N9320B RF Spectrum Analyzer
9 kHz to 3.0 GHz
Data Sheet
Definitions and Conditions
The spectrum analyzer will
meet its specifications when:
“Specifications” describe the performance of parameters covered by the
product warranty and apply to the full temperature range of 5 to 45 °C, unless
otherwise noted.
• It is within its calibration
cycle
• It has been turned on at
least 30 minutes
• It has been stored at an
ambient temperature within
the allowed operating range
for at least two hours before
being turned on; if it has
been stored previously at
a temperature range inside
the allowed storage range,
but outside the allowed
operating range
“Typical” values describe additional product performance information that is
not covered by the product warranty. It is performance beyond specifications
that 80 percent of the units exhibit with a 95 percent confidence level over the
temperature range 20 to 30 °C. Typical performance does not include measurement uncertainty.
“Nominal” values indicate expected performance, or describe product performance that is useful in the application of the product, but are not covered by the
product warranty.
2
Frequency and Time Specification
Supplemental information
Frequency
Range 9 kHz to 3 GHz AC coupled
100 kHz to 3 GHz Preamp on
Resolution 1 Hz
Internal 10 MHz frequency reference
Aging rate ± 1 ppm/year
Temperature stability ± 1 ppm 5 to +45 °C, reference 25 °C
Supply voltage stability ± 0.3 ppm
Residual FM ≤ 100 Hz p-p in 100 ms nominal RBW = 1 kHz, VBW = 1 kHz
Frequency readout accuracy (start, stop, center, marker)
Marker resolution (freq span)/(number of sweep point -1)
1
Uncertainty ± (freq indication x freq reference uncertainty
bandwidth + marker resolution)
Sweep point 461, fixed
Marker frequency counter
Resolution 1 Hz, 10 Hz, 100 Hz, 1 kHz Selectable
Accuracy ± [(marker freq x freq reference uncertainty
Frequency span (FFT and swept mode)
Range 0 Hz (zero span), 100 Hz to 3.0 GHz
Resolution 1 Hz
Accuracy ± span/(swept points -1)
Sweep time and triggering
Span range 10 ms to 1000 s Span > 0 Hz
6 μs to 200 s Span = 0 Hz (minimum resolution = 6 μs)
Mode Continuous, single
Trigger Free run, video, external
Trigger slope Positive or negative edge Selectable
Trigger delay 0 to 80 sweep time
Resolution bandwidth (RBW)
Range (-3 dB bandwidth) 10 Hz to 1 MHz, in 1-3-10 sequence
Accuracy ± 5% nominal
Resolution filter shape factor < 5:1 nominal
Range (-6 dB bandwidth) 200 Hz, 9 kHz, 120 kHz, 1 MHz EMI bandwidth (CISPR 16-1-1 complaint),
Accuracy ± 10% nominal
Resolution filter shape factor < 5:1 nominal -60 dB/-6 dB bandwidth ratio
Video bandwidth (VBW)
Range 1 Hz to 1 MHz in 1-3-10 sequence -3 dB bandwidth
+ 1% x span + 20% x resolution
1
) + (counter resolution)]
requires Option EMF
1. Frequency reference uncertainty = Aging rate x period since adjustment + supply voltage stability + temperature stability.
