User Manual (Part 2)
5.8 GHz Cordless
Speakerphone/
Answering System E5865
with Caller ID & Call Waiting
ATT-5865CIB-d5.qxd 1/3/2004 11:21 AM Page 1
Copyright © 2004 Advanced American Telephones. All Rights Reserved.
AT&T and the Globe Design are trademarks of AT&T Corporation.,
licensed to Advanced American Telephones.
STOP!
See page 7
for easy instructions
You must install and
charge the battery before
using the telephone
Add new handsets to make your phone more versatile (see page 46)
Your telephone can accommodate up to 8 cordless handsets. You can add new
handsets (sold separately) at any time. Up to 4 handsets at a time can be used.
The handset provided with your telephone is automatically registered as Handset 1.
Additional handsets will be assigned numbers in the order they are registered (2, 3, 4,
etc.) up to a maximum of 8 handsets.
Handset 1 Handset 2 Handset 3
For customer service or product
information, visit our web site at
www.telephones.att.com
or call
1-800-222-3111
Please also read
Important Product Information
Enclosed in product package
ATT-5865CIB-d5.qxd 1/3/2004 11:21 AM Page 2
1
Table of contents
User Manual (Part 2)
5.8 GHz Cordless
Speakerphone/
Answering System
E5865
Getting Started
Quick reference guide ........................2
Parts checklist .......................................4
Before you begin ..................................5
Telephone base installation................6
Battery installation & charging ..........7
Wall mounting ......................................8
Belt clip & optional headset...............9
Telephone Operation
Basic handset operation ...................10
Basic base operation .........................11
Options during calls ..........................12
Intercom calls .....................................13
Handset screen images.....................14
Handset sounds & alerts ..................15
Handset settings.................................16
Base settings........................................17
Handset Phonebook Directory
New phonebook entries..................19
Phonebook search.............................20
To dial, edit or delete entries.........21
Base Phonebook Directory
New phonebook entries..................23
Phonebook search.............................24
To dial, edit or delete entries.........25
Handset Calls Log
To review voice messages ...............27
To review Caller ID log ...................28
To dial a Caller ID entry..................29
To review redial log ..........................30
Base Caller ID & Redial
To review Caller ID log ...................32
To dial a Caller ID entry..................33
To review redial log ..........................34
Answering System Operation
Answering system operation ..........35
Day and time announcements ........36
Outgoing announcements................37
Announce Only mode ......................38
Changing feature options.................39
Message playback ...............................40
Recording and playing memos ........41
Message window displays.................42
Remote access....................................43
Appendix
Display screen status icons..............44
Alert tones & indicator lights..........45
Adding new handsets ........................46
Charging spare batteries ..................47
In case of difficulty .............................48
INDEX..................................................50
Technical specifications ....................52
Remote access wallet card ..............53
ATT-5865CIB-d5.qxd 1/3/2004 11:21 AM Page 1
2
Getting Started
NavKey
Press center button to display menus.
Press NavKey buttons to navigate
through menus. Press center button to
select menu item highlighted.
Quick reference guide
Speaker
Press to activate handset speakerphone. Press again to switch call back
to earpiece.
Softkeys
Press a softkey to select a menu item
displayed just above the key.
Off/Cancel
During a call, press to hang up.
While using menus, press to cancel an
operation, back up to the previous menu,
or exit the menu display.
Phone/Flash
Press to begin a call, then dial a number.
During a call, press to receive an incoming
call, if Call Waiting is activated (see page 12).
Sound Select
Press to customize speaker sound for
clear speakerphone conversations.
Handset
Intercom
See page 13 See page 18 See page 26 See page 14 See page 15 See page 16
Vibrate Ringer Control Ringers
Low Batt Tone Keypad Tone Range Tone
Clock On/Off Set Time Contrast
Phone Setup Language Reset Settings
Directory Calls Log Pictures Sounds&Alerts Settings
Main menu
Sounds & Alerts menu Settings menu
Left Right
Select
Up
Down
ATT-5865CIB-d5.qxd 1/3/2004 11:22 AM Page 2
3
Getting Started
Quick reference guide
Answering system controls (see pages 35-43)
ON/OFF ..................Press to turn answering system on or off
DELETE ..................Press to delete message currently playing
TIME SET................Press to set the answering system clock
MENU......................Press to review or change answering system options
CHANGE ................Press to change a menu option
RECORD ................Press to record a memo or outgoing announcement
Telephone function keys (see pages 11-13)
SOFTKEYS ............Press to select menu item displayed just above the key
CLEAR ....................Press to cancel an operation, back up to the
previous menu, or exit the menu display
INTERCOM ............Press to transfer a call or initiate an intercom conversation
FLASH ....................During a call, press to receive an incoming call, if
Call Waiting is activated
VOLUME ................Press to adjust speakerphone listening volume
MUTE ......................Press to silence microphone; press again to resume
SPEAKERPHONE ..Press to turn speakerphone on or off (begin or end a call)
Base/Speakerphone
Answering
system
controls
Telephone
function keys
Swivel antenna fully
upright for best results
REDIAL MENU MEM
Press to play or stop playing messages
Press to repeat message.
Press twice to hear
previous message.
Press to skip to next
message.
ATT-5865CIB-d5.qxd 1/3/2004 11:22 AM Page 3
4
Getting Started
Parts checklist
Remember to save your sales receipt and original packaging in case you ever need to
ship your telephone for warranty service. Check to make sure the telephone package
includes the following:
Telephone base
Telephone
handset
Power
adapter
Belt clip Battery compartment cover
Batteries
Long telephone line cord
Short telephone line cord
Wall mount bracket
ATT-5865CIB-d5.qxd 1/3/2004 11:23 AM Page 4
5
Getting Started
Before you begin
About Caller Identification
Caller ID with Call Waiting features in
this telephone let you see who’s calling
before you answer the phone, even
when you’re on another call. These
features require services provided by
your local telephone company.
Contact your telephone service
provider if:
• You have both Caller ID and Call
Waiting, but as separate services
(you may need combined service)
• You have only Caller ID service, or
only Call Waiting service
• You don’t subscribe to any Caller
ID or Call Waiting services.
You can use this phone with regular
Caller ID service, and you can use its
other features without subscribing to
either Caller ID or combined Caller ID
with Call Waiting service. There may
be fees for these services, and they
may not be available in all areas.
Caller ID features will work only if
both you and the caller are in areas
offering Caller ID service, and if both
telephone companies use compatible
equipment.
See Caller ID Operation, beginning on
page 28, for more details about how
these features work.
Telephone operating range
This cordless telephone operates with
the maximum power allowed by the
Federal Communications Commission
(FCC). Even so, this handset and base
can communicate over only a certain
distance — which can vary with the
locations of the base and handset, the
weather, and the construction of your
home or office. For best performance,
keep the base antenna fully upright.
If you receive a call while you are
out of range, the handset might not
ring — or if it does ring, the call might
not connect when you press PHONE.
Move closer to the base, then press
PHONE to answer the call.
If you move out of range during a
phone conversation, you might hear
noise or interference. To improve
reception, move closer to the base.
If you move out of range without
pressing OFF, your phone will be left
“off the hook.” To hang up properly,
walk back toward the telephone base,
periodically pressing OFF until the call
is disconnected.
ATT-5865CIB-d5.qxd 1/3/2004 11:23 AM Page 5
6
Getting Started
Telephone base installation
Install the speakerphone base as shown below. Choose a location away from electronic equipment, such as personal computers, television sets or microwave ovens. Avoid
excessive heat, cold, dust or moisture.
Plug power cord transformer into electrical outlet
Plug long telephone line cord into telephone jack
NOTE:
Use only the power
cord supplied with this product.
If you need a replacement, call
1 800 222–3111.
Be sure to use an electrical outlet
not controlled by a wall switch.
Route cords through slot in base
ATT-5865CIB-d5.qxd 1/3/2004 11:23 AM Page 6
DID YOU KNOW?
Optional spare batteries can be kept charged in
the base, for quick replacement when handset
batteries become depleted (see page47
7
Getting Started
Battery installation & charging
After installation, place the handset in the base and allow batteries to charge for 12
hours before use. You can keep batteries charged by returning the handset to the base
after each use. When battery power is fully depleted, a full recharge takes about 8 hours.
Place handset in base to charge
for 12 hours before first use.
Rotate antenna to fully upright
position
DID YOU KNOW?
Optional spare batteries can be kept charged in
the base, for quick replacement when handset
batteries become depleted (see page 47).
LOW BATTERY
REDIAL CID LOG
2:10 PM
1
Press coin into slot on
base of handset to
release latch, then
remove battery cover
Insert supplied
batteries
Low battery indicator
Return handset to base to recharge
when this symbol flashes. (Handset
will beep when battery is low.)
Caution: Use only AT&T 2AA
NiCad or NiMH rechargeable
batteries. Do not use AA
alkaline batteries.
Insert top
tab first
To replace battery cover
Press down to
click in place
ATT-5865CIB-d5.qxd 1/3/2004 11:23 AM Page 7
8
Getting Started
Wall mounting
The speakerphone base can be installed on any standard wall-phone outlet as shown
below. Choose a location away from electronic equipment, such as personal computers, television sets or microwave ovens. Avoid excessive heat, cold, dust or moisture.
Plug power cord transformer into electrical outlet
Connect cords as shown, then press and slide down firmly so base is held securely on outlet mounting pegs
Plug short telephone line cord into telephone jack
Clip wall-mount bracket securely into notches on underside of base
Place handset in base to charge
for 12 hours before first use.
