A u d i o P r e c i s i o n P r o d u c t C a t a l o g
2700 Series
Dual Domain Audio Analyzer
APx Series
Multichannel Audio Analyzer
ATS-2
Low Cost Audio Analyzer
Portable 1 / ATS-1
Portable Audio Analyzers
Filters & Accessories
2
2700 Series Dual Domain Audio Analyzer
AP’s agship analyzer, the 2700 Series is designed for audio
engineers who need the highest performance, lowest distortion
and greatest exibility possible in their audio analyzer.
The 2700 Series has the best performance of any audio
analyzer in the world: its high-precision analog audio design is
markedly superior to the best digital implementations in several
key areas, especially residual noise and distortion, and highbandwidth.
The unparalleled accuracy of a dedicated hardware instrument
•
Fast instrument operation and powerful analysis under
•
sophisticated control software
Programmatic control for high-speed automation
•
Serial digital interface testing
•
True dual domain instrument for highest performance
•
192 kHz digital input and output capabilities
•
500 kHz analog / 100 kHz digital measurement bandwidth
•
Vanishingly low residual noise and THD+N
•
Generates and analyzes a broad palette of stimulus signals such as
•
MLS, white and pink noise and other special purpose waveforms
Connects to control PC via USB
•
Analog system 1 kHz THD+N, 20 kHz BW –112 dB
O p t io n s
“A” models include AP2700 control software, APIB or USB interface, cable and full set of user
manuals. “G” models include IEEE-488.2 GPIB control interface, cables and manuals.
SYS-2722A/G Dual domain. Two-channel analog input/output, analog analyzer and
generator, DSP analyzer and generator, plus 192k digital input/output
SYS-2722A-M Windows Vista Logo Test System: SYS-2722A with all required lters
and cables for performing Windows Vista Logo audio tests
SYS-2720A/G Digital domain only. DSP analyzer and generator with 192k digital
input/output
SYS-2712A/G Analog domain only. Two-channel analog input/output, analog analyzer
and generator, DSP analyzer and generator
SYS-2702A/G Analog domain only. Two-channel analog input/output, analog analyzer
and generator
2700-PROG Programmer’s Starter Kit, including: GPIB Programmer’s Reference
Manual and GPIB utilities and samples CD-ROM
S2-IMD Adds IMD generator & analyzer to SYS-2702, SYS-2712, or SYS-2722
S2-W&F Adds wow and utter analyzer to SYS-2702, SYS-2712, or SYS-2722
S2-BUR Adds tone burst, square wave and noise generator to SYS-2702, SYS-
2712, or SYS-2722
S-AES17 Adds multistage low-pass lter for D/A measurements to AES17
standard. Includes special pre-analyzer low-pass lter and analyzer
low-pass option lters FLP-B20k and FLP-B40k
OPT-2020 Adds special pre-analyzer low-pass lter for measurements of signals
with large amounts of out-of-band noise
OPT-2711 Adds the Dolby Digital Generator option to a new SYS-2722 or SYS-
2720, allowing the encoding of stimulus tones in Dolby Digital (AC-3)
before digital output. (Not compatible with GPIB instrument)
EWP2-2700 Two-year extended warranty for 2700 Series
2 7 0 0 S e ri e s K e y Sp e c if i c a t i on s
BASIC FOR MAT
Channels
2
Computer interface
USB, APIB or GPIB
OS Compatability
Windows Vista, XP
Dimensions
3U
GENERATOR P ERF ORMANCE
Sine Frequency Range
10 Hz–204 kHz
Frequency Accuracy
2 ppm
IMD Test Signals
SMPTE, CCIF, DFD, DIM, TIM, DIN,
Maximum Amplitude (balanced)
26.43 Vrms
Amplitude Accuracy
±0.06 dB
Flatness (20 Hz–20 kHz)
±0.008 dB (typically <0.003 dB)
Residual THD+N, 1 kHz
–112 dB, + 1.0 μV , 22 kHz BW
Analog Output Congurations
unbalanced & balanced
Digital Output Sampling Rate
28 kHz–200 kHz
Dolby Digital Generator
Yes
ANALYZER PERFO RMA NCE
Maximum Rated Input Voltage
230 Vpk, 160 Vrms (dc to 20 kHz),
overload protected in all ranges
Maximum Bandwidth
>500 kHz
Amplitude Accuracy (1 kHz)
±0.05 dB
Amplitude Flatness (20 Hz–20 kHz)
±0.02 dB
Residual Input Noise (22 kHz BW)
≤1.0 μV [–117.8 dBu]
Residual THD+N (20 kHz BW)
–112 dB + 1.0 µV, 22 kHz BW
FFT Resolution
Up to 4 M samples (87 seconds at a
sample rate of 48 kHz)
IMD Measurement Capability
SMPTE, CCIF, DFD, DIM, TIM, DIN
DC Voltage Measurement
Yes, with DCX-127 Multifunction Module
a p . c o m
APx Series Multichannel Audio Analyzer
The APx is a dedicated multichannel audio analyzer
that combines a next generation user interface with AP’s
legendary commitment to performance. It’s the perfect audio
analyzer for R&D and production test users who need speed
and ease-of-use.
