY or press RECORD.” Then press PLAY/STOP to

begin playback. Press DELETE during playback to delete your announcement.

When your announcement is deleted, calls will be answered with the pre-programmed announcement described above.

Answering System Operation

Changing feature options

SETUP

Press until desired feature is heard (see list at right).

SKIP or

REPEAT

Press until desired selection is heard.

SETUP

Press to set selection and

move to next menu option.

-OR-

(Play/Stop)

Press to set selection and exit menu.

Menu features can be changed to program how the answering system operates. Press SETUP repeatedly to hear each feature. When you hear the feature you want to modify press

SKIP or REPEAT to change the

setting.

Feature options (Default settings underlined).

System announces: Feature description:

"Number of rings", current setting, then "To change the set-

ting press SKIP or REPEAT; to continue setup, press SETUP"

Options: 2 / 4 / 6 /Toll Saver

"Call screening", current setting, then "To change the set-

ting press SKIP or REPEAT; to continue setup, press SETUP"

Options: On / Off

"Remote access code", current setting, then "To change

the setting press SKIP or REPEAT; to continue setup, press SETUP"

Options: (enter 2-digit code) 19

Choose number of rings before the system answers a call. When Toll Saver is active, the system answers after two rings if you have new messages, and after four rings if you have no new messages. When retrieving messages from a long-distant call, you may disconnect your call after three rings so that long distance charges will not be charged.

When on, you can hear callers leave messages, or answer the call.

Enter a two-digit number (10-99) for remote access from another telephone (see page 43).

"Message alert tone", current setting, then "To change

the setting press SKIP or REPEAT; to continue setup, press SETUP"

Options: On / Off

NOTE: Press and hold SKIP or REPEAT to increase or

decrease the remote access code number by 10.

When on, the telephone beeps every 10 seconds when there are new messages.

Number of messages waiting (or during playback, message number currently playing).

PLAY/STOP to begin

Press or end message playback.

Message playback begins. See options at right.

Message playback ends.

NOTE: If “F” is flashing in

the message window, memory is full. You will have to delete some messages before new ones can be received.

NOTE: New (unheard)

messages cannot be deleted.

(Play/Stop)

“You have [xx] new messages and [xx] old messages”

(Play/Stop)

Answering System Operation

Message playback

Press PLAY/STOP to hear messages. The system announces the number of messages, then begins playback.

If you have new messages waiting, you will hear only the new messages (oldest first). If there are no new messages, the system will play back all messages (oldest first).

Announcements

• When playback begins, you will hear the total number of messages.

• Before each message, you will hear the day and time it was received.

• After the last message, you will hear “End of mes- sages.” If the system has less than five minutes of recording time left, you will hear time remaining.

Options during playback

• Press

• Press SKIP to skip to next message.

• Press REPEAT to repeat message currently playing. Press twice to hear previous message.

• Press DELETE to delete message being played back.

• Press PLAY/STOP to stop playback.

VOLUME button to adjust speaker volume.

To delete all messages

To delete all messages, press and hold DELETE while the telephone is idle (not during a call, or during message playback).

Answering System Operation

Elapsed recording time (seconds).

RECORD

“Record after the tone. Press STOP when you are done.”

Speak into microphone.

Beep (Memo has been recorded).

Press to stop recording.

Microphone

(Play/Stop)

Recording and playing memos

Memos are messages you record yourself. They are saved, played back and deleted exactly like incoming messages. You can record a memo as a reminder to yourself, or leave a message for someone else if other members of your household are using the answering system.

To record a memo

RECORD. Elapsed time (in seconds) is shown in the

Press message window as you record. You can record a memo up to four minutes long. Memos less than one second long will not be recorded.

Press PLAY/STOP to stop recording.

To play back a memo

Press PLAY/STOP to hear messages and memos (see page 40 for other options).

Answering System Operation

Message counter

Message counter displays

The message counter usually displays the total number of memos and incoming messages. See the list below for explanations of other displays in this counter.

Message counter displays

0 No messages.

1-95 Number of messages/memos, or message number

currently playing (flashes when there are new messages).

10-99 Current remote access code while setting

(see page 39).

1-99 (counting) Elapsed time while recording a memo (see page 41)

or announcement up to 90 seconds (page 38).

1-95 (flashing) Total number of messages and memos including

unreviewed messages.