Rotate antenna to fully upright position
ATT-5865CIB-d5.qxd 1/3/2004 11:23 AM Page 8
9
Getting Started
Belt clip & optional headset
Install belt clip as shown below if desired.
For hands-free telephone conversations, you can use any industry standard 2.5 mm
headset (purchased separately). For best results use an AT&T 2.5 mm headset.
Snap belt clip into notches on
side of handset. Rotate and pull
to remove.
Plug 2.5 mm headset
into jack on side of
handset (beneath
small rubber cap)
ATT-5865CIB-d5.qxd 1/3/2004 11:24 AM Page 9
10
Telephone Operation
Basic handset operation
Making and answering calls
To answer a call, press PHONE or any dial pad key. To
make a call, press PHONE, then dial a number. Press
OFF to hang up.
To preview numbers before dialing, enter numbers first,
then press PHONE to dial. Press the left NavKey to
make corrections as you are entering numbers. Press
PAUSE to add a 3-second dialing pause.
Hands-free speakerphone calls
To answer an incoming call, press SPEAKER. To make a
call, press SPEAKER, then dial a number. During a call
you can press SPEAKER to toggle between hands-free
speakerphone and normal handset use. Press OFF to
hang up.
Last number redial
Press REDIAL to display a list of numbers recently called.
Use the NavKey control to select a number, then press
PHONE to dial (see page 30 to delete the number, or
copy it to your phonebook).
Hold and mute
Press HOLD to place a call on hold. Press PHONE to
resume the call.
Press MUTE to silence the microphone. You will be able
to hear, but your caller will not be able to hear you
until you press MUTE again to resume speaking.
Call transfer
During a conversation you can transfer the call to the
base speakerphone (or to another handset if you have
more than one registered).
Press the middle NavKey button to display a list of sets.
Press NavKey buttons to highlight the set you want, then
press the middle NavKey button to transfer the call.
The call will be placed on hold. You can then press PHONE
(or SPEAKERPHONE at the base) to resume speaking.
Transfer Call
BASE
HANDSET 2
HANDSET 3
1
CALL ON HOLD
HOLD MUTE
2:10 PM
1 H
Press NavKey
REDIAL CID LOG
2:10 PM
1
ATT-5865CIB-d5.qxd 1/3/2004 11:24 AM Page 10
11
Telephone Operation
Basic base operation
Making and answering calls
To answer an incoming call, press SPEAKERPHONE. To
make a call, press SPEAKERPHONE, then dial a number.
Press SPEAKERPHONE again to hang up.
To preview numbers before dialing, enter numbers first,
then press SPEAKERPHONE to dial. Press CLEAR at any
time to make corrections as you are entering numbers.
Press PAUSE to add a 3-second dialing pause.
Last number redial
Press REDIAL to display a list of numbers recently called.
Use the NavKey control to select a number, then press
SPEAKERPHONE to dial (see page 34 to delete the
number, or copy it to your phonebook).
Hold and mute
Press HOLD to place a call on hold. Press SPEAKER-
PHONE to resume the call.
Press MUTE to silence the microphone. You will be able
to hear, but your caller will not be able to hear you
until you press MUTE again to resume speaking.
Call transfer
During a conversation you can transfer the call to a
handset.
Press XFER to display a list of registered handsets. Use
arrow buttons to highlight the set you want, then press
OK to transfer the call.
The call will be placed on hold. You can then press
PHONE or SPEAKER at the handset to resume speaking.
8 NEW CALLS
REDIAL MENU MEM
CALL ON
HOLD
XFER HOLD MUTE
PHONE ON
XFER HOLD MUTE
HANDSET 1
HANDSET 2
HANDSET 3
^
OK
V
Volume
Speakerphone
ATT-5865CIB-d5.qxd 1/3/2004 11:24 AM Page 11
12
Telephone Operation
Options while on calls
To adjust volume or sound quality
Press VOLUME buttons on the handset or the base to
adjust listening volume. Each button press raises or
lowers volume by one level.
During a handset call you can press SOUND SELECT to
change sound quality. You can choose Natural Audio,
Bass Boost, Mid Boost or Treble Boost. Each button
press changes to the next tone type.
Call waiting
If you have Call Waiting service, you will hear a beep if
someone calls while you are already on a call. Press
FLASH to put your current call on hold and take the new
call. You can press FLASH at any time to switch back
and forth between calls.
Ring silencing
Press OFF while the handset is ringing (or MUTE while
the base is ringing) to silence the ringer. You can still
answer, or let the caller leave a message.
3-way conference calls
During an outside call, you can use both the handset and
base (or two local handsets) to allow a 3-way
conversation.
While a call is in progress, others can press PHONE (or
SPEAKERPHONE at the base) to join the conference call.
Others can press OFF (or SPEAKERPHONE at the base)
to drop out of the conference call, but the call will not
be terminated until all sets hang up.
Temporary tone dialing
If you have dial pulse (rotary) service, you can switch to
touch tone dialing during a call by pressing
*. This
can be useful if you need to send tone signals for access
to answering systems or long-distance services.
Volume
Silence ringer
Sound quality
Flash
Tone
Flash
Volume
Mute
Tone
ATT-5865CIB-d5.qxd 1/3/2004 11:24 AM Page 12
13
Telephone Operation
Intercom calls
Intercom calls
The intercom allows conversation between the handset
and base, or between handsets if you have registered
additional handsets for use with your system.
Use the NavKeys to select INTERCOM at the handset,
or press the INTERCOM button on the base.
Press the INTERCOM button at a handset or at the base.
Scroll down to select a station, or select GLOBAL PAGE
to page all stations. Press the middle NavKey button (or
OK at the base) to page the selected station.
At a handset, press PHONE to answer an intercom page.
At the base, the phone will ring once, then answer the
intercom page automatically.
When your intercom call is finished, press OFF at the
handset (or INTERCOM at the base) to end the call.
Handling incoming calls
The phone will beep if you receive an outside call during
an intercom conversation.
• At the handset, press PHONE to terminate the
intercom call and answer the incoming call.
• At the base, press INTERCOM to terminate the
intercom call, then press SPEAKERPHONE to
answer the incoming call.
To allow the outside caller to join your intercom
call, press SPEAKERPHONE without terminating the
intercom call.
Intercom Call
Base
GLOBAL PAGE
1
Press base Intercom button
Intercom
1
Select Intercom
Display menu
HANDSET 1
GLOBAL PAGE
^
OK
V
ATT-5865CIB-d5.qxd 1/3/2004 11:25 AM Page 13
14
Telephone Operation
Handset screen images
This feature allows you to select an image or design as
“wallpaper” to be displayed in the background of your
handset display screen.
Press the middle NavKey button to display the menu,
use navigation buttons to highlight PICTURES, then
press the middle button again to select this option.
Choose a category (Images or Emotions), then use the
NavKey buttons to display the available graphics. Press
SET to select an image.
To remove an image from your screen, use the NavKey
buttons to select CLEAR WALLPAPER, then press the
middle NavKey button.
Intercom
1
Display menu
Pictures
1
Select Pictures
Choose category
Browse images
Pictures
Images
Emotions
Clear Wallpaper
1
Images
SET
1 of 16
1
Press SET to select
desired image
ATT-5865CIB-d5.qxd 1/3/2004 11:25 AM Page 14
15
Telephone Operation
Handset sounds & alerts
Note: After selecting any option below, press the
middle Navkey button to confirm your choice.
Vibrate (silent call alerting)
When on, the phone vibrates to signal an incoming call
or intercom page. This can be useful in situations where
ring tones are undesirable, or in noisy environments
where ringing may not be heard. Changing the Vibrate
setting does not affect the ringer.
Ringer control
At this menu you can set a default ring volume level (1-
5), or turn the ringer off.
Ringers
This feature allows you to customize the incoming call
alerter. The menu includes options for 8 ringer styles
and 6 musical passages. You will hear an example of
each ringing type as you scroll through the choices.
Low battery tone
The handset is factory programmed to alert you with a
tone when the battery is low and needs recharging. You
can turn this alert on or off at this menu.
Keypad tone
The handset is factory programmed to beep at each
keypress. You can turn the keypad tones on or off at
this menu.
Out-of-range tone
The handset is factory programmed to alert you with a
tone when the handset is too far from the base, to
remind you to move closer. You can turn this alert on
or off at this menu.
Sounds & Alerts
1
Vibrate
1
Select Sounds&Alerts
Options: On/Off
Ringer Control
1
Volume Level: 1 to 5
Ringer: On/Off
Ringers
1
Choose 1 of 14 ringer types
Low Batt Tone
1
Options: On/Off
Keypad Tone
1
Options: On/Off
Range Tone
1
Options: On/Off
ATT-5865CIB-d5.qxd 1/3/2004 11:27 AM Page 15
16
Telephone Operation
Handset settings
Note: After selecting any option below, press the
middle Navkey button to confirm your choice.
Clock On/Off
At this menu you can choose to turn the handset time
display on or off.
Set time
Select this menu to set the time displayed on screen.
You must enter four digits (09:23). Using the NavKey,
press the DOWN button, then use LEFT/RIGHT buttons
to set AM or PM. After you set the handset time once,
it will thereafter be set automatically with incoming
Caller ID information if you have this service (see page 5).
Contrast
At this menu you can adjust screen contrast to one of
eight levels to maximize readability in different lighting
conditions.