Now available in an 8 or 16 channel conguration, the
APx is capable of taking 14 measurements in as fast as
7 seconds, automatically generating a report of results
with pass/fail limits and saving all test settings in a single,
sharable project le.
The APx is designed specically for multichannel device
manufacturers for use in R&D and production test, with
multiple channels, Dolby/ DTS condence testing, and
automated test sequencing.
One-click measurements and saveable sequences
•
8 or 16 channels in, 8 channels out
•
Real-time signal monitors including residual THD+N in
•
oscilloscope view and one million point FFT
New high- and low pass and weighting lters, automated
•
reference levels, and playback-only test capability
Documented API support
•
O p t io n s
APx585 APx585 8-channel audio analyzer (Includes APx500
APx586 APx586 16-channel audio analyzer (16 analog inputs)
UPG-586 Upgrades 8-channel audio analyzer to 16 analog input channels
APx581 8-channel switch mode lter
CAB-585 DB25M to DB25M balanced loopback cable; 9 BNC to BNC 14″
CAB-586 Cable kit for APx586 (includes above items for CAB-585 kit,
EWP2-585 Two-year extended warranty for APx585
EWP2-586 Two-year extended warranty for APx586
measurement software, USB 2.0 cable, manuals, CD & DVD
Test Discs, and APx Resources Disc)
(See APx585 for included peripherals)
analog and digital coax loopback cables; DB25M to 8-XLR male
cable; DB25M to 8-XLR female cable; 18 BNC to RCA adapters;
Ground strap
with additional XLR to DB25 input cable for the second input
module)
PAR Excellence Award 2006
World’s Best in Test 2007
A P x S e r ie s Ke y S pe c i fi c a t i o ns
BASIC FOR MAT
Channels
8 or 16
Computer interface
USB 2.0
OS Compatabiltiy
Windows Vista, XP
Dimensions
3U
GENERATOR P ERF ORMANCE
Sine Frequency Range
5 Hz to 80.1 kHz
Frequency Accuracy
3 ppm
IMD Test Signals
SMPTE, MOD, DFD
Maximum Amplitude (balanced)
14.4 Vrms
Amplitude Accuracy
±0.05 dB
Flatness (20 Hz–20 kHz)
±0.008 dB
Residual THD+N (20 kHz BW)
–103 dB + 1.4 µV
Analog Output Congurations
unbalanced & balanced
Digital Output Sampling Rate
22 kHz–192 kHz
Dolby Digital Generator
No
Winner of
Pro Audio Review’s
and
Test & Measurement
ANALYZER PERFO RMA NCE
Maximum Rated Input Voltage
110 Vrms
Maximum Bandwidth
>90 kHz
Amplitude Accuracy (1 kHz)
±0.05 dB
Amplitude Flatness (20 Hz–20 kHz)
±0.008 dB
Residual Input Noise (20 kHz BW)
1.3 µV
Residual THD+N (20 kHz BW)
–103 dB + 1.4 µV
Individual Harmonic Analyzer
d2–d10
FFT Resolution
Up to 1 million (1024 K)
IMD Measurement Capability
SMPTE, MOD, DFD
DC Voltage Measurement
±155 V
3
a p . c o m
4
4
Portable One and ATS-1
Portable One audio analyzers bring bench-quality, high-precision
test and measurement to maintenance, engineering and production
facilities. Whether in broadcast, communications, bench or production
use, Portable One offers a complete, easy-to-use audio test set housed in
a rugged fan-cooled clamshell case that’s ready for almost anything.
Designed for rack-mount and production applications, the ATS-1 offers
the same measurement functionality and ease-of-use as an equivalent
Portable One, but is housed in a fan-cooled metal case, designed for
front or rear modular connector placement and rack mounting.
