Agilent
2-Port and 4-Port
PNA-X Network Analyzer
N5249A - 10 MHz to 8.5 GHz
N5241A - 10 MHz to 13.5 GHz
N5242A - 10 MHz to 26.5 GHz
Data Sheet and
Technical Specifications
Documentation Warranty
THE MATERIAL CONTAINED IN THIS DOCUMENT IS PROVIDED "AS IS," AND IS SUBJECT TO BEING CHANGED,
WITHOUT NOTICE, IN FUTURE EDITIONS. FURTHER, TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW,
AGILENT DISCLAIMS ALL WARRANTIES, EITHER EXPRESS OR IMPLIED WITH REGARD TO THIS MANUAL AND ANY
INFORMATION CONTAINED HEREIN, INCLUDING BUT NOT LIMITED TO THE IMPLIED WARRANTIES OF
MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE. AGILENT SHALL NOT BE LIABLE FOR ERRORS OR
FOR INCIDENTAL OR CONSEQUENTIAL DAMAGES IN CONNECTION WITH THE FURNISHING, USE, OR PERFORMANCE
OF THIS DOCUMENT OR ANY INFORMATION CONTAINED HEREIN. SHOULD AGILENT AND THE USER HAVE A
SEPARATE WRITTEN AGREEMENT WITH WARRANTY TERMS COVERING THE MATERIAL IN THIS DOCUMENT THAT
CONFLICT WITH THESE TERMS, THE WARRANTY TERMS IN THE SEPARATE AGREEMENT WILL CONTROL.
DFARS/Restricted Rights Notice
If software is for use in the performance of a U.S. Government prime contract or subcontract, Software is delivered and
licensed as “Commercial computer software” as defined in DFAR 252.227-7014 (June 1995), or as a “commercial item”
as defined in FAR 2.101(a) or as “Restricted computer software” as defined in FAR 52.227-19 (June 1987) or any
equivalent agency regulation or contract clause. Use, duplication or disclosure of Software is subject to Agilent
Technologies’ standard commercial license terms, and non-DOD Departments and Agencies of the U.S. Government will
receive no greater than Restricted Rights as defined in FAR 52.227-19(c)(1-2) (June 1987). U.S. Government users will
receive no greater than Limited Rights as defined in FAR 52.227-14 (June 1987) or DFAR 252.227-7015 (b)(2) (November
1995), as applicable in any technical data.
2
Documentation Warranty ............................................................................................................................................. 2
DFARS/Restricted Rights Notice ................................................................................................................................ 2
Definitions ....................................................................................................................................................................... 6
Corrected System Performance ................................................................................................................................... 7
System Dynamic Range and Receiver Dynamic Range ........................................................ 7
Table 1. System Dynamic Range, Options 200 or 400, and Receiver Dynamic Range, All
Options ........................................................................................................................................ 8
Table 2a. System Dynamic Range at Test Port (dB), Options 200 or 400 ......................... 8
Table 2b. System Dynamic Range at Test Port (dB), Options 219 or 419 ......................... 9
Table 2c. System Dynamic Range at Test Port (dB), Option 224 ....................................... 9
Table 2d. System Dynamic Range at Test Port (dB), Options 224 or 423 ....................... 10
Table 3a. Extended Dynamic Range at Direct Receiver Access Input (dB) - Typical ... 10
Table 3b. Extended Dynamic Range at Direct Receiver Access Input (dB) - Typical ... 11
N5241A, N5242A, and N5249A Corrected System Performance with 3.5mm Connectors, All Opts ................ 12
Table 4. 85052B Calibration Kit ............................................................................................ 12
Table 5. N4433A 4-Port Electronic Calibration Module..................................................... 14
Table 6. N4691B 2-Port Electronic Calibration Module ..................................................... 16
Uncorrected System Performance ............................................................................................................................ 18
Table 7a. Directivity (dB) ....................................................................................................... 18
Table 7b. Source Match (dB) .................................................................................................. 19
Table 7c. Load Match (dB) ...................................................................................................... 19
Table 7d. Transmission Tracking, Reflection Tracking, Crosstalk (dB), All Options, All
Ports - Typical ........................................................................................................................... 20
Test Port Output ........................................................................................................................................................... 21
Table 8. Frequency Information, All Options ...................................................................... 21
Table 9a. Maximum Leveled Power (dBm), Options 200 or 400 ...................................... 21
Table 9b. Maximum Leveled Power (dBm), Options 219 or 419 ...................................... 22
Table 9c. Maximum Leveled Power (dBm), Option 219 or 419 with 0291 ...................... 22
Table 9d. Maximum Leveled Power (dB), Options 224 or 423 ......................................... 23
Table 9e. Maximum Leveled Power (dBm), Options 224 or 423, Combine Mode - Typical
.................................................................................................................................................... 23
Table 9f. Maximum Leveled Power (dBm), Option 224 ..................................................... 24
Table 9g. Maximum Leveled Power (dB), Options 224 or 423 with 0291 ........................ 24
Table 9h. Maximum Leveled Power (dBm), Options 224 or 423 with 0291, Combine
Mode - Typical .......................................................................................................................... 25
Table 10. Power Level Accuracy (dB) at Nominal Power1, All Options .......................... 25
Table 11a. Power Level Linearity1 (dB), All Options - Specification ............................... 26
Table 11b. Power Level Linearity1 (dB), All Options - Specification ............................... 26
Table 11c. Power Level Linearity1 (dB), Option 224 - Specification................................ 26
Table 12a. Power Sweep Range (dB), Options 200 or 400 ................................................ 27
3
Table 12b. Power Sweep Range (dB), Options 219 or 419 ................................................ 27
Table 12c. Power Sweep Range (dB), Options 219 or 419 with 0291 ............................... 28
Table 12d. Power Sweep Range (dB), Options 224 or 423 ................................................ 28
Table 12e. Power Sweep Range (dB), Option 224 ............................................................... 29
Table 12f. Power Sweep Range (dB), Options 224 or 423 with 0291 ............................... 29
Table 13. Nominal Power (Preset Power, dBm) .................................................................. 30
Table 14. Power Resolution and Maximum/Minimum Settable Power, All Ports1 ........ 30
Table 15. Harmonics at Max Specified Power (dBc), All Options - Typical.................... 30
Table 16. Non-Harmonic Spurs (dBc) at Nominal Power, All Options, All Ports - Typical
.................................................................................................................................................... 31
Table 17. Phase Noise (dBc/Hz), All Options, All Ports - Typical .................................... 31
Test Port Input .............................................................................................................................................................. 32
Table 18. Noise Floor1 (dBm) at 10 Hz IFBW, All Options, All Ports .............................. 32
Table 19. 0.1 dB Compression at Test Port (dBm), All Options, All Ports - Typical ..... 32
Table 20. Test Port Compression (dB) at 8 dBm Test Port Power, All Options, All Ports, -
Specification ............................................................................................................................. 32
Table 21a. Trace Noise1 Magnitude (dB rms), All Options, All Ports .............................. 33
Table 21b. Trace Noise1 Phase (deg rms), All Options, All Ports ..................................... 33
Table 22. Reference Level - Specification ............................................................................ 33
Table 23. Stability1 - Typical ................................................................................................... 34
Table 24. Damage Input Level - Specification ..................................................................... 34
Noise Receiver Input (Option 029 only).................................................................................................................... 35
Table 25. Noise Receiver Bandwidth ................................................................................... 35
Table 26. Receiver Noise Figure (dB), Port 2, at All BW, High Gain Setting ................. 35
Table 27. Noise Figure Trace Noise1 (dB rms) at 4 MHz BW ........................................... 35
Table 28. Noise Receiver Linearity (dB) at 4 MHz BW - Specification ........................... 36
Table 29. Noise Receiver Input Range - Specification ....................................................... 36
Dynamic Accuracy ....................................................................................................................................................... 37
Table 30. Dynamic Accuracy - Specification ....................................................................... 37
Table 31. Test Port Input (Group Delay)1............................................................................. 40
General Information ..................................................................................................................................................... 41
Table 32. Miscellaneous Information .................................................................................... 41
Table 33. Front Panel Information, All Options.................................................................. 41
Table 34. Rear Panel Information, All Options ................................................................... 42
Table 35. Analyzer Dimensions and Weight ........................................................................ 46
Regulatory and Environmental information ....................................................................... 46
Measurement Throughput Summary ........................................................................................................................ 47
Table 36a. Cycle Time (ms) for Measurement Completion, All Options - Typical ......... 47
Table 36b. Cycle Time (ms) for Full-Span Measurement Completion - Typical............. 48
4
Table 37. Cycle Time vs. IF Bandwidth - Typical ................................................................ 48
Table 38. Cycle Time vs. Number of Points ......................................................................... 49
Table 39. Data Transfer Time1 (ms) - Typical ...................................................................... 50
Specifications: Front-Panel Jumpers ....................................................................................................................... 51
Table 40. Measurement Receiver Inputs (dBm) - Typical ................................................. 51
Table 41a. Reference Receiver Inputs and Reference Source Outputs (dBm) - Typical51
Table 41b. Reference Receiver Inputs and Reference Source Outputs (dBm) - Typical52
Table 41c. Reference Receiver Inputs and Reference Source Outputs (dBm) - Typical52
Table 42a. Source Outputs (dBm) - Typical ......................................................................... 53
Table 42b. Source Outputs (dBm) - Typical ......................................................................... 53
Table 43. Coupler Inputs (dB) - Typical ............................................................................... 54
Table 44. Damage Level - Typical .......................................................................................... 54
Test Set Block Diagrams ............................................................................................................................................ 55
Figure 1. 2-Port N5241A, N5242A, and N5249A Base Unit Option 200 .......................... 55
Figure 2. 2-Port N5241A, N5242A, and N5249A Option 219 ............................................ 55
Figure 3. 2-Port N5241A, N5242A, and N5249A Option 224 ............................................ 56
Figure 4. 2-Port N5241A, N5242A, and N5249A Option 224 with 029 ............................ 56
Figure 5. 4-Port N5241A, N5242A, and N5249A Base Unit Option 400 .......................... 57
Figure 6. 4-Port N5241A, N5242A, and N5249A Option 419 ............................................ 57
Figure 7. 4-Port N5241A, N5242A, and N5249A Option 423 ............................................ 58
Figure 8. 4-Port N5241A, N5242A, and N5249A Option 423 with 029 ............................ 58
Figure 9. Receiver Block Diagram ......................................................................................... 59
5
This is a complete list of the technical specifications for the N5241A, N5242A, and N5249A with the following
Notes
Specifications for the N5241AS, N5242AS, and N5249AS Option H85, when configured in standard configuration,
are the same as those of closest N5241A, N5242A, and N5249A option configuration.
The Corrected System Performance with Cal Kits and Dynamic Accuracy Charts apply ONLY N5241A, N5242A, and
N5249A models with serial numbers starting with MY5241/42/49, SG5241/42/49, and US5241/42/49, and above.
This document provides technical specifications only for the 85052B calibration kit, the N4433A 4-Port ECal module,
and the N4691B 2-Port ECal module. Please download our free Uncertainty Calculator from
http://www.agilent.com/find/na_calculator to generate the curves for your calibration kit and PNA setup.
