Fluke Norma 4000/5000

High Precision Power Analyzers

Reliable, highly accurate measurements for the test & development of power electronics

Compact Fluke Norma Series power analyzers include the latest power measurement technology to assist engineers working with motors, inverters, lighting, power supplies, transformers and automotive components in making their products more efﬁcient. Based on a patented high-bandwidth architecture, Fluke Norma Series power analyzers deliver precise measurements of single or threephase current and voltage, harmonics analysis, Fast Fourier Transformation (FFT) analysis, as well as calculations of power and other derived values. They provide class-leading accuracy and common mode rejection for any waveform, frequency, or phase shift.

Technical Data

Fluke Norma 4000:

•

Ideal for ﬁeld testing, the Fluke Norma 4000 power analyzer offers easy and straight-forward operation. Features include: 1 to 3 power phases, 5.7” / 144 mm color display, harmonic analysis, FFT analysis, scope mode, vector diagram display, recorder function, Fluke NormaView PC software, and 4 MB RAM data memory.

Fluke Norma 5000:

•

Providing the highest bandwidth on the market, the Fluke Norma 5000 power analyzer is the ideal test and analysis tool for the development of frequency converters and lighting equipment. Features include: 1 to 6 power phases, optional internal printer, and all of the features and functionality of the Fluke Norma 4000 power analyzer described above.

Fluke Norma Series power analyzers at a glance

Fluke Norma 4000 Fluke Norma 5000

Number of Phases 1 or 3 3, 4 or 6 Bandwidth dc to 3 MHz or dc to 10 MHz depending on input

Basic Accuracy

Sampling Rate Voltage Input Range Current Input Range (direct, not via shunt) Display Color, 5.7“ / 144 mm - 320 x 240 pixel Memory for Conﬁgurations Memory for Settings Fast Fourier Transformation (FFT) RS232 Interface PI1 Process Interface

(8 analog / impulse inputs and 4 analog outputs)

IEE E 488/GPI B Interface Fluke NormaView PC Software (for data

download, analysis & report writing)

module

0.2%, 0.1% or 0.03% depending on input

modules

0.33 MHz or 1 MHz depending on input modules

0.3 to 1000 V

0.03 mA – 20 A depending on input module

4 MB

Standard

To the 40th harmonic

Standard

Optional

Standard

Fluke Norma Series power analyzers -- optimum efﬁciency requires precise measurements

Key Features

• Compact, high precision power analyzers – easy to carry

and save working space.

• Simple user interface ensures easy, intuitive operation.

• Standard conﬁgurations allow users to specify the exact

functionality required for their own unique application.

• Accurately display dynamic events on all phases at

exactly the same point in time with simultaneous parallel acquisition of all phases.

• All inputs are galvanically isolated to avoid short circuits

in all applications.

• Voltage, current and power harmonics up to the 40

• FFT analysis, vector diagram display, recorder function

and Digital Oscilloscope (DSO) mode included.

• User-selectable average time – from 15 ms up to 3600 s –

for dynamic measurements.

• 4 MB on-board memory for storage of measured values.

• RS232 and USB available as standard;

optional IEEE 488/Ethernet available.

• Optional process interface available to measure torque

and speed with external sensors; includes four analog outputs for easy use on motor and drive applications.

• 341 kHz or 1 MHz sample rates for detailed signal

analysis.

• Bandwidth from dc to 3 MHz / 10 MHz for reliable

measurement precision.

• Includes Fluke NormaView PC software for setup, data

download, analysis & report writing.

Applications

Electric motors – Complete measurements of both

electrical and mechanical power values with an uncertainty of only 0.1%. Through detailed spectrum analysis and dynamic torque calculation capabilities, switching losses caused by the inverter are accurately measured, and a thorough evaluation is made of torque transients and harmonics at higher frequencies.

Inverter drive systems

measurement of all electrical and mechanical power parameters in the same time window enables users to observe the inﬂuence one component has on another, or on the whole system.

Lighting systems

MHz and a high sampling rate up to 1 MHz provide detailed signal analysis at ballast outputs. A unique shunt technology enables power measurements at very high frequencies. Simultaneous measurement of input and output power provides instant calculation of ballast losses.

