ASUS CM6630 User Manual

ASUS Essentio Desktop PC

CM6630

User Manual

E6450

First Edition
March 2011

Copyright © 2011 ASUSTeK Computer Inc. All Rights Reserved.

No part of this manual, including the products and software described in it, may be reproduced,
transmitted, transcribed, stored in a retrieval system, or translated into any language in any form or by any
means, except documentation kept by the purchaser for backup purposes, without the express written
permission of ASUSTeK Computer Inc. (“ASUS”).

Product warranty or service will not be extended if: (1) the product is repaired, modied or altered, unless
such repair, modication of alteration is authorized in writing by ASUS; or (2) the serial number of the

product is defaced or missing.

ASUS PROVIDES THIS MANUAL “AS IS” WITHOUT WARRANTY OF ANY KIND, EITHER EXPRESS
OR IMPLIED, INCLUDING BUT NOT LIMITED TO THE IMPLIED WARRANTIES OR CONDITIONS OF
MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. IN NO EVENT SHALL ASUS, ITS
DIRECTORS, OFFICERS, EMPLOYEES OR AGENTS BE LIABLE FOR ANY INDIRECT, SPECIAL,
INCIDENTAL, OR CONSEQUENTIAL DAMAGES (INCLUDING DAMAGES FOR LOSS OF PROFITS,
LOSS OF BUSINESS, LOSS OF USE OR DATA, INTERRUPTION OF BUSINESS AND THE LIKE),
EVEN IF ASUS HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES ARISING FROM ANY
DEFECT OR ERROR IN THIS MANUAL OR PRODUCT.

SPECIFICATIONS AND INFORMATION CONTAINED IN THIS MANUAL ARE FURNISHED FOR
INFORMATIONAL USE ONLY, AND ARE SUBJECT TO CHANGE AT ANY TIME WITHOUT NOTICE,
AND SHOULD NOT BE CONSTRUED AS A COMMITMENT BY ASUS. ASUS ASSUMES NO
RESPONSIBILITY OR LIABILITY FOR ANY ERRORS OR INACCURACIES THAT MAY APPEAR IN THIS
MANUAL, INCLUDING THE PRODUCTS AND SOFTWARE DESCRIBED IN IT.

Products and corporate names appearing in this manual may or may not be registered trademarks or

copyrights of their respective companies, and are used only for identication or explanation and to the
owners’ benet, without intent to infringe.

2

Contents

Notices .......................................................................................................... 5

Safety information .......................................................................................... 7

Conventions used in this guide ...................................................................... 8

Where to nd more information ..................................................................... 8

Package contents .......................................................................................... 9

Chapter 1: Getting started

Welcome! ......................................................................................................11

Getting to know your computer .....................................................................11

Setting up your computer ............................................................................. 15

Turning your computer ON/OFF .................................................................. 18

Chapter 2: Using Windows® 7

Starting for the rst time ............................................................................... 19

Using Windows® 7 desktop .......................................................................... 20

Managing your les and folders ................................................................... 22

Restoring your system settings .................................................................... 24

Protecting your computer ............................................................................. 25

Getting Windows® Help and Support ........................................................... 26

Chapter 3: Connecting devices to your computer

Connecting a USB storage device ............................................................... 27

Connecting microphone and speakers ........................................................ 28

Connecting multiple external displays ......................................................... 31

Connecting an HDTV ................................................................................... 33

Chapter 4: Using your computer

Proper posture when using your Desktop PC.............................................. 35

Using the memory card reader .................................................................... 36

Using the optical drive ................................................................................. 37

Using the multimedia keyboard (on selected models only) ......................... 38

Chapter 5: Connecting to the Internet

Wired connection ......................................................................................... 43

Wireless connection (on selected models only) ........................................... 45

3

Contents

Chapter 6: Using the utilities

ASUS AI Suite II ........................................................................................... 49

ASUS AI Manager ........................................................................................ 55

Nero 9 ........................................................................................................

Recovering your system .............................................................................. 59

Chapter 7: Troubleshooting

Troubleshooting ........................................................................................... 61

ASUS contact information ............................................................................ 68

58

4

Notices

REACH

Complying with the REACH (Registration, Evaluation, Authorisation, and Restriction of
Chemicals) regulatory framework, we published the chemical substances in our products at
ASUS REACH website at http://csr.asus.com/english/REACH.htm.

Federal Communications Commission Statement

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions:

• This device may not cause harmful interference; and

• This device must accept any interference received including interference that may cause
undesired operation.

This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed
and used in accordance with manufacturer’s instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not occur
in a particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the user
is encouraged to try to correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment to an outlet on a circuit different from that to which the receiver is
connected.

• Consult the dealer or an experienced radio/TV technician for help.

The use of shielded cables for connection of the monitor to the graphics card is required

to assure compliance with FCC regulations. Changes or modications to this unit not

expressly approved by the party responsible for compliance could void the user’s authority
to operate this equipment.

5

RF exposure warning

This equipment must be installed and operated in accordance with provided instructions and
the antenna(s) used for this transmitter must be installed to provide a separation distance of
at least 20 cm from all persons and must not be co-located or operating in conjunction with
any other antenna or transmitter. End-users and installers must be provide with antenna
installation instructions and transmitter operating conditions for satisfying RF exposure
compliance.

Canadian Department of Communications Statement

This digital apparatus does not exceed the Class B limits for radio noise emissions from
digital apparatus set out in the Radio Interference Regulations of the Canadian Department of
Communications.

This class B digital apparatus complies with Canadian ICES-003.

Macrovision Corporation Product Notice

This product incorporates copyright protection technology that is protected by method
claims of certain U.S. patents and other intellectual property rights owned by Macrovision
Corporation and other rights owners. Use of this copyright protection technology must be

authorized by Macrovision Corporation, and is intended for home and other limited viewing

uses only unless otherwise authorized by Macrovision Corporation. Reverse engineering
or disassembly is prohibited.

CAUTION: Danger of explosion if battery is incorrectly replaced. Replace only with the
same or equivalent type recommended by the manufacturer. Dispose of used batteries
according to the manufacturer’s instructions.

Lithium-Ion Battery Warning

ASUS Recycling/Takeback Services

ASUS recycling and takeback programs come from our commitment to the highest standards
for protecting our environment. We believe in providing solutions for you to be able to
responsibly recycle our products, batteries, other components as well as the packaging
materials. Please go to http://csr.asus.com/english/Takeback.htm for the detailed recycling
information in different regions.

6

Safety information

Disconnect the AC power and peripherals before cleaning. Wipe the Desktop PC using a
clean cellulose sponge or chamois cloth dampened with solution of nonabrasive detergent
and a few drops of warm water then remove any extra moisture with a dry cloth.

• DO NOT place on uneven or unstable work surfaces. Seek servicing if the casing has
been damaged.

•

DO NOT expose to dirty or dusty environments. DO NOT operate during a gas leak.

•

DO NOT place or drop objects on top and do not shove any foreign objects into the
Desktop PC.

•

DO NOT expose to strong magnetic or electrical elds.

•

DO NOT expose to or use near liquids, rain, or moisture. DO NOT use the modem during
electrical storms.

• Battery safety warning:
contacts. DO NOT disassemble the battery.

• Use this product in environments with ambient temperatures between 0˚C (32F)and
35˚C (95F).

•

DO NOT cover the vents on the Desktop PC to prevent the system from getting
overheated.

•

DO NOT use damaged power cords, accessories, or other peripherals.

•

To prevent electrical shock hazard, disconnect the power cable from the electrical outlet

before relocating the system.

•

Seek professional assistance before using an adapter or extension cord. These devices
could interrupt the grounding circuit.

•

Ensure that your power supply is set to the correct voltage in your area. If you are not
sure about the voltage of the electrical outlet you are using, contact your local power
company.

