Asustor AS-202TE User Manual

A blend of data protection and
entertainment designed for

your home oce

The AS-202TE is an exceptionally cost-eective network
storage solution that features an elegant user interface,
a rich variety of multimedia features and rock-solid stability.

AS - 202TE

ASUSTOR AS-202TE

Seamless Cross-Platform File Sharing

ASUSTOR NAS devices provide seamless cross-platform le
sharing, allowing you to easily connect to your NAS device
no matter if you are using Windows, Mac OS, or Unix-like
operating systems. The transfer protocols that you may
use to connect to an ASUSTOR NAS device are as follows:

Windows: CIFS/SMB, FTP and WebDAV
Mac OS X: AFP, SMB, NFS, FTP and WebDAV
Linux: NFS, SMB, FTP and WebDAV

Additionally, ASUSTOR NAS devices feature our Network
Recycle Bin. Any les you delete will be moved to the Recycle
Bin, allowing you to restore any accidentally deleted les.
Transfer protocols supported by the Recycle Bin include:
CIFS/SMB, AFP, FTP and File Explorer.

Ultimate data protection

ASUSTOR NAS makes use of RAID storage technology to provide protection for your data. RAID mainly revolves around the
core concept of combining your disks to protect the data inside. ASUSTOR oers a number of dierent RAID level congurations
that you can choose from when creating storage volumes. Each RAID level oers a diering degree of data protection, system
performance and storage space. ASUSTOR’s supported RAID levels are summarized in the chart below:

Minimum number

of disks

Faulty Disks

Tolerated

Increased System

performance

Maximum use of

Storage space

Single

1

X

X

V

JBOD

2

X

X

V

RAID 0

2

X

V

V

RAID 1

2

1

X

X

Online Capacity Expansion

Insucient storage space forcing you to consider upgrading your NAS to one with more disk bays?
ASUSTOR NAS supports online capacity expansion¹ which means that you can easily swap out all your old disks for higher
capacity ones without turning o your NAS. Now you can increase the storage capacity of your NAS without worrying about
getting an entire new system.

During the capacity expansion process, while your data is being
transferred over to the new disks, you will still be able to access
everything on the NAS. Online capacity expansion does not
require any advanced IT skills to execute and helps you to
eliminate cumbersome backup and migration procedures.
When it's time to upgrade your NAS's capacity, ASUSTOR
simply gets the job done for you without missing a beat.

¹ You must use RAID 1, 5, 6, or 10

Seamless system migration

Outgrowing your system? Time for an upgrade? With ASUSTOR
NAS, switching to a higher capacity NAS model is a piece of
cake. When it's time to move your storage volumes to a new
system, simply take out your existing hard drives and then
insert them into the new system. That's it. Your new system
will be up and running instantly.

Account Management

ADM's account management function allows you to easily
create, edit or remove user accounts on the ASUSTOR NAS.
You also have the option of creating dierent user groups.
Conguring access rights for a group will allow the rights to
be applied to all the users in the group making for ecient
management. ASUSTOR's account management features
not only allow you to assign dierent folder access rights
to each user on the NAS but also gives you optimal management
eciency while ensuring the protection of your data.

A rich and exible backup solution

ASUSTOR's Rsync Backup function supports two-way data
transfers, incremental backup, encrypted backup and also
the scheduling of your NAS to perform regular backup jobs.
It eectively simplies data backup while also substantially
reducing the burden on IT sta. ASUSTOR's Rsync backup
function may be used to complete tasks such as:

The ultimate tool for remote backup

Rsync is an application originally developed for UNIX that
is usually used for backup and sync between two computers.
By providing block level replication, Rsync is able to oer
incremental backup. Incremental backup allows for successive
backup jobs (after your rst backup job) to only copy data
that has changed since your last backup job. Rsync is suitable
for use with les and data that are always changing. It lets
you cut down on backup time while signicantly reducing
bandwidth usage.