Transformers

measurements enable highly accurate efﬁciency and loss calculations of large power transformers even at very low power factors. Synchronous multiphase resistance measurements are also possible of transformer coils. The internal formula editor enables voltage ratio calculations, and the combination of high-precision fundamental values and wide bandwidth provides detailed harmonics analysis.

– Synchronous six-phase power

– Simultaneous

– Unique bandwidth of up to 10

Fluke Norma Series power analyzers provide easy & reliable use in the ﬁeld or as a bench

Fluke Corporation Fluke Norma 4000/5000 power analyzers

unit in test laboratories.

Basic Functions

Fluke Corporation Analyseurs de puissance de la Fluke Norma 4000/5000

Automotive – Detailed analysis of all electrical and mechanical components installed in modern cars for developing strategies that help reduce fuel consumption or the increase the range of electric vehicles. Synchronous electrical input and mechanical output measurements provide complete data on the efﬁciency and losses of individual components as well as the whole drive system.

Switching power supplies and UPS

– Very wide bandwidth enables detailed and accurate power measurements in the switching link of switching power supplies. Unique coaxial shunt technology delivers precision results in high frequencies of several 100 kHz.

Charge pumps/boost converters

– Wide measurement bandwidth combined with wide dynamic range enable precise measurements of charge pumps with very high switching frequency in the link circuit.

Current transducers

– Detect very small phase shift errors between the various current and voltage channels for support the calibration of current transducers.

tan δ (dissipation factor) measurement – Measure power at very small power factors and calculate tan δ from voltage and current at very low loss angles.

Calibration and test laboratories

– High measurement accuracy enables use as a standard for power calibration and for the certiﬁcation of voltage, current, power and distortion.

Fast Fourier Transformation (FFT)

Calculation of harmonics with graphical representation. Up to 3 harmonic spectrums are displayed simultaneously. Measured values: U, I, & P per phase. Order: 1st to 40th harmonics, maximum

half sample frequency.

Digital Oscilloscope (DSO)

Simultaneous display of up to 3 measured values at sample level. Quick view of waveform and distortion.

Integration function (Energy)

Simultaneous display of up to 6 conﬁgurable numeric values. Start/Stop conditions and positive negative direction available.

Vector display

Vector display of the fundamental for up to 6 signals. For easy testing of the right connection of the instrument and quick overview of the phase angle of each signal.

Recorder function

Display of average values over time for trend determination.

RAM data memory

Storing of sample and average values; setting of start and stop conditions. From the RAM approximately 4 MB are available for the storage of measured values. The memory can be expanded up to 128 MB.

Conﬁguration

Set up the analyzer to measure and display data in the format required.

Test Equipment Depot - 800.517.8431 - 99 Washington Street Melrose, MA 02176

FAX 781.665.0780 - TestEquipmentDepot.com

Measure, test & analyze with high precision and ease

Measuring system

Fluke Norma 4000 and Fluke Norma 5000 power analyzers accurately measure current and voltage and calculate active, reactive and apparent power and calculate other derived values from these high-precision measurements. Accuracy is not affected by either the waveform shape or frequency over a wide range. Phase shift accuracy is maintained due to the input channel design. Harmonics are calculated up to half of the sampling rate. The DSO function represents measured input parameters as waveforms. Voltage and current can be measured directly via the instrument’s integrated voltage dividers and shunts. It is also possible to connect external voltage dividers as well as shunts or current probes for speciﬁc applications. Options such as additional interfaces, analogue inputs and outputs are also available. The analyzer ﬁrmware can be updated via the standard RS232 interface.

High precision measurements

Fluke Norma Series power analyzers are designed to measure signals in a wide frequency range from dc to MHz. The input stages are dc coupled and designed to handle high rise time signals. A zero and offset calibration against a stable voltage reference runs automatically over short time periods to stabilize the accuracy. All voltage and current channels are separated by a unique technology of barriers for high channel isolation and common mode rejection. This makes Fluke Norma Series power analyzers suitable for special applications, such as the switching waveforms present on variable frequency drives or high efﬁciency lighting loads.

Non gapping

The exceptionally high processing power enables precise measurements without gapping, ensuring good results even with rapidly changing signals.

Longtime accuracy

Fluke Norma Series power analyzers maintain high performance and reliable accuracy within the industry’s longest recommended recalibration interval of two years. This long interval reduces downtime and saves service costs.

