Asustor AS3204T User Manual

A Multimedia Entertainment Storage Solution

With A Powerful Processor

AS3204T

The AS3204T provides home users with a quad-core multimedia
entertainment storage solution featuring maximum cost-effectiveness,
comprehensive functionality and enhanced graphics processing speed. The
4 disk bays provide high capacity storage, allowing prized digital assets to
be preserved in original high quality formats.

AES-NI

Write: 110 MB/s

Read: 112 MB/s

ULTRA HD

ASUSTOR AS3204T

Powered by the latest Intel Celeron processors

AS3204T is powered by Intel Celeron Braswell quad-core processor, equipped with 2GB of dual-channel memory,

and feature read speeds of over 112 MB/s and write speeds of over 110 MB/s under RAID 1 configurations.

*Performance results may differ depending on the testing environment.

Dual-channel power

The AS32 models support dual-channel memory, be able to smoothly playback 4K video. Furthermore, AS32 series
devices are not only energy efficient, but offer a combination of performance and price that is unmatched in its class.
Get ready to enjoy brilliant ultra high-definition 4K video from the comfort of your own home!

Supercharge your multimedia experience

You no longer need to worry about running into
resolution compatibility issues when playing
videos on your phone, tablet or computer.

Media Converter utilizes a quick and simple

conversion method, allowing you to execute
conversion tasks in the background.

The exclusive built-in Hyper-Transcoding
technology was expertly crafted by ASUSTOR.
This technology utilizes the Intel CPU

hardware acceleration function to make video

file conversions faster and simpler than ever
before. Using Hyper-Transcoding to convert
video files can reduce the normal conversion
time by at least 10 times.

Toolless installation

The AS32 series’ sliding outer cover design allows it to be conveniently removed when needed. The inner hard disk rails
and outer cover all use hand screws allowing for the simple installation of hard disks without any extra tools.

Hardware encryption engine

Protecting your data is ASUSTOR’s top priority. The AS32 series
devices feature Intel AES-NI encryption engines, allowing data to be
completely protected from the moment it is first stored on the NAS.
This means that you never have to worry about your confidential
data falling into the wrong hands even if your hard disks become
lost or stolen. The built-in hardware encryption engine also features

read speeds of over 111 MB/s and write speeds of over 79 MB/s for

encrypted data providing an optimal combination of file security
and system performance.

Add modern flair to your favorite space

The AS32 series devices redefine the aesthetics of a NAS. The stylish
diamond-plate finished cover makes it an elegant addition to any
space, no matter if it is a family room, living room or office.

A Surge in Data Transfer Performance

ADM supports SMB 2.0 which reduces the burden of network traffic on the NAS while simultaneously providing greater
data transfer capacity. In the ASUSTOR testing environment, SMB 2.0 was found to increase Windows networking
performance by 30%-50%*. SMB 2.0 also significantly increases the number of concurrent Windows client connections and
simultaneously open files, making ADM even more suitable for large-scale Microsoft network environments.

* Actual performance may vary due to differences in the installation environment. SMB 2/3 is supported in Windows Vista and later versions of the
Microsoft Windows operating system.

Seamless Cross-Platform File Sharing

ASUSTOR NAS devices provide seamless cross-platform file sharing, allowing you to easily connect to your NAS device no
matter if you are using Windows, Mac OS, or Unix-like operating systems. The transfer protocols that you may use to
connect to an ASUSTOR NAS device are as follows:

Windows: CIFS/SMB, FTP and WebDAV
Mac OS X: AFP, SMB, NFS, FTP and WebDAV
Linux: NFS, SMB, FTP and WebDAV

Enhanced Recycle Bin mechanism

The Network Recycle Bin mechanism is now based on individual
shared folders rather than storage volumes. According to their
needs, users can decide whether or not to enable a Network
Recycle Bin for each individual shared folder, enjoying added
configuration flexibility. Files that are moved to the Recycle Bin
maintain their original directory structure, allowing added
convenience should users need to search for already deleted files.
The simple one-click restore function will restore selected files to
their original directory path while conveniently maintaining all
properties and permissions settings.

Ultimate data protection

ASUSTOR NAS makes use of RAID storage technology to provide protection for your data. RAID mainly revolves around
the core concept of combining your disks to protect the data inside. ASUSTOR offers a number of different RAID level
configurations that you can choose from when creating storage volumes. Each RAID level offers a differing degree of
data protection, system performance and storage space. ASUSTOR’s supported RAID levels are summarized in the
chart below:

Single

JBOD

RAID 0

RAID 1

RAID 5

RAID 6

RAID 10

Minimum number

of disks

Faulty Disks

Tolerated

Increased System

performance

Maximum use of

Storage space

1

X

X

V

2

X

X

V

2

X

V

V

2

1

X

X

3

1

V

X

4

2

V

X

4

2

V

X

Online Capacity Expansion

Insufficient storage space forcing you to consider upgrading your NAS to one with more disk bays?
ASUSTOR NAS supports online capacity expansion¹ which means that you can easily swap out all your old disks for
higher capacity ones without turning off your NAS. Now you can increase the storage capacity of your NAS without
worrying about getting an entire new system.