3
Amplitude Specifications
Supplemental information
Amplitude range
Measurement range 10 MHz to 3 GHz: Displayed average noise
level (DANL) to +30 dBm
(PA OFF) 1 to 10 MHz: DANL up to 23 dBm
100 kHz to 1 MHz: DANL up to 20 dBm
Input attenuator range 0 to 70 dB, in 1 dB steps
Maximum damage level
Average continuous power ≤ +37 dBm Input attenuator setting ≥ 10 dB, 3 minutes
maximum
Peak pulse power ≤ +50 dBm (100 W) For < 10 μs pulse width, < 1% duty cycle,
and input attenuation ≥ 40 dB
DC voltage 50 VDC maximum
Level display range
Log scale units dBm, dBmV, dBμV, dBμA
Linear scale units μV, mV, V, μA, mA, A, μW, mW, W
Marker level readout 0.01 dB Log scale
Resolution 0.01% of reference level Linear scale
Number of traces 4
Detectors Positive-peak, negative-peak, sample,
normal, RMS
Trace function Clear/write, maximum hold, average,
minimum hold, view
Frequency response
10 dB input attenuation, reference: 50 MHz, 20 to -30 °C
200 kHz to 2.0 GHz ± 0.5 dB Preamp off
2.0 to 3.0 GHz ± 0.7 dB Preamp off
1 MHz to 2.0 GHz ± 0.6 dB Preamp on
2.0 to 3.0 GHz ± 0.8 dB Preamp on
Input attenuation switching uncertainty at 50 MHz
Attenuation > 2 dB, preamp off
0 to 60 dB attenuation ± 0.4 dB Relative to 10 dB (reference setting)
Absolute amplitude accuracy
Center frequency 50 MHz, RBW 1 kHz, VBW 1 kHz, amplitude scale log, span 100 kHz, sweep time coupled, peak
detector, signal at reference level
Preamp off ± 0.3 dB Reference level -10 dB, input attenuation
10 dB
Preamp on ± 0.4 dB Reference level -30 dB, input attenuation
10 dB
4
Amplitude Specifications (continued)
Supplemental information
Level measurement uncertainty
20 to -30 °C; frequency > 1 MHz; signal input 0 to -50 dBm; reference level 0 to -50 dBm; input attenuation 20 dB; RBW
1 kHz, VBW 1 kHz; after calibration; preamp off
Overall amplitude accuracy ± 1.5 dB
± 0.5 dB, typical
Level display range
Log scale units dBm, dBmV, dBμV, dBμA
Linear scale and units W, mW, μW, A, mA, μA, V, mV, μV
Marker level readout 0.01 dB
Resolution 0.01% of reference level Log scale
Number of traces 4 Linear scale
Detectors Positive-peak, negative-peak, sample,
normal, RMS
Trace functions Clear/write, maximum hold, average,
minimum hold, view
Preamplifier
Frequency range 1 MHz to 3.0 GHz
Gain 18 dB nominal
5
Dynamic Range Specifications
Supplemental information
1 dB gain compression
Preamp off 50 MHz to 3.0 GHz > 0 dBm, typical; total power at input mixer
Preamp on 50 MHz to 3.0 GHz > -20 dBm, typical; total power at the preamp
Total power at the preamp = total power at the input
(dBm) - input attenuation (dB)
Displayed average noise level (DANL)
Input terminated, 0 dB RF attenuation, RBW = 10 Hz, VBW = 1 Hz, sample detector
Preamp off 9 to 100 kHz < -90 dBm, nominal
100 kHz to 1 MHz < -90 dBm – 3 x (f/100 kHz) dB
1 to 10 MHz < -124 dBm
10 MHz to 3 GHz < -130 dBm + 3 x (f/1 GHz) dB
Preamp on 100 kHz to 1 MHz < -108 dBm – 3 x (f/100 kHz) dB
1 to 10 MHz < -142 dBm
10 MHz to 3 GHz < -148 dBm + 3 x (f/1 GHz) dB
Spurious response
Preamp off, signal input -30 dBm, 0 dB RF attenuation
Second harmonic distortion 10 to 200 MHz +30 dBm
200 to 500 MHz +35 dBm
500 MHz to 3 GHz +43 dBm
Preamp off, signal input -30 dBm, 0 dB RF attenuation
Third-order intermodulation (TOI) 300 MHz to 3 GHz +10 dBm; +13 dBm nominal
6
Dynamic Range Specifications (continued)
Supplemental information
Spurious response (continued)
Input related spurious < -60 dBc -30 dBm signal at input mixer, 20 to 30 °C
Residual response (inherent) < -83 dBc Input terminated and 0 dB RF attenuation, preamp off
Phase noise Specification Typical
Offset from CW signal 10 kHz < -88 dBc/Hz < -90 dBc/Hz