- The transfer or backup of data from your NAS to an Rsync
compatible server

- Initiating downloads of the data from an Rsync compatible
server to your NAS

One touch and you're done

Simply plug your USB storage device or camera into the
ASUSTOR NAS and push the backup button. Your data will
then be copied to a location on the NAS that you specify.
Your photos and data are precious - ASUSTOR NAS ensures
that they are protected with just the push of a button.

One Touch Backup also allows you to back up the data on
your NAS, hassle-free. ASUSTOR's 2-way transfer support
allows for your NAS data to be copied to your favorite USB
storage device, providing an eective disaster recovery
solution.

Your best bet for backup

FTP has always been a widely used and popular transfer
protocol. ASUSTOR NAS's FTP Backup function may be
used to complete tasks such as:

- The transfer or backup of the data from your NAS to an
FTP server.

- Initiating downloads of data from an FTP server to your
NAS

FTP Backup supports two-way data transfers, incremental
backups and also the scheduling of your NAS to perform
regular backup jobs. It eectively simplies data backup
while also substantially reducing the burden on IT sta.

Connect to the cloud

Now home and business users alike can back up the data
from their ASUSTOR NAS to popular cloud storage service
Amazon S3, further ensuring the protection of their data.
This means that in the event that the data on your NAS is
damaged you will be able to immediately restore it from
Amazon S3. ASUSTOR NAS is able to both upload to and
download from Amazon S3, letting you get backup and
restoration jobs done in just a few easy steps.

Regular backups of your vital data

The External backup function supports two-way data
transfers, incremental backups and also the scheduling of
your NAS to perform regular backup jobs. It may be used
to complete tasks such as:

- The transfer or backup of the data from your NAS to an
external device.

- Initializing the copying of data from an external device to
your NAS

Windows Backup

ASUSTOR's Backup Plan software for Windows provides
you with worry-free backup. Simply schedule a regular
backup job of your PC to your NAS, then let Backup Plan
take care of the rest. Backup Plan will work in the background
to ensure that your PC is always backed up.

Any data that is lost between scheduled backups is unprotected.
Backup Plan lets you congure real time le synchronization
for those important and ever-changing le folders. Any
changes that you make to your protected les and folder
will be updated in real time. Now you can rest assured
knowing that your critical les are always protected and
up to date.

Time Machine Backup

Mac lovers rejoice! You can use your Mac's built-in backup,
Time Machine, to easily back up your Mac to an ASUSTOR
NAS. All ASUSTOR NAS devices have been optimized for use
with Time Machine, providing Mac lovers with a familiar
and easy to use backup solution.

Dierent Mac users can now safely backup their computers
to the same NAS device. Unlike other NAS devices, ASUSTOR
NAS does not just use one group account to carry out
backup jobs for all Mac users, storing all their jobs under
the same directory. With ASUSTOR NAS each Mac user is
able to use an independent account and backup location
thereby guaranteeing privacy for all.

Mission Mode

Never again worry about your critical backup jobs stopping or failing to complete because your ASUSTOR NAS won't stop until
it’s “mission complete”. Sometimes backup jobs may be stopped because of various connection problems with a busy server on
the other end. For Rsync, FTP, external and cloud backups, ASUSTOR’s Mission Mode allows you to congure the number of
connection attempts and time interval for connection attempts, ensuring for the successful completion of your backup mission.
This also gives IT administrators a signicant amount of exibility when conguring backup jobs.

Power saving options

All ASUSTOR NAS products are designed around ecologically
friendly concepts and feature a host of power saving options
that can help users save on their power bills. This allows users
to enjoy the conveniences of technology while helping to
protect the environment at the same time.

Features such as power management schedules allow you
to congure startup and shutdown times for the NAS while
disk hibernation allows you to assign times for your hard
disks to automatically enter hibernation mode when there
is no data access to them. This helps you to save power while
also prolonging the lifespan of your disks.

ASUSTOR's exclusive power saving features also include power
management options for LED indicators, LCD display options
which allow you to either display a custom message or the
local temperature and smart fans which automatically adjust
their speed according to the temperature. All ASUSTOR NAS
products are fully compliant with the latest EuP standards
(EuP 2.0). As a responsible citizen of the Earth, it is our mission
to continue to develop superior energy saving and energy
ecient products.

