as - Schwabe 46986 User guide

Installation LED-lamp

IP65

Modell: 200W – Art. 46986

SAFETY WARNING

Please read before use and use in accordance with the safety instructions below.
Never attempt to change any cable connection way or any electronic parts inside lamp-very
important!

 This appliance is only suitable for fixed mounting. Suitable for indoor or outdoor use.
 The floodlight may not be used on a mast (pole). Can be installed onto fence, wall of the

door, Warehouse, shop or similar places.

 Do not mount the project onto the ceiling.
 Use the lamp with the supplied cable/plug, and grommet to ensure that the lamp stay

waterproof

 Replace the protection glass immediately if broken.
 Never attempt to change LED bulbs and inner parts unless a professional electronic

engineer.

 Class I luminaire need grounding.
 If external flexible cable or cord of this luminaire is damaged, it shall be exclusively

replaced by the
manufacture or his service agent or a similar qualified person in order to avoid a hazard.
 The electrical installation shall only be carried out by an electrical qualified person.

Installation

 Before mounting this LED flood light ensure that the mains voltage is switched off
 Should keep a reasonable distance from lighted objects when using. As shoow in Fig.3
 Try to avoid use the flooding to point downwards or gradients (Fig.4), but can adjuest to a

reasonable small angle

 To fix the floodlight onto normal project surfaces follow the instructuon as shown in Fig.2
 If cable damaged, please change cable according to below indication (Fig.1), connect the

yellow/green conductor of the connection supply cable with the connection block marked with
the earth symbol as show in Fig.1
 Try to avoid using lamp at an angle of more than 4 as shown in Fig.4, this may cause
some damage of lamp

Technical Details

220-240V ~ 50Hz Class I IP65, 4.000K

46986, MAX 200W – ca. 15.000 Lumen

Correct Disposal of this product
This marking indicates that this product should not be disposed with
other household wastes throughout the EU. To prevent possible
harm to the environment or human health from uncontrolled waste
disposal, recycle it responsibly to promote the sustainable reuse of
material resources. To return your used device, please use the
return and collection systems or contact the retailer where the
product was purchased. They can take this product for
environmental safe recycling.
