User's Manual

5.8 GHz Expansion Handset E560-2/E560-5

For use with AT&T model E5640/E5643B/ E5644B/E5655

Congratulations on your purchase

of this AT&T product.

Before using this telephone system,

you must

read Important safety information on

pages 20-24 of this manual.

NEED HELP?

Our representatives are here

to help you with any questions concerning

the operation of this product, available accessories, or

any other related issues.

Call toll free

1 (800) 222-3111

In Canada, call

1 (866) 288-4268

or visit our website at

www.telephones.att.com

Model #: AT&T E560-2/E560-5

Product name: 5.8 GHz cordless telephone

Serial #:

(found at the bottom of the handset charger)

Purchase date:

Place of purchase:

IMPORTANT

Information about caller ID with call waiting

This product has a caller ID with call waiting feature which works with service from your local telephone service provider.

Caller ID with call waiting lets you see the name of the caller before answering the telephone, even when on another call.

You may need to change your phone service to use this feature.

• you have both caller ID and call waiting, but as separate

• you have only caller ID service, or only call waiting service.

• you don’t subscribe to any caller ID or call waiting services.

You can use this product with regular caller ID service, or you can use this product’s other features without subscribing to either caller ID or combined caller ID with call waiting service.

There are fees for caller ID services, but these may not be available in all areas.

Contact your telephone service provider if:

services (you may need combined service).

Depending on your service subscription, you may see the caller’s number, or the caller’s name and number. This product can provide information only if both you and the caller are in areas offering caller ID service, and if both telephone companies use compatible equipment. The time and date are sent by the service provider along with the call information.

AT&T and the Globe Design are trademarks of AT&T Corp.,

licensed to Advanced American Telephones.

You must charge the battery and register the handset before use.

STOP!

See pages 2-3

for easy instructions.

For customer service or product information, visit our web site at

www.telephones.att.com

or call 1 (800) 222-3111.

Table of contents

Quick reference guide .............................1

Before you begin ....................................... 2

Parts checklist ............................................ 2

Battery & charger installation ................ 3

Adding new handsets ...............................4

Replacing a handset .................................. 7

Re-registering a handset .......................... 9

Belt clip & optional headset .................11

Troubleshooting .......................................12

Important safety information ...............20

FCC Part 68 and ACTA .........................25

FCC Part 15 ............................................. 27

Limited warranty .....................................28

Please also read

Important safety

information on pages 20-

24.

AT&T and the Globe Design are trademarks of AT&T Corp.,

licensed to Advanced American Telephones.

Quick reference guide

For complete instructions, please refer to the manual provided with your E5640, E5643B, E5644B or E5655 telephone. If your manual for the above models has been misplaced, you may download it from www.telephones.att.com.

Handset

^ CID

Press to scroll up in menus. Press when phone is not in use to display caller ID information. While entering names or numbers, press to move the cursor to the left.

PHONE/FLASH

Press to make or answer a call. During a call, press to receive an incoming call, if call waiting is activated.

REDIAL/PAUSE

Press to view redial memory. While entering numbers, press and hold to insert a dialing pause.

SPEAKER

Press to activate handset speakerphone. Press again to resume normal handset use (earpiece).

Feature menu

> shows highlighted item

>DIRECTORY CALL LOG

Feature Menu

Directory Call log Ringer volume Ringer tone Key tone Language Clear voice mail Dial type

SELECT/MENU

Press to display menu, or to select highlighted item from menu.

DIRV

Press to scroll down in menus. Press when phone is not in use to display directory entries. While entering names, press to advance cursor.

During a call, press to hang up. While using menus, press to cancel an operation, back up to the previous menu, or exit the menu display.

While on a call, press to mute microphone. While reviewing the call log, press to delete an individual entry or press and hold to clear the caller ID log. While pre-dialing, press to delete digits from a string.

Press to initiate an intercom conversation or transfer a call.

Press ^ CID or DIRV to scroll through menu items.

Press SELECT/

or modify a highlighted item. Press OFF/ an operation, back up to the previous menu, or exit the menu display.

OFF/CLEAR

MUTE/DELETE

INTERCOM

MENU to select

CLEAR to cancel

Before you begin

This cordless telephone operates within the maximum power allowed by the Federal Communications Commission (FCC). Even so, this handset and telephone base can communicate over only a certain distance — which can vary with the locations of the telephone base and handset, the weather, and the construction of your home or office.

If there is a call while the handset is out of range, the handset might

not ring — or if it does ring, the call might not connect when you press

PHONE/

FLASH. Move closer to the

telephone base, then press

PHONE/FLASH to answer

the call.

If the handset is out of range during a telephone conversation,

there might be interference. To improve reception, move closer to the base.

If you move out of range without pressing

OFF/CLEAR, your telephone

will be disconnected after five seconds. To hang up properly, walk back toward the telephone base, periodically pressing

OFF/CLEAR until the call is

disconnected.

