Atmel ATmega128, ATmega128L Datasheet

Features

Not

This i

• High-performance, Low-power AVR

• Advanced RISC Architecture

– 133 Powerful Instructions – Most Single Clock Cycle Execution
– 32 x 8 General Purpose Working Registers + Peripheral Control Registers
– Fully Static Operation
– Up to 16 MIPS Throughput at 16 MHz
– On-chip 2-cycle Multiplier

• Nonvolatile Program and Data Memories

– 128K Bytes of In-System Reprogrammable Flash

Endurance: 1,000 Write/Erase Cycles

– Optional Boot Code Section with Independent Lock Bits

In-System Programming by On-chip Boot Program
True Read-While-Write Operation

– 4K Bytes EEPROM

Endurance: 100,000 Write/Erase Cycles

– 4K Bytes Internal SRAM
– Up to 64K Bytes Optional External Memory Space
– Programming Lock for Software Security
– SPI Interface for In-System Programming

• JTAG (IEEE std. 1149.1 Compliant) Interface

– Boundary-scan Capabilities According to the JTAG Standard
– Extensive On-chip Debug Support
– Programming of Flash, EEPROM, Fuses and Lock Bits through the JTAG Interface

• Peripheral Features

– Two 8-bit Timer/Counters with Separate Prescalers and Compare Modes
– Two Expanded 16-bit Timer/Counters with Separate Prescaler, Compare Mode and

Capture Mode

– Real Time Counter with Separate Oscillator
– Two 8-bit PWM Channels
– 6 PWM Channels with Programmable Resolution from 1 to 16 Bits
– 8-channel, 10-bit ADC

8 Single-ended Channels
7 Differential Channels
2 Differential Channels with Programmable Gain (1x, 10x, 200x)

– Byte-oriented 2-wire Serial Interface
– Dual Programmable Serial USARTs
– Master/Slave SPI Serial Interface
– Programmable Watchdog Timer with On-chip Oscillator
– On-chip Analog Comparator

• Special Microcontroller Features

– Power-on Reset and Programmable Brown-out Detection
– Internal Calibrated RC Oscillator
– External and Internal Interrupt Sources
– Six Sleep Modes: Idle, ADC Noise Reduction, Power-save, Power-down, Standby

and Extended Standby

– Software Selectable Clock Frequency
– ATmega103 Compatibility Mode Selected by a Fuse
– Global Pull-up Disable

• I/O and Packages

– 53 Programmable I/O Lines
– 64-lead TQFP

• Operating Voltages

– 2.7 - 5.5V (ATmega128L)
– 4.5 - 5.5V (ATmega128)

• Speed Grades

– 0 - 8 MHz (ATmega128L)
– 0 - 16 MHz (ATmega128)

®

8-bit Microcontroller

8-bit
Microcontroller
with 128K Bytes
In-System
Programmable
Flash

ATmega128
ATmega128L

Preliminary

Summary

Rev. 2467AS-08/01

e:

ava ila ble on ou r w eb site at www.atmel.com.

s a summary docum ent. A complete document is

1

Pin Configurations Figure 1. Pinout ATmega128

AVCC

GND

AREF

PF0 (ADC0)

PF1 (ADC1)

PF2 (ADC2)

PF3 (ADC3)

PF4 (ADC4/TCK)

PF5 (ADC5/TMS)

PF6 (ADC6/TDO)

PF7 (ADC7/TDI)

GND

VCC

PA0 (AD0)

PA1 (AD1)

PA2 (AD2)

PEN

RXD0/(PDI) PE0

(TXD0/PDO) PE1

(XCK0/AIN0) PE2
(OC3A/AIN1) PE3
(OC3B/INT4) PE4
(OC3C/INT5) PE5

(T3/INT6) PE6

(IC3/INT7) PE7

(SS) PB0

(SCK) PB1
(MOSI) PB2
(MISO) PB3

(OC0) PB4

(OC1A) PB5
(OC1B) PB6

646362616059585756555453525150

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16

171819202122232425262728293031

VCC

GND

XTAL2

RESET

TOSC2/PG3

TOSC1/1PG4

(OC2/OC1C) PB7

XTAL1

(SCL/INT0) PD0

(SDA/INT1) PD1

(RXD1/INT2) PD2

(TXD1/INT3) PD3

(T1) PD6

(IC1) PD4

(XCK1) PD5

49
48

PA3 (AD3)

47

PA4 (AD4)

46

PA5 (AD5)

45

PA6 (AD6)

44

PA7 (AD7)

43

PG2(ALE)

42

PC7 (A15)

41

PC6 (A14)

40

PC5 (A13)

39

PC4 (A12)

38

PC3 (A11)

37

PC2 (A10)

36

PC1 (A9)

35

PC0 (A8)

34

PG1(RD)

33

PG0(WR)

32

(T2) PD7

Overview The ATmega128 is a low-power CMOS 8-bit microcontroller based on the AVR

enhanced RISC architecture. By executing powerful instructions in a single clock cycle,
the ATmega128 achieves throughputs approaching 1 MIPS per MHz allowing the sys­tem designer to optimize power consumption versus processing speed.

2

ATmega128(L)

2467AS–08/01

Block Diagram

Figure 2. Block Diagram

ATmega128(L)

VCC

GND

AVCC

AGND

AREF

PEN

DATA REGISTER

JTAG TAP

ON-CHIP DEBUG

BOUNDARY-

SCAN

PROGRAMMING

LOGIC

PORTF DRIVERS

PORTF

DATA DIR.

REG. PORTF

ADC

PROGRAM
COUNTER

PROGRAM

FLASH

INSTRUCTION

REGISTER

INSTRUCTION

DECODER

DATA REGISTER

PORTA

STACK

POINTER

SRAM

GENERAL
PURPOSE

REGISTERS

X

Y

Z

PA0 - PA7PF0 - PF7

PORTA DRIVERS

DATA DIR.