During the capacity expansion process, while your data is being transferred over to the new disks, you will still be able
to access everything on the NAS. Online capacity expansion does not require any advanced IT skills to execute and
helps you to eliminate cumbersome backup and migration procedures. When it's time to upgrade your NAS's capacity,
ASUSTOR simply gets the job done for you without missing a beat.

¹ You must use RAID 1, 5, 6, or 10

The ultimate tool for remote backup

Rsync is an application originally developed for UNIX that is
usually used for backup and sync between two computers. By
providing block level replication, Rsync is able to offer incremental
backup. Incremental backup allows for successive backup jobs
(after your first backup job) to only copy data that has changed
since your last backup job. Rsync is suitable for use with files and
data that are always changing. It lets you cut down on backup
time while significantly reducing bandwidth usage.

A rich and flexible backup solution

ASUSTOR's Rsync Backup function supports two-way data transfers, incremental backup, encrypted backup and also
the scheduling of your NAS to perform regular backup jobs. It effectively simplifies data backup while also substantially
reducing the burden on IT staff. ASUSTOR's Rsync backup function may be used to complete tasks such as:

- The transfer or backup of data from your NAS to an Rsync compatible server

- Initiating downloads of the data from an Rsync compatible server to your NAS

Regular backups of your vital data

The External backup function supports two-way data transfers,
incremental backups and also the scheduling of your NAS to perform
regular backup jobs. It may be used to complete tasks such as:

- The transfer or backup of the data from your NAS to an external device.

- Initializing the copying of data from an external device to your NAS

Create a hybrid cloud, protect and secure your data

Now home and business users alike can back up the data from their ASUSTOR NAS to
popular cloud storage services, including Amazon S3, Google Drive, HiDrive, OneDrive,
Dropbox further ensuring the protection of their data. This means that in the event that
the data on your NAS is damaged you will be able to immediately restore it from cloud
storages.

Windows Backup

ASUSTOR's Backup Plan software for Windows provides
you with worry-free backup. Simply schedule a regular
backup job of your PC to your NAS, then let Backup Plan
take care of the rest. Backup Plan will work in the
background to ensure that your PC is always backed up.

Any data that is lost between scheduled backups is

unprotected. Backup Plan lets you configure real time
file synchronization for those important and
ever-changing file folders. Any changes that you make
to your protected files and folder will be updated in real
time. Now you can rest assured knowing that your
critical files are always protected and up to date.

Mission Mode

Never again worry about your critical backup jobs
stopping or failing to complete because your ASUSTOR
NAS won't stop until it’s “mission complete”.

Sometimes backup jobs may be stopped because of
various connection problems with a busy server on the

other end. For Rsync, FTP, external and cloud backups,
ASUSTOR’s Mission Mode allows you to configure the

number of connection attempts and time interval for

connection attempts, ensuring for the successful
completion of your backup mission. This also gives IT
administrators a significant amount of flexibility when
configuring backup jobs.

Time Machine Backup

Mac lovers rejoice! You can use your Mac's built-in

backup, Time Machine, to easily back up your Mac to an

ASUSTOR NAS. All ASUSTOR NAS devices have been
optimized for use with Time Machine, providing Mac
lovers with a familiar and easy to use backup solution.

Different Mac users can now safely backup their

computers to the same NAS device. Unlike other NAS
devices, ASUSTOR NAS does not just use one group

account to carry out backup jobs for all Mac users,

storing all their jobs under the same directory. With
ASUSTOR NAS each Mac user is able to use an

independent account and backup location thereby

guaranteeing privacy for all.

A cost-effective and efficient mail service solution

The ability to send and receive email is fundamental to all businesses. However, expensive implementation costs and
complicated management create barriers for most small and medium sized businesses. ASUSTOR’s Mail Server offers

a comprehensive and cost-effective solution that allows any business to easily maintain their own dedicated mail

server.

System Notifications

Always checking up on your NAS? Worried about your
data and other digital assets? ASUSTOR NAS features
real-time system event notifications allowing you to
enjoy peace of mind knowing that you'll be notified
about any major system events. Notifications can be
sent via Email, SMS or push notification giving you a

variety of ways to instantly stay on top of the latest

developments.

Your own FTP server

FTP is one of the most widely used and popular transfer protocols in the world. Every ASUSTOR NAS has a built-in
FTP server feature that allows you to create a personal FTP server in just a matter of seconds. Hosting your own FTP
server will instantly give you the power to share and exchange files over the internet.

With FTP server, you will be able to access your NAS via FTP from almost anywhere in the world. No matter if you are
on a business trip or vacation, or wish to share files with family and friends, all that's needed is a device with internet
access and the data on your NAS can be accessed in no time.

