Aten CS1924M, CS1922M User Manual

CS1922M / CS1924M
2/4 Port USB 3.0
4K DisplayPort MST KVMP™ Switch
User Manual
www.aten.com
CS1922M / CS1924M User Manual

EMC Information

Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
FCC Caution: Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate this equipment.
KCC Statement
? ??? ??? (Β? ) ????????? ?? ???? ????
?? ???? ?? , ?? ???? ??? ? ???? .

RoHS

This product is RoHS compliant.
ii
CS1922M / CS1924M User Manual

User Information

Online Registration

Be sure to register your product at our online support center:
International http://eservice.aten.com

Telephone Support

For telephone support, call this number:
International 886-2-8692-6959
China 86-400-810-0-810
Japan 81-3-5615-5811
Korea 82-2-467-6789
North America 1-888-999-ATEN ext 4988
1- 949-428-1111

User Notice

All information, documentation, and specifications contained in this manual are subject to change without prior notification by the manufacturer. The manufacturer makes no representations or warranties, either expressed or implied, with respect to the contents hereof and specifically disclaims any warranties as to merchantability or fitness for any particular purpose. Any of the manufacturer's software described in this manual is sold or licensed as is. Should the programs prove defective following their purchase, the buyer (and not the manufacturer, its distributor, or its dealer), assumes the entire cost of all necessary servicing, repair and any incidental or consequential damages resulting from any defect in the software.
The manufacturer of this system is not responsible for any radio and/or TV interference caused by unauthorized modifications to this device. It is the responsibility of the user to correct such interference.
The manufacturer is not responsible for any damage incurred in the operation of this system if the correct operational voltage setting was not selected prior to operation. PLEASE VERIFY THAT THE VOLTAGE SETTING IS CORRECT BEFORE USE.
iii
CS1922M / CS1924M User Manual

Package Contents

The CS1922M / CS1924M package consists of:
1 CS1922M / CS1924M 2/4-Port USB 3.0 4K DisplayPort MST
KVMP™ Switch
2/4 DisplayPort Cables (CS1922M / CS1924M, Certified)*
2/4 USB 3.0 Cables (CS1922M / CS1924M)
4/8 Audio Cables (CS1922M / CS1924M)
1 Power Adapter
1 User Instructions**
Note: 1. The high quality DisplayPort cables included in this package (or cable
of equal standards) are required to achieve 4K video resolutions.
2. Features may have been added to the CS1922M / CS1924M since this manual was printed. Please visit our website to download the most up-to-date version of the manual.
Check to make sure that all the components are present and that nothing got damaged in shipping. If you encounter a problem, contact your dealer.
Read this manual thoroughly and follow the installation and operation procedures carefully to prevent any damage to the unit, and/or any of the devices connected to it.
iv
CS1922M / CS1924M User Manual

Contents

EMC Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ii
RoHS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ii
User Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .iii
Online Registration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .iii
Telephone Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .iii
User Notice . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .iii
Package Contents. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . iv
Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . v
About this Manual . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . vii
Conventions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .viii
Product Information. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .viii
1. Introduction
Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
Console . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
Computers. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
Cables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
Operating Systems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
CS1922M Front View . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
CS1924M Front View . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
CS1922M Rear View. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
CS1924M Rear View. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
2. Hardware Setup
Cable Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Installation Diagram. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
3. Basic Operation
Port Selection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
Manual Switching. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
Mouse Switching . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Hotkey Switching . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
Hot Plugging . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Powering Off and Restarting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
Port ID Numbering . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Alternative Manual Port Selection Settings. . . . . . . . . . . . . . . . . . . . . . . .15
Display Modes. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Single Stream Transport (SST). . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
Splitter Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
Multi-Stream Transport (MST). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Maximum Resolution / Monitors . . . . . . . . . . . . . . . . . . . . . . . . . .19
v
CS1922M / CS1924M User Manual
4. Hotkey Operation
Cycling Through the Ports. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Going Directly to a Port. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Auto Scanning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Hotkey Setting Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Invoking HSM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Alternate HSM Invocation Keys . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Alternate Port Switching Keys. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Beeper Hotkey . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Display Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Keyboard Operating Platform . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
List Switch Settings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
USB Reset . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Keyboard Language . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Port Switching Keys . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Firmware Upgrade Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Restore Default Settings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Alternative Manual Port Selection. . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Mouse Emulation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Mouse Port Switching . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Keyboard Emulation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Power on Detection. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Monitor Re-detection. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
HSM Summary Table . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
5. Keyboard Emulation
Mac Keyboard. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
6. The Firmware Upgrade Utility
Starting the Upgrade. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Upgrade Successful . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Upgrade Failed . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Appendix
Safety Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Technical Support. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
International . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
North America . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
Hotkey Default Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
Limited Warranty. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
vi
CS1922M / CS1924M User Manual

