1U Rackmount Server
RS100-E7/PI2
User Guide
ii
Copyright © 2011 ASUSTeK COMPUTER INC. All Rights Reserved.
No part of this manual, including the products and software described in it, may be reproduced, transmitted,
transcribed, stored in a retrieval system, or translated into any language in any form or by any means,
except documentation kept by the purchaser for backup purposes, without the express written permission
of ASUSTeK COMPUTER INC. (“ASUS”).
ASUS provides this manual “as is” without warranty of any kind, either express or implied, including but not
limited to the implied warranties or conditions of merchantability or tness for a particular purpose. In no
event shall ASUS, its directors, ofcers, employees, or agents be liable for any indirect, special, incidental,
or consequential damages (including damages for loss of prots, loss of business, loss of use or data,
interruption of business and the like), even if ASUS has been advised of the possibility of such damages
arising from any defect or error in this manual or product.
Specications and information contained in this manual ae furnished for informational use only, and are
subject to change at any time without notice, and should not be construed as a commitment by ASUS.
ASUS assumes no responsibility or liability for any errors or inaccuracies that may appear in this manual,
including the products and software described in it.
Product warranty or service will not be extended if: (1) the product is repaired, modied or altered, unless
such repair, modication of alteration is authorized in writing by ASUS; or (2) the serial number of the
product is defaced or missing.
Products and corporate names appearing in this manual may or may not be registered trademarks or
copyrights of their respective companies, and are used only for identication or explanation and to the
owners’ benet, without intent to infringe.
E6489
First Edition
March 2011
iii
Contents
Contents ...................................................................................................... iii
Notices ........................................................................................................ vii
Safety information .................................................................................... viii
About this guide ......................................................................................... ix
Chapter 1: Product introduction
1.1 System package contents ........................................................... 1-2
1.2 Serial number label ...................................................................... 1-2
1.3 Systemspecications ................................................................. 1-3
1.4 Front panel features ..................................................................... 1-5
1.5 Rear panel features ...................................................................... 1-5
1.6 Internal features ........................................................................... 1-6
1.7 LED information ........................................................................... 1-7
1.7.1 Front panel LEDs ............................................................ 1-7
1.7.2 LAN (RJ-45) LEDs .......................................................... 1-7
Chapter 2: Hardware setup
2.1 Chassis cover ............................................................................... 2-2
2.1.1 Removing the chassis cover ........................................... 2-2
2.1.2 Reinstalling the chassis cover ......................................... 2-3
2.2 Central Processing Unit (CPU) ................................................... 2-5
2.2.1 Installing the CPU ........................................................... 2-5
2.2.2 Installing the CPU heatsink and airduct .......................... 2-8
2.3 System memory ......................................................................... 2-10
2.3.1 Overview ....................................................................... 2-10
2.3.2 Memory Congurations ................................................. 2-10
2.3.3 Installing a DIMM ...........................................................2-11
2.3.4 Removing a DIMM .........................................................2-11
2.4 Hard disk drives ......................................................................... 2-12
2.4.1 Installing a hard disk drive to the HDD tray 1 ................ 2-12
2.4.2 Installing a hard disk drive to the HDD tray 2 ................ 2-13
2.5 Expansion card .......................................................................... 2-15
2.5.1 Installing an expansion card ......................................... 2-15
2.5.2 Conguring an expansion card ..................................... 2-17
2.6 Cable connections ..................................................................... 2-18
2.7 Removable/optional components ............................................. 2-19
2.7.1 Chassis fans ................................................................. 2-19
iv
Contents
2.7.2 Optical disk drive (ODD) ............................................... 2-20
2.7.3 Installing ASMB5 series management board (optional) 2-22
Chapter 3: Rackmount installation
3.1 Rackmount rail kit items .............................................................. 3-2
3.2 Attaching the rails to the rack ..................................................... 3-2
Chapter 4: Motherboard Info
4.1 Motherboard layout ...................................................................... 4-2
4.2 Jumpers ........................................................................................ 4-4
4.3 Internal connectors ...................................................................... 4-9
Chapter 5: BIOS setup
5.1 Managing and updating your BIOS ............................................ 5-2
5.1.1 ASUS CrashFree BIOS 3 utility ...................................... 5-2
5.1.2 ASUS EZ Flash Utility ..................................................... 5-3
5.1.3 BUPDATER utility............................................................ 5-4
5.2 BIOS setup program .................................................................... 5-6
5.2.1 BIOS menu screen .......................................................... 5-7
5.2.2 Menu bar ......................................................................... 5-7
5.2.3 Menu items ..................................................................... 5-8
5.2.4 Submenu items ............................................................... 5-8
5.2.5 Navigation keys ............................................................... 5-8
5.2.6 General help ................................................................... 5-8
5.2.7 Conguration elds ......................................................... 5-8
5.2.8 Pop-up window ............................................................... 5-8
5.2.9 Scroll bar ......................................................................... 5-8
5.3 Main menu .................................................................................... 5-9
5.3.1 System Date [Day xx/xx/xxxx] ......................................... 5-9
5.3.2 System Time [xx:xx:xx] ................................................... 5-9
5.3.3 Security ........................................................................... 5-9
5.4 Event Logs menu ....................................................................... 5-11
5.5 Advanced menu ......................................................................... 5-13
5.5.1 ACPI Settings ................................................................ 5-13
5.5.2 Trusted Computing ........................................................ 5-14
5.5.3 WHEA Conguration ..................................................... 5-14
5.5.4 CPU Conguration ........................................................ 5-15
v
Contents
5.5.5 North Bridge .................................................................. 5-17
5.5.6 South Bridge ................................................................. 5-17
5.5.7 SATA Conguration ....................................................... 5-18
5.5.8 Intel TXT(LT) Conguration ........................................... 5-19
5.5.9 USB Conguration ........................................................ 5-19
5.5.10 Onboard Devices Conguration .................................... 5-20
5.5.11 APM .............................................................................. 5-21
5.5.12 Serial Port Console Redirection .................................... 5-22
5.6 Monitor menu ............................................................................. 5-24
5.7 Boot menu .................................................................................. 5-25
5.8 Tool menu ................................................................................... 5-27
5.9 Exit menu .................................................................................... 5-27
Chapter6: RAIDconguration
6.1 Setting up RAID ............................................................................ 6-2
6.1.1 RAID denitions .............................................................. 6-2
6.1.2 Installing hard disk drives ................................................ 6-3
6.1.3 Setting the RAID item in BIOS ........................................ 6-3
6.1.4 RAID conguration utilities .............................................. 6-3
6.2 Intel® Rapid Storage Technology Option ROM Utility ............... 6-4
6.2.1 Creating a RAID set ........................................................ 6-5
6.2.2 Creating a Recovery set ................................................. 6-6
6.2.3 Deleting a RAID set ........................................................ 6-8
6.2.4 Resetting disks to Non-RAID .......................................... 6-9
6.2.5 Recovery Volume Options ............................................ 6-10
6.2.6 Exiting the Intel® Rapid Storage Technology utility .........6-11
6.2.7 Rebuilding the RAID ......................................................6-11
6.2.8 Setting the Boot array in the BIOS Setup Utility ............ 6-13
Chapter 7: Driver installation
7.1 RAID driver installation ............................................................... 7-2
7.1.1 Creating a RAID driver disk ............................................ 7-2
7.1.2 Installing the RAID controller driver ................................ 7-5
vi
7.2 Intel® chipset device software installation ............................... 7-14
7.3 LAN driver installation ............................................................... 7-16
7.4 VGA driver installation............................................................... 7-19
7.5 Management applications and utilities installation ................ 7-22
7.5.1 Running the support DVD ............................................. 7-22
7.5.2 Drivers menu ................................................................. 7-22
7.5.3 Utilities menu ................................................................ 7-23
7.5.4 Make disk menu ............................................................ 7-23
7.5.5 Contact information ....................................................... 7-23
vii
Notices
Federal Communications Commission Statement
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions:
•
This device may not cause harmful interference, and
•
This device must accept any interference received including interference that
may cause undesired operation.
This equipment has been tested and found to comply with the limits for a Class
A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with manufacturer’s instructions,
may cause harmful interference to radio communications. However, there is
no guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is encouraged to
try to correct the interference by one or more of the following measures:
•
Reorient or relocate the receiving antenna.
•
Increase the separation between the equipment and receiver.
•
Connect the equipment to an outlet on a circuit different from that to which the
receiver is connected.
•
Consult the dealer or an experienced radio/TV technician for help.
Canadian Department of Communications Statement
This digital apparatus does not exceed the Class B limits for radio noise emissions
from digital apparatus set out in the Radio Interference Regulations of the
Canadian Department of Communications.
This Class B digital apparatus complies with Canadian ICES-003.
WARNING! The use of shielded cables for connection of the monitor to the
graphics card is required to assure compliance with FCC regulations. Changes
or modications to this unit not expressly approved by the party responsible for
compliance could void the user’s authority to operate this equipment.
REACH
Complying with the REACH (Registration, Evaluation, Authorization, and Restriction
of Chemicals) regulatory framework, we publish the chemical substances in our
products at ASUS REACH website at http://green.asus.com/english/REACH.htm.
viii
Safety information
Electrical Safety
• Before installing or removing signal cables, ensure that the power cables for
the system unit and all attached devices are unplugged.
• To prevent electrical shock hazard, disconnect the power cable from the
electrical outlet before relocating the system.
• When adding or removing any additional devices to or from the system, contact
a qualied service technician or your dealer. Ensure that the power cables for
the devices are unplugged before the signal cables are connected. If possible,
disconnect all power cables from the existing system before you service.
• If the power supply is broken, do not try to x it by yourself. Contact a qualied
service technician or your dealer.
Operation Safety
• Servicing of this product or units is to be performed by trained service
personnel only.
• Before operating the server, carefully read all the manuals included with the
server package.
• Before using the server, make sure all cables are correctly connected and the
power cables are not damaged. If any damage is detected, contact your dealer
as soon as possible.
• To avoid short circuits, keep paper clips, screws, and staples away from
connectors, slots, sockets and circuitry.
• Avoid dust, humidity, and temperature extremes. Place the server on a stable
surface.
This product is equipped with a three-wire power cable and plug for the user’s
safety. Use the power cable with a properly grounded electrical outlet to avoid
electrical shock.
Lithium-Ion Battery Warning
CAUTION! Danger of explosion if battery is incorrectly replaced. Replace
only with the same or equivalent type recommended by the manufacturer.
Dispose of used batteries according to the manufacturer’s instructions.
CD-ROM Drive Safety Warning
CLASS 1 LASER PRODUCT
Heavy System
CAUTION! This server system is heavy. Ask for assistance when moving or
carrying the system.
ix
About this guide
Audience
This user guide is intended for system integrators, and experienced users with at
least basic knowledge of conguring a server.
Contents
This guide contains the following parts:
1. Chapter 1: Product Introduction
This chapter describes the general features of the server, including sections
on front panel and rear panel specications.
2. Chapter 2: Hardware setup
This chapter lists the hardware setup procedures that you have to perform
when installing or removing system components.
3. Chapter 3: Rackmount installation
This chapter describes how to install the rackmount rail kit to the barebone
server
4. Chapter 4: Motherboard information
This chapter includes the motherboard layout and brief descriptions of the
jumpers and internal connectors.
5. Chapter 5: BIOS information
This chapter tells how to change system settings through the BIOS Setup
menus and describes the BIOS parameters.
6. Chapter 6: Driver installation
This chapter provides instructions for installing the necessary drivers for
different system components.
DO NOT throw the motherboard in municipal waste. This product has been
designed to enable proper reuse of parts and recycling. This symbol of the
crossed out wheeled bin indicates that the product (electrical and electronic
equipment) should not be placed in municipal waste. Check local regulations for
disposal of electronic products.
DO NOT throw the mercury-containing button cell battery in municipal waste.
This symbol of the crossed out wheeled bin indicates that the battery should not
be placed in municipal waste.
x
References
Refer to the following sources for additional information, and for product and
software updates.
1. ASUS Server Web-based Management (ASWM) user guide
This manual tells how to set up and use the proprietary ASUS server
management utility.
2. ASUS websites
The ASUS websites worldwide provide updated information for all ASUS
hardware and software products. Refer to the ASUS contact information.
Conventions
To make sure that you perform certain tasks properly, take note of the following
symbols used throughout this manual.
Typography
Bold text
Indicates a menu or an item to select.
Italics
Used to emphasize a word or a phrase.
<Key> Keys enclosed in the less-than and greater-than
sign means that you must press the enclosed key.
Example: <Enter> means that you must press
the Enter or Return key.
<Key1+Key2+Key3> If you must press two or more keys simultaneously,
the key names are linked with a plus sign (+).
Example: <Ctrl+Alt+D>
Command
Means that you must type the command exactly
as shown, then supply the required item or value
enclosed in brackets.