Portable One Plus Access provides comprehensive two-channel
analog generation and measurement. With twelve different
measurement functions selectable at the push of a button, Portable
One is comprehensive while remaining user-friendly. Easy-to-set-up
sweep capability produces graphs of frequency response, distortion vs.
frequency and even amplitude sweeps. Non-volatile storage of up to 30
tests allows easy, one-button recall of your favorite test setup.
Like the 2700 Series, the Portable One audio analyzer is available as a
dual domain instrument providing simultaneous generation and analysis
capabilities in both the analog domain and the digital domain.
P 1 / A T S -1 K e y Sp e c if i c at i o n s
BASIC FOR MAT
Channels
2
Computer interface
O p t io n s
P1PA Portable One Plus Access audio test system with GPIB interface
P1DD Portable One Dual Domain (digital and analog) audio test system
with GPIB interface. Comes standard with 96 kHz digital sample rate
P1-IMD SMPTE/DIN intermodulation distortion measurement and generation
(analog and digital)
ATS-1A ATS-1 Access audio test system with IEEE-488 GPIB interface
(Specify connector type: BNC or XLR, front or rear mount.)
ATS-1DD ATS-1 Dual Domain (digital and analog) audio test system with
IEEE-488 GPIB interface. Comes standard with 96 kHz digital audio
sample rate
(Specify connector type: BNC or XLR, front or rear mount.)
ATS-IMD SMPTE/DIN intermodulation distortion option
(analog and digital domains)
EWP2-ATS1 Two-year extended warranty for ATS-1 Access or
ATS-1 Dual Domain
EWP2-P1 Two-year extended warranty for Portable One Plus Access or
Portable One Dual Domain
a p . c o m
N/A Self-contained
OS Compatability
N/A Self-contained
Dimensions
3U
GENERATOR P ERF ORMANCE
Sine Frequency Range
10 Hz–120 kHz.
Frequency Accuracy
±0.5%
IMD Test Signals
SMPTE, DIN
Maximum Amplitude (balanced)
24.7 Vrms
Amplitude Accuracy
±0.3 dB
Flatness (20 Hz–20 kHz)
±0.05 dB
Residual THD+N, 1 kHz
0.0025% +3.6 µV
Analog Output Congurations
unbalanced & balanced
Digital Output Sampling Rate
28.8 kHz to 52.8 kHz
Dolby Digital Generator
No
ANALYZER PERFO RMA NCE
Maximum Rated Input Voltage
140 Vrms
Maximum Bandwidth
<10 Hz to 200 kHz
Amplitude Accuracy (1 kHz)
±0.1 dB +100 µV
Amplitude Flatness (20 Hz–20 kHz)
±0.02 dB
Residual Input Noise (20 kHz BW)
1.5 µV rms
Residual THD+N (20 kHz BW)
0.0025% [–92 dB] + 3 µV
FFT Resolution
N/A
IMD Measurement Capability
SMPTE, DIN
DC Voltage Measurement
N/A
ATS-2 Audio Analyzer
The ATS-2 is a general-purpose audio analyzer well suited to the
design lab, broadcast facility or production line—anywhere you
need high-precision, feature-rich audio test and measurement.
The ATS-2 offers an excellent value in audio analyzers. Its
converter-based architecture keeps the cost down while offering a
wide range of features at high levels of performance. Converterbased audio analyzers generate and analyze signals in the digital
domain and use analog-to-digital converters (ADCs) and digital-toanalog converters (DACs) for analog input and output.
Independent analog and digital signal generators
•
Multitone analyzer with FFT for testing playback-only devices
•
Converter-based analyzer delivers high performance at a lower price
•
A wide range of analog and digital test signals
•
Programmatic control for high-speed automation
•
Optional digital interface testing capabilities
•
A full complement of graphing and reporting options
•
Auxiliary instruments are available for specialized testing
•
Connects to control PC via USB
•
5
O p t io n s
ATS2A ATS-2 PC-Based Audio Test System with APIB or USB interface,
ATS2G ATS-2 PC-Based Audio Test System with GPIB Interface,
ATS2-PERF Performance option for ATS-2
ATS2-EURZ Changes generator output impedance selections to 40/200 Ω
ATS2-600Z Changes generator output impedance selections to 40/600 Ω
ATS2G-PROG GPIB Programmers’ Reference Manual
EWP2-ATS2 Two-year extended warranty for ATS-2
ATS software and manuals, and Getting Started Manual
APIB Interface and Getting Started Manual (Software kit and
ATS2G-PROG are not included, but are recommended for GPIB
program development)
(Not compatible with 600Z option)
and adds 600 Ω analyzer input termination selection
(Not compatible with EURZ option)
(Includes CD with samples, manuals, and support software)
