Commercial Audio Products
Description
The Astatic Model 61 1L is an omnidirectional, dynamic microphone designed
for hand held applications in quality sound installations. The frequency
response, especially tailored for voice communications, provides a crisp,
clear, highly intelligible sound. The Model 611L, with modern "tear drop"
styling, offers extreme reliability, convenient handling, rugged construction
and high performance for years of dependable service.
The dynamic cartridge has a rugged polyester diaphragm which resists
moisture, temperature extremes, most acids, alkalies and solvents. Molded
in high impact Cycolac, the Model 611L comes with a permanently attached,
heavy duty, four conductor , two shielded, coil cord. The 61 1L has a simple
to operate 2PDT long life, trouble free switch. The Model 611L has a low
impedance output and is factory wired normally open. The Model 611L
may be rewired in the field if a line shorting function is desired.
611L
OMNIDIRECTIONAL
DYNAMIC MICROPHONE
APPLICATIONS
The Astatic Model 611L, because of its' professional sound and rugged
construction, is an excellent choice for any application requiring a hand
held, microphone for public address in industrial and general applications,
such as factories, airports, lobbies, restaurants, warehouses, etc. and for
two-way communications in taxicabs, buses, construction, police and fire
vehicles, etc.
Page 2
Specifications
Element:
Dynamic
Pattern:
Omnidirectional
Frequency Response:
100 to 7500 Hz
Output Level:
-58 dB (0 dB = 1mw / 10 microbars)
-76 dB (0 dB = 1 volt / microbar)
1.6 mV/PA
Impedance:
400 ohms, matches 150 to 1000 ohms
Cable:
Four conductor, two shielded, permanently attached,
heavy duty, neoprene jacketed coil cord that extends
to 1.8m (6 ft.)
Switch:
Operated by press-to-talk lever, 2PDT long life, trouble free switch
with spring return, has smooth feel. Wired normally open
Housing:
Durable molded black Cycolac
Dimensions:
100mm (3-15/16") high x 75.4mm (2-3/32) wide x 54.8mm (2-5/32")
deep
Weight:
227 grams (8 oz.)
SPECIFICA TIONS FOR 61 1L
TWO-YEAR LIMITED W ARRANTY
Omnitronics, LLC (“ASTATIC”) hereby warrants that this product will be free of defects in material and workmanship for a period of two years
from the date of purchase. In the unlikely event a defect occurs AST ATIC will, at its option, either repair or replace with a new unit of equal or
greater value. You should retain proof of purchase to validate the purchase date and return it with any warranty claim. Return warranty claims
carefully packed, insured and prepaid to the Service Department at the address listed below.
This warranty excludes exterior finish or appearance, damage from abuse, misuse of the product, use contrary to ASTATIC’s instructions or
unauthorized repair. All implied warranties or merchantability or fitness for a particular purpose are hereby disclaimed and ASTATIC hereby
disclaims liability for incidental, special or consequential damages resulting from the use or unavailability of this product. YOU MUST HA VE A
RETURN AUTHORIZATION NUMBER TO RETURN THIS PRODUCT. PLEASE CALL (440) 593-1111 TO GET YOUR RETURN
AUTHORIZATION NUMBER. ALL RETURNS WITHOUT AN R.A. NUMBER WILL BE DECLINED.
This warranty gives you specific legal rights and you may also have other rights which vary from state to state. Some states do not allow the
exclusion or limitation of incidental or consequential damages or limitations on how long an implied warranty lasts, so the above exclusions and
limitations may not apply to you.
Note: No other warranty, written or oral is authorized by Omnitronics,LLC
46873-05-00/Rev.1/8-5-04/S.W.