About this Manual

This user manual is provided to help you get the most from your CS1922M / CS1924M unit. It covers all aspects of installation, configuration and operation. An overview of the information found in the manual is provided below.
Chapter 1, Introduction, introduces you to the CS1922M / CS1924M. Its purpose, features and benefits are presented, and its front and back panel components are described.
Chapter 2, Hardware Setup, describes how to set up your installation. The necessary steps are provided.
Chapter 3, Basic Operation, explains the fundamental concepts involved in operating the CS1922M / CS1924M.
Chapter 4, Hotkey Operation, details all of the concepts and procedures involved in the Hotkey operation of your CS1922M / CS1924M installation.
Chapter 5, Keyboard Emulation, provides tables that list the PC to Mac and PC to Sun keyboard emulation mappings.
Chapter 6, The Firmware Upgrade Utility, explains how to upgrade the CS1922M / CS1924M's firmware with the latest version available.
An
Appendix, provides specifications and other technical information
regarding the CS1922M / CS1924M.
vii
CS1922M / CS1924M User Manual

Conventions

This manual uses the following conventions:
Monospaced Indicates text that you should key in.
[ ] Indicates keys you should press. For example, [Enter] means to
press the Enter key. If keys need to be chorded, they appear together in the same bracket with a plus sign between them: [Ctrl+Alt].
1. Numbered lists represent procedures with sequential steps.
♦ Bullet lists provide information, but do not involve sequential steps.
→ Indicates selecting the option (on a menu or dialog box, for
example), that comes next. For example, Start open the Start menu, and then select Run.
Indicates critical information.

Product Information

→
Run means to
For information about all ATEN products and how they can help you connect without limits, visit ATEN on the Web or contact an ATEN Authorized Reseller. Visit ATEN on the Web for a list of locations and telephone numbers:
International http://www.aten.com
North America http://www.aten-usa.com
viii
Chapter 1
Introduction

Overview

The CS1922M / CS1924M 2/4-Port USB 3.0 4K DisplayPort MST KVMP™ Switch takes a giant leap forward in KVM switch functionality by combining a KVM switch with a DisplayPort video interface, 2-port USB 3.1 Gen 1 hub, MST hub and 2.1 channel audio for rich bass in surround sound. DisplayPort technology provides a 4K UHD @ 60 Hz and 4K DCI @ 60 Hz resolution that displays the most vivid high-definition images available while pumping out premium sound for music, movies, and games.
As a KVM switch with built-in MST hub, the CS1922M / CS1924M allows users to access two or four DisplayPort computers from a single USB keyboard, USB mouse and DisplayPort or HDMI monitor console. In addition to the front panel pushbuttons, hotkeys, and RS-232, the CS1922M / CS1924M offers the latest mouse port-switching functionality which allows a double­click of the scroll-wheel to change ports. A Power On Detection feature also ensures that if one computer is powered off, the CS1922M / CS1924M will automatically switch ports to the next powered-on computer.
The 2-port USB 3.1 Gen 1 hub provides SuperSpeed 5 Gbps data transfer speeds to all connected peripherals. The unit’s independent (asynchronous) switching feature, allows the KVM focus to be on one computer while the USB peripheral focus is on another computer. This eliminates the need to purchase a separate USB hub or stand-alone peripheral sharer – such as a print server, modem splitter, etc.
The CS1922M / CS1924M's built-in MST hub can receive DisplayPort™ 1.2 signals from the source device and split it to independently route the video signal to multiple monitors.
Featuring an unbeatable combination of ultra high 4K resolutions, a next generation USB 3.1 Gen 1 hub and enhanced, user-friendly operations, the CS1922M / CS1924M provides the latest innovations in desktop KVM technology.
1
CS1922M / CS1924M User Manual

