Asus 900HA User Manual

E4229

Eee PC

Windows® XP Edition

User’s Guide

Eee PC 900HD Series Eee PC 900HA Series

September 2008

Table of Contents

Chapter 1: Introducing the Eee PC

About This User’s Manual ............................................................................ 1-2

Notes for This Manual ................................................................................... 1-3

Safety Precautions ......................................................................................... 1-4

Transportation Precautions ...................................................................... 1-6

Charging Your Batteries .............................................................................. 1-6

Airplane Precautions ...................................................................................1-6

Preparing your Eee PC .................................................................................. 1-7

Chapter 2: Knowing the Parts

Top Side ............................................................................................................. 2-2

Bottom Side ...................................................................................................... 2-5

Right Side .......................................................................................................... 2-7

Left Side ............................................................................................................. 2-8

Rear Side ............................................................................................................ 2-9

Chapter 3: Getting Started

Power System .................................................................................................. 3-2

Using AC Power ............................................................................................. 3-2

Using Battery Power ....................................................................................3-3

Battery Care .................................................................................................... 3-5

Power Mode ...................................................................................................3-5

Touchpad Usage ............................................................................................. 3-7

Single-ﬁnger gesture input ....................................................................... 3-7

Multi-ﬁnger gesture input ......................................................................... 3-8

Keyboard Usage .............................................................................................. 3-9

Special Function Keys .................................................................................3-9

First-time Startup .........................................................................................3-11

Desktop ............................................................................................................3-14

ASUS EeePC Tray Utility ..............................................................................3-15

Enabling and Disabling Devices ............................................................3-15

Adjusting the display resolution ...........................................................3-16

Shutdown........................................................................................................3-17

Table of Contents

Chapter 4: Using the Eee PC

Network Connection ..................................................................................... 4-2

Conﬁguring a wireless network connection ....................................... 4-2

Conﬁguring a network connection ........................................................ 4-4

Browsing web pages .................................................................................4-10

ASUS Update ..................................................................................................4-11

Updating the BIOS through the Internet ...........................................4-11

Updating the BIOS through a BIOS ﬁle ...............................................4-13

Super Hybrid Engine

Super Hybrid Engine Modes ...................................................................4-14

Eee Storage .....................................................................................................4-15

Chapter 5: Support DVD & System Recovery

Support DVD information ........................................................................... 5-2

Running the support DVD ......................................................................... 5-2

Drivers menu .................................................................................................. 5-3

Utilities menu ................................................................................................. 5-3

Contact ........................................................................................................... 5-3

Other information ........................................................................................5-3

System Recovery ............................................................................................ 5-4

Using Hard Disk Partition (Eee PC 900HA model only) ................... 5-4

Using the Support DVD .............................................................................. 5-5

Boot Booster .................................................................................................... 5-7

(Eee PC 900HA model only) .....................................4-14

Appendix

Declarations and Safety Statements .......................................................A-2

Limitation of Liability ................................................................................. A-12

Service and Support ................................................................................... A-12

ASUS Eee PC

iii

Table of Contents

About This User’s Manual

Notes for This Manual

Safety Precautions

Preparing Your Eee PC

Introducing

the Eee PC

About This User’s Manual

You are reading the Eee PC User’s Manual. This User’s Manual provides information regarding the various components in the Eee PC and how to use them. The following are major sections of this User’s Manual:

1. Introducing the Eee PC

Introduces the Eee PC and this User’s Manual.

2. Knowing the Parts

Provides information on the Eee PC’s components.

3. Getting Started

Provides information on getting started with the Eee PC.

4. Using the Eee PC

Provides information on using the Eee PC’s utilities.

5. Support DVD & System Recovery

Gives you information on the support DVD and system recovery.

6. Appendix

Provides you safety statements.

1-2

The actual bundled applications differ by models and territories. There may be differences between your Eee PC and the pictures shown in this manual. Please accept your Eee PC as being correct.

Chapter 1: Introducing the Eee PC

Notes for This Manual

A few notes and warnings are used throughout this guide, allowing you to complete certain tasks safely and effectively. These notes have different degrees of importance as follows:

WARNING! Important information that must be followed for safe operation.

