ASUS AP160R-S User Manual

AP160R-S

Pentium® 4 1U Rackmount Server

User Guide

Disclaimer/Copyrights

No part of this manual, including the products and software described in it, may be reproduced,
transmitted, transcribed, stored in a retrieval system, or translated into any language in any
form or by any means, except documentation kept by the purchaser for backup purposes, without
the express written permission of ASUSTeK COMPUTER INC. (“ASUS”).

ASUS PROVIDES THIS MANUAL “AS IS” WITHOUT WARRANTY OF ANY KIND, EITHER
EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED TO THE IMPLIED WARRANTIES
OR CONDITIONS OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE.
IN NO EVENT SHALL ASUS, ITS DIRECTORS, OFFICERS, EMPLOYEES OR AGENTS BE
LIABLE FOR ANY INDIRECT, SPECIAL, INCIDENTAL, OR CONSEQUENTIAL DAMAGES
(INCLUDING DAMAGES FOR LOSS OF PROFITS, LOSS OF BUSINESS, LOSS OF USE OR
DA T A, INTERRUPTION OF BUSINESS AND THE LIKE), EVEN IF ASUS HAS BEEN ADVISED
OF THE POSSIBILITY OF SUCH DAMAGES ARISING FROM ANY DEFECT OR ERROR IN
THIS MANUAL OR PRODUCT.

Product warranty or service will not be extended if: (1) the product is repaired, modified or
altered, unless such repair, modification of alteration is authorized in writing by ASUS; or (2) the
serial number of the product is defaced or missing.

Products and corporate names appearing in this manual may or may not be registered trademarks
or copyrights of their respective companies, and are used only for identification or explanation
and to the owners’ benefit, without intent to infringe.

The product name and revision number are both printed on the product itself. Manual revisions
are released for each product design represented by the digit before and after the period of the
manual revision number. Manual updates are represented by the third digit in the manual revision
number.

For previous or updated manuals, BIOS, drivers, or product release information, contact ASUS
at http://www.asus.com.tw or through any of the means indicated on the following page.

SPECIFICATIONS AND INFORMATION CONTAINED IN THIS MANUAL ARE FURNISHED
FOR INFORMA TIONAL USE ONL Y, AND ARE SUBJECT TO CHANGE A T ANY TIME WITHOUT
NOTICE, AND SHOULD NOT BE CONSTRUED AS A COMMITMENT BY ASUS. ASUS
ASSUMES NO RESPONSIBILITY OR LIABILITY FOR ANY ERRORS OR INACCURACIES
THAT MAY APPEAR IN THIS MANUAL, INCLUDING THE PRODUCTS AND SOFTWARE
DESCRIBED IN IT.

Copyright © 2002 ASUSTeK COMPUTER INC. All Rights Reserved.

Product Name: ASUS AP160R-S
Manual Revision: 1.01 E1068
Release Date: July 2002

2

Contents

Disclaimer/Copyrights ................................................................. 2

ASUS Contact Information .......................................................... 5

FCC/CDC Statements ................................................................... 6

Safety Precautions ....................................................................... 7

Introduction: About This Manual......................... 9

Audience ..................................................................................... 10

Contents ...................................................................................... 10

Conventions.................................................................................11

References ...................................................................................11

System Package Contents ........................................................ 12

Chapter 1: System Overview............................. 13

1.1 System Features................................................................ 14

1.2 Front Panel Features......................................................... 15

1.3 Rear Panel Features.......................................................... 15

1.4 Internal Features ............................................................... 16

Chapter 2: Hardware Setup ............................... 17

2.1 Removing and installing the chassis cover.................... 18

Removing the cover ............................................................ 18

Installing the cover .............................................................. 18

2.2 Motherboard Placement ................................................... 19

Placement Direction ............................................................ 19

Motherboard Screws ........................................................... 19

2.3 Installing a CPU ................................................................. 20

CPU Orientation .................................................................. 20

CPU Socket Location .......................................................... 20

Unlock the CPU Socket....................................................... 21

Insert the CPU..................................................................... 21

Secure the CPU .................................................................. 21

Install the Heatsink .............................................................. 22

2.4 Installing system memory ................................................ 23

DIMM sockets location ........................................................ 23

Install a DIMM ..................................................................... 23

3

Contents

2.5 Installing the backplane and bridge boards ................... 24

Bridge board........................................................................ 24

Backplane board ................................................................. 25

2.6 Installing a hard disk drive ............................................... 26

2.7 Installing a PCI card .......................................................... 28

2.8 Installing the front bezel and rack ears........................... 30

2.9 Installing CD-ROM and floppy drives .............................. 31

Chapter 3: Hardware Options ........................... 33

3.1 Cooling System ................................................................. 34

Fan locations ....................................................................... 34