99 (flashing) Memo recording exceeded maximum time of 99

seconds.

F (flashing) Memory is full. Messages must be deleted before

new messages can be received.

-- System is answering a call, being accessed

remotely, or the clock is being programmed.

-- (flashing) System is being programmed or initialized.

On (or) OF Displayed for one second when any answering

system setting is turned on or off.

02, 04, 06, tS Current number of rings while setting (see page

39).

Dial your telephone number from

any touch-tone telephone.

When system answers, enter

two digit remote access code (19 unless you have changed it).

Enter remote commands

(see list at right).

Answering System Operation

Remote access

A two digit security code is required to access your answering system from any touch-tone telephone. This code is 19 by default; see page 39 to change it.

Play all messages

Press to hear all messages.

Hang up to end call and save all

undeleted messages.

Play new messages

Delete the message

3 33

Repeat or go back

Stop

Skip to next message

Record announcement

*7to begin recording 5to stop recording

Help menu

Turn system off

Press to hear new messages.

Press during playback to delete current message. Press 3 twice to delete all old messages.

Press during the caller’s message to repeat the message. Press during the beginning of the day and time announcement to go back to the previous message.

Press to stop any operation (stop playback, stop recording).

Press to skip current message and advance to next message.

Press * 7, wait for beep, then begin speaking. Press 5 to stop recording and hear playback of new announcement.

Press to hear list of features & commands.

Press to turn off answering system. Incoming calls will no longer be answered.

NOTE: If you pause for

more than 4 seconds during remote access, you will hear a help menu listing all features & commands. If there is no command for another 20 seconds, the call will end automatically.

Turn system on

Exit

If off, system will answer after 10 rings. Enter your access code, then press 0 to turn on.

Press 8 to end remote access call or hang up.

Appendix

Display screen messages, lights and tones

Screen display messages

CONNECTING...

** RINGING **

** PAGING **

NEEDS RECHARGING

BATTERY LOW

PHONE ON

RINGER OFF

HOLD

SCANNING

CAN'T CONNECT

MUTE

The handset is waiting for a dial tone.

There is a call coming in.

An intercom call has been initiated. The handset locator has been activated (handset beeps to help you locate it).

Handset battery is depleted. Place handset in charger to charge the battery.

Handset battery is low. Place handset in charger to charge the battery.

The handset is in use.

The handset ringer is turned off.

Current call is on hold.

Handset is scanning for a clear channel to improve sound quality.

Handset cannot communicate with the telephone base. Check base power, or move closer.

The call is on mute (only for telephone base).

Appendix

Display screen messages, lights and tones

Alert tones

Indicator lights

NEW CALL

If you have Caller ID service: On when new calls have been received; off when all new Caller ID records at the telephone base have been reviewed (see page 29).

IN USE

Steady: Line is in use. Flashing: Call is on hold.

(Also flashes in cadence with ringing to announce an incoming call.)

“Beep-Beep...Beep-Beep...” (Double beep every 5 seconds)

“Beep-Beep-Beep-Beep-Beep”

(5 quick beeps)

“Beeeeeeeeep”

(1 long beep)

“Beep”

(One beep every 10 seconds)

“Siren”

(Alternating tones)

Handset battery is low. Place handset in charger to charge the battery.

Error tone (current operation has been unsuccessful; try again).

Confirmation tone (current operation has been successfully completed).

Message Alert at the telephone base (there are new messages).

Handset is being paged.

SPEAKER

On when speakerphone is activated.

ANSWER ON

On: Answering system is on. Off: Answering system is off.

CHARGE

On when handset is charging in cradle.

Appendix

Troubleshooting

If you have difficulty with your phone, please try the suggestions below. For Customer Service, visit our web site at www.telephones.att.com, or call 1 (800) 222-3111. In Canada, call 1 (866) 288-4268.

My telephone does not work at all.

I cannot get a dial tone.

• Make sure the power cord is securely plugged in.

• Make sure the battery pack is installed and charged correctly (see page 7).

• Make sure the telephone line cord is securely plugged firmly into the telephone base and the telephone wall jack.

• Charge the battery pack in the cordless handset for at least 16 hours. For optimum daily performance, return the cordless handset to its base when not in use.

• Reset the base. Unplug the unit’s electrical power. Wait for approximately 15 seconds, then plug it back in. Allow up to one minute for the cordless handset and base to reset.