•

If the power supply is broken, do not try to x it by yourself. Contact a qualied service

technician or your retailer.

DO NOT throw the battery in re. DO NOT short circuit the

7

Conventions used in this guide

To ensure that you perform certain tasks properly, take note of the following symbols used
throughout this manual.

DANGER/WARNING: Information to prevent injury to yourself

when trying to complete a task.

CAUTION: Information to prevent damage to the components

when trying to complete a task.

IMPORTANT: Instructions that you MUST follow to complete a

task.

NOTE: Tips and additional information to help you complete a

task.

Where to nd more information

Refer to the following sources for additional information and for product and software
updates.

ASUS websites

The ASUS website provides updated information on ASUS hardware and software

products. Refer to the ASUS website www.asus.com.

ASUS Local Technical Support

Visit ASUS website at

local Technical Support Engineer.

http://support.asus.com/contact for the contact information of

8

In

stalla

tion

Guide

Package contents

ASUS Essentio Desktop PC Keyboard x1 Mouse x1

Power cord x1 Nero 9 burning software

Installation Guide x1

DVD x1 (optional)

Warranty card x1 Support DVD x1 (optional) Recovery DVD x1 (optional)

Antenna (optional) x2

• If any of the above items is damaged or missing, contact your retailer.

• The illustrated items above are for reference only. Actual product specications may vary

with different models.

9

10

Chapter 1

Getting started

Welcome!

Thank you for purchasing the ASUS Essentio CM6630 Desktop PC!
The ASUS Essentio CM6630 Desktop PC provides cutting-edge performance,

uncompromised reliability, and user-centric utilities. All these values are encapsulated in a
stunningly futuristic and stylish system casing.

Read the ASUS Warranty Card before setting up your ASUS Desktop PC.

Getting to know your computer

Illustrations are for reference only. The ports and their locations, and the chassis color vary
with different models.

Front panel

2

10

1

9

8

7

3

4

6

ASUS CM6630 11

5

ENGLISH

ENGLISH

1. USB 2.0 ports.USB 2.0 ports. These Universal Serial Bus 2.0 (USB 2.0) ports connect to USB 2.0

devices such as a mouse, printer, scanner, camera, PDA, and others.

2. Microphone port (pink).Microphone port (pink).

3. Headphone port (lime).Headphone port (lime).

4. Power button.

Power button. Press this button to turn on your computer.

5. Optical disk drive eject button.Optical disk drive eject button.

6. Optical disk drive bay (empty).Optical disk drive bay (empty).

this bay.

7. Optical disk drive bay.

Optical disk drive bay. There is an optical disk drive in this bay.

8. Memory Stick™ / Memory Stick Pro™ card slot.Memory Stick™ / Memory Stick Pro™ card slot.

Stick Pro™ card into this slot.

9. Secure Digital™ / MultiMediaCard slot.Secure Digital™ / MultiMediaCard slot.

card into this slot.

10. CompactFlash

CompactFlash® / Microdrive™ card slot. Insert a CompactFlash® / Microdrive™ card

into this slot.

This port connects to a microphone.

This port connects to a headphone or speaker.

Press this button to eject the optical disk drive tray.

Allows you to install an additional optical disk drive in

Insert a Memory Stick™ / Memory

Insert a Secure Digital™ / MultiMediaCard

Rear panel

1

2

19

3

4

5

3

6

7 8

12

10

10

9

12 Chapter 1: Getting started

18

17

16

15

14

13

ENGLISH

1. Power connector.Power connector. Plug the power cord to this connector.

2. Power switch.

Power switch. Switch to turn ON/OFF the power supply to your computer.

3. USB 2.0 ports.

USB 2.0 ports. These Universal Serial Bus 2.0 (USB 2.0) ports connect to USB 2.0

devices such as a mouse, printer, scanner, camera, PDA, and others.

4. HDMI port.

HDMI port. This port is for a High-Denition Multimedia Interface (HDMI) connector,

and is HDCP compliant allowing playback of HD DVD, Blu-ray, and other protected
content.

5. USB 3.0 ports.

USB 3.0 ports. These Universal Serial Bus 3.0 (USB 3.0) ports connect to USB 3.0

devices such as a mouse, printer, scanner, camera, PDA, and others.

• DO NOT connect a keyboard / mouse to any USB 3.0 port when installing Windows®
operating system.

• Due to USB 3.0 controller limitation, USB 3.0 devices can only be used under Windows
OS environment and after the USB 3.0 driver installation.

• USB 3.0 devices can only be used as data storage only.

• We strongly recommend that you connect USB 3.0 devices to USB 3.0 ports for faster
and better performance for your USB 3.0 devices.

®

6. Side Speaker Out port (gray).Side Speaker Out port (gray). This port connects to the side speakers in an 8-channel

audio conguration.

7. Rear Speaker Out port (black).Rear Speaker Out port (black).

This port connects to the rear speakers in a 4, 6, and

8-channel audio conguration.

8. Center/Subwoofer port (orange).Center/Subwoofer port (orange).

This port connects to the center/subwoofer

speakers.

9. Microphone port (pink).Microphone port (pink).

10. Line Out port (lime).Line Out port (lime).

This port connects to a microphone.

This port connects to a headphone or speaker. In a 4, 6, or

8-channel conguration, the function of this port becomes Front Speaker Out.

11. Line In port (light blue).Line In port (light blue).

This port connects to a tape, CD, DVD player, or other audio

sources.

ENGLISH

Refer to the audio conguration table below for the function of the audio ports in a 2, 4, 6,
or 8-channel conguration.

Audio 2, 4, 6, or 8-channel conguration

Port

Light Blue Line In Line In Line In Line In

Lime Line Out Front Speaker Out Front Speaker Out Front Speaker Out

Pink Mic In Mic In Mic In Mic In

Orange – – Center/Subwoofer Center/Subwoofer

Black – Rear Speaker Out Rear Speaker Out Rear Speaker Out

Gray – – – Side Speaker Out

ASUS CM6630 13

Headset

2-channel

4-channel 6-channel 8-channel

ENGLISH

ENGLISH

12. Expansion slot bracket.Expansion slot bracket. Remove the expansion slot bracket when installing an

expansion card.

13. ASUS WLAN Card (on selected models only).ASUS WLAN Card (on selected models only).

This optional WLAN card allows your

computer to connect to a wireless network.

14. ASUS Graphics Card (on selected models only).ASUS Graphics Card (on selected models only).

The display output ports on this

optional ASUS Graphics Card may vary with different models.

15. LAN (RJ-45) port.LAN (RJ-45) port.

This port allows Gigabit connection to a Local Area Network (LAN)

through a network hub.

LAN port LED indications

Activity/Link LED Speed LED

Status Description Status Description

OFF No link OFF 10Mbps connection

ORANGE Linked ORANGE 100Mbps connection

BLINKING Data activity GREEN 1Gbps connection

ACT/LINK

LED

LAN port

SPEED

LED

16. VGA port.VGA port. This port is for VGA-compatible devices such as a VGA monitor.

17. Optical S/PDIF_OUT port.Optical S/PDIF_OUT port.

This port connects to an external audio output device via

an optical S/PDIF cable.

18. PS/2 Keyboard / Mouse Combo port (purple).PS/2 Keyboard / Mouse Combo port (purple). This port is for a PS/2 keyboard or

mouse.

19. Air vents.

Air vents. These vents allow air ventilation.

DO NOT block the air vents on the chassis. Always provide proper ventilation for your
computer.

14 Chapter 1: Getting started

ENGLISH

Setting up your computer

This section guides you through connecting the main hardware devices, such as the external
monitor, keyboard, mouse, and power cord, to your computer.

Connecting an external monitor

Using the ASUS Graphics Card (on selected models only)

Connect your monitor to the display output port on the discrete ASUS Graphics Card.