Firewall

Use ADM Defender's firewall to control access to your
NAS. Ensure the security of your system by deciding
who has access to your NAS and who doesn't.

Secure connections – VPN

ASUSTOR NAS supports VPN connections giving you
secure access and flexible deployment options. Your
NAS is able to act as a VPN client which can then
connect to VPN servers via PPTP or OpenVPN protocols,
allowing you to gain access to different virtual private
networks. ASUSTOR NAS also supports the creation of
multiple VPN connection profiles allowing you to easily
switch connections between different VPN networks.

Network Defender

ADM Defender's Network Defender function

protects you from malicious attacks and prevents

hackers from trying to access your NAS. Any client
IP addresses with too many unsuccessful login
attempts to your NAS within a specified time period
will be blocked by Network Defender.

In addition to the existing automatic black list
function, a trusted list is now provided. The trusted
list can prevent trusted IP addresses from being

automatically blocked in the event of too many

inadvertent login failures. Furthermore, when
manually defining the black and white lists, users
can now specify the IP country of origin or area via
the Geo IP expansion module in addition to
specifying the IP address or segment, providing
added flexibility.

Effectively simplifying network management

Syslog Server supports standard Syslog protocols and can centrally aggregate system logs that are spread out over
various network devices for storage and management. Furthermore, Syslog Server integrates with the NAS’s Instant
Notification function, allowing administrators to receive e-mails or SMS notifications when specified events occur, in
order to quickly employ appropriate measures.

Folder-based AES 256-bit Encryption

Your most important data deserves the best security. ASUSTOR NAS offers folder based military grade AES 256-bit
encryption, giving you the type of security and privacy that you require for your most confidential data. All data stored
in encrypted folders will be automatically encrypted and secured to the highest of standards. Should you ever lose your
NAS or hard disks, you still needn't worry about your sensitive data falling into the wrong hands.

Unlike other NAS devices, ASUSTOR NAS gives you the flexibility to select the individual folders that you want to
encrypt. Other NAS devices encrypt entire storage volumes which significantly slows down the system. Any encrypted
portions of storage volumes will be subject to a decrease in performance. However, with ASUSTOR NAS you are free to
encrypt only your most confidential data while leaving other data unencrypted, creating a perfect balance between
performance and security.

Virtual Drive

Still wasting money and time burning CDs or DVDs
every time you need to install some software?
ASUSTOR NAS supports the mounting of ISO files

which provides you with a cost effective and
environmentally friendly solution that effectively

lowers CD and DVD waste.

External Optical Drive Support

After connecting an external optical drive (CD, DVD,
Blu-ray) to your NAS via USB, you can use File Explorer
to directly access any files that you have backed up to
optical media and even transfer files from your optical
media to your NAS via drag and drop for future access.

Note:

This function only provides data access and does not support the

audio and video playback of optical media.

Certain optical drives will require additional power in order to operate

properly. If you find that your optical drive is not spinning or reading
correctly, please use a USB Y-cable to add additional power.

App Central

The applications that come pre-installed with each

ASUSTOR NAS device are just the beginning. At your
convenience, you can browse through and download

any applications that peak your interest from App

Central. App Central allows you to explore the unlimited
potential of ASUSTOR NAS devices while creating a
personalized NAS device for yourself.

High capacity cloud storage for all your digital assets

The AS3204T provides a large capacity NAS for home users at an affordable price. Users can install four 8 TB hard
disks to immediately create a high capacity storage space of up to 32 TB. When taking photos or recording videos of
family vacations, gatherings and other cherished memories, users no longer need to be confined to the limited storage
on memory cards. With high capacity AS3204T, users can save all of their videos and photos in high quality resolution,
preserving them perfectly. Additionally, RAID 5 and 6 storage volume setting provide comprehensive protection for all
digital assets stored on the NAS, minimizing the risk of data loss due to hard disk failure or accidents.

Virtualization

iSCSI and NFS are primary datastore solutions for virtual environments and are also important in spreading the use of
virtualization as a whole. When compared with other storage mediums, ASUSTOR NAS can offer an optimal
price/performance ratio and value which is of particular importance to small and medium businesses.

ASUSTOR understand that stable and high performing shared storage is a must for virtual environments. iSCSI and
NFS support on the ASUSTOR NAS allows you to seamlessly integrate with any existing IT environments. All
ASUSTOR NAS devices are verified as VMware, Citrix and Hyper-V ready, providing you with a flexible and cost-efficient
virtual storage solution.

iSCSI LUN Snapshots

ASUSTOR’s snapshot technology provides almost instantaneous creation of snapshots. It saves a significant amount
of time and storage capacity when compared with traditional LUN backups.
Should files become damaged or corrupted, the simple and intuitive interface allows administrators to quickly restore
data, completing disaster recovery in the fastest time possible and providing uninterrupted service.