• You may need to purchase a new battery pack, please refer to page 7 of this user’s manual.

• Disconnect the telephone base from the modular jack and plug in a working telephone. If it still does not work, the problem is probably in the wiring or the local service. Call the local telephone company.

• First try all the suggestions above.

• Move the cordless handset closer to the telephone base. You might have moved out of range.

• Your line cord might be malfunctioning. Try installing a new line cord.

• If the previous suggestions don’t work, disconnect the telephone base unit from the telephone jack and connect a different telephone. If there is no dial tone on that telephone either, the problem is in your wiring or local service. Contact your local telephone company.

I cannot dial out.

• First try all the suggestions above.

• Make sure you have a dial tone before dialing. The cordless handset

may take a second or two to find the telephone base and produce a dial tone. This is normal. Wait an extra second before dialing.

• Make sure your telephone is set to the correct dial mode for the type

of service that you have (pulse or touch tone). Refer to the Installation section of this user’s manual (page 13) to set the dial mode.

• If the other telephones in your home are having the same problem,

the problem is in your wiring or local service. Contact your local telephone company (charges may apply).

• Eliminate any background noise. Noise from a television, radio or

other appliance may cause the telephone to not dial out properly. If you cannot eliminate the background noise, first try muting the cordless handset before dialing, or dialing from another room in your home with less background noise.

4646

Appendix

Troubleshooting

My cordless handset beeps five times and is not performing normally.

CAN’T CONNECT displays on my cordless handset.

• Make sure the power cord is securely plugged into the base. Plug the unit into a different, working electrical outlet not controlled by a wall switch.

• Move the cordless handset closer to the telephone base. You might have moved out of range.

• Reset the telephone base. Unplug the unit’s electrical power. Wait for 15 seconds then plug it back in. Allow up to one minute for the cordless handset and base to reset.

• Other electronic products can cause interference to your cordless phone. Try installing your telephone as far away from these types of electronic devices as possible: wireless routers, radios, radio towers, pager towers, cellular telephones, intercoms, room monitors, televisions, personal computers, kitchen appliances and other cordless telephones.

• Place the cordless handset in base cradle for one minute to allow the cordless handset and base to resynchronize channels.

• Move the cordless handset closer to the telephone base. It might have moved out of range.

• If the cordless handset is in its charger and the charging light does not come on, refer to the charge light is off in this troubleshooting guide.

• Reset the base. Unplug the unit’s electrical power. Wait for 15 seconds then plug it back in. Allow up to one minute for the cordless handset and base to reset.

• Other electronic products can cause interference with your cordless telephone. Try installing your telephone as far away from these types of electronic devices as possible: wireless routers, radios, radio towers, page towers, cellular telephones, intercoms, room monitors, televisions, personal computers, kitchen appliances and cordless telephones.

The batteries will not hold a charge.

• Charge the battery in the cordless handset for at least 16 hours. For optimum daily performance, return the cordless handset to its base when not in use.

• Make sure the handset is placed in the charger correctly. The CHARGING light on the charger should be on.

• If the cordless handset is in the charger but the CHARGE light is not on, refer to “The CHARGING light is off” in this section.

• It may be necessary to purchase a new battery pack, please refer to the batteries section of this user’s manual.

• Your telephone might be malfunctioning. Please refer to the Warranty section of this user’s manual for further instruction.

• If the cordless handset is in its charger and the charging light does not come on, refer to “The charge light is off” in this troubleshooting guide.

Appendix

Troubleshooting

I get noise, static, or weak signal even when I’m near the base.

I hear other calls while using my telephone.

• Other electronic products can cause interference to your cordless telephone. Try installing your telephone as far away from the following electronic devices as possible: wireless routers, radios, radio towers, pager towers, cellular telephones, intercoms, room monitors, televisions, personal computers, kitchen appliances and other cordless telephones.

• Microwave ovens operate on the same frequency as your telephone. It is normal to experience static on your telephone while the microwave oven is operating. Do not install this telephone in the same outlet or near a microwave oven.

• If your telephone is plugged in with a modem or a surge protector, plug the telephone (or modem/surge protector) into a different location. If this solves the problem, re-locate your telephone or modem farther apart from one another, or use a different surge protector.

• Relocate your telephone to a higher location. It will likely have better reception when installed in a higher area.

