ATMEL AT89C51IC2 User Manual

BDTIC www.bdtic.com/ATMEL

Features

• 80C52 Compatible

–

8051 Pin and Instruction Compatible – Four 8-bit I/O ports + 2 I/O 2-wire Interface (TWI) Pins – Three 16-bit Timer/Counters – 256 bytes Scratch Pad RAM – 10 Interrupt Sources with 4 Priority Levels – Dual Data Pointer

• Variable Length MOVX for Slow RAM/Peripherals

• ISP (In-System-Programming) Using Standard V

• Boot ROM Contains Low Level Flash Programming Routines and a Default Serial

Loader

• High-speed Architecture

– In Standard Mode:

40 MHz (Vcc 2.7V to 5.5V, both Internal and external code execution) 60 MHz (Vcc 4.5V to 5.5V and Internal Code execution only)

– In X2 mode (6 Clocks/machine cycle)

20 MHz (Vcc 2.7V to 5.5V, both Internal and external code execution)

30 MHz (Vcc 4.5V to 5.5V and Internal Code execution only) – 32K Bytes On-chip Flash Program/Data Memory – Byte and Page (128 Bytes) Erase and Write – 100K Write Cycles

• On-chip 1024 Bytes Expanded RAM (XRAM)

– Software Selectable Size (0, 256, 512, 768, 1024 Bytes) – 256 Bytes Selected at Reset for TS87C51RB2/RC2 Compatibility

• Keyboard Interrupt Interface on Port P1

• 400-Kbits/s Multimaster 2-wire Interface

• SPI Interface (Master/Slave Mode)

• Sub-clock 32 kHz Crystal Oscillator

• 8-bit clock Prescaler

• Improved X2 Mode With Independant Selection for CPU and Each Peripheral

• Programmable Counter Array 5 Channels with:

igh Speed Output

– H – Compare/Capture – Pulse Width Modulator – Watchdog Timer Capabilities

• Asynchronous Port Reset

• Full-duplex Enhanced UART

• Dedicated Baud Rate Generator for UART

• Low EMI (Inhibit ALE)

• Hardware Watchdog Timer (One-time enabled with Reset-Out)

• Power Control Modes:

– Idle Mode – Power-down Mode – Power-Off Flag

• Power Supply:

– 2.7 to 3.6 (3V Version) – 2.7 to 5.5V (5V Version)

• Temperature Ranges: Commercial (0 to +70°C) and Industrial (-40°C to +85°C)

• Packages: PLC44, VQFP44

Power Supply

8-bit Flash Microcontroller with 2-wire Interface

AT89C51IC2

Rev. 4301D–8051–02/08

Description AT89C51IC2 is a high performance Flash version of the 80C51 8-bit microcontrollers. It

contains a 32K bytes Flash memory block for program and data.

The 32K bytes Flash memory can be programmed either in parallel mode or in serial mode with the ISP capability or with software. The programming voltage is internally generated from the standard VCC pin.

The AT89C51IC2 retains all features of the 80C52 with 256 bytes of internal RAM, a 10-source 4-level interrupt controller and three timer/counters.

In addition, the AT89C51IC2 has a 32 kHz Subsidiary clock Oscillator, a Programmable Counter Array, an XRAM of 1024 byte, a Hardware Watchdog Timer, a Keyboard Interface, a 2-wire interface, an SPI Interface, a more versatile serial channel that facilitates multiprocessor communication (EUART) and a speed improvement mechanism (X2 mode).

The fully static design of the AT89C51IC2 allows to reduce system power consumption by bringing the clock frequency down to any value, even DC, without loss of data.

The AT89C51IC2 has 2 software-selectable modes of reduced activity and 8-bit clock prescaler for further reduction in power consumption. In the Idle mode the CPU is frozen while the peripherals and the interrupt system are still operating. In the power-down mode the RAM is saved and all other functions are inoperative.

The added features of the AT89C51IC2 make it more powerful for applications that need pulse width modulation, high speed I/O and counting capabilities such as alarms, motor control, corded phones, smart card readers.

Table 1. Memory Size

PLCC44

VQFP44 1.4 Flash (bytes) XRAM (bytes)

T89C51IC2 32k 1024 1280 34

TOTAL RAM

(bytes) I/O

AT89C51IC2

4301D–8051–02/08

Block Diagram

Timer 0

INT

RAM

256

RxD

TxD

XTAL2

XTAL1

EUART

CPU

Timer 1

INT1

Ctrl

INT0

C51

CORE

(2) (2) (2) (2)

Port 0

Port 1

IB-bus

Reset

Vss

Vcc

(2)(2)

Flash

32K x 8

ECI

PCA

(1)(1)

Port 2

PCA Timer 2

BRG

Port 3

Port 12

ALE/PROG

PSEN

(2)

Parallel I/O Ports & Ext Bus

Watch

Dog

Key

Board

SPI

(1)

SCK

(1)

MOSI

(1)

MISO

(1)

T2EX

(1)

Two-Wire

SDA

SCL

Figure 1. Block Diagram

AT89C51IC2

(1): Alternate function of Port 1

(2): Alternate function of Port 3

4301D–8051–02/08

SFR Mapping The Special Function Registers (SFRs) of the AT89C51IC2 fall into the following

categories:

• C51 core registers: ACC, B, DPH, DPL, PSW, SP

• I/O port registers: P0, P1, P2, P3, PI2

• Timer registers: T2CON, T2MOD, TCON, TH0, TH1, TH2, TMOD, TL0, TL1, TL2, RCAP2L, RCAP2H

• Serial I/O port registers: SADDR, SADEN, SBUF, SCON

• PCA (Programmable Counter Array) registers: CCON, CCAPMx, CL, CH, CCAPxH, CCAPxL (x: 0 to 4)

• Power and clock control registers: PCON

• Hardware Watchdog Timer registers: WDTRST, WDTPRG

• Interrupt system registers: IEN0, IPL0, IPH0, IEN1, IPL1, IPH1

• Keyboard Interface registers: KBE, KBF, KBLS

• SPI registers: SPCON, SPSTR, SPDAT

• 2-wire Interface registers: SSCON, SSCS, SSDAT, SSADR

• BRG (Baud Rate Generator) registers: BRL, BDRCON

• Flash register: FCON

• Clock Prescaler register: CKRL

• 32 kHz Sub Clock Oscillator registers: CKSEL, OSSCON

AT89C51IC2

4301D–8051–02/08

AT89C51IC2

Table 2. C51 Core SFRs

Mnemonic Add Name 7 6 5 4 3 2 1 0

ACC E0h Accumulator

B F0h B Register

PSW D0h Program Status Word CY AC F0 RS1 RS0 OV F1 P

SP 81h Stack Pointer

DPL 82h Data Pointer Low byte

DPH 83h Data Pointer High byte

Table 3. System Management SFRs

Mnemonic Add Name 7 6 5 4 3 2 1 0

PCON 87h Power Control SMOD1 SMOD0 - - GF1 GF0 PD IDL

AUXR 8Eh Auxiliary Register 0 - - M0 XRS1 XRS0

AUXR1 A2h Auxiliary Register 1 - -

CKRL 97h Clock Reload Register - - - - - - - -

CKSEL 85h Clock Selection Register - - - - - - - CKS

OSCON 86h Oscillator Control Register - - - - - SCLKT0 OscBEn OscAEn

CKCKON0 8Fh Clock Control Register 0 TWIX2 WDTX2 PCAX2 SIX2 T2X2 T1X2 T0X2 X2

CKCKON1 AFh Clock Control Register 1 - - - - - - - SPIX2

ENBOO

- GF3 0 - DPS

EXTRA

Table 4. Interrupt SFRs

Mnemonic Add Name 7 6 5 4 3 2 1 0

IEN0 A8h Interrupt Enable Control 0 EA EC ET2 ES ET1 EX1 ET0 EX0

IEN1 B1h Interrupt Enable Control 1 - - - - - ESPI ETWI KBD

IPH0 B7h Interrupt Priority Control High 0 - PPCH PT2H PHS PT1H PX1H PT0H PX0H

IPL0 B8h Interrupt Priority Control Low 0 - PPCL PT2L PLS PT1L PX1L PT0L PX0L

IPH1 B3h Interrupt Priority Control High 1 - - - - - SPIH TWIH KBDH

IPL1 B2h Interrupt Priority Control Low 1 - - - - - SPIL TWIL KBDL

4301D–8051–02/08

Table 5. Port SFRs

Mnemonic Add Name 7 6 5 4 3 2 1 0

P0 80h 8-bit Port 0

P1 90h 8-bit Port 1

P2 A0h 8-bit Port 2

P3 B0h 8-bit Port 3

Table 6. Timer SFRs

Mnemonic Add Name 7 6 5 4 3 2 1 0

TCON 88h Timer/Counter 0 and 1 Control TF1 TR1 TF0 TR0 IE1 IT1 IE0 IT0

TMOD 89h Timer/Counter 0 and 1 Modes GATE1 C/T1# M11 M01 GATE0 C/T0# M10 M00

TL0 8Ah Timer/Counter 0 Low Byte

TH0 8Ch Timer/Counter 0 High Byte

TL1 8Bh Timer/Counter 1 Low Byte

TH1 8Dh Timer/Counter 1 High Byte

WDTRST A6h WatchDog Timer Reset

WDTPRG A7h WatchDog Timer Program - - - - - WTO2 WTO1 WTO0

T2CON C8h Timer/Counter 2 control TF2 EXF2 RCLK TCLK EXEN2 TR2 C/T2# CP/RL2#

T2MOD C9h Timer/Counter 2 Mode - - - - - - T2OE DCEN

RCAP2H CBh

RCAP2L CAh

TH2 CDh Timer/Counter 2 High Byte

TL2 CCh Timer/Counter 2 Low Byte

Timer/Counter 2 Reload/Capture High byte

Timer/Counter 2 Reload/Capture Low byte

Table 7. PCA SFRs

Mnemo

-nic Add Name 7 6 5 4 3 2 1 0

CCON D8h PCA Timer/Counter Control CF CR - CCF4 CCF3 CCF2 CCF1 CCF0

CMOD D9h PCA Timer/Counter Mode CIDL WDTE - - - CPS1 CPS0 ECF

CL E9h PCA Timer/Counter Low byte

CH F9h PCA Timer/Counter High byte

AT89C51IC2

4301D–8051–02/08

AT89C51IC2

Table 7. PCA SFRs (Continued)

Mnemo

-nic Add Name 7 6 5 4 3 2 1 0

CCAPM0

CCAPM1

CCAPM2

CCAPM3

CCAPM4

CCAP0H

CCAP1H

CCAP2H

CCAP3H

CCAP4H

CCAP0L

CCAP1L

CCAP2L

CCAP3L

CCAP4L

DAh

PCA Timer/Counter Mode 0

DBh

PCA Timer/Counter Mode 1

DCh

PCA Timer/Counter Mode 2

DDh

PCA Timer/Counter Mode 3

DEh

PCA Timer/Counter Mode 4

FAh

PCA Compare Capture Module 0 H

FBh

PCA Compare Capture Module 1 H

FCh

PCA Compare Capture Module 2 H

FDh

PCA Compare Capture Module 3 H

FEh

PCA Compare Capture Module 4 H

EAh

PCA Compare Capture Module 0 L

EBh

PCA Compare Capture Module 1 L

ECh

PCA Compare Capture Module 2 L

EDh

PCA Compare Capture Module 3 L

EEh

PCA Compare Capture Module 4 L

CCAP0H7

CCAP1H7

CCAP2H7

CCAP3H7

CCAP4H7

CCAP0L7

CCAP1L7

CCAP2L7

CCAP3L7

CCAP4L7

ECOM0

ECOM1

ECOM2

ECOM3

ECOM4

CCAP0H6

CCAP1H6

CCAP2H6

CCAP3H6

CCAP4H6

CCAP0L6

CCAP1L6

CCAP2L6

CCAP3L6

CCAP4L6

CAPP0

CAPP1

CAPP2

CAPP3

CAPP4

CCAP0H5

CCAP1H5

CCAP2H5

CCAP3H5

CCAP4H5

CCAP0L5

CCAP1L5

CCAP2L5

CCAP3L5

CCAP4L5

CAPN0

CAPN1

CAPN2

CAPN3

CAPN4

CCAP0H4

CCAP1H4

CCAP2H4

CCAP3H4

CCAP4H4

CCAP0L4

CCAP1L4

CCAP2L4

CCAP3L4

CCAP4L4

MAT0

MAT1

MAT2

MAT3

MAT4

CCAP0H3

CCAP1H3

CCAP2H3

CCAP3H3

CCAP4H3

CCAP0L3

CCAP1L3

CCAP2L3

CCAP3L3

CCAP4L3

TOG0

TOG1

TOG2

TOG3

TOG4

CCAP0H2

CCAP1H2

CCAP2H2

CCAP3H2

CCAP4H2

CCAP0L2

CCAP1L2

CCAP2L2

CCAP3L2

CCAP4L2

PWM0

PWM1

PWM2

PWM3

PWM4

CCAP0H1

CCAP1H1

CCAP2H1

CCAP3H1

CCAP4H1

CCAP0L1

CCAP1L1

CCAP2L1

CCAP3L1

CCAP4L1

ECCF0

ECCF1

ECCF2

ECCF3

ECCF4

CCAP0H0

CCAP1H0

CCAP2H0

CCAP3H0

CCAP4H0

CCAP0L0

CCAP1L0

CCAP2L0

CCAP3L0

CCAP4L0

Table 8. Serial I/O Port SFRs

Mnemonic Add Name 7 6 5 4 3 2 1 0

SCON 98h Serial Control FE/SM0 SM1 SM2 REN TB8 RB8 TI RI

SBUF 99h Serial Data Buffer

SADEN B9h Slave Address Mask

SADDR A9h Slave Address

BDRCON 9Bh Baud Rate Control BRR TBCK RBCK SPD SRC

BRL 9Ah Baud Rate Reload

Table 9. SPI Controller SFRs

Mnemonic Add Name 7 6 5 4 3 2 1 0

SPCON C3h SPI Control SPR2 SPEN SSDIS MSTR CPOL CPHA SPR1 SPR0

SPSTA C4h SPI Status SPIF WCOL SSERR MODF - - - -

SPDAT C5h SPI Data SPD7 SPD6 SPD5 SPD4 SPD3 SPD2 SPD1 SPD0

4301D–8051–02/08

Table 10. Two-Wire Interface Controller SFRs

Mnemonic Add Name 7 6 5 4 3 2 1 0

SSCON 93h Synchronous Serial control SSCR2 SSPE SSSTA SSSTO SSI SSAA SSCR1 SSCR0

SSCS 94h Synchronous Serial Status SSC4 SSC3 SSC2 SSC1 SSC0 0 0 0

SSDAT 95h Synchronous Serial Data SSD7 SSD6 SSD5 SSD4 SSD3 SSD2 SSD1 SSD0

SSADR 96h Synchronous Serial Address SSA7 SSA6 SSA5 SSA4 SSA3 SSA2 SSA1 SSGC

Table 11. Keyboard Interface SFRs

Mnemonic Add Name 7 6 5 4 3 2 1 0

KBLS 9Ch Keyboard Level Selector KBLS7 KBLS6 KBLS5 KBLS4 KBLS3 KBLS2 KBLS1 KBLS0

KBE 9Dh Keyboard Input Enable KBE7 KBE6 KBE5 KBE4 KBE3 KBE2 KBE1 KBE0

KBF 9Eh Keyboard Flag Register KBF7 KBF6 KBF5 KBF4 KBF3 KBF2 KBF1 KBF0

AT89C51IC2

4301D–8051–02/08

Table 12. SFR Mapping

Bit

addressable Non Bit addressable

0/8 1/9 2/A 3/B 4/C 5/D 6/E 7/F

AT89C51IC2

Table below shows all SFRs with their address and their reset value.

F8h

F0h

E8h

E0h

D8h

D0h

C8h

C0h

B8h

B0h

0000 0000

ACC

0000 0000

CCON

00X0 0000

PSW

0000 0000

T2CON

0000 0000

PI2 bit

addressable

XXXX XX11

IPL0

X000 000

1111 1111

0000 0000

CMOD

00XX X000

FCON (1)

XXXX 0000

T2MOD

XXXX XX00

SADEN

0000 0000

IEN1

XXXX X000

CCAP0H

XXXX XXXX

CCAP0L

XXXX XXXX

CCAPM0

X000 0000

RCAP2L

0000 0000

IPL1

XXXX X000

CCAP1H

XXXX XXXX

CCAP1L

XXXX XXXX

CCAPM1

X000 0000

RCAP2H

0000 0000

SPCON

0001 0100

IPH1

XXXX X111

CCAPL2H

XXXX XXXX

CCAPL2L

XXXX XXXX

CCAPM2

X000 0000

TL2

0000 0000

SPSTA

0000 0000

CCAPL3H

XXXX XXXX

CCAPL3L

XXXX XXXX

CCAPM3

X000 0000

TH2

0000 0000

SPDAT

XXXX XXXX

CCAPL4H

XXXX XXXX

CCAPL4L

XXXX XXXX

CCAPM4

X000 0000

IPH0

X000 0000

FFh

F7h

EFh

E7h

DFh

D7h

CFh

C7h

BFh

B7h

A8h

A0h

98h

90h

88h

80h

4301D–8051–02/08

IEN0

0000 0000

1111 1111

SCON

0000 0000

1111 1111

TCON

0000 0000

1111 1111

SADDR

0000 0000

SBUF

XXXX XXXX

TMOD

0000 0000

0/8 1/9 2/A 3/B 4/C 5/D 6/E 7/F

0000 0111

AUXR1

XXXX X0X0

BRL

0000 0000

TL0

0000 0000

DPL

0000 0000

BDRCON

XXX0 0000

SSCON

0000 0000

TL1

0000 0000

DPH

0000 0000

KBLS

0000 0000

SSCS

1111 1000

TH0

0000 0000

KBE

0000 0000

SSDAT

1111 1111

TH1

0000 0000

CKSEL

XXXX XXX0

WDTRST

XXXX XXXX

KBF

0000 0000

SSADR

1111 1110

AUXR

XX0X 0000

OSSCON

XXXX X001

CKCON1

XXXX XXX0

WDTPRG

XXXX X000

CKRL

1111 1111

CKCON0

0000 0000

PCON

00X1 0000

reserved

AFh

A7h

9Fh

97h

8Fh

87h

Pin Configurations

Figure 2. Pin Configurations

P1.5/CEX2/MISO

P1.6/CEX3/SCK

P1.7/CEx4/MOSI

RST

P3.0/RxD

PI2.1/SDA

P3.1/TxD

P3.2/INT0

P3.3/INT1

P3.4/T0 P3.5/T1

7 8

14 15

P1.4/CEX1

P1.3/CEX0

5 4 3 2 1 6

P1.1/T2EX/SS

P1.2/ECI

P1.0/T2/XTALB1

XTALB2

VCC

44 43 42 41 40

PLCC44

P0.0/AD0

18 19 23222120 262524 27 28

NIC*

VSS

XTAL2

XTAL1

P3.7/RD

P3.6/WR

P2.0/A8

P2.1/A9

P0.3/AD3

P0.2/AD2

P0.1/AD1

P0.4/AD4

P0.5/AD5

P0.6/AD6

P0.7/AD7

PI2.0/SCL

ALE/PROG

PSEN

P2.7/A15

P2.6/A14

P2.5/A13

P2.2/A10

P2.3/A11

P2.4/A12

P1.5/CEX2/MISO

P1.6/CEX3/SCK

P1.7/CEX4/MOSI

AT89C51IC2

RST

P3.0/RxD

PI2.1/SDA

P3.1/TxD

P3.2/INT0

P3.3/INT1

P3.4/T0

P3.5/T1

P1.4/CEX1

P1.3/CEX0

43 42 41 40 3944 38 37 36 35 34

7 8

P1.0/T2/XTALB1

P1.1/T2EX/SS

P1.2/ECI

XTALB2

VQFP44 1.4

VCC

12 13 17161514 201918 21 22

VSS

NIC*

XTAL1

XTAL2

P3.7/RD

P3.6/WR

P2.0/A8

P0.0/AD0

P0.2/AD2

P0.3/AD3

P0.1/AD1

P0.4/AD4

33 32

P0.5/AD5

P0.6/AD6

P0.7/AD7

PI2.0/SCL

ALE/PROG

PSEN

P2.7/A15

P2.6/A14

P2.5/A13

P2.1/A9

P2.3/A11

P2.2/A10

P2.4/A12

4301D–8051–02/08

Table 13. Pin Description for 40/44 Pin Packages

AT89C51IC2

Pin Number

Mnemonic

P0.0 - P0.7 43 - 36 37 - 30 I/O Port 0: Port 0 is an open-drain, bidirectional I/O port. Port 0 pins that have 1s written to

P1.0 - P1.7 2 - 9 40 - 44

22 16 I Ground: 0V reference

44 38 I

1 - 3

2 40 I/O P1.0: Input/Output

3 41 I/O P1.1: Input/Output

Type

Name and FunctionPLCC44 VQFP44 1.4

Power Supply: This is the power supply voltage for normal, idle and power-down

operation

them float and can be used as high impedance inputs. Port 0 must be polarized to VCC or VSS in order to prevent any parasitic current consumption. Port 0 is also the multiplexed low-order address and data bus during access to external program and data memory. In this application, it uses strong internal pull-up when emitting 1s. Port 0 also inputs the code bytes during EPROM programming. External pull-ups are required during program verification during which P0 outputs the code bytes.