For all tables in this data sheet, the specified performance at the exact frequency of a break is the degraded value
of the two specifications at that frequency.
options:
Option 029, adds hardware and firmware for high-accuracy noise figure measurements. It requires one of option 219,
224, 419, or 423. See the block diagram.
Option 200, 2-port standard test set (includes six front-panel access loops) and power range. See the block diagram.
Option 219, adds 2-port extended power range, source and receiver attenuators, and bias-tees (requires Option 200). See
the block diagram.
Option 224, adds an internal second source, a combiner, and mechanical switches to the 2-port analyzer (requires
Option 200, 219, and 080). See the block diagram.
Option 400, 4-port standard test set (includes twelve front-panel access loops), power range, and an internal second
source (Option 080 recommended). See the block diagram.
Option 419, adds 4-port extended power range, source and receiver attenuators, and bias-tees (requires Option 400). See
the block diagram.
Option 423, adds an internal combiner, and mechanical switches to the 4-port analyzer (requires Option 400, 419, and
080). See the block diagram.
Definitions
All specifications and characteristics apply over a 25 °C ±5 °C range (unless otherwise stated) and 90 minutes after the
instrument has been turned on.
Specification (spec.): Warranted performance. Specifications include guardbands to account for the expected statistical
performance distribution, measurement uncertainties, and changes in performance due to environmental conditions.
Characteristic (char.): A performance parameter that the product is expected to meet before it leaves the factory, but
that is not verified in the field and is not covered by the product warranty. A characteristic includes the same
guardbands as a specification.
Typical (typ.): Expected performance of an average unit which does not include guardbands. It is not covered by the
product warranty.
Nominal (nom.): A general, descriptive term that does not imply a level of performance. It is not covered by the product
warranty.
Calibration: The process of measuring known standards to characterize a network analyzer's systematic (repeatable)
errors.
Corrected (residual): Indicates performance after error correction (calibration). It is determined by the quality of
calibration standards and how well "known" they are, plus system repeatability, stability, and noise.
Uncorrected (raw): Indicates instrument performance without error correction. The uncorrected performance affects
the stability of a calibration.
Standard: When referring to the analyzer, this includes no options unless noted otherwise.
6
Corrected System Performance
The specifications in this section apply for measurements made with the N5241A, N5242A, and N5249A analyzer with
the following conditions:
10 Hz IF bandwidth
No averaging applied to data
Isolation calibration with an averaging factor of 8
Source in filtered mode where applicable
System Dynamic Range and Receiver Dynamic Range
System Dynamic Range is defined as the max leveled output power (spec) minus the noise floor (spec).
Extended Dynamic Range at Direct Access Input is defined as the specified source maximum output power
(typical) minus the direct receiver access input noise floor (typical).
Receiver Dynamic Range is defined as the test port compression at 0.1 dB (typical) minus the noise floor (typical).
Note
The effective dynamic range must take measurement uncertainties and interfering signals into account.
The direct receiver access input extended dynamic range is calculated as the difference between the direct receiver
access input noise floor and the source maximum output power. This set-up should only be used when the receiver
input will never exceed its maximum receiver input. When the analyzer is in segment sweep mode, it can have
predefined frequency segments which will output a higher power level when the extended dynamic range is required
(i.e. devices with high insertion loss), and reduced power when the maximum receiver input level will occur (i.e. devices
with low insertion loss). The extended range is only available in one-path transmission measurements.
It may typically be degraded at particular frequencies below 500 MHz due to spurious receiver residuals.
7
Table 1. System Dynamic Range, Options 200 or 400, and Receiver Dynamic Range, All Options
Description
Specification, Options 200, 400
Typical, All Options
System
Dynamic
Range (dB)
(A)-(B)
Max Leveled
Output
Power
(dBm)
(A)
Test Port
Noise
Floor
(dBm)
(B)
Receiver
Dynamic
Range (dB)
(C)-(D)
Test Port
Compression
at 0.1 dB
(dBm)
(C)
Test Port
Noise
Floor
(dBm)
(D)
Ports 1,31
Ports 1,31
All Ports
All Ports
All Ports
All Ports
10 MHz to 50 MHz
93
13
-80
--
--
-87
50 MHz to 100 MHz
103
13
-90
--
--
-95
100 MHz to 500 MHz
117
13
-104
125
15
-110
500 MHz to 3.2 GHz
124
10
-114
130
13
-117
3.2 GHz to 8.5 GHz
127
13
-114
130
13
-117
8.5 GHz to 13.5 GHz
127
13
-114
130
13
-117
13.5 GHz to 16 GHz
127
13
-114
130
13
-117
16 GHz to 20 GHz
127
13
-114
129
12
-117
20 GHz to 24 GHz
122
12
-110
125.5
10.5
-115
24 GHz to 26.5 GHz
112
5
-107
123
10
-113
Description
Specification
Typical
Ports 1, 31
Ports 2, 41
Ports 1, 31
Ports 2, 41
10 MHz to 50 MHz
93
93
106
104
50 MHz to 100 MHz
103
103
116
115
100 MHz to 500 MHz
117
117
131
130
500 MHz to 3.2 GHz
124
127
130
135
3.2 GHz to 8.5 GHz
127
127
137
136
8.5 GHz to 10 GHz
127
127
137
136
10 GHz to 13.5 GHz
127
127
134
133
13.5 GHz to 16 GHz
127
127
134
133
16 GHz to 20 GHz
127
124
133
129
20 GHz to 24 GHz
122
117
130
126
24 GHz to 26.5 GHz
112
109
124
120
1
Either port can be used as the source port. Any other port can be used as the receiver port.
Table 2a. System Dynamic Range at Test Port (dB), Options 200 or 400
1
Either port can be used as the source port. Any other port can be used as the receiver port.
8
Table 2b. System Dynamic Range at Test Port (dB), Options 219 or 419
Description
Specification
Typical
Ports 1, 31
Ports 2, 41
Ports 1, 31
Ports 2, 41
10 MHz to 50 MHz
93
93
106
104
50 MHz to 100 MHz
103
103
115
114
100 MHz to 500 MHz
117
117
130
129
500 MHz to 3.2 GHz
124
127
130
135
3.2 GHz to 8.5 GHz
127
127
135
134
8.5 GHz to 10 GHz
127
127
135
134
10 GHz to 13.5 GHz
126
125
132
131
13.5 GHz to 16 GHz
126
125
132
131
16 GHz to 20 GHz
124
122
130
127
20 GHz to 24 GHz
118
117
127
124
24 GHz to 26.5 GHz
110
106
121
117
Description
Specification
Typical
Source 2 Out 1
Source 2 Out 2
Source 2 Out 1
Source 2 Out 2
10 MHz to 50 MHz
98
93
108
105
50 MHz to 100 MHz
108
107
117
116
100 MHz to 500 MHz
122
121
132
131
500 MHz to 3.2 GHz
128
128
134
136
3.2 GHz to 8.5 GHz
132
132
139
139
8.5 GHz to 10 GHz
132
132
139
139
10 GHz to 13.5 GHz
130
130
138
137
13.5 GHz to 16 GHz
130
130
138
137
16 GHz to 20 GHz
129
127
136
134
20 GHz to 24 GHz
123
122
133
132
24 GHz to 26.5 GHz
114
112
127
124
1
Either port can be used as the source port. Any other port can be used as the receiver port.
Table 2c. System Dynamic Range at Test Port (dB), Option 224
9
Table 2d. System Dynamic Range at Test Port (dB), Options 224 or 423
Description
Specification
Typical
Ports
1, 31
Ports
2, 41
Ports
1, 31
Ports
2, 41
Source 1 Port 1
Combine Mode
Source 2 Port 1
Combine Mode
10 MHz to 50 MHz
93
93
106
104
104
80
50 MHz to 100 MHz
103
103
115
115
112
90
100 MHz to 500 MHz
117
117
130
130
121
99
500 MHz to 3.2 GHz
124
127
130
134
127
112
3.2 GHz to 8.5 GHz
127
127
136
134
132
119
8.5 GHz to 10 GHz
127
127
136
134
132
119
10 GHz to 13.5 GHz
126
124
132
131
128
115
13.5 GHz to 16 GHz
126
124
132
131
128
115
16 GHz to 20 GHz
124
121
130
127
125
113
20 GHz to 24 GHz
117
115
127
124
121
109
24 GHz to 26.5 GHz
107
105
121
117
115
102
Description
Options 200, 400
Options 219, 419
Ports 1, 31
Ports 2, 41
Ports 1, 31
Ports 2, 41
10 MHz to 50 MHz
128
128
128
128
50 MHz to 100 MHz
115
115
115
115
100 MHz to 500MHz
129
129
129
129
500 MHz to 3.2 GHz
136
139
136
139
3.2 GHz to 8.5 GHz
139
139
139
139
8.5 GHz to 10 GHz
139
139
139
139
10 GHz to 13.5 GHz
139
139
138
137
13.5 GHz to 16 GHz
139
139
138
137
16 GHz to 20 GHz
139
136
136
134
20 GHz to 24 GHz
134
129
130
129
24 GHz to 26.5 GHz
124
121
122
118
1
Either port can be used as the source port. Any other port can be used as the receiver port.
Table 3a. Extended Dynamic Range at Direct Receiver Access Input (dB) - Typical
1
Either port can be used as the source port. Any other port can be used as the receiver port.
10
Table 3b. Extended Dynamic Range at Direct Receiver Access Input (dB) - Typical
Description
Option 224
Options 224, 423
Source 2
Out 1
Source 2
Out 2
Ports 1, 31
Ports 2, 41
Source 1
Port 1
Combine
Mode
Source 2
Port 1
Combine
Mode
10 MHz to 50 MHz
133
128
128
128
139
115
50 MHz to 100 MHz
120
119
115
115
124
102
100 MHz to 500MHz
134
133
129
129
133
111
500 MHz to 3.2 GHz
140
140
136
139
139
124
3.2 GHz to 8.5 GHz
144
144
139
139
144
131
8.5 GHz to 10 GHz
144
144
139
139
144
131
10 GHz to 13.5 GHz
142
142
138
136
140
127
13.5 GHz to 16 GHz
142
142
138
136
140
127
16 GHz to 20 GHz
141
139
136
133
137
125
20 GHz to 24 GHz
135
134
129
127
133
121
24 GHz to 26.5 GHz
126
124
119
121
127
114
1
Either port can be used as the source port. Any other port can be used as the receiver port.
11
N5241A, N5242A, and N5249A Corrected System Performance with 3.5mm Connectors, All Opts
Description
Specification (dB)
10 MHz to
50 MHz
50 MHz to
500 MHz
500 MHz to
2 GHz
2 GHz to
8.5 GHz
8.5 GHz to
13.5 GHz
13.5 GHz to
20 GHz
20 GHz to
26.5 GHz
Directivity
48
48
48
44
44
44
44
Source Match
40
40
40
31
31
31
31
Load Match
48
48
48
44
44
44
44
Reflection Tracking1
Mag
±0.003
±0.003
±0.003
±0.006
±0.006
±0.006
±0.006
Phase (°)
±0.020
±0.020
±0.020
±0.040
±0.040
±0.040
±0.040
Transmission Tracking without Option 029
Mag
±0.034
±0.034
±0.017
±0.091
±0.091
±0.104
±0.119
Phase (°)
±0.225
±0.225
±0.110
±0.602
±0.602
±0.688
±0.788
S21 Transmission Tracking with Option 0291
Mag
±0.034
±0.034
±0.017
±0.091
±0.091
±0.104
±0.119
Phase (°)
±0.225
±0.225
±0.110
±0.602
±0.602
±0.688
±0.788
S12 Transmission Tracking with Option 0291
Mag
±0.017
±0.017
±0.017
±0.091
±0.091
±0.104
±0.119
Phase (°)
±0.110
±0.110
±0.110
±0.602
±0.602
±0.688
±0.788
Note: For any Sii reflection measurement:
Sjj = 0.