Example: At the DOS prompt, type the
command line:
format A:/S
DANGER/WARNING: Information to prevent injury to yourself when
trying to complete a task.
NOTE: Tips and additional information to help you complete a task.
IMPORTANT: Instructions that you MUST follow to complete a task.
CAUTION: Information to prevent damage to the components when
trying to complete a task.
This chapter describes the general
features of the server, including
sections on front panel and rear panel
specications.
Chapter 1
Product introduction
Chapter 1: Product introduction1-2
*ASUS System Web-based Management
If any of the above items is damaged or missing, contact your retailer.
1.1 System package contents
Check your system package for the following items.
1.2 Serial number label
Before requesting support from the ASUS Technical Support team, you must
take note of the product’s serial number containing 14 characters such as
xxS0xxxxxxxxxx shown as the gure below. With the correct serial number of the
product, ASUS Technical Support team members can then offer a quicker and
satisfying solution to your problems.
Model Name RS100-E7/PI2
Chassis ASUS R09 1U Rackmount Chassis
Motherboard ASUS P8B-M Server Board
Component 1 x 220W Single Power Supply
2 x SATA Cables
1 x PCI Express x16 Riser Card (PCIE16-R11)
1 x Front I/O Board (FPB-R9)
1 x USB Board (USB-R9)
2 x System Fans (40mm x 28mm)
Accessories 1 x RS100-E7/PI2 User’s Guide
1 x RS100-E7/PI2 Support CD
1 x Bag of Screws
1 x AC Power Cable
Optional
Items
CPU Heatsink
ASUS ASMB5-iKVM Remote management card
Slim-type Optical Device
Ball Bearing Rail Kit
xxS0xxxxxxxxxx
RS100-E7/PI2
ASUS RS100-E7/PI2 1-3
1.3 Systemspecications
The ASUS RS100-E7/PI2 is a 1U barebone server system featuring the ASUS
P8B-M server board. The server supports Intel® LGA1155 Lynneld / Clarkdale
processors, plus other latest technologies through the chipsets onboard.
Model Name RS100-E7/PI2
Processor / System Bus
1 x Socket LGA1155
Intel® Xeon® E3-1200 Processor Family
Intel® CoreTM i3-2100 Processor Family
Core Logic
Intel® C204 Chipset
ASUS Features
Smart Fan
√
ASWM2.0
√
Memory
Total Slots
4 (2 Channels)
Capacity
Maximum up to 32GB
Do not support R-DIMM and non ECC U-DIMM
Memory Type
DDR3 1333 / 1066 Unbuffered DIMM with ECC
Memory Size
1 GB, 2GB, 4GB, 8GB
Expansion
Slots
Total PCI/PCI-X/
PCI-E Slots
1
Slot Type
1 x PCI-E 2.0 x16 slot (x16 link) (Full-Height/HL)
Storage
2 x SATA3 6Gb/s
Intel® C204 (for Windows only)
- Supports software RAID 0 & 1
HDD Bays
I = internal
A or S = hotswappable
2 x Internal 3.5” SATA2 HDD Bays
Networking LAN
2 x Intel® 82574L + 1 x Mgmt LAN
Graphic VGA
Aspeed® AST2050 16MB
Auxiliary Storage FDD / CD / DVD
1 x Slim-type Optical Device Bay
(Options: No ODD / DVD-ROM / DVD-RW)
Onboard I/O
1 x External Serial Port
3 x RJ-45 ports (1 for ASMB5-iKVM)
4 x USB 2.0 ports (Front x 2, Rear x 2)
1 x VGA port
1 x PS/2 keyboard port
1 x PS/2 mouse port
(continued on the next page)
Chapter 1: Product introduction1-4
*Specicationsaresubjecttochangewithoutnotice.
OS Support
Windows® Server 2008 R2
Windows® Server 2008 Enterprise 32/64-bit
Windows® Server 2003 R2 Enterprise 32/64-bit
RedHat® Enterprise Linux AS5.5/6.0 32/64-bit
SuSE® Linux Enterprise Server 10 SP3/11 32/64-bit
(Subject to change without any notice)
Anti-virus Software
Optional anti-virus CD Pack
Management
Solution
Out of Band
Remote
Hardware
Optional ASMB5-iKVM for KVM-over-IP support
Software
ASUS ASWM Enterprise
®
Net Weight Kg (CPU, DRAM &
HDD not inclu ded)
6.5 Kg
Dimension (DD x WW x HH)
380mm x 429.6mm x 43.2mm
Power Supply
220W Single Power Supply
Power Rating
Input: 100-240Vac, 4-2A, 50-60Hz, Class I
Environment
Operation temperature: 10°C–35°C / Non operation
temperature: -40°C–70°C
Non operation humidity: 20%–90%
( Non-condensing)
ASUS RS100-E7/PI2 1-5
1.4 Front panel features
The barebone server displays a simple yet stylish front panel with easily accessible
features. The power and reset buttons, LED indicators, optical drive, and twp USB
ports are located on the front panel.
Refer to section 1.7.1 Front panel LEDs for the LED descriptions.
Turn off the system power and detach the power supply before removing or
replacing any system component.
1.5 Rear panel features
The rear panel includes the expansion slot and system power socket. The I/O
shield with openings for the rear panel connectors on the motherboard are also
placed in the rear panel.
AC power socket
USB 2.0 ports
PS/2 mouse port
PS/2 keyboard port
Serial port
VGA port
LAN port 1
LAN port 2
Expansion slot
LAN port 3*
Optical drive
USB 2.0 ports
HDD Access LED
LAN2 LED
LAN1 LED
Power LED
Reset button
Power button
• The ports for the PS/2 keyboard, PS/2 mouse, USB, VGA, and Gigabit LAN
do not appear on the rear panel if motherboard is not present.
• *The port is for ASUS ASMB5-iKVM controller card only.
Message LED
Chapter 1: Product introduction1-6
1.6 Internal features
The barebone server includes the basic components as shown.
The barebone server does not include a oppy disk drive. Connect a USB oppy
disk drive to any of the USB ports on the front or rear panel if you need to use a
oppy disk.
Turn off the system power and detach the power supply before removing or
replacing any system component.
*WARNING
HAZARDOUS MOVING PARTS
KEEP FINGERS AND OTHER BODY PARTS AWAY
1. PCI Express x16 Riser Card (at x16 link)
2. System Fan (x2) (9GV0412P3J051)
3. ASUS P8B-M Server Board
4. Power Supply
5. HDD Tray 2 (hidden) and Slim-type Optical
Drive (optional)
6. HDD Tray 1
6
1
2
3
4
5
ASUS RS100-E7/PI2 1-7
1.7 LED information
1.7.1 Front panel LEDs
LED Icon Display status Description
Power LED ON System power ON
HDD Access LED
OFF
Blinking
No activity
Read/write data into the HDD
Message LED
OFF
System is normal; no incoming event
ON
1. Without ASMB5-iKVM installed: CPU
over-heated
2. With ASMB5-iKVM installed: a
hardware monitor event is indicated
LAN LEDs
OFF
Blinking
ON
No LAN connection
LAN is transmitting or receiving data
LAN connection is present
HDD Access LED
LAN2 LED
LAN1 LED
Power LED
1.7.2 LAN (RJ-45) LEDs
ACT/LINK LED SPEED LED
Status Description Status Description
OFF No link OFF 10 Mbps connection
GREEN Linked ORANGE 100 Mbps connection
BLINKING Data activity GREEN 1 Gbps connection
SPEED LED
ACT/LINK LED
Message LED
Chapter 1: Product introduction1-8
This chapter lists the hardware setup
procedures that you have to perform
when installing or removing system
components.
Chapter 2
Hardware setup
Chapter 2: Hardware setup2-2
2.1 Chassis cover
2.1.1 Removing the chassis cover
• Ensure that you unplug the power cord before removing the chassis cover.
• Take extra care when removing the chassis cover. Keep your ngers from
components inside the chassis that can cause injury, such as the CPU fan,
rear fan, and other sharp-edged parts.
• The images of the barebone server shown in this section are for reference
purposes only and may not exactly match the model you purchase.
To remove the chassis cover:
1. Use a Phillips screwdriver to remove the three screws on the chassis cover.
2. Firmly hold the cover and
slide it toward the rear
panel for about half an inch
until it is disengaged from
the chassis.
3. Lift the cover from the chassis.
2-3ASUS RS100-E7/PI2
2.1.2 Reinstalling the chassis cover
To reinstall the chassis cover:
1. Position the cover on top of the chassis with the hooks aligned to the side
tabs of the chassis.
2. Slide the cover toward the front until it snaps in place.
Side tabs
Chapter 2: Hardware setup2-4
3. Secure the cover with three screws.
2-5ASUS RS100-E7/PI2
2.2.1 Installing the CPU
To install a CPU:
1. Locate the CPU socket on the motherboard.
Before installing the CPU, ensure that the socket box is facing toward you and
the load lever is on your left.
2.2 Central Processing Unit (CPU)
The motherboard comes with a surface mount LGA1155 socket designed for the
Intel® Xeon E3-1200/Core™ i3-2100 processor.
• Upon purchase of the motherboard, ensure that the PnP cap is on
the socket and the socket contacts are not bent. Contact your retailer
immediately if the PnP cap is missing, or if you see any damage to the PnP
cap/socket contacts/motherboard components. ASUS will shoulder the cost
of repair only if the damage is shipment/transit-related.
• Keep the cap after installing the motherboard. ASUS will process Return
Merchandise Authorization (RMA) requests only if the motherboard comes
with the cap on the LGA1155 socket.
• The product warranty does not cover damage to the socket contacts
resulting from incorrect CPU installation/removal, or misplacement/loss/
incorrect removal of the PnP cap.
To prevent damage to the socket
pins, do not remove the PnP cap
unless you are installing a CPU.
A
B
Load lever
Retention tab
2. Press the load lever with your
thumb (A), and then move it to the
right (B) until it is released from the
retention tab.
Chapter 2: Hardware setup2-6
The CPU ts in only one correct
orientation. DO NOT force the
CPU into the socket to prevent
bending the connectors on the
socket and damaging the CPU!
Gold
triangle
mark
Alignment keys
CPU notches
5. Position the CPU over the socket,
ensuring that the gold triangle is on
the bottom-left corner of the socket,
and then t the socket alignment
keys into the CPU notches.
4. Remove the PnP cap from the CPU
socket.
PnP cap
3. Lift the load lever in the direction
of the arrow until the load plate is
completely lifted.
Load plate
2-7ASUS RS100-E7/PI2
7. Close the load plate (A), and then
push down the load lever (B),
ensuring that the front edge of the
load plate slides under the retention
lock (C).
C
B
A
8. Insert the load lever under the
retention tab.
Some heatsinks come with preapplied thermal paste. If so, skip
this step.
The Thermal Interface Material is
toxic and inedible. DO NOT eat it.
If it gets into your eyes or touches
your skin, wash it off immediately,
and seek professional medical
help.
6. Apply some Thermal Interface
Material to the exposed area of
the CPU that the heatsink will be
in contact with, ensuring that it is
spread in an even thin layer.
Chapter 2: Hardware setup2-8
2.2.2 Installing the CPU heatsink and airduct
To install the CPU heatsink:
1. Lift one side of the mylar and set it
aside for installing the CPU heatsink.
Protection sticker
3. Place the heatsink on top of the
installed CPU, ensuring that the
four fasteners match the holes on
the motherboard.
2. Remove the protection sticker on
the back of the CPU heatsink.
2-9ASUS RS100-E7/PI2
Tighten the four heatsink screws in a diagonal
sequence.
A
B
B
A
4. Twist each of the four screws with
a Philips (cross) screwdriver just
enough to attach the heatsink to
the motherboard. When the four
screws are attached, tighten them
one by one to completely secure
the heatsink.
5. Secure the heat pipe and air duct
to the server with two screws.
6. Set the mylar back to its original
place. When the mylar is properly
installed, the hook as shown below
should attach the motherboard edge.
Ensure that the mylar does not interfere any motherboard headers or capacitors.
Chapter 2: Hardware setup2-10
2.3 System memory
2.3.1 Overview
The motherboard comes with four Double Data Rate 3 (DDR3) Dual Inline Memory
Modules (DIMM) sockets.
A DDR3 module has the same physical dimensions as a DDR2 DIMM but is
notched differently to prevent installation on a DDR2 DIMM socket. DDR3 modules
are developed for better performance with less power consumption.
The gure illustrates the location of the DDR3 DIMM sockets:
2.3.2 MemoryCongurations
You may install 1GB, 2GB, 4GB and 8GB Unbuffered with ECC DDR3 DIMMs into
the DIMM sockets using the memory congurations in this section.