I/O Port 1: Port 1 is an 8-bit bidirectional I/O port with internal pull-ups. Port 1 pins that

have 1s written to them are pulled high by the internal pull-ups and can be used as inputs. As inputs, Port 1 pins that are externally pulled low will source current because of the internal pull-ups. Port 1 also receives the low-order address byte during memory programming and verification.

Alternate functions for AT89C51IC2 Port 1 include:

I/O T2 (P1.0): Timer/Counter 2 external count input/Clockout

I XTALB1 (P1.0): Sub Clock input to the inverting oscillator amplifier

I T2EX: Timer/Counter 2 Reload/Capture/Direction Control

I SS

4 42 I/O P1.2: Input/Output

I ECI: External Clock for the PCA

5 43 I/O P1.3: Input/Output

I/O CEX0: Capture/Compare External I/O for PCA module 0

6 44 I/O P1.4: Input/Output

I/O CEX1: Capture/Compare External I/O for PCA module 1

7 1 I/O P1.5: Input/Output

I/O CEX2: Capture/Compare External I/O for PCA module 2

I/O MISO: SPI Master Input Slave Output line

8 2 I/O P1.6: Input/Output

I/O CEX3: Capture/Compare External I/O for PCA module 3

I/O SCK: SPI Serial Clock

: SPI Slave Select

When SPI is in master mode, MISO receives data from the slave peripheral. When SPI is in slave mode, MISO outputs data to the master controller.

SCK outputs clock to the slave peripheral

4301D–8051–02/08

Table 13. Pin Description for 40/44 Pin Packages (Continued)

Pin Number

Mnemonic

9 3 I/O P1.7: Input/Output:

XTALA1 21 15 I

XTALA2 20 14 O Crystal A 2: Output from the inverting oscillator amplifier

XTALB1 2 40 I

XTALB2 1 39 O Crystal B 2: (Sub Clock) Output from the inverting oscillator amplifier

P2.0 - P2.7 24 - 31 18 - 25 I/O Port 2: Port 2 is an 8-bit bidirectional I/O port with internal pull-ups. Port 2 pins that

Type

Name and FunctionPLCC44 VQFP44 1.4

I/O CEX4: Capture/Compare External I/O for PCA module 4

I/O MOSI: SPI Master Output Slave Input line

When SPI is in master mode, MOSI outputs data to the slave peripheral. When SPI is in slave mode, MOSI receives data from the master controller.

Crystal A 1: Input to the inverting oscillator amplifier and input to the internal clock generator circuits.

Crystal B 1: (Sub Clock) Input to the inverting oscillator amplifier and input to the internal clock generator circuits.

have 1s written to them are pulled high by the internal pull-ups and can be used as inputs. As inputs, Port 2 pins that are externally pulled low will source current because of the internal pull-ups. Port 2 emits the high-order address byte during fetches from external program memory and during accesses to external data memory that use 16-bit addresses (MOVX @DPTR).In this application, it uses strong internal pull-ups emitting 1s. During accesses to external data memory that use 8-bit addresses (MOVX @Ri), port 2 emits the contents of the P2 SFR. Some Port 2 pins receive the high order address bits during EPROM programming and verification.

P3.0 - P3.7 11,

13 - 19

11 5 I RXD (P3.0): Serial input port

13 7 O TXD (P3.1): Serial output port

14 8 I INT0

15 9 I INT1 (P3.3): External interrupt 1

16 10 I T0 (P3.4): Timer 0 external input

17 11 I T1 (P3.5): Timer 1 external input

18 12 O WR (P3.6): External data memory write strobe

19 13 O RD (P3.7): External data memory read strobe

PI2.0 - PI2.1

34, 12 28, 6

34 28 I/O SCL (PI2.0): 2-wire Serial Clock

12 6 I/O SDA (PI2.1): 2-wire Serial Data

7 - 13

I/O Port 3: Port 3 is an 8-bit bidirectional I/O port with internal pull-ups. Port 3 pins that

have 1s written to them are pulled high by the internal pull-ups and can be used as inputs. As inputs, Port 3 pins that are externally pulled low will source current because of the internal pull-ups. Port 3 also serves the special features of the 80C51 family, as listed below.

(P3.2): External interrupt 0

Port I2: Port I2 is an open drain. It can be used as inputs (must be polarized to Vcc

with external resistor to prevent any parasitic current consumption).

SCL output the serial clock to slave peripherals

SCL input the serial clock from master

AT89C51IC2

4301D–8051–02/08

Table 13. Pin Description for 40/44 Pin Packages (Continued)

AT89C51IC2

Pin Number

Mnemonic

RST 10 4 I/O

ALE/PROG 33 27 O (I) Address Latch Enable/Program Pulse: Output pulse for latching the low byte of the

PSEN 32 26 O Program Strobe ENable: The read strobe to external program memory. When execut-

EA 35 29 I External Access Enable: EA must be externally held low to enable the device to fetch

Type

Name and FunctionPLCC44 VQFP44 1.4

SDA is the bidirectional 2-wire data line

Reset: A high on this pin for two machine cycles while the oscillator is running, resets the device. An internal diffused resistor to V external capacitor to VCC. This pin is an output when the hardware watchdog forces a system reset.

address during an access to external memory. In normal operation, ALE is emitted at a constant rate of 1/6 (1/3 in X2 mode) the oscillator frequency, and can be used for external timing or clocking. Note that one ALE pulse is skipped during each access to external data memory. This pin is also the program pulse input (PROG) during Flash programming. ALE can be disabled by setting SFR’s AUXR.0 bit. With this bit set, ALE will be inactive during internal fetches.

ing code from the external program memory, PSEN is activated twice each machine cycle, except that two PSEN activations are skipped during each access to external data memory. PSEN is not activated during fetches from internal program memory.

code from external program memory locations 0000H to FFFFH (RD). If security level 1 is programmed, EA will be internally latched on Reset.

permits a power-on reset using only an

4301D–8051–02/08

Oscillators

Overview Two oscillators are available for CPU:

• OSCA used for high frequency: Up to 48 MHz @5V +/- 10%

• OSCB used for low frequency: 32.768 kHz

Several operating modes are available and programmable by software:

• to switch OSCA to OSCB and vice-versa

• to stop OSCA or OSCB to reduce consumption

In order to optimize the power consumption and the execution time needed for a specific task, an internal prescaler feature has been implemented between the selected oscillator and the CPU.

Registers Table 14. CKSEL Register

CKSEL - Clock Selection Register (85h)

7 6 5 4 3 2 1 0

- - - - - - - CKS

Bit

Number

7 - Reserved

6 - Reserved

5 - Reserved

4 - Reserved

3 - Reserved

2 - Reserved

1 - Reserved

0 CKS

Bit

Mnemonic Description

CPU Oscillator Select Bit: (CKS)

Cleared, CPU and peripherals connected to OSCB

Set, CPU and peripherals connected to OSCA

Programmed by hardware after a Power-up regarding Hardware Security Byte (HSB).HSB.OSC (Default setting, OSCA selected)

Reset Value = 0000 000’HSB.OSC’b (see Hardware Security Byte (HSB) Table 84) Not bit addressable

AT89C51IC2

4301D–8051–02/08

AT89C51IC2

Table 15. OSCCON Register

OSCCON- Oscillator Control Register (86h)

7 6 5 4 3 2 1 0

- - - - - SCLKT0 OscBEn OscAEn

Bit

Number

7 - Reserved

6 - Reserved

5 - Reserved

4 - Reserved

3 - Reserved

2 SCLKT0

1 OscBEn

0 OscAEn

Bit

Mnemonic Description

Sub Clock Timer0

Cleared by software to select T0 pin

Set by software to select T0 Sub Clock

Cleared by hardware after a Power Up

OscB enable bit

Set by software to run OscB

Cleared by software to stop OscB

Programmed by hardware after a Power-up regarding HSB.OSC (Default cleared, OSCB stopped)

OscA enable bit

Set by software to run OscA

Cleared by software to stop OscA

Programmed by hardware after a Power-up regarding HSB.OSC(Default Set, OSCA runs)

4301D–8051–02/08

Reset Value = XXXX X0’HSB.OSC

’’HSB.OSC’b (see Hardware Security Byte (HSB) Table 84) Not bit addressable

Table 16. CKRL Register

CKRL - Clock Reload Register

7 6 5 4 3 2 1 0

- - - - - - - -

Bit

Number Mnemonic Description

7:0 CKRL

Clock Reload Register:

Prescaler value

Reset Value = 1111 1111b Not bit addressable

Table 17. PCON Register

PCON - Power Control Register (87h)

7 6 5 4 3 2 1 0

SMOD1 SMOD0 - POF GF1 GF0 PD IDL

Bit

Number

7 SMOD1

6 SMOD0

5 -

4 POF

3 GF1

2 GF0

1 PD

0 IDL

Bit

Mnemonic Description

Serial port Mode bit 1

Set to select double baud rate in mode 1, 2 or 3.

Serial port Mode bit 0

Cleared to select SM0 bit in SCON register. Set to select FE bit in SCON register.

Reserved

The value read from this bit is indeterminate. Do not set this bit.

Power-Off Flag

Cleared to recognize next reset type. Set by hardware when VCC rises from 0 to its nominal voltage. Can also be set by software.

General purpose Flag

Cleared by software for general purpose usage. Set by software for general purpose usage.

General purpose Flag

Cleared by software for general purpose usage. Set by software for general purpose usage.

Power-Down mode bit

Cleared by hardware when reset occurs. Set to enter power-down mode.

Idle mode bit

Cleared by hardware when interrupt or reset occurs. Set to enter idle mode.

Reset Value = 00X1 0000b Not bit addressable

AT89C51IC2

4301D–8051–02/08

Functional Block

XtalA2

XtalA1

XtalB1

XtalB2

OscBEn

OscB

OscA

CLK

Idle

CPU clock

OscAEn

CKS

CKRL

Reload

8-bit

Prescaler-Divider

Reset

Peripheral Clock

:128

Sub Clock

FOSCA

PERIPH

CPU

FOSCB

OSCCON

CKCON0

CKSEL

PwdOscA

PwdOscB

CKRL=0xFF?

Diagram

Figure 3. Functional Oscillator Block Diagram

AT89C51IC2

Operating Modes

Reset A hardware RESET puts the Clock generator in the following state:

The selected oscillator depends on OSC bit in Hardware Security Byte (HSB) (see HSB

Table 84)

Functional Modes

HSB.OSC = 1 (Oscillator A selected)

• OscAEn = 1 & OscBEn = 0: OscA is running, OscB is stopped.

• CKS = 1: OscA is selected for CPU.

HSB.OSC = 0 (Oscillator B selected)

• OscAEn = 0 & OscBEn = 1: OscB is running, OscA is stopped.

• CKS = 0: OscB is selected for CPU.

Normal Modes • CPU and Peripherals clock depend on the software selection using CKCON0,

CKCON1 and CKRL registers

• CKS bit in CKSEL register selects either OscA or OscB

• CKRL register determines the frequency of the OscA clock.

4301D–8051–02/08

• It is always possible to switch dynamically by software from OscA to OscB, and vice

versa by changing CKS bit.

Idle Modes • IDLE modes are achieved by using any instruction that writes into PCON.0 bit (IDL)

• IDLE modes A and B depend on previous software sequence, prior to writing into

PCON.0 bit:

• IDLE MODE A: OscA is running (OscAEn = 1) and selected (CKS = 1)

• IDLE MODE B: OscB is running (OscBEn = 1) and selected (CKS = 0)

• The unused oscillator OscA or OscB can be stopped by software by clearing

OscAEn or OscBEn respectively.

• IDLE mode can be canceled either by Reset, or by activation of any enabled

interruption

• In both cases, PCON.0 bit (IDL) is cleared by hardware

• Exit from IDLE modes will leave Oscillators control bits (OscEnA, OscEnB, CKS)

unchanged.

Power Down Modes • POWER DOWN modes are achieved by using any instruction that writes into

PCON.1 bit (PD)

• POWER DOWN modes A and B depend on previous software sequence, prior to

writing into PCON.1 bit:

• Both OscA and OscB will be stopped.

• POWER DOWN mode can be cancelled either by a hardware Reset, an external

interruption, or the keyboard interrupt.

• By Reset signal: The CPU will restart according to OSC bit in Hardware Security Bit

(HSB) register.

• By INT0 or INT1 interruption, if enabled: (standard behavioral), request on Pads

must be driven low enough to ensure correct restart of the oscillator which was selected when entering in Power down.

• By keyboard Interrupt if enabled: a hardware clear of the PCON.1 flag ensure the

restart of the oscillator which was selected when entering in Power down.

Table 18. Overview

AT89C51IC2

PCON.1 PCON.0 OscBEn OscAEn CKS Selected Mode Comment

0 0 0 1 1

0 0 1 1 1

0 0 1 0 0

0 0 1 1 0

X X 0 0 X INVALID

X X X 0 1 INVALID

X X 0 X 0 INVALID

NORMAL MODE A, OscB stopped

NORMAL MODE A, OscB running

NORMAL MODE B, OscA stopped

NORMAL MODE B, OscA running

Default mode after power-up or Warm Reset

Default mode after power-up or Warm Reset + OscB running

OscB running and selected

OscB running and selected + OscA running

OscA & OscB cannot be stopped at the same time

OscA must not be stopped, as used for CPU and peripherals

OscB must not be stopped as used for CPU and peripherals

4301D–8051–02/08

AT89C51IC2

Table 18. Overview (Continued)

PCON.1 PCON.0 OscBEn OscAEn CKS Selected Mode Comment

0 1 X 1 1 IDLE MODE A

0 1 1 X 0 IDLE MODE B

1 X X 1 X

POWER DOWN MODE

The CPU is off, OscA supplies the peripherals, OscB can be disabled (OscBEn = 0)

The CPU is off, OscB supplies the peripherals, OscA can be disabled (OscAEn = 0)

The CPU and peripherals are off, OscA and OscB are stopped

Design Considerations

Oscillators Control • PwdOscA and PwdOscB signals are generated in the Clock generator and used to

control the hard blocks of oscillators A and B.

• PwdOscA =’1’ stops OscA

• PwdOscB =’1’ stops OscB

• The following tables summarize the Operating modes:

PCON.1 OscAEn PwdOscA Comments

0 1 0 OscA running

1 X 1

0 0 1

OscA stopped by

Power-down mode

OscA stopped by

clearing OscAEn

PCON.1 OscBEn PwdOscB Comments

0 1 0 OscB running

1 X 1

0 0 1

Power-down mode

Prescaler Divider • A hardware RESET puts the prescaler divider in the following state:

– CKRL = FFh: F

CLK CPU

= F

CLK PERIPH

• CKS signal selects OSCA or OSCB: F

= F

OSCA

CLK OUT

/2 (Standard C51 feature)

= F

OSCA

or F

OSCB

• Any value between FFh down to 00h can be written by software into CKRL register

in order to divide frequency of the selected oscillator:

– CKRL = 00h: minimum frequency

CLK CPU

= F

CLK PERIPH

= F

CLK PERIPH

= F = F

/1020 (Standard Mode)

OSCA

/510 (X2 Mode)

OSCA

– CKRL = FFh: maximum frequency

CLK CPU

= F = F

CLK PERIPH

= F = F

/2 (Standard Mode)

OSCA

(X2 Mode)

OSCA

OscB stopped by

clearing OscBEn

4301D–8051–02/08

– F

CP U

CL KPE RIP H

OS CA

2 255 CKRL–( )×

----------------------------------------------

CP U

CL KPE RIP H

OS CA

4 255 CKRL–( )×

----------------------------------------------

SCLKT0

FCLK PERIPH

T0 pin

Sub Clock

C/T

OSCCON

TMOD

Gate

INT0

TR0

Timer 0

Control

CLK CPU

and F

CLK PERIPH

In X2 Mode:

In X1 Mode:

Timer 0: Clock Inputs Figure 4. Timer 0: Clock Inputs

, for CKRL<>0xFF

Note: The SCLKT0 bit in OSCCON register allows to select Timer 0 Subsidiary clock.

SCLKT0 = 0: Timer 0 uses the standard T0 pin as clock input (Standard mode)

SCLKT0 = 1: Timer 0 uses the special Sub Clock as clock input, this feature can be use as periodic interrupt for time clock.

AT89C51IC2

4301D–8051–02/08

AT89C51IC2

XTALA1

CKCON0

8 bit Prescaler

OSCA

XTAL

XTALA1:2

CLK CPU

CLK PERIPH

CKSEL

CKS

OSCB

CKRL

0 1

Enhanced Features In comparison to the original 80C52, the AT89C51IC2 implements some new features,

which are:

• The X2 option

• The Dual Data Pointer

• The extended RAM

• The Programmable Counter Array (PCA)

• The Hardware Watchdog

• The SPI interface

• The 2-wire interface

• The 4 level interrupt priority system

• The power-off flag

• The Power On Reset

• The ONCE mode

• The ALE disabling

• Some enhanced features are also located in the UART and the timer 2

X2 Feature and OSCA Clock Generation

The AT89C51IC2 core needs only 6 clock periods per machine cycle. This feature called ”X2” provides the following advantages:

• Divide frequency crystals by 2 (cheaper crystals) while keeping same CPU power.

• Save power consumption while keeping same CPU power (oscillator power saving).

• Save power consumption by dividing dynamically the operating frequency by 2 in

operating and idle modes.

• Increase CPU power by 2 while keeping same crystal frequency.

In order to keep the original C51 compatibility, a divider by 2 is inserted between the XTALA1 signal and the main clock input of the core (phase generator). This divider may be disabled by software.

Description The clock for the whole circuit and peripherals is first divided by two before being used

by the CPU core and the peripherals.

This allows any cyclic ratio to be accepted on XTALA1 input. In X2 mode, as this divider is bypassed, the signals on XTALA1 must have a cyclic ratio between 40 to 60%.

Figure 5. shows the clock generation block diagram.x2 bit is validated on the rising edge of the XTALA1÷2 to avoid glitches when switching from X2 to STD mode. Figure 6. shows the switching mode waveforms.

Figure 5. Clock Generation Diagram

4301D–8051–02/08

Figure 6. Mode Switching Waveforms

XTALA1:2

XTALA1

CPU clock

X2 bit

X2 ModeSTD Mode STD Mode

OSCA

The X2 bit in the CKCON0 register (see Table 19) allow to switch from 12 clock periods per instruction to 6 clock periods and vice versa. At reset, the speed is setting according to X2 bit of Hardware Security Byte (HSB). By default, Standard mode is actived. Setting the X2 bit activates the X2 feature (X2 mode).

The T0X2, T1X2, T2X2, UartX2, PcaX2, WdX2 and I2CX2 bits in the CKCON0 register (See Table 19.) and SPIX2 bit in the CKCON1 register (see Table 20) allow to switch from standard peripheral speed (12 clock periods per peripheral clock cycle) to fast peripheral speed (6 clock periods per peripheral clock cycle). These bits are active only in X2 mode.

More information about the X2 mode can be found in the application note "How to take advantage of the X2 features in TS80C51 microcontroller?"

AT89C51IC2

4301D–8051–02/08

AT89C51IC2

Table 19. CKCON0 Register

CKCON0 - Clock Control Register (8Fh)

7 6 5 4 3 2 1 0

SPIX2 WDX2 PCAX2 SIX2 T2X2 T1X2 T0X2 X2

Bit

Number

7 I2CX2

6 WDX2

5 PCAX2

4 SIX2

3 T2X2

2 T1X2

Bit

Mnemonic Description

2-wire clock (This control bit is validated when the CPU clock X2 is set; when

X2 is low, this bit has no effect) Cleared to select 6 clock periods per peripheral clock cycle.

Set to select 12 clock periods per peripheral clock cycle.