• If the other telephones in your home are having the same problem, the problem is in your wiring or local service. Contact your local telephone company (charges may apply).

• If you subscribe to DSL service and if you hear noise during conversations and/or your caller ID features are not functioning properly, install a noise filter to the telephone line between the base unit and the telephone line jack. Contact your DSL provider to obtain a noise filter.

• Disconnect the telephone base unit from the telephone jack, and plug in a different telephone. If you still hear other calls, the problem is probably in your wiring or local service. Call your local telephone company.

I hear noise in the cordless handset, and none of the keys or buttons work.

• Make sure the power cord is plugged in securely.

Appendix

Troubleshooting

My cordless handset does not ring when I receive a call.

• Make sure that the ringer is turned on. Refer to the section(s) on ringer selection in this user’s manual.

• Make sure the telephone line cord is plugged securely into the telephone base and the telephone jack. Make sure the power cord is securely plugged in.

• The cordless handset may be too far from the telephone base.

• Charge the battery in the cordless handset for at least 16 hours. For optimum daily performance, return the cordless handset to its charger when not in use.

• You may have too many extension telephones on your telephone line to allow all of them to ring simultaneously. Try unplugging some of the other telephones.

• The layout of your home or office might be limiting the operating range. Try moving the telephone base to another location, preferably on an upper floor.

• If the other telephones in your home are having the same problem, the problem is in your wiring or local service. Contact your local telephone company (charges may apply).

• Test a working telephone at the telephone jack. If another telephone has the same problem, the problem is the phone jack. Contact your local telephone company (charges may apply).

• Other electronic products can cause interference with your cordless telephone. Try installing your telephone as far away as possible from electronic devices wireless routers, radios, radio towers, pager towers, cellular telephones, intercoms, room monitors, televisions, personal computers, kitchen appliances and other cordless telephones.

• Your line cord might be malfunctioning. Try installing a new line cord.

My calls fade in and out while I am using my cordless handset.

• Other electronic products can cause interference with your cordless telephone. Try installing your telephone as far away from the following electronic devices as possible: wireless routers, radios, radio towers, pager towers, cellular telephones, intercoms, room monitors, televisions, personal computers, kitchen appliances and other cordless telephones.

• If your telephone is plugged in with a modem or surge protector, plug the telephone (or modem/surge protector) into a different location. If this solves the problem, re-locate your telephone or modem farther apart from one another, or use a different surge protector.

• Relocate your telephone base to a higher location. It will have better reception when installed in a high area.

• If the other telephones in your home are having the same problem, the problem is in your wiring or local service. Contact your local telephone company (charges may apply.)

Appendix

Troubleshooting

The CHARGING light is off.

My Caller ID is not working.

System does not receive CID or system does not display CID during Call Waiting.

Incomplete messages.

• Clean the cordless handset and charging contacts on the charger each month using a pencil eraser or cloth.

• Make sure the power and line cords are plugged in correctly and securely.

• Unplug the unit’s electrical power. Wait for 15 seconds, then plug it back in. Allow up to one minute for the cordless handset and telephone base to reset.

• Your telephone might be malfunctioning. Please refer to the Warranty section of this user’s manual for further instruction.

• Caller ID is a subscription service. You must subscribe to this service

from your local telephone company for this feature to work on your phone.

• Your caller must be calling from an area that supports caller ID.

• Both you and your caller’s telephone companies must use caller ID

compatible equipment.

• If a caller leaves a very long message, part of it may be lost when the

system disconnects the call after four minutes.

• If the caller pauses for more than seven seconds, the system stops

recording and disconnects the call.

• If the system’s memory becomes full during a message, the system

stops recording and disconnects the call.

• If the the caller's voice is very soft, the system may stop recording

and disconnects the call.

Difficulty hearing messages.

System does not answer after correct number of rings.

• Press VOLUME ^ to increase speaker volume.

• Remove any stickers that may have come on your telephone

base and/or handset when you purchased it, they may be obstructing your messages when you play them.

• Make sure that the answering system is on (see page 36).

• If Toll Saver is activated, the number of rings changes to two when

there are new messages waiting (see page 39).

• In some cases, the system may be affected by the ringing system

used by the local telephone company.

• If the memory is full or the system is off, the system will answer after

10 rings.

Appendix

Troubleshooting

System does not respond to remote commands.

System does not record message.

Announcement message is not clear.