Standard configurations

There are four different measuring channels available for each Fluke Norma Series power analyzer. For the highest level of ﬂexibility and simplicity, you can choose from a variety of standard conﬁgurations. This enables users to select the power analyzer best suited to their application’s power measurement requirements. Each power phase module differs in basic accuracy, current measuring range, sampling frequency, and bandwidth. For detailed information about the available optional modular power phases, please refer to Page 6 of the speciﬁcations section.

Intuitive keypad operation

Fluke Norma Series power analyzers are very easy to use. With their simple keypad layout and large display, it is possible to select the desired screen and quickly see the important data.

With the arrow keys, users can change phases or move the cursor to highlight individual ﬁelds, which can be accessed using the ENTER key. Settings can be changed to suit the application at hand. Conﬁgurations most used can be saved for later use.

The input modules can handle up to 10 A or 20 A directly or measure current via wideband precision shunts. The available range of shunts enables measurements up to 1500 A and can be used in conjunction with all of the available input modules.

Powerful NormaView PC software

The Fluke NormaView software improves operation efﬁciency of the analyzers by enabling instrument setup settings to be saved and stored along with the measurement data. Instrument setups can be used for particular measurement tasks. Settings can be easily uploaded to the instrument with just a few mouse clicks. The software also enables quick and easy data download, analysis and report writing.

Optional process interface

The optional process interface can be used with both Fluke Norma 4000 and Fluke Norma 5000 power analyzers. It provides the simultaneous recording of torque (M), speed (N) and mechanical power (Pm) of up to four motors. Each of the eight inputs is switchable between analog (voltage) or digital (frequency) input. This interface provides synchronous capture at a sample rate of 34 kHz. The interface also provides four analog outputs, which are updated after every average interval. By inputting the additional analog and digital values it is possible to fully evaluate electrical and mechanical efﬁciency in real time.

Fluke Corporation Fluke Norma 4000/5000 power analyzers

Speciﬁcations

Ambient conditions

Working Temperature Range 5 °C to 35 °C (41 °F to 95 °F) Storage Temperature Range -20 °C to 50 °C (-4 °F to 122 °F) Housing Equipped with a solid metal case to meet stringent EMC requirements. Weight Fluke Norma 4000: Base unit approx. 5 kg (11 lb.)

Size (HxWxD) Fluke Norma 4000:

Display 5.7“ / 144mm - 320 x 240 pixel

Climatic Class KYG DIN 40040, max. 85 % relative humidity,

Net Connection 85 to 264 V ac, 50 to 60 Hz, dc 100 to 260 V, ca. 40 VA European plug with switch. Measuring Inputs Safety sockets 4 mm, 2 for each input. External shunt connection over BNC socket. Operation Membrane keyboard with cursor – function keys and direct functions. Connections Rear panel of the 3-phase analyzer

Measured Values Non-gapping calculation of averaged values for each phase. In three phase system additionally calculation of total

Fluke Norma 5000: Base unit approx. 7 kg (15 lb.)

15 cm x 23.7 cm x 31.5 cm (5.9 in. x 9.3 in. x 12.4 in.) Fluke Norma 5000: 15 cm x 44.7 cm x 31.5 cm (5.9 in. x 17.6 in x 12.4 in.)

User-selectable background lighting and contrast.

non-condensing.

power and averaging of V and I of the three phases. The fundamental H01 will be calculated in synchronous mode also for these values.

effective value, Urm rectiﬁed mean, Um mean value

RMS

Up-, Up+, Upp peak values Ucf crest factor Ucf, Uff form factor Ufc fundamental content U

distortion factor DIN, IEC

thd

effective value, Irm rectiﬁed mean, Im mean value

RMS

Ip-, Ip+, Ipp peak values Icf crest factor Icf, Iff form factor Ifc fundamental content I

distortion factor DIN, IEC

thd

P active power [W] Q reactive power [Var] S apparent power [VA] ë, cos. phase angular Integral function for active power P, reactive power Q, apparent power S, voltage (Um) and current (Im), Number of digits 4 or 5 dependent on measured value.

Frequency and Synchronization

Range DC and 0.2 Hz to sampling rate Accuracy ±0.01 % of measured value (reading)

• Channels which can be selected: all U/I or external input.

• One of three low pass ﬁlter with different frequencies can be switched into the signal.

• The frequency is always visible on the top of the screen.

• The BNC synchronization socket on backside of the instrument can be used either as input or output.