Watchdog clock (This control bit is validated when the CPU clock X2 is set; when X2 is low, this bit has no effect) Cleared to select 6 clock periods per peripheral clock cycle.

Set to select 12 clock periods per peripheral clock cycle.

Programmable Counter Array clock (This control bit is validated when the CPU clock X2 is set; when X2 is low, this bit has no effect) Cleared to select 6 clock periods per peripheral clock cycle.

Set to select 12 clock periods per peripheral clock cycle.

Enhanced UART clock (Mode 0 and 2) (This control bit is validated when the CPU clock X2 is set; when X2 is low, this bit has no effect) Cleared to select 6 clock periods per peripheral clock cycle.

Set to select 12 clock periods per peripheral clock cycle.

Timer2 clock (This control bit is validated when the CPU clock X2 is set; when X2 is low, this bit has no effect) Cleared to select 6 clock periods per peripheral clock cycle.

Set to select 12 clock periods per peripheral clock cycle.

Timer1 clock (This control bit is validated when the CPU clock X2 is set; when X2 is low, this bit has no effect) Cleared to select 6 clock periods per peripheral clock cycle.

Set to select 12 clock periods per peripheral clock cycle.

4301D–8051–02/08

Timer0 clock (This control bit is validated when the CPU clock X2 is set; when

1 T0X2

0 X2

X2 is low, this bit has no effect) Cleared to select 6 clock periods per peripheral clock cycle.

Set to select 12 clock periods per peripheral clock cycle.

CPU clock

Cleared to select 12 clock periods per machine cycle (STD mode) for CPU and all the peripherals.

Set to select 6clock periods per machine cycle (X2 mode) and to enable the individual peripherals "X2" bits.

Programmed by hardware after Power-up regarding Hardware Security Byte (HSB), Default setting, X2 is cleared.

Reset Value = 0000 000’HSB.X2’b Not bit addressable

Table 20. CKCON1 Register

CKCON1 - Clock Control Register (AFh)

7 6 5 4 3 2 1 0

- - - - - - - SPIX2

Bit

Number

7 - Reserved

6 - Reserved

5 - Reserved

4 - Reserved

3 - Reserved

2 - Reserved

1 - Reserved

0 SPIX2

Bit

Mnemonic Description

SPI (This control bit is validated when the CPU clock X2 is set; when X2 is low,

this bit has no effect) Clear to select 6 clock periods per peripheral clock cycle.

Set to select 12 clock periods per peripheral clock cycle.

Reset Value = XXXX XXX0b Not bit addressable

AT89C51IC2

4301D–8051–02/08

AT89C51IC2

External Data Memory

AUXR1(A2H)

DPS

DPH(83H) DPL(82H)

DPTR0

DPTR1

Dual Data Pointer Register

Figure 7. Use of Dual Pointer

The additional data pointer can be used to speed up code execution and reduce code size.

The dual DPTR structure is a way by which the chip will specify the address of an external data memory location. There are two 16-bit DPTR registers that address the external memory, and a single bit called DPS = AUXR1.0 (see Table 21) that allows the program code to switch between them (Refer to Figure 7).

Table 21. AUXR1 register

AUXR1- Auxiliary Register 1(0A2h)

7 6 5 4 3 2 1 0

- - ENBOOT - GF3 0 - DPS

Bit

Number

7 -

6 -

5 ENBOOT

4 -

3 GF3 This bit is a general purpose user flag.*

2 0 Always cleared.

1 -

0 DPS

Bit

Mnemonic Description

Reserved

The value read from this bit is indeterminate. Do not set this bit.

Reserved

The value read from this bit is indeterminate. Do not set this bit.

Enable Boot Flash

Cleared to disable boot rom.

Set to map the boot rom between F800h - 0FFFFh.

Reserved

The value read from this bit is indeterminate. Do not set this bit.

Reserved

The value read from this bit is indeterminate. Do not set this bit.

Data Pointer Selection

Cleared to select DPTR0. Set to select DPTR1.

4301D–8051–02/08

Reset Value: XXXX XX0X0b Not bit addressable

Note: *Bit 2 stuck at 0; this allows to use INC AUXR1 to toggle DPS without changing GF3.

ASSEMBLY LANGUAGE ; Block move using dual data pointers

; Modifies DPTR0, DPTR1, A and PSW ; note: DPS exits opposite of entry state ; unless an extra INC AUXR1 is added ; 00A2 AUXR1 EQU 0A2H ; 0000 909000MOV DPTR,#SOURCE ; address of SOURCE 0003 05A2 INC AUXR1 ; switch data pointers 0005 90A000 MOV DPTR,#DEST ; address of DEST 0008 LOOP: 0008 05A2 INC AUXR1 ; switch data pointers 000A E0 MOVX A,@DPTR ; get a byte from SOURCE 000B A3 INC DPTR ; increment SOURCE address 000C 05A2 INC AUXR1 ; switch data pointers 000E F0 MOVX @DPTR,A ; write the byte to DEST 000F A3 INC DPTR ; increment DEST address 0010 70F6JNZ LOOP ; check for 0 terminator 0012 05A2 INC AUXR1 ; (optional) restore DPS

INC is a short (2 bytes) and fast (12 clocks) way to manipulate the DPS bit in the AUXR1 SFR. However, note that the INC instruction does not directly force the DPS bit to a particular state, but simply toggles it. In simple routines, such as the block move example, only the fact that DPS is toggled in the proper sequence matters, not its actual value. In other words, the block move routine works the same whether DPS is '0' or '1' on entry. Observe that without the last instruction (INC AUXR1), the routine will exit with DPS in the opposite state.

AT89C51IC2

4301D–8051–02/08

AT89C51IC2

XRAM

Upper

128 bytes

Internal

Ram

Lower

128 bytes

Internal

Ram

Special Function Register

80h 80h

0FFh or 3FFh

0FFh

External

Data

Memory

0000

00FFh up to 03FFh

0FFFFh

indirect accesses

direct accesses

direct or indirect

accesses

7Fh

Expanded RAM (XRAM)

The AT89C51IC2 provides additional Bytes of random access memory (RAM) space for increased data parameter handling and high level language usage.

AT89C51IC2 devices have expanded RAM in external data space; maximum size and location are described in Table 22.

Table 22. Expanded RAM

Address

XRAM size

AT89C51IC2 1024 00h 3FFh

Start End

The AT89C51IC2 h as inte rnal da ta memo ry that is mapped into f our sep arate segments.

The four segments are:

1. The Lower 128 bytes of RAM (addresses 00h to 7Fh) are directly and indirectly addressable.

2. The Upper 128 bytes of RAM (addresses 80h to FFh) are indirectly addressable only.

3. The Special Function Registers, SFRs, (addresses 80h to FFh) are directly addressable only.

4. The expanded RAM bytes are indirectly accessed by MOVX instructions, and with the EXTRAM bit cleared in the AUXR register (see Table 22)

The lower 128 bytes can be accessed by either direct or indirect addressing. The Upper 128 bytes can be accessed by indirect addressing only. The Upper 128 bytes occupy the same address space as the SFR. That means they have the same address, but are physically separate from SFR space.

Figure 8. Internal and External Data Memory Address

When an instruction accesses an internal location above address 7Fh, the CPU knows whether the access is to the upper 128 bytes of data RAM or to SFR space by the addressing mode used in the instruction.

• Instructions that use direct addressing access SFR space. For example: MOV 0A0H, # data, accesses the SFR at location 0A0h (which is P2).

4301D–8051–02/08

• Instructions that use indirect addressing access the Upper 128 bytes of data RAM. For example: MOV @R0, # data where R0 contains 0A0h, accesses the data byte at address 0A0h, rather than P2 (whose address is 0A0h).

• The XRAM bytes can be accessed by indirect addressing, with EXTRAM bit cleared and MOVX instructions. This part of memory which is physically located on-chip, logically occupies the first bytes of external data memory. The bits XRS0 and XRS1 are used to hide a part of the available XRAM as explained in Table 22. This can be useful if external peripherals are mapped at addresses already used by the internal XRAM.

• With EXTRAM = 0, combination with any of the registers R0, R1 of the selected bank or DPTR. An access to XRAM will not affect ports P0, P2, P3.6 (WR) and P3.7 (RD). For example, with EXTRAM = 0, MOVX @R0, # data where R0 contains 0A0H, accesses the XRAM at address 0A0H rather than external memory. An access to external data memory locations higher than the accessible size of the XRAM will be performed with the MOVX DPTR instructions in the same way as in the standard 80C51, with P0 and P2 as data/address busses, and P3.6 and P3.7 as write and read timing signals. Accesses to XRAM above 0FFH can only be done by the use of DPTR.

• With EXTRAM = 1, MOVX @Ri and MOVX @DPTR will be similar to the standard 80C51. MOVX @ Ri will provide an eight-bit address multiplexed with data on Port0 and any output port pins can be used to output higher order address bits. This is to provide the external paging capability. MOVX @DPTR will generate a sixteen-bit address. Port2 outputs the high-order eight address bits (the contents of DPH) while Port0 multiplexes the low-order eight address bits (DPL) with data. MOVX @ Ri and MOVX @DPTR will generate either read or write signals on P3.6 (WR) and P3.7 (RD).

the XRAM is indirectly addressed, using the MOVX instruction in

The stack pointer (SP) may be located anywhere in the 256 bytes RAM (lower and upper RAM) internal data memory. The stack may not be located in the XRAM.

The M0 bit allows to stretch the XRAM timings; if M0 is set, the read and write pulses are exten ded from 6 to 30 clock periods. This is useful to access external slow peripherals.

AT89C51IC2

4301D–8051–02/08

AT89C51IC2

Table 23. AUXR Register

AUXR - Auxiliary Register (8Eh)

7 6 5 4 3 2 1 0

- - M0 - XRS1 XRS0 EXTRAM AO

Bit

Number

7 -

6 -

5 M0

4 -

3 XRS1 XRAM Size

2 XRS0

1 EXTRAM

Bit

Mnemonic Description

Reserved

The value read from this bit is indeterminate. Do not set this bit

Reserved

The value read from this bit is indeterminate. Do not set this bit

Pulse length

Cleared to stretch MOVX control: the RD/ and the WR/ pulse length is 6 clock periods (default).

Set to stretch MOVX control: the RD/ and the WR/ pulse length is 30 clock periods.

Reserved

The value read from this bit is indeterminate. Do not set this bit

XRS1 0 0 256 bytes (default)

0 1 512 bytes

1 0 768 bytes

1 1 1024 bytes

EXTRAM bit

Cleared to access internal XRAM using movx @ Ri/ @ DPTR.

Set to access external memory.

Programmed by hardware after Power-up regarding Hardware Security Byte (HSB), default setting, XRAM selected.

XRS0 XRAM size

4301D–8051–02/08

ALE Output bit

0 AO

Cleared, ALE is emitted at a constant rate of 1/6 the oscillator frequency (or 1/3 if X2 mode is used) (default) Set, ALE is active only during a MOVX or MOVC instruction is used.

Reset Value = XX0X 00’HSB.XRAM’0b Not bit addressable

Timer 2 The Timer 2 in the AT89C51IC2 is the standard C52 the Timer 2.

It is a 16-bit timer/counter: the count is maintained by two eight-bit timer registers, TH2 and TL2 are cascaded. It is controlled by T2CON (Table 24) and T2MOD (Table 25) registers. Timer 2 operation is similar to Timer 0 and Timer 1. C/T2 selects F (timer operation) or external pin T2 (counter operation) as the timer clock input. Setting TR2 allows TL2 to be incremented by the selected input.

Timer 2 has 3 operating modes: capture, autoreload and Baud Rate Generator. These modes are selected by the combination of RCLK, TCLK and CP/RL2

Refer to the Atmel 8-bit Microcontroller Hardware description for the description of Capture and Baud Rate Generator Modes.

Timer 2 includes the following enhancements:

• Auto-reload mode with up or down counter

• Programmable clock-output

(T2CON).

Auto-Reload Mode The auto-reload mode configures timer 2 as a 16-bit timer or event counter with auto-

matic reload. If DCEN bit in T2MOD is cleared, timer 2 behaves as in 80C52 (refer to the Atmel 8-bit Microcontroller Hardware description). If DCEN bit is set, timer 2 acts as an Up/down timer/counter as shown in Figure 9. In this mode the T2EX pin controls the direction of count.

When T2EX is high, timer 2 counts up. Timer overflow occurs at FFFFh which sets the TF2 flag and generates an interrupt request. The overflow also causes the 16-bit value in RCAP2H and RCAP2L registers to be loaded into the timer registers TH2 and TL2.

OSC

/12

When T2EX is low, timer 2 counts down. Timer underflow occurs when the count in the timer registers TH2 and TL2 equals the value stored in RCAP2H and RCAP2L registers. The underflow sets TF2 flag and reloads FFFFh into the timer registers.

The EXF2 bit toggles when timer 2 overflows or underflows according to the direction of the count. EXF2 does not generate any interrupt. This bit can be used to provide 17-bit resolution.

AT89C51IC2

4301D–8051–02/08

Figure 9. Auto-Reload Mode Up/Down Counter (DCEN = 1)

(DOWN COUNTING RELOAD VALUE)

C/T2

TF2

TR2

EXF2

TH2

(8-bit)

TL2

(8-bit)

RCAP2H

(8-bit)

RCAP2L

(8-bit)

FFh

(8-bit)

FFh

(8-bit)

TOGGLE

(UP COUNTING RELOAD VALUE)

TIMER 2

INTERRUPT

CLK PERIPH

T2CON

T2EX:

if DCEN=1, 1=UP

if DCEN=1, 0=DOWN

if DCEN = 0, up counting

Clock O utFreq uency–

CL KPE R IP H

4 65536 RC AP2H– RCAP2 L⁄( )×

-----------------------------------------------------------------------------------------

AT89C51IC2

Programmable ClockOutput

In the clock-out mode, timer 2 operates as a 50%-duty-cycle, programmable clock generator (See Figure 10). The input clock increments TL2 at frequency F

CLK PERIPH

/2. The timer repeatedly counts to overflow from a loaded value. At overflow, the contents of RCAP2H and RCAP2L registers are loaded into TH2 and TL2. In this mode, timer 2 overflows do not generate interrupts. The formula gives the clock-out frequency as a function of the system oscillator frequency and the value in the RCAP2H and RCAP2L registers:

For a 16 MHz system clock, timer 2 has a programmable frequency range of 61 Hz (F

CLK PERIPH

16)

to 4 MHz (F

T2 pin (P1.0).

Timer 2 is programmed for the clock-out mode as follows:

• Set T2OE bit in T2MOD register.

CLK PERIPH

/4). The generated clock signal is brought out to

• Clear C/T2 bit in T2CON register.

• Determine the 16-bit reload value from the formula and enter it in RCAP2H/RCAP2L

registers.

• Enter a 16-bit initial value in timer registers TH2/TL2. It can be the same as the

reload value or a different one depending on the application.

• To start the timer, set TR2 run control bit in T2CON register.

It is possible to use timer 2 as a baud rate generator and a clock generator simultane o usly. For this con f iguratio n, t he baud rates and cloc k f requencie s are n o t independent since both functions use the values in the RCAP2H and RCAP2L registers.

4301D–8051–02/08

Figure 10. Clock-Out Mode C/T2 = 0

EXF2

TR2

OVEFLOW

T2EX

TH2

(8-bit)

TL2

(8-bit)

TIMER 2

RCAP2H

(8-bit)

RCAP2L

(8-bit)

T2OE

CLK PERIPH

T2CON

T2MOD

INTERRUPT

Q D

Toggle

EXEN2

AT89C51IC2

4301D–8051–02/08

AT89C51IC2

Table 24. T2CON Register

T2CON - Timer 2 Control Register (C8h)

7 6 5 4 3 2 1 0

TF2 EXF2 RCLK TCLK EXEN2 TR2 C/T2# CP/RL2#

Bit

Number

7 TF2

6 EXF2

5 RCLK

4 TCLK

3 EXEN2

2 TR2

Bit

Mnemonic Description

Timer 2 overflow Flag

Must be cleared by software. Set by hardware on timer 2 overflow, if RCLK = 0 and TCLK = 0.

Timer 2 External Flag

Set when a capture or a reload is caused by a negative transition on T2EX pin if EXEN2=1. When set, causes the CPU to vector to timer 2 interrupt routine when timer 2 interrupt is enabled. Must be cleared by software. EXF2 doesn’t cause an interrupt in Up/down counter mode (DCEN = 1)

Receive Clock bit

Cleared to use timer 1 overflow as receive clock for serial port in mode 1 or 3. Set to use timer 2 overflow as receive clock for serial port in mode 1 or 3.

Transmit Clock bit

Cleared to use timer 1 overflow as transmit clock for serial port in mode 1 or 3. Set to use timer 2 overflow as transmit clock for serial port in mode 1 or 3.

Timer 2 External Enable bit

Cleared to ignore events on T2EX pin for timer 2 operation. Set to cause a capture or reload when a negative transition on T2EX pin is detected, if timer 2 is not used to clock the serial port.

Timer 2 Run control bit

Cleared to turn off timer 2. Set to turn on timer 2.

4301D–8051–02/08

Timer/Counter 2 select bit

1 C/T2#

0 CP/RL2#

Cleared for timer operation (input from internal clock system: F Set for counter operation (input from T2 input pin, falling edge trigger). Must be 0 for clock out mode.

Timer 2 Capture/Reload bit

If RCLK=1 or TCLK=1, CP/RL2# is ignored and timer is forced to auto-reload on timer 2 overflow. Cleared to auto-reload on timer 2 overflows or negative transitions on T2EX pin if EXEN2=1. Set to capture on negative transitions on T2EX pin if EXEN2=1.

Reset Value = 0000 0000b Bit addressable

CLK PERIPH

Table 25. T2MOD Register

T2MOD - Timer 2 Mode Control Register (C9h)

7 6 5 4 3 2 1 0

- - - - - - T2OE DCEN

Bit

Number

7 -

6 -

5 -

4 -

3 -

2 -

1 T2OE

0 DCEN

Bit

Mnemonic Description

Reserved

The value read from this bit is indeterminate. Do not set this bit.

Reserved

The value read from this bit is indeterminate. Do not set this bit.

Reserved

The value read from this bit is indeterminate. Do not set this bit.

Reserved

The value read from this bit is indeterminate. Do not set this bit.

Reserved

The value read from this bit is indeterminate. Do not set this bit.

Reserved

The value read from this bit is indeterminate. Do not set this bit.

Timer 2 Output Enable bit

Cleared to program P1.0/T2 as clock input or I/O port. Set to program P1.0/T2 as clock output.

Down Counter Enable bit

Cleared to disable timer 2 as up/down counter. Set to enable timer 2 as up/down counter.

Reset Value = XXXX XX00b Not bit addressable

AT89C51IC2

4301D–8051–02/08

AT89C51IC2

Programmable Counter Array PCA

The PCA provides more timing capabilities with less CPU intervention than the standard timer/counters. Its advantages include reduced software overhead and improved accuracy. The PCA consists of a dedicated timer/counter which serves as the time base for an array of five compare/capture modules. Its clock input can be programmed to count any one of the following signals:

• Peripheral clock frequency (F

CLK PERIPH

) ÷ 6 ) ÷ 2

• Timer 0 overflow

• External input on ECI (P1.2)

Each compare/capture modules can be programmed in any one of the following modes:

• rising and/or falling edge capture

• software timer

• high-speed output

• pulse width modulator

Module 4 can also be programmed as a watchdog timer (See Section "PCA Watchdog Timer", page 46).

When the compare/capture modules are programmed in the capture mode, software timer, or high speed output mode, an interrupt can be generated when the module executes its function. All five modules plus the PCA timer overflow share one interrupt vector.

The PCA timer/counter and compare/capture modules share Port 1 for external I/O. These pins are listed below. If the port is not used for the PCA, it can still be used for standard I/O.