REG. PORTA

8-BIT DATA BUS

INTERNAL

OSCILLATOR

WATCHDOG

TIMER

MCU CONTROL

REGISTER

TIMER/

COUNTERS

INTERRUPT

UNIT

PORTC DRIVERS

DATA REGISTER

PORTC

CALIB. OSC

OSCILLATOR

OSCILLATOR

TIMING AND

CONTROL

PC0 - PC7

DATA DIR.

REG. PORTC

XTAL1

XTAL2

RESET

TOR

ANALOG

COMPARA

DATA REGISTER

+

-

USART0

PORTE

CONTROL

LINES

DATA DIR.

REG. PORTE

PORTE DRIVERS

ALU

STATUS

REGISTER

DATA REGISTER

PORTB

PORTB DRIVERS

PB0 - PB7PE0 - PE7

DATA DIR.

REG. PORTB

EEPROM

SPI

DATA REGISTER

PORTD

PORTD DRIVERS

PD0 - PD7

USART1

DATA DIR.

REG. PORTD

2-WIRE SERIAL

INTERFACE

DATA REG.

PORTG

DATA DIR.

REG. PORTG

PORTG DRIVERS

PG0 - PG4

2467AS–08/01

3

The AVR core combines a rich instruction set with 32 general purpose working registers.
All the 32 registers are directly connected to the Arithmetic Logic Unit (ALU), allowing
two independent registers to be accessed in one single instruction executed in one clock
cycle. The resulting architecture is more code efficient while achieving throughputs up to
ten times faster than conventional CISC microcontrollers.

The ATmega128 provides the following features: 128K bytes of In-System Programma­ble Flash with Read-While-Write capabilities, 4K bytes EEPROM, 4K bytes SRAM, 53
general-purpose I/O lines, 32 general purpose working registers, Real Time Counter
(RTC), four flexible timer/counters with compare modes and PWM, 2 USARTs, a byte
oriented 2-wire Serial Interface, an 8-channel, 10-bit ADC with optional differential input
stage with programmable gain, programmable Watchdog Timer with internal oscillator,
an SPI serial port, IEEE std. 1149.1 compliant JTAG test interface, also used for
accessing the On-chip Debug system and programming and six software selectable
power saving modes. The Idle mode stops the CPU while allowing the SRAM,
timer/counters, SPI port, and interrupt system to continue functioning. The Power-down
mode saves the register contents but freezes the oscillator, disabling all other chip func­tions until the next interrupt or hardware reset. In Power-save mode, the asynchronous
timer continues to run, allowing the user to maintain a timer base while the rest of the
device is sleeping. The ADC Noise Reduction Mode stops the CPU and all I/O modules
except asynchronous timer and ADC, to minimize switching noise during ADC conver­sions. In Standby mode, the crystal/resonator oscillator is running while the rest of the
device is sleeping. This allows very fast start-up combined with low power consumption.
In Extended Standby mode, both the main oscillator and the asynchronous timer con­tinue to run.

ATmega103 and ATmega128 Compatibility

The device is manufactured using Atmel’s high-density nonvolatile memory technology.
The on-chip ISP Flash allows the program memory to be reprogrammed in-system
through an SPI serial interface, by a conventional nonvolatile memory programmer, or
by an on-chip Boot program running on the AVR core. The boot program can use any
interface to download the application program in the application Flash memory. Soft­ware in the Boot Flash section will continue to run while the Application Flash section is
updated, providing true Read-While-Write operation. By combining an 8-bit RISC CPU
with In-System Self-Programmable Flash on a monolithic chip, the Atmel ATmega128 is
a powerful microcontroller that provides a highly flexible and cost effective solution to
many embedded control applications.

The ATmega128 AVR is supported with a full suite of program and system development
tools including: C compilers, macro assemblers, program debugger/simulators, in-circuit
emulators, and evaluation kits.

The ATmega128 is a highly complex microcontroller where the number of I/O locations
supersedes the 64 I/O location reserved in the AVR instruction set. To ensure backward
compatibility with the ATmega103, all I/O locations present in ATmega103 have the
same location in ATmega128. Most additional I/O locations are added in an Extended
I/O space starting from $60 to $FF, (i.e., in the ATmega103 internal RAM space). These
location can be reached by using LD/LDS/LDD and ST/STS/STD instruction only, not by
using IN and OUT instruction. The relocation of the internal RAM space may still be a
problem for ATmega103 users. Also, the increased number of interrupt vectors might be
a problem if the code uses absolute addresses. To solve these problems, an
ATmega103 compatibility mode can be selected by programming the fuse M103C. In
this mode, none of the functions in the Extended I/O space are in use, so the internal
RAM is located as in ATmega103. Also, the extended interrupt vectors are removed.

4

ATmega128(L)

2467AS–08/01

ATmega128(L)

The ATmega128 is 100% pin compatible with ATmega103, and can replace the
ATmega103 on current Printed Circuit Boards. The application note “Replacing
ATmega103 by ATmega128” describes what the user should be aware of replacing the
ATmega103 by an ATmega128.

ATmega103 Compatibility Mode

By programming the M103C fuse, the ATmega128 will be compatible with the
ATmega103 regards to RAM, I/O pins and interrupt vectors as described above. How­ever, some new features in ATmega128 are not available in this compatibility mode,
these features are listed below:

• One USART instead of two, asynchronous mode only. Only the 8 least significant
bits of the Baud Rate Register is available.

• One 16 bits Timer/Counter with 2 compare registers instead of two 16-bit
Timer/Counters with 3 compare registers.

• 2-wire serial interface is not supported.

• Port G serves alternate functions only (not a general I/O port).

• Port F serves as digital input only in addition to analog input to the ADC.

• Boot Loader capabilities is not supported.

• It is not possible to adjust the frequency of the internal calibrated RC oscillator.

• The External Memory Interface can not release any Address pins for general I/O,

neither configure different wait-states to different External Memory Address
sections.

Pin Descriptions

VCC Digital supply voltage.