UDIMM
DIMM Slot
Per Channel
DIMM Populated
per Channel
DIMM Type Speed Rank per DIMM
2 1 Unbuffered DDR3 ECC 1066/1333
Single Rank,
Dual Rank
2 2 Unbuffered DDR3 ECC 1066/1333
Single Rank,
Dual Rank
• Start installing the DIMMs from slot A1 and B1 (orange).
• Always install DIMMs with the same CAS latency. For optimum
compatibility, it is recommended that you obtain memory modules from the
same vendor.
2-11ASUS RS100-E7/PI2
2.3.3 Installing a DIMM
2.3.4 Removing a DIMM
Follow these steps to remove a DIMM.
1. Simultaneously press the
retaining clips outward to unlock
the DIMM.
2. Remove the DIMM from the socket.
1
1
2
3. Firmly insert the DIMM into the
socket until the retaining clips snap
back in place and the DIMM is
properly seated.
Ensure to unplug the power supply before adding or removing DIMMs or other
system components. Failure to do so may cause severe damage to both the
motherboard and the components.
A DIMM is keyed with a notch so that it ts in only one direction. DO NOT force
a DIMM into a socket to avoid damaging the DIMM.
Unlocked retaining clip
1
DIMM notch
1. Unlock a DIMM socket by pressing
the retaining clips outward.
2. Align a DIMM on the socket
such that the notch on the DIMM
matches the break on the socket.
Locked Retaining Clip
2
1
Support the DIMM lightly with your ngers when pressing the retaining clips.
The DIMM might get damaged when it ips out with extra force.
3
Chapter 2: Hardware setup2-12
2.4 Hard disk drives
You can install up to two (2) Serial ATA hard disk drives to the system. Follow the
succeeding instructions to install each of the drives.
2.4.1 Installing a hard disk drive to the HDD tray 1
To install a hard disk drive to the HDD tray 1:
1. Locate the HDD tray 1 beside the
power supply unit. Notice the four
standard screw holes.
2. Connect the SATA signal cable and
a power plug from the power supply
to the hard disk drive.
L-type SATA
connector
3. Place the hard disk drive into the
HDD tray 1 matching the four screw
holes with the holes on the disk
drive.
Power plug
SATA signal cable
Use the L-type SATA connector
to connect to the hard disk drive.
2-13ASUS RS100-E7/PI2
4. Secure the hard disk drive with four
screws.
2.4.2 Installing a hard disk drive to the HDD tray 2
To install a hard disk drive to the HDD tray 2:
1. If you have an ODD installed,
remove the ODD rst before
installing a hard disk drive to the
HDD tray 2.
Disconnect the ODD cable, and then
use a screwdriver to remove the two
screws as shown.
2. Remove the four screws to release
the HDD bracket under the optical
disk drive.
HDD bracket
Chapter 2: Hardware setup2-14
3. Insert the hard disk drive into the
HDD bracket and secure it with four
screws.
5. Place the HDD bracket with the
hard disk drive installed into the
HDD tray 2, matching the four
screw holes. Then, secure the HDD
bracket with four screws.
4. Connect the SATA signal cable and
a power plug from the power supply
to the hard disk drive.
L-type SATA
connector
Use the L-type SATA connector
to connect to the hard disk drive.
6. Refer to section
2.7.2 Optical disk drive (ODD)
to reinstall the ODD.
Power plug
SATA signal cable
2-15ASUS RS100-E7/PI2
2.5 Expansion card
The system comes with a riser card. You need to remove the riser card and the
expansion slot bracket if you want to install an expansion card.
Ensure to unplug the power cord before installing or removing an expansion
card. Failure to do so may cause severe damage to the motherboard and other
system components!
2.5.1 Installing an expansion card
To install an expansion card:
1. Hold the riser card and pull it up to
detach it from the PCI Express slot
on the motherboard.
3. Remove the screw to release the
metal slot cover from the expansion
card bracket.
2. Remove the screw to release the
expansion card bracket from the
system.
Chapter 2: Hardware setup2-16
4. Install the expansion card to the
riser card as shown.
5. Attach the expansion card to the
expansion card bracket, and then
secure the card with a screw.
6. Align the riser card with the
expansion card installed to the PCI
Express slot on the motherboard.
7. Press the riser card until the golden
connectors completely t the slot
and the bracket aligns with the rear
panel.
8. Secure the expansion card bracket
to the system with one screw.
2-17ASUS RS100-E7/PI2
2.5.2 Conguringanexpansioncard
After installing the expansion card, congure the it by adjusting the software settings.
1. Turn on the system and change the necessary BIOS settings, if any. See
Chapter 5 for information on BIOS setup.
2. Assign an IRQ to the card. Refer to the following tables.
3. Install the software drivers for the expansion card.
* These IRQs are usually available for ISA or PCI devices.
Standard Interrupt assignments
IRQ Priority Standard function
0 1 System Timer
1 2 Keyboard Controller
2 - Programmable Interrupt
3* 11 Communications Port (COM2)
4* 12 Communications Port (COM1)
5* 13 --
6 14 Floppy Disk Controller
7* 15 -8 3 System CMOS/Real Time Clock
9* 4 ACPI Mode when used
10* 5 IRQ Holder for PCI Steering
11* 6 IRQ Holder for PCI Steering
12* 7 PS/2 Compatible Mouse Port
13 8 Numeric Data Processor
14* 9 Primary IDE Channel
15* 10 Secondary IDE Channel
Chapter 2: Hardware setup2-18
2.6 Cable connections
• The bundled system cables are pre-connected before shipment. You do
not need to disconnect these cables unless you will remove pre-installed
components to install additional devices.
• Refer to Chapter 4 for detailed information on the connectors.
Standard cables connected to the motherboard
1. 24-pin ATX power connector (from power supply to motherboard)
2. 8-pin ATX 12V power connector (from power supply to motherboard)
3. System fan connector (from system fan to motherboard)
4. SATA conectors (system default; from motherboard to SATA devices)
5. USB connector (from motherboard to front I/O board)
6. System panel connectors (from motherboard to front I/O board)
3
2
1
4
5
3
3
6
2-19ASUS RS100-E7/PI2
2.7 Removable/optional components
You may need to remove previously installed system components when installing
or removing system devices. Or you may need to install the optional components
into the system. This section tells how to remove/install the following components:
1. System fans
2. Optical disk drive (optional)
3. ASUS ASMB5-iKVM (optional)
Ensure that the system is turned off before removing any components.
2.7.1 Chassis fans
To remove the system fan:
1. Place the chassis fans and mylar
module besides the heatsink,
matching the screw holes on the
chassis.
2. Tighten the screws.
3. Connect the chassis fans cable to
the onboard fan connectors labeled
CPU_FAN1 and FRNT_FAN1.
Chapter 2: Hardware setup2-20
2.7.2 Optical disk drive (ODD)
To install the optical disk drive:
1. Slide in the optical disk drive into the
drive slot as shown.
2. Align the screw hole of the ODD
bracket with the one on the HDD
bracket, and then secure it with a
screw.
ODD bracket
Optical disk drive (optional)
3. Attach the ODD side bracket to the
ODD, matching the two connectors
of the bracket with the holes on the
side of the ODD.
ODD side bracket
Bracket
connectors
Optical disk drive slot
2-21ASUS RS100-E7/PI2
4. Secure the ODD side bracket to the
HDD bracket with a screw.
5. Connect the ODD cable to the
optical disk drive.
Chapter 2: Hardware setup2-22
2.7.3 Installing ASMB5 series management board (optional)
Follow the steps below to install an optional ASMB5 series management board on
your motherboard.
3. Insert the LAN cable plug to the
LAN port 3 (dedicated LAN) or
LAN port 1 (shared LAN) for server
management.
1. Locate the BMC_FW header on the
motherboard.
2. Orient and press the ASMB5
management card in place.
LAN port 1
LAN port 2
2-
This chapter describes how to install
the rackmount rail kit to the barebone
server.
Chapter 3
Rackmount installation
Chapter 3: Rackmount installation3-2
3.1 Rackmount rail kit items
The rackmount rail kit contains two pairs of rails (one pair for each side of the
server system), six (6) pieces of inner rail screws, and two (2) pieces of rack
screws.
Inner rail screwsRack screws
Outer rails
Inner rails
3.2 Attaching the rails to the rack
To attach the rack rails:
1. Attach the inner rail to the correspoding side of the chassis and secure with
three inner rail screws. Make sure the rail is oriented as shown.
3-3ASUS RS100-E7/PI2
2. Attach the second inner rail to the other side of the chassis and secure with
three inner rail screws.
3. Select one unit of space (1U) on
the rack where you wish to install
the server.
4. Place three (3) nuts on the front
and three at the back. Do the same
to the corresponding side of the
rack.
Nuts
5. Adjust the length of the outer rail
to t the length of the rack cabinet,
then fasten the two screws.
6. Secure the outer rail with two
screws at the front and rear of the
rack cabinet .
7. Find the corresponding 1U space
on the other side of the rack cabinet
then repeat steps 5 and 6 to attach
the other outer rail.
Chapter 3: Rackmount installation3-4
8. Firmly hold the server on both sides. Slide the latches on the inner rack rails
to the direction indicated below. Hold the latches, and insert the rear side of
the server to the front end of the outer rack rail.
Make sure that the inner rails are properly aligned with the outer rails.
3-5ASUS RS100-E7/PI2
10. Secure the server to the rack with
one rack screw at one side. Secure
the other side as well.
9. Carefully push the server all the way to the back until the front panel ts the
front end of the rack.
Rack screw
Chapter 3: Rackmount installation3-6
This chapter includes the motherboard
layout and brief descriptions of the
jumpers and internal connectors.
Chapter 4
Motherboard Info
Chapter 4: Motherboard information4-2
4.1 Motherboard layout
ASUS RS100-E7/PI2 4-3
Layout contents
Slots/Soocket Page
1. CPU sockets 2-5
2. DDR3 sockets 2-10
3. PCI Express x8 / PCI Express x16 / PCI slots 2-15
Jumpers Page
1. Clear RTC RAM (CLRTC1) 4-5
2. VGA controller setting (3-pin VGA_SW1) 4-6
3. CPU Fan and Chassis Fan control setting
(3-pin CPUFAN_SEL1, CHAFAN_SEL1)
4-6
4. LAN controller setting (3-pin LAN_SW1, LAN_SW2) 4-7
5. RAID conguration utility selection (3-pin RAID_SEL1) 4-7
6. Force BIOS recovery setting (3-pin RECOVERY1) 4-8
7. Chassis intrusion connector (2-pin CHASSIS) 4-9
8. ME rmware force recovery setting (3-pin ME_RECOVERY1) 4-9
Internal connectors Page
1. Serial ATA connectors
(SATA 6Gb/s: 7-pin SATA1, SATA2 [Blue])
(SATA 3Gb/s: 7-pin SATA3, SATA4, SATA5, SATA6 [Black])
4-10
2. Hard disk activity LED connector (4-pin HDLED1)
4-10
3. USB connector (10-1 pin USB34, USB56; A-Type USB7)
4-11
4. CPU, front and rear fan connectors
(4-pin CPU_FAN1, FRNT_FAN1, FRNT_FAN2, FRNT_FAN3,
REAR_FAN1)
4-11
5. Serial General Purpose Input/Output connector (6-1 pin SGPIO1)
4-12
6. Thermal sensor cable connectors (3-pin TR1)
4-12
7. Serial port connectors (10-1 pin COM1/COM2)
4-13
8. BMC header (BMC_FW1)
4-13
9. Power Supply SMBus connector (5-pin PSUSMB1)
4-14
10. TPM connector (20-1-pin TPM)
4-14
11. ATX power connectors (24-pin ATXPWR1, 8-pin ATX12V1)
4-15
12. System panel connector (20-1 pin PANEL1)
4-16
13. Auxiliary panel connector (20-2 pin AUX_PANEL1)
4-17
Chapter 4: Motherboard information4-4
4.2 Jumpers
1. Clear RTC RAM (CLRTC1)
This jumper allows you to clear the Real Time Clock (RTC) RAM in CMOS.
You can clear the CMOS memory of date, time, and system setup parameters
by erasing the CMOS RTC RAM data. The onboard button cell battery
powers the RAM data in CMOS, which include system setup information such
as system passwords.
To erase the RTC RAM:
1. Turn OFF the computer and unplug the power cord.
2. Move the jumper cap from pins 1–2 (default) to pins 2–3. Keep the cap
on pins 2–3 for about 5–10 seconds, then move the cap back to pins 1–2.
3. Plug the power cord and turn ON the computer.
4. Hold down the <Del> key during the boot process and enter BIOS setup
to re-enter data.
Except when clearing the RTC RAM, never remove the cap on CLRTC jumper
default position. Removing the cap will cause system boot failure!
If the steps above do not help, remove the onboard battery and move the
jumper again to clear the CMOS RTC RAM data. After the CMOS clearance,
reinstall the battery.