Fc = 1 GHz, RBW = 1 kHz, VBW = 10 Hz,
and sample detector, log average,
average times > 40
Residual FM ≤ 100 Hz peak-to-peak
100 kHz < -100 dBc/Hz < -102 dBc/Hz
1 MHz < -110 dBc/Hz < -112 dBc/Hz
1 kHz RBW, 1 kHz VBW
in 100 ms
Tracking Generator Specifications (Option TG3 required)
Supplemental information
Output frequency
Range 100 kHz to 3 GHz Settable to 9 kHz
Resolution 1 Hz
Output power level
Range -30 to 0 dBm
Resolution 0.1 dB
Absolute accuracy ± 0.75 dB 20 to 30 °C, at 50 MHz with coupled source attenuator,
referenced to -20 dBm
Output flatness ± 3 dB 100 kHz to 10 MHz
± 2 dB 10 MHz to 3 GHz
VSWR < 1.5:1 300 kHz to 3 GHz, input attenuator ≥ 12 dB
Connector and impedance N-type female, 50 Ω
Maximum safe reverse level
Average total power 30 dBm (1 W)
AC coupled 0 VDC MAX
7
Modulation Analysis Specifications
Supplemental information
Demodulation
Frequency range 10 MHz to 3 GHz
Carrier power accuracy ± 2 dB ± 1 dB typical
Input power -30 to +20 dBm Auto attenuation
Carrier power displayed resolution 0.01 dBm
AM measurement (included in Option AMA)
Modulation rate 20 Hz to 100 kHz
Accuracy 1 Hz, nominal Modulation rate < 1 kHz
< 0.1% modulation rate, nominal Modulation rate ≥ 1 kHz
Depth 5 to 95%
Accuracy ± 4% nominal
FM measurement (included in Option AMA)
Modulation rate 20 Hz to 200 kHz
Accuracy 1 Hz, nominal Modulation rate < 1 kHz
< 0.1% modulation rate, nominal Modulation rate ≥ 1 kHz
Deviation 20 Hz to 400 kHz
Accuracy ± 4% nominal
ASK measurement (included in Option DMA)
Symbol rate range 200 Hz to 100 kHz
Modulation depth/index range 10 to 90%
Accuracy ± 4% of reading, nominal
Displayed resolution 0.1%
FSK measurement (included in Option DMA)
Symbol rate range 1 to 100 kH
FSK deviation range 1 to 400 kHz
Accuracy ± 4% nominal β ≥1 and β≤4, β is the ratio of frequency
deviation to symbol rate
Displayed resolution 0.01 Hz
8
Inputs and Outputs
Supplemental information
Front panel
RF input connector N-type female, 50 Ω
VSWR < 1.5:1 300 kHz to 3 GHz, input attenuator ≥ 10 dB
Calibration output Amplitude -10 dBm ± 0.3 dB
Frequency 50 MHz
Accuracy Same as the frequency reference
Connector and impedance BNC-type female, 50 Ω
Probe power Voltage/current +15 V, 150 mA maximum
-12.6 V, 150 mA maximum
RF output connector N-type female, 50 Ω Option TG3 installed
USB interface (host) A plug, version 1.1
Rear panel
10 MHz reference output Output amplitude > 0 dBm
Connector and impedance BNC-type female, 50 Ω
10 MHz reference input Input amplitude -5 to +10 dBm
Frequency lock range ± 5 ppm of specified external reference input
frequency
Connector and impedance BNC-type female, 50 Ω
External trigger input Input amplitude 5 V TTL level
Connector and impedance BNC-type female, 10 kΩ
VGA output VGA analog RGB 31.5 kHz horizontal, 60 Hz vertical sync rates,
non-interlaced
D-sub 15-pin female connector VGA compatible
640 x 480 screen resolution
LAN TCP/IP interface 10Base, RJ-45 connector
USB interface (device) B plug, version 1.1
GPIB interface IEEE-488 bus connector Optional G01 installed
9
General
Supplemental information
Temperature range
Operating +5 to +45 °C
Storage -20 to +70 °C
EMC
Complies with European EMC Directive 2004/108/EC
• IEC/EN 61326-1 or IEC/EN 61326-2-1
• CISPR Pub 11 group 1, class A
• AS/NZS CISPR 11:2004
• ICES/NMB-001:2004
This ISM device complies with Canadian ICES-001
Safety
Complies with European Low Voltage Directive 2006/95/EC
• IEC/EN 61010-1 2nd Edition
• Canada: CSA C22.2 No. 61010-1-04
• USA: UL 61010-1 2nd Edition
Audio noise
Acoustic noise emission
LpA < 70 dB
Operator position
Normal position
Per ISO 7779
Environmental stress
