Page 1
User Manual
10-input Switcher / Scan Converter
with Single HDMI (1.3) Output with 3D Support
AT-HD600
atlona.com
Toll free: 1-877-536-3976
Local: 1-408-962-0515
Page 2
TABLE OF CONTENTS
1
1. Introduction .................................................. 2
2. Features .................................................. 2
3. Operation Controls and Functions .................................................. 3
3.1. Front Panel .................................................. 3
3.2. Rear Panel .................................................. 3
4. Remote Control .................................................. 4
5. RS-232 Remote Control Protocol .................................................. 4
5.1 RS-232 transmission format .................................................. 4
6. Specifications .................................................. 5
7. Connection Diagram .................................................. 6
8. Safety Information .................................................. 7
9. Warranty .................................................. 8
10. Atlona Product Registration .................................................. 9
atlona.com
Toll free: 1-877-536-3976
Local: 1-408-962-0515
Page 3
INTRODUCTION
2
Atlona Technologies’ high quality Video Converter converts analog and digital signals to HDMI v1.3 output. The product
is compatible to HDMI v1.3 specifications, a cutting edge technol¬ogy which defines to transfer Deep Color (10-bit and
12-bit) video. Simply select from the front panel or remote control to choose the input sources.
FEATURES
• HDMI 1.3, HDCP1.1 and DVI1.0 compliant Receiver.
• Deep Color video up to 12bit, 1080p@(24/60)Hz.
• Supports analog/digital video/audio input and HDMI v1.3 output.
• HDCP keysets allow each HDMI input to work independently when connecting to an HDMI display.
• Supports a wide range of PC and HDTV resolutions from VGA to SXGA@75Hz and 480i to 1080p. Component out-
put supports resolutions up to 1080i.
• Support 3D comb filter.
• Support 3D noise reduction (DNR).
• Support format converter from 480i/576i to 480p/576p, simply press the front panel or remote control.
• Support audio delay for 150ms, this feature will not function when HDMI is inputted. Support IR remote control.
Support RS-232 control.
atlona.com
Toll free: 1-877-536-3976
Local: 1-408-962-0515
Page 4
OPERATION CONTROLS AND FUNCTIONS
3
3.1 Front Panel
1 2 3 4
1. Power switch and power LED indicator: Press the switch to power on the unit and the power LED will illuminate.
2. IR sensor.
3. Input source selection: Press the input button to switch to your desired input sources, the LED will illuminate to
indicate which input source is selected.
4. Audio delay: Press to delay audio sources for 150ms, the LED will illuminate when powered on.
3.2 Rear Panel
1 2 3 4 5 6 7
1. Power: Plug the 5V DC power supply into this unit and connect the adaptor to AC wall outlet.
2. CV/SV inputs: Connect each of the input ports to the CV/SV and R/L output ports of your source equipments such
as DVD player or set-top- box. The CV1/SV1/Audio1 and CV2/SV2/Audio2 are individual loops for source equipments.
3. Component inputs: Connect each ofthe input component ports to the component and R/L output ports ofyour
source equipments such as DVD playerorset-top-box. The Componentl/Component Audiol and Component2/ Component Audio2 are individual loops for source equipments.
4. HDMI inputs: Connect each of the input ports to the HDMI or DVI output ports of your source equipment such as
a DVD player or set-top-box.
5. PC input: Connect PC/audio input port to the PC/audio output port ofyour source equipment such as a Note¬book
or PC.