Video Surveillance

Worried about leaving your home unattended? Keep an eye on the most important things with Surveillance Center.
Surveillance Center's fully optimized interface allows you to simultaneously view live feeds from multiple IP cameras,
take snapshots and control the pan tilt and zoom functions of all cameras giving you complete peace of mind.

Recording & Playback

ASUSTOR's Surveillance Center comes with 4 license free
channels letting you to setup 4 different network IP cameras.
This significantly lowers startup costs for your surveillance
system. No matter if you prefer to use Microsoft Internet
Explorer, Mozilla Firefox or Google Chrome, Surveillance
Center's easy-to-use browser based interface and quick start

wizard will allow you to create a security surveillance system

in a snap.

Surveillance Center offers you a variety of recording options. No matter if you need scheduled continuous recording or
recording only when certain events occur, Surveillance Center is sure to satisfy your needs. Surveillance Center's
various recording modes are listed below:

Manual Recording: While viewing a live feed, you can click on the record button at any time to begin or stop

-

recording. In the event that you do not stop your recording, Surveillance Center will record until your designated
recording quota has been reached.
Continuous or Scheduled Recording: Whether you require 24/7 continuous recording or recording only during a

-

specific time, Surveillance Center can get the job done ensuring that you never miss any critical moments.
Motion Trigger Recording: In the event that any motion is detected in the surveilled environment, Surveillance Center

-

will immediately begin recording, allowing you to save significant space on your hard disks and ensuring that you
never miss any critical moments.
Alarm Trigger Recording: Triggering recording via a camera's alarm mechanism allows you to precisely record all

-

critical events. Not only does this save space on your hard disks but also lowers the amount of reading and writing
on your hard disks, prolonging their life.
Motion Trigger and Alarm Trigger Recording: This mode combines motion trigger and alarm trigger recording. If

-

either mode is triggered, recording will begin immediately. This is a comprehensive recording mode that ensures you
will never miss any critical moments.

Surveillance Center comes with 4 free IP camera channel licenses, which is higher than the industry standard. Users

*

can also purchase add-on camera licenses to flexibly add new camera channels.
Two different camera license packages are offered: single channel and 4 channels. Currently, AS32 series can be

*

expanded up to a maximum of 16 channels.
The maximum number of cameras is based on the test results for each channel using 720P (1280x720), 30 FPS

*

and H.264. Actual performance may vary due to camera settings and NAS load.

AiDownloadAiData AiFotoAiMaster AiCastAiMusicAiRemote AiSecureAiVideos

The NAS That's Always With You

ASUSTOR offers multiple mobile apps that give you convenient access to your NAS while on the go.

Bring you the smoothest mobile video viewing experience around: AiVideos

AiVideos brings you the smoothest mobile video viewing
experience around. Browse through the video collection on your
NAS without needing to wait for long downloads. Enjoy
high-definition 1080p streaming video with just one click.
You can even select multilingual subtitles and different audio
channels to enjoy films in different languages, bringing the movie
theatre to your mobile device..

You can even view videos offline! Download videos from your NAS
to your phone in a just a few taps without needing to connect an
external USB cable.
Sometimes you may encounter unstable Wi-Fi reception causing
long wait times for your downloads. At this time you can switch to
a more stable Wi-Fi signal and AiVideos will resume your
downloads from where they were interrupted. With this convenient
feature, you no longer need to worry about half-downloaded files!

Stream videos from your NAS to Chromecast with ease and share
the video collection on your NAS with your family and friends on a
big screen TV. Furthermore, AiVideos allows your mobile device to
become a remote control. Pause, fast-forward, adjust the volume
and even configure subtitles at the touch of a finger.

Stay Connected to Everything You Care About: AiSecure

The AiSecure dedicated mobile app allows you to easily keep an eye on everything that is happening at home. In addition
to monitoring live views of particular locations, AiSecure also features instant push notifications that can be sent to your
mobile device when specified events occur, allowing you to grasp all the latest developments in the palm of your hand.

AiSecure dramatically simplifies the connection process to your surveillance feeds. After enabling Cloud Connect on
your NAS, you will be able to use your dedicated Cloud ID to connect to Surveillance Center, allowing you to easily
monitor all the important things in your life from any corner of the world.

Cloud data access from

The most intuitive way to browse

anywhere: AiData

Get access to your data in the cloud and on your NAS from the
convenience of your mobile device with ASUSTOR's AiData mobile
app. With its intuitive interface and incorporation of well-known
cloud storage services, AiData allows you to manage all the files
on your NAS and across the cloud.

AiData features a host of convenient features to enrich your digital
lifestyle. Use your mobile device to rename, copy, move or delete
data on your NAS. Save items as favorites for quick offline
browsing while on the go or upload your photos directly from your
phone to your NAS. Have a file on your NAS that you want to
share? Instantly email download links to your friends and family.
AiData's features truly let you take advantage of your personal
cloud.