Phone setup
Choose this option to register a new handset or select
dialing mode. To register, you must enter the 15-digit
ID number of the base. (To find this number, go to the
base, press MENU, scroll down to select DISPLAY BASE
ID, then press OK.)
The phone is preset at the factory to use TONE dialing.
You should change it to PULSE only if you do not have
touch-tone dialing service.
Language
At this menu you can select the language used in all
menus and screen displays. Choices are English,
Español, Français.
Reset Settings
At this menu you can delete all entries from your handset phonebook, or restore all factory default settings.
Settings
1
Clock On/Off
1
Select Settings
Turn clock display on/off
Set Time
1
Set time
Contrast
1
Adjust screen contrast
Phone Setup
1
Enter base ID to register handset
Choose Tone or Pulse dialing
Language
1
Choose screen display language
Reset Settings
1
Clear phonebook
Restore factory default settings
ATT-5865CIB-d5.qxd 1/3/2004 11:28 AM Page 16
17
Telephone Operation
Base settings
Note: After selecting any option below, press the
middle Navkey button to confirm your choice.
Ringer volume
At this menu you can set a default ring volume level
(1-6), or turn off the ringer.
Ringer melody
This feature allows you to customize the incoming call
alerter. The menu includes options for 8 ringing styles.
You will hear an example of each ringing style as you
scroll through the choices.
Number announce
If you have Caller ID service, you will hear a caller’s
telephone number spoken after the first ring. You can
turn this feature on or off at this menu.
Keypad tone
The handset is factory programmed to beep at each
keypress. You can turn the keypad tones on or off at
this menu.
Tone/pulse
Factory default setting is TONE. Change this to PULSE
only if you do not have touch-tone dialing service.
Contrast
At this menu you can adjust screen contrast to one of
16 levels to maximize readability in different lighting
conditions.
Language
At this menu you can select the language used in all
menus and screen displays. Choices are English, Spanish,
French.
8 NEW CALLS
REDIAL MENU MEM
CALLS LOG
BASE SETTINGS
DISPLAY BASE-ID
^
OK
V
RINGER VOLUME
RINGER MELODY
NUMBER ANNOUNCE
KEYPAD TONE
^
OK
V
Set ringer volume (levels 1-6/Off)
RINGER VOLUME
RINGER MELODY
NUMBER ANNOUNCE
KEYPAD TONE
^
OK
V
Set ringing style (8 choices)
RINGER VOLUME
RINGER MELODY
NUMBER ANNOUNCE
KEYPAD TONE
^
OK
V
Options: on/off
KEYPAD TONE
TONE/PULSE
CONTRAST
LANGUAGE
^
OK
V
Options: tone/pulse dialing
KEYPAD TONE
TONE/PULSE
CONTRAST
LANGUAGE
^
OK
V
Set contrast (levels 1-16)
KEYPAD TONE
TONE/PULSE
CONTRAST
LANGUAGE
^
OK
V
Options: English/Spanish/French
ATT-5865CIB-d5.qxd 1/3/2004 11:28 AM Page 17
18
Handset Phonebook
Memory capacity
There are separate phonebook directories in the handset and the base. Each phonebook can store up to 50
entries. Each entry can contain a number up to 32 digits,
and a name up to 16 letters long.
If you subscribe to Caller ID service from your local
telephone company, you can select a picture to be displayed with each phonebook entry. You can also select
a distinctive ringing type for each entry, so you know
who is calling. A convenient search feature can help you
find and dial numbers quickly (see page 20).
Timeouts and error tones
If you pause for too long while making an entry the
Phonebook will time out and you will have to begin
again.
If all memory locations are in use, an error tone will
sound when you attempt to enter a new number. This
means the memory is full, and you will not be able to
store a new number until you delete an existing one.
Directory
1
ATT-5865CIB-d5.qxd 1/3/2004 11:28 AM Page 18
19
Handset Phonebook
New phonebook entries
To enter a name
Press dial pad buttons once for the first letter, twice for
the second, three times for the third. Continue for
lower-case letters. To enter a number, continue
pressing the button until the number appears.
The cursor moves to the right when you press another
dial pad button or the RIGHT NavKey button (press
twice to enter a space). When the name is complete,
press OK.
• Press the <-- button to erase letters if you make a
mistake.
• Press 1 repeatedly to enter an ampersand (&),
apostrophe ('), comma (,), period (.), or numeral (1).
To enter a number
Use the dial pad to enter up to 32 digits. When the
number is complete, press OK.
• Press the <-- button to erase numbers if you make a
mistake.
• To enter a 3-second dialing pause, press and hold
# until “P” appears.
Customizing entries
Press the DOWN NavKey button, then LEFT or RIGHT
to choose a distinctive RINGER (see page 15). If you
have Caller ID service, the ringer you assign will alert
you when this person calls.
Press the DOWN NavKey button, then LEFT or RIGHT
to insert a PICTURE into this entry (see page 14).
Press SAVE to save your new entry (or press CANCEL
to discard changes and exit).
Press once
to enter “A” (4 times for “a”)
Press twice
to enter “B” (5 times for “b”)
Press 3 times
to enter “C” (6 times for “c”)
Press 7 times
to enter “2”
2
Select Directory
Directory
Enter Name
Pat Johnson
OK <—
1
Directory
Enter Number
1235556789
OK <—
1
Pat Johnson
123-555-6789
Ringer: < Default >
Picture: < [none] >
SAVE <—
Press SAVE to complete entry,
or down NavKey to customize
entry with ringer or picture
Pat Johnson
123-555-6789
Ringer: < Melody 1>
Picture: < [none] >
SAVE <—
Pat Johnson
123-555-6789
Ringer: Melody 1
Ringer:
Picture:
SAVE <—
Pat Johnson
123-555-6789
Ringer: Melody 1
Picture:
EDIT NEW
Directory
Alice
Bob
Chris
Deborah
FIND NEW
1 of 37
1
ATT-5865CIB-d5.qxd 1/3/2004 11:28 AM Page 19
20
Handset Phonebook
Phonebook search
You can use the NavKey buttons to browse through
the phonebook, or search to find a specific entry. You
can press CANCEL at any time to exit the directory.
To browse through the directory
To browse, press UP or DOWN NavKey buttons to
scroll through all entries one by one.
To search alphabetically
To shorten your search, press FIND, then use the telephone dial pad to enter the first letter of a name. When
you press OK, the first name beginning with that letter
will be displayed.
Press dial pad buttons once for the first letter, twice for
the second, three times for the third, as shown on the
previous page.
For example, press 5 (JKL) once to find Jack, twice to
find Kristen, or three times to find Linda.
To call a displayed number
When you find the entry you want, press PHONE (or
SPEAKER) to dial.
To modify the entry, press the middle NavKey button,
then select EDIT (see next page).
Directory
1
Select Directory
Directory
Alice
Bob
Chris
Deborah
FIND NEW
1 of 37
1
Directory
Search For
J
OK <—
1
5
Directory
Jack
Jennifer
John
Kristen
FIND NEW
8 of 37
1
Jack
123-555-4321
Ringer: < Default >
Picture: < [none] >
EDIT DELETE
8 of 37
ATT-5865CIB-d5.qxd 1/3/2004 11:29 AM Page 20
21
Handset Phonebook
To dial, edit or delete entries
To edit a listing
When any phonebook entry is displayed, press EDIT to
modify the entry. You can change the name, number,
distinct ringer setting or picture by following the steps
on page 19.
To dial a number
Press PHONE (or SPEAKER) to dial the displayed number.
To delete an entry
Press DELETE to delete the displayed entry from the
phonebook. Press YES to confirm. Press NO to return
to previous display. Once deleted an entry cannot be
recovered.
Directory
1
Select Directory
Directory
Alice
Bob
Chris
Deborah
FIND NEW
1 of 37
1
ALICE
555-4321
Ringer: Melody 1
Picture:
EDIT DELETE
1 of 37
Press EDIT to change entry
ALICE
555-4321
Ringer: Melody 1
Picture:
EDIT DELETE
1 of 37
Press DELETE to delete entry
Are you sure?
YES NO
Press YES to confirm
ALICE
555-4321
Ringer: Melody 1
Picture:
EDIT DELETE
1 of 37
Press PHONE to dial entry
ATT-5865CIB-d5.qxd 1/3/2004 11:29 AM Page 21
22
Base Phonebook
Memory capacity
There are separate phonebook directories in the handset and the base. Each phonebook can store up to 50
entries. Each entry can contain a number up to 32 digits,
and a name up to 16 letters long. A convenient search
feature can help you find and dial numbers quickly (see
page 24).
Timeouts and error tones
If you pause for too long while making an entry, the
Phonebook will time out and you will have to begin
again.
If all memory locations are in use, an error tone will
sound when you attempt to enter a new number. This
means the memory is full, and you will not be able to
store a new number until you delete an existing one.
REDIAL MENU MEM
ATT-5865CIB-d5.qxd 1/3/2004 11:29 AM Page 22
23
Base Phonebook
New phonebook entries
To enter a number
Use the dial pad to enter up to 32 digits. When the
number is complete, press MEM.
• Press CLEAR to erase numbers if you make a mistake.
• Press PAUSE to enter a 3-second dialing pause.
To enter a name
Press dial pad buttons once for the first letter, twice for
the second, three times for the third. Continue for
lower-case letters. To enter a number, continue pressing the button until the number appears.
