Agilent N432A
Key features
• Power range: –30 dBm (1 μW) to +10 dBm (10 mW)
• High accuracy ± (0.1% of reading + 0.5 μW), excellent for 1 mW transfer calibration (with 478A-H75)
Thermistor Power Meter
Data Sheet
• Built in 6.5 digit ADC eliminates the need of external DMM
• Selectable bridge resistance (100/200/300/400 Ω)
• Remote interface flexibility
• DC substitution measurement, traceable to the U.S. National Institute of Standards and Technology (NIST)
Agilent’s only power meter that supports thermistor mount with useful enhancements for metrology and calibration lab environments.
Why Agilent’s Power Meters and Sensors?
Reliable, high-performing solutions
Every power meter and sensor from Agilent consistently delivers great results.
A sure investment for many years to come
Code-compatibility between power meters reduces the need for re-coding. Not only that, all Agilent power meters are backward-compatible with most legacy power sensors.
One specific application: One right solution
Agilent offers a wide selection of power meters and sensors for practically all application needs—wireless communications, radar pulse measurements, component test, and more.
Global network support
No matter where you are, Agilent is committed to giving you the 24-hour support you need regarding our products, applications, or services.
Agilent’s power meters have long been recognized as the industry standard for RF and microwave power measurements.
2
We Listened to the Industry, Then Delivered a Better and Easier Replacement Solution for the Legacy 432A Analog Power Meter
LXI Class-C compliant N432A
As today’s power measurements become more complex, it is increas­ingly difficult to make reliable, accu­rate power measurements. For more than 40 years, you’ve depended on Agilent’s 432A analog power meter, used with temperature compensated thermistor sensors to provide high accuracy over a wide temperature range.
Today, the Agilent N432A digital thermistor power meter, loaded with enhancements, including a color digital display, and intuitive front panel interface will continue support your measurement needs with greater capability and expanded functionality. Best of all, you can get these extras at just a fraction of the price of the legacy 432A.
The N432A is a single-channel, aver­age RF power measurement meter that supports thermistor sensors. The N432A has the capability to measure and display average power, RF bridge voltages (V bridge voltages (V
and V
RF0
), compensation
RF1
and V
COMP0
COMP1
), V0, and V1. It is also provided with a set of features such as zeroing and a built-in self-test.
Developed using LXI technology, the N432A is an LXI Class-C compli­ant instrument.1 The N432A basic configuration consists of two key sections: bridge and meter logic. When a compatible thermistor sensor is connected to the N432A, the RF and compensation bridge circuits are formed in the bridge section. VRF, which is the voltage at the top of the RF bridge, is responsive to both input
RF power and ambient temperature changes. On the other hand, V
COMP
, which is the voltage at the top of the compensation bridge, is responsive only to ambient temperature changes. The VRF and V
values are used in
COMP
calculating the RF power. Meanwhile, the meter logic section processes VRF and V
to produce a meter current
COMP
proportional to RF power.
In general, the N432A is an easy-to-use instrument, especially with the availability of an integrated Web browser that provides a con­venient way to view and modify the instrument network configuration. Besides the LAN interface, the N432A also supports industry standard GPIB and USB interfaces for measurement automation.
1. LXI, an acronym for LAN eXtension for Instrumentation, is an instrument standard for devices that use the Ethernet (LAN) as their primary communication interface.
3
High accuracy—no thermoelectric error
The high accuracy ± (0.1% of reading + 0.5 μW) over a wide temperature range featured in the legacy 432A power meter is also included in the N432A, making it excellent for 1 mW transfer calibration (with 478A-H75/ H76*). Accuracy can be maintained on even the most sensitive range as the error due to thermoelectric effect is reduced to a negligible level.
* 478-H75/H76 has a maximum SWR of
1.05 at 50 MHz
Sensor compatibility
The N432A is compatible with the Agilent 478A and 8478B thermistor sensors. The following table lists the frequency range and operating resistance for these two sensors:
Thermistor sensor model Frequency range (GHz) Operating resistance (Ω)
478A 0.01 to 10 200
478A Option H63 0.000001 to 1 200
478A Option H75 0.001 to 1 200
478A Option H76 0.001 to 1 200
8478B 0.01 to 18 200
For further information on the thermistor sensors, refer to the respective manuals.
