Athena GET Hourmeter C1 User Manual

Hourmeter C1 – User Manual rev. 07

GET - ATHENA Spa

Web: www.getdata.it -  [e-mail]

1

Hourmeter C1

User Manual

Hourmeter C1 – User Manual rev. 07

GET - ATHENA Spa

Web: www.getdata.it -  [e-mail]

2

1 MAIN FEATURES

 Exclusive “wireless” system to count engine working hours
 Total counter (non-resettable) up to 1000 hours *
 Partial counter (resettable) up to 1000 hours *
 Control button to reset/visualize counters
 Resolution: 10 minutes
 Internal battery (2 years life with normal use)
 IP66+IP67 protection factor

* once passed 999 hours and 59 minutes, the display visualize 000.0

2 C1 HOURMETER

3 DISPLAY READING

C1 counter visualizes hours in this format:

Examples:

 12 hours and 59 minutes are visualized as 012.5
 13 hours and 05 minutes are visualized as 013.0

4 INSTALLATION

To check a proper installation, please switch on the engine, place the C1 on the chosen position and wait a
few seconds (around 8 – 10 s). The display will switch on showing the working hours and the blinking dot (if
the position is correct).
Install the counter, with adhesive strip in the back, in a position with vibration coming from the engine (in
motorbikes the best part is the outer part of the chassis), but not too close to hot components (as exhaust).
Please clean deeply surfaces before install the C1 (for this it is suggested the use of low residue solvents –
eg. acetone) with outer temperatures exceeding 10°C.
In order to avoid accidental detachments it is possible to use holes in the sides of C1 using two tie wraps to
fix the product to the vehicle.

HHH.M

Hours (tens)

Hours (hundreds)

Hours (unit)

Minutes (tens)

Decimal point

DISPLAY

“S” BUTTON

Hourmeter C1 – User Manual rev. 07

GET - ATHENA Spa

Web: www.getdata.it -  [e-mail]

3

4: IF NEEDED, USE TWO TIE
WRAPS

1: CLEEN PROPERLY THE
SURFACES

2: REMOVE PROTECTION
FROM C1 STRIP

3: FIX THE C1 IN A PROPER
POSITION
