Page 1
USER MANUAL
1X4 3G/HD/SD-SDI DISTRIBUTION AMPLIFIER
WITH RECLOCKING AT-3GSDI-14
Toll free: 1-877-536-3976
Local: 1-408-962-0515
www.atlona.com
Page 2
TABLE OF CONTENTS
1. INTRODUCTION ...................... 1
2. PACKAGE CONTENTS ...................... 1
3. FEATURES ...................... 1
4. SPECIFICATIONS ...................... 2
5. PANEL DESCRIPTIONS ...................... 3
5.1. Transmitting Module ...................... 3
5.1.1. Front Panel ...................... 3
5.1.2. Rear Panel ...................... 3
6. CONNECTION DIAGRAM ...................... 4
7. INSTALLATION ...................... 4
8. SAFETY INFORMATION ...................... 5
9. WARRANTY ...................... 6
10. ATLONA PRODUCT REGISTRATION ...................... 7
11. SIGNAL MEASUREMENT ...................... 8
INTRODUCTION:
The AT-3GSDI-14 1x4 3G/HD/SD-SDI distribution amplifier with Reclocking, receives one SDI input signal,
perfectly duplicates it, and re-transmits to four SDI outputs for a real time multi-viewing. The Atlona 3G HDSDI, HD-SD, SDI Distribution Amplifier is a perfect solution for those who want to split a signal from a camera, Video Card or a Mixer to 4 Outputs. The Atlona unit will not introduce any delay to the video signal and
therefore perfect for professional broadcast applications.
PACKAGE CONTENTS:
• 1xAT-3GSDI-14
• 1x5V universal power supply
• 1x User’s manual
FEATURES:
• Compatible whith full resolution 3G HD-SDI and SDI
• Four separately buffered and reclocked outputs
• Equalized output allows up to 300ft 3G HD-SDI Extension on all outputs and up to 1000ft for SDI signal
• Full Data transmittion without any changes
• Locking power supply for better fixedness’
Toll free: 1-877-536-3976
Local: 1-408-962-0515
1
www.atlona.com
Page 3
SPECIFICATIONS
Technical
Role of usage
SDI standards SD-SDI, HD-SDI, 3G-SDI
Auto 3G/HD/SD detectionY es
Supported protocolsS MPTE 259M, SMPTE 292M, SMPTE 424M, SMPTE 425M
Video bandwidth [2.97Gpbs & 2.97/1.001Gbps]
Data rates 270 / 1483 / 1485 / 2967/ 2970 Mbps
Output impedance
Reclocking functionY es
Audio supportY es
RP-198 pathological patternsI mmune
Input 1x BNC [SDI]
Output 4x BNC [SDI]
BNC connector
Eye pattern characteristics
Mechanical
Housing Metal enclosure
Model
Dimensions
[L x W x H]
Weight
Fixedness Inter-locked power supply
Power supply 5V 4A DC
Power consumption
Operation temperature
Storage temperature
Package
Carton
Model
Package
Relative humidity
Toll free: 1-877-536-3976
Local: 1-408-962-0515
2
www.atlona.com
Page 4
PANEL DESCRIPTIONS
5.1. Transmitting Module
5.1.1. Front Panel
1. 3G/HD/SD-SDI input
2. LED - Orange: 3G/HD-SDI Green: SD-SDI
3. LED - Orange: Power status Green: Signal status
4. 5V DC power jack
1 2 3 4
5.1.2. Rear Panel
1. 3G/HD/SD-SDI output 1
2. 3G/HD/SD-SDI output 2
3. 3G/HD/SD-SDI output 3
4. 3G/HD/SD-SDI output 4
1 2 3 4
Toll free: 1-877-536-3976
Local: 1-408-962-0515
3
www.atlona.com
Page 5
CONNECTION DIAGRAM
SDI camera
AT-3GSDI-14
SDI Monitor
SDI Monitor
SDI Monitor
INSTALLATION:
1. Connect a camera or other SDI source to 3G/HD/SD-SDI input.
2. Connect SDI displays or devices to 3G/HD/SD-SDI outputs.
3. Screw the 5V power supply unit to the locking power jack.
SDI Monitor
Toll free: 1-877-536-3976
Local: 1-408-962-0515
4
www.atlona.com
Page 6
SAFETY INFORMATION
Safeguards
To reduce the risk of electric shock, do not
expose this product to rain or moisture
If the wall plug does not fit into your local
power socket, hire an electrician to replace
your obsolete socket.
Do not modify the wall plug. Doing so will
void the warranty and safety features.