PCA component External I/O Pin

16-bit Counter P1.2 / ECI

16-bit Module 0 P1.3 / CEX0

16-bit Module 1 P1.4 / CEX1

16-bit Module 2 P1.5 / CEX2

16-bit Module 3 P1.6 / CEX3

The PCA timer is a common time base for all five modules (See Figure 11). The timer count source is determined from the CPS1 and CPS0 bits in the CMOD register (Table 26) and can be programmed to run at:

• 1/6 the

peripheral clock frequency (F

• 1/2 the peripheral clock frequency (F

CLK PERIPH

) )

• The Timer 0 overflow

• The input on the ECI pin (P1.2)

4301D–8051–02/08

Figure 11. PCA Timer/Counter

CIDL CPS1 CPS0 ECF

CH CL

16 bit up counter

To PCA modules

Fclk periph /6

Fclk periph / 2

T0 OVF

P1.2

Idle

CMOD 0xD9

WDTE

CF CR

CCON 0xD8

CCF4 CCF3 CCF2 CCF1 CCF0

overflow

AT89C51IC2

4301D–8051–02/08

AT89C51IC2

Table 26. CMOD Register

CMOD - PCA Counter Mode Register (D9h)

7 6 5 4 3 2 1 0

CIDL WDTE - - - CPS1 CPS0 ECF

Bit

Number

7 CIDL

6 WDTE

5 -

4 -

3 -

2 CPS1 PCA Count Pulse Select

1 CPS0

0 ECF

Bit

Mnemonic Description

Counter Idle Control

Cleared to program the PCA Counter to continue functioning during idle Mode.

Set to program PCA to be gated off during idle.

Watchdog Timer Enable

Cleared to disable Watchdog Timer function on PCA Module 4.

Set to enable Watchdog Timer function on PCA Module 4.

Reserved

The value read from this bit is indeterminate. Do not set this bit.

Reserved

The value read from this bit is indeterminate. Do not set this bit.

Reserved

The value read from this bit is indeterminate. Do not set this bit.

CPS1 0 0 Internal clock fCLK PERIPH/6

0 1 Internal clock fCLK PERIPH/2

1 0 Timer 0 Overflow

1 1 External clock at ECI/P1.2 pin (max rate = fCLK PERIPH/ 4)

PCA Enable Counter Overflow Interrupt

Cleared to disable CF bit in CCON to inhibit an interrupt. Set to enable CF bit in CCON to generate an interrupt.

CPS0Selected PCA input

4301D–8051–02/08

Reset Value = 00XX X000b Not bit addressable

The CMOD register includes three additional bits associated with the PCA (See Figure 11 and Table 26).

• The CIDL bit which allows the PCA to stop during idle mode.

• The WDTE bit which enables or disables the watchdog function on module 4.

• The ECF bit which when set causes an interrupt and the PCA overflow flag CF (in

the CCON SFR) to be set when the PCA timer overflows.

The CCON register contains the run control bit for the PCA and the flags for the PCA timer (CF) and each module (Refer to Table 27).

• Bit CR (CCON.6) must be set by software to run the PCA. The PCA is shut off by

clearing this bit.

• Bit CF: The CF bit (CCON.7) is set when the PCA counter overflows and an

interrupt will be generated if the ECF bit in the CMOD register is set. The CF bit can only be cleared by software.

• Bits 0 through 4 are the flags for the modules (bit 0 for module 0, bit 1 for module 1,

etc.) and are set by hardware when either a match or a capture occurs. These flags also can only be cleared by software.

Table 27. CCON Register

CCON - PCA Counter Control Register (D8h)

7 6 5 4 3 2 1 0

CF CR - CCF4 CCF3 CCF2 CCF1 CCF0

Bit

Number

7 CF

6 CR

5 -

4 CCF4

3 CCF3

2 CCF2

1 CCF1

Bit

Mnemonic Description

PCA Counter Overflow flag

Set by hardware when the counter rolls over. CF flags an interrupt if bit ECF in CMOD is set. CF

may be set by either hardware or software but can only be cleared by software.

PCA Counter Run control bit

Must be cleared by software to turn the PCA counter off.

Set by software to turn the PCA counter on.

Reserved

The value read from this bit is indeterminate. Do not set this bit.

PCA Module 4 interrupt flag

Must be cleared by software.

Set by hardware when a match or capture occurs.

PCA Module 3 interrupt flag

Must be cleared by software.

Set by hardware when a match or capture occurs.

PCA Module 2 interrupt flag

Must be cleared by software.

Set by hardware when a match or capture occurs.

PCA Module 1 interrupt flag

Must be cleared by software.

Set by hardware when a match or capture occurs.

AT89C51IC2

PCA Module 0 interrupt flag

0 CCF0

Must be cleared by software.

Set by hardware when a match or capture occurs.

Reset Value = 00X0 0000b Not bit addressable

The watchdog timer function is implemented in module 4 (See Figure 14).

The PCA interrupt system is shown in Figure 12.

4301D–8051–02/08

Figure 12. PCA Interrupt System

CF CR

CCON

0xD8

CCF4 CCF3 CCF2 CCF1 CCF0

Module 4

Module 3

Module 2

Module 1

Module 0

ECF

PCA Timer/Counter

ECCFn

CCAPMn.0CMOD.0

IEN0.6 IEN0.7

To Interrupt

priority decoder

EC EA

AT89C51IC2

PCA Modules: each one of the five compare/capture modules has six possible func-

tions. It can perform:

• 16-bit Capture, positive-edge triggered

• 16-bit Capture, negative-edge triggered

• 16-bit Capture, both positive and negative-edge triggered

• 16-bit Software Timer

• 16-bit High Speed Output

• 8-bit Pulse Width Modulator

In addition, module 4 can be used as a Watchdog Timer.

Each module in the PCA has a special function register associated with it. These registers are: CCAPM0 for module 0, CCAPM1 for module 1, etc. (See Table 28). The registers contain the bits that control the mode that each module will operate in.

• The ECCF bit (CCAPMn.0 where n=0, 1, 2, 3, or 4 depending on the module)

enables the CCF flag in the CCON SFR to generate an interrupt when a match or compare occurs in the associated module.

• PWM (CCAPMn.1) enables the pulse width modulation mode.

• The TOG bit (CCAPMn.2) when set causes the CEX output associated with the

module to toggle when there is a match between the PCA counter and the module's capture/compare register.

• The match bit MAT (CCAPMn.3) when set will cause the CCFn bit in the CCON

• The next two bits CAPN (CCAPMn.4) and CAPP (CCAPMn.5) determine the edge

that a capture input will be active on. The CAPN bit enables the negative edge, and the CAPP bit enables the positive edge. If both bits are set both edges will be enabled and a capture will occur for either transition.

• The last bit in the register ECOM (CCAPMn.6) when set enables the comparator

function.

4301D–8051–02/08

Table 28 shows the CCAPMn settings for the various PCA functions.

Table 28. CCAPMn Registers (n = 0-4)

CCAPM0 - PCA Module 0 Compare/Capture Control Register (0DAh)

CCAPM1 - PCA Module 1 Compare/Capture Control Register (0DBh)

CCAPM2 - PCA Module 2 Compare/Capture Control Register (0DCh)

CCAPM3 - PCA Module 3 Compare/Capture Control Register (0DDh)

CCAPM4 - PCA Module 4 Compare/Capture Control Register (0DEh)

7 6 5 4 3 2 1 0

- ECOMn CAPPn CAPNn MATn TOGn PWMn ECCFn

Bit

Number

7 -

6 ECOMn

5 CAPPn

4 CAPNn

3 MATn

2 TOGn

1 PWMn

Bit

Mnemonic Description

Reserved

The value read from this bit is indeterminate. Do not set this bit.

Enable Comparator

Cleared to disable the comparator function.

Set to enable the comparator function.

Capture Positive

Cleared to disable positive edge capture. Set to enable positive edge capture.

Capture Negative

Cleared to disable negative edge capture. Set to enable negative edge capture.

Match

When MATn = 1, a match of the PCA counter with this module's compare/capture register causes the

CCFn bit in CCON to be set, flagging an interrupt.

Toggle

When TOGn = 1, a match of the PCA counter with this module's compare/capture register causes the

CEXn pin to toggle.

Pulse Width Modulation Mode

Cleared to disable the CEXn pin to be used as a pulse width modulated output.

Set to enable the CEXn pin to be used as a pulse width modulated output.

AT89C51IC2

Enable CCF interrupt

0 CCF0

Cleared to disable compare/capture flag CCFn in the CCON register to generate an interrupt.

Set to enable compare/capture flag CCFn in the CCON register to generate an interrupt.

Reset Value = X000 0000b Not bit addressable

4301D–8051–02/08

AT89C51IC2

Table 29. PCA Module Modes (CCAPMn Registers)

ECOMn CAPPn CAPNn MATn TOGn PWMm ECCFn Module Function

0 0 0 0 0 0 0 No Operation

X 1 0 0 0 0 X

X 0 1 0 0 0 X

X 1 1 0 0 0 X

1 0 0 1 0 0 X

1 0 0 1 1 0 X 16-bit High Speed Output

1 0 0 0 0 1 0 8-bit PWM

1 0 0 1 X 0 X Watchdog Timer (module 4 only)

16-bit capture by a positive-edge trigger on CEXn

16-bit capture by a negative trigger on CEXn

16-bit capture by a transition on CEXn

16-bit Software Timer / Compare mode.

There are two additional registers associated with each of the PCA modules. They are CCAPnH and CCAPnL and these are the registers that store the 16-bit count when a capture occurs or a compare should occur. When a module is used in the PWM mode these registers are used to control the duty cycle of the output (See Table 30 & Table 31).

Table 30. CCAPnH Registers (n = 0-4)

CCAP0H - PCA Module 0 Compare/Capture Control Register High (0FAh)

CCAP1H - PCA Module 1 Compare/Capture Control Register High (0FBh)

CCAP2H - PCA Module 2 Compare/Capture Control Register High (0FCh)

CCAP3H - PCA Module 3 Compare/Capture Control Register High (0FDh)

CCAP4H - PCA Module 4 Compare/Capture Control Register High (0FEh)

7 6 5 4 3 2 1 0

- - - - - - - -

Bit

Number

7-0 -

Bit

Mnemonic Description

PCA Module n Compare/Capture Control

CCAPnH Value

Reset Value = 0000 0000b Not bit addressable

4301D–8051–02/08

Table 31. CCAPnL Registers (n = 0-4)

CCAP0L - PCA Module 0 Compare/Capture Control Register Low (0EAh)

CCAP1L - PCA Module 1 Compare/Capture Control Register Low (0EBh)

CCAP2L - PCA Module 2 Compare/Capture Control Register Low (0ECh)

CCAP3L - PCA Module 3 Compare/Capture Control Register Low (0EDh)

CCAP4L - PCA Module 4 Compare/Capture Control Register Low (0EEh)

7 6 5 4 3 2 1 0

- - - - - - - -

Bit

Number

7-0 -

Bit

Mnemonic Description

PCA Module n Compare/Capture Control

CCAPnL Value

Reset Value = 0000 0000b Not bit addressable

Table 32. CH Register

CH - PCA Counter Register High (0F9h)

7 6 5 4 3 2 1 0

- - - - - - - -

Bit

Number

7-0 -

Bit

Mnemonic Description

PCA counter

CH Value

Reset Value = 0000 0000b Not bit addressable

Table 33. CL Register

AT89C51IC2

CL - PCA Counter Register Low (0E9h)

7 6 5 4 3 2 1 0

- - - - - - - -

Bit

Number

7-0 -

Bit

Mnemonic Description

PCA Counter

CL Value

Reset Value = 0000 0000b Not bit addressable

4301D–8051–02/08

AT89C51IC2

CF CR

CCON 0xD8

CH CL

CCAPnH CCAPnL

CCF4 CCF3 CCF2 CCF1 CCF0

PCA IT

PCA Coun ter/Timer

ECOMn

CCAPMn, n= 0 to 4 0xDA to 0xDE

CAPNn MATn TOGn PWMn ECCFnCAPPn

Cex.n

Capture

PCA Capture Mode To use one of the PCA modules in the capture mode either one or both of the CCAPM

bits CAPN and CAPP for that module must be set. The external CEX input for the module (on port 1) is sampled for a transition. When a valid transition occurs the PCA hardware loads the value of the PCA counter registers (CH and CL) into the module's capture registers (CCAPnL and CCAPnH). If the CCFn bit for the module in the CCON SFR and the ECCFn bit in the CCAPMn SFR are set then an interrupt will be generated (Refer to Figure 13).

Figure 13. PCA Capture Mode

16-bit Software Timer/ Compare Mode

4301D–8051–02/08

The PCA modules can be used as software timers by setting both the ECOM and MAT bits in the modules CCAPMn register. The PCA timer will be compared to the module's capture registers and when a match occurs an interrupt will occur if the CCFn (CCON SFR) and the ECCFn (CCAPMn SFR) bits for the module are both set (See Figure 14).

Figure 14. PCA Compare Mode and PCA Watchdog Timer

CH CL

CCAPnH CCAPnL

ECOMn

CCA PMn, n = 0 to 4

0xDA to 0xDE

CAPNn MA Tn TOGn PWMn ECCFnCAPPn

16 bit comparator

Match

CCON

0xD8

PCA IT

Enable

PCA counter/timer

RESET *

CIDL CPS1 CP S0 ECF

CMOD

0xD9

WDTE

Reset

Write to

CCAPnL

Write to

CCAPnH

CF CCF2 CCF1 CCF0

CCF3CCF4

1 0

Before enabling ECOM bit, CCAPnL and CCAPnH should be set with a non zero value, otherwise an unwanted match could happen. Writing to CCAPnH will set the ECOM bit.

Once ECOM set, writing CCAPnL will clear ECOM so that an unwanted match doesn’t occur while modifying the compare value. Writing to CCAPnH will set ECOM. For this reason, user software should write CCAPnL first, and then CCAPnH. Of course, the ECOM bit can still be controlled by accessing to CCAPMn register.

High Speed Output Mode In this mode the CEX output (on port 1) associated with the PCA module will toggle

each time a match occurs between the PCA counter and the module's capture registers. To activate this mode the TOG, MAT, and ECOM bits in the module's CCAPMn SFR must be set (See Figure 15).

A prior write must be done to CCAPnL and CCAPnH before writing the ECOMn bit.

AT89C51IC2

4301D–8051–02/08

Figure 15. PCA High Speed Output Mode

CH CL

CCAPnH CCAPnL

ECOMn

CCAPMn, n = 0 to 4

0xDA to 0xDE

CAPNn MATn TOGn P WMn ECCFnCAPPn

16 bit comparator

Match

CF CR

CCON

0xD8

CCF4 CCF3 CCF2 CCF1 CCF0

PCA IT

Enable

CEXn

PCA counter/timer

Write to

CCAPnH

Reset

Writ e to

CCAPnL

AT89C51IC2

Pulse Width Modulator Mode

Before enabling ECOM bit, CCAPnL and CCAPnH should be set with a non zero value, otherwise an unwanted match could happen.

All of the PCA modules can be used as PWM outputs. Figure 16 shows the PWM function. The frequency of the output depends on the source for the PCA timer. All of the modules will have the same frequency of output because they all share the PCA timer. The duty cycle of each module is independently variable using the module's capture register CCAPLn. When the value of the PCA CL SFR is less than the value in the module's CCAPLn SFR the output will be low, when it is equal to or greater than the output will be high. When CL overflows from FF to 00, CCAPLn is reloaded with the value in CCAPHn. This allows updating the PWM without glitches. The PWM and ECOM bits in the module's CCAPMn register must be set to enable the PWM mode.

4301D–8051–02/08

Figure 16. PCA PWM Mode

CCAPnH

CCAPnL

ECOMn

CCAPMn, n= 0 to 4

0xDA to 0xDE

CAPNn MATn TOGn PWMn ECCFnCAPPn

8 bit comparator

CEXn

“0”

“1”

Enable

PCA counter/timer

Overflow

PCA Watchdog Timer An on-board watchdog timer is available with the PCA to improve the reliability of the

system without increasing chip count. Watchdog timers are useful for systems that are susceptible to noise, power glitches, or electrostatic discharge. Module 4 is the only PCA module that can be programmed as a watchdog. However, this module can still be used for other modes if the watchdog is not needed. Figure 14 shows a diagram of how the watchdog works. The user pre-loads a 16-bit value in the compare registers. Just like the other compare modes, this 16-bit value is compared to the PCA timer value. If a match is allowed to occur, an internal reset will be generated. This will not cause the RST pin to be driven high.

In order to hold off the reset, the user has three options:

1. periodically change the compare value so it will never match the PCA timer,

2. periodically change the PCA timer value so it will never match the compare values, or

3. disable the watchdog by clearing the WDTE bit before a match occurs and then reenable it.

The first two options are more reliable because the watchdog timer is never disabled as in option #3. If the program counter ever goes astray, a match will eventually occur and cause an internal reset. The second option is also not recommended if other PCA modules are being used. Remember, the PCA timer is the time base for all modules; changing the time base for other modules would not be a good idea. Thus, in most applications the first solution is the best option.

This watchdog timer won’t generate a reset out on the reset pin.

AT89C51IC2

4301D–8051–02/08

AT89C51IC2

RITIRB8TB8RENSM2SM1SM0/FE

IDLPDGF0GF1POF-SMOD0SMOD1

To UART framing error control

SM0 to UART mode control (SMOD0 = 0)

Set FE bit if stop bit is 0 (framing error) (SMOD0 = 1)

SCON (98h)

PCON (87h)

Data byte

SMOD0=X

Stop

bit

Start

bit

RXD

D7D6D5D4D3D2D1D0

SMOD0=1

Serial I/O Port The serial I/O port in the AT89C51IC2 is compatible with the serial I/O port in the 80C52.

It provides both synchronous and asynchronous communication modes. It operates as a Universal Asynchronous Receiver and Transmitter (UART) in three full-duplex modes (Modes 1, 2 and 3). Asynchronous transmission and reception can occur simultaneously and at different baud rates

Serial I/O port includes the following enhancements:

• Framing error detection

• Automatic address recognition

Framing Error Detection Framing bit error detection is provided for the three asynchronous modes (modes 1, 2

and 3). To enable the framing bit error detection feature, set SMOD0 bit in PCON register (See Figure 17).

Figure 17. Framing Error Block Diagram

When this feature is enabled, the receiver checks each incoming data frame for a valid stop bit. An invalid stop bit may result from noise on the serial lines or from simultaneous transmission by two CPUs. If a valid stop bit is not found, the Framing Error bit (FE) in SCON register (See Table 37.) bit is set. Software may examine FE bit after each reception to check for data errors. Once set, only software or a reset can clear FE bit. Subsequently received frames with valid stop bits cannot clear FE bit. When FE feature is enabled, RI rises on stop bit instead of the last data bit (See Figure 18. and Figure 19.).

Figure 18. UART Timings in Mode 1

4301D–8051–02/08

Figure 19. UART Timings in Modes 2 and 3

SMOD0=0

Data byte Ninth

bit

Stop

bit

Start

bit

RXD

D8D7D6

D5D4D3

D1D0

SMOD0=1

Automatic Address Recognition

The automatic address recognition feature is enabled when the multiprocessor communication feature is enabled (SM2 bit in SCON register is set). Implemented in hardware, automatic address recognition enhances the multiprocessor communication feature by allowing the serial port to examine the address of each incoming command frame. Only when the serial port recognizes its own address, the receiver sets RI bit in SCON register to generate an interrupt. This ensures that the CPU is not interrupted by command frames addressed to other devices. If desired, you may enable the automatic address recognition feature in mode 1. In this configuration, the stop bit takes the place of the ninth data bit. Bit RI is set only when the received command frame address matches the device’s address and is terminated by a valid stop bit. To support automatic address recognition, a device is identified by a given address and a broadcast address.

Note: The multiprocessor communication and automatic address recognition features cannot

be enabled in mode 0 (i.e. setting SM2 bit in SCON register in mode 0 has no effect).

Given Address Each device has an individual address that is specified in SADDR register; the SADEN

register is a mask byte that contains don’t-care bits (defined by zeros) to form the device’s given address. The don’t-care bits provide the flexibility to address one or more slaves at a time. The following example illustrates how a given address is formed. To address a device by its individual address, the SADEN mask byte must be 1111 1111b. For example:

SADDR0101 0110b SADEN1111 1100b

Given0101 01XXb

AT89C51IC2

The following is an example of how to use given addresses to address different slaves:

Slave A:SADDR1111 0001b

SADEN1111 1010b

Given1111 0X0Xb

Slave B:SADDR1111 0011b

SADEN1111 1001b

Given1111 0XX1b

Slave C:SADDR1111 0010b

1111 1101b

SADEN

Given1111 00X1b

4301D–8051–02/08

AT89C51IC2

The SADEN byte is selected so that each slave may be addressed separately. For slave A, bit 0 (the LSB) is a don’t-care bit; for slaves B and C, bit 0 is a 1. To communicate with slave A only, the master must send an address where bit 0 is clear (e.g. 1111 0000b). For slave A, bit 1 is a 1; for slaves B and C, bit 1 is a don’t care bit. To communicate with slaves B and C, but not slave A, the master must send an address with bits 0 and 1 both set (e.g. 1111 0011b). To communicate with slaves A, B and C, the master must send an address with bit 0 set, bit 1 clear, and bit 2 clear (e.g. 1111 0001b).