To connect an external monitor using the ASUS Graphics Card:

1. Connect a monitor to a display output port on the ASUS Graphics Card.

2. Plug the monitor to a power source.

The display output ports on the ASUS Graphics Card may vary with different models.

ENGLISH

ASUS CM6630 15

ENGLISH

ENGLISH

Using the onboard display output ports

Connect your monitor to the onboard display output port.

To connect an external monitor using the onboard display output ports:

1. Connect a VGA monitor to the VGA port, or a DVI-D monitor to the DVI-D port, or an
HDMI monitor to the HDMI port on the rear panel of your computer.

2. Plug the monitor to a power source.

• If your computer comes with an ASUS Graphics Card, the graphics card is set as the
primary display device in the BIOS. Hence, connect your monitor to a display output port
on the graphics card.

• To connect multiple external monitors to your computer, refer to
external monitors in Chapter 3 of this user manual for details.

16 Chapter 1: Getting started

Connecting multiple

ENGLISH

Connecting a USB keyboard and a USB mouse

Connect a USB keyboard and a USB mouse to the USB ports on the rear panel of your
computer.

Connecting the power cord

Connect one end of the power cord to the power connector on the rear panel of your
computer and the other end to a power source.

ENGLISH

ASUS CM6630 17

ENGLISH

Turning your computer ON/OFF

This section describes how to turn on/off your computer after setting up your computer.

Turning your computer ON

To turn your computer ON:

1. Turn on the power switch.

2. Turn your monitor ON.

3. Press the power button on your computer.

Power button

4. Wait until the operating system loads automatically.

Turning your computer OFF

To turn your computer OFF:

1. Close all running applications.

2. Click

3. Click

18 Chapter 1: Getting started

on the Windows® desktop.

to shut down the operating system.

Chapter 2

Using Windows® 7

Starting for the rst time

When you start your computer for the rst time, a series of screens appear to guide you in
conguring the basic settings of your Windows® 7 operating system.

To start for the rst time:

1. Turn your computer on. Wait for a few minutes until the
appears.

2. From dropdown list, select your language, then click

3. From the dropdown lists, select your
Keyboard layout, then click Next.

4. Key in uniques names for the

5. Key in the necessary information to set up your password, then click
also click Next to skip this step without entering any information.

If you want to set up a password for your account later, refer to the section Setting up a
user account and password in this chapter.

6. Carefully read the license terms. Tick

7. Select

8. Review your date and time settings. Click

Use recommended settings or Install important updates only to set up the

security settings for your computer. To skip this step, select Ask me later.

restarts. You may now start using your computer.

Country or region, Time and currency, and

user name and computer name, then click Next.

I accept the license terms and click Next.

Next. The system loads the new settings and

Set Up Windows screen

Next.

Next. You may

ENGLISH

ASUS CM6630 19

ENGLISH

Using Windows® 7 desktop

ENGLISH

Click the Start icon > Help and Support to obtain more information about Windows® 7.

Using the Start menu

The Start menu gives you access to programs, utilities, and other useful items on your
computer. It also provides you with more information about Windows 7 through its Help and

Support feature.

Launching items from the Start menu

To launch items from the Start menu:

®

1. From the Windows

2. From the Start menu, select the item that you want to launch.

You may pin programs that you want constantly displayed on the Start menu. For more
details, refer to the section Pinning programs on the Start menu or taskbar on this
chapter.

Using the Getting Started item

The Getting Started item on the Start menu contains information about some basic tasks

such as personalizing Windows®, adding new users, and transferring les to help you to
familiarize yourself with using Windows® 7.

To use the Getting Started item:

1. From the Windows

2. Select

3. Select the task that you want to do.

Getting Started. The list of available tasks appears.

taskbar, click the Start icon .

®

taskbar, click the Start icon to launch the Start menu.

Using the taskbar

The taskbar allows you to launch and manage programs or items installed on your computer.

Launching a program from the taskbar

To launch a program from the taskbar:

®

• From the Windows
program.

You may pin programs that you want constantly displayed on the taskbar. For more details,
refer to the section Pinning programs on the Start menu or taskbar on this chapter.

20 Chapter 2: Using Windows® 7

taskbar, click an icon to launch it. Click the icon again to hide the

ENGLISH

Pinning items on the jumplists

When you right-click an icon on the taskbar, a jumplist launches to provide you with quick­access to the program’s or item’s related links.You may pin items on the jumplist such as

favorite websites, often-visited folders or drives, or recently played media les.

To pin items to the jumplist:

1. From the taskbar, right-click an icon.

2. From the jumplist, right-click the item that you want to pin, then select

Pin to this list.

Unpinning items from the jumplist

To unpin items from the jumplist:

1. From the taskbar, right-click an icon.

2. From the jumplist, right-click the item that you want to remove from the jumplist, then

select Unpin from this list.

Pinning programs on the Start menu or taskbar

To pin programs on the Start menu or taskbar:

®

1. From the Windows

2. Right-click the item that you want to pin on the Start menu or taskbar.

3. Select

Pin to Taskbar or Pin to Start menu.

You may also right-click on the icon of a running program on the taskbar, then select Pin
this program to taskbar.

taskbar, click the Start icon to launch the Start menu.

ENGLISH

Unpinning programs from the Start menu

To unpin programs from the Start menu:

®

1. From the Windows

2. From the Start menu, right-click the program that you want to unpin, then select

Remove from this list.

taskbar, click the Start icon to launch the Start menu.

Unpinning programs from the taskbar

To unpin programs from the taskbar:

1. From the taskbar, right-click the program that you want to remove from the taskbar,

then select Unpin this program from taskbar.

ASUS CM6630 21

ENGLISH

ENGLISH

Using the notication area

By default, the notication area shows these three icons:

Action Center notication

Click this icon to display all the alert messages/notications and launch the Windows

Action Center.

Network connection

This icon displays the connection status and signal strength of the wired or wireless network
connection.

Volume

Click this icon to adjust the volume.

Displaying an alert notication

To display an alert notication:

®

• Click the Notication icon

For more details, refer to the section Using Windows® Action Center in this chapter.

, then click the message to open it.

Customizing icons and notications

You may choose to display or hide the icons and notications on the taskbar or on the
notication area.

To customize icons and notications:

1. From the notication area, click on the arrow icon

2. Click

Customize.

.

3. From the dropdown list, select the behaviors for the icons or items that you want to

customize.

Managing your les and folders

Using Windows® Explorer

Windows® Explorer allows you to view, manage, and organize your les and folders.

Launching Windows® Explorer

To launch Windows Explorer:

®

1. From the Windows

2. Click

Computer to launch Windows Explorer.

taskbar, click the Start icon to launch the Start menu.

22 Chapter 2: Using Windows® 7

ENGLISH

Exploring les and folders

To explore les and folders:

®

1. Launch Windows

2. From the navigation or view pane, browse for the location of your data.

3. From the breadcrumb bar, click the arrow to display the contents of the drive or folder.

Explorer.

Customizing the le/folder view

To customize the le/folder view:

1. Launch Windows Explorer.

2. From the navigation pane, select the location of your data.

3. From the toolbar, click the View icon

4. From the View menu, move the slider to select how you want to view the le/folder.

You may also right-click anywhere on the View pane, click View, and select the view type
that you want.

.

Arranging your les

To arrange your les:

1. Launch Windows Explorer.

2. From the

3. Select your preferred arrangement type.

Arrange by eld, click to display the dropdown list.

ENGLISH

Sorting your les

To sort your les:

1. Launch Windows Explorer.

2. Right-click anywhere on the View pane.

3. From the menu that appears, select

Sort by, then select your preferred sorting type.

Grouping your les

To group your les:

1. Launch Windows Explorer.

2. Right-click anywhere on the View pane.

3. From the menu that appears, select
type.

ASUS CM6630 23

Group by, then select your preferred grouping

ENGLISH

ENGLISH

Adding a new folder

To add a new folder:

1. Launch Windows Explorer.

2. From the toolbar, click

3. Key in a name for the new folder.

You may also right-click anywhere on the View pane, click New > Folder.