IMPORTANT! Vital information that must be followed to prevent damage to data, components, or persons.

TIP: Tips for completing tasks.

NOTE: Information for special situations.

ASUS Eee PC

1-3

Safety Precautions

The following safety precautions will increase the life of the Eee PC. Follow all precautions and instructions. Except as described in this manual, refer all servicing to qualiﬁed personnel. Do not use damaged power cords, accessories, or other peripherals. Do not use strong solvents such as thinners, benzene, or other chemicals on or near the surface.

Disconnect the AC power and remove the battery pack(s) before cleaning. Wipe the Eee PC using a clean cellulose sponge or chamois cloth dampened with a solution of nonabrasive detergent and a few drops of warm water and remove any extra moisture with a dry cloth.

DO NOT place on uneven or unstable work surfaces. Seek servicing if the casing has been damaged.

DO NOT expose to dirty or dusty environments. DO NOT operate during a gas leak.

DO NOT press or touch the display panel. DO NOT place together with small items that may scratch or enter the Eee PC.

DO NOT leave the Eee PC on your lap or any part of the body to prevent discomfort or injury from heat exposure.

DO NOT place or drop objects on top and do not shove any foreign objects into the Eee PC.

DO NOT expose to strong magnetic or electrical ﬁelds.

DO NOT expose to or use near liquids, rain, or moisture. DO NOT use the modem during electrical storms.

Battery safety warning: DO NOT throw the battery in ﬁre. DO NOT short circuit the contacts. DO NOT disassemble the battery.

1-4

Chapter 1: Introducing the Eee PC

SAFE TEMP: This Eee PC should only be used in environments with ambient temperatures between 5°C (41°F) and 35°C (95°F)

INPUT RATING: Refer to the rating label on the bottom of the Eee PC and be sure that your power adapter complies with the rating.

DO NOT carry or cover a Eee PC that is powered ON with any materials that will reduce air

Incorrect installation of battery may cause explosion and damage

the Eee PC. circulation such as a carrying bag.

DO NOT throw the Eee PC in municipal waste. This product has been designed to enable proper reuse of parts and recycling. The symbol of the crossed out wheeled bin indicates that the product (electrical, electronic equipment and mercury-containing button cell battery) should not be placed in municipal waste. Check local regulations for disposal of electronic products.

DO NOT throw the battery in municipal waste. The symbol of the crossed out wheeled bin indicates that the battery should not be placed in municipal waste.

ASUS Eee PC

1-5

Transportation Precautions

To prepare your Eee PC for transport, you should turn it OFF and

disconnect all external peripherals to prevent damage to the connectors. The hard disk drive’s head retracts when the power is

turned OFF to prevent scratching of the hard disk surface during transport. Therefore, you should not transport your Eee PC while the power is still ON. Close the display panel to protect the keyboard and display panel.

The Eee PC’s surface is easily dulled if not properly cared for. Be careful not to rub or scrape surfaces when transporting your Eee PC. You can put your Eee PC in a carrying case for protection from dirt, water, shock, and scratches.

Charging Your Batteries

If you intend to use battery power, be sure to fully charge your battery pack and any optional battery packs before going on long trips. Remember that the power adapter charges the battery pack as long as it is plugged into the computer and an AC power source. Be aware that it takes much longer to charge the battery pack when the Eee PC is in use.

Airplane Precautions

Contact your airline if you want to use the Eee PC on the airplane. Most airlines have restrictions for using electronic devices. Most airlines allow electronic use only between and not during takeoffs and landings.

There are three main types of airport security devices: X-ray machines (used on items placed on conveyor belts), magnetic detectors (used on people walking through security checks), and magnetic wands (hand-held devices used on people or individual items). You can send your Eee PC and diskettes through airport X-ray machines. However, it is recommended that you do not send your Eee PC or diskettes through airport magnetic detectors or expose them to magnetic wands.

1-6

Chapter 1: Introducing the Eee PC

Preparing your Eee PC

These are only quick instructions for using your Eee PC. Read the following chapters for detailed information.