Common cure for electronic equipment.

• Make sure to enter your remote access code correctly (see pages 39 and 43).

• Make sure you are calling from a touch-tone telephone. When dialing a number, you should hear tones. If you hear clicks, it is not a touchtone telephone and cannot activate the answering system.

• The answering system may not detect the remote access code while your announcement is playing. Try waiting until the announcement is over before entering the code.

• There may be noise or interference on the telephone line you are using. Press dial-pad buttons firmly.

• Make sure answering system is on (see page 36).

• When you record your announcement, make sure you speak in a normal tone of voice, about nine inches from the telephone base.

• Make sure there is no background noise (TV, music, etc.) while recording.

If the unit does not seem to be responding normally, try putting the

cordless handset in its charger. If it does not seem to respond, do the following (in the order listed):

• Disconnect the power to the telephone base.

• Disconnect the cordless handset battery, and spare battery, if applicable.

• Wait a few minutes.

• Connect power to the telephone base and charger.

• Re-install the telephone base and charger and place the cordless handset into the charger.

• Wait for the cordless handset to re-establish its connection with the base. To be safe, allow up to one minute for this to take place.

Appendix

Important safety instructions

This symbol is to alert you to important operating or servicing instructions that may appear in this user’s manual. Always follow basic safety precautions when using this product to reduce the risk of injury, fire, or electric shock.

Safety Information

• Read and understand all instructions in the user’s manual. Observe all markings on the product.

• Avoid using a telephone during a thunderstorm. There may be a slight chance of electric shock from lightning.

• Do not use a telephone in the vicinity of a gas leak. If you suspect a gas leak, report it immediately, but use a telephone away from the area where gas is leaking. If this product is a cordless model, make sure the base is also away from the area.

• Do not use this product near water, or when you are wet. For example, do not use it in a wet basement or shower, or next to a swimming pool, bathtub, kitchen sink, or laundry tub. Do not use liquids or aerosol sprays for cleaning. If the product comes in contact with any liquids, unplug any line or power cord immediately. Do not plug the product back in until it has dried thoroughly.

• Install this product in a protected location where no one can trip over any line or power cords. Protect cords from damage or abrasion.

• If this product does not operate normally, read “Troubleshooting” in the user’s manual. If you cannot solve the problem, or if the product is damaged, refer to the Limited Warranty. Do not open this product except as may be directed in your user’s manual. Opening the product or reassembling it incorrectly may expose you to hazardous voltages or other risks.

• If this product has user-replaceable batteries, replace batteries only as described in your user’s manual. Do not burn or puncture batteries — they contain caustic chemicals.

• If this product has a three-prong (grounding) plug or a polarized plug with one wide prong, it may not fit in non-polarized outlets. Do not defeat the purpose of these plugs. If they do not fit in your outlet, the outlet should be replaced by an electrician.

CAUTION: Use only the power adapter provided with this product. To obtain a replacement, call 1-800-222–3111.

In Canada, call 1-866-288-4268.

Appendix

Important safety instructions

Especially About Cordless Telephones

• Privacy: The same features that make a cordless phone convenient create some limitations. Telephone calls are transmitted between the base and the handset by radio waves, so there is a possibility that your cordless phone conversations could be intercepted by radio receiving equipment within range of the cordless handset.

For this reason, you should not think of cordless phone conversations as being as private as those on corded phones.

• Electrical Power: The base unit of this cordless telephone must be connected to a working electrical outlet. The electrical outlet should not be controlled by a wall switch. Calls cannot be made from the handset if the base unit is

unplugged or switched off, or if the electrical power is interrupted.

• Potential TV Interference: Some cordless telephones operate at frequencies that may cause interference to TVs and VCRs. To minimize or prevent such interference, do not place the base unit of the cordless telephone near or on top of a TV or VCR. If interference is experienced, moving the cordless telephone farther away from the TV or VCR will often reduce or eliminate the interference.

• Rechargeable Batteries: This product contains either Nickel-Cadmium or Nickel-Metal Hydride rechargeable batteries. Exercise care in handling batteries in order not to short the battery with conducting material such as rings, bracelets, and keys. The battery or conductor may overheat and cause harm. Observe proper polarity between the battery and the battery charger.