GND Ground.

Port A (PA7..PA0) Port A is an 8-bit bi-directional I/O port with internal pull-up resistors (selected for each

bit). The Port A output buffers have symmetrical drive characteristics with both high sink
and source capability. As inputs, Port A pins that are externally pulled low will source
current if the pull-up resistors are activated. The Port A pins are tri-stated when a reset
condition becomes active, even if the clock is not running.

Port A also serves the functions of various special features of the ATmega128 as listed

page 68.

on

Port B (PB7..PB0) Port B is an 8-bit bi-directional I/O port with internal pull-up resistors (selected for each

bit). The Port B output buffers have symmetrical drive characteristics with both high sink
and source capability. As inputs, Port B pins that are externally pulled low will source
current if the pull-up resistors are activated. The Port B pins are tri-stated when a reset
condition becomes active, even if the clock is not running.

Port B also serves the functions of various special features of the ATmega128 as listed

page 69.

on

Port C (PC7..PC0) Port C is an 8-bit bi-directional I/O port with internal pull-up resistors (selected for each

bit). The Port C output buffers have symmetrical drive characteristics with both high sink
and source capability. As inputs, Port C pins that are externally pulled low will source
current if the pull-up resistors are activated. The Port C pins are tri-stated when a reset
condition becomes active, even if the clock is not running.

2467AS–08/01

5

Port C also serves the functions of special features of the ATmega128 as listed on page

72

. In ATmega103 compatibility mode, Port C is output only, and the port C pins are not

tri-stated when a reset condition becomes active.

Port D (PD7..PD0) Port D is an 8-bit bidirectional I/O port with internal pull-up resistors (selected for each

bit). The Port D output buffers have symmetrical drive characteristics with both high sink
and source capability. As inputs, Port D pins that are externally pulled low will source
current if the pull-up resistors are activated. The Port D pins are tri-stated when a reset
condition becomes active, even if the clock is not running.

Port D also serves the functions of various special features of the ATmega128 as listed

page 73.

on

Port E (PE7..PE0) Port E is an 8-bit bidirectional I/O port with internal pull-up resistors (selected for each

bit). The Port E output buffers have symmetrical drive characteristics with both high sink
and source capability. As inputs, Port E pins that are externally pulled low will source
current if the pull-up resistors are activated. The Port E pins are tri-stated when a reset
condition becomes active, even if the clock is not running.

Port E also serves the functions of various special features of the ATmega128 as listed

page 76.

on

Port F (PF7..PF0) Port F serves as the analog inputs to the A/D Converter.

Port F also serves as an 8-bit bi-directional I/O port, if the A/D Converter is not used.
Port pins can provide internal pull-up resistors (selected for each bit). The Port F output
buffers have symmetrical drive characteristics with both high sink and source capability.
As inputs, Port F pins that are externally pulled low will source current if the pull-up
resistors are activated. The Port F pins are tri-stated when a reset condition becomes
active, even if the clock is not running. If the JTAG interface is enabled, the pull-up resis­tors on pins PF7(TDI), PF5(TMS) and PF4(TCK) will be activated even if a reset occurs.

Port F also serves the functions of the JTAG interface.

In ATmega103 compatibility mode, Port F is an input Port only.

Port G (PG4..PG0) Port G is a 5-bit bidirectional I/O port with internal pull-up resistors (selected for each

bit). The Port G output buffers have symmetrical drive characteristics with both high sink
and source capability. As inputs, Port G pins that are externally pulled low will source
current if the pull-up resistors are activated. The Port G pins are tri-stated when a reset
condition becomes active, even if the clock is not running.

Port G also serves the functions of various special features.

The port G pins are tri-stated when a reset condition becomes active, even if the clock is
not running.

In ATmega103 compatibility mode, these pins only serves as strobes signals to the
external memory as well as input to the 32 kHz oscillator, and the pins are initialized to
PG0 = 1, PG1 = 1, and PG2 = 0 asynchronously when a reset condition becomes active,
even if the clock is not running. PG3 and PG4 are oscillator pins.

RESET

XTAL1 Input to the inverting oscillator amplifier and input to the internal clock operating circuit.

Reset input. A low level on this pin for longer than the minimum pulse length will gener­ate a reset, even if the clock is not running. The minimum pulse length is given in

19 on page 46

. Shorter pulses are not guaranteed to generate a reset.

Table

6

ATmega128(L)

2467AS–08/01

ATmega128(L)

XTAL2 Output from the inverting oscillator amplifier.

AVCC This is the supply voltage pin for Port F and the A/D Converter. It should be externally

connected to VCC, even if the ADC is not used. If the ADC is used, it should be con­nected to VCC through a low-pass filter.

AREF This is the analog reference pin for the A/D Converter.

PEN This is a programming enable pin for the serial programming mode. By holding this pin

low during a power-on reset, the device will enter the serial programming mode. PEN
has no function during normal operation.

2467AS–08/01

7

Register Summary

Address Name Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0 Page

($FF) Reserved - - - - - - - -

.. Reserved - - - - - - - ­($9E)

($9D) UCSR1C - UMSEL1 UPM11 UPM10 USBS1 UCSZ11 UCSZ10 UCPOL1 185

($9C) UDR1 USART1 I/O Data Register 182

($9B) UCSR1A RXC1 TXC1 UDRE1 FE1 DOR1 UPE1 U2X1 MPCM1 183

($9A) UCSR1B RXCIE1 TXCIE1 UDRIE1 RXEN1 TXEN1 UCSZ12 RXB81 TXB81 184

($99) UBRR1L USART1 Baud Rate Register Low 186

($98) UBRR1H
($97)

($96)

($95) UCSR0C
($94)

($93)

($92)

($91)

($90) UBRR0H
($8F)

($8E)

($8D)

($8C)