The cursor moves to the right when you press another
dial pad button or the > button. Press > twice to
enter a space.
• Press CLEAR to erase letters if you make a mistake.
• Press 1 repeatedly to enter an ampersand (&),
apostrophe ('), comma (,), period (.), or numeral (1).
Storing the entry
Press SAVE to store your new phonebook entry. To
change it later, see page 25.
Press once to enter “A” (4 times for “a”)
Press twice
to enter “B” (5 times for “b”)
Press 3 times
to enter “C” (6 times for “c”)
Press 7 times to enter “2”
2
555-1234
PAUSE MENU MEM
ENTER NAME
PAT WILLIAMS
CLEAR SAVE
>
ENTRY HAS BEEN
STORED!
PAUSE MENU MEM
Enter number, then press MEM
Enter name, then press SAVE
ATT-5865CIB-d5.qxd 1/3/2004 11:29 AM Page 23
24
Base Phonebook
Phonebook search
You can use the ^V buttons to browse through the
phonebook, or search to find a specific entry. Press and
hold CLEAR at any time to exit the directory.
To browse through the directory
To browse, press ^ or V to scroll through all
entries one by one.
To search alphabetically
To shorten your search, press FIND, then use the telephone dial pad to enter the first letter of a name. When
you press FIND again, the first name beginning with that
letter will be displayed.
Press dial pad buttons once for the first letter, twice for
the second, three times for the third, as shown on the
previous page.
For example, press 5 (JKL) once to find Jack, twice to
find Kevin, or three times to find Linda.
To call a displayed number
When you find the entry you want, press SPEAKER-
PHONE to dial. Or press EDIT to modify the entry (see
next page).
REDIAL MENU MEM
^
FIND
V
JACK
123-555-1234
^
EDIT
V
SEARCH FOR
J_
CLEAR FIND
Use up/down arrow keys to
search for next/previous names
ATT-5865CIB-d5.qxd 1/3/2004 11:29 AM Page 24
25
Base Phonebook
To dial, edit or delete entries
To edit a listing
When any phonebook entry is displayed, press EDIT. At
the next screen, press EDIT again, then choose NAME
or NUMBER. You can change the name or number by
following the steps on page 23.
To dial a number
Press SPEAKERPHONE to dial the displayed number.
To delete an entry
At the Edit menu, press DEL to display options:
• To delete only the displayed entry, press THIS.
• To delete all entries in the phonebook, press ALL .
To confirm your choice, press YES at the
confirmation screen, and all entries will be deleted.
Once deleted, entries cannot be recovered.
Press EDIT to modify or delete
Press SPEAKERPHONE to dial entry
REDIAL MENU MEM
^
FIND
V
ALLISON
555-4321
^
EDIT
V
ALLISON
555-4321
^
EDIT
V
Press
DEL
to delete entry
Press
EDIT
to change entry
Press
NAME
to change name
Press
NUMBER
to change number
ALLISON
555-4321
DEL EDIT
ATT-5865CIB-d5.qxd 1/3/2004 11:30 AM Page 25
26
Calls Log
1
Handset Calls Log
The Calls Log keeps track of calls you’ve made and
received, and even lets you check voice messages from
your handset.
Use the NavKey controls to select Calls Log, then
make a selection from the list displayed:
Review Messages (see next page)
Play or delete voice messages.
Review CID Log (see page 28)
If you have Caller ID service, you can review the CID
Log to find out who has called, return the call without
dialing, or transfer the caller’s name and number into
your phone directory.
Clear CID Log (see page 28)
Use this command to delete all entries in your Caller
ID Log.
Review Redial (see page 30)
This screen shows a list of the most recent 10 numbers
you’ve dialed. You can redial any number, delete it from
the redial log, or copy it to your phonebook.
Clear Redial (see page 30)
Use this command to delete all recently called numbers
from your Redial list.
Calls Log
Review Messages
Review CID Log
Clear CID Log
Review Redial
Clear Redial
1
Calls Log
1
Select Calls Log
ATT-5865CIB-d5.qxd 1/3/2004 11:30 AM Page 26
27
Handset Calls Log
Review voice messages
At this menu you can use your handset to hear your
memos, or voice messages callers have left in your base
answering system (see pages 35-43).
Playback options
At the Messages screen, use the NavKey to control
message playback:
• Press the LEFT NavKey to repeat the message currently playing. Press twice to hear previous message.
• Press the RIGHT NavKey to skip forward to the next
message.
At the handset, voice messages are played through the
speakerphone. If you prefer to listen privately, you can
press SPEAKER to switch to earpiece playback.
To delete a message, press DELETE while the message
is playing.
Press EXIT to halt playback and exit the Messages menu.
Announcements
• When playback begins, you will hear the total
number of messages.
• Before each message, you will hear the day and time
it was received.
• After the last message, you will hear “End of
messages.”
Calls Log
Review Messages
Review CID Log
Clear CID Log
Review Redial
Clear Redial
1
Calls Log
1
Select Calls Log
Messages
EXIT DELETE
2:10 PM
1
Repeat Skip
Delete
Exit
NEW MESSAGES
MSGS 2:10 PM CID LOG
The screen alerts you when
you have new messages.
Press MSGS to hear them.
ATT-5865CIB-d5.qxd 1/3/2004 11:30 AM Page 27
28
Handset Calls Log
To review your call log
How Caller ID works
If you subscribe to Caller ID service, information about
each caller will be displayed after the first ring.
You can review the log to find out who has called,
return the call without dialing, or transfer the caller’s
name and number into your phonebook.
The call log can store up to 50 entries. Calls are displayed in reverse order (most recent first). When the
log is full, the oldest entry is deleted to make room for
new incoming call information.
If you answer a call before the information appears on
the screen, it will not be saved in your call log.
Names of callers are displayed only if the information is
provided by your local telephone company. If the telephone number of the person calling matches a number
in your phonebook, the name shown on screen will
match the name you entered into your phonebook.
(Example: If "Christine Smith" calls, her name will
appear as "Chris" if this is how you entered it.)
To review your Caller ID log
The most recent call is displayed first. Use the NavKey
buttons to scroll through the list as shown at left.
To return a call
Press PHONE (or SPEAKER) to call the person currently
displayed (see page 29 for important dialing options).
To save or delete an entry
Press SAVE to copy the displayed information into your
phonebook (see page 19). Press DELETE to delete this
entry from your CID log.
To delete all entries
To clear the Caller ID log of all entries, return to the
Calls Log menu, then use the NavKey controls to scroll
down and select CLEAR CID LOG. To confirm, press YES.
Calls Log
Review Messages
Review CID Log
Clear CID Log
Review Redial
Clear Redial
1
Calls Log
1
Select Calls Log
Chris Thompson
123-555-6789
11:29 AM Oct. 20
SAVE DELETE
1 of 32
Save entry in
phonebook
Delete entry
Calls Log
Review Messages
Review CID Log
Clear CID Log
Review Redial
Clear Redial
1
Display previous entry
Display next entry
ATT-5865CIB-d5.qxd 1/3/2004 11:31 AM Page 28
29
Handset Calls Log
To dial a call log entry
When any Caller ID screen is displayed, press PHONE
(or SPEAKER) to dial the number exactly as it appears
on the screen.
Dialing options
Caller ID numbers may appear with an area code that
may not be required for local calls. If the number
displayed is not in the correct format, you can change
how it is dialed.
Press the middle NavKey button to see a list of dialing
options. Press the UP or DOWN NavKey buttons to
select the option you want. To dial it, press the middle
NavKey button again.
Chris Thompson
123-555-6789
11:29 A Oct 20
SAVE DELETE
1 of 32
Chris Thompson
123-555-6789
11:29 A Oct 20
SAVE DELETE
1 of 32
Dial Options
555-6789
1-555-6789
123-555-6789
1-123-555-6789
1
Select desired option,
then press to dial
ATT-5865CIB-d5.qxd 1/3/2004 11:31 AM Page 29
30
Handset Calls Log
To review your redial log
About the redial memory
You can review the redial log to see what numbers
you’ve recently called, redial, or copy the number into
your phonebook.
The handset remembers the last 10 numbers you call.
Each time you make a call the oldest entry is deleted to
make room for a new one.
To review your redial log
The most recent call is displayed first. Use the
UP/DOWN NavKey buttons to scroll through the list as
shown at left.
To redial a call
Press PHONE (or SPEAKER) to redial the number
currently displayed.
To save or delete an entry
Press SAVE to copy the highlighted number into your
phonebook (see page 19).
Press DELETE to delete this entry from your redial log.
To delete all entries
To clear the redial log of all entries, return to the Calls
Log menu, then use the
DOWN NavKey button to scroll
down and select CLEAR REDIAL. To confirm, press YES.
Calls Log
Review Messages
Review CID Log
Clear CID Log
Review Redial
Clear Redial
1
Calls Log
1
Select Calls Log
123-555-6789
555-1234
123-555-4321
555-4321
SAVE DELETE
1 of 10
Display previous entry
Save entry in
phonebook
Delete entry
Redial
1
Display next entry
Calls Log
Review Messages
Review CID Log
Clear CID Log
Review Redial
Clear Redial
1
ATT-5865CIB-d5.qxd 1/3/2004 11:31 AM Page 30
31
Base CID & Redial
The memory in the telephone base keeps track of calls
you’ve made and received. Use the softkeys beneath
the display screen to select REDIAL (for a list of
outgoing calls) or MENU, then CALLS LOG (for a list of
incoming calls).