You can download data from your NAS to any folder on your
Android device or upload files from folders on your Android device
to your NAS. Now, data on your NAS and the rich variety of apps
on your mobile devices can be more closely integrated than ever
before.

When browsing through the substantial amount of data on your
NAS, you can choose to list files in ascending or descending order
according to filename, size or date modified, giving you better
organization when managing files.

Worried about losing your phone and accidentally giving someone
full access to all the data on your NAS? Passcode protection is
your first line of defense. When using passcode protection, you will
need to enter a correct passcode before being able to use an
ASUSTOR mobile app. This significantly enhances mobile privacy
while ensuring that you won’t have to worry about accidentally
giving someone access to your NAS.

One stop searching and
downloading: AiDownload

through your photos: AiFoto

AiFoto presents each photo using refined thumbnail
previews. Effortlessly browse through all your favorite
memories stored on your NAS with just the swipe of a
finger.

The automatic camera roll upload function ensures that
you will never have to worry about how to backup your

photos. Let AiFoto automatically take care of your
backup needs! You can also open an online album and

take photos that will be automatically uploaded to the

album, giving you easy organization of your photos.

People will always be curious. Protect your privacy with

password encrypted offline albums to create a private

space that belongs to you and you alone.

Terabytes of music in the palm
of your hand: AiMusic

AiMusic allows you to stream music from your NAS to your
mobile device, letting you enjoy your entire music collection
while on the go.

Play music from playlists that you create yourself for an

optimal listening experience. Like listening to random songs?
AiMusic's Random songs play mode is your best friend! You

need only select it once to create a random playlist from your

entire music collection, allowing you to enjoy a new listening
experience each and every time.

AiMusic also allows you to download songs from your NAS
to your mobile device for offline listening. No matter if it is is a
single song, an album or an entire playlist, all can be easily
downloaded to your mobile device for convenient listening.

Imagine the convenience of searching and downloading while
on the go and then having your downloads ready on your NAS
as soon as you get home. With ASUSTOR's AiDownload app,
all this is possible and more. AiDownload is a mobile app that
interfaces with ASUSTOR's Download Center to provide you
with mobile download management. No matter if it's
searching, downloading, configuring settings or monitoring,
you can do it all with AiDownload.

AiDownload includes a push notification feature that alerts
you when downloads have been completed. Now you are free
to concentrate on your more important tasks knowing that
you will be notified as soon as your downloads are finished.

Your NAS multimedia player
remote: AiRemote

What would a home entertainment center be without a
remote control?

AiRemote is a mobile app that turns your mobile device

into a remote control for Boxee on ASUSTOR NAS. Now
you can operate Boxee wirelessly and access all the media
content on your NAS from the comfort of your couch. All
that's left to do is to sit back, relax and enjoy the show.

Stay up to date with your NAS:
AiMaster

AiMaster’s exclusive initialization function makes it easy
set up your NAS. Now you can instantly configure and
initialize your NAS from the convenience of your mobile
device. No matter if it is adding new users, installing
exciting new NAS apps, upgrading your firmware or
checking the real-time status of your system, AiMaster can
helps you get it done with ease.

AiMaster features real-time system event notifications
allowing you to monitor your system status from the
convenience of your mobile device. When certain events
occur, notifications are sent to your mobile device in the
form of push notifications helping you stay abreast of all
the latest developments.

With AiMaster you are never far from your NAS. Manage all

your services, applications, and backup jobs at any time

and from any place. Execute one touch backup jobs and
monitor all users and system status. Even use the Find Me
function to locate your NAS among many. All this is
possible and more with AiMaster.

Hardware Specification

AS3204T

Processor

Memory

Internal Disk

External Device Interface

Dimensions (HxWxD)

Weight

Power

Operation*

Disk Hibernation*

Sleep Mode (S3)*

HD Display

Intel Celeron 1.6GHz Quad Core (burst up to 2.24 GHz)

2GB SO-DIMM DDR3L (Not Expandable)

4 x 3.5” SATA

3 x USB 3.0

165 x 164 x 218 mm

1.6 kg / 3.53 lb

External Power Adapter: 90 W

27 W

11.4 W

0.79 W

1 x HDMI 1.4b

* Test HDD: WD Red 3 TB HDD

Software & Features

Operating System

•ADM 2.5 Onwards

•Supports Online Firmware Updates

Supported OS

Windows XP, Vista, 7, 8, Server 2003,

•

Server 2008, Server 2012
Mac OS X 10.6 Onwards

•

UNIX, Linux, and BSD

•

Supported Languages

Deutsch, English, Français, Italiano,

•

Nederlands,Русский, 日本語, 한글, 简体中文,
繁體中文, Česká,Polski, Svenska, Dansk, Norsk,

Suomi, Português,Türkçe, Español, Magyar

Supported Browsers

•Internet Explorer 9 Onwards

•FireFox

•Chrome

•Safari

Network Protocols

CIFS / SMB, SMB 2.0, AFP, NFS, FTP (Unicode

•

Supported), TFTP, WebDAV, Rsync, SSH, SFTP,
iSCSI, HTTP, HTTPS, Proxy, SNMP, Syslog

