Atomic G01889W User Manual

y t i l a u q t s e h g i h e h t f o e r a s t c u d o r p r u o t a h t e r u s n e o t e v i r t s e W

e r f d n a

f i , r e v e w o H . s t r a p g n i s s i m r o s t c e f e d g n i r u t c a f u n a m f o e

, t c u d o r p w e n r u o y h t i w s m e l b o r p y n a e v a h u o y

E R O T S E H T O T T I N R U T E R T O N O D ,

: @ e e r f l l o t s u t c a t n o c e s a e l p

888-996-2729 - 1

1 3 5 3 - 3 7 8 - 6 6 8 - 1 : X A F

m o c . s t r o p s e d a l a c s e @ gameroom

: o t e t i r w r O

s t r o p S e d a l a c s E

t n e m t r a p e D e c i v r e S r e m o t s u C

9 8 8 x o B . O . P

6 0 7 7 4 N I , e l l i v s n a v E

. s t r a p t u o b a g n i r i u q n i n e h w dat e code r u o y e v a h e s a e l P

date code (if , r e b m u n l e d o m r u o y e d i v o r p e s a e l p s t r o p S e d a l a c s E g n i t c a t n o c n e h W

e r a g n i t s e u q e r f i r e b m u n t r a p d n a , ) e l b a c i l p p a

. l a u n a m s r e n w o s i h t n i d n a , g n i g a k c a p , t c u d o r p e h t n o d e t a c o l

G01889W

r e b m u N l e d o M r u o Y

Dat e Code:

Purchase Date:

PLEASE RETAIN THIS INSTRUCTION MANUAL FOR FUTURE REFERENCE

All Rights Reserved

2 - G01889W - - WJ

888-996-2729 - 1 l l a C e c i v r e S r e m o t s u C r o F 1 s t r o p S e d a l a c s E 120 2 ©

e r a s r e b m u n e s e h T . t r a p t n e m e c a l p

IMPORTANT! READ EACH STEP

IN THIS MANUAL BEFORE YOU

BEGIN THE ASSEMBLY.

TWO

ADULTS ARE REQUIRED TO ASSEMBLE

THIS ATOMIC GLADIATOR SOCCER TABLE

Tools Required:

T1 - Allen Wrench (Included)
Phillips Screwdriver

Furniture Polish and Cloth

Assembly Tips

Make sure you understand the following tips before you begin to assemble your soccer table.

1. Start all bolts by hand before tightening.

2. Some drawings or images in this manual may not look exactly like your product. Please
read and understand the text before starting each assembly step.

ATTENTION:

READ AND FOLLOW ALL ASSEMBLY, OPERATION, AND

SAFETY INSTRUCTIONS CAREFULLY. AT LEAST TWO

ADULTS ARE NEEDED TO PUT THIS SOCCER TABLE

TOGETHER.

All Rights Reserved.

©

2012 Escalade Sports

2

For Customer Service Call 1-888-996-2729

HARDWARE IDENTIFIER

( To Scale)

H1 - 5/16” x 1-1/2”

Allen Head Bolt

(8 pcs)

H5 - #4 x 2”
Phillips Flat

Head Screw

(6 pcs)

H9 - #3 x 15mm

Phillips Flat Head

Screw (8 pcs)

H2 - 5/16” x 1-1/4”

Allen Head Bolt

(16 pcs)

H6 - #4 x 5/8”
Phillips Round

Head Screw

(6 pcs)

H10 - #4 x 1”

Phillips Round Head

Bolt (26 pcs)

H3 - 5/16”

Flat Washer

(24 pcs)

H7 - #4 x 1/2”

Phillips Round

Head Screw

(20 pcs)

H11 - #4

Lock Nut

(26 pcs)

H4 - #3.5 x 1-1/2”

Phillips Washer

Head Screw

(12 pcs)

H8 - 3/16” x 5/8”

Phillips Round

Head Bolt

(8 pcs)

(Not to Scale)

T1 - Allen Wrench

(1 pc)

All Rights Reserved.

©

2012 Escalade Sports

ACCESSORIES IDENTIFIER

( Not to Scale)

A1- Soccer Ball (4 pcs)

WARNING:

CHOKING HAZARD

!