6. RS232: 9-pin D-Sub connector for connecting to your PC or other control consoles from remote control.
7. HDMI output: Connect the output port to the HDMI display.
atlona.com
Toll free: 1-877-536-3976
Local: 1-408-962-0515
Page 5
REMOTE CONTROL
4
1. Audio Delay: Press to delay audio output for 150ms.
2. Format selection: To switch between Interlace and Progressive format.
3. Power: Press the button to turn on/offthe unit.
4. Component 1/2: Press to select Composite 1or2 inputs.
5. PC: Press for PC input.
6. S-Video1/2: Press to select S-Video 1or2 inputs.
7. Video1/2: Press to select Video 1or2 inputs.
8. HDMI 1/2/3: Press to select HDMI 1,2or3 inputs.
RS-232 REMOTE CONTROL PROTOCOL
System Remote Controller
Pin Definition Pin Definition
1 NC 1 NC
2 TxD 2 RxD
3 RxD 3 TxD
4 NC 4 NC
5 GND 5 GND
6 NC 6 NC
7 NC 7 NC
8 NC 8 NC
9 NC 9 NC
RS-232 transmission format: Baud
Rate : 9600 bps
Data Bit : 8 bits
Parity : None
Stop Bit : 1 bit
atlona.com
Toll free: 1-877-536-3976
Local: 1-408-962-0515
Page 6
5.1 RS-232 transmission format:
5
Command Code Response Description
S POWER 0 > POWER OFF POWER OFF
S POWER 1 > POWER ON POWER ON
S SOURCE 0 > SOURCE HDMI1 HDMI1 INPUT
S SOURCE 1 > SOURCE HDMI2 HDMI2 INPUT
S SOURCE 2 > SOURCE HDMI3 HDMI3 INPUT
S SOURCE 3 > SOURCE PC PC INPUT
S SOURCE 4 > SOURCE COMP1 COMPONENT1 INPUT
S SOURCE 5 > SOURCE COMP2 COMPONENT2 INPUT
S SOURCE 6 > SOURCE SV1 SV1 INPUT
S SOURCE 7 > SOURCE SV2 SV2 INPUT
S SOURCE 8 > SOURCE CV1 CV1 INPUT
S SOURCE 9 > SOURCE CV2 CV2 INPUT
S AUDIODELAY 0 > AUDIODELAY OFF OFF: NO DELAY
S AUDIODELAY 1 > AUDIODELAY ON ON: DELAY 150ms
S RESET 1 > RESET ON RESET ACTION
R POWER > POWER ON - OFF SHOW POWER STATUS
R SOURCE > SOURCE HDMI - CV SHOW SOURCE STATUS
R AUDIODELAY > AUDIODELAY OFF - ON SHOW AUDIO DELAY STATUS
R FW_VER > FIRMWARE VERSION: Vx.xx SHOW FIRMWARE VERSION
SPECIFICATIONS
Frequency bandwidth 2.25Gbps (single link)
Input ports 3 x HDMI female ports (Type A connector) 1xPC with audio jack 2 x Y/Pb/Pr with
R/L 2 x CV/SV with R/L
Output port 1 x RS-232
1 x HDMI female port (signal link)
Power Supply 5VDC/2.6A (US/EU standards, CE/FCC/UL certified)
Dimensions (mm) 280(W) x 147(D) x 44(H)
Weight (g) 1380
Chassis Material Metal
Operating Temperature Operating from 0°C - 48°C
atlona.com
Toll free: 1-877-536-3976
Local: 1-408-962-0515
Page 7
CONNECTION DIAGRAM
6
PC
DVD 1
RS-232
DVD 2
Blu-Ray 1 Blu-Ray 2
LCD TV
atlona.com
Toll free: 1-877-536-3976
Local: 1-408-962-0515
Page 8
SAFETY INFORMATION
7
Safeguards
To reduce the risk of electric shock, do not
expose this product to rain or moisture
If the wall plug does not fit into your local
power socket, hire an electrician to replace
your obsolete socket.
Precautions
FCC regulations state that any unauthorized changes or modifications to this equipment, not expressly
approved by the manufacturer, could void the user’s authority to operate this equipment.
Operate this product using only the included external power supply. Use of other power supplies could impair
performance, damage the product, or cause fires.
In the event of an electrostatic discharge this device may automatically turn off. If this occurs, unplug the device
and plug it back in.
Protect and route power cords so they will not be stepped on or pinched by anything placed on or against
them. Be especially careful of plug-ins or cord exit points from this product.
Do not modify the wall plug. Doing so will
void the warranty and safety features.
This equipment should be installed near
the socket outlet and the device should
be easily accessible in the case it requires
disconnection.
Avoid excessive humidity, sudden temperature changes or temperature extremes.
Keep this product away from wet locations such as bathtubs, sinks, laundries, wet basements, fish tanks, and
swimming pools.
Use only accessories recommended by Atlona to avoid fire, shock, or other hazards.
Unplug the product before cleaning. Use a damp cloth for cleaning and not cleaning fluid or aerosols.
Such products could enter the unit and cause damage, fire, or electric shock. Some substances may also
mar the finish of the product.
Never open, remove unit panels, or make any adjustments not described in this manual. Attempting to
do so could expose you to dangerous electrical shock or other hazards. It may also cause damage to your
AT-HD620. Opening the product will void the warranty.
Do not attempt to service the unit. Disconnect the product and contact your authorized Atlona reseller or
contact Atlona directly.
atlona.com
Toll free: 1-877-536-3976
Local: 1-408-962-0515
Page 9
Atlona, Inc. (“Atlona”) Limited Product Warranty Policy
8
Coverage
Atlona warrants its products will substantially perform to their published specifications and will be free from defects in
materials and workmanship under normal use, conditions and service.
Under its Limited Product Warranty, Atlona, at its sole discretion, will either:
A) repair or facilitate the repair of defective products within a reasonable period of time, restore products to their
proper operating condition and return defective products free of any charge for necessary parts, labor and shipping
OR
B) replace and return, free of charge, any defective products with direct replacement or with similar products deemed
by Atlona to perform substantially the same function as the original products
OR
C) refund the pro-rated value based on the remaining term of the warranty period, not to exceed MSRP, in cases
where products are beyond repair and/or no direct or substantially similar replacement products exist.
Repair, replacement or refund of Atlona’s products is the purchaser’s exclusive remedy and Atlona’s liability does not
extend to any other damages, incidental, consequential or otherwise.
This Limited Product Warranty extends to the original end-user purchaser of Atlona’s products and is non-transferrable to
any subsequent purchaser(s) or owner(s) of these products.