Features

2/4-port DisplayPort KVMP Switch with USB 3.1 Gen 1 hub and 2.1
surround sound audio
One USB console controls 2/4 computers and two USB peripherals
Computer selection via front panel pushbuttons, hotkeys, RS-232
commands, and mouse*
Independent switching of KVM, USB hub and audio focus
Superior video quality – 4K UHD (3840 x 2160 @ 60 Hz) and 4K DCI
(4096 x 2160 @ 60 Hz)
2-port USB 3.1 Gen 1 hub with SuperSpeed 5 Gbps transfer rates
DisplayPort 1.2 compliant, HDCP 1.3 compliant
Supports HD audio through DisplayPort**
Full bass response for high-quality 2.1 channel surround sound systems
Power On Detection – if a computer is powered off the CS1922M /
CS1924M automatically switches to the next powered-on computer
Built-in Multi-Stream Transport (MST) hub – allows multiple monitors
through a single DisplayPort source***
DisplayPort Dual-Mode (DP++) technology supports passive HDMI and
DVI adapters****
Hot pluggable – add or remove computers without powering down the
switch
Mouse emulation/bypass feature supports most mouse drivers and
multifunction mice
Multi-platform support – Windows 2000, Windows XP, Windows Vista,
Windows 7/8 and higher, Mac, and Linux
Multilingual keyboard mapping supports English, Japanese, French and
German keyboards
Mac keyboard support and emulation*****
Auto Scan Mode for monitoring all computers
Firmware upgradeable
Note: 1. Mouse port switching is only supported under mouse emulation mode
with a USB 3-button mouse wheel.
2. HD audio through DisplayPort cannot be switched independently.
2
Chapter 1. Introduction
3. MST (Multi-Stream Transport) requires either monitors capable of DisplayPort 1.2 daisy-chaining, or use of a powered DisplayPort MST Hub. A DisplayPort v1.1a display can be the last display in a DisplayPort v1.2 chain. The PC source must be DisplayPort 1.2 compliant.
4. DisplayPort Dual-Mode (DP++) does not require an active adapter for most single display setups. Active DisplayPort adapters are recommended if you are unsure of the video source's DP++ compatibility.
5. PC keyboard combinations emulate Mac keyboards. Mac keyboards only work with their own operating system.
3
CS1922M / CS1924M User Manual

Requirements

Console

A DisplayPort or HDMI monitor capable of the highest possible resolution
A USB mouse
A USB keyboard
Microphone and speakers

Computers

The following equipment must be available on each computer:
DisplayPort port
USB Type A port
Audio ports

Cables

To guarantee video quality we recommend using only ATEN DisplayPort KVM cables which are certified by the VESA Compliance Program. Two (CS1922M) or four (CS1924M) cables are provided with this package.
Note: 1. The video quality displayed is affected by the quality and length of the
cables you use. We recommend the total length from the source to the monitor not exceed 3 meters. If you need additional cable sets, please contact your dealer to purchase ATEN approved cables.
2. If you use DisplayPort cables that are DP 1.1 compliant, make sure the DisplayPort EQ setting on the monitor is set to auto or DP 1.1.
4
Chapter 1. Introduction

Operating Systems

OS Version
Windows 2K / XP / 2003 / 2008 / Vista (x64 / x86) / 7 / 10 and higher
Linux RedHat 9.0, Fedora and higher, RHEL AS 4, RHEL 5
SuSE 10 / 11.1 and higher; OpenSUSE 10.2; SLES 10 SP1
Debian 3.1 / 4.0
Ubuntu 7.04 / 7.10 and higher
Unix IBM AIX 4.3 / 5L (V5.2, V5.3) / V6 (V6.1)
FreeBSD 5.5 / 6.1 / 6.2
Novell Netware 6.0 / 6.5
Mac OS 10.1 / 10.2 / 10.3 / 10.4 / 10.5 / 10.7 / 10.8 and higher
5
CS1922M / CS1924M User Manual
1
324