Calls Log (see page 32)
If you have Caller ID service, you can review the Calls
Log to find out who has called, return the call without
dialing, or transfer the caller’s name and number into
your phone directory.
Review Redial (see page 34)
This screen shows a list of the most recent 10 numbers
you’ve dialed. You can call the number again without
dialing, or copy the number into your phone directory.
32 NEW CALLS
REDIAL MENU MEM
32 NEW CALLS
REDIAL MENU MEM
CALLS LOG
BASE SETTINGS
DISPLAY BASE-ID
^
OK
V
Display redial log
Display calls log
ATT-5865CIB-d5.qxd 1/3/2004 11:31 AM Page 31
32
Base Calls Log & Redial
To review your call log
How Caller ID works
If you subscribe to Caller ID service, information about
each caller will be displayed after the first ring.
You can review the log to find out who has called,
return the call without dialing, or transfer the caller’s
name and number into your phonebook.
The call log can store up to 50 entries. Calls are displayed in reverse order (most recent first). When the
log is full, the oldest entry is deleted to make room for
new incoming call information.
If you answer a call before the information appears on
the screen, it will not be saved in your call log.
Names of callers are displayed only if the information is
provided by your local telephone company. If the telephone number of the person calling matches a number
in your phonebook, the name shown on screen will
match the name you entered into your phonebook.
(Example: If "Christine Smith" calls, her name will
appear as "Chris" if this is how you entered it.)
To review your call log
The most recent call is displayed first. Use the arrow
buttons to scroll through the list as shown at left.
To return a call
Press SPEAKERPHONE to call the person currently
displayed (see page 33 for important dialing options).
To save or delete an entry
Press SAVE to copy the displayed information into your
phonebook (see page 23).
Press DEL to choose an option. Select THIS to delete
the entry displayed, or ALL to clear the Caller ID log of
all entries (to confirm, press YES).
32 NEW CALLS
REDIAL MENU MEM
CALLS LOG
BASE SETTINGS
DISPLAY BASE-ID
^
OK
V
Chris Thompson
123-555-6789
11:29 A Oct 20 #01
^
CID
V
Chris Thompson
123-555-6789
11:29 A Oct 20 #01
DEL OPT # SAVE
Display
previous
entry
Display
next
entry
Delete entry
(or all entries)
Copy entry to
phonebook
ATT-5865CIB-d5.qxd 1/3/2004 11:31 AM Page 32
33
Base Calls Log & Redial
To dial a call log entry
When any Caller ID screen is displayed, press
SPEAKERPHONE to dial the number exactly as it
appears on the screen.
Dialing options
Caller ID numbers may appear with an area code that
may not be required for local calls. If the number
displayed is not in the correct format, you can change
how it is dialed.
Select CID, then OPT # to see a list of dialing options.
Press V or ^ to highlight the option you want, then
press DIAL.
Chris Thompson
123-555-6789
11:29 A Oct 20 #01
^
CID
V
Chris Thompson
123-555-6789
11:29 A Oct 20 #01
DEL OPT # SAVE
555-6789
1-555-6789
123-555-6789
1-123-555-6789
^
DIAL
V
Select desired option,
then press to dial
ATT-5865CIB-d5.qxd 1/3/2004 11:31 AM Page 33
34
Base Calls Log & Redial
To review your redial log
About the redial memory
You can review the redial log to see what numbers
you’ve recently called, redial, or copy the number into
your phonebook.
The handset remembers the last 10 numbers you call.
Each time you make a call the oldest entry is deleted to
make room for a new one.
To review your redial log
The most recent call is displayed first. Use the arrow
keys to scroll through the list as shown at left.
To redial a call
Press SPEAKERPHONE to redial the number currently
displayed.
To save or delete an entry
Press SAVE to copy the highlighted number into your
phonebook (see page 23).
Press ERASE to delete this entry from your redial log.
REDIAL MENU MEM
123-555-6789
555-1234
123-555-4321
^
SELECT
V
123-555-6789
555-1234
123-555-4321
ERASE SAVE
Display
previous
entry
Display
next
entry
Delete entry Save entry in
phonebook
ATT-5865CIB-d5.qxd 1/3/2004 11:31 AM Page 34
35
Answering System Operation
Message capacity
The answering system can record up to 99
messages, depending on how long each message is.
Individual messages can be up to 4 minutes long, but
total maximum recording time is 25 minutes. Messages
will remain available for replay until you delete them.
Handset access
In addition to the features described in this section, you
can also use your handset to review or delete messages
(see page 27).
14
Message counter
Number of messages waiting
(or, during playback, message
number currently playing)
Press repeatedly to hear
feature options (see page 39)
Press to select or change a
feature option (see page 39)
Press to set clock
(see page 36)
Press to record memo (see page 41)
or outgoing announcement (page 37)
Press to delete message
(see page 40)
Press to repeat message;
hold to slow playback
(see page 40)
Press to skip message;
hold to speed up playback
(see page 40)
Press to start or stop message
playback (see page 40)
Press to turn answering
system on or off
ATT-5865CIB-d5.qxd 1/3/2004 11:32 AM Page 35
36
Answering System Operation
Day and time announcements
To set day and time
Before playing each message, the answering system
announces the day and time the message was received.
Before using the answering system, you should follow
the steps at left to set the day and time, so messages
are dated correctly.
The system uses voice prompts to guide you. Each time
you press CHANGE, the day, hour, minute or year
advances by one. When you hear the correct setting,
press TIME SET to move to the next setting.
To check day and time
You can press TIME SET at any time to hear the
current day and time without changing it.
1
TIME SET
“Friday, 10:07 am, 2003”
8
TIME SET
“2003”
10
@TIME SET
“Monday, 2:26 pm, 2004”
“To change clock,
press Time Set”
2
TIME SET
“Friday”
3
CHANGE
“Monday”
Press until correct day is spoken
4
TIME SET
“10 am”
5
CHANGE
“2 pm”
Press until correct hour is spoken
6
TIME SET
“07”
7
CHANGE
“26”
9
@CHANGE
“2004”
Press until correct minute is spoken
Press until correct year is spoken
NOTE:
Press and hold
CHANGE
to advance the minute or year by 10.
ATT-5865CIB-d5.qxd 1/3/2004 11:32 AM Page 36
37
Answering System Operation
Outgoing announcements
Outgoing announcements are the messages callers hear
when calls are answered by the answering system.
The phone is pre-programmed with an announcement
that answers calls with “Hello. Please leave a message
after the tone.” You can use this announcement, or
replace it with a recording of your own voice.
To record your outgoing announcement
Press MENU until you hear “Change announcement.”
Then press RECORD and begin speaking after you hear
“Now recording.” Speak facing the telephone base from
about 9 inches away.
Elapsed time (in seconds) will be shown in the message
window as you record. You can record an announcement up to 90 seconds long. Announcements less than 3
seconds long will not be recorded.
To delete your outgoing announcement
Press MENU until you hear “Change announcement,”
then press PLAY/STOP to begin playback. Press DELETE
during playback to delete your announcement.
When your announcement is deleted, calls will be
answered with the pre-programmed announcement
described above.
1
MENU
“Change
announcement”
2
(Plays announcement
previously recorded)
2
RECORD
“Now recording...”
3
4
(Announcement is
played back)
Speak into microphone
Microphone
Or
12
Elapsed
recording time
(seconds)
Press to stop
recording
(Play/Stop)
(Play/Stop)
ATT-5865CIB-d5.qxd 1/3/2004 11:32 AM Page 37
38
Answering System Operation
Announce Only mode
In Announce Only mode, callers hear an announcement
but cannot leave messages. This option is useful, for
example, to notify callers that you will be away for an
extended period and request that they call back after a
certain date.
To turn Announce Only on or off
Press MENU repeatedly until you hear “Change
Announce Only.” Then press CHANGE until you hear
the option you want (On or Off). Press PLAY/STOP to
store your selection and exit, or press MENU again to
modify other features (see page 39).
To record your outgoing announcement
When Announce Only is turned on, calls are answered
with a pre-recorded announcement that says “We’re
sorry, messages to this number cannot be accepted.”
You can use this announcement, or replace it with a
recording of your own voice.
After turning on the Announce Only feature, follow the
steps on page 37 to record your announcement. Callers
will hear this announcement only when the Announce
Only feature is turned on. Otherwise they will hear the
standard announcement asking them to leave a message.
1
MENU
“Change
Announce Only”
2
CHANGE
“Off”
3
CHANGE
“On”
4
Beep
(Option selected)
A
“A” is displayed when Announce
Only is activated
(Play/Stop)
ATT-5865CIB-d5.qxd 1/3/2004 11:32 AM Page 38
39
Answering System Operation
Changing feature options
Menu features can be changed to customize how the
answering system operates. Press MENU repeatedly to
hear each feature. Press CHANGE when you hear the
feature you want to modify.
Feature options (Default settings underlined)
System announces: Feature description:
1
MENU
3
MENU
Or
Press until desired feature
is heard (see list at right)
Press until desired selection
is heard
Press to set selection and
move to next menu option
Press to set selection and
exit menu
2
CHANGE
“Change Announcement”
Options: [record announcement]
“Change remote access code”
Options: [enter 2-digit code] 19
“Change message alert”
Options: On / Off
“Change announce only”
Options: On / Off
“Change call screening”
Options: On / Off
“Change number of rings”
Options: 2 / 4 / 6 /Toll Saver
Record your outgoing announcement
(see page 37).