Broadcast Address A broadcast address is formed from the logical OR of the SADDR and SADEN registers

with zeros defined as don’t-care bits, e.g.:

SADDR 0101 0110b SADEN 1111 1100b

Broadcast =SADDR OR SADEN1111 111Xb

The use of don’t-care bits provides flexibility in defining the broadcast address, however in most applications, a broadcast address is FFh. The following is an example of using broadcast addresses:

Slave A:SADDR1111 0001b

SADEN1111 1010b

Broadcast1111 1X11b,

Slave B:SADDR1111 0011b

SADEN1111 1001b

Broadcast1111 1X11B,

Slave C:SADDR=1111 0010b

SADEN1111 1101b

Broadcast1111 1111b

For slaves A and B, bit 2 is a don’t care bit; for slave C, bit 2 is set. To communicate with all of the slaves, the master must send an address FFh. To communicate with slaves A and B, but not slave C, the master can send and address FBh.

Reset Addresses On reset, the SADDR and SADEN registers are initialized to 00h, i.e. the given and

broadcast addresses are XXXX XXXXb (all don’t-care bits). This ensures that the serial port will reply to any address, and so, that it is backwards compatible with the 80C51 microcontrollers that do not support automatic address recognition.

Table 34. SADEN Register

SADEN - Slave Address Mask Register (B9h)

4301D–8051–02/08

7 6 5 4 3 2 1 0

Reset Value = 0000 0000b Not bit addressable

Table 35. SADDR Register

RCLK

/ 16

RBCK

INT_BRG

TIMER1

TIMER2

INT_BRG

TIMER1

TIMER2

TIMER_BRG_RX

Rx Clock

/ 16

TIMER_BRG_TX

Tx Clock

TBCK

TCLK

SADDR - Slave Address Register (A9h)

7 6 5 4 3 2 1 0

Reset Value = 0000 0000b Not bit addressable

Baud Rate Selection for UART for mode 1 and 3

The Baud Rate Generator for transmit and receive clocks can be selected separately via the T2CON and BDRCON registers.

Figure 20. Baud Rate selection

Table 36. Baud Rate Selection Table UART

TCLK

(T2CON)

RCLK

(T2CON)

TBCK

(BDRCON)

RBCK

(BDRCON)

Clock Source

UART Tx

Clock Source

UART Rx

AT89C51IC2

0 0 0 0 Timer 1 Timer 1

1 0 0 0 Timer 2 Timer 1

0 1 0 0 Timer 1 Timer 2

1 1 0 0 Timer 2 Timer 2

X 0 1 0 INT_BRG Timer 1

X 1 1 0 INT_BRG Timer 2

0 X 0 1 Timer 1 INT_BRG

1 X 0 1 Timer 2 INT_BRG

X X 1 1 INT_BRG INT_BRG

4301D–8051–02/08

AT89C51IC2

Peripheral clock

BRG

BRL

INT_BRG

BRR

auto reload counter

overflow

SPD

Ba u dRate

SMO DFCLK P E R I P H

2 2 6×× 1 SP D–〈 〉 16× 256 BRL( )–[ ]×

----------------------------------------------------------------------------------------------------------

BR L( ) 256

SM OD1FCLK P E R I P H

2 2 6××

1 S P D–( )

16× Bau dRate×

-----------------------------------------------------------------------------------------

–=

Internal Baud Rate Generator (BRG)

Figure 21. Internal Baud Rate

When the internal Baud Rate Generator is used, the Baud Rates are determined by the BRG overflow depending on the BRL reload value, the value of SPD bit (Speed Mode) in BDRCON register and the value of the SMOD1 bit in PCON register.

• The baud rate for UART is token by formula:

4301D–8051–02/08

Table 37. SCON Register

SCON - Serial Control Register (98h)

7 6 5 4 3 2 1 0

FE/SM0 SM1 SM2 REN TB8 RB8 TI RI

Bit

Number

6 SM1

5 SM2

4 REN

3 TB8

Bit

Mnemonic Description

Framing Error bit (SMOD0=1)

SM0

Clear to reset the error state, not cleared by a valid stop bit. Set by hardware when an invalid stop bit is detected.

SMOD0 must be set to enable access to the FE bit.

Serial port Mode bit 0

Refer to SM1 for serial port mode selection.

SMOD0 must be cleared to enable access to the SM0 bit.

Serial port Mode bit 1

SM1 Mode Baud Rate

SM0 0 0 Shift Register F 0 1 8-bit UART Variable 1 0 9-bit UART F 1 1 9-bit UART Variable

Serial port Mode 2 bit / Multiprocessor Communication Enable bit

Clear to disable multiprocessor communication feature.

Set to enable multiprocessor communication feature in mode 2 and 3, and eventually mode 1. This bit should be cleared in mode 0.

Reception Enable bit

Clear to disable serial reception. Set to enable serial reception.

Transmitter Bit 8 / Ninth bit to transmit in modes 2 and 3

o transmit a logic 0 in the 9th bit. Set to transmit a logic 1 in the 9th bit.

XTAL

/12 (or F

/64 or F

/6 in mode X2)

XTAL

/32

XTAL

AT89C51IC2

Receiver Bit 8 / Ninth bit received in modes 2 and 3

2 RB8

1 TI

0 RI

Cleared by hardware if 9th bit received is a logic 0. Set by hardware if 9th bit received is a logic 1.

In mode 1, if SM2 = 0, RB8 is the received stop bit. In mode 0 RB8 is not used.

Transmit Interrupt flag

Clear to acknowledge interrupt. Set by hardware at the end of the 8th bit time in mode 0 or at the beginning of the stop bit in the other modes.

Receive Interrupt flag

Clear to acknowledge interrupt. Set by hardware at the end of the 8th bit time in mode 0, see Figure 18. and Figure 19. in the other modes.

Reset Value = 0000 0000b

Bit addressable

4301D–8051–02/08

AT89C51IC2

Table 38. Example of computed value when X2=1, SMOD1=1, SPD=1

Baud Rates F

BRL Error (%) BRL Error (%)

115200 247 1.23 243 0.16

57600 238 1.23 230 0.16

38400 229 1.23 217 0.16

28800 220 1.23 204 0.16

19200 203 0.63 178 0.16

9600 149 0.31 100 0.16

4800 43 1.23 - -

= 16.384 MHz F

OSCA

= 24MHz

Table 39. Example of computed value when X2=0, SMOD1=0, SPD=0

Baud Rates F

BRL Error (%) BRL Error (%)

4800 247 1.23 243 0.16

2400 238 1.23 230 0.16

1200 220 1.23 202 3.55

600 185 0.16 152 0.16

= 16.384 MHz F

OSCA

= 24MHz

The baud rate generator can be used for mode 1 or 3 (refer to Figure 20.), but also for mode 0 for UART, thanks to the bit SRC located in BDRCON register (Table 46.)

4301D–8051–02/08

UART Registers Table 40. SADEN Register

SADEN - Slave Address Mask Register for UART (B9h)

7 6 5 4 3 2 1 0

Reset Value = 0000 0000b

Table 41. SADDR Register

SADDR - Slave Address Register for UART (A9h)

7 6 5 4 3 2 1 0

Reset Value = 0000 0000b

Table 42. SBUF Register

SBUF - Serial Buffer Register for UART (99h)

7 6 5 4 3 2 1 0

Reset Value = XXXX XXXXb

Table 43. BRL Register

BRL - Baud Rate Reload Register for the internal baud rate generator, UART (9Ah)

7 6 5 4 3 2 1 0

Reset Value = 0000 0000b

AT89C51IC2

4301D–8051–02/08

AT89C51IC2

Table 44. T2CON Register

T2CON - Timer 2 Control Register (C8h)

7 6 5 4 3 2 1 0

TF2 EXF2 RCLK TCLK EXEN2 TR2 C/T2# CP/RL2#

Bit

Number

7 TF2

6 EXF2

5 RCLK

4 TCLK

3 EXEN2

2 TR2

Bit

Mnemonic Description

Timer 2 overflow Flag

Must be cleared by software. Set by hardware on timer 2 overflow, if RCLK = 0 and TCLK = 0.

Timer 2 External Flag

Receive Clock bit for UART

Cleared to use timer 1 overflow as receive clock for serial port in mode 1 or 3. Set to use timer 2 overflow as receive clock for serial port in mode 1 or 3.

Transmit Clock bit for UART

Cleared to use timer 1 overflow as transmit clock for serial port in mode 1 or 3. Set to use timer 2 overflow as transmit clock for serial port in mode 1 or 3.

Timer 2 External Enable bit

Cleared to ignore events on T2EX pin for timer 2 operation. Set to cause a capture or reload when a negative transition on T2EX pin is detected, if timer 2 is not used to clock the serial port.

Timer 2 Run control bit

Cleared to turn off timer 2. Set to turn on timer 2.

4301D–8051–02/08

Timer/Counter 2 select bit

1 C/T2#

0 CP/RL2#

Cleared for timer operation (input from internal clock system: F Set for counter operation (input from T2 input pin, falling edge trigger). Must be 0 for clock out mode.

Timer 2 Capture/Reload bit

Reset Value = 0000 0000b Bit addressable

CLK PERIPH

Table 45. PCON Register

PCON - Power Control Register (87h)

7 6 5 4 3 2 1 0

SMOD1 SMOD0 - POF GF1 GF0 PD IDL

Bit

Number

7 SMOD1

6 SMOD0

5 -

4 POF

3 GF1

2 GF0

1 PD

0 IDL

Bit

Mnemonic Description

Serial port Mode bit 1 for UART

Set to select double baud rate in mode 1, 2 or 3.

Serial port Mode bit 0 for UART

Cleared to select SM0 bit in SCON register. Set to select FE bit in SCON register.

Reserved

The value read from this bit is indeterminate. Do not set this bit.

Power-Off Flag

Cleared to recognize next reset type. Set by hardware when VCC rises from 0 to its nominal voltage. Can also be set by software.

General purpose Flag

Cleared by user for general purpose usage. Set by user for general purpose usage.

General purpose Flag

Cleared by user for general purpose usage. Set by user for general purpose usage.

Power-Down mode bit

Cleared by hardware when reset occurs. Set to enter power-down mode.

Idle mode bit

Cleared by hardware when interrupt or reset occurs. Set to enter idle mode.

Reset Value = 00X1 0000b Not bit addressable

Power-off flag reset value will be 1 only after a power on (cold reset). A warm reset doesn’t affect the value of this bit.

AT89C51IC2

4301D–8051–02/08

AT89C51IC2

Table 46. BDRCON Register

BDRCON - Baud Rate Control Register (9Bh)

7 6 5 4 3 2 1 0

- - - BRR TBCK RBCK SPD SRC

Bit

Number

7 -

6 -

5 -

4 BRR

3 TBCK

2 RBCK

1 SPD

0 SRC

Bit

Mnemonic Description

Reserved

The value read from this bit is indeterminate. Do not set this bit

Reserved

The value read from this bit is indeterminate. Do not set this bit

Reserved

The value read from this bit is indeterminate. Do not set this bit.

Baud Rate Run Control bit

Cleared to stop the internal Baud Rate Generator. Set to start the internal Baud Rate Generator.

Transmission Baud rate Generator Selection bit for UART Cleared to select Timer 1 or Timer 2 for the Baud Rate Generator. Set to select internal Baud Rate Generator.

Reception Baud Rate Generator Selection bit for UART Cleared to select Timer 1 or Timer 2 for the Baud Rate Generator. Set to select internal Baud Rate Generator.

Baud Rate Speed Control bit for UART Cleared to select the SLOW Baud Rate Generator. Set to select the FAST Baud Rate Generator.

Baud Rate Source select bit in Mode 0 for UART

Cleared to select F mode). Set to select the internal Baud Rate Generator for UARTs in mode 0.

/12 as the Baud Rate Generator (F

OSC

CLK PERIPH

/6 in X2

4301D–8051–02/08

Reset Value = XXX0 0000b Not bit addressable

Interrupt System The AT89C51IC2 has a total of 10 interrupt vectors: two external interrupts (INT0 and

IE1

High priority interrupt

Interrupt polling sequence, decreasing from

high to low priority

Low priority

interrupt

Global Disable

Individual Enable

EXF2

TF2

TF0

INT0

INT1

TF1

IPH, IPL

IE0

PCA IT

KBD IT

SPI IT

TWI IT

INT1), three timer interrupts (timers 0, 1 and 2), the serial port interrupt, SPI interrupt, Two Wire Interface (I2C) interrupt, Keyboard interrupt and the PCA global interrupt. These interrupts are shown in Figure 22.

Figure 22. Interrupt Control System

AT89C51IC2

Each of the interrupt sources can be individually enabled or disabled by setting or clearing a bit in the Interrupt Enable register (Table 51 and Table 49). This register also contains a global disable bit, which must be cleared to disable all interrupts at once.

Each interrupt source can also be individually programmed to one out of four priority levels by setting or clearing a bit in the Interrupt Priority register (Table 52) and in the Interrupt Priority High register (Table 50 and Table 51) shows the bit values and priority levels associated with each combination.

4301D–8051–02/08

AT89C51IC2

Registers The PCA interrupt vector is located at address 0033H, the SPI interrupt vector is located

at address 0043H, the I2C interrupt vector at 0043H and Keyboard interrupt vector is located at address 003BH. All other vectors addresses are the same as standard C52 devices.

Table 47. Priority Level Bit Values

IPH.x IPL.x Interrupt Level Priority

0 0 0 (Lowest)

0 1 1

1 0 2

1 1 3 (Highest)

A low-priority interrupt can be interrupted by a high priority interrupt, but not by another low-priority interrupt. A high-priority interrupt can’t be interrupted by any other interrupt source.

If two interrupt requests of different priority levels are received simultaneously, the request of higher priority level is serviced. If interrupt requests of the same priority level are received simultaneously, an internal polling sequence determines which request is serviced. Thus within each priority level there is a second priority structure determined by the polling sequence.

4301D–8051–02/08

Table 48. IENO Register

IEN0 - Interrupt Enable Register (A8h)

7 6 5 4 3 2 1 0

EA EC ET2 ES ET1 EX1 ET0 EX0

Bit

Number

7 EA

6 EC

5 ET2

4 ES

3 ET1

2 EX1

1 ET0

Bit

Mnemonic Description

Enable All interrupt bit

Cleared to disable all interrupts. Set to enable all interrupts.

PCA interrupt enable bit

Cleared to disable.

Set to enable.

Timer 2 overflow interrupt Enable bit

Cleared to disable timer 2 overflow interrupt. Set to enable timer 2 overflow interrupt.

Serial port Enable bit

Cleared to disable serial port interrupt. Set to enable serial port interrupt.

Timer 1 overflow interrupt Enable bit

Cleared to disable timer 1 overflow interrupt. Set to enable timer 1 overflow interrupt.

External interrupt 1 Enable bit

Cleared to disable external interrupt 1. Set to enable external interrupt 1.

Timer 0 overflow interrupt Enable bit

Cleared to disable timer 0 overflow interrupt. Set to enable timer 0 overflow interrupt.

0 EX0

External interrupt 0 Enable bit

Cleared to disable external interrupt 0. Set to enable external interrupt 0.

Reset Value = 0000 0000b Bit addressable

AT89C51IC2

4301D–8051–02/08

AT89C51IC2

Table 49. IPL0 Register

IPL0 - Interrupt Priority Register (B8h)

7 6 5 4 3 2 1 0

- PPCL PT2L PSL PT1L PX1L PT0L PX0L

Bit

Number

7 -

6 PPCL

5 PT2L

4 PSL

3 PT1L

2 PX1L

1 PT0L

0 PX0L

Bit

Mnemonic Description

Reserved

The value read from this bit is indeterminate. Do not set this bit.

PCA interrupt Priority bit

Refer to PPCH for priority level.

Timer 2 overflow interrupt Priority bit

Refer to PT2H for priority level.

Serial port Priority bit

Refer to PSH for priority level.

Timer 1 overflow interrupt Priority bit

Refer to PT1H for priority level.

External interrupt 1 Priority bit

Refer to PX1H for priority level.

Timer 0 overflow interrupt Priority bit

Refer to PT0H for priority level.

External interrupt 0 Priority bit

Refer to PX0H for priority level.

Reset Value = X000 0000b Bit addressable

4301D–8051–02/08

Table 50. IPH0 Register

IPH0 - Interrupt Priority High Register (B7h)

7 6 5 4 3 2 1 0

- PPCH PT2H PSH PT1H PX1H PT0H PX0H

Bit

Number

7 -

6 PPCH

5 PT2H

4 PSH

3 PT1H

Bit

Mnemonic Description

Reserved

The value read from this bit is indeterminate. Do not set this bit.

PCA interrupt Priority high bit.

PPCHPPCLPriority Level 0 0 Lowest 0 1 1 0 1 1 Highest

Timer 2 overflow interrupt Priority High bit

PT2HPT2LPriority Level 0 0 Lowest 0 1 1 0 1 1 Highest

Serial port Priority High bit

PSH PSLPriority Level 0 0 Lowest 0 1 1 0 1 1 Highest

Timer 1 overflow interrupt Priority High bit

PT1HPT1L Priority Level 0 0 Lowest 0 1 1 0 1 1 Highest

AT89C51IC2

External interrupt 1 Priority High bit

PX1HPX1LPriority Level

2 PX1H

1 PT0H

0 PX0H

0 0 Lowest 0 1 1 0 1 1 Highest

Timer 0 overflow interrupt Priority High bit

PT0HPT0LPriority Level 0 0 Lowest 0 1 1 0 1 1 Highest

External interrupt 0 Priority High bit

PX0H PX0LPriority Level 0 0 Lowest 0 1 1 0 1 1 Highest

Reset Value = X000 0000b Not bit addressable

4301D–8051–02/08

AT89C51IC2

Table 51. IEN1 Register

IEN1 - Interrupt Enable Register (B1h)

7 6 5 4 3 2 1 0

- - - - - ESPI ETWI KBD

Bit

Number

7 -

6 -

5 -

4 -

3 -

2 ESPI

1 ETWI

0 KBD

Bit

Mnemonic Description

Reserved

SPI interrupt Enable bit

Cleared to disable SPI interrupt.

Set to enable SPI interrupt.

TWI interrupt Enable bit

Cleared to disable TWI interrupt.

Set to enable TWI interrupt.

Keyboard interrupt Enable bit

Cleared to disable keyboard interrupt. Set to enable keyboard interrupt.

Reset Value = XXXX X000b Bit addressable

4301D–8051–02/08

Table 52. IPL1 Register

IPL1 - Interrupt Priority Register (B2h)

7 6 5 4 3 2 1 0

- - - - - SPIL TWIL KBDL

Bit

Number

7 -

6 -

5 -

4 -

3 -

2 SPIL

1 TWIL

0 KBDL

Bit

Mnemonic Description

Reserved

The value read from this bit is indeterminate. Do not set this bit.

Reserved

The value read from this bit is indeterminate. Do not set this bit.

Reserved

The value read from this bit is indeterminate. Do not set this bit.

Reserved

The value read from this bit is indeterminate. Do not set this bit.

Reserved

The value read from this bit is indeterminate. Do not set this bit.

SPI interrupt Priority bit

Refer to SPIH for priority level.

TWI interrupt Priority bit

Refer to TWIH for priority level.

Keyboard interrupt Priority bit

Refer to KBDH for priority level.

Reset Value = XXXX X000b Bit addressable

AT89C51IC2

4301D–8051–02/08

AT89C51IC2

Table 53. IPH1 Register

IPH1 - Interrupt Priority High Register (B3h)

7 6 5 4 3 2 1 0

- - - - - SPIH TWIH KBDH

Bit

Number

7 -

6 -

5 -

4 -

3 -

2 SPIH

1 TWIH

Bit

Mnemonic Description

Reserved

The value read from this bit is indeterminate. Do not set this bit.

Reserved

The value read from this bit is indeterminate. Do not set this bit.

Reserved

The value read from this bit is indeterminate. Do not set this bit.

Reserved

The value read from this bit is indeterminate. Do not set this bit.

Reserved

The value read from this bit is indeterminate. Do not set this bit.