ASUS RS100-E7/PI2 4-5
2. VGA controller setting (3-pin VGA_SW1)
This jumper allows you to enable or disable the onboard VGA controller. Set
to pins 1–2 to activate the VGA feature.
3. CPU Fan and Chassis Fan control setting
(3-pin CPUFAN_SEL1, CHAFAN_SEL1)
These jumpers allow you to switch for fan pin selection. The CPUFAN_SEL1
jumper is for the CPU fans control and the CHAFAN_SEL1 jumper is for the
front fans and rear fans control. Set to pins 1–2 when using 4-pin fans or pins
2–3 when using 3-pin fans.
• If you use a 4-pin fan but set the jumper to pin 2–3, the fan you installed
may not work.
• If you use a 3-pin fan but set the jumper for a 4-pin fan, the fan control will
not work and the fan you installed will always run at full speed.
Chapter 4: Motherboard information4-6
4. LAN controller setting (3-pin LAN_SW1, LAN_SW2)
These jumpers allow you to enable or disable the onboard Intel
®
Intel
82574LGigabit LAN controllers. Set to pins 1–2 to activate the Gigabit LAN
feature.
5. RAIDcongurationutilityselection(3-pinRAID_SEL1)
This jumper allows you to select the RAID conguration utility to use when
you create disk arrays. Place the jumper caps over pins 1–2 if you want to
use the LSI Logic Embedded SATA RAID Setup Utility (default); otherwise,
place the jumper caps to pins 2–3 to use the Intel® Rapid Storage Manager.
ASUS RS100-E7/PI2 4-7
6. Force BIOS recovery setting (3-pin RECOVERY1)
This jumper allows you to quickly update or recover the BIOS settings when it
becomes corrupted.
To update the BIOS:
1. Prepare a USB ash disk that contains the original or latest BIOS for the
motherboard (XXXXXX.ROM).
2. Set the jumper to pins 2–3.
3. Insert the USB ash and turn on the system to update the BIOS.
4. Shut down the system.
5. Set the jumper back to pins 1–2.
6. Turn on the system.
Chapter 4: Motherboard information4-8
7. Chassis intrusion connector (2-pin CHASSIS)
This connector is for a chassis-mounted intrusion detection sensor or switch.
Connect one end of the chassis intrusion sensor or switch cable to this
connector. The chassis intrusion sensor or switch sends a high-level signal to
this connector when a chassis component is removed or replaced. The signal
is then generated as a chassis intrusion event.
By default , the pin labeled “Chassis Signal” and “Ground” are shorted with
a jumper cap. Remove the jumper caps only when you intend to use the
chassis intrusion detection feature.
8. MErmwareforcerecoverysetting(3-pinME_RECOVERY1)
This jumper allows you to quickly recover the Intel Management Engine (ME)
rmware when it becomes corrupted.
ASUS RS100-E7/PI2 4-9
4.3 Internal connectors
1. Serial ATA connectors
(SATA 6Gb/s: 7-pin SATA1, SATA2 [Blue])
(SATA 3Gb/s: 7-pin SATA3, SATA4, SATA5, SATA6 [Black])
Supported by the Intel® C204 chipset, these connectors are for the Serial ATA
signal cables for Serial ATA hard disk drives that allows up to 6Gb/s of data
transfer rate.
If you installed Serial ATA hard disk drives, you can create a RAID 0, RAID 1,
RAID 10, or RAID 5 conguration.
2. Hard disk activity LED connector (4-pin HDLED1)
This LED connector is for the storage add-on card cable connected to
the SATA or SAS add-on card. The read or write activities of any device
connected to the SATA or SAS add-on card causes the front panel LED to
light up.
The actual data transfer rate depends on the speed of Serial ATA hard disks
installed.
Chapter 4: Motherboard information4-10
3. USB connector (10-1 pin USB34, USB56; A-Type USB7)
These connectors are for USB 2.0 ports. Connect the USB module cables
to connectors USB34, then install the modules to a slot opening at the
back of the system chassis. These USB connectors comply with USB 2.0
specication that supports up to 480 Mbps connection speed.
4. CPU, front and rear fan connectors
(4-pin CPU_FAN1, FRNT_FAN1, FRNT_FAN2, FRNT_FAN3, REAR_FAN1)
The fan connectors support cooling fans of 350 mA–740 mA (8.88 W max.)
or a total of 3.15 A–6.66 A (53.28 W max.) at +12V. Connect the fan cables to
the fan connectors on the motherboard, ensuring that the black wire of each
cable matches the ground pin of the connector.
• DO NOT forget to connect the fan cables to the fan connectors. Insufcient
air ow inside the system may damage the motherboard components.
• These are not jumpers! DO NOT place jumper caps on the fan connectors!
• All fans feature the ASUS Smart Fan technology.
ASUS RS100-E7/PI2 4-11
6. Thermal sensor cable connectors (3-pin TR1)
This connector is for temperature monitoring. Connect the thermal sensor
cable to this connector and place the other end to the device, which you want
to monitor temperature.
You can connect the thermal sensor cable to either pin 1-2 or pin 2-3.
5. Serial General Purpose Input/Output connector (6-1 pin SGPIO1)
This connector is used for the SGPIO peripherals for the Intel Rapid Storage
Technology RAID SATA LED.
Chapter 4: Motherboard information4-12
7. Serial port connector (10-1 pin COM2)
Thess connectors are for the serial (COM) ports. Connect the serial port
module cable to one of these connectors, then install the module to a slot
opening at the back of the system chassis.
8. BMC header (BMC_FW1)
The BMC connector on the motherboard supports an ASUS® Server
Management Board 5 Series (ASMB5).
ASUS RS100-E7/PI2 4-13
9. Power Supply SMBus connector (5-pin PSUSMB1)
This connector allows you to connect SMBus (System Management Bus) to
the power supply unit to read PSU information. Devices communicate with an
SMBus host and/or other SMBus devices using the SMBus interface.
This connector functions only when you install the ASUS ASMB5.
10. TPM connector (20-1 pin TPM)
This connector supports a Trusted Platform Module (TPM) system, which can
securely store keys, digital certicates, passwords, and data. A TPM system
also helps enhance network security, protects digital identities, and ensures
platform integrity.
Chapter 4: Motherboard information4-14
11. ATX power connectors (24-pin ATXPWR1, 8-pin ATX12V1)
These connectors are for an ATX power supply plugs. The power supply
plugs are designed to t these connectors in only one orientation. Find the
proper orientation and push down rmly until the connectors completely t.
• DO NOT forget to connect the 24+8-pin power plugs; otherwise, the system
will not boot up.
• Use of a PSU with a higher power output is recommended when conguring
a system with more power-consuming devices. The system may become
unstable or may not boot up if the power is inadequate.
• This motherboard supports ATX2.0 PSU or later version.
• Ensure that your power supply unit (PSU) can provide at least the minimum
power required by your system.
ASUS RS100-E7/PI2 4-15
12. System panel connector (20-1 pin PANEL1)
This connector supports several chassis-mounted functions.
1. System power LED (3-pin PLED)
This 3-pin connector is for the system power LED. Connect the chassis
power LED cable to this connector. The system power LED lights up
when you turn on the system power, and blinks when the system is in
sleep mode.
2. Message LED (2-pin MLED)
This 2-pin connector is for the message LED cable that connects to
the front message LED. The message LED is controlled by Hardware
monitor to indicate an abnormal event occurance.
3. System warning speaker (4-pin SPEAKER)
This 4-pin connector is for the chassis-mounted system warning
speaker. The speaker allows you to hear system beeps and warnings.
4. Hard disk drive activity LED (2-pin HDDLED)
This 2-pin connector is for the HDD Activity LED. Connect the HDD
Activity LED cable to this connector. The IDE LED lights up or ashes
when data is read from or written to the HDD.
5. Power button/soft-off button (2-pin PWRSW)
This connector is for the system power button. Pressing the power
button turns the system on or puts the system in sleep or soft-off mode
depending on the BIOS settings. Pressing the power switch for more
than four seconds while the system is ON turns the system OFF.
6. Reset button (2-pin RESET)
This 2-pin connector is for the chassis-mounted reset button for system
reboot without turning off the system power.
Chapter 4: Motherboard information4-16
13. Auxiliary panel connector (20-2 pin AUX_PANEL1)
This connector is for additional front panel features including front panel
SMB, locator LED and switch, chassis intrusion, and LAN LEDs.
1. Front panel SMB (6-1 pin FPSMB)
These leads connect the front panel SMBus cable.
2. LAN activity LED (2-pin LAN1_LED, LAN2_LED)
These leads are for Gigabit LAN activity LEDs on the front panel.
3. Chassis intrusion (4-1 pin CHASSIS)
These leads are for the intrusion detection feature for chassis with
intrusion sensor or microswitch. When you remove any chassis
component, the sensor triggers and sends a high-level signal to these
leads to record a chassis intrusion event. The default setting is short
CASEOPEN and GND pin by jumper cap to disable the function.
4. Locator LED (2-pin LOCATORLED1 and 2-pin LOCATORLED2)
These leads are for the locator LED1 and LED2 on the front panel.
Connect the Locator LED cables to these 2-pin connector. The LEDs will
light up when the Locator button is pressed.
5. Locator Button/Swich (2-pin LOCATORBTN)
These leads are for the locator button on the front panel. This button
queries the state of the system locator.
This chapter tells how to change the
system settings through the BIOS Setup
menus. Detailed descriptions of the BIOS
parameters are also provided.
Chapter 5
BIOS setup
5-2 Chapter 5: BIOS setup
5.1 Managing and updating your BIOS
The following utilities allow you to manage and update the motherboard Basic
Input/Output System (BIOS) setup:
1.
ASUS CrashFree BIOS 3
(To recover the BIOS using a bootable USB ash
disk drive when the BIOS le fails or gets corrupted.)
2.
ASUS EZ Flash 2
(Updates the BIOS using a USB ash disk.)
3.
BUPDATER utility
(Updates the BIOS in DOS mode using a bootable USB
ash disk drive.)
Refer to the corresponding sections for details on these utilities.
Save a copy of the original motherboard BIOS le to a bootable
USB ash
disk drive
in case you need to restore the BIOS in the future. Copy the original
motherboard BIOS using the BUPDATER utility.
5.1.1 ASUS CrashFree BIOS 3 utility
The ASUS CrashFree BIOS 3 is an auto recovery tool that allows you to restore
the BIOS le when it fails or gets corrupted during the updating process. You can
update a corrupted BIOS le using a USB ash drive that contains the updated
BIOS le.
Prepare a USB ash drive containing the updated motherboard BIOS before
using this utility.
RecoveringtheBIOSfromaUSBashdrive
To recover the BIOS from a USB ash drive:
1. Insert the USB ash drive with the original or updated BIOS le to one USB
port on the system.
2. The utility will automatically recover the BIOS. It resets the system when the
BIOS recovery nished.
DO NOT shut down or reset the system while recovering the BIOS! Doing so
would cause system boot failure!
The recovered BIOS may not be the latest BIOS version for this motherboard.
Visit the ASUS website at www.asus.com to download the latest BIOS le.
ASUS RS100-E7/PI2 5-3
3. Press <Tab> to switch to the Drive eld.
4. Press the Up/Down arrow keys to nd the USB ash disk that contains the
latest BIOS, and then press <Enter>.
5. Press <Tab> to switch to the Folder Info eld.
6. Press the Up/Down arrow keys to nd the BIOS le, and then press <Enter>
to perform the BIOS update process. Reboot the system when the update
process is done.
5.1.2 ASUS EZ Flash Utility
The ASUS EZ Flash Utility feature allows you to update the BIOS without having to
use a DOS-based utility.
Before you start using this utility, download the latest BIOS from the ASUS
website at www.asus.com.
To update the BIOS using EZ Flash Utility
1. Insert the USB ash disk that contains the latest BIOS le to the USB port.
2. Enter the BIOS setup program. Go to the
Tool
menu to select
ASUS EZ
Flash Utility
and press <Enter> to enable it.
Flash Info
MODEL: P8B-M VER: 0205 DATE: 01/14/2011
Exit
[Enter] Select or Load [Tab] Switch [Up/Down/PageUp/PageDown/Home/End] Move [Esc] Exit [F2] Backup
fs0:\
Drive Folder Info
fs0:\ 12/09/10 10:23p 4194304 P8B-M.ROM
fs1:\
ASUSTek EZ Flash BIOS ROM Utility V00.75
File Infor
MODEL: VER: DATE:
Help Info
5-4 Chapter 5: BIOS setup
5.1.3 BUPDATER utility
The succeeding BIOS screens are for reference only. The actual BIOS screen
displays may not be the same as shown.
The BUPDATER utility allows you to update the BIOS le in DOS environment
using a bootable USB ash disk drive with the updated BIOS le.
