Atlas IED B2237 Datasheet
Platinum Design Series
Premium Tripod/Boom Systems
General Description
Platinum design tripod/boom systems are engineered to provide the
highest level of performance and quality for high demanding applications
with the positioning convenience and compact storage advantage only
a tripod stand can provide. Night after night on stage or session after
session in the studio, performances will never be compromised by a mic
stand failure when you use the Platinum Design Series tripod mic stands
& booms.
T3664 – Versatile stand that is adjustable from 36" to 64" to meet the
needs of seated and standing instrumentalists and performers. Model
includes two section metal tubing with 3 piece clutch for easy vertical
height adjustment. Unit also features three, low profile metal legs with
cup terminations for optimum stability and balance. The end is threaded
5
or extension boom. The T3664 has a base spread of 25" (653mm) inches
and weighs 5lbs without boom and 7lbs with boom.
T1930 - Versatile stand that is adjustable from 19" to 30" to meet the
needs of seated instrumentalists and performers. Model includes
two section metal tubing with 3 piece clutch for easy vertical height
adjustment. Unit also features three, low profile metal legs with cup
terminations for optimum stability and balance. The end is threaded
27 and includes a lock-nut ring for versatile positioning of accessories or
extension boom. The T1930 has a base spread of 25" (653mm) inches
and weighs 4lbs without boom and 6lbs with boom.
B2237 – Adjustable boom designed to be used with the T3664 or T1930
vertical mic stands. Friction notches on the boom swivel are designed
to prevent sagging even when used with heavy microphones. Cast 0.5
lb counterweight allows for proper boom positioning while maintaining
boom arm balance. B2237 is adjustable from 19" to 37".
TB3664 – Kit includes (1)T3664 & (1)B2237 Combination - Ebony
TB1930 – Kit includes (1)T1930 & (1)B2237 Combination - Ebony
⁄8"-27 and includes a lock-nut ring for versatile positioning of accessories
5
⁄8"-
Platinum Design Series Mics.
Features
• Low Profile Leg Cup For Increased Stability
• Heavy Duty Clutch Assembly
• Boom Swivel Including Friction Notches That Prevent Sagging
1
⁄2lb Counterweight
• Cast
• Non-Reflective Ebony Finish
• Available As Separate Parts Or Complete Kits
Applications
The Atlas Sound Platinum Design Series tripods and booms are ideal for
any application including live stage/touring, house of worship, recording
studios, and broadcast scenarios.
©2012 Atlas Sound L.P. All rights reserved. Atlas Sound and Strategy Series are trademarks of Atlas Sound L.P. All other trademarks are the property of their respective owners. ATS004279 RevA 3/12
Specification
T3664
Description Tall Tri-Pod Base
Tube Color Non-Reective Ebony
Height Adjustable 36" – 64" (914mm - 1626mm)
Base Spread 25" (653mm)
T1930
Description Short Tri-Pod Base
Tube Color Non-Reective Ebony
Height Adjustable 19" – 30" (483mm - 762mm)
Base Spread 25" (653mm)
B2237
Description Telescoping Boom
Tube Color Non-Reective Ebony
Height Adjustable 22" – 37" (559mm - 940mm)
1601 JACK MCKAY BLVD. ENNIS, TEXAS 75119 U.S.A.
TELEPHONE: (800) 876-3333
FAX (800) 765-3435
AtlasSound.com