New folder.

Backing up your les

Setting up a backup

To set up a backup:

1. Click

2. Click

3. Select your backup destination. Click

4. Select Let Windows choose (recommended)

5. Follow the onscreen instructions to nish the process.

> All Programs > Maintenance > Backup and Restore.

Set up backup. Click Next.

Next.

or Let me choose as your backup

mode.

If you select Let Windows choose, Windows will not back up your programs, FAT-

formatted les, Recycle Bin les, or temporary les that are 1GB or more.

Restoring your system settings

The Windows® System Restore feature creates a restore point where the computer’s system
settings are stored at certain time and date. It allows you to restore or undo changes to your
computer’s system settings without affecting your personal data.

To restore your system:

1. Close all running applications.

2. Click

3. Follow the onscreen instructions to complete the process.

> All Programs > Accessories > System Tools > System Restore.

24 Chapter 2: Using Windows® 7

ENGLISH

Protecting your computer

Using Windows® 7 Action Center

Windows® 7 Action Center provides you with alert notications, security information, system

maintenance information, and the option to automatically troubleshoot and x some common

computer problems.

You may customize the notications. For more details, refer to the previous section

Customizing icons and notications in this chapter.

Launching Windows® 7 Action Center

To launch Windows® 7 Action Center:

ENGLISH

1. To launch Windows 7 Action Center, click the Notication icon

Action Center.

2. From Windows 7 Action Center, click the task that you want to do.

, then click Open

Using Windows® Update

Windows Update allows you to check and install the latest updates to enhance the security
and performance of your computer.

Launching Windows® Update

To launch Windows® Update:

®

1. From the Windows

2. Select

3. From the Windows Update screen, click the task that you want to do.

All Programs > Windows Update.

taskbar, click the Start icon to launch the Start menu.

Setting up a user account and password

You may create user accounts and passwords for people who will use your computer.

Setting up a user account

To set up a user account:

®

1. From the Windows

2. Select

3. Select

4. Key in the name of the new user.

5. Select either

6. When done, click

Manage another account.

Create a new account.

taskbar, click > Getting Started > Add new users.

Standard user or Administrator as the user type.

Create Account.

ASUS CM6630 25

ENGLISH

Setting up a user’s password

To set up a user’s password:

1. Select the user that you would like to set a password.

2. Select

3. Key in a password and conrm it. Key in your password’s hint.

4. When done, click

Create a password.

Create password.

Activating the anti-virus software

Trend Micro Internet Security is pre-installed on your computer. It is a third-party anti-virus
software protecting your computer from virus. It is purchased separately. You have a 30-day
trial period after activating it.

To activate Trend Micro Internet Security:

1. Run the Trend Micro Internet Security application.

2. Carefully read the license terms. Click

3. Input your e-mail address and select your location. Click

4. Click Finish to complete the activation.

Agree & Activate.

Next.

Getting Windows® Help and Support

Windows® Help and Support provides you with guides and answers in using the applications
in Windows® 7 platform.

To launch Windows® Help and Support, click > Help and Support.

Ensure that you are connected to the Internet to obtain the latest Windows

26 Chapter 2: Using Windows® 7

®

online help.

Chapter 3

Connecting devices to your computer

Connecting a USB storage device

This desktop PC provides USB 2.0/1.1 ports on both the front and rear panels. The USB
ports allow you to connect USB devices such as storage devices.

To connect a USB storage device:

• Insert the USB storage device to your computer.

Front panel

Rear panel

USB3.0 USB2.0

To remove a USB storage device:

1. Click

from the Windows notication area on your

computer, then click Eject USB2.0 FlashDisk.

ENGLISH

2. When the
pops up, remove the USB storage device from
your computer.

ASUS CM6630 27

Safe to Remove Hardware message

DO NOT remove a USB storage device when data transfer is in progress. Doing so may
cause data loss or damage the USB storage device.

ENGLISH

ENGLISH

Connecting microphone and speakers

This desktop PC comes with microphone ports and speaker ports on both the front and
rear panels. The audio I/O ports located on the rear panel allow you to connect 2-channel,
4-channel, 6-channel, and 8-channel stereo speakers.

Connecting Headphone and Mic

Connecting 2-channel Speakers

28 Chapter 3: Connecting devices to your computer

ENGLISH

Connecting 4-channel Speakers

Connecting 6-channel Speakers

ENGLISH

ASUS CM6630 29

ENGLISH

ENGLISH

Connecting 8-channel Speakers

30 Chapter 3: Connecting devices to your computer

ENGLISH

Connecting multiple external displays

Your desktop PC may come with VGA, HDMI, or DVI ports and allows you to connect multiple
external displays.

When a graphics card is installed in your computer, connect the monitors on the output
ports of the graphics card.

Setting up multiple displays

When using multiple monitors, you are allowed to set display modes. You can use the
additional monitor as a duplicate of your main display, or as an extension to enlarge your
Windows desktop.

To set up multiple displays:

1. Turn off your computer.

2. Connect the two monitors to your computer and connect the power cords to the
monitors. Refer to Setting up your computer section in Chapter 1 for details on how
to connect a monitor to your computer.

For some graphic cards, only the monitor that is set to be the primary display has display
during POST. The dual display function works only under Windows.

ENGLISH

ASUS CM6630 31

ENGLISH

ENGLISH

3. Turn on your computer.

4. Do any of the following to open the

Screen Resolution setting screen:

• Click

• Right click anywhere on your Windows desktop. When the pop-up menu appears,

5. Select the display mode from the Multiple displays: drop-down list.

•

•

•

•

> Control Panel > Appearance and Personalization > Display >

Change display settings.

click Personalize > Display > Change display settings.

Duplicate these displays: Select this option to use the additional monitor as a
duplicate of your main display.

Extend these displays: Select this option to use the additional monitor as an
extension display. This increases your desktop space.

Show desktop only on 1 / 2: Select this option to show desktop only on monitor
1 or monitor 2.

Remove this display: Select this options to remove the selected display.

6. Click Apply or OK. Then click Keep Changes on the conrmation message.

32 Chapter 3: Connecting devices to your computer

ENGLISH

Connecting an HDTV

Connect a High Denition TV (HDTV) to the HDMI port of your computer.

• You need an HDMI cable to connect the HDTV and the computer. The HDMI cable is
purchased separately.

• To get the best display performance, ensure that your HDMI cable is less than 15
meters.

ENGLISH

ASUS CM6630 33

ENGLISH

34 Chapter 3: Connecting devices to your computer

Chapter 4

Eye level to the top of
the monitor screen

Foot rest 90˚ angles

Using your computer

Proper posture when using your Desktop PC

When using your Desktop PC, maintaining the proper posture is necessary to prevent strain to
your wrists, hands, and other joints or muscles. This section provides you with tips on avoiding
physical discomfort and possible injury while using and fully enjoying your Desktop PC.

To maintain the proper posture:

• Position your computer chair to make sure that your elbows are at or slightly above the
keyboard to get a comfortable typing position.

• Adjust the height of your chair to make sure that your knees are slightly higher than
your hips to relax the backs of your thighs. If necessary, use a footrest to raise the level
of your knees.

• Adjust the back of your chair so that the base of your spine is rmly supported and

angled slightly backward.

• Sit upright with your knees, elbows and hips at an approximately 90º angle when you
are at the PC.

• Place the monitor directly in front of you, and turn the top of the monitor screen even
with your eye level so that your eyes look slightly downward.

• Keep the mouse close to the keyboard, and if necessary, use a wrist rest for support to
reduce the pressure on your wrists while typing.

• Use your Desktop PC in a comfortably-lit area, and keep it away from sources of glare
such as windows and straight sunlight.

• Take regular mini-breaks from using your Desktop PC.