Enter a 2-digit number (10-99) for remote
access from another phone (see page 43).
When on, the telephone beeps every 10
seconds when you have new messages.
When on, callers hear an announcement
but cannot leave messages (see page 38).
When on, you can hear callers leave
messages, or answer the call.
Choose number of rings before the system
answers a call. When Toll Saver is active,
the system answers after 2 rings if you
have new messages, and after 4 rings if
you have no new messages.
NOTE:
Press and hold
CHANGE
to advance the remote access code
number by 10.
(Play/Stop)
ATT-5865CIB-d5.qxd 1/3/2004 11:32 AM Page 39
40
Answering System Operation
Message playback
Press PLAY/STOP to hear messages. The system
announces the number of messages, then begins playback.
If you have new messages waiting, you will hear only the
new messages (oldest first). If there are no new messages,
the system will play back all messages (oldest first).
Announcements
• When playback begins, you will hear the total
number of messages.
• Before each message, you will hear the day and time
it was received.
• After the last message, you will hear “End of messages.”
If the system has less than 5 minutes of recording
time left, you will hear time remaining.
Options during playback
• Press VOLUME button to adjust speaker volume.
• Press SKIP to skip to next message (or hold down to
speed up message playback).
• Press REPEAT to repeat message currently playing.
Press twice to hear previous message. (Hold down
to slow message playback).
• Press DELETE to delete message being played back.
• Press PLAY/STOP to stop playback.
To delete all messages
To delete all messages, press and hold DELETE while
the phone is idle (not during a call, or during message
playback).
1
“You have [xx] new
and [xx] old messages”
Number of messages waiting
(or, during playback, message
number currently playing)
14
Message playback begins. See
options at right.
2
Message playback ends.
NOTE:
If “F” is flashing in
the message window, memory is
full. You will have to delete some
messages before new ones can
be received.
NOTE:
New (unheard)
messages cannot be deleted.
Press PLAY/STOP to begin or
end message playback
(Play/Stop)
(Play/Stop)
ATT-5865CIB-d5.qxd 1/3/2004 11:32 AM Page 40
41
Answering System Operation
Recording and playing memos
Memos are messages you record yourself. They are
saved, played back and deleted exactly like incoming
messages. You can record a memo as a reminder to
yourself, or leave a message for someone else if others
in your household use the answering system.
To record a memo
Follow the steps at left to record a memo. Elapsed time
(in seconds) are shown in the message window as you
record. You can record a memo up to 4 minutes long.
Memos less than 1 second long will not be recorded.
To play back a memo
Press PLAY/STOP to hear messages and memos (see
page 40 for other options).
1
RECORD
“Now recording...”
3
Beep
(Memo has been
recorded)
12
Elapsed
recording time
(seconds)
Press to stop
recording
2
Speak into microphone
Microphone
(Play/Stop)
ATT-5865CIB-d5.qxd 1/3/2004 11:33 AM Page 41
42
Answering System Operation
Message window displays
The message window usually displays the total number of
memos and incoming messages. See list below for
explanation of other displays in this window.
Message window displays
0
No messages waiting.
1-98
Number of messages/memos, or message
currently playing (see page 40).
10-99
Current Remote Access Code while setting
(see page 39).
1-8
Current volume level while adjusting
1-99
(counting)
Elapsed time while recording a memo (see page 41)
or announcement up to 90 seconds (page 37).
99
(flashing)
Memo recording exceeded maximum time of 99
seconds.
F
(flashing)
Memory is full. Messages must be deleted before
new messages can be received.
CL
(flashing)
Clock needs to be set (see page 36).
A
Announce Only mode is on (see page 38).
--
System is answering a call, or being accessed
remotely.
--
(flashing)
System is being programmed or initialized.
On
(or)
OF
Displayed for 1 second when any answering
system setting is turned on or off.
12
Message window
ATT-5865CIB-d5.qxd 1/3/2004 11:33 AM Page 42
43
Answering System Operation
1
Remote access
A 2-digit security code is required to access your
answering system from any touch-tone phone. This
code is “19” by default; see page 39 to change it.
Dial your telephone number from
any touch-tone phone
2
When system answers, enter 2digit Remote Access Code (“19”
unless you have changed it)
3
Enter remote commands
(see list at right)
4
Hang up to end call and save all
undeleted messages
Play messages
#2
Repeat or go back
#4
Skip to next message
#6
Stop
#5
Delete message
#9
Review announcement
#7
Record announcement
*7
to begin recording
#5
to stop recording
Record memo
*8
to begin recording
#5
to stop recording
Turn system off
#0
Turn system on
#0
Help Menu
#1
Exit
*0
Press to hear new messages (if none are
new, all play back).
Press to repeat current message. Press
twice (# 4 # 4) to hear previous message.
Press to skip current message and
advance to next message.
Press to stop any operation
(stop playback, stop recording).
Press during playback to delete current
message.
Press to review current outgoing
announcement.
Press * 7, wait for beep, then begin
speaking. Press # 5 to stop recording and
hear playback of new announcement.
Press * 8, wait for beep, then begin
speaking. Press # 5 to stop recording.
Press to turn off answering system.
Incoming calls will no longer be answered.
If off, system will answer after 10 rings. Enter
your access code, then press # 0 to turn on.
Press to hear list of features & commands.
End remote access call (or hang up).
NOTE: If you pause for
more than 10 seconds during
remote access, you will hear a
help menu listing all features &
commands. If you issue no
command for another 20 seconds,
the call will end automatically.
ATT-5865CIB-d5.qxd 1/3/2004 11:33 AM Page 43
44
Appendix
Display screen status icons
Handset status icons
REDIAL CID LOG
2:10 PM
1
Base status icons
Spare battery charging
Ringer off
Battery power levels
Battery fully charged
Approximately half power remaining
Battery power is low; should be recharged soon
(flashing) Battery power is very low and must be recharged
REDIAL MENU MEM
Phone in use (external call)
Parallel set in use (non-system)
Phone in use (intercom call); flashes when handset is being paged
Battery power level (see below); animated display when charging
Ringer off
1
Current handset identification.
!
Handset is not yet registered, or searching for base
1
Answering system is receiving an incoming call
Phone in use (external or intercom call); 1-8 = handsets, 0 = base
M
Microphone is muted
H
Call is on hold
ATT-5865CIB-d5.qxd 1/3/2004 11:33 AM Page 44
45
Appendix
Confirmation tone
(“Happy” tone)
Handset registration or programming
command successfully completed.
Out of Range tone (multiple
beeps at 1-second intervals)
The handset is out of range. Move closer
to the base.
“Beeeeeeeeep”
(1 long beep)
Error tone (current operation has been
unsuccessful; try again).
Alert tones and indicator lights
“Beep-Beep-Beep-Beep-Beep”
(5 quick beeps)
Handset battery is low. Place handset in
base to charge the battery.
Alert tones
Indicator lights
MUTE
On when base
microphone is muted.
SPEAKER
On when speakerphone
is in use
(Flashes when call
is on hold)
ON/OFF
On when answering
system is on.
ATT-5865CIB-d5.qxd 1/3/2004 11:33 AM Page 45
46
Appendix
Adding new handsets
Your telephone can accommodate up to 8 cordless handsets. You can add new handsets
(sold separately) at any time. Up to 4 handsets at a time can be used.
REDIAL MENU MEM
CALLS LOG
BASE SETTINGS
DISPLAY BASE-ID
^
OK
V
CALLS LOG
BASE SETTINGS
DISPLAY BASE-ID
^
OK
V
123456789012345
OK
Before using a new handset, you must register it with the
base. During registration, you must enter the 15-digit ID
number of the telephone base. To find this number, go to
the base, press MENU, scroll down to select DISPLAY
BASE ID, then press OK.
Follow the instructions provided with your new handset
to register it for use with your telephone.
The handset provided with your telephone is automatically
registered as Handset 1. Additional handsets will be
assigned numbers in the order they are registered (2, 3, 4,
etc.) up to a maximum of eight handsets.
Handset 1 Handset 2 Handset 3
ATT-5865CIB-d5.qxd 1/3/2004 11:34 AM Page 46
47
Appendix
Charging spare batteries
Optional spare batteries (sold separately) can be kept charged in the base, for quick
replacement when handset batteries become depleted.
In the event of a power failure, the charged batteries in the base will allow you to
make and receive calls from the cordless handset for up to 2.5 hours.
Spare batteries require at least 20 hours to reach full charge.
Slide latch left to open battery drawer
Insert spare batteries,
then close drawer
Caution: Use only AT&T AA NiMH
rechargeable batteries. Do not
use AA alkaline batteries.
ATT-5865CIB-d5.qxd 1/3/2004 11:34 AM Page 47
48
Appendix
In case of difficulty
If you have difficulty with your phone, please try the suggestions below. For Customer
Service, visit our web site at www.telephones.att.com, or call 1 800 222–3111.
Telephone does not work at all
• Make sure batteries are installed and charged correctly (see page 7).
• Make sure the AC adapter is plugged into an outlet not controlled by
a wall switch.
• Make sure the telephone line cord is plugged firmly into the base unit
and the modular jack.
• Make sure the base antenna is fully upright.
• If you have dial pulse telephone service, make sure the dial mode is
set to dial pulse (see page 17).
• If these suggestions do not work, unplug the base, remove and reinsert the batteries, then place the handset in the base to re-initialize.