Parts checklist

Remember to save your sales receipt and original packaging in case it is necessary to ship your telephone for warranty service. Check to make sure the telephone package includes the following:

Handset

Powe r adapter

Belt clip

Handset charger

CHARGING

Battery

Battery compartment cover

Battery & charger installation

After installation, place the handset in the handset charger or the telephone base and allow the battery to charge for at least 16 hours before use. You can keep the battery charged by returning the handset to the handset charger or the telephone base after each use. When battery power is completely depleted, a full recharge takes about 16 hours. The average talk time on a completely charged battery is about eight hours depending on the environmental conditions, and the standby time is approximately four days.

LOW BATTERY

Low battery indicator

Return handset to the handset charger or the telephone base to recharge when this symbol flashes. (The handset will beep when battery is low.)

Align the two holes in the connector with the socket pins according to the diagram inside the battery compartment, then snap

Press tab and slide the cover away from the center of the telephone to open battery compartment.

Caution: Use only the supplied rechargeable battery or AT&T replacement battery model 27910 (SKU 00102. Part number 89-0099-00-00).

Plug the power cord into the jack on the underside of the handset charger, then plug the power adapter into an electrical outlet not controlled by a wall switch.

NOTE: Use only the power adapter

supplied with this product. If you need

a replacement, call 1 (800) 222-3111.

Be sure to use an electrical outlet not

controlled by a wall switch.

the connector into place.

Place the battery and wires in the compartment.

Replace the compartment cover by sliding it towards the center of the handset until it is securely in place.

CHARGER light remains on while battery is charging.

Adding new handsets

The handset provided with your E5640/E5655 is automatically registered as Handset 1. Additional handsets will be assigned numbers in the order they are registered (Handset 2, Handset 3, or Handset 4). A maximum of 4 handsets can be registered to the same telephone base.

The E5643B has 3 handsets automatically registered as handset 1, 2 and 3. You can register one additional handset, which will be called Handset 4.

Enter base ID, then press SELECT.

ENTER BASE ID

HANDSET 2

Before using a new E560-2/E560-5 handset, you must register it with the E5640/E5643B/E5655 telephone base. During registration, you must enter the 15-digit ID number of the telephone base. The base ID of the E5640/E5643B is located on the bottom of the telephone base.

For the E5655, you can find the base ID code in the E5655 base menu. Press SELECT/MENU just below the screen on the telephone base, then press ^ CID twice and the screen shows >DISPLAY BASE ID. Press SELECT/MENU and the base ID code will be displayed on the screen.

NOTE: A maximum of two handsets or one handset and the speakerphone on the telephone base can be connected to an external line anytime.

Adding new handsets

To add a new handset:

• Make sure the handset battery is properly installed and fully charged.

• If the battery in the handset is not sufficiently charged, the screen on the handset will show

PLACE IN CHARGER

If this happens, return the handset to the handset charger until

the screen shows

ENTER BASE ID

• Enter the 15-digit base ID number. The number is located on the bottom of the E5640 and E5643B telephone base. To find the number on the E5655, press base, and scroll down to highlight DISPLAY BASE ID, then press SELECT/MENU.

• When the base ID is being entered, the following keys can be used:

• DELETE to delete the last digit entered.

• Press and hold DELETE to delete all digits entered.

• Press SELECT when the complete base ID has been entered.

SELECT on the telephone

Adding new handsets

• If the number is not entered correctly, the screen will be blank for a few seconds and

ENTER BASE ID

will be displayed again until a valid base ID has been entered.

• After entering the code, press code to complete the registration process.

NOTE: In some cases, the last digit of the base ID may be an *. Treat that as part of the base ID and enter it into the handset for registration purpose.

NOTE: If an invalid base ID code is entered, there will be an error tone and the handset will continue to display ENTER BASE ID. To make corrections while entering the code, erase digits by

pressing the DELETE/

MENU key.

When a valid base ID has been entered and recognized by the telephone base, the screen will be blank for a few seconds and will show:

SEARCHING...

followed by a screen indicating the number for the newly registered handset.

HANDSET X

SELECT/MENU to accept the

The new handset will be assigned the next available handset number (Handset 2, Handset 3, or Handset 4). A maximum of four handsets can be registered to each telephone base.

Replacing a handset

If you are replacing a handset on a system which already has the maximum number of handsets registered (4), or wish to change the assigned handset number of your registered handsets, you must first de-register all handsets, then re-register them again.

To de-register all handsets (E5640/E5643B/E5644B)

• Unplug the power supply from the telephone base.

• Plug in the power supply while pressing and holding the

HANDSET LOCATOR button on the telephone base.

• Continue pressing HANDSET LOCATOR until the IN USE and CHARGING indicators are lit. This should take about 10 seconds.

• Release the

All handsets will display:

ENTER BASE ID

Once the base indicators turn off (may take up to 30 seconds), the handsets are de-registered from the telephone base, and can now be re-registered (see page 9).

HANDSET LOCATOR button.

Replacing a handset

To de-register all handsets (E5655 ONLY)

• Press * 8 8 3 2 4 4 # on the dial pad of the telephone base.

• Press

All handsets will be de-registered from the telephone base and the handsets will display (may take up to 30 seconds):

The handsets are now de-registered from the telephone base, and can now be re-registered (see page 9).

SELECT/MENU on the telephone base.

ENTER BASE ID