($8B) TCCR3A COM3A1 COM3A0 COM3B1 COM3B0 COM3C1 COM3C0 WGM31 WGM30 127

($8A) TCCR3B ICNC3 ICES3

($89) TCNT3H Timer/Counter3 - Counter Register High Byte 132

($88) TCNT3L Timer/Counter3 - Counter Register Low Byte 132

($87) OCR3AH Timer/Counter3 - Output Compare Register A High Byte 133

($86) OCR3AL Timer/Counter3 - Output Compare Register A Low Byte 133

($85) OCR3BH Timer/Counter3 - Output Compare Register B High Byte 133

($84) OCR3BL Timer/Counter3 - Output Compare Register B Low Byte 133

($83) OCR3CH Timer/Counter3 - Output Compare Register C High Byte 133

($82) OCR3CL Timer/Counter3 - Output Compare Register C Low Byte 133

($81) ICR3H Timer/Counter3 - Input Capture Register High Byte 134

($80) ICR3L Timer/Counter3 - Input Capture Register Low Byte 134
($7F)

($7E)

($7D) ETIMSK

($7C) ETIFR - - ICF3 OCF3A OCF3B TOV3 OCF3C OCF1C 136

($7B)

($7A)

($79) OCR1CH Timer/Counter1 - Output Compare Register C High Byte 133

($78) OCR1CL Timer/Counter1 - Output Compare Register C Low Byte 133
($77)

($76)

($75)

($74) TWCR TWINT TWEA TWSTA TWSTO TWWC TWEN -TWIE 198

($73) TWDR 2-wire Serial Interface Data Register 199

($72) TWAR TWA6 TWA5 TWA4 TWA3 TWA2 TWA1 TWA0 TWGCE 200

($671 TWSR TWS7 TWS6 TWS5 TWS4 TWS3 - TWPS1 TWPS0 199

($70) TWBR 2-wire Serial Interface Bit Rate Register 197

($6F) OSCCAL Oscillator Calibration Register 38
($6E)

($6D)

($6C)

($6B)

($6A) EICRA ISC31 ISC30 ISC21 ISC20 ISC11 ISC10 ISC01 ISC00 84
($69)

($68)

($67)

($66)

($65)

($64)

($63)

($62) PORTF PORTF7 PORTF6 PORTF5 PORTF4 PORTF3 PORTF2 PORTF1 PORTF0 83

Reserved - - - - - - - -

Reserved

Reserved - - - - - - - -

Reserved

Reserved - - - - - - - -

Reserved

Reserved - - - - - - - -

Reserved

Reserved - - - - - - - -

Reserved

TCCR3C FOC3A FOC3B FOC3 C

Reserved

Reserved

Reserved

TCCR1C FOC1A FOC1B FOC1 C

Reserved - - - - - - - -

Reserved - - - - - - - -

Reserved - - - - - - - -

Reserved - - - - - - - -

XMCRA - SRL2 SRL1 SRL0 SRW01 SRW00 SRW11 29

XMCRB XMBK - - - - XMM2 XMM1 XMM0 31

Reserved - - - - - - - -

Reserved - - - - - - - -

SPMCSR SPMIE RWWSB - RWWSRE BLBSET PGWRT PGERS SPMEN 270

Reserved - - - - - - - -

Reserved - - - - - - - -

PORTG - - - PORTG4 PORTG3 PORTG2 PORTG1 PORTG0 83

DDRG - - - DDG4 DDG3 DDG2 DDG1 DDG0 83

PING - - - PING4 PING3 PING2 PING1 PING0 83

- - - - USART1 Baud Rate Register High 186

- - - - - - - -

- UMSEL0 UPM01 UPM00 USBS0 UCSZ01 UCSZ00 UCPOL0 185

- - - - - - - -

- - - - - - - -

- - - - USART0 Baud Rate Register High 186

- - - - - - - -

- - - - - - - -

- - - - -132

- WGM33 WGM32 CS32 CS31 CS30 130

- - - - - - - -

- - - - - - - -

- - TICIE3 OCIE3A OCIE3B TOIE3 OCIE3C OCIE1C 135

- - - - - - - -

- - - - -131

8

ATmega128(L)

2467AS–08/01

ATmega128(L)

Register Summary (Continued)