Phone does not ring
• Make sure the ringer is on (see page 15).
• Make sure the telephone line cord and AC adapter are plugged in
properly (see page 6).
• Make sure the base antenna is fully upright.
• Move the handset closer to the base.
• You might have too many extension phones on your telephone line to
allow all of them to ring. Try unplugging some of them.
If you hear noise or interference during a call
• Make sure the base antenna is fully upright.
• You may be out of range. Move closer to the base.
• Appliances plugged into the same circuit as the base can cause
interference. Try moving the appliance or base to another outlet.
• The layout of your home or office might be limiting the operating
range. Try moving the base to another location, preferably on an
upper floor.
• If the buttons don’t work, try placing the handset in the base for at
least 15 seconds.
• Disconnect the base from the modular jack and plug in a corded telephone. If calls are still not clear, the problem is probably in your
wiring or local service. Call your local telephone service company.
ATT-5865CIB-d5.qxd 1/3/2004 11:34 AM Page 48
49
Appendix
If you lose a call after changing channels
Incomplete messages
• You were probably almost out of range. Move closer to the base
before changing channels. Before placing another call, set the handset in the base for at least 15 seconds.
• If a caller leaves a very long message, part of it may be lost when the
system disconnects the call after 4 minutes.
• If the caller pauses for more than 7 seconds, the system stops
recording and disconnects the call.
• If the system’s memory becomes full during a message, the system
stops recording and disconnects the call.
Difficulty hearing messages
• Press ^ to increase speaker volume.
System does not answer after correct number of rings
• Make sure that the answering system is on.
• If Toll Saver is activated, the number of rings changes to 2 when you
have new messages waiting (see page 39).
• In some cases, the system may be affected by the ringing system
used by the local telephone company.
• If the memory is full or the system is off, the system will answer after
10 rings.
“CL” flashes in message window
• You need to reset the answering system clock (see page 36).
Announcement message is not clear
• When you record your announcement, make sure you speak in a
normal tone of voice, about 9 inches from the base.
• Make sure there is no “background” noise (TV, music, etc.) while you
are recording.
System does not respond to remote commands
• Make sure to enter your Remote Access Code correctly (see page 43).
• Make sure you are calling from a touch-tone phone. When you dial a
number, you should hear tones. If you hear clicks, the phone is not a
touch-tone telephone and cannot activate the answering system.
• The answering system may not detect the Remote Access Code
while your announcement is playing. Try waiting until the announcement is over before entering the code.
• There may be noise or interference on the phone line you are using.
Press dial-pad buttons firmly.
In case of difficulty
ATT-5865CIB-d5.qxd 1/3/2004 11:34 AM Page 49
50
Appendix
A
AC adapter, 6
Access code, 39, 43
Alert tones, 45
Answering calls, 10, 11
Answering system, 35
announce only, 38
delete messages, 40, 43
feature options, 39
handset access, 27
outgoing announcement, 37, 43
memos, 41
message window, 42
play messages, 40, 43
remote access, 43
remote access code, 39, 43
Antenna, 7
B
Battery charging, 7, 47
Battery installation, 7
Belt clip, 9
C
Call logs, 26, 31
Caller ID, 5, 28, 32
add entries to phone directory, 28, 32
delete entries, 28, 32
dial entries, 29, 33
Call screening, 39
Call waiting, 5, 12
CID, 28, 32
Conference calls, 12
D
Day/time, 36
Delete Call Log entries, 28, 32
Delete redial entries, 30, 34
Dialing,
manual dialing, 10, 11
phonebook dialing, 21, 25
Display screen, 44
Distinctive ring, 18
E
Elapsed time, 37, 41
Ending calls, 10, 11
Error tones, 45
F
Flash (switchhook flash), 12
H
Hands-free use, 10
Headphone, 9
Hold, 10, 11
I
Incoming call log, 28, 32
Incoming calls, answering, 10, 11, 13
Incoming messages, 35
Indicator lights, 45
Intercom, 13
L
Last number redial, 30, 34
Low battery, 7
M
Making calls, 10, 11
Memos, 41
Menus, 2, 14-17
Message alert, 39
Messages, 35-43
Microphone, 37, 41
Missed calls, 28, 32
Mute, 10, 11
Index
ATT-5865CIB-d5.qxd 1/3/2004 11:34 AM Page 50
51
Appendix
N
Names,
enter into phonebook, 19, 23
search for, 20, 24
New handsets, 46
Number of rings before answer, 39
O
On/off button, 35
Operating range, 5
Outgoing announcement, 37, 43
Out of range, 5
P
Paging, 13
Phonebooks,
base phonebook, 22
handset phonebook, 18
dial number, 21, 25
edit entries, 21, 25
name search, 20, 24
new entries, 19, 23
Pictures, 14
Playback (messages), 40
Problems, 48
Q
Quick reference guide, 2-3
R
Receiving calls, 10, 11
Recharging, 7, 47
Redial, 30, 34
Repeat, 40
Ring silencing, 12
Ring tone options, 15, 17
S
Search for name, 20, 24
Security codes, 39, 43
Skip, 40
Sounds & alerts, 15, 45
Spare batteries, 47
Speakerphone, 10, 11
T
Technical specifications, 52
Time, 36
Timers,
recording announcement, 37
recording memo, 41
Tones,
base tones & alerts, 17
handset tones & alerts, 15
send tones during call, 12
Troubleshooting, 48
V
Voice mail, 27, 35
Volume controls, 12
Index
ATT-5865CIB-d5.qxd 1/3/2004 11:34 AM Page 51
52
Appendix
Technical specifications
RF Frequency Band
(Handset to Base)
2400 MHz — 2483.5 MHz
Sensitivity -93 dBm
RF Frequency Band
(Base to Handset)
5725 MHz — 5850 MHz
Channels 95
Channel Spacing 864 KHz
Base Unit Voltage
(AC Voltage, 60Hz)
96 — 127 Vrms
Base Unit Voltage
(AC Adapter Output)
7 Vdc @1A
Handset Voltage 2.4 Vdc (2 x AA NiMH 1400mAh batteries)
ATT-5865CIB-d5.qxd 1/3/2004 11:34 AM Page 52
Appendix
Your package includes a handy wallet card to help you remember access commands
you can use to control your answering system from any touch-tone telephone.
If you misplace this card, just clip and save the card below.
Remote access wallet card
Fold here
Cut along dotted line
Action Remote Command
Voice help menu ......................#1
Play messages ............................#2
Repeat message ........................#4
Skip message ..............................#6
Stop..............................................#5
Save messages............................Hang up
Delete message ........................#9 while message plays
Review announcement ............#7
Record announcement ............*7 speak after beep
#5 to stop
Record memo............................*8 speak after prompt
#5 to stop
End remote access call ............*0 (or hang up)
Turn system off ........................#0 (enter again to turn on)
Turn system on ........................If off, system answers after 10 rings.
Enter your access code, then press
# 0 to turn system on.
Call your phone number, then enter
your 2-digit access code (preset to 19).
5.8 GHz Cordless Speakerphone/Answering System E5865
ATT-5865CIB-d5.qxd 1/3/2004 11:34 AM Page 53
Copyright © 2004 Advanced American Telephones. All Rights Reserved.
AT&T and the Globe Design are trademarks of AT&T Corporation,
licensed to Advanced American Telephones. Printed in China. Issue 1.5 AT&T 01/03/04.
www.telephones.att.com
ATT-5865CIB-d5.qxd 1/3/2004 11:34 AM Page 54
User Manual (Part 2)
5.8 GHz Expansion
Handset E580-1
For use with AT&T models
E5860 • E5865 • E5900B • E5965C
ATT-580-1CIB-d2.qxd 1/17/2004 6:12 PM Page 1
Table of contents
Copyright © 2004 Advanced American Telephones. All Rights Reserved.
AT&T and the Globe Design are trademarks of AT&T Corp.,
licensed to Advanced American Telephones.
STOP!
See pages 2-3
for easy instructions.
You must charge
batteries and register the
handset before use.
For customer service or product
information, visit our web site at
www.telephones.att.com
or call
1-800-222-3111.
Please also read
Important Product Information
Enclosed in product package.
Before you begin........................................1
Parts checklist.............................................1
Battery installation & charging................2
Registering the handset............................3
Belt clip & optional headset ....................4
Quick reference guide..............................5
ATT-580-1CIB-d2.qxd 1/17/2004 6:12 PM Page 2
1
Before you begin
This cordless telephone operates with
the maximum power allowed by the
Federal Communications Commission
(FCC). Even so, the handset and base
can communicate over only a certain
distance — which can vary with the
locations of the base and handset, the
weather, and the construction of your
home or office. For best performance,
keep the base antenna fully upright.
If you receive a call while you are
out of range, the handset might not
ring — or if it does ring, the call might
not connect when you press PHONE.
Move closer to the base, then press
PHONE to answer the call.
If you move out of range during a
phone conversation, you might hear
noise or interference. To improve
reception, move closer to the base.
If you move out of range without
pressing OFF, your phone will be left
“off the hook.” To hang up properly,
walk back toward the telephone base,
periodically pressing OFF until the call
is disconnected.