ENGLISH

ASUS CM6630 35

ENGLISH

ENGLISH

Using the memory card reader

Digital cameras and other digital imaging devices use memory cards to store digital picture or

media les. The built-in memory card reader on the front panel of your system allows you to

read from and write to different memory card drives.

1

To use the memory card:

1. Insert the memory card into the card slot.

• A memory card is keyed so that it ts in only one direction. DO NOT force a card into a

slot to avoid damaging the card.

• You can place media in one or more of the card slots and use each media
independently. Place only one memory card in a slot at one time.

2. Select a program from the AutoPlay window to access your les.

• If AutoPlay is NOT enabled in your computer, click Windows® 7 Start button on the
taskbar, click Computer, and then double-click the memory card icon to access the data
on it.

• Each card slot has its own drive icon which is displayed on the

• The memory card reader LED lights up and blinks when data is being read from or
written to the memory card.

Computer screen.

3. When nished, right-click the memory card drive icon on the Computer screen, click

Eject, and then remove the card.

Never remove cards while or immediately after reading, copying, formatting, or deleting
data on the card or else data loss may occur.

To prevent data loss, use “Safely Remove Hardware and Eject Media” in the Windows

notication area before removing the memory card.

36 Chapter 4: Using your computer

ENGLISH

Using the optical drive

1

2

Inserting an optical disc

To insert an optical disc:

1. While your system is on, press the eject button below the drive bay cover to open the
tray.

2. Place the disc to the optical drive with the label side facing up.

3. Push the tray to close it.

4. Select a program from the AutoPlay window to access your les.

If AutoPlay is NOT enabled in your computer, click Windows® 7 Start button on the taskbar,
click Computer, and then double-click the CD/DVD drive icon to access the data on it.

ENGLISH

3

Removing an optical disc

To remove an optical disc:

1. While the system is on, do either of the following to eject the tray:

• Press the eject button below the drive bay cover.

• Right-click the CD/DVD drive icon on the

2. Remove the disc from the disc tray.

ASUS CM6630 37

Computer screen, and then click Eject.

ENGLISH

ENGLISH

`

6

789 10 11 12 13 14 15 16 17

2

3

4

5

1

18

19

20

21

22

Using the multimedia keyboard (on selected models only)

The keyboard varies with models. The illustrations on this section are for reference only.

ASUS SK-2045 keyboard

Keys Description Keys Description

Launches Windows® gadgets.

Activates Windows® Flip 3D.

Reduces picture size in Windows®

Photo Viewer.

Increases picture size in Windows®

Photo Viewer.

Functions with keys F1~F12.

Press <Fn + F1> to launch Microsoft®
Word.

Press <Fn + F2> to launch Microsoft®
Excel.

Press <Fn + F3> to launch Microsoft®
PowerPoint.

Press <Fn + F4> to launch Microsoft®
Internet Explorer.

Press <Fn + F5> to launch Microsoft®
Outlook.

Press <Fn + F6> to launch the
Favorites folder in Windows® Internet
Explorer.

1.

2.

3.

4.

5.

6.

7.

8.

9.

10.

11.

12.

13.

14.

15.

16.

17.

18.

19.

20.

21.

22.

Press <Fn + F7> to launch Microsoft®
MSN or, if not installed, connects to the
MSN download page.

Press <Fn + F8> to launch Windows®
Search screen.

Press <Fn + F9> to play or pause
playback in Windows® Media Player.

Press <Fn + F10> to stop playback in
Windows® Media Player.

Press <Fn + F11> to go to the previous
track in Windows® Media Player.

Press <Fn + F12> to go to the next
track in Windows® Media Player.

Decreases the system volume.

Increases the system volume.

Turns the volume’s mute mode on/off.

Launches Windows® Media Player.

Launches Windows® Media Center.

38 Chapter 4: Using your computer

The special function keys only work on Windows® Vista / Windows® 7 operating systems.

ENGLISH

ASUS-Razer Arctosa Gaming keyboard

Keys Description

1.

2.

3.

4.

5.

6.

7.

8.

Plays or pauses playback in a media
player.

Stops playback in a media player.

Goes to the previous track in a media
player.

Goes to the next track in a media
player.

Decreases the system volume.

Increases the system volume.

Turns the volume’s mute mode on/off.

Switches proles working with F1 ~

F10 keys.

1

2 5 6

3

4 8 7

ENGLISH

• The special function keys work on Windows® XP / Vista / 7 operating systems.

• Install the keyboard driver before using. Visit the Razer website at
www.razersupport.com to download the driver.

ASUS CM6630 39

ENGLISH

ENGLISH

ASUS PRIMAX/KB2621 keyboard

Keys Description

1.

2.

3.

4.

5.

6.

Decreases the system volume.

Turns the volume’s mute mode on/off.

Increases the system volume.

Goes to the previous track in a media
player.

Plays or pauses playback in a media
player.

Goes to the next track in a media
player.

The special function keys only work on Windows® Vista / Windows® 7 operating systems.

1 32

5 64

40 Chapter 4: Using your computer

ENGLISH

`

1

234 5

6

7

8

9

10 11

12

13

BTC 6200C keyboard

Keys Description Keys Description

Enters into sleep mode. Press any key

1.

to wake up your computer and return to
the previous working status.

Returns to the last page you viewed.

2.

Goes to the next page you viewed

3.
before.

Launches the default homepage in

4.
Windows® Internet Explorer.

Launches the Favorites folder in

5.
Windows® Internet Explorer.

Launches your default email application.

6.

Decreases the system volume.

7.

Increases the system volume.

8.

Turns the volume’s mute mode on/off.

9.

Goes to the previous track in a media

10.
player.

Plays or pauses playback in a media

11.
player.

Goes to the next track in a media player.

12.

Stops playback in a media player.

13.

ENGLISH

• The special function keys work on Windows® ME / 2000 / XP / Vista / 7 operating
systems without installing a driver. For Windows® 98SE operating system, visit the BTC
website at www.btc.com.tw to download the driver.

• Install Microsoft

ASUS CM6630 41

®

Internet Explorer 5.0 or later versions before using the Internet keys.

ENGLISH

ASUS KB34211 modern wired keyboard

1 2 3

Hot keys Description

1.

2.

3.

The special function keys only work on Windows® Vista / Windows® 7 / XP operating
systems.

Turns the volume’s mute mode on/off.

Decreases the system volume.

Increases the system volume.

42 Chapter 4: Using your computer

Chapter 5

Modem

RJ-45 cable

Connecting to the Internet

Wired connection

Use an RJ-45 cable to connect your computer to a DSL/cable modem or a local area network
(LAN).

Connecting via a DSL/cable modem

To connect via a DSL/cable modem:

1. Set up your DSL/cable modem.

Refer to the documentation that came with your DSL/cable modem.

2. Connect one end of an RJ-45 cable to the LAN (RJ-45) port on the rear panel of your
computer and the other end to a DSL/cable modem.

ENGLISH

3. Turn on the DSL/cable modem and your computer.

4. Congure the necessary Internet connection settings.

Contact your Internet Service Provider (ISP) for details or assistance in setting up your
Internet connection.

ASUS CM6630 43

ENGLISH

ENGLISH

RJ-45 cable

LAN

Connecting via a local area network (LAN)

To connect via a LAN:

1. Connect one end of an RJ-45 cable to the LAN (RJ-45) port on the rear panel of your
computer and the other end to your LAN.

2. Turn on your computer.

3. Congure the necessary Internet connection settings.

Contact your network administrator for details or assistance in setting up your Internet
connection.

44 Chapter 5: Connecting to the Internet

ENGLISH

Wireless connection (on selected models only)

Wireless AP

Modem

Connect your computer to the Internet through a wireless connection.

To establish a wireless connection, you need to connect to a wireless access point (AP).

ENGLISH

• To increase the range and sensitivity of the wireless radio signal, connect the external
antennas to the antenna connectors on the ASUS WLAN Card.