For any Sij transmission measurement:
Sji = Sij when Sij 1
Sji = 1/Sij when Sij 1
Skk = 0 for all k
Applies to the N5241A, N5242A, and N5249A Option 200 or 219 or 224 or 400 or 419 or 423 analyzers with serial
numbers listed below, 85131F flexible test port cable set, and a full 2-port calibration.
N5241A and N5241AS: MY5241/SG5241/US5241 and above
N5242A and N5242AS: MY5242/SG5242/US5242 and above
Also applies to the following condition: Environmental temperature 23° ±3 °C, with < 1 °C deviation from calibration
temperature. This document does not present specifications for the 85052C or 85052D Calibration Kit. The uncertainty
charts were generated for Option 423, although they are applicable for any option without Option 029. Please download
our free Uncertainty Calculator from http://www.agilent.com/find/na_calculator to generate the curves for your
calibration kit and PNA setup.
Table 4. 85052B Calibration Kit
The port 1 noise tuner switch set to the bypass position, and port 2 noise receiver switch set to the normal position.
12
Transmission Uncertainty
Reflection Uncertainty
13
Table 5. N4433A 4-Port Electronic Calibration Module
Description
Specification (dB)
10 MHz to
50 MHz
50 MHz to
500 MHz
500 MHz to
2 GHz
2 GHz to
8.5 GHz
8.5 GHz to
13.5 GHz
13.5 GHz to
20 GHz
Directivity
50
50
50
45
45
40
Source
Match
42
42
42
37
37
31
Load Match
40
41
41
35
35
29
Reflection Tracking1
Mag
±0.060
±0.060
±0.060
±0.100
±0.100
±0.180
Phase (°)
±0.396
±0.396
±0.396
±0.660
±0.660
±1.188
Transmission Tracking without Option 029
Mag
±0.068
±0.064
±0.064
±0.115
±0.115
±0.210
Phase (°)
±0.447
±0.421
±0.421
±0.761
±0.761
±1.387
S21 Transmission Tracking with Option 0291
Mag
±0.070
±0.066
±0.070
±0.126
±0.126
±0.225
Phase (°)
±0.460
±0.436
±0.460
±0.829
±0.829
±1.485
S12 Transmission Tracking with Option 0291
Mag
±0.082
±0.071
±0.072
±0.123
±0.123
±0.227
Phase (°)
±0.541
±0.469
±0.472
±0.812
±0.812
±1.496
Note: Uncertainty curves for the N4433A are created using a 2-port calibration. Multiport uncertainties are not
supported at this time.
The port 1 noise tuner switch set to the bypass position, and port 2 noise receiver switch set to the normal position.
14
Transmission Uncertainty
Reflection Uncertainty
15
Table 6. N4691B 2-Port Electronic Calibration Module
Description
Specification (dB)
10 MHz to
50 MHz
50 MHz to
500 MHz
500 MHz to
2 GHz
2 GHz to
8.5 GHz
8.5 GHz to
13.5 GHz
13.5 GHz to
20 GHz
20 GHz to
26.5 GHz
Directivity
46
46
52
46
46
46
44
Source
Match
41
41
47
42
42
42
40
Load Match
40
40
46
41
41
40
38
Reflection Tracking
Mag
±0.050
±0.050
±0.020
±0.040
±0.040
±0.040
±0.050
Phase (°)
±0.330
±0.330
±0.132
±0.264
±0.264
±0.264
±0.330
Transmission Tracking without Option 029
Mag
±0.062
±0.056
±0.023
±0.054
±0.054
±0.055
±0.072
Phase (°)
±0.410
±0.370
±0.152
±0.354
±0.354
±0.365
±0.473
S21 Transmission Tracking with Option 0291
Mag
±0.065
±0.060
±0.028
±0.063
±0.063
±0.063
±0.079
Phase (°)
±0.431
±0.394
±0.183
±0.416
±0.416
±0.416
±0.521
S12 Transmission Tracking with Option 0291
Mag
±0.085
±0.068
±0.029
±0.061
±0.061
±0.064
±0.078
Phase (°)
±0.559
±0.446
±0.193
±0.400
±0.400
±0.421
±0.517
The port 1 noise tuner switch set to the bypass position, and port 2 noise receiver switch set to the normal position.
16
Transmission Uncertainty
Reflection Uncertainty
17
Uncorrected System Performance
Description
Specification
Typical
Options
200, 219, 224, 400,
419, 423
Option 029
Options
200, 219, 224, 400,
419, 423
Option 029
All Ports
Ports 1, 2
All Ports
Ports 1, 2
10 MHz to 50 MHz
16
16
23
22
50 MHz to 500 MHz
24
24
28
28
500 MHz to 3.2 GHz
24
24
32
32
3.2 GHz to 8.5 GHz
23
23
25
25
8.5 GHz to 10 GHz
23
23
25
25
10 GHz to 13.5 GHz
16
16
22
20
13.5 GHz to 16 GHz
16
16
22
20
16 GHz to 20 GHz
16
15
22
20
20 GHz to 24 GHz
16
15
22
20
24 GHz to 26.5 GHz
16
15
22
20
Specifications apply to following conditions:
Over environmental temperature of 25 °C ±5 °C, with less than 1°C variation from the calibration temperature.
Cable loss not included in Transmission Tracking.
Crosstalk measurement conditions: normalized to a thru, measured with shorts on all ports, 10 Hz IF
bandwidth, averaging factor of 8, alternate mode, source power set to the specified maximum power.
With option 029, port 1 impedance tuner switch is in external position and port 2 noise receiver switch is in
noise receiver position unless specified. Refer to Options 200, 219, 224, 400, 419, 423 for performance of Option
029 Port 1 with impedance tuner switch in internal position, Port 2 noise receiver switch in normal position,
Ports 3 and 4.
Table 7a. Directivity (dB)
18
Table 7b. Source Match (dB)
Description
Specification
Typical
Options
200, 219,
224, 400,
419, 423
Option 029
Options
200, 219,
224, 400,
419, 423
Option 029
All Ports
Port 1
Port 2
All Ports
Port 1
Port 2
10 MHz to 50 MHz
11 9 9
14
13
12
50 MHz to 500 MHz
18
18
13
28
28
15
500 MHz to 3.2 GHz
18
17 9 22
22
12
3.2 GHz to 8.5 GHz
14
12 6 18
18
7
8.5 GHz to 10 GHz
14
12 6 18
18
7
10 GHz to 13.5 GHz
12
11 6 16
16
8
13.5 GHz to 16 GHz
12
11 6 16
16
8
16 GHz to 20 GHz
10 9 7
15
13
9
20 GHz to 24 GHz
10 8 6
14
13
9
24 GHz to 26.5 GHz
8 7 6
12
12
9
Description
Specification
Typical
Options
200, 219,
224, 400,
419, 423
Option 029
Options
200, 219,
224, 400,
419, 423
Option 029
All Ports
Port 1
Port 2
All Ports
Port 1
Port 2
10 MHz to 50 MHz
11
11 9 18
18
12
50 MHz to 500 MHz
17
17
13
25
24
15
500 MHz to 3.2 GHz
17
15 9 22
19
12
3.2 GHz to 8.5 GHz
13
10
5.5
17
15
7.5
8.5 GHz to 10 GHz
13
10
5.5
17
15
7.5
10 GHz to 13.5 GHz
10 9 5.5
15
15
7.5
13.5 GHz to 16 GHz
10 9 5.5
15
15
7.5
16 GHz to 20 GHz
9 8 5.5
14
13
7.5
20 GHz to 24 GHz
9 7 5.5
14
13
7.5
24 GHz to 26.5 GHz
8 7 5.5
13
11
7.5
Table 7c. Load Match (dB)
19
Table 7d. Transmission Tracking, Reflection Tracking, Crosstalk (dB), All Options, All Ports - Typical
Transmission Tracking
Reflection Tracking
Crosstalk
10 MHz to 50 MHz
+/-1.5
+/-1.5
-84
50 MHz to 100 MHz
+/-1.5
+/-1.5
-90
100 MHz to 500 MHz
+/-1.5
+/-1.5
-110
500 MHz to 3.2 GHz
+/-1.5
+/-1.5
-120
3.2 GHz to 8.5 GHz
+/-1.5
+/-1.5
-122
8.5 GHz to 13.5 GHz
+/-1.5
+/-1.5
-122
13.5 GHz to 20 GHz
+/-1.5
+/-1.5
-122
20 GHz to 24 GHz
+/-1.5
+/-1.5
-117
24 GHz to 26.5 GHz
+/-1.5
+/-1.5
-114
20
Test Port Output
Description
Specification (dB)
Typical (dB)
N5249A Frequency Range
10 MHz to 8.5 GHz
--
N5241A Frequency Range
10 MHz to 13.5 GHz
--
N5242A Frequency Range
10 MHz to 26.5 GHz
--
Frequency Resolution
1 Hz
--
Frequency Accuracy
+/- 1 ppm
--
Frequency Stability
--
+/-0.05 ppm, -10° to 70° C1
+/-0.1 ppm/yr maximum2
Description
Specification
Typical
Ports 1, 31
Ports 2, 41
Ports 1, 31
Ports 2, 41
Filtered
Mode2
Hi Power
Mode2
Filtered
Mode2
Hi Power
Mode2
10 MHz to 50 MHz
8
13
13
10
19
17
50 MHz to 500 MHz
10
13
13
11
21
20
500 MHz to 3.2 GHz
10
10
13
12
13
18
3.2 GHz to 8.5 GHz
13
13
13
20
20
19
8.5 GHz to 10 GHz
13
13
13
20
20
19
10 GHz to 13.5 GHz
13
13
13
17
17
16
13.5 GHz to 16 GHz
13
13
13
17
17
16
16 GHz to 20 GHz
13
13
10
16
16
12
20 GHz to 24 GHz
12
12 7 15
15
11
24 GHz to 26.5 GHz
5 5 2
11
11
7
See Block diagrams for all models and options beginning on page 59.
With option 029, port 1 noise tuner switch is in internal position and port 2 noise receiver switch is in normal position
unless specified.
Table 8. Frequency Information, All Options
1
Assumes no variation in time.
2
Assumes no variation in temperature.
Table 9a. Maximum Leveled Power (dBm), Options 200 or 400
1
Either port can be used as the source port.
2
In Filtered Mode, the signal path goes through filters to minimize harmonics below 3.2 GHz. In Hi Power Mode, the
signal bypasses the filters to maximize output power.