• The input signals can be measured up to the sample rate of the power phase. The maximum level must not be higher then 50 V.

• The output signal is a pulsed 5 Volts TTL signal (frequency depends on the measured synch frequency).

Conﬁguration Memory

Up to 15 user conﬁgurations can be saved into a permanent memory and reloaded later on. Changes that were not saved are lost after switching off the instrument.

Interface

RS232/USB interface for upload of ﬁrmware and data exchange with the PC. A printer can be connected over an external converter. Options IEEE 488.2 / 1 MBit/s

Ethernet / 10 MBit/s or 100 Mbit/s

Standards and Safety

Electrical Safety EN 61010-1 / 2nd Edition 1000 V CAT II (600 V CAT III)

Degree of pollution 2, safety Class I EN 61558 for transformer EN 61010-2-031/032 for accessories

Maximum Inputs For voltage inputs Measurement range 1000 V

For current inputs Measurement range 10 A

, 20 A

eff

, 2 kV

eff

peak

Test Voltages Net input - case (protective conductor): 1.5 KV ac

Net connection – Measurement input: 5.4 kV ac Measurement inputs – Case: 3.3 kV ac Measurement input – Measurement input: 5.4 kV

Electromagnetic Susceptibility Emission: IEC 61326-1, EN 50081-1, EN 55011 Class B

Immunity: IEC 61326-1 / Annex A (industrial sector), EN 50082-1

Fluke Corporation Fluke Norma 4000/5000 power analyzers

Modular Power Phases

The Fluke Norma 4000 power analyzer can be equipped with up to three power phases, and the Fluke Norma 5000 power analyzer can be equipped with up to six power phases. Users can select the type of power phase best suited for their application from a variety of optional power phases. Speciﬁcations vary depending on the model of the power phase. Each modular plug-in power phase consists of a voltage and a current measurement channel. Each measuring channel is available for each basic unit. However, only one kind of channel can be used per unit (see standard conﬁgurations).

Fluke Norma 4000 (rear panel)

Power Phase Overview

Channel Accuracy Current range Sampling rate Bandwidth

PP42 0.2% (0.1% rg + 0.1% rg) 20 A 341 kHz 3 MHz PP50 PP54 10 A 341 kHz 3 MHz

PP64

0.1%

(0.05% rg + 0.05% rg)

0.03%

(0.02% rg + 0.01% rg)

PP42 Power Phase

Ranges

Voltage

8 ranges: 0.3 – 1 – 3 – 10 – 30 – 100 – 300 –

Input impedance: 2 MOhm / 20 pF CMR common mode rejection: 120 dB at 100 kHz

Current

6 ranges:

Input impedance with integrated shunts: Ranges 60, 200 mA: 0.5 Ohm Ranges 0.6, 2 A: 0.05 Ohm Ranges 6, 20 A: 0.005 Ohm Current overload: max. 25 A continuous

Input for external shunt or probe: BNC terminal: 100 kOhm / 30 pF

Overload: max. 20 V CMR common mode rejection: 120 dB at 100 kHz

1000 V U

= 2 x range

peak

60 – 200 mA – 0.6 – 2 – 6 – 20 A I

= 2 x range; max level 150% at

peak

sine wave (limit of error as at 100%).

30 A < 5 sec / 15 sec no load 100 A < 0.1 s / 30 sec no load

30 – 100 mV – 0.3 – 1 – 3- 10 V

rms

Error of Amplitude

Basic accuracy PP42 Sum limit of error

Range 0.1% 0.1% Reading 0.1% 0.1%

Fluke Corporation Fluke Norma 4000/5000 power analyzers

U I

Test Equipment Depot - 800.517.8431 - 99 Washington Street Melrose, MA 02176

Fluke Norma 5000 (rear panel)

10 A 1 MHz 10 MHz

10 A 341 kHz 3 MHz

Voltage and current depending on the input level at 45 – 65 Hz frequency range

Input level Sum limit of error U Sum limit of error I

in % in % in %

100 0.20 0.20

50 0.30 0.30 30 0.43 0.43

10 1.10 1.10

5 2.10 2.10 3 3.43 3.43 1 10.10 10.10

PP42 Bandwidth

U and I via BNC I direct measured

Bandwidth –3 dB 3 MHz 0.5 MHz

Current measurement accuracy depending on the frequency (reading + range)