1. Install the battery pack

2. Connect the AC power adapter

ASUS Eee PC

Remember to fully charge the battery (8 hours or more) before ﬁrst use and whenever it is depleted to prolong battery life. The battery reaches its maximum capacity after a few full charging and discharging cycles.

Your Eee PC may come with either a two or three-prong plug depending on territory. If a three-prong plug is provided, you must use a grounded AC outlet or use a properly grounded adapter to ensure safe operation of the Eee PC.

1-7

3. Open the display panel

4. Turn ON the Eee PC

1-8

When you open the display panel, do not force it down to the table or else the hinges may break! Never lift the Eee PC by the display panel!

Chapter 1: Introducing the Eee PC

Top Side

Bottom Side

Right Side

Left Side

Rear Side

Knowing the Parts

Top Side

Refer to the following illustration to identify the components on this side of the Eee PC.

2-2

The keyboard differs for each territory.

Chapter 2: Knowing the Parts

Microphone (Built-in)

The built-in mono microphone can be used for skype, voice

narrations, or simple audio recordings.

Built-in Camera

The built-in camera allows picture taking or video

recording.

Display Panel

The display panel functions the same as a desktop monitor.

The Eee PC uses an active matrix TFT LCD, which provides excellent viewing like that of desktop monitors. Unlike desktop monitors, the LCD panel does not produce any radiation or ﬂickering, so it is easier on the eyes. Use a soft cloth without chemical liquids (use plain water if necessary) to clean the display panel.

Power Switch

The power switch allows powering ON and OFF the Eee PC

and recovering from STR. Press the switch once to turn ON and hold it to turn OFF the Eee PC. The power switch only works when the display panel is opened.

Keyboard

The keyboard provides keys with comfortable travel (depth

at which the keys can be depressed) and palm rest for both hands.

Touchpad and Buttons

The touchpad and its buttons comprises a pointing device

that provides the same functions as a desktop mouse. Multi-ﬁnger gesture input is available to allow easy web and document navigation.

ASUS Eee PC

2-3

Status Indicators (front)

Power Indicator

The power indicator lights when the Eee PC is turned

ON and blinks slowly when the Eee PC is in the Save-toRAM (Suspend) mode. This indicator is OFF when the Eee PC is turned OFF.

Battery Charge Indicator

The battery charge indicator (LED) shows the status of

the battery’s power as follows:

Powered ON

Battery charge is between 100%–80% Battery charge is between 80%–10% Battery charge is less than 10%

Standby Mode / Powered OFF

Battery charge is between 100%–80% Battery charge is between 80%–10% Battery charge is less than 10%

AC Mode Battery Mode

Orange ON Green ON

Orange Blinking Slowly Green Blinking Slowly

Orange Blinking Quickly Green Blinking Quickly

AC Mode Battery Mode

Orange ON Off

Orange Blinking Slowly Off

Orange Blinking Quickly Off

2-4

The Battery Charge Indicator will not light when the battery is removed from your Eee PC.

Hard disk drive (HDD) Indicator

The hard disk drive indicator blinks when data is

written to or read from the disk drive.

Wireless Indicator

This is only applicable on models with built-in wireless

LAN. When the built-in wireless LAN is enabled, this indicator lights.

Chapter 2: Knowing the Parts

Bottom Side

Refer to the following illustration to identify the components on this side of the Eee PC.

The bottom side may vary in appearance depending on model.

ASUS Eee PC

The bottom of the Eee PC can get very hot. Be careful when handling the Eee PC while it is in operation or recently been in operation. High temperatures are normal during charging or operation. DO NOT use on soft surfaces such as beds or sofas ,which may block the vents. DO NOT PUT THE Eee PC ON YOUR LAP OR OTHER PARTS OF THE BODY TO AVOID INJURY FROM THE HEAT.

2-5

Battery Lock - Spring

The spring battery lock keeps the battery pack secure.

When the battery pack is inserted, it will automatically lock. When removing the battery pack, this spring lock must be retained in the unlocked position.