21
Table 9b. Maximum Leveled Power (dBm), Options 219 or 419
Description
Specification
Typical
Ports 1, 31
Ports 2, 41
Ports 1, 31
Ports 2, 41
Filt. Mode2
Hi Pwr Mode2
Filt. Mode2
Hi Pwr Mode2
10 MHz to 50 MHz
8
13
13
10
19
17
50 MHz to 500 MHz
10
13
13
11
20
19
500 MHz to 3.2 GHz
10
10
13
11
13
18
3.2 GHz to 8.5 GHz
13
13
13
18
18
17
8.5 GHz to 10 GHz
13
13
13
18
18
17
10 GHz to 13.5 GHz
12
12
11
15
15
14
13.5 GHz to 16 GHz
12
12
11
15
15
14
16 GHz to 20 GHz
10
10 8 13
13
10
20 GHz to 24 GHz
8 8 7
12
12
9
24 GHz to 26.5 GHz
3 3 -1 8 8
4
Description
Specification
Typical
Port 1
Port 2
Port 1
Port 2
Filt. Mode2
Hi Pwr Mode2
Filt. Mode2
Hi Pwr Mode2
10 MHz to 50 MHz
7
12
13 9 18
17
50 MHz to 500 MHz
9
12
13
10
19
19
500 MHz to 3.2 GHz
9 9 13
10
12
18
3.2 GHz to 8.5 GHz
12
12
13
17
17
17
8.5 GHz to 10 GHz
12
12
13
17
17
17
10 GHz to 13.5 GHz
12
12 9 15
15
12
13.5 GHz to 16 GHz
12
12 9 15
15
12
16 GHz to 20 GHz
10
10 5 13
13
7
20 GHz to 24 GHz
8 8 2
12
12
4
24 GHz to 26.5 GHz
3 3 -2 8 8
3
1
Either port can be used as the source port.
2
In Filtered Mode, the signal path goes through filters to minimize harmonics below 3.2 GHz. In Hi Power Mode, the
signal bypasses the filters to maximize output power.
Table 9c. Maximum Leveled Power (dBm), Option 219 or 419 with 0291
1
Option 029 affects port 1 and port 2 maximum leveled power. Refer to Table 9b for other ports.
2
In Filtered Mode, the signal path goes through filters to minimize harmonics below 3.2 GHz. In Hi Power Mode, the
signal bypasses the filters to maximize output power.
22
Table 9d. Maximum Leveled Power (dB), Options 224 or 423
Description
Specification
Typical
Ports 1, 31
Ports 2, 41
Ports 1, 31
Ports 2, 41
Filtered
Mode2
Hi Power
Mode2
Filtered
Mode2
Hi Power
Mode2
10 MHz to 50 MHz
7
13
13 9 19
17
50 MHz to 500 MHz
8
13
13
11
20
20
500 MHz to 3.2 GHz
8
10
13
11
13
17
3.2 GHz to 8.5 GHz
13
13
13
19
19
17
8.5 GHz to 10 GHz
13
13
13
19
19
17
10 GHz to 13.5 GHz
12
12
10
15
15
14
13.5 GHz to 16 GHz
12
12
10
15
15
14
16 GHz to 20 GHz
10
10 7 13
13
10
20 GHz to 24 GHz
7 7 5
12
12
9
24 GHz to 26.5 GHz
0 0 -2 8 8
4
Description
Source 1 Port 1
Source 2 Port 1
Filtered Mode1
Hi Power Mode1
Filtered Mode1
Hi Power Mode1
10 MHz to 50 MHz
7
17
-7
3
50 MHz to 500 MHz
9
17
-5
4
500 MHz to 3.2 GHz
9
10
-5
-4
3.2 GHz to 8.5 GHz
15
15 2 2
8.5 GHz to 10 GHz
15
15 2 2
10 GHz to 13.5 GHz
11
11
-2
-2
13.5 GHz to 16 GHz
11
11
-2
-2
16 GHz to 20 GHz
8 8 -4
-4
20 GHz to 24 GHz
6 6 -6
-6
24 GHz to 26.5 GHz
2 2 -11
-11
1
Either port can be used as the source port.
2
In Filtered Mode, the signal path goes through filters to minimize harmonics below 3.2 GHz. In Hi Power Mode, the
signal bypasses the filters to maximize output power.
Table 9e. Maximum Leveled Power (dBm), Options 224 or 423, Combine Mode - Typical
1
In Filtered Mode, the signal path goes through filters to minimize harmonics below 3.2 GHz. In Hi Power Mode, the
signal bypasses the filters to maximize output power.
23
Table 9f. Maximum Leveled Power (dBm), Option 224
Description
Specification
Typical
Source 2 Out 1
Source 2
Out 2
Source 2 Out 1
Source 2
Out 2
Filt. Mode2
Hi Pwr Mode2
Filt. Mode2
Hi Pwr Mode2
10 MHz to 50 MHz
9
18
13
12
21
18
50 MHz to 500 MHz
11
18
17
13
22
21
500 MHz to 3.2 GHz
10
14
14
13
17
19
3.2 GHz to 8.5 GHz
18
18
18
22
22
22
8.5 GHz to 10 GHz
18
18
18
22
22
22
10 GHz to 13.5 GHz
16
16
16
21
21
20
13.5 GHz to 16 GHz
16
16
16
21
21
20
16 GHz to 20 GHz
15
15
13
19
19
17
20 GHz to 24 GHz
13
13
12
18
18
17
24 GHz to 26.5 GHz
7 7 5
14
14
11
Description
Specification
Typical
Port 1
Ports 2
Port 1
Ports 2
Filt. Mode2
Hi Pwr Mode2
Filt. Mode2
Hi Pwr Mode2
10 MHz to 50 MHz
6
12
13 8 18
17
50 MHz to 500 MHz
8
13
13
11
20
20
500 MHz to 3.2 GHz
8
10
12
11
13
16
3.2 GHz to 8.5 GHz
13
13
13
19
19
17
8.5 GHz to 10 GHz
13
13
13
19
19
17
10 GHz to 13.5 GHz
12
12
10
15
15
14
13.5 GHz to 16 GHz
12
12
10
15
15
14
16 GHz to 20 GHz
10
10 6 13
13
9
20 GHz to 24 GHz
6 6 4
11
11
8
24 GHz to 26.5 GHz
0 0 -2 8 8
4
1
In Filtered Mode, the signal path goes through filters to minimize harmonics below 3.2 GHz. In Hi Power Mode, the
signal bypasses the filters to maximize output power.
Table 9g. Maximum Leveled Power (dB), Options 224 or 423 with 0291
1
Option 029 affects port 1 and port 2 maximum leveled power. Refer to Table 9c for other ports.
2
In Filtered Mode, the signal path goes through filters to minimize harmonics below 3.2 GHz. In Hi Power Mode, the
signal bypasses the filters to maximize output power.
24
Table 9h. Maximum Leveled Power (dBm), Options 224 or 423 with 0291, Combine Mode - Typical
Description
Source 1 Port 1
Source 2 Port 1
Filtered Mode2
Hi Power Mode2
Filtered Mode2
Hi Power Mode2
10 MHz to 50 MHz
6
16
-8
2
50 MHz to 500 MHz
9
17
-5
4
500 MHz to 3.2 GHz
9
10
-5
-4
3.2 GHz to 8.5 GHz
15
15 2 2
8.5 GHz to 10 GHz
15
15 2 2
10 GHz to 13.5 GHz
11
11
-2
-2
13.5 GHz to 16 GHz
11
11
-2
-2
16 GHz to 20 GHz
8 8 -4
-4
20 GHz to 24 GHz
5 5 -7
-7
24 GHz to 26.5 GHz
0 0 -11
-11
Description
Specification
Typical
Ports 1, 2, 3, 42
Source 2 Out 1
Source 2 Out 2
Ports 1, 2, 3, 42
Source 2 Out 1
Source 2 Out 2
10 MHz to 50 MHz
+/-1.0
+/-2.0
+/-0.40
+/-0.55
50 MHz to 500 MHz
+/-1.0
+/-2.0
+/-0.20
+/-0.25
500 MHz to 3.2 GHz
+/-1.0
+/-2.0
+/-0.25
+/-0.25
3.2 GHz to 8.5 GHz
+/-1.0
+/-2.0
+/-0.40
+/-0.25
8.5 GHz to 10 GHz
+/-1.0
+/-2.0
+/-0.40
+/-0.25
10 GHz to 13.5 GHz
+/-1.2
+/-2.0
+/-0.60
+/-0.25
13.5 GHz to 18 GHz
+/-2.0
+/-2.5
+/-0.60
+/-1.00
18 GHz to 26.5 GHz
+/-2.5
+/-2.5
+/-0.80
+/-0.90
1
Option 029 affects port 1 and port 2 maximum leveled power.
2
In Filtered Mode, the signal path goes through filters to minimize harmonics below 3.2 GHz. In Hi Power Mode, the
signal bypasses the filters to maximize output power.
Table 10. Power Level Accuracy (dB) at Nominal Power1, All Options
1
Level accuracy at power other than nominal power, Power Level Accuracy (dB) at Nominal Power + Power Level
Linearity (dB)
2
Any port can be used as the source port. Source in filtered mode where applicable.
25
Table 11a. Power Level Linearity1 (dB), All Options - Specification
Description
Ports 1, 32
-25 dBm ≤ P <-20 dBm
Ports 1, 32
-20 dBm ≤ P <-15 dBm
Ports 1, 32
P ≥-15 dBm
10 MHz to 50 MHz
+/-2.0
+/-1.5
+/-1.0
50 MHz to 500 MHz
+/-1.5
+/-1.0
+/-1.0
500 MHz to 8.5 GHz
+/-1.0
+/-1.0
+/-1.0
8.5 GHz to 13.5 GHz
+/-1.0
+/-1.0
+/-1.0
13.5 GHz to 26.5 GHz
+/-1.0
+/-1.0
+/-1.0
Description
Ports 2, 42
-25 dBm ≤ P <-20 dBm
Ports 2, 42
-20 dBm ≤ P <-15 dBm
Ports 2, 42
P ≥-15 dBm
10 MHz to 50 MHz
+/-5.0
+/-2.0
+/-1.5
50 MHz to 500 MHz
+/-4.0
+/-2.0
+/-1.5
500 MHz to 3.2 GHz
+/-2.5
+/-1.0
+/-1.0
3.2 GHz to 8.5 GHz
+/-2.0
+/-1.0
+/-1.0
8.5 GHz to 10 GHz
+/-2.0
+/-1.0
+/-1.0
10 GHz to 13.5 GHz
+/-1.5
+/-1.5
+/-1.5
13.5 GHz to 16 GHz
+/-1.5
+/-1.5
+/-1.5
16 GHz to 26.5 GHz
+/-1.0
+/-1.0
+/-1.0
Description
Source 2 Out 12
P ≥-15 dBm
Source 2 Out 2
-15 dBm ≤ P <-10 dBm
Source 2 Out 2
P ≥-10 dBm
10 MHz to 500 MHz
+/-1.0
+/-1.5
+/-1.0
500 MHz to 8.5 GHz
+/-1.0
+/-1.0
+/-1.0
8.5 GHz to 13.5 GHz
+/-1.0
+/-1.0
+/-1.0
13.5 GHz to 26.5 GHz
+/-1.0
+/-1.0
+/-1.0
1
Referenced to nominal power.