UpdatingtheBIOSle
To update the BIOS le using the BUPDATER utility:
1. Visit the ASUS website at www.asus.com and download the latest BIOS le
for the motherboard. Save the BIOS le to a bootable USB ash disk drive.
2. Copy the BUPDATER utility (BUPDATER.exe) from the ASUS support
website at support.asus.com to the bootable USB ash disk drive you created
earlier.
3. Boot the system in DOS mode, then at the prompt, type:
BUPDATER /i[lename].ROM
where [lename] is the latest or the original BIOS le on the bootable USB
ash disk drive, then press <Enter>.
A:\>BUPDATER /i[le name].ROM
• This function can support devices such as a USB ash disk with FAT 32/16
format and single partition only.
• DO NOT shut down or reset the system while updating the BIOS to prevent
system boot failure!
Ensure to load the BIOS default settings to ensure system compatibility and
stability. Press <F5> and select Yes to load the BIOS default settings.
ASUS RS100-E7/PI2 5-5
The utility veries the le, then starts updating the BIOS le.
DO NOT shut down or reset the system while updating the BIOS to prevent
system boot failure!
ASUSTek BIOS Update for DOS V1.06 (09/08/04)
Current ROM
Update ROM
Note
Writing BIOS:
FLASH TYPE: MXIC 25L1605A
PATH:
BOARD: P8B-M
VER: 0201
DATE: 12/01/2010
BOARD: P8B-M
VER: 0202
DATE: 12/09/2010
5. The utility returns to the DOS prompt after the BIOS update process is
completed. Reboot the system from the hard disk drive.
The BIOS update is nished! Please restart your system.
C:\>
WARNING! Do not turn off power during ash BIOS
5-6 Chapter 5: BIOS setup
5.2 BIOS setup program
This motherboard supports a programmable rmware chip that you can update
using the provided utility described in section
5.1 Managing and updating your
BIOS
.
Use the BIOS Setup program when you are installing a motherboard, reconguring
your system, or prompted to “Run Setup.” This section explains how to congure
your system using this utility.
Even if you are not prompted to use the Setup program, you can change the
conguration of your computer in the future. For example, you can enable the
security password feature or change the power management settings. This
requires you to recongure your system using the BIOS Setup program so that the
computer can recognize these changes and record them in the CMOS RAM of the
rmware chip.
The rmware chip on the motherboard stores the Setup utility. When you start up
the computer, the system provides you with the opportunity to run this program.
Press <Del> during the Power-On Self-Test (POST) to enter the Setup utility;
otherwise, POST continues with its test routines.
If you wish to enter Setup after POST, restart the system by pressing
<Ctrl+Alt+Delete>, or by pressing the reset button on the system chassis. You can
also restart by turning the system off and then back on. Do this last option only if
the rst two failed.
The Setup program is designed to make it as easy to use as possible. Being a
menu-driven program, it lets you scroll through the various sub-menus and make
your selections from the available options using the navigation keys.
• The default BIOS settings for this motherboard apply for most conditions
to ensure optimum performance. If the system becomes unstable after
changing any BIOS settings, load the default settings to ensure system
compatibility and stability. Press <F5> and select
Yes
to load the BIOS
default settings.
• The BIOS setup screens shown in this section are for reference purposes
only, and may not exactly match what you see on your screen.
• Visit the ASUS website (www.asus.com) to download the latest BIOS le for
this motherboard.
ASUS RS100-E7/PI2 5-7
5.2.2 Menu bar
The menu bar on top of the screen has the following main items:
Main
For changing the basic system conguration
Event Logs
For changing the event log settings
Advanced
For changing the advanced system settings
Monitor
For displaying the system temperature, power status, and
changing the fan settings
Boot
For changing the system boot conguration
Tool
For conguring options for special functions
Exit
For selecting the exit options
To select an item on the menu bar, press the right or left arrow key on the keyboard
until the desired item is highlighted.
5.2.1 BIOS menu screen
Version 2.01.1204. Copyright (C) 2010 American Megatrends, Inc.
Aptio Setup Utility - Copyright (C) 2010 American Megatrends, Inc.
Main Event Logs Advanced Monitor Boot Tool Exit
Set the Date, Use Tab to
switch between Data elements.
→←: Select Screen
↑↓: Select Item
Enter: Select Item
+/-: Change Opt.
F1: General Help
F2: Previous Values
F5: Optimized Defaults
F10: Save & Exit
ESC: Exit
BIOS Information
BIOS Version 0202 x64
Build Date 02/14/2011
CPU Information
Intel(R) Xeon(R) CPU E31230 @ 3.20GHz
Memory Information
Total Memory 1024 MB
System Date [Tue 02/15/2011]
System Time [15:07:28]
Access Level Administrator
Security
Navigation keys
General help
Menu bar
Submenu item
CongurationeldsMenu items
5-8 Chapter 5: BIOS setup
5.2.3 Menu items
The highlighted item on the menu bar displays the specic items for that menu. For
example, selecting
Main
shows the Main menu items.
The other items (Event Logs, Advanced, Monitor, Boot, Tool, and Exit) on the menu
bar have their respective menu items.
5.2.4 Submenu items
A solid triangle before each item on any menu screen means that the item has a
submenu. To display the submenu, select the item and press <Enter>.
5.2.5 Navigation keys
At the bottom right corner of a menu screen are the navigation keys for the BIOS
setup program. Use the navigation keys to select items in the menu and change
the settings.
5.2.6 General help
At the top right corner of the menu screen is a brief description of the selected item.
5.2.7 Congurationelds
These elds show the values for the menu items. If an item is user-congurable,
you can change the value of the eld opposite the item. You cannot select an item
that is not user-congurable.
A congurable eld is enclosed in brackets, and is highlighted when selected. To
change the value of a eld, select it and press <Enter> to display a list of options.
5.2.8 Pop-up window
Select a menu item and press <Enter> to display a pop-up window with the
conguration options for that item.
5.2.9 Scroll bar
A scroll bar appears on the right side of a menu screen when there are items that
do not t on the screen. Press the Up/Down arrow keys or <Page Up> /<Page
Down> keys to display the other items on the screen.
ASUS RS100-E7/PI2 5-9
5.3 Main menu
When you enter the BIOS Setup program, the Main menu screen appears. The
Main menu provides you an overview of the basic system information, and allows
you to set the system date, time, language, and security settings.
5.3.1 System Date [Day xx/xx/xxxx]
Allows you to set the system date.
5.3.2 System Time [xx:xx:xx]
Allows you to set the system time.
5.3.3 Security
The Security menu items allow you to change the system security settings.
Aptio Setup Utility - Copyright (C) 2010 American Megatrends, Inc.
Main Event Logs Advanced Monitor Boot Tool Exit
Set Setup Administrator
Password
Password Description
If ONLY the Administrator's password is set,
then this only limits access to Setup and is
only asked for when entering Setup
If ONLY the User's password is set, then this
is a power on password and must be entered to
boot or enter Setup. In Setup the User will
have Administrator rights
Administrator Password Not Installed
User Password Not Installed
Administrator Password
User Password
• If you have forgotten your BIOS password, erase the CMOS Real Time
Clock (RTC) RAM to clear the BIOS password. See section 2.6 Jumpers
for information on how to erase the RTC RAM.
• The Administrator or User Password items on top of the screen show
the default Not Installed. After you set a password, these items show
Installed.
Aptio Setup Utility - Copyright (C) 2010 American Megatrends, Inc.
Main Event Logs Advanced Monitor Boot Tool Exit
Set the Date, Use Tab to
switch between Data elements.
BIOS Information
BIOS Version 0202 x64
Build Date 02/14/2011
CPU Information
Intel(R) Xeon(R) CPU E31230 @ 3.20GHz
Memory Information
Total Memory 1024 MB
System Date [Tue 02/15/2011]
System Time [15:07:28]
Access Level Administrator
Security
5-10 Chapter 5: BIOS setup
Administrator Password
If you have set an administrator password, we recommend that you enter the
administrator password for accessing the system. Otherwise, you might be able to
see or change only selected elds in the BIOS setup program.
To set an administrator password:
1. Select the Administrator Password item and press <Enter>.
2. From the Create New Password box, key in a password, then press <Enter>.
3. Conrm the password when prompted.
To change an administrator password:
1. Select the Administrator Password item and press <Enter>.
2. From the Enter Current Password box, key in the current password, then
press <Enter>.
3. From the Create New Password box, key in a new password, then press
<Enter>.
4. Conrm the password when prompted.
To clear the administrator password, follow the same steps as in changing an
administrator password, but press <Enter> when prompted to create/conrm the
password. After you clear the password, the Administrator Password item on top
of the screen shows Not Installed.
User Password
If you have set a user password, you must enter the user password for accessing
the system. The User Password item on top of the screen shows the default Not
Installed. After you set a password, this item shows Installed.
To set a user password:
1. Select the User Password item and press <Enter>.
2. From the Create New Password box, key in a password, then press
<Enter>.
3. Conrm the password when prompted.
To change a user password:
1. Select the User Password item and press <Enter>.
2. From the Enter Current Password box, key in the current password, then
press <Enter>.
3. From the Create New Password box, key in a new password, then press
<Enter>.
4. Conrm the password when prompted.
To clear the user password, follow the same steps as in changing a user password,
but press <Enter> when prompted to create/conrm the password. After you clear
the password, the User Password item on top of the screen shows Not Installed.
ASUS RS100-E7/PI2 5-11
5.4 Event Logs menu
The Event Logs menu items allow you to change the event log settings and view
the system event logs.
Aptio Setup Utility - Copyright (C) 2010 American Megatrends, Inc.
Main Event Logs Advanced Monitor Boot Tool Exit
Press <Enter> to change the
Smbios Event Log conguration.
Change Smbios Event Log Settings
View Smbios Event Log
View System Event Log
Smbios Event Log [Enabled]
Allows you to enable or disable all features of Smbios event logging.
Conguration option: [Disabled] [Enabled]
Erase Event Log [No]
Allows you to select the options for erasing Smbios event log.
Conguration options: [No] [Yes, Next reset] [Yes, Every reset]
When Log is Full [Do Nothing]
Allows you to select the options for reaction when the event logs are full.
Conguration options: [Do Nothing] [Erase Immediately]
MECI [xx]
Allows you to adjust value for the MECI (Multiple Event Count Increment),
which is the number of occurrences of a duplicate event that must pass
before the multiple-event counter associated with log entry is updated. Use
the <+> and <-> keys to adjust the value. The values range from 1 to 255.
METW [xx]
Allows you to adjust value for the METW (Multiple Event Time Window),
which is the number of minutes that must pass between duplicate log entries
which utilize a multiple-event counter. Use the <+> and <-> keys to adjust the
value. The values range from 0 to 99.
Change Smbios Event Log Settings
Aptio Setup Utility - Copyright (C) 2010 American Megatrends, Inc.
Main Event Logs Advanced Monitor Boot Tool Exit
Change this to enable or
disable all features of Smbios
Event Logging during boot.
Enabling/Disabling Options
Smbios Event Log [Enabled]
Erasing Settings
Erase Event Log [No]
When Log is Full [Do Nothing]
Smbios Event Log Standard Settings
MECI 1
METW 60
Custom Options
Log OEM Codes [Enabled]
Convert OEM Codes [Disabled]
NOTE: All values changed here do not take effect
until computer is restarted.
5-12 Chapter 5: BIOS setup
Log OEM Codes [Enabled]
Allows you to enable or disable the logging of EFI status codes as OEM
codes. Conguration option: [Disabled] [Enabled]
Convert OEM Codes [Disabled]
Allows you to enable or disable the converting of EFI status codes to standard
Smbios types. Conguration option: [Disabled] [Enabled]
View Smbios Event Log
Press <Enter> to view the Smbios event logs.
View System Event Log
Press <Enter> to view the system event logs.
ASUS RS100-E7/PI2 5-13
5.5 Advanced menu
The Advanced menu items allow you to change the settings for the CPU and other
system devices.
Take caution when changing the settings of the Advanced menu items. Incorrect
eld values can cause the system to malfunction.
Aptio Setup Utility - Copyright (C) 2010 American Megatrends, Inc.
Main Event Logs Advanced Monitor Boot Tool Exit
System ACPI Parameters
ACPI Settings
Trusted Computing
WHEA Conguration
CPU Conguration
North Bridge
South Bridge
SATA Conguration
Intel TXT(LT) Conguration
USB Conguration
Onboard Devices Conguration
APM
Serial Port Console Redirection
5.5.1 ACPI Settings
Aptio Setup Utility - Copyright (C) 2010 American Megatrends, Inc.
Advanced
Enables or Disables BIOS ACPI
Auto Conguration.
ACPI Settings
Enable ACPI Auto Conguration [Disabled]
ACPI Sleep State [S3 (Suspend to RAM)]
EnableACPIAutoConguration[Disabled]
Allows you to enable or disable ACPI Auto Conguration.