• Nickel-Cadmium Rechargeable Batteries: Must be recycled or disposed of properly. Do not dispose of in household garbage. Do not burn or puncture. Like other batteries of this type, if burned or punctured, they could release caustic material which could cause injury.

The RBRC™ Seal means that the manufacturer is voluntarily participating in an industry program to collect and recycle Nickel-Cadmium rechargeable batteries when taken out of service within the United States. These batteries may be taken to a participating local retailer of replacement batteries or recycling center. Or you may call 1 (800) 8 BATTERY for locations accepting spent Nickel-Cadmium Batteries. Nickel-Metal

Hydride Rechargeable Batteries: Dispose of these batteries in a safe manner. Do not burn or puncture. Like other batteries of this type, if burned or punctured, they could release caustic material which could cause injury.

• Nickel-Metal Hydride Rechargeable Batteries: Dispose of these batteries in a safe manner. Do not burn or puncture. Like other batteries of this type, if burned or punctured, they could release caustic material which could cause injury.

Appendix

Important safety instructions

Precautions for Users of Implanted Cardiac Pacemakers

Cardiac Pacemakers (applies only to 900 MHz Digital Cordless Telephones):

Wireless Technology Research, LLC (WTR), an independent research entity, led a multidisciplinary evaluation of the interference between portable wireless telephones and implanted cardiac pacemakers. Supported by the U.S. Food and Drug Administration, WTR had recommended to physicians that:

PACEMAKER PATIENTS

• Should keep wireless phones at least six inches from the pacemaker.

• Should NOT place wireless phones directly over the pacemaker, such as in a breast pocket, when it is turned ON.

• Should use the wireless phone at the ear opposite the pacemaker.

WTR’s evaluation did not identify any risk to bystanders with pacemakers from other persons using wireless phones.

Especially About Telephones Answering Systems

Two-Way Recording: This unit does not sound warning beeps to let the other party know that the call is being recorded. To ensure that you are in compliance with any federal or state regulations regarding recording a telephone call, you should start the recording process and then inform the other party that you are recording the call.

SAVE THESE INSTRUCTIONS

Appendix

FCC part 68 and ACTA

This equipment complies with Part 68 of the FCC rules and with technical requirements adopted by the Administrative Council for Terminal Attachments (ACTA). The label on the back or bottom of this equipment contains, among other things, a product identifier in the format US: AAAEQ##TXXXX. This identifier must be provided to your local telephone company upon request. The plug and jack used to connect this equipment to premises wiring and the telephone network must comply with applicable Part 68 rules and technical requirements adopted by ACTA. A compliant telephone cord and modular plug is provided with this product. It is designed to be connected to a compatible modular jack that is also compliant. An RJ11 jack should normally be used for connecting to a single line and an RJ14 jack for two lines. See Installation Instructions in the user’s manual. The Ringer Equivalence Number (REN) is used to determine how many devices you may connect to your telephone line and still have them ring when you are called. The REN for this product is encoded as the 6th and 7th characters following the US: in the product identifier (e.g., if ## is 03, the REN is 0.3). In most, but not all areas, the sum of all RENs should be five (5.0) or less. For more information, please contact your local telephone company. This equipment may not be used with Party Lines. If you have specially wired alarm dialing equipment connected to your telephone line, ensure the connection of this equipment does not disable your alarm equipment. If you have questions about what will disable alarm equipment, consult your telephone company or a qualified installer. If this equipment is malfunctioning, it must be unplugged from the modular jack until the problem has been corrected. Repairs to this telephone equipment can only be made by the manufacturer or its authorized agents. For repair procedures, follow the instructions outlined under the Limited Warranty. If this equipment is causing harm to the telephone network, the telephone company may temporarily discontinue your telephone service. The telephone company is required to notify you before interrupting service. If advance notice is not practical, you will be notified as soon as possible. You will be given the opportunity to correct the problem and the telephone company is required to inform you of your right to file a complaint with the FCC. Your telephone company may make changes in its facilities, equipment, operation, or procedures that could affect the proper functioning of this product. The telephone company is required to notify you if such changes are planned. If this product is equipped with a corded or cordless handset, it is hearing aid compatible. If this product has memory dialing locations, you may choose to store emergency telephone numbers (e.g., police, fire, medical) in these locations. If you do store or test emergency numbers, please:

• Remain on the line and briefly explain the reason for the call before hanging up.

• Perform such activities in off-peak hours, such as early morning or late evening.