• Place the antennas on the top of your computer for the best wireless performance.

• The external antennas are optional items.

ASUS CM6630 45

ENGLISH

ENGLISH

To connect to a wireless network:

1. Click the network icon
networks.

2. Select the wireless network that you want to connect to, then click Connect.

in the notication area to display the available wireless

3. You may need to key in the network security key for a secured wireless network, then
click OK.

46 Chapter 5: Connecting to the Internet

ENGLISH

4. Wait while your computer is connecting to the wireless network.

5. The wireless connection is established successfully. The connection status is displayed

and the network icon displays the connected status.

ENGLISH

ASUS CM6630 47

ENGLISH

48 Chapter 5: Connecting to the Internet

Chapter 6

Using the utilities

The Support DVD and Recovery DVD may not be included in the package. You may use
the Recovery Partition feature to create the Support DVD and Recovery DVD. For details,
refer to Recovering your system in this chapter.

ASUS AI Suite II

ASUS AI Suite II is an all-in-one interface that integrates several ASUS utilities and allows
users to launch and operate these utilities simultaneously.

Installing AI Suite II

To install AI Suite II:

1. Place the support DVD in the optical drive. The Drivers installation tab appears if
Autorun is enabled.

2. Click the

3. Follow the onscreen instructions to complete the installation.

Using AI Suite II

AI Suite II automatically starts when you enter the Windows® operating system. The AI Suite
II icon appears in the Windows® notication area. Click the icon to open the AI Suite II main
menu bar.

Click each button to select and launch a utility, to monitor the system, to update the

motherboard BIOS, to display the system information, and to customize the settings of AI

Suite II.

Utilities tab, then click ASUS AI Suite II.

ENGLISH

Click to select a
utility

ASUS CM6630 49

Click to monitor
sensors or CPU
frequency

Click to update the
motherboard BIOS

Click to show
the system
information

Click to customize
the interface
settings

ENGLISH

ENGLISH

The Tool menu

The Tool menu includes the EPU, Probe II, and Sensor Recorder panels.

Launching EPU

EPU is an energy-efcient tool that provides you with a total power-saving solution. It detects

the current loading and intelligently adjusts the power usage in real-time. When you select
the Auto mode, the system changes modes automatically according to the current system

status. It allows you to customize each mode through conguring the settings such as CPU

frequency, vCore Voltage, and Fan Control.

To launch EPU:

• Click

Tool > EPU on the AI Suite II main menu bar.

Displays the following message
if no VGA power saving engine is
detected.

Displays current mode

The items lighting up
means power saving
engine is activated

Displays the amount
of CO2 reduced

*Shifts between the
display of Total and
Current CO2 reduced

Displays the current
CPU power

Advanced settings for each mode

Multiple system
operating modes

• * Select From EPU Installation to show the CO2 that has been reduced since you

installed EPU.

• *

Select From the Last Reset to show the total CO2 that has been reduced since you
click the Clear button .

50 Chapter 26: Using the utilities

Displays the system
properties of each mode

ENGLISH

Launching and conguring Probe II

Probe II is a utility that monitors the computer’s vital components, and detects and alerts you
of any problem with these components. Probe II senses fan rotations, CPU temperature,
and system voltages, among others. With this utility, you are assured that your computer is
always at a healthy operating condition.

To launch Probe II:

• Click

To congure Probe II:

• Click the Voltage/Temperature/Fan Speed

• The

Tool > Probe II on the AI Suite II main menu bar.

tabs to activate the sensors or to adjust the

sensor threshold values.

Preference tab allows you to customize the time interval of sensor alerts, or

change the temperature unit.

ENGLISH

Saves your

conguration

Loads your saved

conguration

ASUS CM6630 51

Loads the default
threshold values
for each sensor

Applies your
changes

ENGLISH

ENGLISH

Launching and conguring Sensor Recorder

Sensor Recorder allows you to monitor the changes in the system voltage, temperature, and
fan speed, as well as recording the changes.

To launch Sensor Recorder:

• Click

Tool > Sensor Recorder on the AI Suite II main menu bar.

To congure Sensor Recorder:

• Click the Voltage/Temperature/Fan Speed

tabs and select the sensors that you want

to monitor.

• The

History Record tab allows you to record the changes in the sensors that you

enable.

Select the
sensors that you
want to monitor

Drag to view the
status during a
certain period
of time

Click to return to
the default mode

Click to zoom in/out
the X axis

Click to zoom in/out
the Y axis

52 Chapter 26: Using the utilities

ENGLISH

The Monitor menu

The Monitor menu includes the Sensor and CPU Frequency panels.

Launching Sensor

The Sensor panel displays the current value of a system sensor such as fan rotation, CPU
temperature, and voltages.

To launch Sensor:

• Click

Monitor > Sensor on the AI Suite II main menu bar.

Launching CPU Frequency

The CPU Frequency panel displays the current CPU frequency and CPU usage.

To launch CPU frequency:

• Click

Monitor > CPU Frequency on the AI Suite II main menu bar.

The Update menu

The Update menu allows you to update the motherboard BIOS and the BIOS boot logo with
the ASUS designed update utilities.

ASUS Update

The ASUS Update is a utility that allows you to manage, save, and update the motherboard
BIOS in Windows® OS. The ASUS Update utility allows you to update the BIOS directly

from the Internet, download the latest BIOS le from the Internet, update the BIOS from an
updated BIOS le, save the current BIOS le or view the BIOS version information.

ENGLISH

Updating the BIOS through the Internet
To update the BIOS through the Internet:

1. From the ASUS Update screen, select

2. Select the ASUS FTP site nearest you to avoid network trafc.

Tick the two items if you want to enable the BIOS downgradable and Auto-BIOS

backup functions.

3. Select the BIOS version that you want to download, then click

When no updated version is detected, a message is displayed informing you that there

is no new BIOS le from the BIOS server.

4. Click

5. Follow the onscreen instructions to complete the update process.

ASUS CM6630 53

Yes if you want to change the boot logo, which is the image appearing on screen

during the Power-On Self-Tests (POST). Otherwise, click No.

Update BIOS from le, then click Next.

Next.

ENGLISH

ENGLISH

Updating the BIOS through a BIOS le
To update the BIOS through a BIOS le:

1. From the ASUS Update screen, select

2. Locate the BIOS le from the Open window, click

3. Click

4. Follow the onscreen instructions to complete the update process.

Yes if you want to change the boot logo, which is the image appearing on screen

during the Power-On Self-Tests (POST). Otherwise, click No.

Update BIOS from le, then click Next.

Open, and click Next.

The System Information screen

The System Information screen displays the information about the motherboard, CPU, and
memory slots.

• Click the
version, and BIOS.

• Click the

• Click the
module installed on the corresponding slot.

MB tab to see the details on the motherboard manufacturer, product name,

CPU tab to see the details on the processor and the Cache.

SPD tab and then select the memory slot to see the details on the memory

The Settings screen

The Settings screen allows you to customize the main menu bar settings and the interface’s

skin.

• Application allows you to select the application that you want to enable.

• Bar allows you to modify the bar setting,

• Skin allows you to customize the interface’s contrast, brightness, saturation, hue, and

gamma.

54 Chapter 26: Using the utilities

ENGLISH

ASUS AI Manager

ASUS AI Manager is a utility which gives you quick and easy access to frequently-used
applications.

Installing AI Manager

To install AI Manager:

1. Place the support DVD in the optical drive. If Autorun is enabled, the Drivers installation

wizard appears.

If Autorun is disabled, double-click the setup.exe le from the ASUS AI Manager folder in
the support DVD.

2. Click the Utilities tab, then click ASUS AI Manager.

3. Follow the onscreen instructions to complete the installation.

Launching AI Manager

To launch the AI Manager from the Windows® desktop, click

AI Manager > AI Manager 1.xx.xx

After launching the application, the AI Manager icon appears in the Windows® taskbar.
Right-click this icon to switch between the quick bar and the main window, and to launch the

AI Manager either from the quick bar or taskbar.