Address Name Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0 Page

($61) DDRF DDF7 DDF6 DDF5 DDF4 DDF3 DDF2 DDF1 DDF0 83

($60) Reserved - - - - - - - -

$3F ($5F) SREG I T H S V N Z C 9

$3E ($5E) SPH SP15 SP14 SP13 SP12 SP11 SP10 SP9 SP8 12

$3D ($5D) SPL SP7 SP6 SP5 SP4 SP3 SP2 SP1 SP0 12

$3C ($5C) XDIV X DIVEN XDIV6 XDIV5 XDIV4 XDIV3 XDIV2 XDIV1 XDIV0 39

$3B ($5B) RAMPZ

$3A ($5A) EICRB ISC71 ISC70 ISC61 ISC60 ISC51 ISC50 ISC41 ISC40 85

$39 ($59) EIMSK INT7 INT6 INT5 INT4 INT3 INT2 INT1 INT0 86

$38 ($58) EIFR INTF7 INTF6 INTF5 INTF4 INTF3 INTF INTF1 INTF0 86

$37 ($57) TIMSK OCIE2 TOIE2 TICIE1 OCIE1A OCIE1B TOIE1 OCIE0 TOIE0 103, 134, 153

$36 ($56) TIFR OCF2 TOV2 ICF1 OCF1A OCF1B TOV1 OCF0 TOV0 103, 136, 154

$35 ($55) MCUCR SRE SRW10 SE SM1 SM0 SM2 IVSEL IVCE 29, 41, 58

$34 ($54) MCUCSR JTD

$33 ($53) TCCR0 FOC0 WGM00 COM01 COM00 WGM01 CS02 CS01 CS00 98

$32 ($52) TCNT0 Timer/Counter0 (8 Bit) 100

$31 ($51) OCR0 Timer/Counter0 Output Compare Register 100

$30 ($50) ASSR - - - - AS0 TCN0UB OCR0UB TCR0UB 101

$2F ($4F) TCCR1A COM1A1 COM1A0 COM1B1 COM1B0 COM1C1 COM1C0 WGM11 WGM10 127

$2E ($4E) TCCR1B ICNC1 ICES1

$2D ($4D) TCNT1H Timer/Counter1 - Counter Register High Byte 132

$2C ($4C) TCNT1L Timer/Counter1 - Counter Register Low Byte 132

$2B ($4B) OCR1AH Timer/Counter1 - Output Compare Register A High Byte 133

$2A ($4A) OCR1AL Timer/Counter1 - Output Compare Register A Low Byte 133

$29 ($49) OCR1BH Timer/Counter1 - Output Compare Register B High Byte 133

$28 ($48) OCR1BL Timer/Counter1 - Output Compare Register B Low Byte 133

$27 ($47) ICR1H Timer/Counter1 - Input Capture Register High Byte 134

$26 ($46) ICR1L Timer/Counter1 - Input Capture Register Low Byte 134

$25 ($45) TCCR2 FOC2 WGM20 COM21 COM20 WGM21 CS22 CS21 CS20 151

$24 ($44) TCNT2 Timer/Counter2 (8 Bit) 153

$23 ($43) OCR2 Timer/Counter2 Output Compare Register 153

$22 ($42) OCDR

$21 ($41) WDTCR

$20 ($40) SFIOR TSM

$1F ($3F) EEARH - - - - EEPROM Address Register High 19

$1E ($3E) EEARL EEPROM Address Register Low Byte 19

$1D ($3D) EEDR EEPROM Data Register 20

$1C ($3C) EECR - - - - EERIE EEMWE EEWE EERE 20

$1B ($3B) PORTA PORTA7 PORTA6 P ORTA5 PORTA4 PORTA3 PORTA2 PORTA1 PORTA0 81

$1A ($3A) DDRA DDA7 DDA6 DDA5 DDA4 DDA3 DDA2 DDA1 DDA0 81

$19 ($39) PINA PINA7 PINA6 PINA5 PINA4 PINA3 PINA2 PINA1 PINA0 81

$18 ($38) PORTB PORTB7 PORTB6 PORTB5 PORTB4 PORTB3 PORTB2 PORTB1 PORTB0 81

$17 ($37) DDRB DDB7 DDB6 DDB5 DDB4 DDB3 DDB2 DDB1 DDB0 81

$16 ($36) PINB PINB7 PINB6 PINB5 PINB4 PINB3 PINB2 PINB1 PINB0 82

$15 ($35) PORTC PORTC7 PORTC6 PORTC5 PORTC4 PORTC3 PORTC2 PORTC1 PORTC0 82

$14 ($34) DDRC DDC7 DDC6 DDC5 DDC4 DDC3 DDC2 DDC1 DDC0 82

$13 ($33) PINC PINC7 PINC6 PINC5 PINC4 PINC3 PINC2 PINC1 PINC0 82

$12 ($32) PORTD PORTD7 PORTD6 PORTD5 PORTD4 PORTD3 PORTD2 PORTD1 PORTD0 82

$11 ($31) DDRD DDD7 DDD6 DDD5 DDD4 DDD3 DDD2 DDD1 DDD0 82

$10 ($30) PIND PIND7 PIND6 PIND5 PIND4 PIND3 PIND2 PIND1 PIND0 82

$0F ($2F) SPDR SPI Data Register 163

$0E ($2E) SPSR SPIF WCOL - - - - -SPI2X 162

$0D ($2D) SPCR SPIE SPE DORD MSTR CPOL CPHA SPR1 SPR0 161

$0C ($2C) UDR0 USART0 I/O Data Register 182

$0B ($2B) UCSR0A RXC0 TXC0 UDRE0 FE0 DOR0 UPE0 U2X0 MPCM0 183

$0A ($2A) UCSR0B RXCIE0 TXCIE0 UDRIE0 RXEN0 TXEN0 UCSZ02 RXB80 TXB80 184

$09 ($29) UBRR0L USART0 Baud Rate Register Low 186

$08 ($28) ACSR ACD ACBG ACO ACI ACIE ACIC ACIS1 ACIS0 218

$07 ($27) ADMUX REFS1 REFS0 ADLAR MUX4 MUX3 MUX2 MUX1 MUX0 233

$06 ($26) ADCSRA ADEN ADSC ADRF ADIF ADIE ADPS2 ADPS1 ADPS0 235

$05 ($25) ADCH ADC Data Register High Byte 236

$04 ($24) ADCL ADC Data Register Low byte 236

$03 ($23) PORTE PORTE7 PORTE6 PORTE5 PORTE4 PORTE3 PORTE2 PORTE1 PORTE0 82

$02 ($22) DDRE DDE7 DDE6 DDE5 DDE4 DDE3 DDE2 DDE1 DDE0 83

- - - - - - - RAMPZ0 12

- - JTRF WDRF BORF EXTRF PORF 49, 246

- WGM13 WGM12 CS12 CS11 CS10 130

IDRD/

OCDR7

- - - WDCE WDE WDP2 WDP1 WDP 0 51

OCDR6 OCDR5 OCDR4 OCDR3 OCDR2 OCDR1 OCDR0 242

- - ADHSM ACME PUD PSR0 PSR321 67, 104, 139, 237

2467AS–08/01

9

Register Summary (Continued)

Address Name Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0 Page

$01 ($21) PINE PINE7 PINE6 PINE5 PINE4 PINE3 PINE2 PINE1 PINE0 83

$00 ($20) PINF PINF7 PINF6 PINF5 PINF4 PINF3 PINF2 PINF1 PINF0 83

Notes: 1. For compatibility with future devices, reserved bits should be written to zero if accessed. Reserved I/O memory addresses

should never be written.