Fan connectors.................................................................... 34

Fan cable connections ........................................................ 35

Removing the fans .............................................................. 36

3.2 Power connections ........................................................... 37

3.3 Removing the power supply ............................................ 38

Appendix A: Power Supply ................................ 39

A.1 General Description .......................................................... 40

A.2 Specifications .................................................................... 41

Input Characteristics............................................................ 41

Output Characteristics......................................................... 41

Over-Voltage Protection (OVP) ........................................... 41

Appendix B: Troubleshooting............................ 43

B.1 Simple Fixes ...................................................................... 44

4

ASUS Contact Information

ASUSTeK COMPUTER INC. (Asia-Pacific)

Address: 150 Li-Te Road, Peitou, Taipei, Taiwan 112
General Tel: [phone]
General Fax: [phone]
General Email: [e-mail]

Technical Support

MB/Others (Tel): [phone] (English)
Notebook (Tel): [phone] (English)
Desktop/Server (Tel): [phone] (English)
Support Fax: [phone]
Support Email: [e-mail]
Web Site: www.asus.com.tw
Newsgroup: cscnews.asus.com.tw

ASUS COMPUTER INTERNATIONAL (America)

Address: 6737 Mowry Avenue, Mowry Business Center,

Building 2, Newark, CA 94560, USA
General Fax: [phone]
General Email: [e-mail]

Technical Support

Support Fax: [phone]
General Support: [phone]
Web Site: www.asus.com
Support Email: [e-mail]

ASUS COMPUTER GmbH (Europe)

Address: Harkortstr. 25, 40880 Ratingen, BRD, Germany
General Fax: [phone]
General Email: [e-mail] (for marketing requests only)

Technical Support

Support Hotline: MB/Others: [phone]
Notebook (Tel): [phone]
Support Fax: [phone]
Support (Email): www.asuscom.de/de/support (for online support)
Web Site: www.asuscom.de

5

FCC/CDC Statements

Federal Communications Commission Statement

This device complies with FCC Rules Part 15. Operation is subject to the following
two conditions:

• This device may not cause harmful interference, and

• This device must accept any interference received including interference that
may cause undesired operation.

This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with manufacturer’s instructions, may cause harmful
interference to radio communications. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the interference by one
or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment to an outlet on a circuit different from that to which the
receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

WARNING! The use of shielded cables for connection of the monitor to the
graphics card is required to assure compliance with FCC regulations. Changes
or modifications to this unit not expressly approved by the party responsible
for compliance could void the user’s authority to operate this equipment.

Canadian Department of Communications Statement

This digital apparatus does not exceed the Class B limits for radio noise emissions
from digital apparatus set out in the Radio Interference Regulations of the Canadian
Department of Communications.

This class B digital apparatus complies with Canadian ICES-003.

6

Safety Precautions

Electrical Safety

IMPORTANT

•

Before installing or removing signal cables, ensure that the power
cables for the system unit and all attached devices are unplugged.

• T o prevent electrical shock hazard, disconnect the power cable from
the electrical outlet before relocating the system.

• When adding or removing any additional devices to or from the
system, ensure that the power cables for the devices are unplugged
before the signal cables are connected. If possible, disconnect all
power cables from the existing system before you add a device.

• If the power supply is broken, do not try to fix it by yourself. Contact
a qualified service technician or your dealer.

CAUTION

This product is equipped with a three-wire power cable and
plug for the user’s safety. Use the power cable with a properly
grounded electrical outlet to avoid electrical shock.

Operation Safety

IMPORTANT

• Any mechanical operation on this server must be conducted by
certified or experienced engineers.

• Before operating the server, carefully read all the manuals
included with the server package.

• Before using the server, make sure all cables are correctly
connected and the power cables are not damaged. If any
damage is detected, contact your dealer as soon as possible.

• To avoid short circuits, keep paper clips, screws, and staples
away from connectors, slots, sockets and circuitry.

• Avoid dust, humidity, and temperature extremes. Place the
server on a stable surface.

7

89ASUS AP160R-S 1U Rackmount Server

Introduction

“About This Guide” introduces the contents
of this document. This part includes the target
audience, chapter description, and
conventions used. It also lists other sources
of information that are not contained in this
manual.

About this guide

Audience

This user guide is intended for system integrators, and experienced users
with at least basic knowledge of configuring an entry-level server.

Contents

This guide contains the following parts:

1. Introduction: About this guide

This part introduces the contents of this document. It includes the target
audience, chapter description, and conventions used. It also lists other
sources of information that are not contained in this manual.