Battery Pack

The battery pack is automatically charged when connected

to an AC power source and maintains power to the Eee PC when AC power is not connected. This allows use when moving temporarily between locations. Battery time varies by usage and by the speciﬁcations for this Eee PC. The battery pack cannot be disassembled and must be purchased as a single unit.

Battery Lock - Manual

The manual battery lock is used to keep the battery pack

secured. Move the manual lock to the unlocked position to insert or remove the battery pack. Move the manual lock to the locked position after inserting the battery pack.

Hard Disk & Memory Compartment

The hard disk drive and memory are secured in a dedicated

compartment.

Reset Button (Emergency)

In case your operating system cannot properly turn OFF or

restart, the reset button can be depressed with a pin or a straightened paper clip to restart the Eee PC.

2-6

Audio Speaker System

The built-in stereo speaker system allows you to hear audio

without additional attachments. The multimedia sound system features an integrated digital audio controller that produces rich, vibrant sound (results improved with external stereo headphones or speakers). Audio features are software controlled.

Chapter 2: Knowing the Parts

Right Side

1 2

3 4

2.0

Refer to the following illustration to identify the components on this side of the Eee PC.

Memory Card Slot

The built-in memory card reader can read MMC/SD cards

from devices such as digital cameras, MP3 players, mobile phones, and PDAs.

USB Port (2.0/1.1)

The USB (Universal Serial Bus) port is compatible with USB

2.0 or USB 1.1 devices such as keyboards, pointing devices, cameras, and storage devices, connected in a series up to 12Mbits/sec (USB 1.1) and 480Mbits/sec (USB 2.0). USB allows many devices to run simultaneously on a single computer, with some peripherals acting as additional plug-in sites or hubs. Also, the USB supports hot-swapping function.

Display (Monitor) Output

The 15-pin D-sub monitor port supports a standard VGA-

compatible device such as a monitor or projector to allow viewing on a larger external display.

Kensington® Lock Port

The Kensington® lock port allows the Eee PC to be secured

using Kensington® compatible security products. These security products usually include a metal cable and lock that prevent the Eee PC to be removed from a ﬁxed object.

ASUS Eee PC

2-7

2 3 4

Left Side

2.0

Refer to the following illustration to identify the components on this side of the Eee PC.

LAN Port

The eight-pin RJ-45 LAN port (10/100M bit) supports a

standard Ethernet cable for connection to a local network. The built-in connector allows convenient use without additional adapters.

USB Port (2.0/1.1)

The USB (Universal Serial Bus) port is compatible with USB

2.0 or USB 1.1 devices such as keyboards, pointing devices, cameras, and storage devices, connected in a series up to 12Mbits/sec (USB 1.1) and 480Mbits/sec (USB 2.0). USB allows many devices to run simultaneously on a single computer, with some peripherals acting as additional plugin sites or hubs. Also, it supports hot-swapping function.

2-8

Microphone Jack

The microphone jack is designed to connect the

microphone used for Skype, voice narrations, or simple audio recordings.

Headphone Output Jack

The 1/8” stereo headphone jack (3.55mm) connects the Eee

PC’s audio out signal to ampliﬁed speakers or headphones. Using this jack automatically disables the built-in speakers.

Chapter 2: Knowing the Parts

Rear Side

1 2

Refer to the following illustration to identify the components on this side of the Eee PC.

Battery Pack

The battery pack is automatically charged when connected

Power (DC) Input

The supplied power adapter converts AC power to DC

power for use with this jack. Power supplied through this jack supplies power to the Eee PC and charges the internal battery pack. To prevent damage to the Eee PC and battery pack, always use the supplied power adapter.

CAUTION: MAY BECOME WARM TO HOT WHEN IN USE. BE SURE NOT TO COVER THE ADAPTER AND KEEP IT AWAY FROM YOUR BODY.

ASUS Eee PC

2-9

2-10

Chapter 2: Knowing the Parts

Power System

Touchpad Usage

Keyboard Usage

First-time Startup

Operating Mode

Shutdown

Getting Started

+ 53 hidden pages