. The AI Manager quick bar appears on the desktop.

AI Manager quick bar

The AI Manager quick bar saves the desktop space and allows you to launch the ASUS
utilities or display system information easily. Click any of the Main, My Favorites, Support or
Information tab to display the menu’s contents.

Start > All Programs > ASUS >

ENGLISH

Exit button
Switch to main Window
Add to ToolBar

Main

My Favorites

Click the Maximize/restore button to switch between full window and quick bar. Click the
Minimize button to keep the AI Manager on the taskbar. Click the Close button to quit

the AI Manager.

Support

Information

Main

The Main menu contains three utilities: AI Disk, AI Security, and AI Booting. Click the arrow
on the Main menu icon to browse through the utilities in the main menu.

ASUS CM6630 55

ENGLISH

ENGLISH

AI Disk

AI Disk allows you to easily clear temporary IE les, IE cookies, IE URLs, IE history,

or the Recycle Bin. Click the AI Disk icon on the quick bar to display the full AI Disk
window and select the items you want to clear. Click Apply when done.

AI Security

AI Security enables you to set a password to secure your devices, such as USB ash
disks and CD/DVD disks, from unauthorized access.

To lock a device:

1. When using AI Security for the rst time, you are asked to set a password. Key in

2. Conrm the password.

3. Key in the password hint (recommended).

4. When done, click

5. Select the device you want to lock, then click

6. Key in the password you have set previously, then click

To unlock the device:

1. Deselect the locked device, then click

2. Key in the password you have set previously, then click

To change the password:

• Click

To specify the boot sequence:

1. Select a device, then click the left/right button to specify the boot sequence.

2. When done, press

a password with at most 20 alphanumeric characters.

Ok.

Apply.

Ok.

Apply.

Ok.

Change Password, then follow the onscreen instructions to change

password.

AI Booting

AI Booting allows you to specify the boot device priority sequence.

Apply.

My Favorites

My Favorites allows you to add applications that you frequently use, saving you from

searching for the applications throughout your computer.

56 Chapter 26: Using the utilities

ENGLISH

To add an application:

1. Click

2. Click

Right click on the application icon to launch, delete, or rename the selected application. You
can also double click to launch the selected application.

Add, then locate the application you want to add to My Favorites.

Open on the le location window. The application is added to My Favorites list.

Support

Click any links on the Support window to go to the ASUS website, technical support website,
download support website, or contact information.

Information

Click the tab on the Information window to see the detailed information about your system,
motherboard, CPU, BIOS, installed device(s), and memory.

ENGLISH

ASUS CM6630 57

ENGLISH

ENGLISH

Nero 9

Nero 9 allows you to create, copy, burn, edit, share, and update different kinds of data.

Installing Nero 9

To install Nero 9:

1. Insert the Nero 9 DVD into your optical drive.

2. If Autorun is enabled, the main menu appears automatically.

If Autorun is disabled, double-click the SeupX.exe le from the main directory of your Nero
9 DVD.

3. From the main menu, click Nero 9 Essentials.

4. Select the language you want to use for Installation Wizard. Click

5. Click

6. Tick

7. Select

8. Tick

9. When done, click

Next to continue.

I accept the License Conditions. When done, click Next.

Typical then click Next.

Yes, I want to help by sending anonymous application data to Nero then click

Next.

Exit.

Burning les

To burn les:

1. From the main menu, click

2. Select the les that you want to burn. When done, click

3. After selecting les that you want to burn, click

Data Burning > Add.

Add.

Burn to burn the les to a disc.

Next.

For more details about using Nero 9, refer to the Nero website at www.nero.com

58 Chapter 26: Using the utilities

ENGLISH

Recovering your system

Using the Recovery Partition

The Recovery Partition quickly restores your Desktop PC’s software to its original working

state. Before using the Recovery Partition, copy your data les (such as Outlook PST les)
to USB storage devices or to a network drive and make note of any customized conguration

settings (such as network settings).

About the Recovery Partition

The Recovery Partition is a reserved space on your hard disk drive used to restore the
operating system, drivers, and utilities installed on your Desktop PC at the factory.

DO NOT delete the partition named
RECOVERY. The Recovery Partition
is created at the factory and cannot be
restored if deleted. Take your Desktop

PC to an authorized ASUS service

center if you have problems with the
recovery process.

Using the Recovery Partition:

1. Press <

2. Press <

3. Select one of the following recovery options.

System Recovery:

This feature allows you to restore the system to the factory default settings.

System Image Backup:

This feature allows you to burn the system image backup in DVD discs, which you can use

System DVD Backup:

This feature allows you to make a backup copy of the support DVD.

4. Follow the onscreen instructions to complete the recovery process.

F9> during bootup.

Enter> to select Windows Setup [EMS Enabled].

later to restore the system to its default settings.

ENGLISH

Visit the ASUS website at www.asus.com for updated drivers and utilities.

ASUS CM6630 59

ENGLISH

Using the Recovery DVD (on selected models)

Prepare 1~3 blank writable DVDs as instructed to create the Recovery DVD.

Remove the external hard disk drive before performing system recovery on your Desktop
PC. According to Microsoft, you may lose important data because of setting up Windows on
the wrong disk drive or formatting the incorrect drive partition.

To use the Recovery DVD:

1. Insert the Recovery DVD into the optical drive. Your Desktop PC needs to be powered
ON.

2. Restart the Desktop PC and press <
labeled as “CD/DVD”) and press <Enter> to boot from the Recovery DVD.

3. Select OK to start to restore the image.

4. Select OK to conrm the system recovery.

Restoring will overwrite your hard drive. Ensure to back up all your important data before
the system recovery.

5. Follow the onscreen instructions to complete the recovery process.

DO NOT remove the Recovery disc, unless instructed to do so, during the recovery process
or else your partitions will be unusable.

Visit the ASUS website at www.asus.com for updated drivers and utilities.

F8> on bootup and select the optical drive (may be

60 Chapter 26: Using the utilities

Chapter 7

Troubleshooting

Troubleshooting

This chapter presents some problems you might encounter and the possible solutions.

My computer cannot be powered on and the power LED on the front

?

panel does not light up

• Check if your computer is properly connected.

• Check if the wall outlet is functioning.

• Check if the Power Supply Unit is switched on. Refer to the section

your computer ON/OFF in Chapter 1.

My computer hangs.

?

• Do the following to close the programs that are not responding:

1. Simultaneously press <Alt> + <Ctrl> + <Delete> keys on the keyboard,

2. Click

3. Select the program that is not responding, then click

• If the keyboard is not responding. Press and hold the Power button on the top

then click Start Task Manager.

Applications tab.

End Task.

of your chassis until the computer shuts down. Then press the Power button
to turn it on.

Turning

ENGLISH

I cannot connect to a wireless nestwork using the ASUS WLAN Card

?

(on selected models only)?

• Ensure that you enter the correct network security key for the wireless network
you want to connect to.

• Connect the external antennas (optional) to the antenna connectors on the
ASUS WLAN Card and place the antennas on the top of your computer
chassis for the best wireless performance.

The arrow keys on the number key pad are not working.

?

Check if the Number Lock LED is off. When the Number Lock LED is on,

the keys on the number key pad are used to input numbers only. Press the
Number Lock key to turn the LED off if you want to use the arrow keys on the
number key pad.

ASUS CM6630 61

ENGLISH

ENGLISH

No display on the monitor.

?

• Check if the monitor is powered on.

• Ensure that your monitor is properly connected to the video output port on
your computer.

• If your computer comes with a discrete graphics card, ensure that you connect
your monitor to a video output port on the discrete graphics card.