Samples of this product have been type tested in accordance with the Agilent Environmental Test Maunal and verified to be
robust against the environmental stresses of storage, transportation, and end-use; those stresses include, but are not limited to,
temperature, humidity, shock, vibration, altitude, and power line conditions. Test methods are aligned with IEC 60068-2
and levels are similar to MILPRF-28800F Class 3
Power requirements
Voltage and frequency (nominal) 100 to 240 VAC, 50 to 60 Hz Auto ranging
Power consumption < 65 W
Display
Resolution 640 x 480
Size 165.1 mm (6.5 in) diagonal (nominal)
Data storage
Internal 16 MB nominal
External Supports USB 2.0 compatible memory
devices
10
General (continued)
Supplemental information
Weight (without options)
Net 8.4 kg (18 lbs) nominal
Shipping 14.5 kg (32 lbs) nominal
Dimensions
Height 132.5 mm (5.2 in) 3U rack height
Width 320 mm (12.6 in)
Length 400 mm (15.7 in)
Warranty
The N9320B spectrum analyzer is supplied with a one-year warranty
Calibration cycle
The recommended calibration cycle is one year. Calibration services are available through Agilent Service Centers
Related Literature
• Agilent N9320B RF Spectrum Analyzer, Brochure, literature number 5990-8118EN
• Agilent N9320B RF Spectrum Analyzer, Configuration Guide, literature number 5990-8120EN
11
www.agilent.com
www.agilent.com/find/n9320b
Agilent Email Updates
www.agilent.com/find/emailupdates
Get the latest information on the
products and applications you select.
Agilent Channel Partners
www.agilent.com/find/channelpartners
Get the best of both worlds: Agilent’s
measurement expertise and product
breadth, combined with channel
partner convenience.
Agilent Education Corner
www.agilent.com/find/edu
Your one-stop education resource for
college and university engineering
educators, researchers and students
Agilent Product Registration
www.agilent.com/find/register
Register your instruments for service
notifications, firmware update alerts,
application notes and more. You have
the Agilent edge. Register today and
keep it sharp
Agilent Advantage Services is committed
to your success throughout your equipment’s lifetime. To keep you competitive,
we continually invest in tools and
processes that speed up calibration and
repair and reduce your cost of ownership.
You can also use Infoline Web Services
to manage equipment and services more
effectively. By sharing our measurement
and service expertise, we help you create
the products that change our world.
www.agilent.com/find/advantageservices
www.agilent.com/quality
For more information on Agilent
Technologies’ products, applications or
services, please contact your local Agilent
office. The complete list is available at:
www.agilent.com/find/contactus
Americas
Canada (877) 894 4414
Brazil (11) 4197 3500
Mexico 01800 5064 800
United States (800) 829 4444
Asia Pacific
Australia 1 800 629 485
China 800 810 0189
Hong Kong 800 938 693
India 1 800 112 929
Japan 0120 (421) 345
Korea 080 769 0800
Malaysia 1 800 888 848
Singapore 1 800 375 8100
Taiwan 0800 047 866
Other AP Countries (65) 375 8100
Europe & Middle East
Belgium 32 (0) 2 404 93 40
Denmark 45 70 13 15 15
Finland 358 (0) 10 855 2100
France 0825 010 700*
*0.125 €/minute
Germany 49 (0) 7031 464 6333
Ireland 1890 924 204
Israel 972-3-9288-504/544
Italy 39 02 92 60 8484
Netherlands 31 (0) 20 547 2111
Spain 34 (91) 631 3300
Sweden 0200-88 22 55
United Kingdom 44 (0) 131 452 0200
For other unlisted countries:
www.agilent.com/find/contactus
Revised: June 8, 2011
Product specifications and descriptions
in this document subject to change
without notice.
© Agilent Technologies, Inc. 2011
Published in USA, November 4, 2011
5990-8119EN
Loading...