Frequency Limits of error current in %

[Hz] Internal shunt BNC input

0 0.20 -0.20 0.20 -0.20

10 0.20 -0.20 0.20 -0.20 45 0.20 -0.20 0.20 -0.20 65 0.20 -0.20 0.20 -0.20

500 0.20 -0.20 0.20 -0.20 1000 0.20 -0.20 0.20 -0.20 2000 0.25 -0.41 0.23 -0.32 5000 0.30 -0.69 0.27 -0.48

10000 0.35 -0.91 0.30 -0.60 20000 0.40 -1.12 0.33 -0.72 50000 0.45 -1.40 0.37 -0.88

100000 0.50 -1.61 0.40 -1.00

FAX 781.665.0780 - TestEquipmentDepot.com

Voltage measurement accuracy depending on the frequency (reading + range)

Frequency in Hz Limits of error voltage in %

0 0.20 -0.20 10 0.20 -0.20 45 0.20 -0.20 65 0.20 -0.20

500 0.20 -0.20 1000 0.20 -0.20 2000 0.23 -0.32 5000 0.27 -0.48

10000 0.30 -0.60 20000 0.33 -0.72 50000 0.37 -0.88

100000 0.40 -1.00

Valid for averaged values at 23 ± 0,5 °C ambient temperature, sine waveform and after 1 hour turn on time with measuring signal.

Power / Angular Error

PP42 Between U and I

Angular Error 0.005° +0.005° / kHz 0.025° +0.015° / kHz

BNC

Between U and I

Aliasing ﬁlter OFF

Shunt

Error Power

Frequency in Hz Limit of error power in % at Lamda = 1

45 0.33 -0.33 65 0.33 -0.33

PP50 Power Phase

Ranges

Voltage

8 ranges: 0.3 – 1 – 3 – 10 – 30 – 100 – 300 –

Input impedance: 2 MOhm / 20 pF CMR common mode rejection: 120 dB at 100 kHz

Current

6 ranges:

Input impedance with integrated shunts: Ranges 30, 100 mA: 1 Ohm Ranges 0.3, 1 A: 0.1 Ohm Ranges 3, 10 A: 0.01 Ohm Current overload: max. 15 A continuous

Input for external shunt or probe: BNC terminal: 100 kOhm / 30 pF

Overload: max. 20 Vrms CMR common mode rejection: 120 dB at 100 kHz

1000 V U

= 2 x range

peak

30 – 100 mA – 0.3 – 1 – 3 – 10 A I

= 2 x range; max level 150% at

peak

sine wave (limit of error as at 100%).

30 A < 5 sec / 15 sec no load 100 A < 0.1 s / 30 sec no load

30 – 100 mV – 0.3 – 1 – 3- 10 V

Error of Amplitude

Basic accuracy PP50 Sum limit of error

range 0.05% 0.05% reading 0.05% 0.05%

U I

Voltage and current depending on the input level at 45 – 65 Hz frequency range

Input level Sum limit of error U Sum limit of error I

in % in % in %

100 0.10 0.10

50 0.15 0.15 30 0.22 0.22 10 0.55 0.55

5 1.05 1.05 3 1.72 1.72 1 5.05 5.05

PP50 Bandwidth

U and I via BNC I direct measured

Bandwidth –3 dB 10 MHz 1 MHz

Current measurement accuracy depending on the frequency (reading + range)

Frequency Limits of error current [ % ]

[Hz] Internal shunt BNC input

0 0.10 -0.10 0.10 -0.10 10 0.10 -0.10 0.10 -0.10 45 0.10 -0.10 0.10 -0.10 65 0.10 -0.10 0.10 -0.10

500 0.10 -0.10 0.10 -0.10 1000 0.10 -0.10 0.10 -0.10 2000 0.12 -0.19 0.12 -0.16 5000 0.15 -0.31 0.13 -0.24

10000 0.18 -0.40 0.15 -0.30 20000 0.20 -0.49 0.17 -0.36 50000 0.23 -0.61 0.18 -0.44

100000 0.25 -0.70 0.20 -0.50

Voltage measurement accuracy depending on the frequency (reading + range)

Frequency in Hz Limits of error voltage in %

0 0.10 -0.10 10 0.10 -0.10 45 0.10 -0.10 65 0.10 -0.10

500 0.10 -0.10 1000 0.10 -0.10 2000 0.12 -0.16 5000 0.13 -0.24

10000 0.15 -0.30 20000 0.17 -0.36 50000 0.18 -0.44

100000 0.20 -0.50

Valid for averaged values at 23 ± 0.5 °C ambient temperature, sine waveform and after 1 hour turn on time with measuring signal.

