ASRock System Remote Control Quick Start Guide

System Remote Control

Quick Start Guide

Contents

1. IPMI (Intelligent Platform Management Interface) LAN

2. IPMI LAN IP address

3. Manage your System via IPMI over LAN (IOL)

4. BIOS setup for Serial over LAN (SOL)

5. Operating System Setup for Serial over LAN (SOL)

6. Control your System from remote site via Serial over LAN

(SOL)

1. IPMI (Intelligent Platform

Management Interface) LAN

a.) Connect your System to Local Area Network via System’s

MNG (dedicated IPMI LAN)port:

b.) For some ASRR Server Systems which support to NCSI

function, you can also connect your System to Local Area
Network via either System’s MNG or LAN1(shared IPMI
LAN ) port:

To check if your System’s LAN1 support NCSI function, please
refer to MB’s user manual.
For example, following is the MB’s user manual of 3U10G-F
System:

You can find if LAN1 support NCSI or not in Specifications page.