SPI interrupt Priority High bit

SPIHSPILPriority Level 0 0 Lowest 0 1 1 0 1 1 Highest

TWI interrupt Priority High bit

TWIHTWILPriority Level 0 0 Lowest 0 1 1 0 1 1 Highest

4301D–8051–02/08

Keyboard interrupt Priority High bit

KB DHKBDLPriority Level

0 KBDH

0 0 Lowest 0 1 1 0 1 1 Highest

Reset Value = XXXX X000b Not bit addressable

Interrupt Sources and Vector Addresses

Table 54. Interrupt Sources and Vector Addresses

Number Polling Priority Interrupt Source

0 0 Reset 0000h

1 1 INT0 IE0 0003h

2 2 Timer 0 TF0 000Bh

3 3 INT1 IE1 0013h

4 4 Timer 1 IF1 001Bh

5 6 UART RI+TI 0023h

6 7 Timer 2 TF2+EXF2 002Bh

7 5 PCA CF + CCFn (n = 0-4) 0033h

8 8 Keyboard KBDIT 003Bh

9 9 TWI TWIIT 0043h

10 10 SPI SPIIT 004Bh

Interrupt

Request

Vector

Address

AT89C51IC2

4301D–8051–02/08

AT89C51IC2

RST

VSS

To CPU Core and Peripherals

RST

VDD

Power-on ResetRST input circuitry

VDD

From Internal Reset Source

Power Management Two power reduction modes are implemented in the AT89C51IC2: the Idle mode and

the Power-down mode. These modes are detailed in the following sections. In addition to these power reduction modes, the clocks of the core and peripherals can be dynamically divided by 2 using the X2 mode detailed in Section “Enhanced Features”.

Reset In order to start-up (cold reset) or to restart (warm reset) properly the microcontroller, an

high level has to be applied on the RST pin. A bad level leads to a wrong initialization of the internal registers like SFRs, Program Counter… and to unpredictable behavior of the microcontroller. A proper device reset initializes the AT89C51IC2 and vectors the CPU to address 0000h. RST input has a pull-down resistor allowing power-on reset by simply connecting an external capacitor to V be applied either directly on the RST pin or indirectly by an internal reset source such as the watchdog timer. Resistor value and input characteristics are discussed in the Section “DC Characteristics” of the AT89C51IC2 datasheet.

Figure 23. Reset Circuitry and Power-On Reset

as shown in Figure 23. A warm reset can

Cold Reset 2 conditions are required before enabling a CPU start-up:

• V

must reach the specified VDD range

• The level on X1 input pin must be outside the specification (VIH, VIL)

If one of these 2 conditions are not met, the microcontroller does not start correctly and can execute an instruction fetch from anywhere in the program space. An active level applied on the RST pin must be maintained till both of the above conditions are met. A reset is active when the level V

is reached and when the pulse width covers the

IH1

period of time where VDD and the oscillator are not stabilized. 2 parameters have to be taken into account to determine the reset pulse width:

• VDD rise time,

• Oscillator startup time.

To determine the capacitor value to implement, the highest value of these 2 parameters has to be chosen. Table 1 gives some capacitor values examples for a minimum R 50 KΩ and different oscillator startup and VDD rise times.

4301D–8051–02/08

RST

Table 1. Minimum Reset Capacitor Value for a 50 kΩ Pull-down Resistor

RST

VSS

To CPU Core and Peripherals

VDD

From WDT Reset Source

VSS

VDD

RST

To Other On-board

Circuitry

(1)

Oscillator

VDD Rise Time

Start-Up Time

1 ms 10 ms 100 ms

5 ms 820 nF 1.2 µF 12 µF

20 ms 2.7 µF 3.9 µF 12 µF

Note: These values assume VDD starts from 0V to the nominal value. If the time between 2

on/off sequences is too fast, the power-supply de-coupling capacitors may not be fully discharged, leading to a bad reset sequence.

Warm Reset To achieve a valid reset, the reset signal must be maintained for at least 2 machine

cycles (24 oscillator clock periods) while the oscillator is running. The number of clock periods is mode independent (X2 or X1).

Watchdog Reset As detailed in Section “Hardware Watchdog Timer”, page 102, the WDT generates a 96-

clock period pulse on the RST pin. In order to properly propagate this pulse to the rest of the application in case of external capacitor or power-supply supervisor circuit, a 1 kΩ resistor must be added as shown Figure 24.

Figure 24. Reset Circuitry for WDT Reset-out Usage

AT89C51IC2

4301D–8051–02/08

AT89C51IC2

Reset Recommendation to Prevent Flash Corruption

An example of bad initialization situation may occur in an instance where the bit ENBOOT in AUXR1 register is initialized from the hardware bit BLJB upon reset. Since this bit allows mapping of the bootloader in the code area, a reset failure can be critical.

If one wants the ENBOOT cleared in order to unmap the boot from the code area (yet due to a bad reset) the bit ENBOOT in SFRs may be set. If the value of Program Counter is accidently in the range of the boot memory addresses then a Flash access (write or erase) may corrupt the Flash on-chip memory.

It is recommended to use an external reset circuitry featuring power supply monitoring to prevent system malfunction during periods of insufficient power supply voltage (power supply failure, power supply switched off).

Idle Mode An instruction that sets PCON.0 indicates that it is the last instruction to be executed

before going into Idle mode. In Idle mode, the internal clock signal is gated off to the CPU, but not to the interrupt, Timer, and Serial Port functions. The CPU status is preserved in its entirety: the Stack Pointer, Program Counter, Program Status Word, Accumulator and all other registers maintain their data during idle. The port pins hold the logical states they had at the time Idle was activated. ALE and PSEN hold at logic high level.

There are two ways to terminate the Idle mode. Activation of any enabled interrupt will cause PCON.0 to be cleared by hardware, terminating the Idle mode. The interrupt will be serviced, and following RETI the next instruction to be executed will be the one following the instruction that put the device into idle.

The flag bits GF0 and GF1 can be used to give an indication if an interrupt occurred during normal operation or during idle. For example, an instruction that activates idle can also set one or both flag bits. When idle is terminated by an interrupt, the interrupt service routine can examine the flag bits.

The other way of terminating the Idle mode is with a hardware reset. Since the clock oscillator is still running, the hardware reset needs to be held active for only two machine cycles (24 oscillator periods) to complete the reset.

Power-down Mode To save maximum power, a Power-down mode can be invoked by software (see PCON

In Power-down mode, the oscillator is stopped and the instruction that invoked Powerdown mode is the last instruction executed. The internal RAM and SFRs retain their value until the Power-down mode is terminated. VCC can be lowered to save further power. Either a hardware reset or an external interrupt can cause an exit from Powerdown. To properly terminate Power-down, the reset or external interrupt should not be executed before VCC is restored to its normal operating level and must be held active long enough for the oscillator to restart and stabilize.

Only external interrupts INT0, INT1 and Keyboard Interrupts are useful to exit from Power-down. For that, interrupt must be enabled and configured as level or edge sensitive interrupt input. When Keyboard Interrupt occurs after a power down mode, 1024 clocks are necessary to exit to power down mode and enter in operating mode.

Holding the pin low restarts the oscillator but bringing the pin high completes the exit as detailed in Figure 25. When both interrupts are enabled, the oscillator restarts as soon as one of the two inputs is held low and power down exit will be completed when the first input will be released. In this case, the higher priority interrupt service routine is executed. Once the interrupt is serviced, the next instruction to be executed after RETI will be the one following the instruction that puts the AT89C51IC2 into Power-down mode.

4301D–8051–02/08

Figure 25. Power-down Exit Waveform

INT1

INT0

XTALA

Power-down Phase Oscillator Restart Phase Active PhaseActive Phase

or XTALB

Exit from Power-down by reset redefines all the SFRs, exit from Power-down by external interrupt does no affect the SFRs.

Exit from Power-down by either reset or external interrupt does not affect the internal RAM content.

Note: If idle mode is activated with Power-down mode (IDL and PD bits set), the exit sequence

Table 55 shows the state of ports during idle and power-down modes.

Table 55. State of Ports

Mode Program Memory ALE PSEN PORT0 PORT1 PORT2 PORT3

Idle Internal 1 1 Port Data

is unchanged, when execution is vectored to interrupt, PD and IDL bits are cleared and idle mode is not entered.

(1)

Port Data Port Data Port Data

Idle External 1 1 Floating Port Data Address Port Data

Power Down Internal 0 0 Port Data

Power Down External 0 0 Floating Port Data Port Data Port Data

(1)

Port Data Port Data Port Data

Port 0 can force a 0 level. A "one" will leave port floating.

AT89C51IC2

4301D–8051–02/08

AT89C51IC2

Slave 1

MISO

MOSI

SCK

MISO MOSI SCK SS

PORT

0 1 2 3

Slave 3

MISO

MOSI

SCK

Slave 4

MISO

MOSI

SCK

Slave 2

MISO

MOSI

SCK

VDD

Master

Serial Port Interface (SPI)

The Serial Peripheral Interface Module (SPI) allows full-duplex, synchronous, serial communication between the MCU and peripheral devices, including other MCUs.

Features Features of the SPI Module include the following:

• Full-duplex, three-wire synchronous transfers

• Master or Slave operation

• Eight programmable Master clock rates

• Serial clock with programmable polarity and phase

• Master Mode fault error flag with MCU interrupt capability

• Write collision flag protection

Signal Description Figure 26 shows a typical SPI bus configuration using one Master controller and many

Slave peripherals. The bus is made of three wires connecting all the devices.

Figure 26. SPI Master/Slaves Interconnection

The Master device selects the individual Slave devices by using four pins of a parallel

pins of the Slave devices.

Master Output Slave Input (MOSI)

port to control the four SS

This 1-bit signal is directly connected between the Master Device and a Slave Device. The MOSI line is used to transfer data in series from the Master to the Slave. Therefore, it is an output signal from the Master, and an input signal to a Slave. A Byte (8-bit word) is transmitted most significant bit (MSB) first, least significant bit (LSB) last.

Master Input Slave Output (MISO)

This 1-bit signal is directly connected between the Slave Device and a Master Device. The MISO line is used to transfer data in series from the Slave to the Master. Therefore, it is an output signal from the Slave, and an input signal to the Master. A Byte (8-bit word) is transmitted most significant bit (MSB) first, least significant bit (LSB) last.

SPI Serial Clock (SCK) This signal is used to synchronize the data movement both in and out of the devices

Slave Select (SS

) Each Slave peripheral is selected by one Slave Select pin (SS). This signal must stay

through their MOSI and MISO lines. It is driven by the Master for eight clock cycles which allows to exchange one Byte on the serial lines.

low for any message for a Slave. It is obvious that only one Master (SS high level) can

4301D–8051–02/08

drive the network. The Master may select each Slave device by software through port pins (Figure 27). To prevent bus conflicts on the MISO line, only one slave should be selected at a time by the Master for a transmission.

In a Master configuration, the SS line can be used in conjunction with the MODF flag in the SPI Status register (SPSTA) to prevent multiple masters from driving MOSI and SCK (see Error conditions).

A high level on the SS pin puts the MISO line of a Slave SPI in a high-impedance state.

The SS

pin could be used as a general-purpose if the following conditions are met:

• The device is configured as a Master and the SSDIS control bit in SPCON is set.

This kind of configuration can be found when only one Master is driving the network and there is no way that the SS pin could be pulled low. Therefore, the MODF flag in the SPSTA will never be set

• The Device is configured as a Slave with CPHA and SSDIS control bits set

(1)

(2)

. This kind of configuration can happen when the system comprises one Master and one Slave only. Therefore, the device should always be selected and there is no reason that the Master uses the SS pin to select the communicating Slave device.

Note: 1. Clearing SSDIS control bit does not clear MODF.

2. Special care should be taken not to set SSDIS control bit when CPHA = ’0’ because in this mode, the SS is used to start the transmission.

Baud Rate In Master mode, the baud rate can be selected from a baud rate generator which is con-

trolled by three bits in the SPCON register: SPR2, SPR1 and SPR0.The Master clock is selected from one of seven clock rates resulting from the division of the internal clock by 2, 4, 8, 16, 32, 64 or 128.

Table 56 gives the different clock rates selected by SPR2:SPR1:SPR0.

Table 56. SPI Master Baud Rate Selection

SPR2 SPR1 SPR0 Clock Rate Baud Rate Divisor (BD)

0 0 0 F

0 0 1 F

0 1 0 F

0 1 1 F

1 0 0 F

1 0 1 F

1 1 0 F

1 1 1 Don’t Use No BRG

CLK PERIPH

/2 2

/4 4

/8 8

/16 16

/32 32

/64 64

/128 128

AT89C51IC2

4301D–8051–02/08

Functional Description Figure 27 shows a detailed structure of the SPI Module.

Shift Register

234567

Internal Bus

Pin Control Logic

MISO

MOSI

SCK

Clock Logic

Clock Divider

Clock Select

/64

/128

SPI Interrupt Request

8-bit bus

1-bit signal

FCLK PERIPH

/32

/16

Receive Data Register

SPDAT

SPI Control

SPSTA

CPHA

SPR0

SPR1

CPOLMSTRSSDISSPEN

SPR2

SPCON

WCOL MODFSPIF

- - - - -

Figure 27. SPI Module Block Diagram

AT89C51IC2

Operating Modes The Serial Peripheral Interface can be configured in one of the two modes: Master

mode or Slave mode. The configuration and initialization of the SPI Module is made through one register:

• The Serial Peripheral Control register (SPCON)

Once the SPI is configured, the data exchange is made using:

• SPCON

• The Serial Peripheral STAtus register (SPSTA)

• The Serial Peripheral DATa register (SPDAT)

During an SPI transmission, data is simultaneously transmitted (shifted out serially) and received (shifted in serially). A serial clock line (SCK) synchronizes shifting and sampling on the two serial data lines (MOSI and MISO). A Slave Select line (SS individual selection of a Slave SPI device; Slave devices that are not selected do not interfere with SPI bus activities.

When the Master device transmits data to the Slave device via the MOSI line, the Slave

4301D–8051–02/08

device responds by sending data to the Master device via the MISO line. This implies full-duplex transmission with both data out and data in synchronized with the same clock (Figure 28).

) allows

Figure 28. Full-Duplex Master-Slave Interconnection

8-bit Shift register

SPI

Clock Generator

Master MCU

8-bit Shift register

MISOMISO

MOSI

SCK SCK

VSS

VDD

SSSS

Slave MCU

Master Mode The SPI operates in Master mode when the Master bit, MSTR

is set. Only one Master SPI device can initiate transmissions. Software begins the transmission from a Master SPI Module by writing to the Serial Peripheral Data Register (SPDAT). If the shift register is empty, the Byte is immediately transferred to the shift register. The Byte begins shifting out on MOSI pin under the control of the serial clock, SCK. Simultaneously, another Byte shifts in from the Slave on the Master’s MISO pin. The transmission ends when the Serial Peripheral transfer data flag, SPIF, in SPSTA becomes set. At the same time that SPIF becomes set, the received Byte from the Slave is transferred to the receive data register in SPDAT. Software clears SPIF by reading the Serial Peripheral Status register (SPSTA) with the SPIF bit set, and then reading the SPDAT.

(1)

, in the SPCON register

Slave Mode The SPI operates in Slave mode when the Master bit, MSTR

(2)

, in the SPCON register is cleared. Before a data transmission occurs, the Slave Select pin, SS, of the Slave device must be set to ’0’. SS must remain low until the transmission is complete.

In a Slave SPI Module, data enters the shift register under the control of the SCK from the Master SPI Module. After a Byte enters the shift register, it is immediately transferred to the receive data register in SPDAT, and the SPIF bit is set. To prevent an overflow condition, Slave software must then read the SPDAT before another Byte

(3)

enters the shift register

. A Slave SPI must complete the write to the SPDAT (shift register) at least one bus cycle before the Master SPI starts a transmission. If the write to the data register is late, the SPI transmits the data already in the shift register from the previous transmission. The maximum SCK frequency allowed in slave mode is

/4.

CLK PERIPH

Transmission Formats Software can select any of four combinations of serial clock (SCK) phase and polarity

using two bits in the SPCON: the Clock Polarity (CPOL

( 4)

) and the Clock Phase (CPHA4). CPOL defines the default SCK line level in idle state. It has no significant effect on the transmission format. CPHA defines the edges on which the input data are sampled and the edges on which the output data are shifted (Figure 29 and Figure 30). The clock phase and polarity should be identical for the Master SPI device and the communicating Slave device.

AT89C51IC2

1. The SPI Module should be configured as a Master before it is enabled (SPEN set). Also,

the Master SPI should be configured before the Slave SPI.

2. The SPI Module should be configured as a Slave before it is enabled (SPEN set).

3. The maximum frequency of the SCK for an SPI configured as a Slave is the bus clock

speed.

4. Before writing to the CPOL and CPHA bits, the SPI should be disabled (SPEN = ’0’).

4301D–8051–02/08

Figure 29. Data Transmission Format (CPHA = 0)

MSB bit6 bit5 bit4 bit3 bit2 bit1 LSB

bit6 bit5 bit4 bit3 bit2 bit1MSB LSB

1 32 4 5 6 7 8

Capture Point

SS (to Slave)

MISO (from Slave)

MOSI (from Master)

SCK (CPOL = 1)

SCK (CPOL = 0)

SPEN (Internal)

SCK Cycle Number

MSB bit6 bit5 bit4 bit3 bit2 bit1 LSB

bit6 bit5 bit4 bit3 bit2 bit1

MSB LSB

1 32 4 5 6 7 8

Capture Point

SS (to Slave)

MISO (from Slave)

MOSI (from Master)

SCK (CPOL = 1)

SCK (CPOL = 0)

SPEN (Internal)

SCK Cycle Number

Byte 1 Byte 2

Byte 3

MISO/MOSI

Master SS

Slave SS

(CPHA = 1)

Slave SS

(CPHA = 0)

Figure 30. Data Transmission Format (CPHA = 1)

AT89C51IC2

Figure 31. CPHA/SS

4301D–8051–02/08

Timing

As shown in Figure 29, the first SCK edge is the MSB capture strobe. Therefore, the Slave must begin driving its data before the first SCK edge, and a falling edge on the SS pin is used to start the transmission. The SS pin must be toggled high and then low between each Byte transmitted (Figure 31).

Figure 30 shows an SPI transmission in which CPHA is ’1’. In this case, the Master begins driving its MOSI pin on the first SCK edge. Therefore, the Slave uses the first SCK edge as a start transmission signal. The SS pin can remain low between transmissions (Figure 31). This format may be preffered in systems having only one Master and only one Slave driving the MISO data line.

Error Conditions The following flags in the SPSTA signal SPI error conditions:

Mode Fault (MODF) Mode Fault error in Master mode SPI indicates that the level on the Slave Select (SS)

pin is inconsistent with the actual mode of the device. MODF is set to warn that there may be a multi-master conflict for system control. In this case, the SPI system is affected in the following ways:

• An SPI receiver/error CPU interrupt request is generated

• The SPEN bit in SPCON is cleared. This disables the SPI

• The MSTR bit in SPCON is cleared

When SS

Disable (SSDIS) bit in the SPCON register is cleared, the MODF flag is set

when the SS signal becomes ’0’.

However, as stated before, for a system with one Master, if the SS pin of the Master device is pulled low, there is no way that another Master attempts to drive the network. In this case, to prevent the MODF flag from being set, software can set the SSDIS bit in the SPCON register and therefore making the SS pin as a general-purpose I/O pin.

Clearing the MODF bit is accomplished by a read of SPSTA register with MODF bit set, followed by a write to the SPCON register. SPEN Control bit may be restored to its original set state after the MODF bit has been cleared.

Write Collision (WCOL) A Write Collision (WCOL) flag in the SPSTA is set when a write to the SPDAT register is

done during a transmit sequence.

WCOL does not cause an interruption, and the transfer continues uninterrupted.

Clearing the WCOL bit is done through a software sequence of an access to SPSTA and an access to SPDAT.

Overrun Condition An overrun condition occurs when the Master device tries to send several data Bytes

and the Slave devise has not cleared the SPIF bit issuing from the previous data Byte transmitted. In this case, the receiver buffer contains the Byte sent after the SPIF bit was last cleared. A read of the SPDAT returns this Byte. All others Bytes are lost.

This condition is not detected by the SPI peripheral.

SS Error Flag (SSERR) A Synchronous Serial Slave Error occurs when SS

goes high before the end of a received data in slave mode. SSERR does not cause in interruption, this bit is cleared by writing 0 to SPEN bit (reset of the SPI state machine).

Interrupts Two SPI status flags can generate a CPU interrupt requests:

Table 57. SPI Interrupts

Flag Request

SPIF (SP data transfer) SPI Transmitter Interrupt request

MODF (Mode Fault) SPI Receiver/Error Interrupt Request (if SSDIS = ’0’)

Serial Peripheral data transfer flag, SPIF: This bit is set by hardware when a transfer has been completed. SPIF bit generates transmitter CPU interrupt requests.