2
Either port can be used as the source port. Source in filtered mode.
Table 11b. Power Level Linearity1 (dB), All Options - Specification
1
Referenced to nominal power.
2
Either port can be used as the source port.
Table 11c. Power Level Linearity1 (dB), Option 224 - Specification
1
Referenced to nominal power.
2
Source in filtered mode.
26
Table 12a. Power Sweep Range (dB), Options 200 or 400
Description
Specification
Typical
Ports 1, 31
Ports 2, 41
Ports 1, 31
Ports 2, 41
10 MHz to 50 MHz
33
38
46
44
50 MHz to 500 MHz
35
38
48
47
500 MHz to 3.2 GHz
35
38
40
45
3.2 GHz to 8.5 GHz
38
38
47
46
8.5 GHz to 10 GHz
38
38
47
46
10 GHz to 13.5 GHz
38
38
44
43
13.5 GHz to 16 GHz
38
38
44
43
16 GHz to 20 GHz
38
35
43
39
20 GHz to 24 GHz
37
32
42
38
24 GHz to 26.5 GHz
30
27
38
34
Description
Specification
Typical
Ports 1, 31
Ports 2, 41
Ports 1, 31
Ports 2, 41
10 MHz to 50 MHz
33
38
46
44
50 MHz to 500 MHz
35
38
47
46
500 MHz to 3.2 GHz
35
38
40
45
3.2 GHz to 8.5 GHz
38
38
45
44
8.5 GHz to 10 GHz
38
38
45
44
10 GHz to 13.5 GHz
37
36
42
41
13.5 GHz to 16 GHz
37
36
42
41
16 GHz to 20 GHz
35
33
40
37
20 GHz to 24 GHz
33
32
39
36
24 GHz to 26.5 GHz
28
24
35
31
1
Either port can be used as the source port. Source in filtered mode where applicable.
Table 12b. Power Sweep Range (dB), Options 219 or 419
1
Either port can be used as the source port. Source in filtered mode where applicable.
27
Table 12c. Power Sweep Range (dB), Options 219 or 419 with 0291
Description
Specification
Typical
Port 12
Port 22
Port 12
Port 22
10 MHz to 50 MHz
32
38
45
44
50 MHz to 500 MHz
34
38
46
46
500 MHz to 3.2 GHz
34
38
39
45
3.2 GHz to 8.5 GHz
37
38
44
44
8.5 GHz to 10 GHz
37
38
44
44
10 GHz to 13.5 GHz
37
34
42
39
13.5 GHz to 16 GHz
37
34
42
39
16 GHz to 20 GHz
35
30
40
34
20 GHz to 24 GHz
33
27
39
31
24 GHz to 26.5 GHz
28
23
35
30
Description
Specification
Typical
Ports 1, 31
Ports 2, 41
Ports 1, 31
Ports 2, 41
10 MHz to 50 MHz
32
38
46
44
50 MHz to 500 MHz
33
38
47
47
500 MHz to 3.2 GHz
33
38
40
44
3.2 GHz to 8.5 GHz
38
38
46
44
8.5 GHz to 10 GHz
38
38
46
44
10 GHz to 13.5 GHz
37
35
42
41
13.5 GHz to 16 GHz
37
35
42
41
16 GHz to 20 GHz
35
32
40
37
20 GHz to 24 GHz
32
30
39
36
24 GHz to 26.5 GHz
25
23
35
31
1
Option 029 affects port 1 and port 2 power sweep ranges. Refer to Table 12b for other ports.
2
Source in filtered mode where applicable.
Table 12d. Power Sweep Range (dB), Options 224 or 423
1
Either port can be used as the source port. Source in filtered mode where applicable.
28
Table 12e. Power Sweep Range (dB), Option 224
Description
Specification
Typical
Source 2 Out 11
Source 2 Out 2
Source 2 Out 11
Source 2 Out 2
10 MHz to 50 MHz
24
28
38
35
50 MHz to 500 MHz
26
32
39
38
500 MHz to 3.2 GHz
25
29
34
36
3.2 GHz to 8.5 GHz
33
33
39
39
8.5 GHz to 10 GHz
33
33
39
39
10 GHz to 13.5 GHz
31
31
38
37
13.5 GHz to 16 GHz
31
31
38
37
16 GHz to 20 GHz
30
28
36
34
20 GHz to 24 GHz
28
27
35
34
24 GHz to 26.5 GHz
22
20
31
28
Description
Specification
Typical
Port 12
Port 22
Port 12
Port 22
10 MHz to 50 MHz
31
38
45
44
50 MHz to 500 MHz
33
38
47
47
500 MHz to 3.2 GHz
33
37
40
43
3.2 GHz to 8.5 GHz
38
38
46
44
8.5 GHz to 10 GHz
38
38
46
44
10 GHz to 13.5 GHz
37
35
42
41
13.5 GHz to 16 GHz
37
35
42
41
16 GHz to 20 GHz
35
31
39
36
20 GHz to 24 GHz
31
29
37
35
24 GHz to 26.5 GHz
25
23
35
31
1
Source in filtered mode where applicable.
Table 12f. Power Sweep Range (dB), Options 224 or 423 with 0291
1
Option 029 affects port 1 and port 2 power sweep ranges. Refer to Table 12d for other ports.
2
Source in filtered mode where applicable.
29
Table 13. Nominal Power (Preset Power, dBm)
Description
Options
200, 400
Options 219,
224, 419,
423
Option 224
Options 224, 423
All Ports1
Ports
1, 2, 3, 41
Source 2
Out 1
Source 2
Out 2
Source 1
Port 1
Combine
Mode
Source 2
Port 1
Combine
Mode
N5241A 0 -5
-5
-5
-5
-5
N5242A 0 -5
-5
-5
-5
-5
N5249A 0 -5
-5
-5
-5
-5
Description
Specification (dB)
Typical (dBm)
All Options
All Options
Options 200, 400
Options 219, 419,
224, 423
Power Resolution
0.01
--
--
--
Maximum Settable Power
--
30
--
--
Minimum Settable Power
--
--
-30
-95
Description1
2nd and 3rd Harmonics
1/2 and 1/4 Sub-Harmonics
Ports 1, 32
Source 2 Out 13
Ports 2, 42
Source 2 Out 2
Ports 1 32
Source 2 Out 13
Ports 2, 42
Source 2 Out 2
10 MHz to 2 GHz
-51
-13
-73
-73
2 GHz to 3.2 GHz
-60
-21
-73
-73
3.2 GHz to 8.5 GHz
-60
-21
-66
-63
8.5 GHz to 13.5 GHz
-60
-21
-66
-63
13.5 GHz to 20 GHz
-60
-21
-66
-63
20 GHz to 26.5 GHz
-60
-21
-61
-52
1
Any port can be used as the source port.
Table 14. Power Resolution and Maximum/Minimum Settable Power, All Ports1
1
Any port can be used as the source port.
Table 15. Harmonics at Max Specified Power (dBc), All Options - Typical
1
Listed frequency is fundamental frequency; test at max specified power
2
Any port can be used as the source port. Source in Filtered mode where applicable.
3
At port 1 max specified power.
30
Table 16. Non-Harmonic Spurs (dBc) at Nominal Power, All Options, All Ports - Typical
Description
Based on 8 kHz offset Frac-N
10 MHz to 500 MHz
-50
500 MHz to 2 GHz
-60
2 GHz to 4 GHz
-57
4 GHz to 8 GHz
-51
8 GHz to 8.5 GHz
-45
8.5 GHz to 13.5 GHz
-45
13.5 GHz to 16 GHz
-45
16 GHz to 24 GHz
-39
24 GHz to 26.5 GHz
-33
Description
1 kHz Offset
10 kHz Offset
100 kHz Offset
1 MHz Offset
10 MHz to 500 MHz
-85
-85
-85
-120
500 MHz to 1 GHz
-105
-115
-110
-127
1 GHz to 2 GHz
-100
-110
-105
-121
2 GHz to 4 GHz
-95
-105
-100
-115
4 GHz to 8 GHz
-89
-100
-94
-110
8 GHz to 8.5 GHz
-83
-94
-88
-105
8.5 GHz to 13.5 GHz
-83
-94
-88
-105
13.5 GHz to 16 GHz
-83
-94
-88
-105
16 GHz to 26.5 GHz
-78
-89
-82
-100
Table 17. Phase Noise (dBc/Hz), All Options, All Ports - Typical
31
Test Port Input
Description
Specification
Typical
Test Port
Direct Receiver
Access Input
Test Port
Direct Receiver
Access Input
10 MHz to 50 MHz2
-80
--
-87
-130
50 MHz to 100 MHz2
-90
--
-95
-128
100 MHz to 500 MHz2
-104
--
-110
-132
500 MHz to 2 GHz
-114
--
-117
-133
2 GHz to 8.5 GHz
-114
--
-117
-129
8.5 GHz to 13.5 GHz
-114
--
-117
-129
13.5 GHz to 20 GHz
-114
--
-117
-129
20 GHz to 24 GHz
-110
--
-115
-122
24 GHz to 26.5 GHz
-107
--
-113
-119
Description
Typical
10 MHz to 500 MHz1
--
500 MHz to 8.5 GHz
13
8.5 GHz to 13.5 GHz
13
13.5 GHz to 16 GHz
13
16 GHz to 20 GHz
12
20 GHz to 24 GHz
10.5
24 GHz to 26.5 GHz
10
Description
Specification
10 MHz to 500 MHz1
--
500 MHz to 8.5 GHz
<0.17
8.5 GHz to 13.5 GHz
<0.17
13.5 GHz to 16 GHz
<0.17
Table 18. Noise Floor1 (dBm) at 10 Hz IFBW, All Options, All Ports
1
Total average (rms) noise power calculated as the mean value of a linear magnitude trace expressed in dBm.
2
May typically be degraded at particular frequencies below 500 MHz due to spurious receiver residuals.
Table 19. 0.1 dB Compression at Test Port (dBm), All Options, All Ports - Typical
1
Test port receiver compression at specified input levels below 500 MHz is negligible due to coupler roll.
Table 20. Test Port Compression (dB) at 8 dBm Test Port Power, All Options, All Ports, - Specification
32
16 GHz to 24 GHz
<0.23
24 GHz to 26.5 GHz
<0.29
1
Description
Specification
Typical
1 kHz IFBW
1 kHz IFBW
100 kHz IFBW
600 kHz IFBW
10 MHz to 100 MHz
0.007
0.0039
0.040
0.140
100 MHz to 8.5 GHz
0.002
0.0005
0.005
0.011
8.5 GHz to 13.5 GHz
0.002
0.0005
0.005
0.011
13.5 GHz to 16 GHz
0.002
0.0005
0.005
0.011
16 GHz to 22.5 GHz
0.002
0.0006
0.005
0.012
22.5 GHz to 24 GHz
0.003
0.0014
0.008
0.020
24 GHz to 26.5 GHz
0.005
0.0020
0.008
0.020
Description
Specification
Typical
1 kHz IFBW
1 kHz IFBW
100 kHz IFBW
600 kHz IFBW
10 MHz to 100 MHz
0.051
0.0261
0.266
1.053
100 MHz to 8.5 GHz
0.015
0.0041
0.030
0.075
8.5 GHz to 13.5 GHz
0.015
0.0041
0.030
0.075
13.5 GHz to 16 GHz
0.042
0.0124
0.030
0.075
16 GHz to 22.5 GHz
0.042
0.0135
0.033
0.082
22.5 GHz to 26.5 GHz
0.054
0.0225
0.057
0.139
Description
Magnitude (dB)
Phase (°)
Range
+/-500
+/-500
Resolution
0.001
0.01
Test port receiver compression at specified input levels below 500 MHz is negligible due to coupler roll.