2. Some of the status flags are cleared by writing a logical one to them. Note that the CBI and SBI instructions will operate on
all bits in the I/O register, writing a one back into any flag read as set, thus clearing the flag. The CBI and SBI instructions
work with registers $00 to $1F only.

10

ATmega128(L)

2467AS–08/01

ATmega128(L)

Instruction Set Summary

Mnemonics Operands Description Operation Flags #Clocks

ARITHMETIC AND LOGIC INSTRUCTIONS

ADD Rd, Rr Add two Registers Rd ← Rd + Rr Z,C,N,V,H 1

ADC Rd, Rr Add with Carry two Registers Rd ← Rd + Rr + C Z,C,N,V,H 1

ADIW Rdl,K Add Immediate to Word Rdh:Rdl ← Rdh:Rdl + K Z,C,N,V ,S 2

SUB Rd, Rr Subtract two Registers Rd ← Rd - Rr Z,C,N,V,H 1

SUBI Rd, K Subtract Constant from Register Rd ← Rd - K Z,C,N,V,H 1

SBC Rd, Rr Subtract with Carry two Registers Rd ← Rd - Rr - C Z,C,N,V,H 1

SBCI Rd, K Subtract with Carry Constant from Reg. Rd ← Rd - K - C Z,C,N,V,H 1

SBIW Rdl,K Subtract Immediate from Word Rdh:Rdl ← Rdh:Rdl - K Z,C,N,V ,S 2

AND Rd, Rr Logical AND Registers Rd ← Rd • Rr Z,N,V 1

ANDI Rd, K Logical AND Register and Constant Rd ← Rd • KZ,N,V1

OR Rd, Rr Logical OR Registers Rd ← Rd v Rr Z,N,V 1

ORI Rd, K Logical OR Register and Constant Rd ← Rd v K Z,N,V 1

EOR Rd, Rr Exclusive OR Registers Rd ← Rd ⊕ Rr Z,N,V 1

COM Rd One’s Complement Rd ← $FF − Rd Z,C,N,V 1

NEG Rd Two’s Complement Rd ← $00 − Rd Z,C,N,V,H 1

SBR Rd,K Set Bit(s) in Register Rd ← Rd v K Z,N,V 1

CBR Rd,K Clear Bit(s) in Register Rd ← Rd • ($FF - K) Z,N,V 1

INC Rd Increment Rd ← Rd + 1 Z,N,V 1

DEC Rd Decrement Rd ← Rd − 1 Z,N,V 1

TST Rd Test for Zero or Minus Rd ← Rd • Rd Z,N,V 1

CLR Rd Clear Register Rd ← Rd ⊕ Rd Z,N,V 1

SER Rd Set Register Rd ← $FF None 1

MUL Rd, Rr Multiply Unsigned R1:R0 ← Rd x Rr Z,C 2

MULS Rd, Rr Multiply Signed R1:R0 ← Rd x Rr Z,C 2

MULSU Rd, Rr Multiply Signed with Unsigned R1:R0 ← Rd x Rr Z,C 2
FMUL Rd, Rr Fractional Multiply Unsigned R1:R0 ← (Rd x Rr) << 1 Z,C 2
FMULS Rd, Rr Fractional Multiply Signed R1:R0 ← (Rd x Rr) << 1 Z,C 2
FMULSU Rd, Rr Fractional Multiply Signed with Unsigned R1:R0 ← (Rd x Rr) << 1 Z,C 2

BRANCH INSTRUCTIONS

RJMP k Relative Jump PC ← PC + k + 1 None 2

IJMP Indirect Jump to (Z) PC ← Z None 2

JMP k Direct Jump PC ← k None 3

RCALL k Relative Subroutine Call PC ← PC + k + 1 None 3

ICALL Indirect Call to (Z) PC ← Z None 3

CALL k Direct Subroutine Call PC ← k None 4

RET Subroutine Return PC ← STACK None 4

RETI Interrupt Return PC ← STACK I 4

CPSE Rd,Rr Compare, Skip if Equal if (Rd = Rr) PC ← PC + 2 or 3 None 1 / 2 / 3

CP Rd,Rr Compare Rd − Rr Z, N,V,C,H 1

CPC Rd,Rr Compare with Carry Rd − Rr − C Z, N,V,C,H 1

CPI Rd,K Compare Register with Immediate Rd − K Z, N,V,C,H 1

SBRC Rr, b Skip if Bit in Register Cleared if (Rr(b)=0) PC ← PC + 2 or 3 None 1 / 2 / 3

SBRS Rr, b Skip if Bit in Register is Set if (Rr(b)=1) PC ← PC + 2 or 3 None 1 / 2 / 3

SBIC P, b Skip if Bit in I/O Register Cleared if (P(b)=0) PC ← PC + 2 or 3 None 1 / 2 / 3

SBIS P, b Skip if Bit in I/O Register is Set if (P(b)=1) PC ← PC + 2 or 3 None 1 / 2 / 3

BRBS s, k Branch if Status Flag Set if (SREG(s) = 1) then PC←PC+k + 1 None 1 / 2

BRBC s, k Branch if Status Flag Cleared if (SREG(s) = 0) then PC←PC+k + 1 None 1 / 2

BREQ k Branch if Equal if (Z = 1) then PC ← PC + k + 1 None 1 / 2

BRNE k Branch if Not Equal if (Z = 0) then PC ← PC + k + 1 None 1 / 2

BRCS k Branch if Carry Set if (C = 1) then PC ← PC + k + 1 None 1 / 2

BRCC k Branch if Carry Cleared if (C = 0) then PC ← PC + k + 1 None 1 / 2

BRSH k Branch if Same or Higher if (C = 0) then PC ← PC + k + 1 None 1 / 2

BRLO k Branch if Lower if (C = 1) then PC ← PC + k + 1 None 1 / 2

BRMI k Branch if Minus if (N = 1) then PC ← PC + k + 1 None 1 / 2

BRPL k Branch if Plus if (N = 0) then PC ← PC + k + 1 None 1 / 2

BRGE k Branch if Greater or Equal, Signed if (N ⊕ V= 0) then PC ← PC + k + 1 None 1 / 2

