Agilent N9311X RF and
Microwave Accessory Kit for
Low-cost Handheld and
Benchtop Solutions
N9311x-500
70 to 1000 MHz
N/A
65 g
113.5 cm (full length),
19.5 cm (retracted), 10 stages
N9311x-504
N9311X-500
N9311X-501
N9311X-504
Bandpass Filter
Antenna
700 MHz-4 GHz
4 dBi
270 g
340 x 200 x 25 mm
N9311x-518
680 MHz-18 GHz
5 dBi
250 g 340 x 200 x 25 mm
180 degrees tilt angle adjustable telescopic whip
antenna, shipped with type N(m) to type BNC(f) adapter
Logarithmic-periodic
Logarithmic-periodic
N9311X-550
814 to 850 MHz
Bandpass filter 3 dB Passband Rejection Insertion loss
VSWR
≥36 dBc @ 740 MHz
≥36 dBc @ 915 MHz
≤ 0 .5 dB ≤ 1.5
N9311X-551
N9311X-551
880 to 915 MHz
≥35 dBc @ 862 MHz
≥35 dBc @ 932 MHz
≤ 1 dB ≤ 1.5
N9311X-552
1707.5 to 1787.5 MHz
≥35 dBc @ 1550 MHz
≥35 dBc @ 1925 MHz
≤ 0 .4 dB ≤ 1.5
N9311X-553
1845 to 1915 MHz
≥35 dBc @ 1770 MHz
≥35 dBc @ 1986 MHz
≤ 0 .6 dB ≤ 1.5
N9311X-554
1910 to 1990 MHz
≥35 dBc @ 1825 MHz
≥35 dBc @ 2070 MHz
≤ 0 .6 dB ≤ 1.5
w
Antenna
Frequency
range
Antenna
gain
Weight Dimension
Other information
N/A
N9311x-501
700 to 2500 MHz
70 g
210 x 20 mm
Omni-directional, shipped with type N(m) to type
SMA(f) adapter
N9311x-508
680 MHz-8 GHz 5 dBi 250 g 340 x 200 x 25 m m
Logarithmic-periodic
N9311X RF and Microwave Accessory Kit complements Agilent's low-cost handheld
and
benchtop solutions (N934xC/N9340B/N9330B/N9310A/N9320B/N9000A).
These accessories provide you with a complete solution for your measurement needs.
*
N9311x-504/508/518 shipping package includes: Antenna, aluminum design carrycase, detachable pistol grip
with "miniature tripod" mode, and type N to type SMA toolset
*
*
*
Phase stable, 1.5 m,
type N(m) to N(m),
DC to 18 GHz
Phase stable, 3.0 m,
type N(m) to N(m),
DC to 18 GHz
1.5 m, type
SMA(m) to SMA(m),
DC to 8 GHz
1.5 m, type
BNC(m) to BNC(m),
DC to 1 GHz
Cable
N9311X-580
Phase stable, 1.5 m,
type N(m) to DIN(f),
DC to 18 GHz
N9311X-585
Phase stable, 1.5 m,
type N(m) to N(f),
DC to 18 GHz
N9311X-586N9311X-581 N9311X-582
N9311X-583
Adapter
N9311X-540
N9311X-541
N9311X-543
N9311X-544
N9311X-545
N9311X-546 N9311X-547
Type N(m) to
BNC(f), DC to
2 GHz
Type N(m)
to SMA(f),
DC to 12.4 GHz
Type N(f) to
BNC(m), DC
to 4 GHz
Type N(f)
to 7/16 DIN(m),
DC to 7.5 GHz
Type N(f) to
SMA(m), DC
to 12.4 GHz
Type N(f) to
N(f), DC
to 18 GHz
N9311X-542
Type N(f)
to 7/16 DIN(f),
DC to 7.5 GHz
Type N(m)
to 7/16 DIN(f),
DC to 7.5 GHz
Attenuator
N9311X-560
40 dB N(m) to N (f)
N9311X-561
40 dB N(m) to N (f)
N9311X-562
40 dB N(m) to N (f)
DC – 4.0 GHz: 1.15
4.0 – 8.5 GHz: 1.2
DC – 4.0 GHz: 1.2
4.0 – 8.5 GHz: 1.3
DC – 4.0 GHz: 1.2
4.0 – 8.5 GHz: 1.3
10 watts average 67.3 mm (2.65 inch) 0.085 kg/3 oz
50 watts average 111.76mm (4.37 inch) 0.28 kg/10 oz
100 watts average 112.01mm (4.41 inch) 1.5 kg/3.3 lb
Attenuator Attenuation Port VSWR Power rating Length Weight
N9311X-561
2
N9311x-201 Mechanical
calibrator
DC to 7 GHz
42 dB 50 Ω
Calibrator
Calibrator
Type
N(m)
Connector
3-in-1 OSL
OtherFrequency range Directivity
Impedance
Close Field Probe Set
30 MHz to 3 GHz 30 MHz to 3 GHz 30 MHz to 2 GHz 30 MHz to 3 GHz
3
N9311X-100