Conguration options: [Disabled] [Enabled]
ACPI Sleep State [S3 (Suspend to RAM)]
Allows you to set the ACPI Sleep State.
Conguration options: [Suspend Disabled] [S1 (CPU Stop Clock)] [S3 (Suspend to
RAM)]
5-14 Chapter 5: BIOS setup
5.5.2 Trusted Computing
Aptio Setup Utility - Copyright (C) 2010 American Megatrends, Inc.
Advanced
Enables or Disables TPM
support. O.S. will not show
TPM. Reset of platform is
required.
TPM Conguration
TPM SUPPORT [Disabled]
Current TPM Status Information
NO TPM Hardware
TPM SUPPORT [Disabled]
Allows you to enable or disable the TPM support.
Conguration options: [Disabled] [Enabled]
5.5.3 WHEAConguration
Aptio Setup Utility - Copyright (C) 2010 American Megatrends, Inc.
Advanced
Enable or disable Windows
Hardware Error Architecture.
WHEA Support [Enabled]
WHEA Support [Enabled]
Allows you to enable or disable the Windows Hardware Error Architecture support.
Conguration options: [Disabled] [Enabled]
ASUS RS100-E7/PI2 5-15
5.5.4 CPUConguration
The items in this menu show the CPU-related information that the BIOS
automatically detects. Some items may not appear if your CPU does not support
the related functions.
Intel Adaptive Thermal Monitor [Enabled]
Allows you to enable or disable the CPU thermal monitor function.
Conguration options: [Disabled] [Enabled]
Hyper-threading [Enabled]
This item appears only when you install a CPU with Hyper-threading support and
allows you to enable or disable the Intel Hyper-Threading Technology function.
When disabled, only one thread per activated core is enabled.
Conguration options: [Enabled] [Disabled]
Active Processor Cores [All]
Allows you to choose the number of CPU cores to activate in each processor
package. Conguration options: [All] [1] [2] [3]
Limit CPUID Maximum [Disabled]
Setting this item to [Enabled] allows legacy operating systems to boot even without
support for CPUs with extended CPUID functions.
Conguration options: [Disabled] [Enabled]
Version 2.01.1204. Copyright (C) 2010 American Megatrends, Inc.
Aptio Setup Utility - Copyright (C) 2010 American Megatrends, Inc.
Advanced
Includes TM1, TM2 and EMTTM
→←: Select Screen
↑↓: Select Item
Enter: Select Item
+/-: Change Opt.
F1: General Help
F2: Previous Values
F5: Optimized Defaults
F10: Save & Exit
ESC: Exit
CPU Conguration
Intel(R) Xeon(R) CPU E31230 @ 3.20GHz
EM64T Supported
Processor Speed 3200 MHz
Processor Stepping 206a7
Microcode Revision d
L1 CACHE 256 KB
L2 CACHE 1024 KB
L3 CACHE 8192 KB
Processor Cores 4
Intel HT Technology Supported
CPU Current Ratio 32
Intel Adaptive Thermal Monitor [Enabled]
Hyper-threading [Enabled]
Active Processor Cores [All]
Limit CPUID Maximum [Disabled]
Execute Disable Bit [Enabled]
Intel Virtualization Technology [Enabled]
Enhanced Intel SpeedStep Technolog [Enabled]
Turbo Mode [Enabled]
CPU C1E [Enabled]
CPU C3 Report [Enabled]
CPU C6 Report [Enabled]
Package C State limit [No Limit]
5-16 Chapter 5: BIOS setup
Execute Disable Bit [Enabled]
Allows you to enable or disable the No-Execution Page Protection Technology.
Setting this item to [Disabled] forces the XD feature ag to always return to zero (0).
Conguration options: [Disabled] [Enabled]
Intel Virtualization Tech [Enabled]
The Intel® Virtualization Technology allows a hardware platform to run multiple
operating systems separately and simultaneously, enabling one system to virtually
function as several systems. Conguration options: [Disabled] [Enabled]
Enhanced Intel SpeedStep Technology [Enabled]
Allows you to enable or disable the Enhanced Intel® SpeedStep Technology (EIST).
Conguration options: [Disabled] [Enabled]
Turbo Mode [Enabled]
This item appears only when you set the
Enhanced Intel SpeedStep Technology
item to [Enabled] and allows you to enable or disable the Intel
®
Turbo Mode
Technology. Conguration options: [Disabled] [Enabled]
CPU C1E [Enabled]
[Enabled] Enables the C1E support function. This item should be enabled in
order to enable the Enhanced Halt State.
[Disabled] Disables this function.
CPU C3 Report [Enabled]
Allows you to disable or enable the CPU C3 report to OS.
CPU C6 Report [Enabled]
Allows you to disable or enable the CPU C6 report to OS.
Package C State limit [No Limit]
Conguration options: [C0] [C1] [C6] [No Limit]
ASUS RS100-E7/PI2 5-17
5.5.5 North Bridge
The North Bridge is built in the CPU.
Aptio Setup Utility - Copyright (C) 2010 American Megatrends, Inc.
Advanced
Low MMIO resources align at
64MB/1024MB
Memory Information
TOTAL Memory 1024 MB
DIMM_A1 0 MB (DDR3 1333)
DIMM_A2 0 MB (DDR3 1333)
DIMM_B1 0 MB (DDR3 1333)
DIMM_B2 1024 MB (DDR3 1333)
Low MMIO Align [64M]
DMI Gen2 [Enabled]
VT-d [Disabled]
Initate Graphic Adapter [PEG/PCI]
Low MMIO Align [64M]
Allows you to select the options for the Low MMIO Align.
Conguration options: [64M] [1024M]
DMI Gen2 [Enabled]
Allows you to enable or disable the DMI Gen2.
Conguration options: [Disabled] [Enabled]
VT-d [Disabled]
Allows you to enable or disable the VT-d.
Conguration options: [Disabled] [Enabled]
Initiate Graphic Adapter [PEG/PCI]
Allows you to decide which graphics controller to use as the primary boot device.
Conguration options: [PCI/PEG] [PEG/PCI]
5.5.6 South Bridge
Aptio Setup Utility - Copyright (C) 2010 American Megatrends, Inc.
Advanced
Enabled/disabled the High
Precision Event Timer.
SB Chipset Conguration
High Precision Event Timer Conguration
High Precision Timer [Enabled]
High Precision Timer [Enabled]
Allows you to enable or disable the High Precision Event Timer.
Conguration options: [Enabled] [Disabled]
5-18 Chapter 5: BIOS setup
Aptio Setup Utility - Copyright (C) 2010 American Megatrends, Inc.
Advanced
(1) IDE Mode. (2) AHCI Mode.
(3) RAID Mode.
SATA Conguration
SATA Mode [IDE Mode]
Serial-ATA Controller 0 [Enhanced]
Serial-ATA Controller 1 [Enhanced]
S.M.A.R.T. Status Check [Enabled]
SATA Port1 ST3160812AS (160.0GB)
SATA Port2 ST3160812AS (160.0GB)
SATA Port3 ASUS CB-521 ATAPI
SATA Port4 Not Present
SATA Port5 Not Present
SATA Port6 Not Present
5.5.7 SATAConguration
While entering Setup, the BIOS automatically detects the presence of SATA
devices. The SATA Port items show
Not Present
if no SATA device is installed to
the corresponding SATA port.
SATA Mode [IDE Mode]
Allows you to set the SATA conguration.
Conguration options: [Disabled] [IDE Mode] [AHCI Mode] [RAID Mode]
• If you want to use the Serial ATA hard disk drives as Parallel ATA physical
storage devices, keep the default setting [IDE Mode].
• If you want the Serial ATA hard disk drives to use the Advanced Host
Controller Interface (AHCI), set this item to [AHCI Mode]. The AHCI allows
the onboard storage driver to enable advanced Serial ATA features that
increases storage performance on random workloads by allowing the drive
to internally optimize the order of commands.
• If you want to create RAID sets with LSI MegaRAID utility, or Intel® Rapid
Storage Technology from the Serial ATA hard disk drives, set this item to
[RAID Mode].
Serial-ATA Controller 0 [Enhanced]
This item appears only when you set the
SATA Mode
item to [IDE Mode]. Set to
[Enhanced] to support two SATA 6.0 Gb/s and two SATA 3.0 Gb/s devices. Set to
[Compatible] when using Windows 98/NT/2000/MS-DOS. Up to four SATA devices
are supported under these operating systems.
Conguration options: [Disabled] [Enhanced] [Compatible]
Serial-ATA Controller 1 [Enhanced]
This item appears only when you set the SATA Mode item to [IDE Mode]. Set
to [Enhanced] to support two SATA 3.0 Gb/s devices. Conguration options:
[Disabled] [Enhanced]
ASUS RS100-E7/PI2 5-19
5.5.9 USBConguration
Aptio Setup Utility - Copyright (C) 2010 American Megatrends, Inc.
Advanced
Enables Legacy USB support.
AUTO option disables legacy
support if no USB devices are
connected. DISABLE option will
keep USB devices available
only for EFI applications.
USB Conguration
USB Devices
1 Mouse, 2 Hubs
Legacy USB Support [Enabled]
EHCI Hand-off [Disabled]
USB hardware delays and time-out:
USB transfer time-out [20 sec]
Device reset time-out [20 sec]
Device power-up delay [Auto]
The
USB Devices
item shows the auto-detected values. If no USB device is
detected, the item shows
None
.
Legacy USB Support [Enabled]
Allows you to enable or disable support for legacy USB devices. Setting to [Auto]
allows the system to detect the presence of USB devices at startup. If detected, the
USB controller legacy mode is enabled. If no USB device is detected, the legacy
USB support is disabled. Conguration options: [Disabled] [Enabled] [Auto]
5.5.8 IntelTXT(LT)Conguration
Aptio Setup Utility - Copyright (C) 2010 American Megatrends, Inc.
Advanced
Enables Legacy USB support.
AUTO option disables legacy
support if no USB devices are
connected. DISABLE option will
keep USB devices available
only for EFI applications.
Intel Trusted Execution Technology Conguration
Intel TXT support only can be enabled/disabled if SMX
is enabled. VT and VT-d support must also be enabled
prior to TXT.
Secure Mode Extensions (SMX) Enabled
Intel TXT(LT) Support [Disabled]
Intel TXT(LT) Support [Disabled]
Allows you to enable or disable the Intel Trusted Execution Technology (TXT)
feature. Conguration options: [Disabled] [Enabled]
The
Intel TXT(LT) Support
item requires a Trusted Platform Module (TPM) to
be installed on the motherboard to enable.
S.M.A.R.T. Status Check [Enabled]
S.M.A.R.T. (Self-Monitoring, Analysis and Reporting Technology) is a monitor
system. When read/write of your hard disk errors occur, this feature allows the hard
disk to report warning messages during the POST.
Conguration options: [Enabled] [Disabled]
5-20 Chapter 5: BIOS setup
EHCI Hand-off [Disabled]
Enables or disables the BIOS EHCI hand-off support.
Conguration options: [Disabled] [Enabled]
USB transfer time-out [20 sec]
Allows you to select the USB transfer time-out value.
Conguration options: [1 sec] [5 sec] [10 sec] [20 sec]
Device reset time-out [20 sec]
Allows you to select the USB device reset time-out value.
Conguration options: [10 sec] [20 sec] [30 sec] [40 sec]
Device power-up delay [Auto]
Conguration options: [Auto] [Manual]
Device power-up delay in seconds [XX]
This item appears only when you set the
Device power-up delay
item to [manual].
Use the <+> and <-> keys to adjust the value. The values range from 1 to 40 with a
one-second interval.
5.5.10 OnboardDevicesConguration
The Onboard Devices Conguration menu items allow you to change the advanced
settings for onboard devices.
Aptio Setup Utility - Copyright (C) 2010 American Megatrends, Inc.
Advanced
Launch Intel PXE OpROM
INTEL W82574L OpROM1 [PXE]
INTEL W82574L OpROM2 [PXE]
Serial Port 1 Conguration
Serial Port 2 Conguration
INTEL W82574L OpROM1/OpROM2 [PXE]
Allows you to select the options for the OptionRom of the Intel LAN controllers.
Conguration options: [Disabled] [PXE] [iSCSI]
SerialPort1/2Conguration
The sub-items in this menu allow you to set the serial port 1/2 conguration.
Serial Port [Enabled]
Allows you to enable or disable the serial port (COM).
Conguration options: [Enabled] [Disabled]
ASUS RS100-E7/PI2 5-21
5.5.11 APM
Aptio Setup Utility - Copyright (C) 2010 American Megatrends, Inc.
Advanced
Specify what state to go to
when power is re-applied after
a power failure (G3 state).
Restrore AC Power Loss [Power Off]
EuP Ready [Disabled]
Power On By PCI [Disabled]
Power On By PCIE [Disabled]
Power On By Ring [Disabled]
Power On By RTC [Disabled]
Change Settings [Auto]
Allows you to select the serial port base address.