BRLT k Branch if Less Than Zero, Signed if (N ⊕ V= 1) then PC ← PC + k + 1 None 1 / 2

BRHS k Branch if Half Carry Flag Set if (H = 1) then PC ← PC + k + 1 None 1 / 2

BRHC k Branch if Half Carry Flag Cleared if (H = 0) then PC ← PC + k + 1 None 1 / 2

BRTS k Branch if T Flag Set if (T = 1) then PC ← PC + k + 1 None 1 / 2

BRTC k Branch if T Flag Cleared if (T = 0) then PC ← PC + k + 1 None 1 / 2

BRVS k Branch if Overflow Flag is Set if (V = 1) then PC ← PC + k + 1 None 1 / 2

BRVC k Branch if Overflow Flag is Cleared if (V = 0) then PC ← PC + k + 1 None 1 / 2

2467AS–08/01

11

Instruction Set Summary (Continued)

Mnemonics Operands Description Operation Flags #Clocks

BRIE k Branch if Interrupt Enabled if ( I = 1) then PC ← PC + k + 1 None 1 / 2

BRID k Branch if Interrupt Disabled if ( I = 0) then PC ← PC + k + 1 None 1 / 2

DATA TRANSFER INSTRUCTIONS

MOV Rd, Rr Move Between Registers Rd ← Rr None 1

MOVW Rd, Rr Copy Register Word

LDI Rd, K Load Immediate Rd ← K None 1

LD Rd, X Load Indirect Rd ← (X) None 2

LD Rd, X+ Load Indirect and Post-Inc. Rd ← (X), X ← X + 1 None 2

LD Rd, - X Load Indirect and Pre-Dec. X ← X - 1, Rd ← (X) None 2

LD Rd, Y Load Indirect Rd ← (Y) None 2

LD Rd, Y+ Load Indirect and Post-Inc. Rd ← (Y), Y ← Y + 1 None 2

LD Rd, - Y Load Indirect and Pre-Dec. Y ← Y - 1, Rd ← (Y) None 2

LDD Rd,Y+q Load Indirect with Displacement Rd ← (Y + q) None 2

LD Rd, Z Load Indirect Rd ← (Z) None 2

LD Rd, Z+ Load Indirect and Post-Inc. Rd ← (Z), Z ← Z+1 None 2

LD Rd, -Z Load Indirect and Pre-Dec. Z ← Z - 1, Rd ← (Z) None 2

LDD Rd, Z+q Load Indirect with Displacement Rd ← (Z + q) None 2

LDS Rd, k Load Direct from SRAM Rd ← (k) None 2

ST X, Rr Store Indirect (X) ← Rr None 2

ST X+, Rr Store Indirect and Post-Inc. (X) ← Rr, X ← X + 1 None 2

ST - X, Rr Store Indirect and Pre-Dec. X ← X - 1, (X) ← Rr None 2

ST Y, Rr Store Indirect (Y) ← Rr None 2

ST Y+, Rr Store Indirect and Post-Inc. (Y) ← Rr, Y ← Y + 1 None 2

ST - Y, Rr Store Indirect and Pre-Dec. Y ← Y - 1, (Y) ← Rr None 2

STD Y+q,Rr Store Indirect with Displacement (Y + q) ← Rr None 2

ST Z, Rr Store Indirect (Z) ← Rr None 2

ST Z+, Rr Store Indirect and Post-Inc. (Z) ← Rr, Z ← Z + 1 None 2

ST -Z, Rr Store Indirect and Pre-Dec. Z ← Z - 1, (Z) ← Rr None 2

STD Z+q,Rr Store Indirect with Displacement (Z + q) ← Rr None 2

STS k, Rr Store Direct to SRAM (k) ← Rr None 2

LPM Load Program Memory R0 ← (Z) None 3

LPM Rd, Z Load Program Memory Rd ← (Z) None 3

LPM Rd, Z+ Load Program Memory and Post-Inc Rd ← (Z), Z ← Z+1 None 3

ELPM Extended Load Program Memory R0 ← (RAMPZ:Z) None 3

ELPM Rd, Z Extended Load Program Memory Rd ← (RAMPZ:Z) None 3

ELPM Rd, Z+ Extended Load Program Memory and Post-Inc Rd ← (RAMPZ:Z), RAMPZ:Z ← RAMPZ:Z+1 None 3

SPM Store Program Memory (Z) ← R1:R0 None -

IN Rd, P In Port Rd ← P None 1

OUT P, Rr Out Port P ← Rr None 1

PUSH Rr Push Register on Stack STACK ← Rr None 2

POP Rd Pop Register from Stack Rd ← STACK None 2

BIT AND BIT-TEST INSTRUCTIONS

SBI P,b Set Bit in I/O Register I/O(P,b) ← 1 None 2

CBI P,b Clear Bit in I/O Register I/O(P,b) ← 0 None 2

LSL Rd Logical Shift Left Rd(n+1) ← Rd(n), Rd(0) ← 0 Z,C,N ,V 1

LSR Rd Logical Shift Right Rd(n) ← Rd(n+1), Rd(7) ← 0 Z,C,N ,V 1

ROL Rd Rotate Left Through Carry Rd(0)←C,Rd(n+1)← Rd(n),C←Rd(7) Z,C,N,V 1

ROR Rd Rotate Right Through Carry Rd(7)←C,Rd(n)← Rd(n+1),C←R d(0) Z,C,N,V 1

ASR Rd Arithmetic Shift Right Rd(n) ← Rd(n+1), n=0..6 Z,C,N,V 1

SWAP Rd Swap Nibbles Rd(3..0)←Rd(7..4),Rd(7..4)←Rd(3..0) None 1

BSET s Flag Set SREG(s) ← 1 SREG(s) 1

BCLR s Flag Clear SREG(s) ← 0 SREG(s) 1

BST Rr, b Bit Store from Register to T T ← Rr(b) T 1

BLD Rd, b Bit load from T to Register Rd(b) ← T None 1

SEC Set Carry C ← 1C1

CLC Clear Carry C ← 0 C 1

SEN Set Negative Flag N ← 1N1

CLN Clear Negative Flag N ← 0 N 1

SEZ Set Zero Flag Z ← 1Z1

CLZ Clear Zero Flag Z ← 0 Z 1

SEI Global Interrupt Enable I ← 1I1

CLI Global Interrupt Disable I ← 0 I 1

SES Set Signed Test Flag S ← 1S1

CLS Clear Signed Test Flag S ← 0 S 1

Rd+1:Rd ← Rr+1:Rr

None 1

12

ATmega128(L)