4
Take a Closer Look
N432A front panel
High-resolution color LCD display for easy viewing of test results
Display key allows selection of the display format for the active window (single/split screen)
Display key allows selection of the display mode (windowed, expanded, or full­screen) of numeric measurements
Soft keys provide menu selection
Hard keys provide quick access to the most frequently used functions, such as System, Trigger, and Acquisition, etc.
Arrow keys enable navigation of parameter entry screens, values selection, and entering of text
Numeric keypad for easy entry of numeric values
Power reference of 1 mW (0 dBm)
Channel sensor connector
N432A back panel
and V
V
RF
output terminals for calibrating the N432A and for precision power measurements
COMP
DC recorder outputs (DC voltage corresponds
Ground connector
to the power level of the channel input)
Go beyond GPRB with USB and LAN/LXI-C interface
Line power accepts voltage with automatic range selection
5
Specifications and Characteristics
Specifications describe the instrument’s warranted performance and apply after a 30 minute warm-up.
These specifications are valid over its operating/environmental range unless otherwise stated and after performing a zero and calibration procedure.
Supplemental characteristics (shown in italics) are intended to provide additional information, useful in applying the instru­ment by giving typical (expected), but not warranted performance parameters. These characteristics are shown in italics or labeled as “typical”, “nominal” or “approximate”.
General specifications
Frequency range 100 kHz to 18 GHz, sensor dependent
Power range –30 to +10 dBm (1 μW to 10 mW), thermistor-sensor dependent
Compatible power sensors • Agilent 478A thermistor sensor (100 kHz to 10 GHz, with option H63)
• Agilent 8478B thermistor sensor (10 MHz to 18 GHz)
Meter power accuracy Power absolute accuracy ± (0.1% of reading + 0.5 μW)
Meter voltage accuracy (1-year reference specifications) VRF and V V0 and V
COMP
1
Bridge resistance 100, 200, 300, or 400 Ω (user selectable)
Display units Power Relative V
, V
, V0, and V
RF
COMP
1
Bridge resistance
Display resolution Power
Default resolution Voltage Bridge resistance
23 °C ± 5 °C: ± (0.0035% + 50 µV) [reading + range] 23 °C ± 5 °C: ± (0.0040% + 25 µV) [reading + range]
Watts (W) or dBm Percent (%) or dB VDC and mVDC Ohm
Selectable resolution of: 1.0, 0.1, 0.01 and 0.001 dB in logarithmic mode, or 1, 2, 3, and 4 significant digits in linear mode
0.01 dB in logarithmic mode or three digits in linear mode
6.5-digit resolution
6.5-digit resolution
6
Specifications and Characteristics (continued)
Power meter functions
Accessed by key entry Either hard keys, or soft key menu, and programmable
Zero Zeros the meter. (Power reference calibrator is switched off during zeroing)
Frequency Entered frequency range is used to interpolate the calibration factors table. Frequency range from
1 kHz to 999.9 GHz
Bridge resistance type Setting the bridge resistance, user-selectable Rmeasure (factory set) or Ruser (measured by user)
Cal factor Sets the cal factor versus frequency for the calibration factor for power sensor. Range: 1.00% to
150.00%, in 0.01% increments. Cal factor can be set from either CF table or single entry CF
Relative Displays all successive measurements relative to the last displayed value
Offset Allows power measurements to be offset by –100 to +100 dB, settable in 0.001dB increments, to
compensate for external loss or gain. Offset table can be set from either CF table or single entry CF
Save/recall Store up to 10 instrument states via the save/recall menu
Measurement averaging Selectable from 4 to 128
Duty cycle Duty cycle values between 0.001 to 99.999%, in 0.001% increments, can be entered to display a
peak power representation of measured power. The following equation is used to calculate the displayed peak power value: peak power = measured power/duty cycle
Limits High and low limits can be set in the range –150.000 to +230.000 dBm, in 0.001 dBm increments
Preset default values dBm mode, relative off, power reference off, duty cycle off, offset off, frequency 50 MHz,
measurement averaging 16, free run
Display Color display with selectable single and split screen formats are available. User selectable on
digital measurement type or analog scale presentation
1 mW (0 dBm) power reference
1.0 mW (0.0 dBm), 50 MHz from type N (f) connector on the front panel, for power meter/sensor function check.