File System

•Internal Disk: EXT4

•External Disk: FAT32, NTFS, EXT3, EXT4, HFS+

Storage Management

•Volume Type: Single disk, JBOD, RAID 0, RAID 1,
RAID 5, RAID 6, RAID 10

•Support for Online RAID Level Migration

•Support for Online RAID Capacity Expansion

iSCSI

•Maximum Targets: 256

•Maximum LUNs: 256

•Maximum Snapshot Versions of a Single LUN: 256

•Target Masking

•LUN Mapping

•ISO File Mounting

•Supports MCS

•Persistent (SCSI-3) Reservations

A
B
C
D

Power LED Indicator

A.

System Status LED Indicator

B.

Network LED Indicator

C.

Hard Disk LED Indicator

D.

Customized Sign In Page

2 Different Template Choices

•

Customizable Title, Imageand Background

•

Image Import Function

•

Disk Management

•Scheduled Bad Block Scans

•Scheduled S.M.A.R.T Scans

Network

•TCP/IP (IPv4 & IPv6)

•Jumbo Frame (MTU)

•VLAN

•Cloud Connect

•Wireless Network

•DDNS and EZ-Router

•Supports Wake-on-LAN (WOL)

Backup Solutions

Rsync (Remote Sync) Backup

•

Cloud Backup

•

FTP Backup

•

External Backup

•

Internal Backup

•

System Administration

•Log Type: System Log, Connection Log, File Access Log

•Real-time Online User Monitor

•Real-time System Monitor

•User Quota

•Virtual Drive (ISO Mounting, Maximum 16)

•UPS Support

Network Recycle Bin

Share folder-based

•

Maintains original directory structure and file

•

permission

On-click restore

•

Supports scheduled emptying

•

Filtering rules

•

-File size

-File extension

8

7

Power Button

1.
Reset Button

2.
USB 3.0 Port

3.
HDMI Port

4.
Network Port

5.
DC Input

6.
K-Lock

7.
System Fan

8.

Energy Control

Configurable Disk Hibernation and Sleep Mode Wait Time

•

Configurable Time Period for Sleep Mode Activation

•

Automatic Sleep

•

Access Control

•Maximum Number of Users: 4096

•Maximum Number of Groups: 512

•Maximum Number of Shared Folders: 512

•Maximum Number of Concurrent Connections: 512

•Supports Windows Active Directory

ACL

Provides both Windows ACL and Linux ACL permission

•

configuration methods
Can enable Windows ACL for specific shared folders

•

Comprehensive support for Windows’ 13 types of

•

advanced permission settings
Can view Windows ACL permission settings from within ADM

•

Supports local users and groups

•

Exclusive permission reset function allows users to

•

quickly restore default permissions

Security

AES 256-Bit Folder Encryption

•

Firewall: Prevent Unauthorized Access

•

Alert Notifications: E-mail, SMS

•

Encrypted Connections: HTTPS, FTP over

•

SSL/TLS, SSH, SFTP, Rsync over SSH
Built-in Hardware Encryption Engine

•

Network Defender

Auto black list

•

Trusted list

•

Black/White list

•

-Supports IP/IP range/geolocation

External Devices

•Supports USB External Storage Devices

•USB Wi-Fi Dongle Support

•Bluetooth Dongle/Speaker Support

•USB Printer Support

•USB DAC/IR Receiver/Keyboard/Mouse Support

•CD ROM Drive/DVD ROM Drive/Blu-Ray ROM

1
2

3

4

5
6

Featured Apps

Antivirus

Scheduled Scans

•

Automatic Virus Definition Updates

•

Quarantine Infected Files

•

ASUSTOR Portal(HDMI Local Output)

Supports Output for 4 Channels of Megapixel IP

•

Camera Video Feeds
Chrome Web Browser and YouTube Integration

•

Downloads from Chrome Automatically Saved

•

to the NAS
Power Control Settings: Power on, Sleep, Restart

•

and Wake via Remote
Customizable ASUSTOR Portal Desktop

•

Wallpaper
Add Shortcuts to Favorite Websites

•

Increased TV Compatibility via Overscan and

•

Resolution Settings
Max. Resolution: 2160p(4k)

•

ADM integrated for local system management

•

KODI

Kodi 14.2

•

Play All Media Content Stored on NAS

•

Video Output via HDMI

•

TV Shows, Movies, Apps and More

•

ASUSTOR Easy Selectable Shared Folder

•

AiRemote Mobile App for iOS & Android

•

Supports SBS 3D Playback (Side By Side)

•

Max resolution: 2160p (4K)