Quickly nd the items you need

Can't nd that song on your NAS that you want to share?
Use Searchlight to instantly nd that song and send a Share
Link to your friend! Developed by ASUSTOR, Searchlight is a
rapid search technology that is built into ADM and provides
quick and precise searches allowing you to easily nd the
les that you need. Searchlight also features instant le
previewing and fuzzy searches, substantially increasing
your eciency and productivity.

System Sleep Mode and Instant Wake

ASUSTOR NAS is the rst NAS in the world to feature System
Sleep Mode (S3) and instant wake. Don't throw your money
away to an always-on system. When your NAS is not in use
you can lower its power consumption by putting it into Sleep
Mode.

No longer will you have to endure those long waits while
your NAS slowly starts up. With ASUSTOR NAS you get to
enjoy almost instantaneous wake times. Wake your NAS up
when you need it and put it to sleep when you don't. No
matter what time of day or night get immediate access to
your NAS when you need it the most.

EZ-Router

Still trying to nd a way to get remote access to your NAS?
Struggling with router conguration and don't know where
to start? ADM's built-in EZ-Router function can help you
easily complete router conguration in a snap.

EZ-Router allows your NAS to quickly integrate with the
cloud by helping you congure designated ports.
Additionally, it also gives you the exibility to specify the
services you want enabled helping you to create a customized
cloud server for yourself.

Cloud Connect

DDNS

Worried about the safety of storing your data in public cloud
storage? ASUSTOR's built-in Cloud Connect function can
help you to quickly create your own private cloud [1]. Sign
up for a unique and personal Cloud ID and you will be able
to connect to your ASUSTOR NAS from almost any corner
of the world.

Once you enable Cloud Connect, you will be able to have a
personalized hostname (i.e., allen.myasustor.com) and be
able to use MyASUSTOR to connect to your NAS. No matter
if you are in the oce or on vacation, you will now be able
to enjoy the convenience of cloud access from anywhere
and at any time.

Can't remember your ever-changing IP address?Sign up
for DDNS service to get an easy to remember hostname
for your NAS. Further pair it with the EZ-Router function
and you can get remote access to your NAS from anywhere
and at any time.

ASUSTOR NAS currently supports the following DDNS
providers:

- oray.com - dnsexit.com

- freedns.afraid.org - changeip.com

- no-ip.com - DynamicDo!.jp

- twoDNS.de - Dyndns

- 3322.net

App Central

The applications that come pre-installed with each ASUSTOR
NAS device are just the beginning. At your convenience,
you can browse through and download any applications
that peak your interest from App Central. App Central allows
you to explore the unlimited potential of ASUSTOR NAS
devices while creating a personalized NAS device for yourself.

Downloading has never been this convenient – Download Center

Spending a lot of time ddling with torrents, trackers and BitTorrent clients? Download Center
provides a one stop solution that simplies the entire download process. Powerful features allow
you to easily search for and download the les that you need in the blink of an eye.

Download Center also oers many intelligent features such as RSS downloading (broadcatching)
and scheduled downloads. With RSS downloading, you can have Download Center automatically
search RSS feeds for torrents of your favorite content and then have that content automatically
downloaded to your AUSTOR NAS as soon as it is released. This feature is great for regularly
released content like TV shows.

With the Smart Download Folder function you can specify a folder on the NAS as a Smart
Download folder. For any torrents that are added to the folder, a download task will be added
and Download Center will automatically begin downloading the torrent.

Enjoy your music collection from anywhere - SoundsGood

Sounds good is a Web music player that can play all the music stored on your NAS over the Internet.
Now you can access your music from anywhere and even share your music collection with family
and friends.

With SoundsGood, each user can have their own personalized music collection and playlists.
Users are free to congure any folder on the NAS as a music source along with options for setting
the music source as public or private.

Can't decide on what software to use to edit your ID3 tags? SoundsGood's built-in ID3 tag editor
allows you to conveniently edit the ID3 tags for your entire music collection without having to
use any additional software.