Power / Angular Error

PP50 Between U and I

Angular Error 0.005° +0.005° / kHz 0.025° +0.015° / kHz

BNC

Between U and I

Aliasing ﬁlter OFF

Shunt

Error Power

Frequency in Hz Limit of error power in % at Lamda = 1

45 0.16 -0.16 65 0.16 -0.16

7 Fluke Corporation Fluke Norma 4000/5000 power analyzers

PP54 Power Phase

Ranges

Voltage

8 ranges:

Input impedance: 2 MOhm / 20 pF CMR common mode rejection: 120 dB at 100 kHz

Current

6 ranges:

Input impedance with integrated shunts: Ranges 30, 100 mA: Ranges 0.3, 1 A: Ranges 3, 10 A: Current overload: max. 15 A continuous

Input for external shunt or probe: BNC terminal: 100 kOhm / 30 pF

Overload: max. 20 V CMR common mode rejection: 120 dB at 100 kHz

0.3 – 1 – 3 – 10 – 30 – 100 – 300 – 1000 V U

= 2 x range

peak

30 – 100 mA – 0,3 – 1 – 3 – 10 A I

= 2 x range; max level 150% at

peak

sine wave (limit of error as at 100%).

1 Ohm

0.1 Ohm

0.01 Ohm

30 A < 5 sec / 15 sec no load 100 A < 0.1 s / 30 sec no load

30 – 100 mV – 0.3 – 1 – 3- 10 V

rms

Error of Amplitude

Basic accuracy PP54 Sum limit of error

range 0.05% 0.05% reading 0.05% 0.05%

U I

Voltage and current depending on the input level at 45 – 65 Hz frequency range

Input level Sum limit of error U Sum limit of error I

in % in % in %

100 0.10 0.10

50 0.15 0.15 30 0.22 0.22 10 0.55 0.55

5 1.05 1.05 3 1.72 1.72 1 5.05 5.05

PP54 Bandwidth

U and I via BNC I direct measured

Bandwidth –3 dB 3 MHz 1 MHz

Current measurement accuracy depending on the frequency (reading + range)

Frequency Limits of error current [ % ]

[Hz] Internal shunt [Hz]

0 0.10 -0.10 0.10 -0.10

10 0.10 -0.10 0.10 -0.10 45 0.10 -0.10 0.10 -0.10 65 0.10 -0.10 0.10 -0.10

500 0.10 -0.10 0.10 -0.10 1000 0.10 -0.10 0.10 -0.10 2000 0.15 -0.28 0.13 -0.22 5000 0.20 -0.52 0.17 -0.38

10000 0.25 -0.70 0.20 -0.50 20000 0.30 -0.88 0.23 -0.62 50000 0.35 -1.12 0.27 -0.78

100000 0.40 -1.30 0.30 -0.90

Voltage measurement accuracy depending on the frequency (reading + range)

Frequency in Hz Limits of error voltage in %

0 0.10 -0.10

10 0.10 -0.10 45 0.10 -0.10 65 0.10 -0.10

500 0.10 -0.10 1000 0.10 -0.10 2000 0.13 -0.22 5000 0.17 -0.38

10000 0.20 -0.50 20000 0.23 -0.62 50000 0.27 -0.78

100000 0.30 -0.90

Valid for averaged values at 23 ± 0.5 °C ambient temperature, sine waveform and after 1 hour turn on time with measuring signal.

Power / Angular Error

PP54 Between U and I

Angular Error 0.005° +0.005° / kHz 0.025° + 0.015° / kHz

BNC

Between U and I

Aliasing ﬁlter OFF

Shunt

Error Power

Frequency in Hz Limit of error power in % at Lamda = 1

45 0.16 -0.16 65 0.16 -0.16

PP64 Power Phase

Fluke Corporation Fluke Norma 4000/5000 power analyzers

Ranges

Voltage

8 ranges:

Input impedance: 2 MOhm / 20 pF CMR common mode rejection: 120 dB at 100 kHz

0.3 – 1 – 3 – 10 – 30 – 100 – 300 – 1000 V U

= 2 x range

peak

Current

6 ranges:

Input impedance with integrated shunts: Ranges 30, 100 mA: Ranges 0.3, 1 A: Ranges 3, 10 A: Current overload: max. 15 A continuous

Input for external shunt or probe: BNC terminal: 100 kOhm / 30 pF

Overload: max. 20 V CMR common mode rejection: 120 dB at 100 kHz

30 – 100 mA – 0,3 – 1 – 3 – 10 A I

= 2 x range; max level 150% at

peak

sine wave (limit of error as at 100%).