Mode Fault flag, MODF: This bit becomes set to indicate that the level on the SS is inconsistent with the mode of the SPI. MODF with SSDIS reset, generates receiver/error CPU interrupt requests. When SSDIS is set, no MODF interrupt request is generated.

Figure 32 gives a logical view of the above statements.

AT89C51IC2

4301D–8051–02/08

Figure 32. SPI Interrupt Requests Generation

SSDIS

MODF

CPU Interrupt Request

SPI Receiver/error

CPU Interrupt Request

SPI Transmitter

SPI

CPU Interrupt Request

SPIF

AT89C51IC2

Registers

Serial Peripheral Control Register (SPCON)

There are three registers in the Module that provide control, status and data storage functions. These registers are describes in the following paragraphs.

• The Serial Peripheral Control Register does the following:

• Selects one of the Master clock rates

• Configure the SPI Module as Master or Slave

• Selects serial clock polarity and phase

• Enables the SPI Module

• Frees the SS pin for a general-purpose

Table 58 describes this register and explains the use of each bit

Table 58. SPCON Register

SPCON - Serial Peripheral Control Register (0C3H)

7 6 5 4 3 2 1 0

SPR2 SPEN SSDIS MSTR CPOL CPHA SPR1 SPR0

Bit Number Bit Mnemonic Description

7 SPR2

6 SPEN

Serial Peripheral Rate 2

Bit with SPR1 and SPR0 define the clock rate.

Serial Peripheral Enable

Cleared to disable the SPI interface.

Set to enable the SPI interface.

4301D–8051–02/08

5 SSDIS

4 MSTR

3 CPOL

2 CPHA

SS Disable

Cleared to enable SS in both Master and Slave modes.

Set to disable SS in both Master and Slave modes. In Slave mode, this bit has no effect if CPHA =’0’. When SSDIS is set, no MODF interrupt request is generated

Serial Peripheral Master

Cleared to configure the SPI as a Slave.

Set to configure the SPI as a Master.

Clock Polarity

Cleared to have the SCK set to ’0’ in idle state.

Set to have the SCK set to ’1’ in idle low.

Clock Phase

Cleared to have the data sampled when the SCK leaves the idle state (see CPOL).

Set to have the data sampled when the SCK returns to idle state (see CPOL).

Bit Number Bit Mnemonic Description

SPR2 SPR1 SPR0 Serial Peripheral Rate

0 SPR0

SPR1

0 0 0 F

0 0 1 F

0 1 0 F

0 1 1 F

1 0 0 F

1 0 1 F

1 1 0 F

1 1 1 Invalid

Reset Value = 0001 0100b

Not bit addressable

CLK PERIPH

/16

/32

/64

/128

Serial Peripheral Status Register (SPSTA)

The Serial Peripheral Status Register contains flags to signal the following conditions:

• Data transfer complete

• Write collision

• Inconsistent logic level on SS pin (mode fault error)

Table 59 describes the SPSTA register and explains the use of every bit in the register.

Table 59. SPSTA Register

SPSTA - Serial Peripheral Status and Control register (0C4H)

7 6 5 4 3 2 1 0

SPIF WCOL SSERR MODF - - - -

Bit

Number

7 SPIF

6 WCOL

Bit

Mnemonic Description

Serial Peripheral Data Transfer Flag

Cleared by hardware to indicate data transfer is in progress or has been approved by a clearing sequence.

Set by hardware to indicate that the data transfer has been completed.

Write Collision Flag

Cleared by hardware to indicate that no collision has occurred or has been approved by a clearing sequence.

Set by hardware to indicate that a collision has been detected.

AT89C51IC2

5 SSERR

4 MODF

3 -

2 -

Synchronous Serial Slave Error Flag

Set by hardware when SS is deasserted before the end of a received data.

Cleared by disabling the SPI (clearing SPEN bit in SPCON).

Mode Fault

Cleared by hardware to indicate that the SS pin is at appropriate logic level, or has been approved by a clearing sequence.

Set by hardware to indicate that the SS pin is at inappropriate logic level.

Reserved

The value read from this bit is indeterminate. Do not set this bit

Reserved

The value read from this bit is indeterminate. Do not set this bit.

4301D–8051–02/08

AT89C51IC2

Serial Peripheral DATa Register (SPDAT)

Bit

Number

1 -

0 -

Bit

Mnemonic Description

Reserved

The value read from this bit is indeterminate. Do not set this bit.

Reserved

The value read from this bit is indeterminate. Do not set this bit.

Reset Value = 00X0 XXXXb

Not Bit addressable

The Serial Peripheral Data Register (Table 60) is a read/write buffer for the receive data register. A write to SPDAT places data directly into the shift register. No transmit buffer is available in this model.

A Read of the SPDAT returns the value located in the receive buffer and not the content of the shift register.

Table 60. SPDAT Register

SPDAT - Serial Peripheral Data Register (0C5H)

7 6 5 4 3 2 1 0

R7 R6 R5 R4 R3 R2 R1 R0

Reset Value = Indeterminate

R7:R0: Receive data bits

SPCON, SPSTA and SPDAT registers may be read and written at any time while there is no on-going exchange. However, special care should be taken when writing to them while a transmission is on-going:

• Do not change SPR2, SPR1 and SPR0

• Do not change CPHA and CPOL

• Do not change MSTR

• Clearing SPEN would immediately disable the peripheral

• Writing to the SPDAT will cause an overflow.

4301D–8051–02/08

Keyboard Interface The AT89C51IC2 implements a keyboard interface allowing the connection of a

P1:x

KBE.x

KBF.x

KBLS.x

Vcc

Internal Pullup

P1.0

Keyboard Interface Interrupt Request

KBD

IEN1

Input Circuitry

P1.1 Input Circuitry

P1.2 Input Circuitry

P1.3 Input Circuitry

P1.4 Input Circuitry

P1.5 Input Circuitry

P1.6 Input Circuitry

P1.7 Input Circuitry

KBDIT

8 x n matrix keyboard. It is based on 8 inputs with programmable interrupt capability on both high or low level. These inputs are available as alternate function of P1 and allow to exit from idle and power down modes.

The keyboard interface interfaces with the C51 core through 3 special function registers: KBLS, the Keyboard Level Selection register (Table 63), KBE, The Keyboard interrupt Enable register (Table 62), and KBF, the Keyboard Flag register (Table 61).

Interrupt The keyboard inputs are considered as 8 independent interrupt sources sharing the

same interrupt vector. An interrupt enable bit (KBD in IEN1) allows global enable or disable of the keyboard interrupt (see Figure 33). As detailed in Figure 34 each keyboard input has the capability to detect a programmable level according to KBLS.x bit value. Level detection is then reported in interrupt flags KBF.x that can be masked by software using KBE.x bits. This structure allow keyboard arrangement from 1 by n to 8 by n matrix and allow usage of P1 inputs for other purpose.

Figure 33. Keyboard Interface Block Diagram

Figure 34. Keyboard Input Circuitry

Power Reduction Mode P1 inputs allow exit from idle and power down modes as detailed in Section “Power

Management”, page 67.

AT89C51IC2

4301D–8051–02/08

Registers Table 61. KBF Register

KBF-Keyboard Flag Register (9Eh)

7 6 5 4 3 2 1 0

KBF7 KBF6 KBF5 KBF4 KBF3 KBF2 KBF1 KBF0

AT89C51IC2

Bit

Number

7 KBF7

6 KBF6

5 KBF5

4 KBF4

3 KBF3

2 KBF2

Bit

Mnemonic Description

Keyboard line 7 flag

Set by hardware when the Port line 7 detects a programmed level. It generates a Keyboard interrupt request if the KBKBIE.7 bit in KBIE register is set. Must be cleared by software.

Keyboard line 6 flag

Set by hardware when the Port line 6 detects a programmed level. It generates a Keyboard interrupt request if the KBIE.6 bit in KBIE register is set. Must be cleared by software.

Keyboard line 5 flag

Set by hardware when the Port line 5 detects a programmed level. It generates a Keyboard interrupt request if the KBIE.5 bit in KBIE register is set. Must be cleared by software.

Keyboard line 4 flag

Set by hardware when the Port line 4 detects a programmed level. It generates a Keyboard interrupt request if the KBIE.4 bit in KBIE register is set. Must be cleared by software.

Keyboard line 3 flag

Set by hardware when the Port line 3 detects a programmed level. It generates a Keyboard interrupt request if the KBIE.3 bit in KBIE register is set. Must be cleared by software.

Keyboard line 2 flag

Set by hardware when the Port line 2 detects a programmed level. It generates a Keyboard interrupt request if the KBIE.2 bit in KBIE register is set. Must be cleared by software.

4301D–8051–02/08

Keyboard line 1 flag

1 KBF1

0 KBF0

Set by hardware when the Port line 1 detects a programmed level. It generates a Keyboard interrupt request if the KBIE.1 bit in KBIE register is set. Must be cleared by software.

Keyboard line 0 flag

Set by hardware when the Port line 0 detects a programmed level. It generates a Keyboard interrupt request if the KBIE.0 bit in KBIE register is set. Must be cleared by software.

Reset Value= 0000 0000b

This register is read only access, all flags are automatically cleared by reading the register.

Table 62. KBE Register

KBE-Keyboard Input Enable Register (9Dh)

7 6 5 4 3 2 1 0

KBE7 KBE6 KBE5 KBE4 KBE3 KBE2 KBE1 KBE0

Bit

Number

7 KBE7

6 KBE6

5 KBE5

4 KBE4

3 KBE3

2 KBE2

1 KBE1

Bit

Mnemonic Description

Keyboard line 7 Enable bit

Cleared to enable standard I/O pin. Set to enable KBF.7 bit in KBF register to generate an interrupt request.

Keyboard line 6 Enable bit

Cleared to enable standard I/O pin. Set to enable KBF.6 bit in KBF register to generate an interrupt request.

Keyboard line 5 Enable bit

Cleared to enable standard I/O pin. Set to enable KBF.5 bit in KBF register to generate an interrupt request.

Keyboard line 4 Enable bit

Cleared to enable standard I/O pin. Set to enable KBF.4 bit in KBF register to generate an interrupt request.

Keyboard line 3 Enable bit

Cleared to enable standard I/O pin. Set to enable KBF.3 bit in KBF register to generate an interrupt request.

Keyboard line 2 Enable bit

Cleared to enable standard I/O pin. Set to enable KBF.2 bit in KBF register to generate an interrupt request.

Keyboard line 1 Enable bit

Cleared to enable standard I/O pin. Set to enable KBF.1 bit in KBF register to generate an interrupt request.

0 KBE0

Keyboard line 0 Enable bit

Cleared to enable standard I/O pin. Set to enable KBF.0 bit in KBF register to generate an interrupt request.

Reset Value= 0000 0000b

AT89C51IC2

4301D–8051–02/08

AT89C51IC2

Table 63. KBLS Register

KBLS-Keyboard Level Selector Register (9Ch)

7 6 5 4 3 2 1 0

KBLS7 KBLS6 KBLS5 KBLS4 KBLS3 KBLS2 KBLS1 KBLS0

Bit

Number

7 KBLS7

6 KBLS6

5 KBLS5

4 KBLS4

3 KBLS3

2 KBLS2

1 KBLS1

Bit

Mnemonic Description

Keyboard line 7 Level Selection bit

Cleared to enable a low level detection on Port line 7. Set to enable a high level detection on Port line 7.

Keyboard line 6 Level Selection bit

Cleared to enable a low level detection on Port line 6. Set to enable a high level detection on Port line 6.

Keyboard line 5 Level Selection bit

Cleared to enable a low level detection on Port line 5. Set to enable a high level detection on Port line 5.

Keyboard line 4 Level Selection bit

Cleared to enable a low level detection on Port line 4. Set to enable a high level detection on Port line 4.

Keyboard line 3 Level Selection bit

Cleared to enable a low level detection on Port line 3. Set to enable a high level detection on Port line 3.

Keyboard line 2 Level Selection bit

Cleared to enable a low level detection on Port line 2. Set to enable a high level detection on Port line 2.

Keyboard line 1 Level Selection bit

Cleared to enable a low level detection on Port line 1. Set to enable a high level detection on Port line 1.

0 KBLS0

Keyboard line 0 Level Selection bit

Cleared to enable a low level detection on Port line 0. Set to enable a high level detection on Port line 0.

Reset Value= 0000 0000b

4301D–8051–02/08

2-wire Interface (TWI) This section describes the 2-wire interface. In the rest of the section SSLC means Two-

SCL

SDA

device2device1 deviceNdevice3

...

wire. The 2-wire bus is a bi-directional 2-wire serial communication standard. It is designed primarily for simple but efficient integrated circuit (IC) control. The system is comprised of two lines, SCL (Serial Clock) and SDA (Serial Data) that carry information between the ICs connected to them. The serial data transfer is limited to 400Kbit/s in standard mode. Various communication configuration can be designed using this bus. Figure 35 shows a typical 2-wire bus configuration. All the devices connected to the bus can be master and slave.

Figure 35. 2-wire Bus Configuration

AT89C51IC2

4301D–8051–02/08

Figure 36. Block Diagram

Address Register

Comparator

Timing & Control logic

Arbitration & Sink Logic

Serial clock generator

Shift Register

Control Register

Status Register

Status Decoder

Input Filter

Output Stage

Input Filter

Output Stage

ACK

Status Bits

Internal Bus

Timer 1 overflow

CLK PERIPH

Interrupt

SDA

SCL

SSADR

SSCON

SSDAT

SSCS

PI2.1

PI2.0

AT89C51IC2

4301D–8051–02/08

Description The CPU interfaces to the 2-wire logic via the following four 8-bit special function regis-

SDA

SCL

start condition

MSB

1 2

8 9

ACK

acknowledgement

signal from receiver

acknowledgement

signal from receiver

1 2 3-8 9

ACK

stop condition

clock line held low

while interrupts are serviced

ters: the Synchronous Serial Control register (SSCON; Table 73), the Synchronous Serial Data register (SSDAT; Table 74), the Synchronous Serial Control and Status register (SSCS; Table 75) and the Synchronous Serial Address register (SSADR Table 78).

SSCON is used to enable SSLC, to program the bit rate (see Table 66), to enable slave modes, to acknowledge or not a received data, to send a START or a STOP condition on the 2-wire bus, and to acknowledge a serial interrupt. A hardware reset disables SSLC.

In write mode, SSCS is used to select the 2-wire interface and to select the bit rate source. In read mode, SSCS contains a status code which reflects the status of the 2wire logic and the 2-wire bus. The three least significant bits are always zero. The five most significant bits contains the status code. There are 26 possible status codes. When SSCS contains F8h, no relevant state information is available and no serial interrupt is requested. A valid status code is available in SSCS one machine cycle after SI is set by hardware and is still present one machine cycle after SI has been reset by software. Table 68.to Table 72. give the status for the master modes and miscellaneous states.

SSDAT contains a byte of serial data to be transmitted or a byte which has just been received. It is addressable while it is not in process of shifting a byte. This occurs when 2-wire logic is in a defined state and the serial interrupt flag is set. Data in SSDAT remains stable as long as SI is set. While data is being shifted out, data on the bus is simultaneously shifted in; SSDAT always contains the last byte present on the bus.

SSADR may be loaded with the 7-bit slave address (7 most significant bits) to which SSLC will respond when programmed as a slave transmitter or receiver. The LSB is used to enable general call address (00h) recognition.

Figure 37 shows how a data transfer is accomplished on the 2-wire bus.

Figure 37. Complete data transfer on 2-wire bus

The four operating modes are:

• Master Transmitter

• Master Receiver

• Slave transmitter

• Slave receiver

Data transfer in each mode of operation is shown in Table 68 to Table 72 and Figure 38. to Figure 41.. These figures contain the following abbreviations:

AT89C51IC2

S : START condition

4301D–8051–02/08

AT89C51IC2

R : Read bit (high level at SDA)

W: Write bit (low level at SDA)

A: Acknowledge bit (low level at SDA)

A: Not acknowledge bit (high level at SDA)

Data: 8-bit data byte

P : STOP condition

In Figure 38 to Figure 41, circles are used to indicate when the serial interrupt flag is set. The numbers in the circles show the status code held in SSCS. At these points, a service routine must be executed to continue or complete the serial transfer. These service routines are not critical since the serial transfer is suspended until the serial interrupt flag is cleared by software.

When the serial interrupt routine is entered, the status code in SSCS is used to branch to the appropriate service routine. For each status code, the required software action and details of the following serial transfer are given in Table 68 to Table 72.

Master Transmitter Mode In the master transmitter mode, a number of data bytes are transmitted to a slave

receiver (Figure 38). Before the master transmitter mode can be entered, SSCON must be initialised as follows:

Table 64. SSCON Initialization

CR2 SSIE STA STO SI AA CR1 CR0

bit rate 1 0 0 0 X bit rate bit rate

CR0, CR1 and CR2 define the internal serial bit rate if external bit rate generator is not used. SSIE must be set to enable SSLC. STA, STO and SI must be cleared.

The master transmitter mode may now be entered by setting the STA bit. The 2-wire logic will now test the 2-wire bus and generate a START condition as soon as the bus becomes free. When a START condition is transmitted, the serial interrupt flag (SI bit in SSCON) is set, and the status code in SSCS will be 08h. This status must be used to vector to an interrupt routine that loads SSDAT with the slave address and the data direction bit (SLA+W).

When the slave address and the direction bit have been transmitted and an acknowledgement bit has been received, SI is set again and a number of status code in SSCS are possible. There are 18h, 20h or 38h for the master mode and also 68h, 78h or B0h if the slave mode was enabled (AA=logic 1). The appropriate action to be taken for each of these status code is detailed in Table 68. This scheme is repeated until a STOP condition is transmitted.

SSIE, CR2, CR1 and CR0 are not affected by the serial transfer and are referred to Table 7 to Table 11. After a repeated START condition (state 10h) SSLC

may switch to

the master receiver mode by loading SSDAT with SLA+R.

Master Receiver Mode In the master receiver mode, a number of data bytes are received from a slave transmit-

ter (Figure 39). The transfer is initialized as in the master transmitter mode. When the START condition has been transmitted, the interrupt routine must load SSDAT with the 7-bit slave address and the data direction bit (SLA+R). The serial interrupt flag SI must then be cleared before the serial transfer can continue.

4301D–8051–02/08

When the slave address and the direction bit have been transmitted and an acknowledgement bit has been received, the serial interrupt flag is set again and a number of status code in SSCS are possible. There are 40h, 48h or 38h for the master mode and also 68h, 78h or B0h if the slave mode was enabled (AA=logic 1). The appropriate action to be taken for each of these status code is detailed in Table 69. This scheme is repeated until a STOP condition is transmitted.

SSIE, CR2, CR1 and CR0 are not affected by the serial transfer and are referred to Table 7 to Table 11. After a repeated START condition (state 10h) SSLC may switch to the master transmitter mode by loading SSDAT with SLA+W.

Slave Receiver Mode In the slave receiver mode, a number of data bytes are received from a master transmit-

ter (Figure 40). To initiate the slave receiver mode, SSADR and SSCON must be loaded as follows:

Table 65. SSADR: slave receiver mode initialization

A6 A5 A4 A3 A2 A1 A0 GC

own slave address

The upper 7 bits are the address to which SSLC will respond when addressed by a master. If the LSB (GC) is set SSLC will respond to the general call address (00h); otherwise it ignores the general call address.

Table 66. SSCON: slave receiver mode initialization

CR2 SSIE STA STO SI AA CR1 CR0

bit rate 1 0 0 0 1 bit rate bit rate

CR0, CR1 and CR2 have no effect in the slave mode. SSIE must be set to enable SSLC. The AA bit must be set to enable the own slave address or the general call address acknowledgement. STA, STO and SI must be cleared.

When SSADR and SSCON have been initialised, SSLC waits until it is addressed by its own slave address followed by the data direction bit which must be at logic 0 (W) for SSLC to operate in the slave receiver mode. After its own slave address and the W bit have been received, the serial interrupt flag is set and a valid status code can be read from SSCS. This status code is used to vector to an interrupt service routine.The appropriate action to be taken for each of these status code is detailed in Table 70. The slave receiver mode may also be entered if arbitration is lost while SSLC is in the master mode (states 68h and 78h).

If the AA bit is reset during a transfer, SSLC will return a not acknowledge (logic 1) to SDA after the next received data byte. While AA is reset, SSLC does not respond to its own slave address. However, the 2-wire bus is still monitored and address recognition may be resume at any time by setting AA. This means that the AA bit may be used to temporarily isolate SSLC from the 2-wire bus.