Small parts.
Not for children under 3 yrs.

3

For Customer Service Call 1-888-996-2729

PARTS IDENTIFIER

( Not to Scale)

P1 - Side Apron

(2 pcs)

P5 - Playfield Support

Brace (3 pcs)

P9 - Playfield Trim

(2 pcs)

P2 - End Apron

(2 pcs)

P6 - Goal Box

(2 pcs)

P10 - Leg Leveler

(4 pcs)

P3 - Playfield (1 pc)

P7 - Ball Catcher

(2 pcs)

P11 - Corner Cap

(4 pcs)

P4 - Leg

(4 pcs)

P8 - Ball Return

Tube (2 pcs)

P12 - Corner Post

(4 pcs)

P13 - Scorer (2 pcs)

P17 - Rod Bushing

(16 pcs)

P21 - 2 Player Rod

(2 pcs)

All Rights Reserved.

©

2012 Escalade Sports

P14 - Rod Bumper

(16 pcs)

P18 - Ball Entry

Cup (2 pcs)

P22 - 3 Player Rod

(4 pcs)

WARNING:

CHOKING HAZARD

!

Small parts.
Not for children under 3 yrs.

P15 - Rod End

Cap (8 pcs)

P19 - Red Shirt /

Black Shorts

Player (13 pcs)

P23 - 5 Player Rod

(2 pcs)

4

P16 - Rod Handle

(8 pcs)

P20 - Black Shirt /

Yellow Shorts

Player (13 pcs)

P24 - Cup Holder

(4 pcs)

For Customer Service Call 1-888-996-2729

PARTS REQUIRED:

2 pcs - P1 Side Apron
1 pc - P3 Playfield

ATTENTION:

THIS STEP REQUIRES TWO OR MORE ADULTS.

VERY CAREFULLY SET P3 PLAYFIELD INTO THE GROOVES

IN P1 SIDE APRON.

STEP 1:

Find a clean, level place to begin the assembly
of your soccer table. We recommend building
the table on the box top to protect the parts
during assembly.

Set P3 Playfield into the grooves in P1 Side
Apron as shown in FIGURE 1.

FIGURE 1

PARTS REQUIRED:

8 pcs - H1 Allen Head Bolt 8 pcs - H7 Phillips Round Head Screw 4 pcs - P12 Corner Post
8 pcs - H3 Flat Washer 2 pcs - P2 End Apron 1 pc - T1 Allen Wrench

P1

NOTE:

Graphic on this side.

Groove

P3

P1

STEP 2:

Attach P2 End Aprons onto P1 Side Apron using H1 Allen Head Bolts with H3 Flat Washers as shown in DETAIL A.
Do not tighten H1 Bolts on this time.

Slide P12 Corner Posts on the each end of P1 Side Apron and P2 End Apron. Use T1 Allen Wrench to tighten H1
Bolts. Use H7 Screws to secure P12 Corner Post as shown in FIGURE 2. Tighten, but do not strip out H7
Screws.

P12

NOTE: Install P12 Corner Posts
with arrow pointing down.

ATTENTION:

THIS STEP REQUIRES TWO OR MORE ADULTS.

VERY CAREFULLY ATTACH P12 CORNER POST

ONTO EACH P1 & P2 APRON.

P1

NOTE: P12 Corner Post should be
flush with bottom of P1 Side and
P2 End aprons.

P12

H7

H7

P2

DETAIL A

P12

H3

H3

H1

All Rights Reserved.

©

2012 Escalade Sports

P2

P12

FIGURE 2

P1

5

For Customer Service Call 1-888-996-2729

PARTS REQUIRED:

12 pcs - H4 Phillips Washer Head Screw 3 pcs - P5 Playfield
6 pcs - H5 Phillips Flat Head Screw Support Brace

STEP 3:

Center and attach P3 Playfield in the cabinet using pre-drilled pilot holes with H4 Screws as shown in FIGURE 3.
Place each P5 Playfield Support Brace and attach using pre-drilled pilot holes with H5 Screws as shown in
FIGURE 3.