All your music on all your computers - iTunes Server

Still storing your music and movie collections on dierent computers? Running out of disk space?

iTunes Server is what you need. Now you can store all your music and movies on your ASUSTOR
NAS and have them streamed to any Mac or Windows computer within the local network. AirPlay,
iOS Remote pairing and playlists are also supported.

iTunes Server also works with the amplier on your home sound system. Use the NAS's HDMI port
to connect it to your amplier and in a snap you'll have a digital stereo system ready with all your
favorite songs. Furthermore, you can utilize the iOS Remote app to turn any iOS device into a remote
control for your music. Get ready to enjoy stereo surround sound from the comfort of your own
home with ASUSTOR NAS and iTunes Server.

Eortless multimedia streaming - UPnP Media Server

Still using a power consuming computer as your home's multimedia server? Each and every
ASUSTOR NAS can be outtted with the UPnP Multi Media Server App, which allows it to become
your home's multimedia streaming server. As long as you have devices that support UPnP (for
example, SONY BRAVIA TV or PlayStation3®), you will be able to browse and stream all multimedia
stored on your ASUSTOR NAS. Don't forget that you can also use UPnP or DMP compatible
applications on your mobile devices to stream multimedia from your NAS.

The ultimate combination - Local Display

Other than becoming your home's multimedia server, ASUSTOR NAS can also become a media
player through the use of the well-known multimedia player Apps Boxee and XBMC¹. Boxee and
XBMC allow you to play all the multimedia content stored on your NAS on your LCD/LED TV. Simply
connect your NAS to your TV using an HDMI cable and you are ready to go.

Currently, Boxee is only available on the 6 series while XBMC is only available on the 3 series.

The NAS That's Always With You

ASUSTOR oers multiple mobile apps that give you convenient access to your NAS while on the go.

AiDownload

AiRemote AiData

AiMaster

Cloud data access from anywhere: AiData

Get access to your data in the cloud and on your NAS from the convenience of your mobile device with ASUSTOR's AiData mobile
app. With its intuitive interface and incorporation of well-known cloud storage services, AiData allows you to manage all the les
on your NAS and across the cloud.

AiData features a host of convenient features to enrich your digital lifestyle. Use your mobile device to rename, copy, move or delete
data on your NAS. Save items as favorites for quick oine browsing while on the go or upload your photos directly from your phone
to your NAS. Have a le on your NAS that you want to share? Instantly email download links to your friends and family. AiData's
features truly let you take advantage of your personal cloud.

One stop searching and downloading: AiDownload

Imagine the convenience of searching and downloading while on the go and then having your downloads ready on your NAS
as soon as you get home. With ASUSTOR's AiDownload app, all this is possible and more. AiDownload is a mobile app that interfaces
with ASUSTOR's Download Center to provide you with mobile download management. No matter if it's searching, downloading,
conguring settings or monitoring, you can do it all with AiDownload.

AiDownload includes a push notication feature that alerts you when downloads have been completed. Now you are free to
concentrate on your more important tasks knowing that you will be notied as soon as your downloads are nished.

Stay up to date with your NAS: AiMaster

AiMaster is ASUSTOR's NAS management app for mobile devices that allows you to easily control all your NAS devices no matter if
you are a home user or IT administrator.

AiMaster features real-time system event notications allowing you to monitor your system status from the convenience of your
mobile device. When certain events occur, notications are sent to your mobile device in the form of push notications helping
you stay abreast of all the latest developments.

With AiMaster you are never far from your NAS. Manage all your services, applications, and backup jobs at any time and from any
place. Execute one touch backup jobs and monitor all users and system status. Even use the Find Me function to locate your NAS
among many. All this is possible and more with AiMaster.

Your NAS multimedia player remote: AiRemote

What would a home entertainment center be without a remote control?
AiRemote is a mobile app that turns your mobile device into a remote control for Boxee on ASUSTOR NAS. Now you can operate
Boxee wirelessly and access all the media content on your NAS from the comfort of your couch. All that's left to do is to sit back,
relax and enjoy the show.