AT S - 2 K e y S p e c i f ic a t io n s
BASIC FOR MAT
Channels
2
Computer interface
USB, APIB or GPIB
OS Compatability
Windows Vista, XP
Dimensions
2U
GENERATOR P ERF ORMANCE
Sine Frequency Range
2 Hz–61.6 kHz (SR=131.072 kS/s).
Frequency Accuracy
±0.015625 Hz
IMD Test Signals
SMPTE, DIN
Maximum Amplitude (balanced)
24.1 dBm (Rs = 40)
Amplitude Accuracy
±0.09 dB [±1.0 %]
Flatness (20 Hz–20 kHz)
±0.007 dB
Residual THD+N, 1 kHz
0.0009% [–101 dB] +1.6 µV
Analog Output Congurations
unbalanced & balanced
Digital Output Sampling Rate
28.8 kHz to 108 kHz
Dolby Digital Generator
No
ANALYZER PERFO RMA NCE
Maximum Rated Input Voltage
140 V rms (dc to 20 kHz)
overload protected in all ranges
Maximum Bandwidth
<10 Hz to 120 kHz
(with performance option)
Amplitude Accuracy (1 kHz)
±0.09 dB [±1.0%]
Amplitude Flatness (20 Hz–20 kHz)
±0.01 dB, 20 Hz to 20 kHz
(0.45SR if less)
Residual Input Noise (20 kHz BW)
1.6 µV rms
Residual THD+N (20 kHz BW)
0.0009% [–101 dB] + 1.6 µV
FFT Resolution
Up to 256 K
IMD Measurement Capability
SMPTE, DIN
DC Voltage Measurement
Yes with DCX-127 Multifunction Module
a p . c o m
6
Other Instruments
SWR-2755 Switchers (Input, Output & Unbalanced)
Audio Precision offers three models of the SWR-2755 audio
switchers: the SWR-2755M Output Switcher (balanced male
XLRs), SWR-2755F Input Switcher (balanced female XLRs)
and SWR-2755U Unbalanced Switcher (oating unbalanced
BNCs).
All models are 12 X 2 with ability to cascade up to 16 units for
a maximum of 192 channels. Generator outputs can be routed
to any of the 12 channels. Inter-channel crosstalk is less than
–150 dB at 20 kHz in the balanced models.
PSIA-2722 Programmable Serial Interface Adapter
This adapter enables the connection of chip-level devices,
such as analog-to-digital converters, digital-to-analog converters
and sample rate converters, to Audio Precision 2700 Series and
System Two Cascade Plus audio analyzers. Devices under test
may have a variety of interface protocols, including different
logic families and voltage levels, clock rates, word orientations,
and formats.
DCX-127 Multifunction Module
The DCX-127 Multifunction Module provides Audio
Precision’s PC-controlled audio analyzers with an interface
toolkit of non-audio functions and interface capabilities that are
often required in typical audio test applications. Applications
include VCA gain control linearity, VCA distortion, amplier DC
offset and power supply checks, power amplier load switching
control, loudspeaker voice coil resistance measurements,
temperature measurements, test xture control, and testing DC
parameters of A/D and D/A converters.
AUX-0025 & APx581 Switching Amplier
Measurement Filters
The Audio Precision AUX-0025 Switching Amplier
Measurement Filter is a dual-channel passive lter that provides
the necessary attenuation of out-of-band signals for testing Class
D ampliers.
The APx581 is an 8-channel version suitable for use with the
multichannel APx585.
a p . c o m
AP Service
Audio Precision’s dedicated Service Department and Tech
Support staff are the most experienced professionals in the audio
test and measurement industry.
AP offers free tech support for the life of our products. Simply
put, there’s virtually no audio test and measurement challenge AP
Tech Support haven’t already faced and solved. So if you have
any questions about your Audio Precision products or if there’s a
particular challenge you’d like some help with, don’t hesitate to
contact us by phone or email.
For more information about AP Service, visit ap.com/service
Accredited calibration and the best warranty in the
industry
All new PC-controlled AP analyzers are calibrated to the ISO
17025 standard before being shipped, and Audio Precision is proud
to offer a limited three-year warranty on all new products (terms
and conditions apply). Two-year extended warranties are also
available.