Accuracy (for two years)
SWR
± 0.4% (25 ± 10 ºC) ± 1.2% (0 to 45 ºC)
1.06 maximum
7
Specifications and Characteristics (continued)
Power meter general specifications
Dimensions The following dimensions exclude
front and rear protrusions:
212.6 mm W x 88.5 mm H x 348.3 mm D (8.5 in x 3.5 in x 13.7 in)
Weight Model Net Shipping
N432A 3.6 kg (8.0 lb) 8.2 kg (18.1 lb)
Rear panel connectors
VRF output VRF BNC terminal outputs the RF bridge voltage, used to connect to external DMM for more
precise power measurement
V
output V
COMP
Recorder output Analog 0 to 1 V, 1 kΩ output impedance, BNC connector
GPIB, USB 2.0 and 10/100BaseT LAN Interfaces to allow communication with an external controller
Ground Binding post, accepts 4 mm plug or bare wire connection
Line power Input voltage range
Input frequency range
Power requirement 70 VA
BNC terminal outputs the compensation bridge voltage, used to connect to external
COMP
DMM for more precise power measurement
100 – 240 VAC, automatic selection 220 – 240 V ±10% 50 – 60 Hz, 400 Hz 400 Hz (100 – 120 Vac)
8
Specifications and Characteristics (continued)
Environmental characteristics
Electromagnetic compatibility Complies with the essential requirements of EMC Directive (2004/108/EC) as follows:
• IEC61326-1:2005 / EN61326-1:2006
• CISPR11:2003 / EN55011:2007 (Group 1, Class A)
The product also meets the following EMC standards:
• Canada: ICES/NMB-001:2004
• Australia/New Zealand: AS/NZS CISPR 11:2004
Product safety This product conforms to the requirements of the following safety standards:
• IEC 61010-1:2001 / EN 61010-1:2001
• CAN/CSA-C22.2 No.61010-1-04
• ANSI/UL61010-1:2004
Low voltage directive This product conforms to the requirements of European Council Directive “2006/95/EC”
Operating environment Temperature Maximum humidity Minimum humidity Maximum altitude
Storage conditions Non-operating storage temperature Non-operating maximum humidity Non-operating maximum altitude
Remote programming Interface Command language GPIB compatibility
0 °C to 45 °C 95% at 40 °C (non-condensing) 15% at 40 °C (non-condensing) 4,600 m (15,000 ft)
–40 °C to +70 °C 90% at 65 °C (non-condensing) 4,600 m (15,000 ft)
GPIB, USB, and LAN interfaces operates to IEEE 488.2 standard SCPI standard interface commands SH1, AH1, T6, TE0, L4, LE0, SR1, RL1, PP1, DC1, DT1, C0
9
Ordering Information
Standard product
N432A Thermistor power meter
Standard shipped accessories • Thermistor sensor adaptor cable 1.5 m* (5 ft)
• Power cord (country dependant)
• USB adaptor cable
• Agilent N432A thermistor power meter product reference CD-ROM
• Envelope—calibration certificate
• IO libraries media suite
Warranty • Standard 1-year, return-to-Agilent warranty and service plan
• 3 months for standard shipped accessories
Power sensors, accessories, calibration, and documentation options
478A-H13 Frequency range 100 kHz to 1 GHz, with maximum SWR 1.8 to 300 KHz, 1.3 to 1 GHz. Include 13
frequency points Standard Lab calibration
478A-H55 Frequency range 1 MHz to 1 GHz, with maximum SWR 1.3
478A-H63 Frequency range 100 kHz to 1 GHz, max SWR 1.8 to 300 kHz, 1.3 to 1 GHz
478A-H72 Frequency range 1 MHz to 1 GHz, with maximum SWR 1.2
478A-H73 Frequency range 1 MHz to 100 MHz, with maximum SWR 1.1, except 1.05 at 50 MHz
478A-H75 Frequency range 1 MHz to 1 GHz, max SWR 1.3 except 1.05 at 50 MHz
478A-H76 Frequency range 1 MHz to 1 GHz, max SWR 1.3 except 1.05 at 50 MHz. Standard lab calibration at
50 MHz
478A-H83 Frequency range 1 MHz to 1 GHz, with maximum SWR 1.3, except 1.05 at 50 MHz Include 8
frequency points Standard Lab calibration