Conguration options: [Auto] [IO=3F8h; IRQ=4]
[IO=3F8h: IRQ=3, 4, 5, 6, 7, 9, 10, 11, 12]
[IO=2F8h; IRQ=3, 4, 5, 6, 7, 9, 10, 11, 12]
[IO=3E8h; IRQ=3, 4, 5, 6, 7, 9, 10, 11, 12]
[IO=2E8h; IRQ=3, 4, 5, 6, 7, 9, 10, 11, 12]
Restore AC Power Loss [Power Off]
When set to [Power Off], the system goes into off state after an AC power loss.
When set to [Power On], the system will reboot after an AC power loss. When set
to [Last State], the system goes into either off or on state, whatever the system
state was before the AC power loss.
Conguration options: [Power Off] [Power On] [Last State]
EuP Ready [Disabled]
When set to [Enabled], all other PME options will be switched off.
Conguration options: [Disabled] [Enabled]
Power On By PCI [Disabled]
[Disabled] Disables the PME to wake up from S5 by PCI devices.
[Enabled] Allows you to turn on the system through a PCI LAN or modem
card. This feature requires an ATX power supply that provides at
least 1A on the +5VSB lead.
Power On By PCIE [Disabled]
[Disabled] Disables the PCIE devices to generate a wake event.
[Enabled] Enables the PCIE devices to generate a wake event.
Power On By Ring [Disabled]
[Disabled] Disables Ring to generate a wake event.
[Enabled] Enables Ring to generate a wake event.
5-22 Chapter 5: BIOS setup
Power On By RTC [Disabled]
[Disabled] Disables RTC to generate a wake event.
[Enabled] When set to [Enabled], the items RTC Alarm Date (Days) and
Hour/Minute/Second will become user-congurable with set
values.
5.5.12 Serial Port Console Redirection
Aptio Setup Utility - Copyright (C) 2010 American Megatrends, Inc.
Advanced
Redirection After BIOS POST [Disabled]
COM1
Console Redirection [Disabled]
Console Redirection Settings
COM2
Console Redirection [Enabled]
Console Redirection Settings
Redirection After BIOS POST [Disabled]
Enables or disables the redirection after BIOS POST feature.
Conguration options: [Disabled] [Enabled]
COM1
Console Redirection [Disabled]
Enables or disables the console redirection feature.
Conguration options: [Disabled] [Enabled]
Console Redirection Settings
This item becomes congurable only when you enable the
Console Redirection
item. The settings specify how the host computer and the remote computer (which
the user is using) will exchange data. Both computers should have the same or
compatible settings.
Terminal Type [VT-UTF8]
Allows you to set the terminal type.
[VT100] ASCII char set.
[VT100+] Extends VT100 to support color, function keys, et.
[VT-UTF8] Uses UTF8 encoding to map Unicode chars onto 1 or more bytes
[ANSI] Extended ASCII char set
Bits per second [57600]
Selects serial port transmission speed. The speed must be matched on the
other side. Long or noisy lines may require lower speeds.
Conguration options: [9600] [19200] [38400] [57600] [115200]
ASUS RS100-E7/PI2 5-23
Data Bits [8]
Conguration options: [7] [8]
Parity [None]
A parity bit can be sent with the data bits to detect some transmission errors.
[Mark] and [Space] parity do not allow for error detection.
[Even] parity bit is 0 if the num of 1’s in the data bits is even
[Odd] parity bit is 0 if num of 1’s in the data bits is odd
[Mark] parity bit is always 1
[Space] parity bit is always 0
Stop Bits [1]
Stop bits indicate the end of a serial data packet. (A start bit indicates the
beginning.) The standard setting is 1 stop bit. Communication with slow
devices may require more than 1 stop bit. Conguration options: [1] [2]
Flow Control [Hardware RTS/CTS]
Flow control can prevent data loss from buffer overow. When sending data,
if the receiving buffers are full, a “stop” signal can be sent to stop the data
ow. Once the buffers are empty, a “start” signal can be sent to re-start the
ow. Hardware ow control uses two wires to send start/stop signals.
Conguration options: [None] [Hardware RTS/CTS]
Recorder Mode [Disabled]
With this mode enabled only text will be sent. This is to capture Terminal data.
Conguration options: [Disabled] [Enabled]
Legacy OS Redirction Resolution [80x24]
Congures the number of rows and columns supported on legacy OS.
Conguration options: [80x24] [80x25]
COM2
Console Redirection [Enabled]
Enables or disables the console redirection feature.
Conguration options: [Disabled] [Enabled]
Console Redirection Settings
Please refer to the description of the
Console Redirection Settings
item under
COM1 for details.
5-24 Chapter 5: BIOS setup
5.6 Monitor menu
The Monitor menu displays the system temperature/power status, and allows you
to change the fan settings.
Aptio Setup Utility - Copyright (C) 2010 American Megatrends, Inc.
Main Event Logs Advanced Monitor Boot Tool Exit
CPU Temperature(PECI) [ +35ºC/ +94ºF]
MB Temperature [ +35ºC/ +94ºF]
TR1 Temperature [ N/A ]
CPU FAN1 Speed [ 1305 RPM]
FRNT FAN1 Speed [ N/A ]
FRNT FAN2 Speed [ N/A ]
FRNT FAN3 Speed [ N/A ]
REAR FAN1 Speed [ N/A ]
FAN Speed Control [Generic Mode]
VCORE1 [ +1.200 V ]
+3.3V [ +3.360 V ]
+5V [ +5.160 V ]
+12V [ +12.384 V ]
VBAT [ +3.408 V ]
+3VSB [ +3.422 V ]
+1.5V [ +1.496 V ]
CPU/MB/TR1 Temperature [xxx�C/xxx�F][xxx�C/xxx�F]
The onboard hardware monitor automatically detects and displays the CPU and
motherboard component temperatures. Select Ignore if you do not wish to display
the detected temperatures.
CPU FAN1 Speed; FRNT FAN1–3 Speed; REAR FAN1 Speed
[xxxx RPM] or [Ignore] / [N/A]
The onboard hardware monitor automatically detects and displays the speed of
CPU fans, front fans, and rear fan in rotations per minute (RPM). If the fan is not
connected to the motherboard, the eld shows
N/A
.
Fan Speed Control [Generic Mode]
Allows you to congure the ASUS Smart Fan feature that smartly adjusts the fan
speeds for more efcient system operation.
Conguration options: [Full Speed Mode] [High Density Mode] [Generic Mode]
[Whisper Mode]
VCORE1 Voltage, 3.3V Voltage, +5V Voltage, +12V Voltage,
VBAT Voltage, +3VSB Voltage, +1.5V ICHVoltage
The onboard hardware monitor automatically detects the voltage output through
the onboard voltage regulators. Select
Ignore
if you do not want to detect this item.
ASUS RS100-E7/PI2 5-25
5.7 Boot menu
The Boot menu items allow you to change the system boot options.
Aptio Setup Utility - Copyright (C) 2010 American Megatrends, Inc.
Main Event Logs Advanced Monitor Boot Tool Exit
Number of seconds to wait for
setup activation key.
65535(0xFFFF) means indenite
waiting.
Setup Prompt Timeout 5
Bootup NumLock State [On]
Full Screen Logo [Enabled]
Option ROM Messages [Force BIOS]
Interrupt 19 Capture [Enabled]
EFI Boot [Disabled]
Boot Device Seeking [Endless PXE]
Boot Option Priorities
Boot Option #1 [IBA GE Slot 0200 v...]
Boot Option #2 [Intel Volume0]
Boot Override
IBA GE Slot 0200 v1353
IBA GE Slot 0300 v1353
Network Device BBS Priorities
CD/DVD ROM Drive BBS Priorities
Hard Drive BBS Priorities
Setup Prompt Timeout [xx]
Use the <+> and <-> keys to adjust the number of seconds to wait for setup
activation key.
Bootup NumLock State [On]
Allows you to select the power-on state for the NumLock.
Conguration options: [Off] [On]
Full Screen Logo [Enabled]
Allows you to enable or disable the full screen logo display feature.
Conguration options: [Disabled] [Enabled]
Set this item to [Enabled] to use the ASUS MyLogo2™ feature.
Option ROM Messages [Force BIOS]
Allows you to set the display mode for Options ROM.
Conguration options: [Force BIOS] [Keep Current]
Interrupt 19 Capture [Enabled]
Allows Option ROMs to trap interrupt 19.
Conguration options: [Disabled] [Enabled]
EFI Boot [Disabled]
Enables or disables EFI Boot.
Conguration options: [Disabled] [Enabled]
5-26 Chapter 5: BIOS setup
Boot Device Seeking [Endless PXE]
[Endless PXE] Continuous seek remote boot image until boot image found or user
abort (press Ctrl+Alt+Del).
[Normal] Seek remote boot image once then stop.
Boot Option Priorities
These items specify the boot device priority sequence from the available devices.
The number of device items that appears on the screen depends on the number of
devices installed in the system.
• To select the boot device during system startup, press <F8> when ASUS
Logo appears.
• To access Windows OS in Safe Mode, do any of the following:
- Press <F5> when ASUS Logo appears.
- Press <F8> after POST.
Boot Override
These items displays the available devices. The number of device items that
appears on the screen depends on the number of devices installed in the system.
Click an item to start booting from the selected device.
Network Device BBS Priorities
Set the booting order of network devices.
Boot Option #1/#2 [IBA GE Slot 0200 v1324]
Conguration options: [IBA GE Slot 0200 v1353] [IBA GE Slot 0300 v1353]
[Disabled]
CD/DVD ROM Drives BBS Priorities
Hard Drive BBS Priorities
These two items appear only when you connect SATA ODD or hard drive to the
SATA ports and allow you to set the booting order of the SATA devices.
ASUS RS100-E7/PI2 5-27
5.8 Tool menu
The Tool menu items allow you to congure options for special functions. Select an
item then press <Enter> to display the submenu.
Aptio Setup Utility - Copyright (C) 2010 American Megatrends, Inc.
Main Event Logs Advanced Monitor Boot Tool Exit
Be used to update BIOS
ASUS EZ Flash Utility
ASUS EZ Flash Utility
Allows you to run ASUS EZ Flash BIOS ROM Utility when you press <Enter>.
Check section 5.1.2 ASUS EZ Flash Utility for details.
5.9 Exit menu
The Exit menu items allow you to save or discard your changes to the BIOS items.
Pressing <Esc> does not immediately exit this menu. Select one of the options
from this menu or <F10> from the legend bar to exit.
Save Changes & Reset
Once you are nished making your selections, choose this option from the Exit
menu to ensure the values you selected are saved. When you select this option or
if you press <F10>, a conrmation window appears. Select
Yes
to save changes
and exit.
Discard Changes & Exit
This option allows you to exit the Setup program without saving your changes.
When you select this option or if you press <Esc>, a conrmation window appears.
Select
Yes
to discard changes and exit.
LaunchEFIShellfromlesystemdevice
This option allows you to attempt to launch the EFI Shell application (shellx64.e)
from one of the available lesystem devices.
Aptio Setup Utility - Copyright (C) 2010 American Megatrends, Inc.
Main Event Logs Advanced Monitor Boot Tool Exit
Reset the system after saving
the changes.
Save Changes & Reset
Discard Changes & Exit
Launch EFI Shell from lesystem device
5-28 Chapter 5: BIOS setup
This chapter provides instructions for
setting up, creating and conguring RAID
sets using the available utilities.
Chapter 6
RAIDconguration
6-2 Chapter 6: RAID conguration
6.1 Setting up RAID
The motherboard comes with the Intel® C204 controller that supports the following
SATA RAID solutions:
•
Intel Rapid Storage Technology
with RAID 0, RAID 1, RAID 10, and RAID 5
support (for Windows OS only).
6.1.1 RAIDdenitions
RAID 0
(Data striping)
optimizes two identical hard disk drives to read and write
data in parallel, interleaved stacks. Two hard disks perform the same work as a
single drive but at a sustained data transfer rate, double that of a single disk alone,
thus improving data access and storage. Use of two new identical hard disk drives
is required for this setup.
RAID 1
(Data mirroring)
copies and maintains an identical image of data from one
drive to a second drive. If one drive fails, the disk array management software
directs all applications to the surviving drive as it contains a complete copy of
the data in the other drive. This RAID conguration provides data protection and
increases fault tolerance to the entire system. Use two new drives or use an
existing drive and a new drive for this setup. The new drive must be of the same
size or larger than the existing drive.
RAID 10
is data striping and data mirroring combined without parity (redundancy
data) having to be calculated and written. With the RAID 10 conguration you get
all the benets of both RAID 0 and RAID 1 congurations. Use four new hard disk
drives or use an existing drive and three new drives for this setup.