Table 21a. Trace Noise1 Magnitude (dB rms), All Options, All Ports
1
Ratioed measurement, nominal power at test port.
Table 21b. Trace Noise1 Phase (deg rms), All Options, All Ports
1
Ratioed measurement, nominal power at test port.
Table 22. Reference Level - Specification
33
Table 23. Stability1 - Typical
Description
Magnitude (dB/°C)
Phase (°/°C)
10 MHz to 50 MHz
0.01
0.29
50 MHz to 500 MHz
0.01
0.06
500 MHz to 3.2 GHz
0.01
0.07
3.2 GHz to 8.5 GHz
0.02
0.13
8.5 GHz to 10 GHz
0.02
0.13
10 GHz to 13.5 GHz
0.02
0.13
13.5 GHz to 16 GHz
0.02
0.13
16 GHz to 20 GHz
0.03
0.40
20 GHz to 24 GHz
0.03
0.54
24 GHz to 26.5 GHz
0.04
0.56
Description
RF (dBm)
DC (V)
Test Port 1, 2, 3, 4 (All Options)
> +30
40
Source 2 Out 1, Source 2 Out 2 (Option 224 only)
> +30
0
Test Port 2, Noise Mode1 (Option 029 only)
> +27
40
1
Stability is defined as a ratio measurement made at the test port.
Table 24. Damage Input Level - Specification
1
Noise mode sets port 2 noise receiver switch to noise receiver position.
34
Noise Receiver Input (Option 029 only)
Description
Bandwidth
10 MHz to 25 MHz
800 kHz, 2 MHz
25 MHz to 60 MHz
800 kHz, 2/4 MHz
60 MHz to 150 MHz
800 kHz, 2/4/8 MHz1
150 MHz to 26.5 GHz
800 kHz, 2/4/8/24 MHz1
Description
Specification
Typical
10 MHz to 200 MHz
9.0
--
200 MHz to 2 GHz
12.0
--
2 GHz to 8.5 GHz
14.5
--
8.5 GHz to 13.5 GHz
14.5
--
13.5 GHz to 16 GHz
14.5
--
16 GHz to 26.5 GHz
17.01
--
Frequency
Specification
Typical
Low Gain
Setting
Medium Gain
Setting
High Gain
Setting
Low Gain
Setting
Medium Gain
Setting
High Gain
Setting
10 MHz to 15 MHz
0.30
0.30
0.10
0.15
0.15
0.07
15 MHz to 3 GHz
0.10
0.10
0.10
0.07
0.07
0.07
3 GHz to 8.5 GHz
0.11
0.10
0.10
0.07
0.07
0.07
8.5 GHz to 13.5 GHz
0.11
0.10
0.10
0.07
0.07
0.07
13.5 GHz to 26.5 GHz
0.11
0.10
0.10
0.07
0.07
0.07
Table 25. Noise Receiver Bandwidth
1
8 and 24 MHz bandwidths are available only with calibration using noise source.
Table 26. Receiver Noise Figure (dB), Port 2, at All BW, High Gain Setting
1
Degraded by 1.5 dB with 24 MHz BW.
Table 27. Noise Figure Trace Noise1 (dB rms) at 4 MHz BW
1
Trace noise magnitude performance on noise figure trace or sometime called noise jitter, 201 points, 1 noise average,
port 2 terminated. May typically be degraded at frequencies below 500 MHz due to spurious noise receiver residuals.
35
Table 28. Noise Receiver Linearity (dB) at 4 MHz BW - Specification
Power Range (dBm)
Specification
Low Gain Setting
Reference to -60 dBm
Medium Gain Setting
Reference to -60 dBm
High Gain Setting
Reference to -60 dBm
-34 to -64
-48 to -76
-58 to -84
+/-0.05
-64 to -70
-76 to -86
-84 to -92
+/-0.10
Description
Max DUT NF + Gain (dB)1
Max Input Power (dBm)
for <0.1 dB Compression2
High Gain
Setting
Medium
Gain Setting
Low Gain
Setting
High Gain
Setting
Medium
Gain Setting
Low Gain
Setting
500 MHz to 3 GHz
32
44
55
<=-57
<=-45
<=-34
3 GHz to 8.5 GHz
46
57
68
<=-43
<=-32
<=-21
8.5 GHz to 13.5 GHz
46
57
68
<=-43
<=-32
<=-21
13.5 GHz to 26.5 GHz
46
57
68
<=-43
<=-32
<=-21
Table 29. Noise Receiver Input Range - Specification
1
Limited by 0.1 dB receiver compression. Applies to devices with bandwidth < 400 MHz. For devices with higher
bandwidths, calculate the DUT output noise power as -174 dBm + 10*log10(B) + Gain (dB) + NF (dB), where B is the
bandwidth of the DUT in Hz, and use the Max Input Power specification.
2
Derived from ensuring < 0.25 dB compression with a CW signal 5 dB higher than the stated max input power value for
0.1 dB compression. Referenced to test port 2.
36
Dynamic Accuracy
Table 30. Dynamic Accuracy - Specification
Standard receiver accuracy of the test port input power reading relative to the reference input power level. It is verified
with the following measurements:
Compression over frequency
IF linearity at a single frequency of 1.998765 GHz using a reference level of -20 dBm for an input power range
of 0 to -60 dBm. For value below -60 dBm, refer to “VNA Receiver Dynamic Accuracy Specifications and
Uncertainties”.
Applies to N5249A (all serial numbers) and N5241A, N5242A with following serial numbers:
N5241A and N5241AS: MY5241/SG5241/US5241 and above
N5242A and N5242AS: MY5242/SG5242/US5242 and above
Please download our free Uncertainty Calculator from http://www.agilent.com/find/na_calculator to generate the
curves for your PNA.
Dynamic Accuracy, 0.010 GHz
Dynamic Accuracy, 0.050 GHz
37
Dynamic Accuracy, 1 GHz
Dynamic Accuracy, 8.5 GHz
Dynamic Accuracy, 10 GHz
38
Dynamic Accuracy, 13.5 GHz
Dynamic Accuracy, 20 GHz
Dynamic Accuracy, 26.5 GHz
39
Table 31. Test Port Input (Group Delay)1
Description
Typical Performance
Aperture (selectable)
(frequency span)/(number of points -1)
Maximum Aperture
20% of frequency span
Range
0.5 x (1/minimum aperture)
Maximum Delay
Limited to measuring no more than 180° of phase change within the
minimum aperture.)
Accuracy
See graph below. Char.
The following graph shows characteristic group delay accuracy with full 2-port calibration and a 10 Hz IF bandwidth.
Insertion loss is assumed to be < 2 dB and electrical length to be ten meters.
For any Sij Group Delay measurement, Sii = 0, Sij = 1, Sji = 0, Skl = 0 for all kl ij
In general, the following formula can be used to determine the accuracy, in seconds, of specific group delay
measurement:
±Phase Accuracy (deg)/[360 × Aperture (Hz)]
Depending on the aperture and device length, the phase accuracy used is either incremental phase accuracy or
worst-case phase accuracy.
1
Group delay is computed by measuring the phase change within a specified frequency step (determined by the
frequency span and the number of points per sweep).
40
General Information
Description
Supplemental Information
System IF Bandwidth Range
1 Hz to 15 MHz, nominal (7 MHz, 10 MHz, and 15 MHz IFBWs are available ONLY
with FW A.09.42 and later, and with DSP version 5)
CPU
Intel 2.0 GHz Core i7. Note: Some instruments may have a different CPU.
For the latest information on CPUs and associated hard drives, visit:
http://na.tm.agilent.com/pna/hdnumbers.html
LXI
Class C (only applies to N5241A, N5242A, and N5249A models that are shipped with
firmware revision A.08.20 and higher)
Description
Typical Performance
RF Connectors
Test Ports
3.5 mm (male), 50 ohm (nominal), 0.002 in. Center Pin Recession (characteristic)
Jumpers
3.5 mm (female) connectors with SMA (male) jumper cables
USB 2.0 Ports – Master (4 ports)
Standard
Compatible with USB 2.0
Connector
USB Type-A female
Display
Size
26.3 cm (10.4 in) diagonal color active matrix LCD; 1024 (horizontal) X 768 (vertical)
resolution
Refresh Rate
Vertical 60 Hz; Horizontal 46.08 kHz
Pixels
A display is considered faulty if:
• A complete row or column consists of “stuck” or “dark” pixels.
• More than six “stuck on” pixels (but not more than three green) or more than 0.002% of
the total pixels are within the LCD specifications.
• More than twelve “dark” pixels (but no more than seven of the same color) or more than
0.004% of the total pixels are within the LCD specifications.
• Two or more consecutive "stuck on" pixels or three or more consecutive "dark" pixel (but
no more than one set of two consecutive dark pixels)
• “Stuck on” “dark” pixels are less than 6.5 mm apart (excluding consecutive pixels)
Miscellaneous Information
Front Panel
Rear Panel
Environment and Dimensions
Table 32. Miscellaneous Information
Table 33. Front Panel Information, All Options
41
Table 33. (Continued) Front Panel Information, All Options
Description
Typical Performance
Display Range
Magnitude
+/-2500 dB (at 500 dB/div), max
Phase
+/-2500° (at 500 dB/div), max
Polar
10 pUnits, min
10,000 Units, max
Display Resolution
Magnitude
0.001 dB/div, min
Phase
0.01°/div, min
Marker Resolution
Magnitude
0.001 dB, min
Phase
0.01°, min
Polar
10 pUnit, min
Description
Typical Performance
10 MHz Reference In
Connector
BNC, female
Input Frequency
10 MHz ± 10 ppm
Input Level
-15 dBm to +20 dBm
Input Impedance
200 , nom.