Components

CS1922M Front View

CS1924M Front View

1
324
6
No. Component Description
Chapter 1. Introduction
1 Port Selection
Pushbuttons
2 Port LEDs The Port LEDs are built into the Port Selection Pushbuttons. The
3 Audio Ports The cables from your main speakers and main microphone plug in
4 USB 3.0 Port USB peripherals (printers, scanners, drives etc.) plug into this port.
For manual port selection (see Manual Switching, page 13):
Press a port selection pushbutton for longer than two seconds to bring the KVM, USB hub, and audio focus to the computer attached to its corresponding port.
Press a port selection pushbutton twice to bring the audio focus to the computer attached to its corresponding port.
Press a port selection pushbutton for less than two seconds to bring only the KVM focus to the computer attached to its corre-
sponding port.
Press port selection pushbutton 1 and 2 simultaneously for 2 sec­onds to start Auto Scan Mode (see Auto Scanning, page 23).
upper are KVM Port LEDs; the lower are USB LEDs: KVM
Lights DIM ORANGE to indicate that the computer attached to the corresponding port is connected (online).
Changes to BRIGHT ORANGE to indicate that the computer attached to its corresponding port is the one that has the KVM focus (Selected).
Flashes to indicate that the computer attached to its corresponding port is being accessed under Auto Scan mode.
USB
Lights GREEN to indicate that the computer attached to its corre­sponding port is the one that has access to the USB peripherals.
here. The speakers and microphone plugged in here have priority over those on the rear panel.
This USB 3.1 Gen 1 port features 5 Gbps data transfer rates for compatible USB peripherals.
7
CS1922M / CS1924M User Manual
1
23
1
23

CS1922M Rear View

CS1924M Rear View

No. Component Description
1 Console Ports The cables from your DisplayPort monitor, HDMI monitor, USB
2 Power Jack The power adapter cable plugs into this jack.
3 KVM Ports The cables that link the switch to your computers plug in here. Each
8
keyboard, USB mouse, speakers, microphone, and USB peripherals* plug in here. In addition, th ere is an RJ-11 port f or serial control. Each connector is marked with an appropriate icon to indicate its use.
Note: This USB 3.1 Gen 1 port features 5 Gbps data transfer rates for compatible USB peripherals.
KVM port section is comprised of a microphone jack, speaker jack, USB Type B socket and a DisplayPort connector.
Chapter 2
1. Important safety information regarding the placement of this device is provided on page 39. Please review it before proceeding.
2. To prevent damage to your installation from power surges or static electricity. It is important that all connected devices are properly grounded.
3. Make sure that power to all the devices you will be installing has been turned off. You must unplug the power cords of any computers that have the Keyboard Power On function.
Hardware Setup

Cable Connections

To set up your installation, refer to the installation diagram on the following page (the numbers in the diagram on page 11 correspond to the steps below), and do the following:
1. Plug the USB keyboard and USB mouse into the USB console ports located on the unit’s rear panel.
2. Plug the console monitor into the DisplayPort and/or HDMI port located on the unit’s rear panel and power on the monitor(s). For multiple monitor setups, see Display Modes, on page 16.
3. Plug the main microphone and speakers into the console microphone and speaker jacks located on the unit’s front panel. The microphone and speakers plugged into these ports have priority over those in the rear panel.
4. (Optional) Plug your secondary microphone and speakers into the console audio ports located on the unit’s rear panel.
5. Using the cables provided with this package, plug the DisplayPort, USB
3.0, microphone, and speaker connectors into their corresponding sockets in the KVM Port section of the switch.
9
Loading...
+ 38 hidden pages
Buy Points How it Works FAQ Contact Us Questions and Suggestions Privacy Policy Cookie Policy Terms of Use