RAID 5
stripes both data and parity information across three or more hard disk
drives. Among the advantages of RAID 5 conguration include better HDD
performance, fault tolerance, and higher storage capacity. The RAID 5 conguration
is best suited for transaction processing, relational database applications,
enterprise resource planning, and other business systems. Use a minimum of three
identical hard disk drives for this setup.
• If you want to boot the system from a hard disk drive included in a created
RAID set, copy rst the RAID driver from the support DVD to a oppy disk
before you install an operating system to the selected hard disk drive.
• Please refer to chapter 2 for how to select the RAID conguration utility.
Move the jumper to choose between LSI MegaRAID and Intel® Rapid RAID.
ASUS RS100-E7/PI2 6-3
6.1.3 Setting the RAID item in BIOS
You must set the RAID item in the BIOS Setup before you can create a RAID set
from SATA hard disk drives attached to the SATA connectors supported by
Intel® C204 chipset. To do this:
1. Enter the BIOS Setup during POST.
2. Go to the
Advanced
Menu >
SATAConguration
, then press <Enter>.
3. Set
SATA Mode
to [RAID Mode]
4. Press <F10> to save your changes and exit the BIOS Setup.
Refer to Chapter 4 for details on entering and navigating through the BIOS
Setup.
6.1.4 RAIDcongurationutilities
Depending on the RAID connectors that you use, you can create a RAID set using
the utilities embedded in each RAID controller. For example, use the
Intel® Rapid
Storage Technology
if you installed Serial ATA hard disk drives on the Serial ATA
connectors supported by the Intel® C204 chipset.
Refer to the succeeding section for details on how to use the RAID conguration
utility.
6.1.2 Installing hard disk drives
The motherboard supports Serial ATA for RAID set conguration. For optimal
performance, install identical drives of the same model and capacity when creating
a disk array.
To install the SATA hard disks for RAID conguration:
1. Install the SATA hard disks into the drive bays following the instructions in the
system user guide.
2. Connect a SATA signal cable to the signal connector at the back of each drive
and to the SATA connector on the motherboard.
3. Connect a SATA power cable to the power connector on each drive.
6-4 Chapter 6: RAID conguration
6.2 Intel® Rapid Storage Technology
Option ROM Utility
The Intel® Rapid Storage Technology Option ROM utility allows you to create RAID 0,
RAID 1, RAID 10 (RAID 1+0), and RAID 5 set(s) from Serial ATA hard disk drives
that are connected to the Serial ATA connectors supported by the Southbridge.
To enter the Intel® Rapid Storage Technology option ROM utility:
1. Install all the Serial ATA hard disk drives.
2. Turn on the system.
3. During POST, press <Ctrl+I> to display the utility main menu.
The navigation keys at the bottom of the screen allow you to move through
the menus and select the menu options.
The RAID BIOS setup screens shown in this section are for reference only and
may not exactly match the items on your screen.
Intel(R) Rapid Storage Technology - Option ROM - 10.1.0.1008
Copyright(C) 2003-10 Intel Corporation. All Rights Reserved.
[ MAIN MENU ]
1. Create RAID Volume 3. Reset Disks to Non-RAID
2. Delete RAID Volume 4. Recovery Volume Options
5. Exit
[ DISK/VOLUME INFORMATION ]
RAID Volumes: * = Data is Encrypted
None dened.
Physical Devices:
Port Drive Model Serial # Size Type/Status(Vol ID)
0 ST3160812AS 9LS0HJA4 149.0GB Non-RAID Disk
1 ST3160812AS 9LS0F4HL 149.0GB Non-RAID Disk
2 ST3160812AS 3LS0JYL8 149.0GB Non-RAID Disk
3 ST3160812AS 9LS0BJ5H 149.0GB Non-RAID Disk
[↑↓]-Select [ESC]-Exit [ENTER]-Select Menu
ASUS RS100-E7/PI2 6-5
6.2.1 Creating a RAID set
To create a RAID set:
1. From the utility main menu, select
1. Create RAID Volume
and press
<Enter>. The following screen appears.
2. Enter a name for the RAID set and press <Enter>.
3. When the
RAID Level
item is selected, press the up/down arrow keys to
select a RAID level to create, and then press <Enter>.
4. When the
Disks
item is selected, press <Enter> to select the hard disk drives
you want to include in the RAID set. The
SELECT DISKS
screen appears.
5. Use the up/down arrow keys to select a drive, and then press <Space>
to select. A small triangle marks the selected drive. Press <Enter> after
completing your selection.
Intel(R) Rapid Storage Technology - Option ROM - 10.1.0.1008
Copyright(C) 2003-10 Intel Corporation. All Rights Reserved.
[ CREATE VOLUME MENU ]
[ HELP ]
Enter a unique volume name that has no special characters and is
16 characters or less.
[↑↓]Change [TAB]-Next [ESC]-Previous Menu [ENTER]-Select
Name: Volume0
RAID Level: RAID0(Stripe)
Disks: Select Disks
Strip Size: 128KB
Capacity: 0.0 GB
Sync: N/A
Create Volume
[ SELECT DISKS ]
Port Drive Model Serial # Size Status
0 ST3160812AS 9LS0HJA4 149.0GB Non-RAID Disk
1 ST3160812AS 9LS0F4HL 149.0GB Non-RAID Disk
2 ST3160812AS 3LS0JYL8 149.0GB Non-RAID Disk
3 ST3160812AS 9LS0BJ5H 149.0GB Non-RAID Disk
Select 2 to 6 disks to use in creating the volume.
[↑↓]-Prev/Next [SPACE]-SelectDisk [ENTER]-Done
6-6 Chapter 6: RAID conguration
6. Use the up/down arrow keys to select the stripe size for the RAID array (for
RAID 0, 10 and 5 only), and then press <Enter>. The available stripe size
values range from 4 KB to 128 KB. The following are typical values:
RAID 0: 128KB
RAID 10: 64KB
RAID 5: 64KB
We recommend a lower stripe size for server systems, and a higher stripe size
for multimedia computer systems used mainly for audio and video editing.
7. When the
Capacity
item is selected, enter the RAID volume capacity that you
want and press <Enter>. The default value indicates the maximum allowed
capacity.
8. When the
Create Volume
item is selected, press <Enter>. The following
warning message appears.
WARNING: ALL DATA ON SELECTED DISKS WILL BE LOST.
Are you sure you want to create this volume? (Y/N):
9. Press <Y> to create the RAID volume and return to the main menu, or <N> to
go back to the
CREATE VOLUME
menu.
6.2.2 Creating a Recovery set
To create a recovery set:
1. From the utility main menu, select
1. Create RAID Volume
and press
<Enter>. The following screen appears.
Intel(R) Rapid Storage Technology - Option ROM - 10.1.0.1008
Copyright(C) 2003-10 Intel Corporation. All Rights Reserved.
[ CREATE VOLUME MENU ]
[ HELP ]
Enter a unique volume name that has no special characters and is
16 characters or less.
[↑↓]Change [TAB]-Next [ESC]-Previous Menu [ENTER]-Select
Name: Volume0
RAID Level: RAID0(Stripe)
Disks: Select Disks
Strip Size: 128KB
Capacity: 0.0 GB
Sync: N/A
Create Volume
ASUS RS100-E7/PI2 6-7
2. Enter a name for the recovery set and press <Enter>.
3. When the
RAID Level
item is selected, press the up/down arrow keys to
select
Recovery
, and then press <Enter>.
4. When the
Disks
item is selected, press <Enter> to select the hard disk drives
you want to include in the recovery set. The
SELECT DISKS
screen appears.
5. Use the up/down arrow keys to select a drive, press <TAB> to select a Master
disk, and then press <SPACE> to select a Recovery disk. A small triangle
marks the selected drive. Press <Enter> after completing your selection.
6. When the
Sync
item is selected, use the up/down arrow keys to select a sync
option that you want and press <Enter>.
7. When the
Create Volume
item is selected, press <Enter>. The following
warning message appears.
[ SELECT DISKS ]
Port Drive Model Serial # Size Status
0 ST3160812AS 9LS0HJA4 149.0GB Non-RAID Disk
1 ST3160812AS 9LS0F4HL 149.0GB Non-RAID Disk
2 ST3160812AS 3LS0JYL8 149.0GB Non-RAID Disk
3 ST3160812AS 9LS0BJ5H 149.0GB Non-RAID Disk
Select 1 Master and 1 Recovery disk to create volume.
[↑↓]-Prev/Next [TAB]-(M)aster [SPACE]-(R)ecovery [ENTER]-Done
WARNING: ALL DATA ON SELECTED DISKS WILL BE LOST.
Are you sure you want to create this volume? (Y/N):
8. Press <Y> to create the recovery set and return to the main menu, or <N> to
go back to the
CREATE VOLUME
menu.
If a recovery set is created, you cannot add more RAID sets even when you
have more non-RAID disks installed in your system.
6-8 Chapter 6: RAID conguration
6.2.3 Deleting a RAID set
Take caution when deleting a RAID set. You will lose all data on the hard disk
drives when you delete a RAID set.
To delete a RAID set:
1. From the utility main menu, select
2. Delete RAID Volume
and press
<Enter>. The following screen appears.
2. Use the up/down arrow keys to select the RAID set you want to delete, and
then press <Del>. The following warning message appears.
3. Press <Y> to delete the RAID set and return to the utility main menu, or press
<N> to return to the
DELETE VOLUME
menu.
ALL DATA IN THE VOLUME WILL BE LOST!
(This does not apply to Recovery volumes)
Are you sure you want to delete volume “Volume0”? (Y/N):
[ DELETE VOLUME VERIFICATION ]
Intel(R) Rapid Storage Technology - Option ROM - 10.1.0.1008
Copyright(C) 2003-10 Intel Corporation. All Rights Reserved.
[ DELETE VOLUME MENU ]
[ HELP ]
Deleting a volume will reset the disks to non-RAID.
WARNING: ALL DISK DATA WILL BE DELETED.
(This does not apply to Recovery volumes)
[↑↓]-Select [ESC]-Previous Menu [DEL]-Delete Volume
Name Level Drives Capacity Status Bootable
Volume0 RAID0(Stripe) 2 298.0GB Normal Yes
ASUS RS100-E7/PI2 6-9
6.2.4 Resetting disks to Non-RAID
Take caution before you reset a RAID volume hard disk drive to non-RAID.
Resetting a RAID volume hard disk drive deletes all internal RAID structure on
the drive.
To reset a RAID set hard disk drive:
1. From the utility main menu, select
3. Reset Disks to Non-RAID
and press
<Enter>. The following screen appears.
2. Use the up/down arrow keys to select the RAID set drive(s) you want to reset,
and then press <Space> to select.
3. Press <Enter> to reset the RAID set drive(s). A conrmation message
appears.
4. Press <Y> to reset the drive(s) or press <N> to return to the utility main
menu.
Resetting RAID disk will remove its RAID structures
and revert it to a non-RAID disk.
WARNING: Resetting a disk causes all data on the disk to be lost.
(This does not apply to Recovery volumes)
Port Drive Model Serial # Size Status
0 ST3160812AS 9LS0HJA4 149.0GB Member Disk
1 ST3160812AS 9LS0F4HL 149.0GB Member Disk
Select the disks that should be reset.
[↑↓]-Previous/Next [SPACE]-Selects [ENTER]-Selection Complete
[ RESET RAID DATA ]
6-10 Chapter 6: RAID conguration
6.2.5 Recovery Volume Options
If you have created a recovery set, you can congure more recovery set options
following the descriptions in the section.
See section
6.2.2 Creating a Recovery set
to create a recovery set before
continue.
To congure a recovery set:
1. From the utility main menu, select
4. Recovery Volume Options
and press
<Enter>. The following screen appears.
2. Use the up/down arrow keys to select the option you want, and then press
<ENTER>. The
SELECT RECOVERY VOLUME
screen appears.
Intel(R) Rapid Storage Technology - Option ROM - 10.1.0.1008
Copyright(C) 2003-10 Intel Corporation. All Rights Reserved.
[ RECOVERY VOLUME OPTIONS ]
[ HELP ]
Enable Only Recovery Disk - enables recovery disk if available and
disables master disk.
Enable Only Master Disk - enables master disk if available and
disables recovery disk.
Actions will result in change from Continuous Update mode to On-Request.
[↑↓]-Select [ESC]-Previous Menu [ENTER]-Select
1. Enable Only Recovery Disk
2. Enable Only Master Disk
[ SELECT RECOVERY VOLUME ]
Name Level Capacity Status Bootable
Volume0 Recovery(Cont.) 149.0GB Normal Yes
Select a Recovery volume to do the operation.
[↑↓]-Up/Down [SPACE]-Selects [ENTER]-Done
3. Use the up/down arrow keys to select a drive, and then press <Space>
to select. A small triangle marks the selected drive. Press <Enter> after
completing your selection and return to the utility main menu.
Loading...