• Check if any of the pins on the monitor video connector is bent. If you discover
bent pins, replace the monitor video connector cable.

• Check if your monitor is plugged to a power source properly.

• Refer to the documentation that came with your monitor for more
troubleshooting information.

When using multiple monitors, only one monitor has display.

?

• Ensure that the both monitors are powered on.

• During POST, only the monitor connected to the VGA port has display. The
dual display function works only under Windows.

• When a graphics card is installed on your computer, ensure that you connect
the monitors to the output port on the graphics card.

• Check if the multiple displays settings are correct. Refer to section

Connecting multiple external displays in Chapter 3 for details.

My computer cannot detect my USB storage device.

?

• The rst time you connect your USB storage device to your computer,

Windows automatically installs a driver for it. Wait for a while and go to My
Computer to check if the USB storage device is detected.

• Connect your USB storage device to another computer to test if the USB
storage device is broken or malfunctions.

I want to restore or undo changes to my computer’s system settings

?

without affecting my personal les or data.

The Windows® System Restore feature allows you to restore or undo changes

to your computer’s system settings without affecting your personal data such
as documents or photos. For more details, refer to the section Restoring your
system in Chapter 2.

62 Chapter 7: Troubleshooting

ENGLISH

The picture on the HDTV is distorted.

?

• It is caused by the different resolutions of your monitor and your HDTV. Adjust

the screen resolution to t your HDTV. To change the screen resolution:

1. Do any of the following to open the

• Click

Display > Change display settings.

• Right click anywhere on your Windows desktop. When the pop-up

2. Adjust the resolution. Refer to the documentation came with your HDTV

3. Click

My speakers produce no sound.

?

• Ensure that you connect your speakers to the Line out port (lime) on the front

• Check if your speak is connected to a electrical source and turned on.

• Adjust your speakers’ volume.

• Ensure that your computer’s system sounds are not Muted.

• Connect your speakers to another computer to test if the speakers arer

menu appears, click Personalize > Display > Change display
settings.

for the resolution.

message.

panel or the rear panel.

• If it is muted, the volume icon is displayed as
sounds, click

• If it is not muted, click

working properly.

> Control Panel > Appearance and Personalization >

Apply or OK. Then click Keep Changes on the conrmation

from the Windows notication area, then click .

Screen Resolution setting screen:

. To enable the system

and drag the slider to adjust the volume.

ENGLISH

The DVD drive cannot read a disc.

?

• Check if the disc is placed with the label side facing up.

• Check if the disc is centered in the tray, especially for the discs with

non-standard size or shape.

• Check if the disc is scratched or damaged.

The DVD drive eject button is not respond.

?

1. Click > Computer.

2. Right-click

ASUS CM6630 63

, then click Eject from the menu.

ENGLISH

ENGLISH

Power

Problem Possible Cause Action

• Set your computer’s power voltage

No power
(The power
indicator is off)

Incorrect power voltage

Your computer is not
turned on.

Your computer’s power
cord is not properly
connected.

• Adjust the voltage settings. Ensure

Press the power key on the front panel
to ensure that your computer is turned
on.

• Ensure that the power cord is

• Use other compatible power cord.

switch to your area’s power
requirements.

that the power cord is unplugged
from the power outlet.

properly connected.

PSU (Power supply unit)
problems

Try installing another PSU on your
computer.

Display

Problem Possible Cause Action

No display
output after
turning the
computer on
(Black screen)

The signal cable is
not connected to the
correct VGA port on your
computer.

Signal cable problems Try connecting to another monitor.

• Connect the signal cable to the
correct display port (onboard VGA or
discrete VGA port).

• If you are using a discrete VGA
card, connect the signal cable to the
discrete VGA port.

64 Chapter 7: Troubleshooting

ENGLISH

LAN

Problem Possible Cause Action

Cannot access
the Internet

The LAN cable is not
connected.

LAN cable problems

Your computer is not
properly connected to a
router or hub.

Network settings

Problems caused by the
anti-virus software

Driver problems Reinstall the LAN driver

Connect the LAN cable to your
computer.

Ensure the LAN LED is on. If not,
try another LAN cable. If it still does
not work, contact the ASUS service
center.

Ensure that your computer is properly
connected to a router or hub.

Contact your Internet Service Provider
(ISP) for the correct LAN settings.

Close the anti-virus software.

Audio

Problem Possible Cause Action

Speaker or headphone is
connected to the wrong
port.

• Refer to your computer’s user
manual for the correct port.

• Disconnect and reconnect the
speaker to your computer.

ENGLISH

No Audio

ASUS CM6630 65

Speaker or headphone
does not work.

The front and back audio
ports do not work.

Driver problems Reinstall the audio driver

Try using another speaker or
headphone.

Try both the front and back audio
ports. If one port failed, check if the
port is set to multi-channel.

ENGLISH

ENGLISH

System

Problem Possible Cause Action

System speed is
too slow

The system often

hangs or freezes.

Too many programs are
running.

Computer virus attack

Hard disk drive failure

Memory module problems

There is not enough
air ventilation for your
computer.

Incompatible softwares are
installed.

Close some of the programs.

• Use an anti-virus software to

• Reinstall the operating system.

• Send the damaged hard disk

• Replace with a new hard disk drive.

• Replace with compatible memory

• Remove the extra memory

Move your computer to an area with

better air ow.

Reinstall the OS and reinstall
compatible softwares.

scan for viruses and repair your
computer.

drive to ASUS Service Center for
servicing.

modules.

modules that you have installed,
then try again.

66 Chapter 7: Troubleshooting

ENGLISH

CPU

Problem Possible Cause Action

Your computer is booting
up.

Too noisy right
after turning on
the computer.

Computer is too
noisy when in use.

If the problem still persists, refer to your Desktop PC’s warranty card and contact the ASUS
Service Center. Visit the ASUS Support site at http://support.asus.com for the service
center information.

The BIOS settings have
been changed.

Old BIOS version

The CPU fan has been
replaced.

There is not enough
air ventilation for the
computer.

The system temperature is
too high.

It is normal. The fan runs on its
full speed when the computer is
powering on. The fan slows down
after entering the OS.

Restore the BIOS to its default
settings.

Update the BIOS to the latest
version. Visit the ASUS Support
site at http://support.asus.com to
download the latest BIOS versions.

Ensure that you are using a
compatible or ASUS-recommended
CPU fan.

Ensure that your computer is

working in an area with good air ow.

• Update the BIOS.

• If you know how to reinstall the
motherboard, try to clean the inner
space of the chassis.

ENGLISH

ASUS CM6630 67

ASUS contact information

ASUSTeK COMPUTER INC.

Address 15 Li-Te Road, Peitou, Taipei, Taiwan 11259
Telephone [phone]
Fax [phone]
E-mail [e-mail]
Web site www.asus.com.tw

Technical Support

Telephone [phone]
Online support support.asus.com

ASUS COMPUTER INTERNATIONAL (America)

Address 800 Corporate Way, Fremont, CA 94539, USA
Telephone [phone]
Fax [phone]
Web site usa.asus.com

Technical Support

Telephone [phone]
Support fax [phone]
Online support support.asus.com

ASUS COMPUTER GmbH (Germany and Austria)

Address Harkort Str. 21-23, D-40880 Ratingen, Germany
Fax [phone]
Web site www.asus.de
Online contact www.asus.de/sales

Technical Support

Telephone (Component) [phone]*
Telephone (System/Notebook/Eee/LCD) [phone]*
Support Fax [phone]
Online support support.asus.com

* EUR 0.14/minute from a German xed landline; EUR 0.42/minute from a mobile

phone.

Manufacturer: ASUSTeK Computer Inc.

Address: No.150, LI-TE RD., PEITOU, TAIPEI 112,

Authorised representative in
Europe:

Address: HARKORT STR. 21-23, 40880 RATINGEN,

TAIWAN

ASUS Computer GmbH

GERMANY