Slave Transmitter Mode In the slave transmitter mode, a number of data bytes are transmitted to a master

receiver (Figure 41). Data transfer is initialized as in the slave receiver mode. When SSADR and SSCON have been initialized, SSLC waits until it is addressed by its own

AT89C51IC2

4301D–8051–02/08

AT89C51IC2

slave address followed by the data direction bit which must be at logic 1 (R) for SSLC to operate in the slave transmitter mode. After its own slave address and the R bit have been received, the serial interrupt flag is set and a valid status code can be read from SSCS. This status code is used to vector to an interrupt service routine. The appropriate action to be taken for each of these status code is detailed in Table 71. The slave transmitter mode may also be entered if arbitration is lost while SSLC is in the master mode.

If the AA bit is reset during a transfer, SSLC will transmit the last byte of the transfer and enter state C0h or C8h. SSLC is switched to the not addressed slave mode and will ignore the master receiver if it continues the transfer. Thus the master receiver receives all 1’s as serial data. While AA is reset, SSLC does not respond to its own slave address. However, the 2-wire bus is still monitored and address recognition may be resume at any time by setting AA. This means that the AA bit may be used to temporarily isolate SSLC from the 2-wire bus.

Miscellaneous States There are two SSCS codes that do not correspond to a define SSLC hardware state

(Table 72 ). These codes are discuss hereafter.

Status F8h indicates that no relevant information is available because the serial interrupt flag is not set yet. This occurs between other states and when SSLC is not involved in a serial transfer.

Status 00h indicates that a bus error has occurred during an SSLC serial transfer. A bus error is caused when a START or a STOP condition occurs at an illegal position in the format frame. Examples of such illegal positions happen during the serial transfer of an address byte, a data byte, or an acknowledge bit. When a bus error occurs, SI is set. To recover from a bus error, the STO flag must be set and SI must be cleared. This causes SSLC to enter the not addressed slave mode and to clear the STO flag (no other bits in SSCON are affected). The SDA and SCL lines are released and no STOP condition is transmitted.

Notes SSLC interfaces to the external 2-wire bus via two port pins: SCL (serial clock line) and

SDA (serial data line). To avoid low level asserting on these lines when SSLC is enabled, the output latches of SDA and SLC must be set to logic 1.

Table 67. Bit frequency configuration

Bit Frequency ( kHz)

CR2 CR1 CR0 F

0 0 0 47 62.5 256

0 0 1 53.5 71.5 224

0 1 0 62.5 83 192

0 1 1 75 100 160

1 0 0 - - Unused

1 0 1 100 133.3 120

1 1 0 200 266.6 60

1 1 1 0.5 <. < 62.5 0.67 <. < 83

= 12 MHz F

OSCA

= 16 MHz F

OSCA

divided by

OSCA

96 · (256 - reload valueTimer 1)

(reload value range: 0-254 in mode 2)

4301D–8051–02/08

Figure 38. Format and State in the Master Transmitter Mode

S SLA W A Data A P

08h 18h

28h

S SLA W

A P

10h

20h

30h

A or A

continues

38h38h

continues

68h

Other master

78h B0h To corresponding

states in slave mode

Successfull transmission to a slave receiver

Next transfer started with a repeated start condition

Not acknowledge received after the slave address

Not acknowledge received after a data

Arbitration lost in slave address or data byte

Arbitration lost and addressed as slave

byte

A or A

continues

Other master

Data A

From master to slave

From slave to master

Any number of data bytes and their associated acknowledge bits

This number (contained in SSCS) corresponds to a defined state of the 2-wire bus

AT89C51IC2

4301D–8051–02/08

Status

Code

SSSTA

08h

Status of the Twowire Bus and Twowire Hardware

A START condition has been transmitted

AT89C51IC2

Table 68. Status in master transmitter mode

Application software response

To SSCON

SSSTA SSSTO SSI SSAA

Write SLA+W X 0 0 X SLA+W will be transmitted.

Next Action Taken by Two-wire HardwareTo/From SSDAT

A repeated START

10h

condition has been transmitted

SLA+W has been

18h

transmitted; ACK has been received

SLA+W has been

20h

transmitted; NOT ACK has been received

Data byte has been

28h

transmitted; ACK has been received

Data byte has been

30h

transmitted; NOT ACK has been received

Write SLA+W

Write SLA+R

Write data byte

No SSDAT action

Write data byte

No SSDAT action

Write data byte

No SSDAT action

Write data byte

No SSDAT action

SLA+W will be transmitted.

SLA+R will be transmitted.

Logic will switch to master receiver mode

Data byte will be transmitted.

Repeated START will be transmitted.

STOP condition will be transmitted and SSSTO flag

will be reset.

STOP condition followed by a START condition will

be transmitted and SSSTO flag will be reset.

Data byte will be transmitted.

Repeated START will be transmitted.

STOP condition will be transmitted and SSSTO flag

will be reset.

STOP condition followed by a START condition will

be transmitted and SSSTO flag will be reset.

Data byte will be transmitted.

Repeated START will be transmitted.

STOP condition will be transmitted and SSSTO flag

will be reset.

STOP condition followed by a START condition will

be transmitted and SSSTO flag will be reset.

Data byte will be transmitted.

Repeated START will be transmitted.

STOP condition will be transmitted and SSSTO flag

will be reset.

STOP condition followed by a START condition will

be transmitted and SSSTO flag will be reset.

Arbitration lost in

38h

SLA+W or data bytes

4301D–8051–02/08

No SSDAT action

Two-wire bus will be released and not addressed

slave mode will be entered.

A START condition will be transmitted when the bus

becomes free.

Figure 39. Format and State in the Master Receiver Mode

S SLA R A

Data

08h

40h

58h

S SLA R

A P

10h

48h

A or A

continues

38h38h

continues

68h

Other master

78h B0h

To corresponding states in slave mode

Successfull transmission to a slave receiver

Next transfer started with a repeated start condition

Not acknowledge received after the slave address

Arbitration lost and addressed as slave

continues

Other master

From master to slave

From slave to master

Any number of data bytes and their associated acknowledge bits

This number (contained in SSCS) corresponds to a defined state of the 2-wire bus

Data

50h

Arbitration lost in slave address or acknowledge bit

Data A

AT89C51IC2

4301D–8051–02/08

Status

Code

SSSTA

08h

Status of the Twowire Bus and Twowire Hardware

A START condition has been transmitted

AT89C51IC2

Table 69. Status in master receiver mode

Application software response

To SSCON

SSSTA SSSTO SSI SSAA

Write SLA+R X 0 0 X SLA+R will be transmitted.

Next Action Taken by Two-wire HardwareTo/From SSDAT

A repeated START

10h

condition has been transmitted

Arbitration lost in

38h

SLA+R or NOT ACK bit

SLA+R has been

40h

transmitted; ACK has been received

SLA+R has been

48h

transmitted; NOT ACK has been received

Data byte has been

50h

received; ACK has been returned

Data byte has been

58h

received; NOT ACK has been returned

Write SLA+R

Write SLA+W

No SSDAT action

Read data byte

SLA+R will be transmitted.

SLA+W will be transmitted.

Logic will switch to master transmitter mode.

Two-wire bus will be released and not addressed

slave mode will be entered.

A START condition will be transmitted when the bus

becomes free.

01Data byte will be received and NOT ACK will be

returned.

Data byte will be received and ACK will be returned.

Repeated START will be transmitted.

STOP condition will be transmitted and SSSTO flag

will be reset.

STOP condition followed by a START condition will

be transmitted and SSSTO flag will be reset.

01Data byte will be received and NOT ACK will be

returned.

Data byte will be received and ACK will be returned.

Repeated START will be transmitted.

STOP condition will be transmitted and SSSTO flag

will be reset.

STOP condition followed by a START condition will

be transmitted and SSSTO flag will be reset.

4301D–8051–02/08

Figure 40. Format and State in the Slave Receiver Mode

S SLA W A

Data A

Data

P or S

General Call A

Data A

Data

P or S

60h

68h

80h

A0h

88h

70h 90h

90h

A0h

P or S

98h

78h

Data A

From master to slave

From slave to master

Any number of data bytes and their associated acknowledge bits

This number (contained in SSCS) corresponds to a defined state of the 2-wire bus

Reception of the own slave address and one or more data bytes. All are acknowledged.

Last data byte received is not acknowledged.

Arbitration lost as master and addressed as slave

Reception of the general call address and one or more data bytes.

Last data byte received is not acknowledged.

Arbitration lost as master and addressed as slave by general call

AT89C51IC2

4301D–8051–02/08

Table 70. Status in slave receiver mode

Application Software Response

AT89C51IC2

Status

Code

(SSCS)

60h

68h

70h

78h

80h

Status of the 2-wire bus and

2-wire hardware

Own SLA+W has been

received; ACK has been

returned

Arbitration lost in SLA+R/W as master; own SLA+W has been

received; ACK has been

returned

General call address has been

received; ACK has been

returned

Arbitration lost in SLA+R/W as

master; general call address

has been received; ACK has

been returned

Previously addressed with

own SLA+W; data has been

received; ACK has been

returned

To/from SSDAT To SSCON

STA STO SI AA

No SSDAT action or

No SSDAT action

No SSDAT action or

No SSDAT action

No SSDAT action or

No SSDAT action

No SSDAT action or

No SSDAT action

No SSDAT action or

No SSDAT action

Next Action Taken By 2-wire Software

Data byte will be received and NOT ACK will be

returned

Data byte will be received and ACK will be

returned

Data byte will be received and NOT ACK will be

returned

Data byte will be received and ACK will be

returned

Data byte will be received and NOT ACK will be

returned

Data byte will be received and ACK will be

returned

Data byte will be received and NOT ACK will be

returned

Data byte will be received and ACK will be

returned

Data byte will be received and NOT ACK will be

returned

Data byte will be received and ACK will be

returned

88h

90h

Previously addressed with

own SLA+W; data has been

received; NOT ACK has been

returned

Previously addressed with

general call; data has been

received; ACK has been

returned

Read data byte or

Read data byte

Read data byte or

Read data byte

Switched to the not addressed slave mode; no

recognition of own SLA or GCA

Switched to the not addressed slave mode; own SLA will be recognised; GCA will be recognised if

GC=logic 1

Switched to the not addressed slave mode; no recognition of own SLA or GCA. A START

condition will be transmitted when the bus becomes free

Switched to the not addressed slave mode; own SLA will be recognised; GCA will be recognised if

GC=logic 1. A START condition will be transmitted when the bus becomes free

Data byte will be received and NOT ACK will be

returned

Data byte will be received and ACK will be

returned

4301D–8051–02/08

Application Software Response

Status

Code

(SSCS)

98h

A0h

Status of the 2-wire bus and

2-wire hardware

Previously addressed with

general call; data has been

received; NOT ACK has been

returned

A STOP condition or repeated

START condition has been

received while still addressed

as slave

To/from SSDAT To SSCON

STA STO SI AA

Read data byte or

Read data byte

No SSDAT action or

No SSDAT action

Next Action Taken By 2-wire Software

Switched to the not addressed slave mode; no

recognition of own SLA or GCA

Switched to the not addressed slave mode; own SLA will be recognised; GCA will be recognised if

GC=logic 1

Switched to the not addressed slave mode; no recognition of own SLA or GCA. A START

condition will be transmitted when the bus becomes free

Switched to the not addressed slave mode; own SLA will be recognised; GCA will be recognised if

GC=logic 1. A START condition will be transmitted when the bus becomes free

Switched to the not addressed slave mode; no recognition of own SLA or GCA

Switched to the not addressed slave mode; own SLA will be recognised; GCA will be recognised if

GC=logic 1

Switched to the not addressed slave mode; no recognition of own SLA or GCA. A START

condition will be transmitted when the bus becomes free

Switched to the not addressed slave mode; own SLA will be recognised; GCA will be recognised if

GC=logic 1. A START condition will be transmitted when the bus becomes free

AT89C51IC2

4301D–8051–02/08

Figure 41. Format and State in the Slave Transmitter Mode

S SLA R

Data A

Data

P or S

A8h

B8h C0h

P or S

C8h

All 1’s

B0h

Data A

From master to slave

From slave to master

Any number of data bytes and their associated acknowledge bits

This number (contained in SSCS) corresponds to a defined state of the 2-wire bus

Reception of the own slave address and one or more data bytes

Arbitration lost as master and addressed as slave

Last data byte transmitted. Switched to not addressed slave (AA=0)

AT89C51IC2

Status

Code

(SSCS)

A8h

B0h

B8h

Status of the 2-wire bus and

2-wire hardware

Own SLA+R has been

received; ACK has been

returned

Arbitration lost in SLA+R/W as

master; own SLA+R has been

received; ACK has been

returned

Data byte in SSDAT has been

transmitted; NOT ACK has

been received

Table 71. Status in slave transmitter mode

Application Software Response

To/from SSDAT To SSCON

Load data byte or

Load data byte

Load data byte or

Load data byte

Load data byte or

STA STO SI AA

Load data byte

Next Action Taken By 2-wire Software

Last data byte will be transmitted and NOT ACK

will be received

Data byte will be transmitted and ACK will be

received

Last data byte will be transmitted and NOT ACK

will be received

Data byte will be transmitted and ACK will be

received

Last data byte will be transmitted and NOT ACK

will be received

Data byte will be transmitted and ACK will be

received

4301D–8051–02/08

Application Software Response

Status

Code

(SSCS)

C0h

C8h

Status of the 2-wire bus and

2-wire hardware

Data byte in SSDAT has been

transmitted; NOT ACK has

been received

Last data byte in SSDAT has

been transmitted (AA=0); ACK

has been received

To/from SSDAT To SSCON

STA STO SI AA

No SSDAT action or

No SSDAT action

No SSDAT action or

No SSDAT action

Next Action Taken By 2-wire Software

Switched to the not addressed slave mode; no

recognition of own SLA or GCA

Switched to the not addressed slave mode; own SLA will be recognised; GCA will be recognised if

GC=logic 1

Switched to the not addressed slave mode; no recognition of own SLA or GCA. A START

condition will be transmitted when the bus becomes free

Switched to the not addressed slave mode; own SLA will be recognised; GCA will be recognised if

GC=logic 1. A START condition will be transmitted when the bus becomes free

Switched to the not addressed slave mode; no recognition of own SLA or GCA

Switched to the not addressed slave mode; own SLA will be recognised; GCA will be recognised if

GC=logic 1

Switched to the not addressed slave mode; no recognition of own SLA or GCA. A START

condition will be transmitted when the bus becomes free

Switched to the not addressed slave mode; own SLA will be recognised; GCA will be recognised if

GC=logic 1. A START condition will be transmitted when the bus becomes free

AT89C51IC2

Table 72. Miscellaneous status

Application Software Response

To/from

Status

Code

(SSCS)

F8h

00h

Status of the 2-wire

bus and 2-wire

hardware

No relevant state

information

available; SI= 0

Bus error due to an

illegal START or

STOP condition

SSDAT

No SSDAT

action

No SSDAT

action

To SSCON

Next Action Taken By 2-wire

STA STO SI AA

No SSCON action Wait or proceed current transfer

0 1 0 X

Software

Only the internal hardware is affected, no STOP condition is sent on the bus. In all cases, the bus is released and STO is reset.

4301D–8051–02/08

Registers Table 73. SSCON Register

SSCON - Synchronous Serial Control register (93h)

7 6 5 4 3 2 1 0

CR2 SSIE STA STO SI AA CR1 CR0

AT89C51IC2

Bit

Number

7 CR2

6 SSIE

5 STA

4 ST0

3 SI

2 AA

1 CR1

Bit

Mnemonic Description

Control Rate bit 2

See Table 67.

Synchronous Serial Interface Enable bit

Clear to disable SSLC. Set to enable SSLC.

Start flag

Set to send a START condition on the bus.

Stop flag

Set to send a STOP condition on the bus.

Synchronous Serial Interrupt flag

Set by hardware when a serial interrupt is requested. Must be cleared by software to acknowledge interrupt.

Assert Acknowledge flag

Clear in master and slave receiver modes, to force a not acknowledge (high level on SDA). Clear to disable SLA or GCA recognition. Set to recognise SLA or GCA (if GC set) for entering slave receiver or transmitter modes. Set in master and slave receiver modes, to force an acknowledge (low level on SDA). This bit has no effect when in master transmitter mode.

Control Rate bit 1

See Table 67.

4301D–8051–02/08

0 CR0

Control Rate bit 0

See Table 67.

Table 74. SSDAT (095h) - Syncrhonous Serial Data register (read/write)

SD7 SD6 SD5 SD4 SD3 SD2 SD1 SD0

7 6 5 4 3 2 1 0

Bit

Number

7 SD7 Address bit 7 or Data bit 7.

6 SD6 Address bit 6 or Data bit 6.

5 SD5 Address bit 5 or Data bit 5.

4 SD4 Address bit 4 or Data bit 4.

3 SD3 Address bit 3 or Data bit 3.

2 SD2 Address bit 2 or Data bit 2.

Bit

Mnemonic Description

Bit

Number

1 SD1 Address bit 1 or Data bit 1.

0 SD0 Address bit 0 (R/W) or Data bit 0.

Bit

Mnemonic Description

Table 75. SSCS (094h) read - Synchronous Serial Control and Status Register

7 6 5 4 3 2 1 0

SC4 SC3 SC2 SC1 SC0 0 0 0

Table 76. SSCS Register: Read Mode - Reset Value = F8h

Bit

Number

0 0 Always zero

1 0 Always zero

2 0 Always zero

Bit

Mnemonic Description

3 SC0

4 SC1

5 SC2

6 SC3

7 SC4

Status Code bit 0

See Table 68.to Table 72.

Status Code bit 1

See Table 68.to Table 72.

Status Code bit 2

See Table 68.to Table 72.

Status Code bit 3

See Table 68.to Table 72.

Status Code bit 4

See Table 68.to Table 72.

100

AT89C51IC2

4301D–8051–02/08

ATMEL AT89C51IC2 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

Features

Description AT89C51IC2 is a high performance Flash version of the 80C51 8-bit microcontrollers. It

Block Diagram

SFR Mapping The Special Function Registers (SFRs) of the AT89C51IC2 fall into the following

Pin Configurations

Oscillators

Overview Two oscillators are available for CPU:

Registers Table 14. CKSEL Register

Operating Modes

Design Considerations

Timer 0: Clock Inputs Figure 4. Timer 0: Clock Inputs

Enhanced Features In comparison to the original 80C52, the AT89C51IC2 implements some new features,

X2 Feature and OSCA Clock Generation

Dual Data Pointer Register

Expanded RAM (XRAM)

Timer 2 The Timer 2 in the AT89C51IC2 is the standard C52 the Timer 2.

Auto-Reload Mode The auto-reload mode configures timer 2 as a 16-bit timer or event counter with auto-

Programmable Counter Array PCA

Figure 13. PCA Capture Mode

16-bit Software Timer/ Compare Mode

High Speed Output Mode In this mode the CEX output (on port 1) associated with the PCA module will toggle

Pulse Width Modulator Mode

PCA Watchdog Timer An on-board watchdog timer is available with the PCA to improve the reliability of the

Serial I/O Port The serial I/O port in the AT89C51IC2 is compatible with the serial I/O port in the 80C52.

• Framing error detection

Automatic Address Recognition

Baud Rate Selection for UART for mode 1 and 3

UART Registers Table 40. SADEN Register

Interrupt System The AT89C51IC2 has a total of 10 interrupt vectors: two external interrupts (INT0 and

Registers The PCA interrupt vector is located at address 0033H, the SPI interrupt vector is located

Interrupt Sources and Vector Addresses

Power Management Two power reduction modes are implemented in the AT89C51IC2: the Idle mode and

Reset In order to start-up (cold reset) or to restart (warm reset) properly the microcontroller, an

Reset Recommendation to Prevent Flash Corruption

Idle Mode An instruction that sets PCON.0 indicates that it is the last instruction to be executed

Power-down Mode To save maximum power, a Power-down mode can be invoked by software (see PCON

Serial Port Interface (SPI)

Features Features of the SPI Module include the following:

Signal Description Figure 26 shows a typical SPI bus configuration using one Master controller and many

Functional Description Figure 27 shows a detailed structure of the SPI Module.

Keyboard Interface The AT89C51IC2 implements a keyboard interface allowing the connection of a

Registers Table 61. KBF Register

2-wire Interface (TWI) This section describes the 2-wire interface. In the rest of the section SSLC means Two-

Description The CPU interfaces to the 2-wire logic via the following four 8-bit special function regis-

Notes SSLC interfaces to the external 2-wire bus via two port pins: SCL (serial clock line) and

Registers Table 73. SSCON Register
