AT&T E250 User Manual

User Manual (Part 2)

2.4 GHz Expansion
Handset E250

For use with AT&T models
E2555 • E2525 • E2600B

ATT-250CIB-d1.qxd 12/30/2003 2:02 PM Page 1

Table of contents

Copyright © 2003 Advanced American Telephones. All Rights Reserved.

AT&T and the Globe Design are trademarks of AT&T Corporation.,

licensed to Advanced American Telephones.

STOP!

See pages 2-3

for easy instructions

You must charge
batteries and register the
handset before use

For customer service or product
information, visit our web site at

www.telephones.att.com

or call

1-800-222-3111

Please also read

Important Product Information

Enclosed in product package

Before you begin........................................1

Parts checklist.............................................1

Battery installation & charging................2

Registering the handset............................3

Belt clip & optional headset ....................4

Quick reference guide..............................5

ATT-250CIB-d1.qxd 12/30/2003 2:02 PM Page 2

1

Before you begin

This cordless telephone operates with
the maximum power allowed by the
Federal Communications Commission
(FCC). Even so, this handset and base
can communicate over only a certain
distance — which can vary with the
locations of the base and handset, the
weather, and the construction of your
home or office. For best performance,
keep the base antenna fully upright.

If you receive a call while you are
out of range, the handset might not

ring — or if it does ring, the call might
not connect when you press PHONE.
Move closer to the base, then press

PHONE to answer the call.

If you move out of range during a
phone conversation, you might hear

noise or interference. To improve
reception, move closer to the base.

If you move out of range without
pressing OFF, your phone will be left

“off the hook.” To hang up properly,
walk back toward the telephone base,
periodically pressing OFF until the call
is disconnected.

Parts checklist

Remember to save your sales receipt and original packaging in case you ever need to
ship your telephone for warranty service. Check to make sure the telephone package
includes the following:

Handset charger

Telephone
handset

Power
adapter

Belt clip

Batteries

ATT-250CIB-d1.qxd 12/30/2003 2:02 PM Page 1

2

LOW BATTERY

Battery installation & charging

Install batteries as shown, then place the handset in the charger for at least 8 hours
before use. You can keep batteries charged by returning the handset to the charger after
each use. When battery power is fully depleted, a full recharge takes about 6 hours.

Press coin into slot on
base of handset to
release latch, then
remove battery cover

Insert supplied
batteries

Place handset in charger to
charge for 8 hours before first use.

Light remains on while batteries
are charging.

Low battery indicator

Return handset to charger to recharge
when this symbol flashes. (Handset
will beep when battery is low.)

Caution: Use only AT&T 2AA
NiCad or NiMH rechargeable
batteries. Do not use AA
alkaline batteries.

Insert top
tab first

To replace battery cover

Press down to
click in place

REDIAL MEM

MENU

Plug power cord into jack on underside
of charger, then plug transformer into
electrical outlet

ATT-250CIB-d1.qxd 12/30/2003 2:03 PM Page 2

3

Registering the handset

Before using your new handset, you must register it with
the base. During registration, you must enter the 15-digit
ID number of the telephone base. To find this number, go
to the base, press MENU, scroll down to select DISPLAY

BASE ID, then press OK.

The handset provided with your telephone is automatically
registered as Handset 1. Additional handsets will be
assigned numbers in the order they are registered (2, 3, 4,
etc.) up to a maximum of eight.

ENTER BASE ID

123456789012345

Enter base ID, then press OK

HANDSET 2

Handset 1 Handset 2 Handset 3

REDIAL MEMMENU

<

OK

ATT-250CIB-d1.qxd 12/30/2003 2:03 PM Page 3

4

Belt clip & optional headset

Install belt clip as shown below if desired.

For hands-free telephone conversations, you can use any industry standard 2.5 mm
headset (purchased separately). For best results use an AT&T 2.5 mm headset.

Snap belt clip into notches on
side of handset. Rotate and pull
to remove.

Plug 2.5 mm headset
into jack on side of
handset (beneath
small rubber cap)

ATT-250CIB-d1.qxd 12/30/2003 2:03 PM Page 4

5

HANDSET 1

REDIAL MEM

MENU

Off/Clear

During a call, press to hang up.

While using menus, press to cancel an
operation, back up to the previous
menu, or exit the menu display.

Quick reference guide

Speaker

Press to activate handset speaker­phone. Press again to switch call back
to earpiece.

Softkeys

Press a softkey to select a menu item
displayed just above the key.

Phone/Flash

Press to begin a call, then dial a number.

During a call, press to receive an incoming
call, if Call Waiting is activated.

Sound Select

Press to customize speaker sound for
clear speakerphone conversations.

Xfer/Intercom

Press to transfer a call or initiate an
intercom conversation.

Redial Log Phonebook

Screen menus

Item 1 Item 2 Item 3

Menus

Main Menu

Calls Log

Play Messages

Handset Settings

Set Time

Clock Mode

Register

Handset Settings

Ringer Volume

Ringer Melody

Low Batt Tone

Range Tone

Keypad Tone

Contrast

Language

For complete instructions, please refer to the manual provided with your telephone.

ATT-250CIB-d1.qxd 12/30/2003 2:03 PM Page 5