H4

Important Note: Please be sure to install H4 screws and H5 screws
exactly as per FIGURE 3. Screws must be screwed straight down.

H5

P5

PARTS REQUIRED:

16 pcs - H2 Allen Head Bolt 4 pcs - P4 Leg
16 pcs - H3 Flat Washer 4 pcs - P10 Leg Leveler
1 pc - T1 Allen Wrench

P5

DETAIL B

P5

H3

H2

FIGURE 3

P10

P10

P4

STEP 4:

Attach P4 Legs using H2 Allen Head
Bolts with H3 Flat Washers as shown
in FIGURE 4 & DETAIL B.
Use T1 Allen Wrench to tighten H1 Bolts.

Thread P10 Leg Levelers onto each P4 Leg
as shown in FIGURE 4.

FIGURE 4

All Rights Reserved.

©

2012 Escalade Sports

P10

P4

P4

P10

P4

6

For Customer Service Call 1-888-996-2729

PARTS REQUIRED:

12 pcs - H7 Phillips Round Head Screw 2 pcs - P7 Ball Catcher
2 pcs - P6 Goal Box 2 pcs - P8 Ball Return Tube

STEP 5:

Center P6 Goal Box over the opening in the end panel and attach using pre-drilled pilot holes with H7 Screws as
shown in FIGURE 5.

Center P7 Ball Catcher over the opening in the side panel and attach using pre-drilled pilot holes with H7 Screws
as shown in FIGURE 5.
Make sure the round opening for P8 Ball Return Tube is towards the floor (when table is turned upright).
Repeat for both ends of the table.

Attach P8 Ball Return Tubes between P6 Goal Box and P7 Ball Catcher as shown in FIGURE 5.

NOTE: Make sure the round opening

P8

P7

for the ball return tube is towards the
floor (when table is turned upright)

P6

H7

FIGURE 5

All Rights Reserved.

©

2012 Escalade Sports

CAUTION:

THIS STEP REQUIRES FOUR OR MORE ADULTS.

VERY CAREFULLY TURN THE TABLE OVER AND SET IT ON

ITS LEGS. BE CAREFUL. THE TABLE IS VERY HEAVY.

7

For Customer Service Call 1-888-996-2729

PARTS REQUIRED:

6 pcs - H6 Phillips Round Head Screw 4 pcs - P11 Corner Cap 2 pcs - P18 Ball Entry Cup
8 pcs - H9 Phillips Flat Head Screw 2 pcs - P13 Scorer 4 pcs - P24 Cup Holder
2 pcs - P9 Playfield Trim 16 pcs - P17 Rod Bushing

STEP 6:

Peel the protective coating off P9 Playfield Trims, then peel the adhesive strip protective coating off the underside
of P9 Playfield Trims, then very carefully place them along P3 Playfield as shown in FIGURE 6.

Attach P11 Corner Caps using H9 Screws as shown in FIGURE 6.

Tighten, but do not strip out H9 Screws.

Attach P13 Scorers onto the top of P2 End Apron as shown in FIGURE 6.

Insert P17 Rod Bushings onto both P1 Side Aprons as shown in FIGURE 6.
Please make sure to insert P17 Rod Bushings from the inner side of P1 Side Apron for correct assembly.

IMPORTANT NOTE: P17 Rod Bushings may require the use of a rubber hammer for installation into side apron.
With a rubber hammer, lightly tap bushing squarely into place. DO NOT USE STEEL HAMMER!
If a rubber hammer is not available, place a piece of wood squarely on bushing and lightly tap into place.

Attach P18 Ball Entry Cups using H6 Screws as shown in DETAIL C.
Tighten, but do not strip out H6 Screws.

P13

Carefully - Tap P24 Cup Holders down into P2 End
Aprons as shown in FIGURE 6.

P24

P9

Note:

Red Bead scorer should
be on opposite side of
Ball Return.

Note:

Carefully tap P24
Cup Holders down.

Note:

Red Bead scorer should
be on opposite side of
Ball Return.

H9

P13

P17

Rubber
Hammer

DETAIL C

P11

H9

P18

H6

FIGURE 6

All Rights Reserved.

©

2012 Escalade Sports

8