•

DataSync for Microsoft OneDrive

Each ADM account is able to individually log into a

•

OneDrive account
Supports file filter and bandwidth limitation

•

Supported backup methods:

•

-

Sync

-

Directly upload files to OneDrive from NAS

-

Directly download files from OneDrive to NAS

VirtualBox

Virtual Machines are Able to run the Following

•

Operating Systems: Windows, Linux, Solaris, Mac
OS X
Virtual Machine Import Format: OVF

•

Virtual Machine Export Format: OVF 0.9, OVF 1.0, OVF 2.0

•

Virtual Machine Snapshots

•

Virtual Machine HDMI Audio Output

•

Physical NAS Network Port can be Designated for

•

use by Specific Virtual Machine

Download Center

•Supports BT(Torrent & Magnet Link), HTTP and FTP

Downloads

•Torrent Search

•Choose Files Before a BT Task Starts

•Customizable Download Schedule

•Bandwidth Control

•RSS Subscription and Automatic Downloading

(Broadcatching)

•ASUSTOR Download Assistant for Windows & Mac

•AiDownload for iOS & Android with Push Notification

•Smart Download Function

Photo Gallery

Supported Image Formats: JPG/JPEG, GIF, PNG,

•

BMP, TIFF, RAW (ARW, CR2, CRW, DNS, DCR, ERF,
K25, KDC, MEF, MONO, MRW, NEF, NRW, ORF, PEF,
PPM, RAF, RW2, SR2, SRF)
Image Library Import

•

Album Access Control

•

Supports video playback

•

Unique Pinterest Style Photo Album with 5 Photos

•

on Cover

Supported Image Format: JPG, PNG, GIF, Raw

•

SoundsGood

Import Personal/Public Music Collection

•

Personal/Public Music Collection Permission Control

•

Playlist Editor

•

ID3 Tag Editor

•

Local Speaker Support: USB

•

Supported Audio Formats for Browser: MP3, WAV, Ogg

•

Supported Audio Formats for Transcoding Through

•

Browser: AIFF, Flac
Supported Audio Formats for Local Speaker: MP3,

•

WAV, Ogg, AIFF, Flac
ASUS DAC Support

•

Takeasy

•Download from YouTube, Vimeo, YouKu, Tudou

and More

•Selectable the Video Type and Quality

•Automatic Downloads with YouTube

Subscriptions

•Preview Downloads in Progress

•Online Playback

UPnP Media Server

Supports PS3 and other Digital Media Player

•

Capable Devices

Supports On-The-Fly Transcoding for Most RAW

•

Images and Audio(OGG, FLAC)
Supported Image Formats: BMP, GIF, ICO, JPG,

•

PNG, PSD, TIF, RAW Image
CRW, DCR, DNG, ERF, KDC, MEF, MOS, MRW, NEF,

2

(3FR, ARW, CR2,

NRW, ORF, PEF, RAF, RAW, RW2, SR2, X3F)
Supported Audio Formats: 3GP, AAC, AC3, AIFC,

•

AIFF, AMR, APE, AU, AWB, FLAC1, M4A, M4R,
MP2, MP3, OGG Vorbis1, PCM, WAV, WMA
Supported Video Formats: 3GP, 3G2, ASF, AVI,

•

DAT, FLV, ISO, M2T, M2V, M2TS, M4V, MKV, MPv4,
PEG1, MPEG2, MPEG4, MTS, MOV, QT, SWF, TP,
TRP, TS, VOB, WMV, RMVB, VDR, MPE

VPN Client

•

Supported VPN Protocols: PPTP, OpenVPN

•

Transmission Package Monitor

•

PPTP Authentication: PAP, CHAP, MS CHAP, MS
CHAP2

•

PPTP Encryption: No MPPE, MPPE (40, 128 bit),
Maximum MPPE (128 bit)

•

OpenVPN Port Control

•

OpenVPN Link Compression

VPN Server

Supports PPTP and OpenVPN Protocols

•

View Current Connections & Ability to

•

Disconnect Suspicious Connections

Comprehensive Connection Log

•

SNMP Server

Supports SNMP v1, v2c, v3 and trap

•

ASUSTOR NAS MIB provided

•

Syslog server

Supports standard syslog protocol

•

Graphical log monitoring by time and device

•

Supports TCP and UDP

•

Auto log archiving

•

User-defined email notification

•

File Explorer

Web-based File Management

•

ISO File Mounting

•

Share Links

•

Task Monitor

•

Browse Files on Local PC

•

Thumbnail Previews

•

Data Access via External Optical Drive

•

Supports video playback

•

FTP Explorer

•Directory Structure View with Drag & Drop Transfers

•Task Monitor

•Stopping of Transmission Task & Resumption of

Connection

•Encrypted Connections: Explicit over TLS, Implicit

over TLS

•FTP Site Manager

•Bandwidth Control

•Maximum Simultaneous Transfer Control

DropBox

•

Each ADM Account is Able to Individually Log in to One
Dropbox Account
Supported Backup Methods:

•

-Sync

Google Drive

•

Each ADM Account is Able to Individually Log in to One
Google Account
Supported Backup Methods:

•

- Sync

- Directly Upload Files to Google Drive from NAS

- Directly Download Files from Google Drive to NAS

HiDrive

•Each ADM Account is Able to Individually Log in
to One HiDrive Account

•Supported Backup Methods:

- Directly Upload Files to HiDrive from NAS

- Directly Download Files from HiDrive to NAS

•Supported Protocols:

- Rsync

- FTP

- FTPS

- SFTP

- Rsync + SSH

iTunes Server

•For iTunes on Mac & Windows

•Supports AirPlay

•Supports iOS Remote Pairing

•Supported Audio Formats: AIF

Loseless), M4P, M4R, MP3, WAV

•Supported Video Formats: M4V, MOV, MP4

1

, M4A (AAC & Apple

1

•Supported Playlist Formats: M3U, WPL

Mail Server

Each ADM Account can Become an Independent

•

Email Account

Email Activity Monitor (Over 1 Week, 1/3/6 Months)

•

Provides SMTP, IMAP and POP3 Mail Protocols

•

Supports SMTP Relay and Verification

•

SMTP-SSL Secure Connections

•

Spam Filter and Black List Settings

•

Email Alias Creation and Mapping

•

Monitoring of Mail Queue

•

Mail Service Activity Log

•

Exclusive Email Backup Mechanism

•

Auto-Forwarding and Auto-Response Protocols

•

LooksGood

Currently only available for Windows Firefox and

•

Mac Safari. Installation of the VLC media player
browser plug-in is required.
Supports the use of DVB-T/DTMB digital TV dongles

•

to stream and record scheduled digital TV programs.
Only certain countries and territories support DVB-T.

•

Please click on the following link to learn more about
the regions supporting DVB-T.

Supports multiple TV tuners. A single TV tuner can

•

only stream or record from one channel at a time.
Playback of High-Definition Video Files

•

Supports External Subtitles and Multiple Audio

•

Channels

Supports the Browsing of Photos

•

Recently Added, Recently Watched and Favorite

•

Browsing Categories
Supports Browsing of Electronic Program Guides

•

Edit and Manage Recording Tasks

•

Configure Recording Tasks: Time, Length and

•

Recording Frequency
No Need for an EPG, Just Select a Channel and

•

Time to Begin Recording
Recording Task Log

•

Supported browsers

Supported video formats

Supported video codec

Supported external

subtitle formats

Supported photo formats

Supported TV stick TV

standards

Series supporting
hardware transcoding

Windows Firefox / Mac Safari

avi, flv, mov, mp4, mkv, mka, ts,

mpg, ra, ram, rm, rv, rmvb

aac_latm, aac, ac3_fixed, ac3, dca,
eac3, h.264, mlp, mp1, mp2, mp3,
mpeg2video, mpeg4, treuhd, vc1,

wmav2, wmv3

srt, ass, ssa

jpg, jpeg, bmp, png, gif, tif

DVB-T, DTMB

AS3/31/32/50/51/61/62/70

Surveillance Center

Up to 24channels in 720p on single live view display

•

(4 Free Channels)
On-screen camera controls including camera PTZ,

•

manual recordings, take snapshots,configure
camera settings and open Maps
Up to 4 channels of synchronous and

•

non-synchronous playback with audio

Intelligent video analytics including motion detection

•

and foreign object detection
Supported Browsers: Windows Internet Explorer,

•

Firefox, Mac Safari, Mac Firefox
Event notification supports SMS, E-mail, and mobile

•

push notification

Automated event action rules

•

Role-based access control

•

RTSP streaming server (video and audio)

•

AiSecure mobile app for iOS and Android with Push

•

notification
ONVIF™ 2.4, Profile S certified

•

Two different camera license packages are offered:

•

single channel and 4 channels.
Maximum IP Cam (4 Free Licenses; Additional
Licenses to be Purchased)

Series

AS10

AS2

AS2TE/AS3

AS31/32

AS6

AS50/51

AS61/62

AS7

Maximum

IP cam

8

8

8

16

16

25

25

49

Local

display

N/A

N/A

Yes

Yes

Yes

Yes

Yes

Yes

Note:

1.Metadata (e.g. title) may not be able to displayed in iTunes.

2.You must first enable real time transcoding for these files in order to play them.

ASUSTOR Inc.

3F, No.136, Daye Rd., Beitou Dist., Taipei City 112, Taiwan
Tel: [phone]
www.asustor.com

Designs and specifications are subject to change without notice.
© 2014 ASUSTOR Inc. ASUSTOR and all other ASUSTOR product names are trademarks or registered trademarks of ASUSTOR Inc. All
other product and company names mentioned herein are the trademarks of their respective owners.

Dealer Seal