2467AS–08/01

ATmega128(L)

Instruction Set Summary (Continued)

Mnemonics Operands Description Operation Flags #Clocks

SEV Set Twos Complement Overflow. V ← 1V1

CLV Clear Twos Complement Overflow V ← 0 V 1

SET Set T in SREG T ← 1T1

CLT Clear T in SREG T ← 0 T 1

SEH Set Half Carry Flag in SREG H ← 1H1
CLH Clear Half Carry Flag in SREG H ← 0 H 1

MCU CONTROL INSTRUCTIONS

NOP No Operation None 1

SLEEP Sleep (see specific descr. for Sleep function) None 1

WDR Watchdog Reset (see specific descr. for WDR/timer) None 1
BREAK Break For On-chip Debug Only None N/A

2467AS–08/01

13

Ordering Information

Speed (MHz) Power Supply Ordering Code Package Operation Range

8 2.7 - 5.5V ATmega128-8AC 64A Commercial

ATmega128-8AI 64A Industrial

16 4.5 - 5.5V ATmega128-16AC 64A Commercial

ATmega128-16AI 64A Industrial

o

C to 70oC)

(0

o

(-40

o

C to 70oC)

(0

o

(-40

C to 85oC)

C to 85oC)

Package Type

64A 64-Lead, Thin (1.0 mm) Plastic Gull Wing Quad Flat Package (TQFP)

14

ATmega128(L)

2467AS–08/01

Packaging Information

64A

64-lead, Thin (1.0 mm) Plastic Quad Flat Package
(TQFP), 14x14mm body, 2.0mm footprint, 0.8mm pitch.
Dimensions in Millimeters and (Inches)*
JEDEC STANDARD MS-026 AEB

ATmega128(L)

PIN 1 ID

0.80(0.0315) BSC

16.25(0.640)
SQ

15.75(0.620)

PIN 1

0.45(0.018)

0.30(0.012)

2467AS–08/01

0.20(0.008)

0.09(0.004)

REV. A 04/11/2001

0˚~7˚

14.10(0.555)

13.90(0.547)

0.75(0.030)

0.45(0.018)

*Controlliing dimension: millimeter

SQ

1.20 (0.047) MAX

0.15(0.006)

0.05(0.002 )

15

Atmel Headquarters Atmel Product Operations

Corporate Headquarters

2325 Orchard Parkway
San Jose, CA 95131
TEL [phone]
FAX [phone]

Europe

Atmel SarL
Route des Arsenaux 41
Casa Postale 80
CH-1705 Fribourg
Switzerland
TEL [phone]
FAX [phone]

Asia

Atmel Asia, Ltd.
Room 1219
Chinachem Golden Plaza
77 Mody Road Tsimhatsui
East Kowloon
Hong Kong
TEL [phone]
FAX [phone]

Japan

Atmel Japan K.K.
9F, Tonetsu Shinkawa Bldg.
1-24-8 Shinkawa
Chuo-ku, Tokyo 104-0033
Japan
TEL [phone]
FAX [phone]

Atmel Colorado Springs

1150 E. Cheyenne Mtn. Blvd.
Colorado Springs, CO 80906
TEL [phone]
FAX [phone]

Atmel Grenoble

Avenue de Rochepleine
BP 123
38521 Saint-Egreve Cedex, France
TEL [phone]
FAX [phone]

Atmel Heilbronn

Theresienstrasse 2
POB 3535
D-74025 Heilbronn, Germany
TEL [phone]
FAX [phone]

Atmel Nantes

La Chantrerie
BP 70602
44306 Nantes Cedex 3, France
TEL [phone]
FAX [phone]

Atmel Rousset

Zone Industrielle
13106 Rousset Cedex, France
TEL [phone]
FAX [phone]

Atmel Smart Card ICs

Scottish Enterprise Technology Park
East Kilbride, Scotland G75 0QR
TEL [phone]
FAX [phone]

e-mail

[e-mail]

Web Site

http://www.atmel.com

BBS

1-[phone]

© Atmel Corporation 2001.

Atmel Corporation makes no warranty for the use of its products, other than those expressly contained in the Company’s standard warranty
which is detailed in Atmel’s Terms and Conditions located on the Company’s web site. The Company assumes no responsibility for any errors
which may appear in this document, reserves the right to change devices or specifications detailed herein at any time without notice, and does
not make any commitment to update the information contained herein. No licenses to patents or other intellectual property of Atmel are granted
by the Company in connection with the sale of Atmel products, expressly or by implication. Atmel’s products are not authorized for use as critical
components in life support devices or systems.

ATME L®, AVR® and AVR Studio® are the registered trademarks of Atmel.

®

Microsoft

Other terms and product names may be the trademarks of others.

, Windows® and Windows NT® are the registered trademarks of Microsoft Corporation.

Printed on recycled paper.

2467AS–08/01

WWW.ALLDATASHEET.COM

Copyright © Each Manufacturing Company.

All Datasheets cannot be modified without permission.

This datasheet has been download from :

www.AllDataSheet.com

100% Free DataSheet Search Site.

Free Download.

No Register.

Fast Search System.

www.AllDataSheet.com
