ATEC AL170 User Manual
Before Use
E
nglish
● This user manual contains proprietary information that is protected by copyright.
All rights are reserved. No part of this user manual may be reproduced, photocopied,
transcribed, translated or transmitted in whatsoever from without the prior permission of
the manufacturer.
● The size and appearance of this monitor may be changed for improvement without
notice.
● Damage caused by using the unauthorized components or disregard of the information
and cautions in this user manual is not covered by the warranty service.
● If you have problem with your monitor, please check TroubleShooting in this user
manual before asking for help service center.
● The information in this user manual is subject to change without notice.
● If you let display the static images on the LCD monitor for prolonged time, the LCD
monitor may show you the screen images retention. It is not a continuous condition and
will fade away in a period time. The Image retention is a condition that may occur on all
LCD monitors.
● The LCD consists of about 5 million pixels. One pixel includes 3 dots and some of dots
could be seen bright and dark compared to other dots. Please, note that it may occur
on all LCD monitors and it is not a product inferiority.
CE Conformity Notice
The Product herewith complies with requirements of the Low Voltage Directive
73/23/EEC and the EMC Directive 89/336/EEC and carries the ‘CE’ mark accordingly.
Confirms to the following hamonized European standards have been applied:
EMC : EN 55022 Class B : 1998
EN 55024 : (EN 61000-4-2 : 1995, A1 : 1998, EN61000-4-3 : 1996, EN 61000-4-4:
1995, EN61000-4-5 : 1995, EN61000-4-4 : 1996, EN61000-4-8 : 1993 and
EN61000-4-11 : 1994)
EN61000-3-3 : 1995, A1 : 98, A2 : 98
EN61000-3-3 : 1995
FCC Compliance Statement
This device complies with Part 15 of the FCC Rules. Operation is subject to the following
two conditions : (1) this device may not cause harmful interference, and (2) this device must
accept any interference received including interference that may cause undesired
operation.
INFORMATION TO THE USER
This equipment has been tested and found to comply with the limits for a Class B digital
device pursuant to Part 15 of the FCC Rules. These limits are designed to provide
resonable protection against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and if not installed
and used in accordance with the instructions, may cause harmful interference to radio
communication. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the user
is encouraged to try to correct the interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment an receiver.
- Connect the equipment into an outlet in a circuit different from that to which the receiver is
connected.
- consult the dealer or an experienced radio / TV technician for help.
WARNING
Changes or modifications not expressly approved by the manufacturer could void the use’s
authority to operate the equipment.
E
nglish
E
nglish
Unpacking
After opening the box, make sure the following items are provided with the monitor.
If you find that any of these items is missing or appears damaged, contact your
dealer immediately.
The actual monitor and accessories may appear differently from those shown on
the above figure
Note
Diskette
(Monitor Driver)
Power Cord
User Manual
DC Adapter
Audio Cable
VGA Signal Cable
Monitor
E
nglish
●
Don’t plug the power adapter into a non-grounding
power outlet.
▶ Matters that demand special attention are divided into ‘Warning’ and
‘Caution’, and are detailed a follows.
● Never touch the power plug with wet hands.
An electric shock accident may occur.
●
Don’t plug with other electrical cords into one power outlet.
An electric shock or fire accident may occur.
● Only use the adapter provided with the monitor.
An electric shock or fire accident may occur.
● Don’t use a power cord or plug that is frayed or damaged.
An electric shock or ignition may be caused.
● Insert the plug completely so that the power supply unit
can be connected tightly.
Unsafe power connection may cause a fire.
In case of the possibility that a serious injury or death
may occur during a violation of the instructions.
In case of the possibility that a slight injury or product
damage may occur during a violation of the instructions.
Instructions for Safety
E
nglish
● Grasp the power plug at the base to remove it from the
wall, and pull firmly but gently.
If you yank at the cord, the wire may be broken, causing
ignition or heat generation.
● Pull the power cord out when the monitor is not used for
a long time, or while you are away.
A dust covering may cause an electric shock, electric leakage,
or fire by heat generation, ignition, and insulation degradation.
● Select a cool, dry area and protect your monitor from
extremes in temperature, humidity, dust and smoke.
Accidents of electric shock, fire or failure may occur.
● Avoid direct sunlight or any other source of heat such
as a fireplace.
A fire or electric shock accident may be caused.
● Place the monitor at a proper distance (over 10 cm)
away from the wall for sufficient ventilation.
A fire may be caused due to an increase in internal temperature.
● Place the monitor in a well-ventilated room.
A fire may be caused due to an increase in internal temperature.
● Note that air-flow holes must not be blocked such as a
table cloth or curtain.
A fire may be caused due to an increase in internal temperature.
● Keep the power cord from proximity to a heating instrument.
The covering material of the cord may melt, causing a fire or
electric shock.
E
nglish
● Don’t block or obstruct the air-flow holes of the monitor.
A fire or damage of the monitor may be caused due to an
increase in internal temperature.
● Don’t spill liquids such as chemicals, water on the monitor.
A fire or electric shock accident may be caused.
● Never disassemble and repair the monitor but trained
repair engineers.
A fire or electric shock accident may be caused. If you need the
repair and adjustment, please contact the appropriate sales
agency or customer counsel window for check-ups.
● Don’t insert metals (such as coins, hair pins or ironware)
or flammable items (such as paper or matches) into the
monitor.
A fire or electric shock accident may be caused.
● Stop using in case of smoke or abnormal odors.
Immediately turn off the power and pull out the power
cord from the wall and then contact the service center.
Continuity of use in such a state may cause a fire or electric
shock.
● Don’t spray any liquids directly onto the monitor.
An electric shock or fire accident may occur.
● Clean the LCD panel with a soft material such as cotton
cloth after removing the power cord from the monitor.
A fire or electric shock accident may be caused.
E
nglish
● Turn off the monitor and disconnect all cables from the
monitor before moving the monitor.
● Be careful with the shock when moving the monitor.
● Place the monitor on a stable and secure surface.
Fall or displacement of the monitor may cause an injury.
● Don’t scratch or jolt the monitor surface.
Damage or failure of the panel may be caused.
● Often take a rest to protect your eyes when you work
for a long time.
● Take hold of the monitor with both hands setting the
panel forward.
If the monitor is dropped, contact the service center to check
it for a susceptibility to fire or electric shock.
● Don’t press upon the panel or scratch the surface with
your hands or sharp item such as a nail, pens.
Damage or failure of the panel may be caused.
● The fluorescent light of the monitor contains a mercury
which could be exploded. Don’t discard or bury the
monitor without permission of the law concerned.