Coverage Periods
Atlona’s Limited Product Warranty Period begins on the date of purchase by the end-purchaser. The date contained on
the end-purchaser ‘s sales or delivery receipt is the proof purchase date.
Limited Product Warranty Terms – New Products
• 10 years from proof of purchase date for hardware/electronics products purchased on or after June 1, 2013
• 3 years from proof of purchase date for hardware/electronics products purchased before June 1, 2013
• Lifetime Limited Product Warranty for all cable products
Limited Product Warranty Terms – Refurbished (B-Stock) Products
• 3 years from proof of purchase date for all Refurbished (B-Stock) hardware and electronic products purchased on or
after June 1, 2013
Remedy
Atlona recommends that end-purchasers contact their authorized Atlona dealer or reseller from whom they purchased
their products. Atlona can also be contacted directly. Visit www.atlona.com for Atlona’s contact information and hours
of operation. Atlona requires that a dated sales or delivery receipt from an authorized dealer, reseller or end-purchaser is
provided before Atlona extends its warranty services. Additionally, a return merchandise authorization (RMA) and/or case
number, is required to be obtained from Atlona in advance of returns.
Atlona requires that products returned are properly packed, preferably in the original carton, for shipping. Cartons not
bearing a return authorization or case number will be refused. Atlona, at its sole discretion, reserves the right to reject
any products received without advanced authorization. Authorizations can be requested by calling 1-877-536-3976 (US
toll free) or 1-408- 962-0515 (US/international) or via Atlona’s website at www.atlona.com.
Exclusions
This Limited Product Warranty excludes:
• Damage, deterioration or malfunction caused by any alteration, modification, improper use, neglect, improper
packing or shipping (such claims must be presented to the carrier), lightning, power surges, or other acts of nature.
• Damage, deterioration or malfunction resulting from the installation or removal of this product from any installation,
any unauthorized tampering with this product, any repairs attempted by anyone unauthorized by Atlona to make
such repairs, or any other cause which does not relate directly to a defect in materials and/or workmanship of this
product.
• Equipment enclosures, cables, power supplies, batteries, LCD displays, and any accessories used in conjunction with
the product(s).
• Products purchased from unauthorized distributors, dealers, resellers, auction websites and similar unauthorized
channels of distribution.
atlona.com
Toll free: 1-877-536-3976
Local: 1-408-962-0515
Page 10
Disclaimers
9
This Limited Product Warranty does not imply that the electronic components contained within Atlona’s products will
not become obsolete nor does it imply Atlona products or their electronic components will remain compatible with any
other current product, technology or any future products or technologies in which Atlona’s products may be used in
conjunction with. Atlona, at its sole discretion, reserves the right not to extend its warranty offering in instances arising
outside its normal course of business including, but not limited to, damage inflicted to its products from acts of god.
Limitation on Liability
The maximum liability of Atlona under this limited product warranty shall not exceed the original Atlona MSRP for
its products. To the maximum extent permitted by law, Atlona is not responsible for the direct, special, incidental or
consequential damages resulting from any breach of warranty or condition, or under any other legal theory. Some
countries, districts or states do not allow the exclusion or limitation of relief, special, incidental, consequential or indirect
damages, or the limitation of liability to specified amounts, so the above limitations or exclusions may not apply to you.
Exclusive Remedy
To the maximum extent permitted by law, this limited product warranty and the remedies set forth above are exclusive
and in lieu of all other warranties, remedies and conditions, whether oral or written, express or implied. To the maximum
extent permitted by law, Atlona specifically disclaims all implied warranties, including, without limitation, warranties of
merchantability and fitness for a particular purpose. If Atlona cannot lawfully disclaim or exclude implied warranties
under applicable law, then all implied warranties covering its products including warranties of merchantability and fitness
for a particular purpose, shall provide to its products under applicable law. If any product to which this limited warranty
applies is a “Consumer Product” under the Magnuson-Moss Warranty Act (15 U.S.C.A. §2301, ET SEQ.) or other
applicable law, the foregoing disclaimer of implied warranties shall not apply, and all implied warranties on its products,
including warranties of merchantability and fitness for the particular purpose, shall apply as provided under applicable
law.
Other Conditions
Atlona’s Limited Product Warranty offering gives legal rights, and other rights may apply and vary from country to
country or state to state. This limited warranty is void if (i) the label bearing the serial number of products have been
removed or defaced, (ii) products are not purchased from an authorized Atlona dealer or reseller. A comprehensive list of
Atlona’s authorized distributors, dealers and resellers can be found at www.atlona.com .
Atlona, Inc Product Registration
Thank you for purchasing this Atlona product. - We hope you enjoy it and will take an extra few
moments to register your new purchase.
Registration creates an ownership record if your product is lost or stolen and helps ensure you’ll
receive notification of performance issues and firmware updates.
At Atlona we respect and protect your privacy, assuring you that your registration information is
completely secure. Atlona product registration is completely voluntary and failure to register will not
diminish your limited warranty rights.
To register go to: http://www.atlona.com/registration
atlona.com
Toll free: 1-877-536-3976
Local: 1-408-962-0515
Loading...