This equipment should be installed near
the socket outlet and the device should
be easily accessible in the case it requires
disconnection.
Precautions
FCC regulations state that any unauthorized changes or modifications to this equipment, not expressly
approved by the manufacturer, could void the user’s authority to operate this equipment.
Operate this product using only the included external power supply. Use of other power supplies could impair
performance, damage the product, or cause fires.
In the event of an electrostatic discharge this device may automatically turn off. If this occurs, unplug the device
and plug it back in.
Protect and route power cords so they will not be stepped on or pinched by anything placed on or against
them. Be especially careful of plug-ins or cord exit points from this product.
Avoid excessive humidity, sudden temperature changes or temperature extremes.
Keep this product away from wet locations such as bathtubs, sinks, laundries, wet basements, fish tanks, and
swimming pools.
Use only accessories recommended by Atlona to avoid fire, shock, or other hazards.
Unplug the product before cleaning. Use a damp cloth for cleaning and not cleaning fluid or aerosols.
Such products could enter the unit and cause damage, fire, or electric shock. Some substances may also
mar the finish of the product.
Never open, remove unit panels, or make any adjustments not described in this manual. Attempting to
do so could expose you to dangerous electrical shock or other hazards. It may also cause damage to your
AT-3GSDI-14. Opening the product will void the warranty.
Do not attempt to service the unit. Disconnect the product and contact your authorized Atlona reseller or
contact Atlona directly.
Toll free: 1-877-536-3976
Local: 1-408-962-0515
5
www.atlona.com
Page 7
WARRANTY
Limited Warranty
Atlona Technologies warrants that (a) its products (the AT-3GSDI-14) will perform
substantially in accordance with the accompanying written materials for a period of 3 years from
the date of receipt and (b) that the product will be free from defects in materials and workmanship
under normal use and service for a period of 3 years. In the event applicable law imposes any
implied warranties, the implied warranty period is limited to 3 years from the date of receipt. Some
jurisdictions do not allow such limitations on duration of an implied warranty, so the above limitation
may not apply to customers that fall within those areas.
Customer Remedies
Atlona Technologies’ and its suppliers’ entire liability and Customer’s exclusive remedy shall
be, at Atlona Technologies’ decision, either return of the price paid for the product, repair, or
replacement of the product that does not meet this Limited Warranty and which is returned to Atlona
Technologies with a copy of the Customer’s receipt. This Limited Warranty is void if failure of the
product has resulted from accident, abuse, misapplication, or natural occurrence. In example but not
limited to: power surges (electrical storms, local power outage), dropping the product (or items on
the product), contact with fluids, and physical misconduct (i.e. kicking or punching). Any replacement
product will be warranted for the remainder of the original warranty period.
No other warranties
To the maximum extent permitted by applicable law, Atlona Technologies and its suppliers
disclaim all other warranties, either expressed or implied, including, but not limited to, implied
warranties of merchantability and fitness for a particular purpose, with regard to the product and any
related written materials. This Limited Warranty gives customer specific legal rights. Customers may
have other rights depending on the jurisdiction.
No liability for damages
To the maximum extent permitted by applicable law, in no event shall Atlona Technologies or
its suppliers be liable for any damages arising out of the use of or inability to use this product, even
if Atlona Technologies has been advised of the possibility of such damages. Such damages include
but are not limited to: special, incidental, consequential, or indirect damages for personal injury, loss
of business profits, business interruption, loss of business information, or any other pecuniary loss.
Atlona Technologies’ and its suppliers’ entire liability under any provision of this agreement shall
be limited to the amount actually paid by you for the product. Some Jurisdictions do not allow the
exclusion or limitation of liability for consequential or incidental damage. The above limitations may
not apply to you in such jurisdictional cases.
Toll free: 1-877-536-3976
Local: 1-408-962-0515
6
www.atlona.com
Page 8
ATLONA PRODUCT REGISTRATION
Thank you for purchasing this Atlona product. - We hope you enjoy it and will take an extra few
moments to register your new purchase.
Registration creates an ownership record if your product is lost or stolen and helps ensure you’ll
receive notification of performance issues and firmware updates.
At Atlona, we respect and protect your privacy, assuring you that your registration information
is completely secure. Atlona product registration is completely voluntary and failure to register will not
diminish your limited warranty rights.
To register go to: http://www.atlona.com/registration
Toll free: 1-877-536-3976
Local: 1-408-962-0515
7
www.atlona.com
Page 9
SIGNAL MEASUREMENT
Toll free: 1-877-536-3976
Local: 1-408-962-0515
8
www.atlona.com