1 Ohm

0.1 Ohm

0.01 Ohm

30 A < 5 sec / 15 sec no load 100 A < 0.1 s / 30 sec no load

30 – 100 mV – 0.3 – 1 – 3- 10 V

rms

Voltage measurement accuracy depending on the frequency (reading + range)

Frequency in Hz Limits of error voltage in %

0 0.03 -0.03 10 0.03 -0.03 45 0.03 -0.03 65 0.03 -0.03

500 0.03 -0.03 1000 0.06 -0.15 5000 0.10 -0.31

10000 0.13 -0.43 20000 0.16 -0.55 50000 0.20 -0.71

100000 0.23 -0.83

Error of Amplitude

Basic accuracy PP64 Sum limit of error

range 0.02% 0.02% reading 0.01% 0.01%

U I

Voltage and current depending on the input level at 45 – 65 Hz frequency range

Input level Sum limit of error U Sum limit of error I

in % in % in %

100 0.03 0.03

50 0.05 0.05 30 0.08 0.08 10 0.21 0.21

5 0.41 0.41 3 0.68 0.68 1 2.01 0.03

PP64 Bandwidth

U and I via BNC I direct measured

Bandwidth –3dB 3 MHz 1 MHz

Current measurement accuracy depending on the frequency (reading + range)

Frequency Limits of error current [ % ]

[Hz] Internal shunt [Hz]

0 0.03 -0.03 0.03 -0.03 10 0.03 -0.03 0.03 -0.03 45 0.03 -0.03 0.03 -0.03 65 0.03 -0.03 0.03 -0.03

500 0.03 -0.03 0.03 -0.03

1000 0.03 -0.03 0.03 -0.03 2000 0.08 -0.21 0.06 -0.15 5000 0.13 -0.45 0.10 -0.31

10000 0.18 -0.63 0.13 -0.43 20000 0.23 -0.81 0.16 -0.55 50000 0.28 -1.05 0.20 -0.71

100000 0.33 -1.23 0.23 -0.83

Valid for averaged values at 23 ± 0.5 °C ambient temperature, sine waveform and after 1 hour turn on time with measuring

signal.

Power / Angular Error

PP64 Between U and I

Angular Error 0.0025° +0.0025°/kHz 0.005° +0.005°/kHz

BNC

Between U and I

Shunt

Error Power

Frequency in Hz Limit of error power in % at Lamda = 1

45 0.05 -0.05 65 0.05 -0.05

Test Equipment Depot - 800.517.8431 - 99 Washington Street Melrose, MA 02176

Fluke Corporation Fluke Norma 4000/5000 power analyzers

FAX 781.665.0780 - TestEquipmentDepot.com

Ordering Information

Fluke Norma 4000 Basic Conﬁguration

Fluke Norma 4000 High Precision Power Analyzer

Basic conﬁguration includes:

• Power supply cable

• 5.7“ / 144 mm Color display

• RS232/USB interface for data download

• Space for three power-phases and options

• Fluke NormaView PC software

• Color user’s manual

• Test certiﬁcate

• Calibration values

Fluke Norma 5000 Basic Conﬁguration

Fluke Norma 5000 High Precision Power Analyzer

Recommended Accessories

Shunts

The input modules can take up to 10 A or 20 A directly or measure current via wideband precision shunts. The available range of shunts enable measurements up to 1500 A and can be used in conjunction with all of the available input modules.