Parts checklist
Remember to save your sales receipt and original packaging in case you ever need to
ship your telephone for warranty service. Check to make sure the telephone package
includes the following:
Handset charger
Telephone
handset
Power
adapter
Belt clip
Batteries
ATT-580-1CIB-d2.qxd 1/17/2004 6:12 PM Page 1
LOW BATTERY
REDIAL CID LOG
2:10 PM
1
2
Battery installation & charging
After installation, place the handset in the charger and allow batteries to charge for 12
hours before use. You can keep batteries charged by returning the handset to the charger
after each use. When battery power is fully depleted, a full recharge takes about 8 hours.
Press coin into slot on
base of handset to
release latch, then
remove battery cover.
Insert supplied
batteries.
Place handset in charger to charge
for 12 hours before first use.
Light remains on while batteries
are charging.
Low battery indicator
Return handset to charger to recharge
when this symbol flashes. (Handset
will beep when battery is low.)
Insert top
tab first.
To replace battery cover
Press down to
click in place.
Plug power cord into jack on underside
of charger, then plug transformer into
electrical outlet.
Caution: Use only the supplied
NiMH battery (80-5461-00-00) or
AT&T model 2AA NiMH replacement battery (SKU 26820). Do not
use alkaline batteries.
ATT-580-1CIB-d2.qxd 1/17/2004 6:13 PM Page 2
3
Registering the handset
Before using your new handset, you must register it with
the base. During registration, you must enter the 15-digit
ID number of the telephone base. To find this number, go
to the base, press MENU, scroll down to select DISPLAY
BASE ID, then press OK.
The handset provided with your telephone is automatically
registered as Handset 1. Additional handsets will be
assigned numbers in the order they are registered (2, 3, 4,
etc.) up to a maximum of eight.
Handset 1 Handset 2 Handset 3
MENU
CALLS LOG
BASE SETTINGS
DISPLAY BASE-ID
^
OK
V
CALLS LOG
BASE SETTINGS
DISPLAY BASE-ID
^
OK
V
123456789012345
OK
ATT-580-1CIB-d2.qxd 1/17/2004 6:13 PM Page 3
4
Belt clip & optional headset
Install belt clip as shown below if desired.
For hands-free telephone conversations, you can use any industry standard 2.5 mm
headset (purchased separately). For best results use an AT&T 2.5 mm headset.
Snap belt clip into notches on
side of handset. Rotate and pull
to remove.
Plug 2.5 mm headset
into jack on side of
handset (beneath
small rubber cap).
ATT-580-1CIB-d2.qxd 1/17/2004 6:14 PM Page 4
5
Quick reference guide
For complete instructions, please refer to the manual provided with your telephone.
NavKey
Press center button to display menus.
Press NavKey buttons to navigate
through menus. Press center button to
select menu item highlighted.
Speaker
Press to activate handset speakerphone. Press again to switch call back
to earpiece.
Softkeys
Press a softkey to select a menu item
displayed just above the key.
Off/Cancel
During a call, press to hang up.
While using menus, press to cancel an
operation, back up to the previous menu,
or exit the menu display.
Phone/Flash
Press to begin a call, then dial a number.
During a call, press to receive an incoming
call, if Call Waiting is activated.
Sound Select
Press to customize speaker sound for
clear speakerphone conversations.
Intercom
Vibrate Ringer Control Ringers
Low Batt Tone Keypad Tone Range Tone
Clock On/Off Set Time Contrast
Phone Setup Language Reset Settings
Directory Calls Log Pictures Sounds&Alerts Settings
Main menu
Sounds & Alerts menu Settings menu
Left Right
Select
Up
Down
ATT-580-1CIB-d2.qxd 1/17/2004 6:15 PM Page 5
Copyright © 2004 Advanced American Telephones. All Rights Reserved.
AT&T and the Globe Design are trademarks of AT&T Corp.,
licensed to Advanced American Telephones. Printed in China. Issue 1.2 AT&T 1/19/04.
www.telephones.att.com
ATT-580-1CIB-d2.qxd 1/17/2004 6:15 PM Page 6
User Manual (Part 2)
5.8 GHz Expansion
Handset E580-2
For use with AT&T models
E5860 • E5865 • E5900B • E5965C
ATT-580-2CIB-d2.qxd 1/17/2004 6:06 PM Page 1
Table of contents
Copyright © 2004 Advanced American Telephones. All Rights Reserved.
AT&T and the Globe Design are trademarks of AT&T Corp.,
licensed to Advanced American Telephones.
STOP!
See pages 2-3
for easy instructions.
You must charge
batteries and register the
handset before use.
For customer service or product
information, visit our web site at
www.telephones.att.com
or call
1-800-222-3111.
Please also read
Important Product Information
Enclosed in product package.
Before you begin........................................1
Parts checklist.............................................1
Battery installation & charging................2
Registering the handset............................3
Belt clip & optional headset ....................4
Quick reference guide..............................5
ATT-580-2CIB-d2.qxd 1/17/2004 6:06 PM Page 2
1
Before you begin
This cordless telephone operates with
the maximum power allowed by the
Federal Communications Commission
(FCC). Even so, the handset and base
can communicate over only a certain
distance — which can vary with the
locations of the base and handset, the
weather, and the construction of your
home or office. For best performance,
keep the base antenna fully upright.
If you receive a call while you are
out of range, the handset might not
ring — or if it does ring, the call might
not connect when you press PHONE.
Move closer to the base, then press
PHONE to answer the call.
If you move out of range during a
phone conversation, you might hear
noise or interference. To improve
reception, move closer to the base.
If you move out of range without
pressing OFF, your phone will be left
“off the hook.” To hang up properly,
walk back toward the telephone base,
periodically pressing OFF until the call
is disconnected.
Parts checklist
Remember to save your sales receipt and original packaging in case you ever need to
ship your telephone for warranty service. Check to make sure the telephone package
includes the following:
Handset charger
Telephone
handset
Power
adapter
Belt clip
Batteries
ATT-580-2CIB-d2.qxd 1/17/2004 6:06 PM Page 1
LOW BATTERY
REDIAL CID LOG
2:10 PM
1
2
Battery installation & charging
After installation, place the handset in the charger and allow batteries to charge for 12
hours before use. You can keep batteries charged by returning the handset to the charger
after each use. When battery power is fully depleted, a full recharge takes about 8 hours.
Press coin into slot on
base of handset to
release latch, then
remove battery cover.
Insert supplied
batteries.
Place handset in charger to charge
for 12 hours before first use.
Light remains on while batteries
are charging.
Low battery indicator
Return handset to charger to recharge
when this symbol flashes. (Handset
will beep when battery is low.)
Insert top
tab first.
To replace battery cover
Press down to
click in place.
Plug power cord into jack on underside
of charger, then plug transformer into
electrical outlet.
Caution: Use only the supplied
NiMH battery (80-5461-00-00) or
AT&T model 2AA NiMH replacement battery (SKU 26820). Do not
use alkaline batteries.
ATT-580-2CIB-d2.qxd 1/17/2004 6:07 PM Page 2
3
Registering the handset
Before using your new handset, you must register it with
the base. During registration, you must enter the 15-digit
ID number of the telephone base. To find this number, go
to the base, press MENU, scroll down to select DISPLAY
BASE ID, then press OK.
The handset provided with your telephone is automatically
registered as Handset 1. Additional handsets will be
assigned numbers in the order they are registered (2, 3, 4,
etc.) up to a maximum of eight.
Handset 1 Handset 2 Handset 3
MENU
CALLS LOG
BASE SETTINGS
DISPLAY BASE-ID
^
OK
V
CALLS LOG
BASE SETTINGS
DISPLAY BASE-ID
^
OK
V
123456789012345
OK
ATT-580-2CIB-d2.qxd 1/17/2004 6:08 PM Page 3
4
Belt clip & optional headset
Install belt clip as shown below if desired.
For hands-free telephone conversations, you can use any industry standard 2.5 mm
headset (purchased separately). For best results use an AT&T 2.5 mm headset.
Snap belt clip into notches on
side of handset. Rotate and pull
to remove.
Plug 2.5 mm headset
into jack on side of
handset (beneath
small rubber cap).
ATT-580-2CIB-d2.qxd 1/17/2004 6:08 PM Page 4
5
Quick reference guide
For complete instructions, please refer to the manual provided with your telephone.
NavKey
Press center button to display menus.
Press NavKey buttons to navigate
through menus. Press center button to
select menu item highlighted.
Speaker
Press to activate handset speakerphone. Press again to switch call back
to earpiece.
Softkeys
Press a softkey to select a menu item
displayed just above the key.
Off/Cancel
During a call, press to hang up.
While using menus, press to cancel an
operation, back up to the previous menu,
or exit the menu display.
Phone/Flash
Press to begin a call, then dial a number.
During a call, press to receive an incoming
call, if Call Waiting is activated.
Sound Select
Press to customize speaker sound for
clear speakerphone conversations.
Intercom
Vibrate Ringer Control Ringers
Low Batt Tone Keypad Tone Range Tone
Appearance Set Time Contrast
Phone Setup Language Reset Settings
Directory Calls Log Pictures Sounds&Alerts Settings
Main menu
Sounds & Alerts menu Settings menu
Left Right
Select
Up
Down
ATT-580-2CIB-d2.qxd 1/17/2004 6:09 PM Page 5
Copyright © 2004 Advanced American Telephones. All Rights Reserved.
AT&T and the Globe Design are trademarks of AT&T Corp.,
licensed to Advanced American Telephones. Printed in China. Issue 1.2 AT&T 1/19/04.
www.telephones.att.com
ATT-580-2CIB-d2.qxd 1/17/2004 6:09 PM Page 6
Loading...