Hardware Specication

AS - 202TE

Processor

Memory

Internal Disk

External Device Interface

Dimensions (HxWxD)

Weight

Power

Operation*

Disk Hibernation*

Sleep Mode (S3)*

HD Display

*Test HDD: WD Red 3 TB HDD

Intel 1.2GHz Dual-Core Processor

External Power Adaptor 100~240V AC

Software & Features

1 GB DDR3

2 x (2.5”/3.5” SATA or SSD)

2 x USB 2.0, 2 x USB 3.0

163.5 x 108 x 230mm

1.87 kg/ 4.12 lb

19.7 W

13 W

0.8W

1 x HDMI 1.4a

A
B
C

D
E

A.

Power LED Indicator

B.

System Status LED Indicator

C.

Hard Disk LED Indicator

D.

Network LED Indicator

E.

USB LED Indicator

A.

Reset Button

B.

USB 3.0 Port

C.

System Fan

D.

HDMI Port

E.

RJ45 & USB 2.0 Port

F.

K-lock

A
B

C
D

E

F

Operating System

•

ADM 2.0 Onwards

•

Built-in App Central for Various Apps

Supported OS

•

Windows XP, Vista, 7, 8, Server 2003, Server 2008, Server 2012

•

Mac OS X 10.6 Onwards

•

UNIX, Linux, and BSD

Supported Languages

•

Deutsch, English, Français, Italiano, Nederlands, Русский, 日本
語, 한글, 简体中文, 繁體中文 Česká, Polski, Svenska, Dansk,

Norsk, Suomi

Supported Browsers

•

Internet Explorer 9 Onwards

•

FireFox

•

Chrome

•

Safari

Network Protocols

•

CIFS/SMB, AFP, NFS, FTP, WebDAV, Rsync, SSH, SFTP, iSCSI,
HTTP, HTTPS

File System

•

Internal Disk: EXT4

•

External Disk: FAT32, NTFS, EXT3, EXT4, HFS+

Storage Management

•

Support Multiple Volumes with Spare Disks

•

Volume Type: Single disk, JBOD, RAID 0, RAID 1

•

Support for Online RAID Level Migration

•

Support for Online RAID Capacity Expansion

Disk Management

•

Scheduled Bad Block Scans

•

Scheduled S.M.A.R.T Scans

Network

•

TCP/IP (IPv4 & IPv6)

•

Jumbo Frame (MTU)

•

VLAN

•

Cloud Connect

•

Wireless Network

•

DDNS and EZ-Router

Backup Solutions

•

Rsync (Remote Sync) Backup

•

Cloud Backup

•

FTP Backup

•

External Backup

•

One Touch Backup

System Administration

•

Log Type: System Log, Connection Log, File Access Log

•

Real-time Online User Monitor

•

Real-time System Monitor

•

Network Recycle Bin

•

User Quota

•

Virtual Drive (ISO Mounting, Maximum 16)

•

UPS Support

Access Control

•

Maximum Number of Users: 4096

•

Maximum Number of Groups: 512

•

Maximum Number of Shared Folders: 512

•

Maximum Number of Concurrent Connections: 512

•

Supports Windows Active Directory

iSCSI

•

Maximum Targets: 256

•

Maximum LUNs: 256

•

Target Masking

•

LUN Mapping

•

ISO File Mounting

•

Supports MCS

•

Persistent (SCSI-3) Reservations

Security

•

AES 256-Bit Folder Encryption

•

Firewall: Prevent Unauthorized Access

•

Network Defender: Prevent Network Attacks

•

Alert Notications: E-mail, SMS

•

Encrypted Connections: HTTPS, FTP over SSL/TLS, SSH, SFTP,
Rsync over SSH

Featured Apps

File Explorer

•Web-based File Management

•ISO File Mounting

•Share Links

Surveillance Center

•Live Monitoring (4 Free Channels)

•Multiple Channel Playback with Audio

•Supported Browsers: Internet Explorer, Chrome, FireFox

(Windows only)