2. Chapter 1: System overview

This chapter describes the general features of the AP160R-S server. It
includes sections on front panel and rear panel specifications.

3. Chapter 2: Hardware setup

This chapter lists the hardware setup procedures that you have to perform
when installing system components.

4. Chapter 3: Hardware options

This chapter describes the optional hardware procedures that you may
have to do when configuring the system.

5. Appendix A: Power supply information

This appendix gives information on the 200-watt switching power supply
that came with the AP160R-S server.

6. Appendix B: Troubleshooting

This appendix lists the common problems that you may encounter while
using the AP160R-S server. It lists the possible causes of the problems
and offers solutions. You may refer to this part and try to solve simple
problems before calling customer support.

10

Introduction: About this guide

Conventions

Symbols

T o make sure that you perform certain tasks properly , take note of the following
symbols used throughout this manual.

WARNING: Information to prevent injury to yourself when trying to
complete a task.

CAUTION: Information to prevent damage to the components when
trying to complete a task.

IMPORTANT: Information that you MUST follow to complete a task.
NOTE: Tips and information to aid in completing a task.

References

Refer to the following sources for additional information and for product and
software updates.

1. ASUS NR-LSR Motherboard User’s Manual

This manual contains detailed information about the NR-LSR
motherboard.

2. ASUS Websites

The ASUS websites worldwide provide updated information on ASUS
hardware and softare products. The ASUS websites are listed in the ASUS
Contact Information on page 5.

3. Optional Documentation

Your product package may include optional documentation such as a
CD-ROM manual, warranty flyers, and others that may have been added
by your dealer. NOTE: These documents are not part of the standard
server package.

ASUS AP160R-S 1U Rackmount Server

11

System Package Contents

The following checklist enumerates the components included in the standard
system package.

1) ASUS 1U chassis (AR-12)

2) ASUS NR-LSR motherboard

3) 284W power supply

4) Backplane board (BP4LS-AR12)

5) PCI riser card (PCI64-3V-AR12)

6) Bridge board (BRIDGE-AR12)

7) Bridge board for SCSI RAID (BRIDGE/S-AR12)

8) 40x40x28 mm system fans (3 units)

9) Two fan modules each composed of 4 units of 40x40x28 mm fans

10) Front bezel and mounting ears

11) ASUS 1U rail kit

12) CPU heatsink

13) SCSI HDD trays (4 units)

14) Support CD that includes drivers, utilities, and ASUS Server
Web-based Management (ASWM)

15) User guides (for system and motherboard)

NOTE

If any of the above items is missing, contact your dealer.

12

Introduction: About this guide

Chapter 1

This chapter describes the general features
of the AP160R-S server. It includes sections
on front panel, rear panel, and internal
features of the server.

ASUS AP160R-S 1U Rackmount Server

System Overview

13

1.1 System Features

The ASUS AP160R-S is a stylish barebone server featuring the ASUS
NR-LSR motherboard. The server supports the Intel® Pentium® 4 processor
in a 478-pin socket, and includes the latest I/O, and video technologies through
the chipsets embedded on the motherboard.

Following are highlights of the server’s many features.

• Processor: Support for Intel

®

Pentium 4 processor with 400MHz FSB

and 512KB L2 cache

• Memory: Four DIMM sockets support up to 8GB of system memory
using registered ECC PC2100/PC1600 DDR DIMMs

• System Chipset: The Serverworks

®

Grand Champion Low End (GCLE)
SystemSet includes the Champion Memory and I/O Controller LE
(CMIC-LE) as the host bridge, the Champion South Bridge (CSB5) as a
PCI to Low Pin Count (LPC) bridge, and the Champion I/O Bridge
(CIOB-X2) that provides a high performance data flow path between
the IMB and the I/O subsystem.

• LAN Chipsets: The Intel

®

82544GC Gigabit Ethernet controller is an
integrated Ethernet LAN component that supports 1000Mbps, 100Mbps,
and 10Mbps data rates. The Intel 82550 Fast Ethernet controller fully
supports 10BASE-T/100BASE-TX networking protocols.

• SCSI Chipset: The LSI

®

53C1010R SCSI controller supports up to 30
Ultra-160 SCSI devices through the onboard dual-channel SCSI
connectors.

14

• VGA Chipset: The ATI

®

Rage-XL PCI-based VGA controller supports
up to 8MB PC-100 display SDRAM for 1280x1024 and true color
resolutions.

• Storage: Four 1” height, 3.5-inch width HDD drive bays

• Expansion: Two full-length 64-bit 133/100MHz PCI-X slots on a
proprietary riser card.

• Power Supply: 115V ac/230V ac 284-watt auto-switching power supply

Chapter 1: System Overview