European Service Center
Opened in 2007, the European Service Center allows faster
warranty work, repairs, factory adjustments and other AP services
for AP customers in Europe, the Middle East and Africa who do
not wish to ship their instruments to the AP factory in Beaverton.
The European Service Center offers accredited calibrations to the
ISO 9000 standard.
AP Calibration Lab
Audio Precision is accredited
by the American Association for
Laboratory Accreditation under
ISO/IEC 17025:2005 for equipment
calibration at our US factory.
Calibration provides documented and
traceable verication that instruments
meet or exceed all of their published
specications.
Accredited by A2LA under
•
ISO/IEC 17025:2005
Documented Quality System for
calibration; 17025 is the highest
standard for calibration services.
Full service available
•
If the unit does not meet
specication, we can repair or
adjust it immediately. No extra time
or cost shipping from the Cal lab to
the Factory.
Dedicated audio engineers
•
Automated systems and
experienced AP technicians who
know audio.
7
S e r vi c e s
MODEL - ADJ Factory Adjustment to Specication
MODEL - REP Repair & Factory Adjustment to Specication
MODEL - CAL Accredited Calibration
MODEL - CALP Calibration, Repair & Adjustment
RUSH 1 week rush service available
Accredited by A2LA
under ISO/IEC 17025:2005
for equipment calibration
a p . c o m
About Audio Precision
Since 1984, AP has been the worldwide leader of audio test and measurement. AP is committed to making audio test
easier and more productive for R&D and production line test in consumer audio, pro sound, automotive and broadcast.
For more information about any of our instruments, please visit the AP website at ap.com.
AP instruments are sold through an international network of knowledgeable distributors and US sales representatives
who are ready to assist you with any sales questions, training or application engineering. For more information about
your local sales partner, please visit the AP website at ap.com/contact/sales or email sales@ap.com.
US Headquarters ............................................................ Beaverton, Oregon, USA (503) 627-0832
US Headquarters ........................................................... Toll Free in the USA (800) 231-7350
Australia ........................................................................ Vicom Australia Pty. Ltd. +61 3 9563 7844
Bangladesh ..................................................................... Kinetic Trade International +880 2 956 1969
Belgium ......................................................................... Heynen NV +32 (0)11-60 09 09
Canada ........................................................................... Gerraudio +1 613 342 6999
Czech Republic .............................................................. TR Instruments +420 541 633 670
China (incl Hong Kong) ................................................ AP Technology, Ltd. +852 3114 6028
Denmark, Norway, Sweden ........................................... DK-Technologies, Ltd. +45 44 85 02 54
Finland ........................................................................... Genelec OY +358 17 83 881
France ............................................................................ Equipements Scientiques +33 1 47 95 99 4
Germany, Austria ........................................................... RTW GmbH & Co. KG +49 221 70913 44
Greece, Cyprus .............................................................. KEM Electronics SA +30 210 67 48 51
India ............................................................................... COMCON Industries +91 11 2638 4606
Indonesia, Malaysia, Singapore, Thailand ..................... TME Systems Pte. Ltd. +65 6747 7234
Israel .............................................................................. Dan-El Technologies, Ltd. +972 3 9271888
Italy ................................................................................ Audio Link s.r.l. +39 0521 648723
Japan .............................................................................. Toyo Corporation +81 3 3279 0771
Luxembourg ................................................................... Heynen GMBH +352 (0) 26 91 07 81
Netherlands .................................................................... Heynen BV +31 (0) 485 55 09 09
New Zealand .................................................................. Vicom New Zealand +64 9 379 4596
Portugal .......................................................................... MRA Instrumentacao +351 21 4217472
South Africa ................................................................... Soundfusion (Pty.) Ltd. +27 11 838 0620
South Korea ................................................................... B & P International +82 2 546 1457
Spain .............................................................................. Alava Ingenieros S.A. +34 91 5679700
Switzerland .................................................................... Dr. W. A. Guenther Audio Systems +41 43 222 30 01
Taiwan ............................................................................ Audiotech Science Technology Co. +886 2 2792 0199
UK, Ireland .................................................................... TTi +44 1480 412451
Vietnam .......................................................................... System Interlace Company +84 4 822 9808
a p . c o m
© 2008 Audio Precision, Inc. All rights reserved. VII02261523 pn 0057.004 rev1
5750 SW Arctic Drive
Beaverton, Oregon 97005
503-627-0832
1-800-231-7350
info@ap.com
Loading...