•Event Notication

UPnP Media Server

•Supports PS3 and other Digital Media Player Capable Devices

•Supports On-The-Fly Transcoding for Most RAW Images and Audio

(OGG, FLAC)

•Supported Image Formats: BMP, GIF, ICO, JPG, PNG, PSD, TIF, RAW
Image (3FR, ARW, CR2, CRW, DCR, DNG, ERF, KDC, MEF, MOS, MRW,
NEF, NRW, ORF, PEF, RAF, RAW, RW2, SR2, X3F)

•Supported Audio Formats: 3GP, AAC, AC3, AIFC, AIFF, AMR, APE, AU,
AWB, FLAC1, M4A, M4R, MP2, MP3, OGG Vorbis1, PCM, WAV, WMA

•Supported Video Formats: 3GP, 3G2, ASF, AVI, DAT, FLV, ISO, M2T,
M2V, M2TS, M4V, MKV, MPv4, MPEG1, MPEG2, MPEG4, MTS, MOV,
QT, SWF, TP, TRP, TS, VOB, WMV, RMVB, VDR, MPE

FTP Explorer

•Directory Structure View with Drag & Drop Transfers

•Task Monitor

•Stopping of Transmission Task & Resumption of Connection

•Encrypted Connections: Explicit over TLS, Implicit over TLS

•FTP Site Manager

•Bandwidth Control

•Maximum Simultaneous Transfer Control

VPN Client

•

Supported VPN Protocols: PPTP, OpenVPN

•

Transmission Package Monitor

•

PPTP Authentication: PAP, CHAP, MS CHAP, MS CHAP2

•

PPTP Encryption: No MPPE, MPPE (40, 128 bit), Maximum

•

MPPE (128 bit)

•

OpenVPN Port Control

•

OpenVPN Link Compression

iTunes Server

•For iTunes on Mac & Windows

•Supports AirPlay

•Supports iOS Remote Pairing

•Supported Audio Formats: AIF, M4A (AAC & Apple Loseless),

M4P, M4R, MP3, WAV

•Supported Video Formats: M4V, MOV, MP4

•Supported Playlist Formats: M3U, WPL

Download Center

•Supports BT(Torrent & Magnet Link), HTTP and FTP Downloads

•Torrent Search

•Choose Files Before a BT Task Starts

•Customizable Download Schedule

•Bandwidth Control

•RSS Subscription and Automatic Downloading (Broadcatching)

•ASUSTOR Download Assistant for Windows & Mac

•AiDownload for iOS & Android

Boxee / XBMC

*

•Play All Media Content Stored on NAS

•Video Output via HDMI

•TV Shows, Movies, Apps and More

•ASUSTOR Customized Features

•AiRemote Mobile App

SoundsGood

•

Import Personal/Public Music Collection

•

Personal/Public Music Collection Permission Control

•

Playlist Editor

•

ID3 Tag Editor

•

Local Speaker Support: HDMI, USB, Audio Jack

•

Supported Audio Formats for Browser: MP3, WAV, Ogg

•

Supported Audio Formats for Transcoding Through Browser:
AAC, AIFF, Flac, Apple lossless, WMA

•

Supported Audio Formats for Local Speaker: MP3, WAV, Ogg,
AAC, AIFF, Flac, Apple lossless, WMA

•

ASUS DAC Support

More...

•

For information on additional Apps, please visit:

http://www.asustor.com/apps

Note:

Currently, Boxee is only available on the 6 series while XBMC is only available on the 2TE & 3 series..

ASUSTOR Inc.

3F, No.136, Daye Rd., Beitou Dist., Taipei City 112, Taiwan
Tel: [phone]
www.asustor.com

Designs and specifications are subject to change without notice.
© 2013 ASUSTOR Inc. ASUSTOR and all other ASUSTOR product names are trademarks or registered trademarks of ASUSTOR Inc. All
other product and company names mentioned herein are the trademarks of their respective owners.

Dealer Seal

1553-T0ENG021-130