10 MHz Reference Out
Connector
BNC, female
Output Frequency
10 MHz ± 1 ppm
Signal Type
Sine Wave
Output Level
+10 dBm ± 4 dB into 50
Output Impedance
50 , nominal
Harmonics
<-40 dBc, typical
Table 34. Rear Panel Information, All Options
42
Table 34. (Continued) Rear Panel Information, All Options
Description
Typical Performance
External IF Inputs
Function
Allows use of external IF signals from remote mixers, bypassing the PNA's first converters
Connectors
SMA (female); A, B, C, D, R (4-port); A, B, R1, R2 (2-port)
Frequency
Path
Normal IF path:
Narrowband IF path:
DSP Version
4
5
4 or 5
IF Bandwidth
All
All
<= 600 kHz
1 MHz
1.5 MHz
2 MHz
3 MHz
5 MHz
7 MHz
10 MHz
15 MHz
All
RF Frequency
< 53 MHz
>= 53 MHz
< 53 MHz
>= 53 MHz
All
All
All
All
All
All
All
All
All
IF Frequency
2.535211 MHz
7.605634 MHz
2.479339 MHz
7.438017 MHz
7.692 MHz
7.368 MHz
8.450 MHz
8.163 MHz
6.897 MHz
10.53 MHz
15.38 MHz
22.22 MHz
10.70 MHz
Input Impedance
50
RF Damage Level
+23 dBm
DC Damage Level
5.5 VDC
0.1 dB Compression Point
Normal IF path
Narrowband IF path
-9.0 dBm at 7.438 MHz
-17 dBm at 10.70 MHz
Pulse Inputs (IF Gates)
Function
Internal receiver gates used for point-in-pulse and pulse-profile measurements
Connectors
15-pin mini D-sub
Input Impedance
1 K Ohm
Source Modulators
20 ns minimum pulse width
Receiver Gates
20 ns minimum pulse width
DC Damage Level
5.5 VDC
Drive Voltage
0 V (off), +3.3 V (on), nominal
43
Table 34. (Continued) Rear Panel Information, All Options
Description
Typical Performance
RF Pulse Modulator Input (Source Modulator)
On/Off Ratio
10 MHz to 3.2 GHz
-64 dB
3.2 GHz to 8.5 GHz
-80 dB
8.5 GHz to 13.5 GHz
-80 dB
13.5 GHz to 26.5 GHz
-80 dB
Pulse Period
Minimum
20 ns
Maximum
70 s
Pulse Outputs
Voltage (TTL)
High: 3.3 V to 3.5 V
Low: <1 V
Impedance
50 Ohm
External Test Set Driver
Function
Used for driving remote mixers
Connections
SMA (female)
RF, LO Output Frequency
Range1
1.7 to 13.5 GHz (N5241A)
1.7 to 26.5 GHz (N5242A)
Rear Panel LO Power
Upper Limit (dBm)
Lower Limit (dBm)
1.7 GHz to 8.5 GHz 0 -10
8.5 GHz to 13.5 GHz 0 -10
13.5 GHz to 18 GHz 0 -10
18 GHz to 22.5 GHz 2 -8
22.5 GHz to 26.5 GHz 6 -5
Rear Panel RF Power
Upper Limit (dBm)
Lower Limit (dBm)
3.2 GHz to 13.5 GHz
-3
-8
13.5 GHz to 20 GHz
-3
-8
20 GHz to 26.5 GHz
-8
-14
1 Full LO frequency range is: 12.535 MHz to 13.5 GHz. (N5241A), 12.535 MHz to 26.5 GHz. (N5242A)
44
Table 34. (Continued) Rear Panel Information, All Options
Description
Typical Performance
VGA Video Output
Connector
15-pin mini D-Sub; Drives VGA compatible monitors
Devices Supported:
Resolutions:
Flat Panel (TFT)
1024 X 768, 800 X 600, 640 X 480
Flat Panel (DSTN)
800 X 600, 640 X 480
CRT Monitor
1280 X 1024, 1024 X 768, 800 X 600, 640 X 480
Simultaneous operation of the internal and external displays is allowed, but with 640 X 480 resolution only. If you
change resolution, you can only view the external display (internal display will "white out").
Bias Tee Inputs
Connectors
BNC(f) for ports 1, 2, 3 and 4
Fuse
500 mA, bi-pin style
Maximum Bias Current
+/-200 mA with no degradation of RF specifications
Maximum Bias Voltage
+/-40 VDC
Trigger Inputs/Outputs
BNC(f), TTL/CMOS compatible
Test Set IO
25-pin D-Sub connector, available for external test set control.
Power IO
9-pin D-Sub, female; analog and digital IO
Handler IO
36-pin parallel I/O port; all input/output signals are default set to negative logic; can
be reset to positive logic via GPIB command.
GPIB
Two ports - dedicated controller and dedicated talker/listener. 24-pin D-sub (Type D-
24), female; compatible with IEEE-488.
Parallel Port (LPT1)
25-pin D-Sub miniature connector, female; provides connection to printers or any other
parallel port peripherals
USB Port
Four ports on front panel (all Host) and five ports (four Host and one Device) on rear
panel. Type A configuration (eight Host) and Type B configuration (one Device), USB
2.0 compatible.
LAN
10/100BaseT Ethernet, 8-pin configuration; auto selects between the two data rates
Line Power
Frequency, Voltage
50/60/400 Hz for 100 to 120 VAC
50/60 Hz for 220 to 240 VAC
Power supply is auto switching
Max
450 watts
45
Table 35. Analyzer Dimensions and Weight
Cabinet Dimensions
Metric (mm)
Imperial (inches)
Height
Without bottom feet: EIA RU1 = 6
266.1
10.5
With bottom feet
279.1
11.0
Width
Without handles or rack-mount flanges
425.6
16.8
With handles, without rack-mount flanges
458.7
18.1
With handles and rack-mount flanges
482.9
19.0
Depth
Without front and rear panel hardware
533.0
21.0
With front and rear panel hardware, handles
578.0
22.7
Weight (nominal)
Net
Shipping
2-port models
27 kg (60 lb)
43 kg (95 lb)
4-port models
37 kg (82 lb)
53 kg (117 lb)
All N5241A, N5242A, and N5249A models are shipped with bottom feet, handles, and front and rear hardware.
See detailed PNA dimension drawings at: http://na.tm.agilent.com/pna/PNADimensions.pdf
1
Electronics Industry Association rack units. 1 RU = 1.75 in.
Regulatory and Environmental information
For Regulatory and Environmental information, refer to the PNA Series Installation and Quick Start Guide, located online
at http://cp.literature.agilent.com/litweb/pdf/E8356-90001.pdf.
46
Measurement Throughput Summary
Sweep
Range
IF
Bandwidth
Number of Points
201
401
1601
16001
7 GHz to
8 GHz
600 kHz
Uncorrected
6
6.3
9.6
56
2-Port cal
20
21
28
134
10 kHz
Uncorrected
36
53
200
1945
2-Port cal
80
115
405
3900
1 kHz
Uncorrected
227
444
1740
17000
2-Port cal
460
900
3484
34000
9 GHz to
10 GHz
600 kHz
Uncorrected
6
6.3
9.6
56
2-Port cal
20
21
28
134
10 kHz
Uncorrected
36
53
200
1945
2-Port cal
80
115
405
3900
1 kHz
Uncorrected
227
444
1740
17000
2-Port cal
460
900
3484
34000
10 GHz to
13.5 GHz
600 kHz
Uncorrected
26
33
54
85
2-Port cal
62
77
121
190
10 kHz
Uncorrected
70
118
273
1958
2-Port cal
149
245
553
3922
1 kHz
Uncorrected
236
459
1780
17300
2-Port cal
400
926
3565
34600
13.5 GHz
to 20 GHz
600 kHz
Uncorrected
26
33
54
85
2-Port cal
62
77
121
190
10 kHz
Uncorrected
70
118
273
1958
2-Port cal
149
245
553
3922
1 kHz
Uncorrected
236
459
1780
17300
2-Port cal
400
926
3565
34600
Typical Cycle Time for Measurement Completion
Cycle Time vs. IF Bandwidth
Cycle Time vs. Number of Points
Data Transfer Time
Cycle time Includes sweep time, retrace time and band-crossing time. Analyzer display turned off with DISPLAY:ENABLE
OFF. Add 21 ms for display on. Data for one trace (S11) measurement.
Table 36a. Cycle Time (ms) for Measurement Completion, All Options - Typical
47
Table 36b. Cycle Time (ms) for Full-Span Measurement Completion - Typical
10 MHz to 26.5 GHz
Number of Points
IF Bandwidth
201
401
1601
16001
600 kHz
Uncorrected
59
69
118
350
2-Port cal
125
147
244
707
10 kHz
Uncorrected
94
156
480
2333
2-Port cal
196
320
968
4674
1 kHz
Uncorrected
277
504
1873
17950
2-Port cal
561
1015
3756
35900
Description
Typical Performance
IF Bandwidth (Hz)
Cycle Time (ms)
Trace Noise
600,000
5.00
0.009
100,000
6.84
0.003
30,000
11.6
0.002
10,000
29.0
0.001
3,000
71.8
0.0007
1,000
222
0.0004
300
640
0.0003
100
1826
0.0002
30
5982
<0.0002
10
17830
<0.0002
3
60000
<0.0002
Table 37. Cycle Time vs. IF Bandwidth - Typical
Applies to the Preset condition (201 points, correction off) except for the following changes:
CF = 10 GHz
Span = 100 MHz
Display off (add 21 ms for display on)
Cycle time includes sweep and retrace time.
48
Table 38. Cycle Time vs. Number of Points
Description
IF Bandwidth (Hz)
Number of Points
1,000
10,000
30,000
600,000
3
7.7
5.44
5.7
5.4
11
16.6
7.90
5.9
5.4
51
60
10.7
6.5
5.5
101
115
16.8
8.2
5.6
201
222
29.0
11.8
5.9
401
436
53.0
18.8
6.3
801
860
102
32.8
7.2
1,601
1,700
199
60.5
9.6
6,401
6,700
780
228
25
16,001
16,000
1950
566
56
Applies to the Preset condition (correction off) except for the following changes:
CF = 10 GHz
Span = 100 MHz
Display off (add 21 ms for display on)
Cycle time includes sweep and retrace time.
49
Table 39. Data Transfer Time1 (ms) - Typical
Description
Number of Points
201
401
1601
16,001
SCPI over GPIB (Program executed on external PC2)
32-bit floating point
5.6
10.5
39.9
400
64-bit floating point
10.5
20.3
79.2
788
ASCII
46
92.5
370
3702
SCPI over SICL/LAN or TCP/IP Socket (Program executed in the analyzer)
32-bit floating point
0.18
0.21
0.5
3.6
64-bit floating point
0.22
0.28
0.62
5.3
ASCII
6.3
12.3
47.3
470
COM3 (Program executed in the analyzer)
32-bit floating point
<0.15
0.15
0.2
0.7
Variant type
0.75
1.2
4.5
50
DCOM over LAN3 (Program executed on external PC)
32-bit floating point
<1.0
1.2
2.1
13
Variant type
2.7
4.5
15
150
1
Measured with the analyzer display off. Values will increase slightly if the analyzer display is on.
2
Measured when using the SCPI command DISPlay: VISible OFF.
3
Values are for real and imaginary pairs, with the analyzer display off.
Note: Specifications for Recall & Sweep Speed are not provided for the N5241A, N5242A, and N5249A analyzers.
50
Specifications: Front-Panel Jumpers
Description
All Options
10 MHz to 50 MHz
-4
50 MHz to 500 MHz
-3
500 MHz to 8.5 GHz
-2
8.5 GHz to 13.5 GHz
-2
13.5 GHz to 16 GHz
-2
16 GHZ to 20 GHz
-2.5
20 GHZ to 26.5 GHz
-4
Description
Options 200, 400
Options 219, 419
Options 224, 423
Filtered
Mode1
Hi Power
Mode1
Filtered
Mode1
Hi Power
Mode1
Filtered
Mode1
Hi Power
Mode1
10 MHz to 50 MHz
-8
-3
-8
-3
-9
-6
50 MHz to 500 MHz
-6
-3
-6
-3
-7
-5
500 MHz to 3.2 GHz
-6
-6
-5
-5
-7
-5
3.2 GHz to 8.5 GHz
-3
-3
-2
-2
-2
-2
8.5 GHz to 10 GHz
-3
-3
-2
-2
-2
-2
10 GHz to 13.5 GHz
-4
-4
-3
-3
-3
-3
13.5 GHZ to 16 GHz
-4
-4
-3
-3
-3
-3
16 GHZ to 20 GHz
-5
-5
-6
-6
-6
-6
20 GHZ to 24 GHz
-7
-7
-8
-8
-9
-9
24 GHZ to 26.5 GHz
-16
-16
-15
-15
-18
-18
Note: All PNA-X options have the following front-panel jumpers for each port.