478A-H93 Frequency range 1 MHz to 1 GHz, with maximum SWR 1.3, except 1.05 at 50 MHz Include 2
frequency points Standard Lab calibration
8478B-H01 Frequency range 10 MHz to 18 GHz, with maximum SWR 1.05 at 50 MHz
8478B-H27 Frequency range 10 MHz to 18 GHz. Include Standard Lab calibration at 9 MHz
N4998A Thermistor sensor adaptor cable 1.5 m (5 ft)
N4998B Thermistor sensor adaptor cable 3 m (10 ft)
N4998C Thermistor sensor adaptor cable 6.1 m (20 ft)
N432A-908 Rackmount kit with 1 unit with blank filler included
N432A-909 Rackmount kit with 2 units side-by-side
N432A-OBK English language user guide and English programming guide
N432A-ABJ Japanese user guide and English programming guide
N432A-0B1 English language user guide and installation guide
N432A-0BF English language programming guide
N432A-A6J Certificate of compliance calibration - ANSI/NCSL Z540
N432A-1A7 Compliant calibration test data - ISO17025
* The 1.5 m (5 ft) standard cable can be replaced with a 3 or 6.1 m (10 or 20 ft) cable, charges apply
10
www.agilent.com
s
www.agilent.com/find/N432A
myAgilent
myAgilent
www.agilent.com/find/myagilent
A personalized view into the information most relevant to you.
www.axiestandard.org
AdvancedTCA Instrumentation and Test (AXIe) is an open standard that extends the AdvancedTCA for general purpose and semiconductor test. Agilent is a founding
member of the AXIe consortium.
www.lxistandard.org
LAN eXtensions for Instruments puts the power of Ethernet and the Web inside your test systems. Agilent is a founding member of the LXI consortium.
www.pxisa.org
PCI eXtensions for Instrumentation (PXI) modular instrumentation delivers a rugged, PC-based high-performance measurement and automation system.
®
Extensions for
Agilent Channel Partners
www.agilent.com/find/channelpartners
Get the best of both worlds: Agilent’s measurement expertise and product breadth, combined with channel partner
convenience.
Three-Year Warranty
www.agilent.com/find/ThreeYearWarranty
Agilent’s combination of product reliability and three-year warranty coverage is another way we help you achieve your business goals: increased confidence in uptime, reduced cost of ownership and greater convenience.
Agilent Advantage Services
www.agilent.com/find/AdvantageServices
Accurate measurements throughout the life of your instruments.
Agilent Electronic Measurement Group
DEKRA Certified
ISO 9001:2008
Quality Management SystemQuality Management Sy
www.agilent.com/quality
For more information on Agilent Technologies’ products, applications or services, please contact your local Agilent
office. The complete list is available at:
www.agilent.com/find/contactus
Americas
Canada (877) 894 4414 Brazil (11) 4197 3600 Mexico 01800 5064 800 United States (800) 829 4444
Asia Pacifi c
Australia 1 800 629 485 China 800 810 0189 Hong Kong 800 938 693 India 1 800 112 929 Japan 0120 (421) 345 Korea 080 769 0800 Malaysia 1 800 888 848 Singapore 1 800 375 8100 Taiwan 0800 047 866 Other AP Countries (65) 375 8100
Europe & Middle East
Belgium 32 (0) 2 404 93 40 Denmark 45 45 80 12 15 Finland 358 (0) 10 855 2100 France 0825 010 700* *0.125 €/minute Germany 49 (0) 7031 464 6333 Ireland 1890 924 204 Israel 972-3-9288-504/544 Italy 39 02 92 60 8484 Netherlands 31 (0) 20 547 2111 Spain 34 (91) 631 3300 Sweden 0200-88 22 55 United Kingdom 44 (0) 118 927 6201
For other unlisted countries: www.agilent.com/find/contactus
(BP-3-1-13)
Product specifications and descriptions in this document subject to change without notice.
© Agilent Technologies, Inc. 2013 Published in USA, March 25, 2013 5990-5740EN
Loading...
