ASUS D509DA-BQ693 User Manual

Part No 90NB0P52-M12980

Model Name D509DA-BQ693

EAN Code 4718017713238

UPC Code 192876713235

Operating System Without OS

LCD cover-material Plastic

LCD cover-color Slate Grey

Top case-material Plastic

Top case-color Slate Grey

Bottom case-material Plastic

Bottom case-color Slate Grey

Military grade N/A

Panel Size 15.6-inch

Backlit LED Backlit

OLED LCD

Brightness 250nits

Resolution FHD (1920 x 1080) 16:9

Glare Anti-glare display

Color gamut NTSC: 45%

Touch Panel N/A

Screen-to-body ratio 83%

Pantone N/A

IPS-level IPS-level Panel

Processor AMD Ryzen™ 7 3700U Processor 2.3 GHz (2M Cache, up to 4.0 GHz)

Chipset N/A

Discrete/Share Share

Intergrated GPU Radeon™ RX Vega 10 Graphics

VRAM N/A

Expansion Slot(includes used) 1x DDR4 SO-DIMM slot

1x M.2 2280 PCIe 3.0x2

1x STD 2.5” SATA HDD

Total System Memory 4GB DDR4 on board + 4GB DDR4 SO-DIMM

On board memory 4GB DDR4 on board

DIMM Memory 4GB DDR4 SO-DIMM

Storage 512GB M.2 NVMe™ PCIe® 3.0 SSD

N/A

Front-facing camera VGA camera//Without privacy shutter

Rear-facing camera N/A

Page: 1 / 3

World-facing camera N/A

Wireless Wi-Fi 5(802.11ac)+Bluetooth 4.1 (Dual band) 1*1

3G/4G N/A

NumberPad N/A

ScreenPad™ N/A

FingerPrint N/A

I/O ports

1x 3.5mm Combo Audio Jack
1x HDMI 1.4//2x USB 2.0 Type-A
1x USB 3.2 Gen 1 Type-A

Audio Built-in microphone

Built-in speaker
SonicMaster (Close)

Voice control with Cortana support

AC Adapter ø4.0, 45W AC Adapter, Output: 19V DC, 2.37A, 45W, Input: 100~240V AC 50/60Hz universal

Battery 32WHrs, 2S1P, 2-cell Li-ion

Replaceable Battery No

Keyboard type Backlit Chiclet Keyboard

Dimension (WxHxD) 36.00 x 23.50 x 2.29 ~ 2.29 cm

Weight (with Battery) 1.90 kg

Weight (without Battery) 1.70 kg

Security

McAfee LiveSafe™ 30-day trial

Security Lock
Trusted Platform Module (Firmware TPM)

MyASUS feature

Tru2Life (Intel Platform models)
Keyboard hotkeys (All models)
Link to MyASUS (All models, Bluetooth needed)

Built-in Apps MyASUS (for all)

Included in the Box N/A