Measurement Receiver Inputs
Reference Receiver Inputs and Reference Source Outputs
Source Outputs
Coupler Inputs
Damage Level
Table 40. Measurement Receiver Inputs (dBm) - Typical
(RCVR A, B, C, D IN) @ 0.1 dB Typical Compression
Table 41a. Reference Receiver Inputs and Reference Source Outputs (dBm) - Typical
(RCVR R1 IN, REF 1 SOURCE OUT) @ Max Specified Output Power
51
1
Description
Option 400
Options 200,
400
Option 419
Options 219,
419
RCVR R3
IN,
REF 3
SOURCE
OUT
RCVR R3
IN,
REF 3
SOURCE
OUT
RCVR R2,
R4 IN,
REF 2, 4
SOURCE OUT
RCVR R3
IN,
REF 3
SOURCE
OUT
RCVR R3
IN,
REF 3
SOURCE
OUT
RCVR R2,
R4 IN,
REF 2, 4
SOURCE OUT
Filtered
Mode1
Hi Power
Mode1
Filtered
Mode1
Hi Power
Mode1
10 MHz to 50 MHz
-6
-1
-1
-6
-1
-1
50 MHz to 500 MHz
-4
-1
-1
-4
-1
-1
500 MHz to 3.2 GHz
-4
-4 0 -3
-3
-1
3.2 GHz to 8.5 GHz
0
0 0 1 1 0
8.5 GHz to 10 GHz
0
0 0 1 1 0
10 GHz to 13.5 GHz
1 1 0 1 1
1
13.5 GHZ to 16 GHz
1 1 0 1 1
1
16 GHZ to 20 GHz
1 1 -3 0 0
-3
20 GHZ to 24 GHz
0 0 -6
-1
-1
-4
24 GHZ to 26.5 GHz
-8
-8
-12
-7
-7
-13
Description
Option 423
Options 224, 423
RCVR R3 IN,
REF 3 SOURCE OUT
RCVR R3 IN,
REF 3 SOURCE OUT
RCVR R2, R4 IN,
REF 2, 4 SOURCE OUT
Filtered Mode1
Hi Power Mode1
10 MHz to 50 MHz
-7
-4
-1
50 MHz to 500 MHz
-6
-4
-1
500 MHz to 3.2 GHz
-5
-3
-1
3.2 GHz to 8.5 GHz
1 1 0
8.5 GHz to 10 GHz
1 1 0
In Filtered Mode, the signal path goes through filters to minimize harmonics below 3.2 GHz. In Hi Power Mode, the
signal bypasses the filters to maximize output power.
Table 41b. Reference Receiver Inputs and Reference Source Outputs (dBm) - Typical
(RCVR R2, R3, R4 IN, REF 2, 3, 4 SOURCE OUT) @ Max Specified Output Power
1
In Filtered Mode, the signal path goes through filters to minimize harmonics below 3.2 GHz. In Hi Power Mode, the
signal bypasses the filters to maximize output power.
Table 41c. Reference Receiver Inputs and Reference Source Outputs (dBm) - Typical
(RCVR R2, R3, R4 IN, REF 2, 3, 4 SOURCE OUT) @ Max Specified Output Power
52
10 GHz to 13.5 GHz
1 1 -2
13.5 GHZ to 16 GHz
1 1 -2
16 GHZ to 20 GHz 0 0
-4
20 GHZ to 24 GHz
-2
-2
-6
24 GHZ to 26.5 GHz
-10
-10
-10
1
Description
Options 200, 400
Options 219, 419
PORT 1, 3 SORUCE OUT
PORT 2, 4
SOURCE OUT
PORT 1, 3 SORUCE OUT
PORT 2, 4
SOURCE OUT
Filtered
Mode1
Hi Power
Mode1
Filtered
Mode1
Hi Power
Mode1
10 MHz to 50 MHz
8
13
13 8 13
13
50 MHz to 500 MHz
10
13
13
10
13
13
500 MHz to 3.2 GHz
11
11
13
11
11
14
3.2 GHz to 8.5 GHz
14
14
14
14
14
14
8.5 GHz to 10 GHz
14
14
14
14
14
14
10 GHz to 13.5 GHz
14
14
14
14
14
13
13.5 GHZ to 16 GHz
14
14
14
14
14
13
16 GHZ to 20 GHz
14
14
11
12
12
10
20 GHZ to 24 GHz
13
13 9 10
10
9
24 GHZ to 26.5 GHz
7 7 4 5 5
2
Description
Options 224, 423
PORT 1, 3 SORUCE OUT
PORT 2, 4 SOURCE OUT
Filtered Mode1
Hi Power Mode1
10 MHz to 50 MHz
7
10
13
50 MHz to 500 MHz
8
10
13
500 MHz to 3.2 GHz
9
11
14
In Filtered Mode, the signal path goes through filters to minimize harmonics below 3.2 GHz. In Hi Power Mode, the
signal bypasses the filters to maximize output power.
Table 42a. Source Outputs (dBm) - Typical
(PORT 1, 2, 3, 4 SOURCE OUT) @ Max Specified Output Power
1
In Filtered Mode, the signal path goes through filters to minimize harmonics below 3.2 GHz. In Hi Power Mode, the
signal bypasses the filters to maximize output power.
Table 42b. Source Outputs (dBm) - Typical
(PORT 1, 2, 3, 4 SOURCE OUT) @ Max Specified Output Power
53
3.2 GHz to 8.5 GHz
14
14
14
8.5 GHz to 10 GHz
14
14
14
10 GHz to 13.5 GHz
14
14
12
13.5 GHZ to 16 GHz
14
14
12
16 GHZ to 20 GHz
12
12
9
20 GHZ to 24 GHz
9 9 7
24 GHZ to 26.5 GHz
2 2 4
1
Description
Options 200, 400
Options 219, 419, 224, 423
10 MHz to 50 MHz 0 -0.5
50 MHz to 500 MHz
-0.25
-0.75
500 MHz to 3.2 GHz
-0.5
-1.0
3.2 GHz to 8.5 GHz
-0.75
-1.25
8.5 GHz to 10 GHz
-0.75
-1.25
10 GHz to 13.5 GHz
-1.0
-1.75
13.5 GHZ to 16 GHz
-1.0
-1.75
16 GHZ to 20 GHz
-1.5
-2.25
20 GHZ to 24 GHz
-1.5
-2.5
24 GHZ to 26.5 GHz
-1.75
-2.5
Description
RF (dBm)
DC (V)
RCVR A, B, C, D IN
15
0
RCVR R1 IN
15
7
RCVR R2, R3, R4 IN
15
15
REF 1 SOURCE OUT
15
7
REF 2, 3, 4 SOURCE OUT
30
0
PORT 1, 2, 3, 4 SOURCE OUT
15
0
PORT 1, 2, 3, 4 CPLR THRU
30
0
PORT 1, 2, 3, 4 CPLR ARM
30
40
In Filtered Mode, the signal path goes through filters to minimize harmonics below 3.2 GHz. In Hi Power Mode, the
signal bypasses the filters to maximize output power.
Table 43. Coupler Inputs (dB) - Typical
(PORT 1, 2, 3, 4 CPLR THRU) Insertion Loss of Coupler Thru
Table 44. Damage Level - Typical
54
Test Set Block Diagrams
NOTE: For best readability, use a color printer for printing the following graphics.
Legend
Figure 1. 2-Port N5241A, N5242A, and N5249A Base Unit Option 200
Figure 2. 2-Port N5241A, N5242A, and N5249A Option 219
55
Figure 3. 2-Port N5241A, N5242A, and N5249A Option 224
Figure 4. 2-Port N5241A, N5242A, and N5249A Option 224 with 029
56
Figure 5. 4-Port N5241A, N5242A, and N5249A Base Unit Option 400
Figure 6. 4-Port N5241A, N5242A, and N5249A Option 419
57
Figure 7. 4-Port N5241A, N5242A, and N5249A Option 423
Figure 8. 4-Port N5241A, N5242A, and N5249A Option 423 with 029
58
Figure 9. Receiver Block Diagram
IF gate
Anti-alias
filter
ADC
Digital FIR
IF filter
Narrowband filter
External
IF input
A
IF gate
Anti-alias
filter
ADC
Digital FIR
IF filter
Narrowband filter
External
IF input
AA
59
Agilent Email Updates
Americas
Canada
Brazil
Mexico
United States
(877) 894-4414
(11) 4197 3500
01800 5064 800
(800) 829-4444
Asia Pacific
Australia
China
Hong Kong
India
Japan
Korea
Malaysia
Singapore
Taiwan
Other AP Countries
1 800 629 485
800 810 0189
800 938 693
1 800 112 929
0120 (421) 345
080 769 0800
1 800 888 848
1 800 375 8100
0800 047 866
(65) 375 8100
Europe & Middle East
Belgium
Denmark
Finland
France
Germany
Ireland
Israel
Italy
Netherlands
Spain
Sweden
United Kingdom
32 (0) 2 404 93 40
45 70 13 15 15
358 (0) 10 855 2100
0825 010 700*
*0.125 €/minute
49 (0) 7031 464 6333
1890 924 204
972-3-9288-504/544
39 02 92 60 8 484
31 (0) 20 547 2111
34 (91) 631 3300
0200-88 22 55
44 (0) 118 9276201
www.agilent.com/find/emailupd
ates
Get the latest information on the
products and applications you select.
.
www.axiestandard.org
AdvancedTCA© Extensions for
Instrumentation and Test (AXIe) is an
open standard that extends the
AdvancedTCA for general purpose
and semiconductor test. Agilent is a
founding member of the AXIe
consortium.
www.lxistandard.org
LAN eXtensions for Instruments puts
the power of Ethernet and the Web
inside your test systems. Agilent is a
founding member of the LXI
consortium.
www.agilent.com
www.agilent.com/find/pnax
For more information on Agilent
Technologies’ products, applications or
services, please contact your local Agilent
office. The complete list is available at:
www.agilent.com/find/contactus
www.pxisa.org
PCI eXtensions for Instrumentation
(PXI) modular instrumentation
delivers a rugged, PC-based highperformance measurement and
automation system.
Agilent Channel Partners
www.agilent.com/find/channelpartn
ers
Get the best of both worlds: Agilent’s
measurement expertise and product
breadth, combined with channel
partner convenience.
For other unlisted countries:
www.agilent.com/find/contactus
Product specifications and
descriptions in this document
subject to change without notice.
© Agilent Technologies, Inc.
Published in USA, April 1, 2014
Supersedes: Nov. 22, 2013
N5242-90007
Loading...