Appendix

FCC part 15

This equipment has been tested and found to comply with the requirements for a Class B digital device under Part 15 of the Federal Communications Commission (FCC) rules. These requirements are intended to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to which the

receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

Changes or modifications to this equipment not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. To ensure safety of users, the FCC has established criteria for the amount of radio frequency energy that can be safely absorbed by a user or bystander according to the intended usage of the product. This product has been tested and found to comply with the FCC criteria. The handset may be safely held against the ear of the user. The base unit shall be installed and used such that parts of the user’s body other than the hands are maintained at a distance of approximately 20 cm (8 inches) or more. If you choose to use a clipping device, please make sure to only use the supplied AT&T belt clip.

Appendix

Limited warranty

The AT&T brands are used under license. Any repair, replacement or warranty service, and all questions about this product should be directed to: Advanced American Telephones, 1 (800) 222-3111 or www.telephones.att.com. In Canada, call 1 (866) 288-

4268.

1 What does this limited warranty cover?

The manufacturer of this AT&T-branded product, Advanced American Telephones

(“AAT”), warrants to the holder of a valid proof of purchase (“CONSUMER” or “YOU”) that the product and all accessories provided by AAT in the sales package (“PRODUCT”) are free from material defects in material and workmanship, pursuant to the following terms and conditions, when installed and used normally and in accordance with operation instructions. This limited warranty extends only to the consumer for products purchased and used in the United States of America.

2 What will AAT do if the product is not free from material defects in materials

and workmanship during the limited warranty period (“MATERIALLY DEFECTIVE PRODUCT”)?

During the limited warranty period, AAT’s authorized service representative will

repair or replace, at AAT’s option, without charge, a materially defective product. If AAT repairs this product, AAT may use new or refurbished replacement parts. If AAT chooses to replace this product, AAT may replace it with a new or refurbished product of the same or similar design. AAT will return repaired or replacement products to you in working condition.

AAT will retain defective parts, modules, or equipment. Repair or replacement of

product, at AAT’s option, is your exclusive remedy. You should expect the repair or replacement to take approximately 30 days.

3 How long is the limited warranty period?

The limited warranty period for the product extends for ONE (1) YEAR from the

date of purchase.

If AAT repairs or replaces a materially defective product under the terms of this

limited warranty, this limited warranty also applies to repaired or replacement products for a period of either (a) 90 days from the date the repaired or replacement product is shipped to you or (b) the time remaining on the original one-year limited warranty, whichever is longer.

Appendix

Limited warranty

4 What is not covered by this limited warranty?

This limited warranty does not cover:

• Product that has been subjected to misuse, accident, shipping or other physical damage, improper installation, abnormal operation or handling, neglect, inundation, fire, water, or other liquid intrusion; or

• Product that has been damaged due to repair, alteration, or modification by anyone other than an authorized service representative of AAT; or

• Product to the extent that the problem experienced is caused by signal conditions, network reliability or cable or antenna systems; or

• Product to the extent that the problem is caused by use with non-AAT accessories; or

• Product whose warranty/quality stickers, product serial number plates or electronic serial numbers have been removed, altered or rendered illegible; or

• Product purchased, used, serviced, or shipped for repair from outside the United States, or used for commercial or institutional purposes (including but not limited to products used for rental purposes); or

• Product returned without valid proof of purchase (see 6 below); or

• charges for installation or setup, adjustment of customer controls, and installation or repair of systems outside the unit.

5 How do you get warranty service?

To obtain warranty service in the United States of America, call 1 (800) 222-3111 (In

Canada, please dial 1 (866) 288-4268) for instructions regarding where to return the product. Before calling for service, please check the user’s manual. A check of the product controls and features may save you a service call.

Except as provided by applicable law, you assume the risk of loss or damage dur-

ing transit and transportation and are responsible for delivery or handling charges incurred in the transport of product(s) to the service location. AAT will return repaired or replaced product under this limited warranty to you, transportation, delivery or handling charges prepaid. AAT assumes no risk for damage or loss of the product in transit.

If the product failure is not covered by this limited warranty, or proof of purchase

does not meet the terms of this limited warranty, AAT will notify you and will request that you authorize the cost of repair prior to any further repair activity. You must pay for the cost of repair and return shipping costs for the repair of products that are not covered by this limited warranty.