Order Number Description

3024677 32 A Planar Shunt 3024689 Cables for 32 A Planar Shunt 3024886 3024899 3024847 3024858 3024864 3024873 3024692 LG Shunt Cables for High Current Shunts

10 A Triaxial Shunt with Cables (0.333 Ω, 0 to 0.5 MHz) 30 A Triaxial Shunt with Cables (0.010 Ω, 0 to 0.5 MHz) 100 A Shunt with Cables (0.001 Ω, 0 to 0.5 MHz) 150 A Shunt with Cables (0.5 mΩ, 0 to 0.5 MHz) 300 A Shunt with Cables (0.1 mΩ, 0 to 1 MHz) 500 A Shunt with Cables (0.1 mΩ, 0 to 0.2 MHz)

Basic conﬁguration includes:

• Power supply cable

• 5.7“ / 144 mm Color display

• Internal printer (optional)

• RS232/USB interface for data download

• Space for six power-phases and options

• Fluke NormaView PC software

• Color user’s manual

• Test certiﬁcate

• Calibration values

Optional shunts for Fluke Norma Series power analyzers

Cables & Adaptors

Order Number Description

3024661 Measurement Cable Set (for one power phase) 3024704 Fluke Norma WYE Adaptor (external accessory box)

Printer Accessories

Order Number Description

3024650 Printer Cable for Fluke Norma 5000 (RS232-Centronics)

All accessories have a two-year warranty.

Fluke Corporation Fluke Norma 4000/5000 power analyzers

32 A Planar Shunt

See Recommended Accessories on Page 10.

Standard conﬁgurations

Order number

Fluke-N4K 1PP42 Fluke-Norma 4000, single phase with PP42 power phase input

Fluke-N4K 3PP42 Fluke-Norma 4000, three phase with 3 x PP42 power phase input

Fluke-N4K 3PP42I Fluke-Norma 4000, three phase with 3 x PP42 power phase input

Fluke-N4K 3PP42IP Fluke-Norma 4000, three phase with 3 x PP42 power phase input

Fluke-N4K 3PP42B Fluke-Norma 4000, three phase with 3 x PP42 power phase input

Fluke-N4K 3PP42IB Fluke-Norma 4000, three phase with 3 x PP42 power phase input

Fluke-N4K 3PP42IPB Fluke-Norma 4000, three phase with 3 x PP42 power phase input

Fluke-N4K 3PP50 Fluke-Norma 4000, three phase with 3 x PP50 power phase input

Fluke-N4K 3PP50I Fluke-Norma 4000, three phase with 3 x PP50 power phase input

Fluke-N4K 3PP50IP Fluke-Norma 4000, three phase with 3 x PP50 power phase input

Fluke-N4K 3PP54I Fluke-Norma 4000, three phase with 3 x PP54 power phase input

Fluke-N4K 3PP54IP Fluke-Norma 4000, three phase with 3 x PP54 power phase input

Fluke-N5K 3PP50 Fluke-Norma 5000, three phase with 3 x PP50 power phase input

Fluke-N5K 3PP50I Fluke-Norma 5000, three phase with 3 x PP50 power phase input

Fluke-N5K 3PP50IP Fluke-Norma 5000, three phase with 3 x PP50 power phase input

Fluke-N5K 3PP54 Fluke-Norma 5000, three phase with 3 x PP54 power phase input

Fluke-N5K 3PP54I Fluke-Norma 5000, three phase with 3 x PP54 power phase input

Fluke-N5K 3PP54IP Fluke-Norma 5000, three phase with 3 x PP54 power phase input

Fluke-N5K 3PP64 Fluke-Norma 5000, three phase with 3 x PP64 power phase input

Fluke-N5K 3PP64I Fluke-Norma 5000, three phase with 3 x PP64 power phase input

Fluke-N5K 3PP64IP Fluke-Norma 5000, three phase with 3 x PP64 power phase input

Fluke-N5K 4PP54 Fluke-Norma 5000, four phase with 4 x PP54 power phase input

Fluke-N5K 4PP54IP Fluke-Norma 5000, four phase with 4 x PP54 power phase input

Fluke-N5K 6PP54I Fluke-Norma 5000, six phase with 6 x PP54 power phase input

Fluke-N5K 6PP54IP Fluke-Norma 5000, six phase with 6 x PP54 power phase input

Fluke-N5K 6PP64I Fluke-Norma 5000, six phase with 6 x PP64 power phase input

Fluke-N5K 6PP64IP Fluke-Norma 5000, six phase with 6 x PP64 power phase input

Description PP42 PP50 PP54 PP64

module

modules

modules with IEEE488/ Ethernet (IFC1) interface