Appendix

Limited warranty

6 What must you return with the product to get warranty service? You must:

a return the entire original package and contents including the product to the AAT

service location along with a description of the malfunction or difficulty;

b include “valid proof of purchase” (sales receipt) identifying the product purchased

(product model) and the date of purchase or receipt (keep a copy for your records); and

c provide your name, complete and correct mailing address, and telephone number.

7 Other limitations This warranty is the complete and exclusive agreement between you and AAT. It

supersedes all other written or oral communications related to this product. AAT provides no other warranties for this product. The warranty exclusively describes all of AAT’s responsibilities regarding the product. There are no other express warranties. No one is authorized to make modifications to this limited warranty and you should not rely on any such modification.

State Law Rights: This warranty gives you specific legal rights, and you may also have

other rights which vary from state to state. Limitations: Implied warranties, including those of fitness for a particular purpose and merchant-

ability (an unwritten warranty that the product is fit for ordinary use) are limited to

one year from date of purchase. Some states do not allow limitations on how long an implied warranty lasts, so the

above limitation may not apply to you. In no event shall AAT be liable for any indirect, special, incidental, consequential, or

similar damages (including, but not limited to lost profits or revenue, inability to use

the product, or other associated equipment, the cost of substitute equipment, and

claims by third parties) resulting from the use of this product. Some states do not allow the exclusion or limitation of incidental or consequential

damages, so the above limitation or exclusion may not apply to you.

Please retain your receipt as your proof of purchase.

Appendix

Index

AC adapter, 6, 8 Alert tones, 45 Answering calls, 15-16 Answering system, 36 announcements, 38 memos, 41 message playback, 40 remote access, 43

Battery charging, 7 Battery installation, 7 Belt clip, 9

Call waiting, 17, 35 Caller ID, 29 CID memory, 31 delete number, 33 delete records, 34 Conference calls, 18

Day and time, 37 Delete an entry, 28 Dialing, directory dialing, 27 from CID memory, 32 Directories, 22 enter a name, 25 enter a number, 26 search, 27 speed dial number, 23

Error tones, 22, 45

Flash, 17

Handset locator, 16 Headset, 9 Hold, 17

Intercom calls, 19-21 Indicator lights, 45

Last number redial, 15-16 Low battery, 7

Making calls, 15-16 Memos, 41 Message playback, 40 Message counter displays, 42 Mute, 17

Names, enter a name, 25 search for, 27

Outgoing announcement, 38

Playback, 40

Quick reference guide, 2-3

Recharging, 7 Redial, 15,16 Ring silencing, 15 Ringer tone, 12

Search for name, 27 Speaker, 16 Speed dialing, 23-24 Switchhook, 20,21

Technical specifications, 61 Troubleshooting, 46-51

Volume controls, 17

Appendix

Technical specifications

RF Frequency Band (Handset to Base)

RF Frequency Band (Base to Handset)

Channels 30

Modulation

Operating Temperature

Base Unit Voltage (AC Voltage, 60Hz)

Base Unit Voltage (DC Adapter Output)

Handset Voltage 3.1 — 4.3 Vdc @600 mAh

Charger Voltage (DC Adapter Output)

Replacement Battery Model 3301 (Part Number 80-5071-00-00)

5863.8MHz — 5872.5MHz

912.75MHz — 917.10MHz

32°F — 122°F 0°C – 50°C

104 — 129 Vrms

9 Vdc @500 mA

6 Vdc @200 mA

3.6V 600mAh Ni-Cd

Appendix

Remote access wallet card

Use the wallet card below to help you remember commands to control your answering system from any touch tone telephone.

Cut along dotted line

Call your phone number, then enter your 2-digit access code (preset to 19).

Fold card here

Action Remote Command

Play all messages ....................... 1

Play new messages ................... 2

Delete the message ................. 3

Delete all old messages .......... 33

Repeat a message ..................... 4

Stop ............................................. 5

Help menu ................................. *5

Skip the message ...................... 6

Record announcement............ *7

Turn system off/on ................... 0

End remote access call ............8 (or hang up)

5.8 GHz Corded/Cordless Telephone/Answering System E5908

www.telephones.att.com

AT&T and the Globe Design are trademarks of AT&T Corp.,

licensed to Advanced American Telephones. Printed in China. Issue 4 AT&T 05 /06. 91-000646-040-000

AT&T E5908 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
